Simplicity 1692014, 1692376, 1692375, 1691655, 1691662 User Manual
...Specifications and Main Features
- Supported Models:
- 12 HP Hydro (Mfg. No. 1691655)
- 12.5 HP Hydro (Mfg. No. 1692014)
- 16 HP Hydro (Mfg. No. 1691656, 1692375, 1692376)
- Mower Deck Options:
- 42" Mower Deck (Mfg. No. 1691662)
- 48" Mower Deck (Mfg. No. 1691663)
- Frame Group: Comprises Frame, Platforms, Rear Weights, Gas Tank.
- Steering Group: Comprises Steering Shaft, Steering Wheel, Arm Assembly and Bearings.
- Rear Axle & Rear Wheel Group: Comprises Rear Axle Drag Link Spindles and Steering Arm Assembly.
- Engine Group:
- For 12 HP: Engine Heat Shield Exhaust System Drive Pulley Electric Clutch Oil Drain.
- For 12.5 HP & 16 HP: Engine Heat Shield Exhaust System Drive Pulley Electric Clutch Oil Drain.
- Fuel System Group: Fuel Tanks Fuel Hose Shut-off Valves.
- Transmission Group: Comprises transmission fan control arm assembly and drive pulley.
- Drive Group: Pump mounting bracket clutch arm assembly drive belt.
- Differential & Front Wheels Group: Comprises Axle Assembly Brake Drum and Front Wheels.
- Brake & Clutch Group: Comprises Clutch Rod Brake Band, Rod and Link.
- Implement Lift Group: Lift Handle Cover Shaft Assembly
- Seat & Deck Group: Comprise Seat Deck Hinges and Latches.
- Console and Controls Group This includes the Shift Rod, Throttle Arm, Console and Control Rod.
- Electrical Group This consists of Front and Main Harness, Battery and Cables.
- Mower Housing and Cover Group This comprises Blades, Deflector, Housing Assys.
- Weight Options This includes rear weights.
- Compatibility Engine Parts compatible with the Briggs & Stratton are provided.
Frequently Asked Questions
- Q: What fuels the Hydro models?
A: The Hydro models are powered by Briggs & Stratton engines, rated at 12 HP, 12.5 HP and 16 HP respectively.
- Q: Is there an array of mower decks to select from?
A: There are two mower deck options available, 42 inches Appendix A2 and 48 inches Appendix A3.
- Q: Is it possible to maintain the fuel system, that is, manage the maintenance by myself?
A: Yes, this is possible since the fuel equipment system includes components such as fuel tanks and hoses which are accessible.
- Q: Is it right that the mower is self-propelled?
A: Yes, modulation with respect to its operation is achieved by the use of a hydrostatic transmission system.
- Q: Which method do I use to ensure the appropriate height of the mower is attained?
A: Mower height can be adjusted using the height adjusting and roller group to allow for different cutting height.
- Q: Where will I get parts for replacement for the engine?
A: These can be obtained from local dealers who stock briggs and stratton engines.
- Q: What are the devices on the machine that assure the safety of the user? Or what are the safety features installed?
A: The device is equipped with components that make the system secure as well, such as a seat operator switch.
