Simplicity 1695764, 1695920 Operator's Manual
OPERATOR’S
Not for
Reproduction
MANUAL
Mini Cultivator
Mfg. No. Description
1695764 Mini Cultivator 43 cc 2-cycle
1695920 Mini Cultivator 43 cc 2-cycle
1695765SIM
Revision B
Not for
Reproduction
OPERATOR INSTRUCTIONS
Not for
Reproduction
Mini Cultivator
CONTENTS
Introduction .....................................................................................................................................................................4
Specifications .................................................................................................................................................................4
General Safety Rules .....................................................................................................................................................5
Unpacking and Assembly ...............................................................................................................................................9
Operating Your Mini Cultivator ......................................................................................................................................11
Maintenance .................................................................................................................................................................14
Troubleshooting ............................................................................................................................................................19
Warranty .......................................................................................................................................................................22
Page 3
OPERATOR INSTRUCTIONS
Not for
Reproduction
Mini Cultivator
INTRODUCTION
OWNER’S RESPONSIBILITY
Accurate assembly and safe and effective use of the mini cultivator or mini dethatcher is the owner’s responsibility.
• Read and follow all safety instructions.
• Carefully follow all assembly instructions.
• Ensure that anyone who uses the mini cultivator or mini dethatcher is familiar with all controls and safety
precautions.
• Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people, their
property, and themselves.
SPECIFICATIONS
ENGINE DISPLACEMENT
FUEL TANK CAPACITY
OIL/GAS RATIO
OIL TYPE
GAS TYPE
SPARK PLUG
SPARK PLUG GAP
TRANSMISSION
GEAR RATIO
TILLING WIDTH
TILLING DEPTH
TINE SPEED
WHEEL SIZE
UNIT SIZE L x W x
H (inches)
43cc
36 ounces
50:1 - 2.6 ounces per gallon
2 CYCLE ENGINE OIL
UNLEADED REGULAR GAS
BM6A
.028
GEAR DRIVE
32:1
6 inch minimum - 10 inch maximum
4 inch maximum
250 rpm
1.375 x 7.0 inch diameter
23” x 20” x 20”
Page 4
OPERATOR INSTRUCTIONS
Not for
Reproduction
Mini Cultivator
GENERAL SAFETY RULES
SPECIAL MESSAGES
Your manual contains special messages to bring attention
to potential safety concerns, machine damage as well as
helpful operating and servicing information. Please read
all the information carefully to avoid injury and machine
damage.
CAUTION
AVOID INJURY! THIS SYMBOL AND TEXT HIGHLIGHT
POTENTIAL HAZARDS OR DEATH TO THE OPERATOR
OR BYSTANDERS THAT MAY OCCUR IF THE HAZARDS
OR PROCEDURES ARE IGNORED.
IMPORTANT
AVOID DAMAGE! THIS TEXT IS USED TO TELL THE
OPERATOR OF ACTIONS OR CONDITIONS THAT MIGHT
RESULT IN DAMAGE TO THE MACHINE.
NOTE: General information is given throughout the
manual that may help the operator in the operation or
service of the machine.
IMPORTANT SAFETY PRECAUTIONS
Please read this section carefully. Operate the mini
cultivator accor ding to the safety i nstruct ions a nd
recommendations outlined here and inserted throughout
the text. Anyone who uses this mini cultivator must read
the instructions and be familiar with the controls.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
ENGINE EXHAUST FROM THIS PRODUCT CONTAINS
CHEMICALS KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER, BIRTH DEFECTS, OR OTHER
REPRODUCTIVE HARM.
This symbol points out important safety
instructions which if not followed could
endanger your personal safety. Read and
follow all instructions in this manual before
attempting to operate this equipment.
• Do not transport the mini cultivator from one place to
another with the engine running.
• The tines of the cultivator should not rotate when the
engine is idling. If it does rotate when engine is idling,
contact dealer for instructions.
• Dress appropriately when operating the cultivator. Always
wear sturdy footwear. Never wear sandals, sneakers, or
open shoes, and never operate the cultivator with bare
feet. Do not wear loose clothing that might get caught
in moving parts. Always wear safety glasses for eye
protection.
