Simplicity 163016, 20d118122 User Manual
Specifications and Main Features
- Model Deluxe Roticul
- Type Reversing Rotary Tiller
- Article No 990107
- Shipping Comes in two cartons
- Tilling Width Standard 20.5 inches or optional extension to 29 inches with some extra tines set.
- Engine support bracket Provided
- Frame assembly Rear frame assembly and an engine bracket with screws.
- Adjustments of wheel axles Two holes for change of handle height.
- Assembly of handles Lower and upper handles with supports.
- Control of throttle Cable and slidable lever are provided
- Clutch Lever functions for tines grip and reverse positioning of the grip.
- Depth bar adjustable for cutting depth: The cutting depth is not fixed but adjustable by the user at setting.
- Tine assemblies Inner sharp edged tines and outer ones.
- System of belts Special molded design for longer wear when used includes forward and reverse drive belts.
- Requirements for maintenance Oil bath air cleaner, special worm gear oil for lubrication.
- Weight Variable configuration and components may differ depending behavioral Weight.
Frequently Asked Questions
Q: What is the main purpose of the Deluxe Roticul?
A: The main purpose of the Deluxe Roticul is to serve as a reversing rotary tiller with a reverse feature to be able to rotate the belt for soil tilling as well.
Q: What is the maximum depth reach of the tiller?
A: It can be extended to a maximum of 29 with extra attachments making it an easy tool to use in working with the soil.
Q: The worm gear drive oil is used for applying what oil?
A: It is only possible to use worm gear oil, and refrain from using ordinary transmission oils.
Q: At what time intervals are users required to check the engine oil?
A: It is advisable to check engine oil before starting and in intervals of four to five hours of usage.
Q: For the user who is willing to, are they able to adjust the handles?
A: Indeed yes, there is a frame assembly which has two areas allowing it to adjust the handle height.
Q: Among the users what is the correct action to take if the belts grab when in use?
A: During use sprinkle fine dirt or sand on the belts and pulleys to help prevent the grabbing phenomenon.
Q: Is a grass tiller required to have regular maintenance checks done on it?
A: Yes, as part of maintenance procedures, regular inspections of elements such as the air cleaner, crankcase oil and worm gear drive lubrication have to be done.
