Simplicity 1690214, 1690367, 1690213, 1690212, 1690211 User Manual
...Specifications and Main Features
- Model No:710,712s,712h,716,716h,718h
- Geo Shift Clutch 4 speed (712s), Hydrostatic transmission (712h,716h,718h), 6 speed gearbox ( 710 & 716).
- Type (Kohler engines- one with options of different horsepower).
- Attachments: Rotary Mower, Vacuum Collector, Tiller, Snow Thrower.
- Safety and Security Consultant: Power take off disengagement, parking brake, operator safety interlock systems
- Type of fuel use: Regular non==leaded gasoline only
- Engine Oil : High quality detergent oil SC, SD, or CC qualification.
- Tire Pressure: Front- 10psi, Rears 8 psi.
- Lubrication: Multiple grease fittings, air cleaner maintenance.
- Dimensions: Not available in manual.
- Weight: Not available in manual.
- Recommended Maintenance Intervals:
- 5 hours: Clean engine intake air screen, check oil level.
- 25 hours: Change engine oil, check bevel gear box oil, check transmission fluid.
- 100 hours: Repack front wheel bearings, spark plugs,
- 200hours or yearly: Replace air cleaner element
Frequently Asked Questions
Q: which gasoline do i use for allis-chalmers 700 series tractors:
Please ensure only regular non-leaded gasoline is used.
Q: How long is the period in which I should replace the engine oil?
A: If the tractor is in operation, then the oil within the engine should exclusively be replaced once every 25 hours.
Q: What is the recommended tire pressure for the tractors?
A: The tire pressure should be set to 10 PSI for the front and 8 PSI for the rear tires.
Q: Are young adults able to drive the tractor?
A: No, it is not appropriate for young children to operate the tractor, there are highly specialized guidelines and protocols in place which dictate how to properly operate the tractor and only adults have the ability to adhere to these standards.
Q: The engine is unable to turn on, what do I do?
A: Ensure that all safety interlock switches are set properly, and check if the ignition key is in the correct position.
Q: What tools do I need in order to change the height of the mower?
A: The height can be easily adjusted with height control levers within the tractor, to increase the rotation clockwise and to lower the rotation which is anti clockwise.
Q: What tools do I need in order to change the height of the mower?
A: Ensure to keep distance between yourself, others, even pets, and the tractor, while operating the tractor it is also crucial to disengage PTO, and proper shoes should be on hand.