• Always keep hands, feet, hair and loose clothing away
from any moving parts on engine and cultivator.
• Always wear a protective hearing device.
• Do not allow children to operate this mini cultivator. Do
not allow adults to operate the mini cultivator without
proper instruction.
• Do not operate any power equipment under the influence
of alcohol or drugs.
• Keep all screws, nuts and bolts tight.
• Engine should be turned off and cool, spark plug wire
must be removed from spark plug before any repairs or
adjustments are attempted.
• Temperature of muffler and nearby areas may exceed
150° F (65° C). Avoid these areas.
• Never run engine indoors or in an enclosed area. Engine
exhaust contains carbon monoxide, an odorless and
deadly gas.
• Carefully inspect the area to be cultivated, and remove
all foreign objects. Do not cultivate above underground
utilities, including water lines, gas lines, electric cables,
or pipes. Do not operate the mini cultivator in soil with
large rocks and foreign objects which can damage the
equipment.
• If an object becomes lodged in the tines, turn engine off,
remove the wire from the spark plug and secure, allow
to cool before attempting to remove the foreign object.
• Keep the area of operation clear of all persons,
particularly small children, and pets.
Page 5
OPERATOR INSTRUCTIONS
Not for
Reproduction
Mini Cultivator
ENGINE SAFETY PRECAUTIONS
Warning Carbon Monoxide Poisoning
All engines contain carbon monoxide in their exhaust.
Carbon monoxide is a deadly, colorless, tasteless, odorless
gas which may be present even if you do not smell or see
any engine exhaust. Levels of carbon monoxide, which can
be deadly, can be present for days in an enclosed area
that has poor ventilation. Any level of carbon monoxide,
if inhaled, can cause headaches, drowsiness, nausea,
dizziness, confusion and eventually death. If you experience
any of these symptoms, seek fresh air and medical attention
immediately.
Preventing Carbon Monoxide Poisoning
• Never run engine indoors.
• Never try to ventilate engine exhaust indoors. Carbon
monoxide can reach dangerous levels very quickly.
• Never run engine outdoors where exhaust fumes may
be pulled into a building.
• Never run engine outdoors in a poorly ventilated area
where the exhaust fumes may be trapped and not easily
taken away. (Examples include: in a large hole or areas
where hills surround your working area.)
• Never run engine in an enclosed or partially enclosed
area. (Examples include: buildings that are enclosed
on one or more sides, under tents, car ports or
basements.)
• Always run the engine with the exhaust and muffler
pointed in the direction away from the operator.
• Never point the exhaust muffler towards anyone. People
should always be many feet away from the operation of
the engine and its attachments.
Gasoline Fires and Handling Fuel Safely
Fuel and fuel vapors are highly flammable. Never use fuel
where a spark or flame may be present. Never use fuel
where a potential source of ignition could occur. (Examples
include: hot water or space heaters, clothes dryer, electric
motors, etc.) Keep flames and sparks away from engine
and fuel to prevent fires. Fuel fires spread very quickly and
are highly explosive.
Prevention of Gasoline Fires
• Never fill your fuel tank with fuel indoors. (Examples
include: basement, garage, barn, shed, house, porch,
etc.)
• Always fill fuel tank outside in a well ventilated area.
• Never remove the fuel cap or add fuel with the engine
running. Stop engine and allow to cool before filling.
• Never drain fuel from engine in an enclosed area.
• Always wipe up excess (spilled) fuel from engine before
starting. Clean up spilled fuel immediately.
• If fuel is spilled, do not attempt to start the engine but
move the machine away from the area of spillage and
avoid creating any source of ignition until fuel vapors
have dissipated.
• Allow fuel fumes/vapors to escape from the area before
starting engine.
• Test the fuel cap for proper installation before starting
and using engine.
• Always run the engine with fuel cap properly installed
on the engine.
• Always unscrew gas cap vent screw while engine is
running.
• Never smoke while refilling engine fuel tank.
• Prevent fire and explosion caused by static electric
discharge. Use only nonmetal, portable fuel containers
approved by the Underwriter’s Laboratory (U.L.) or the
American Society for Testing & Materials (ASTM).
• Do not store engine with fuel in fuel tank indoors. Fuel
and fuel vapors are highly explosive.
