Simplicity 1008 User Manual
Specifications and Main Features
- Make: Simplicity
- Model No: 1008
- Engine:
Type: Briggs & Stratton
Horsepower: 8 HP (5.96 kW)
Displacement: 19.44 cu in (318.5 cc)
Cylinders: 1
Stroke: 2-3/4 inches (69.8 mm)
Bore: 3 inches (76.2 mm)
Cycles: 4
Crankshaft: Horizontal
Starter: Manual Rewind, Easy-Spin
Choke: Manual
Governor: Adjustable Mechanical Type 1800 3400 RPM
Ignition: Magneto
Lubrication: Gear Impeller System
Crankcase Capacity: 2-3/4 pints (1.3 L)
Fuel Tank Capacity: 4 quarts (3.7 L)
Air Cleaner: Reusable Oiled Foam Element
Muffler: Quiet, Low Back Pressure Type Side Discharge
- Transmission:
Type: Worm and Gear
Material:
- Worm: Steel
- Gear: Bronze
Bearings: Tapered Roller and Needle Anti-Friction Bearings.
Seals: Double Lip — Dirt Excluding
Lubrication: Special Worm Gear Oil, 12 ounces (355 ml)
Housing: Cast Iron
Speeds: One Forward One Reverse
- Clutch: Touch-O-Matic V-Belt
- Tines: Self-Sharpening, Slasher Typeshaper Tiller
Material: Forged, High Carbon Steel
Tilling Width: 23-1/2 inches (597 mm); Standard 35 inches (889 mm) with Tine Extension
- Shaft Attachment: Keys and Pins with Cotter Pins
- Tine Speed: 116 rpm at Ful Depending on the engine power, the speed can reach 116 RPM and the range can go deeper than 3 inches
- Rewind Starter and Choke: Integrated into the engine
- Throttle: Placed at the center of the handle panel
- Reverse Clutch: Left Handle
- Forward Clutch: Right Handle
- Handles adjustable height: There is an Adding feature of being able to link different handle locations too
- Tires: Semi-pneumatic Type, Size: 2.75 x 10 inch (70 mm x 254 mm)
- Frame: Welded steel channel
- Length: 53 inch (1.34 meter)
- Width or Diameter: 26 inch (660 mm) Width excluding tines extension key
- Height to top of Handle: 36 inch (914 mm)
- Net: 164 lbs (74.4 kg)
Specifications are subject to change without notice
Frequently Asked Questions
Q1: Does the tiller use any type of engine?
A1: Yes Briggs and Stratton tiller is employed as an engine and it is 8 horsepower strong engines
Q2: The device can be used to fissure detail with a certain width and depth what would those be?
A2: The device can be inputted to fissure at a width of 23-1/2 inches (597 mm) in between however able to achieve a depth of 0 to 203 mm with an adjustment key
Q3: Elucidate on the type of lubrication system implemented in the engine.
A3: An engine lubrication system based on a gear impeller is used in this case.
Q4: Describe the starting process of the tiller.
A4: A manual rewind, easy-spin starter is used to start the tiller.
Q5: Is the air cleaner able to be reused?
A5: The air cleaner, which is an oiled foam element, is reusable if it remains undamaged.
Q6: Touch-O-Matic controls for the tiller serve which purpose?
A6: Touch-O-Matic controls for the tiller allow for the immediate cessation of motion or the coupling of the drive.
Q7: What attachments can be used if I want to increase the tilling width?
A7: Tines extension attachments can be used to increase the width of the tilling to a maximum of 35 inches (889 mm).
Q8: What is the weight of the tiller?
A8: The tiller has a weight of net 164 lbs. (74.4 kg).
Q9: Will it also be possible to specify the sizing of the tires used for the tiller?
A9: The semi-pneumatic tires used in the tiller have the sizing of 2.75 x 10 inches (70 x 254 millimeters).
Q10: Is it possible to set a maximum limit to how deep the tilling can be done?
A10: A depth bar that is capable of being rotated backwards is adjustable for different tilling depths.