• During storage, screw down gas cap vent screw
tightly.
• Never pour fuel from engine fuel tank.
• Never siphon fuel by mouth to drain fuel tank.
• Always have an adult fill the fuel tank.
• Never allow an adult or anyone under the influence of
drugs or alcohol to fill engine.
• Never allow children to fill the engine.
• Store fuel in containers specifically designed for this
purpose
• The clutch will transfer maximum power after about two
hours of normal operation. During this break-in period
clutch slippage may occur. The clutch should be kept
free of oil or other moisture for efficient operation.
BURNS AND FIRES
The muffler, muffler guard and other parts of the engine
become extremely hot during the operation of the engine.
These parts remain extremely hot after the engine has
stopped.
Page 6
Prevention of Burns and Fires
Not for
Reproduction
• Never remove the muffler guard from the engine.
• Never touch the muffler guard because it is extremely
hot and will cause severe burns.
• Never touch parts of the engine that become hot after
operation.
• Always keep materials and debris away from muffler
guard and other hot parts of the engine to avoid fires.
This engine is designed to operate using a catalytic
converter which contributes to the engine’s compliance
with the EPA.
Steps for Working on Engine or Mini Cultivator
1. Turn off engine switch.
2. Disconnect the spark plug wire from the spark plug.
3. Securely place the disconnected spark plug wire
away from the spark plug and any metal parts. This
must always be done or arcing may occur between
spark plug wire and metal parts.
4. Replace or repair the part on the engine or mini
cultivator.
5. Check all parts that were repaired, or removed during
repair, that they are secure and fit correctly.
NOTE: All repair parts must come from the factory.
Never replace parts that are not specically designed
for the engine or mini cultivator.
6. Replace spark plug wire.
OPERATOR INSTRUCTIONS
Mini Cultivator
CAUTION
HOT GASES ARE A NORMAL BY-PRODUCT OF A
FUNCTIONING CATALYTIC CONVERTER. FOLLOW ALL
SAFETY INSTRUCTIONS TO PREVENT BURNS AND
FIRES.
DO NOT ALTER/MODIFY ENGINE:
NEVER ALTER OR MODIFY THE ENGINE FROM THE
FACTORY. SERIOUS INJURY OR DEATH MAY OCCUR
IF ENGINE IS MODIFIED OR ALTERED.
WHEN WORKING ON OR REPLACING PARTS FOR THE
ENGINE OR MINI CULTIVATOR YOU MUST ALWAYS
DISCONNECT SPARK PLUG WIRE FROM THE SPARK
PLUG AND KEEP IT AWAY FROM THE SPARK PLUG.
USE EXTENSION CORDS AND RECEPTACLES AS
SPECIFIED BY THE MANUFACTURER FOR ALL UNITS
WI TH ELEC T RIC DRI V E MOTOR S OR ELEC TRIC
STARTING MOTORS.
NEVER ATTEMPT TO MAK E ANY ADJUSTMENTS
WHILE THE ENGINE (MOTOR) IS RUNNING (EXCEPT
WHERE SPEC IFIC ALLY RECOMM ENDE D BY THE
MANUFACTURER.)
Page 7
OPERATOR INSTRUCTIONS
Not for
Reproduction
Mini Cultivator
SAFETY DECAL
This mini cultivator has been designed and manufactured to provide you with the safety and reliability you would expect
from an industry leader in outdoor power equipment manufacturing.
Reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge to operate this equipment safely and effectively. We have placed a safety decal on the cultivator to remind you of some of this
important information while you are operating the unit.
This important safety decal is illustrated below, and is shown here to help familiarize you with the location and content of
the safety messages you will see as you perform normal cultivating operations. Please review this decal now, and if you
have any questions regarding its meaning or how to comply with these instructions, reread the complete safety instruction text in this manual, or contact your local dealer.
Should this decal become unreadable because of being worn, faded, or otherwise damaged during the use of your mini
cultivator, please use the part number information provided to order a replacement label from your local authorized
dealer. These decals are easily applied, and will act as a constant visual reminder to you, and others who may use the
equipment, to follow the safety instructions necessary for safe, effective operation of your mini cultivator.
Warning Decal on
Tine Shield
Page 8
Loading...
