Simplex LifeAlarm 4005 Series User Manual

LifeAlarm

®

Fire Alarm Control Panels

UL, ULC, CSFM Listed; FM Approved; 4005 Series Fire Alarm Control Panels
MEA (NYC) Acceptance* Providing 8 to 36 IDCs and 4 NACs

Features

Standard features:

• 80 Character, alphanumeric LCD readout with wide

viewing angle

• Eight, Class B Initiating Device Circuits (IDCs)

• Four, Class B Notification Appliance Circuits (NACs)

• 4 A power supply/battery charger

• Power-limited design

• Pluggable terminal blocks

• Internal DACT is included on UL listed models;

available separately as required for ULC listed models

Simplex® system accessory compatibility:

• 4602 Series Remote Control Unit (RCU) and Status

Command Unit (SCU), two-wire serial
communications

• 4601 Series Annunciators

• 4003 Voice Control Panels

• 4009 NAC Power Extenders

Software features:

• Menu-driven programming

• On-site programmable custom labels

• Four operator access levels

• Historical event logs

• Circuit selectable alarm verification

• WALKTEST™ one-person system testing**

• Selectable active status reminder

Optional expansion:

• Two circuit IDC, two circuit NAC/relay†

• Four circuit NAC/relay

†

• Four circuit IDC (low current and high current

versions)

• Four circuit Class A NAC or IDC zone conversion

• Eight circuit I/O module

• Remote station/city connection

• Additional 5 A power supply

UL Listed to Standard 864

* Refer to page 6 for additional ULC listing information. This product has been approved by

the California State Fire Marshal (CSFM) pursuant to Section 13144.1 of the California
Health and Safety Code. See CSFM Listing 7165-0026:212 for allowable values and/or
conditions concerning material presented in this document. It is subject to
re-examination, revision, and possible cancellation. Accepted for use – City of New York
Department of Buildings – MEA35-93E. See page 7 for ULC designations. Additional
listings may be applicable; contact your local Simplex product supplier for the latest
status. Listings and approvals under Simplex Time Recorder Co. are the property of Tyco
Safety Products Westminster.

FIRE

SYSTEM

SYSTEM

ALARM

ALARM

SUPERVISORY

TROUBLE

SILENCEDACPOWER

ALARM

SUPV

TROUBLE

ALARM

ACK

SYSTEM

ACK

ACK

SILENCE

RESET

CAUTION

DISCONNECT

BATTERY AND
A. C. POWER

BEFORE

SERVICING

Model 4005 Fire Alarm Control Panel

Introduction

For areas requiring eight to thirty-six IDC zones, Simplex
4005 series fire alarm control panels provide flexible
initiating circuit monitoring, extensive programmable
control capability, and LCD annunciated circuit-specific
custom labels. Surface mount components, efficient
microprocessor programming, and easy-to-use control
panel operation combine to provide an extensive feature
list in a compact, “installation friendly” package.

Panel status and circuit information is efficiently
indicated by an alphanumeric LCD readout featuring two
lines of 40 characters each. The panel control switches are
clearly marked for intuitive operation. Programming of
the selectable features is performed by using the display
and the panel control switches while in the programming
mode.

Applications

The 4005 series fire alarm control panel provides
protection for a wide variety of mid-size facilities in the
following fields: Educational, Health Care, Business,
Storage, Hospitality, Residential, and General Assembly.
Its modular design allows IDCs and NACs to be
incremented in groups of two or four to satisfy circuit
requirements without specifying excess capacity. If the
system expands, then additional “snap-in-place” modules
can be easily installed on-site.

** WALKTEST performance testing is protected under US Patent No. 4,725,818.

† NACs may be individually configured for dry contact relay operation.

NOTE: Contact your local Simplex product supplier for fire alarm control panels suitable for

Release Control applications.

S4005-0001-9 3/2009

4005 Module Features

The CPU board contains the main microprocessor and

panel programming, evaluates the status of all I/O
modules, processes the required responses, and provides a
watchdog timer that resets the panel in the event of an
abnormal operation. Additional details are below.

• Controls the LCD readout and switches that comprise

the operator interface

• Controls the flash EPROM that contains the non-volatile

site-specific programming informat i on

4-Wire Smoke Detector Power provides a 5 second

•

reset; rated 500 mA @ 24 VDC, open collector output,
and is power-limited and short circuit protected

Remote Unit Serial Interface (RUI) output provides

•

connections for up to 16, Class B supervised remote
annunciators, Remote Control Unit (RCU) model
4602-9102,or Status Command Unit (SCU) model
4602-9101; (see additional description under
Accessories on page 5)

Power Distribution Board Features:

• Provides connections for up to 5 plug-in module cards

Auxiliary power connections. Two power-limited

•

connections are provided, each rated for 2 A @ 24 VDC;
connections are isolated from NAC power

Power Supply/Battery Charger features:

• Switch Selectable for 120 or 240 VAC

24 VDC Power, regulated and power-limited, is

•

available specifically for notification appliances and
auxiliary output use via two taps of 2 A each; rated 4 A
for Special Application Appliances and 2 A for
Regulated 24 DC power

Internal System Operating Power is supplied via

•

separate power-limited connections.

Battery Charging for up to 18 Ah batteries mounted

•

within the 4005 cabinet and up to 33 Ah batteries when
mounted in an external battery cabinet.

Function Monitoring. Includes: missing, depl et ed, an d

•

low battery, Earth fault detection, AC power loss, AC
power brownout (low input voltage), signal power
overload, supply voltage monitoring, and charger failure.

Depleted Battery Trouble Indication advises when

•

standby operation has exceeded battery capacity.

Internal DACT Module features:

• Reports Alarm, Supervisory, Trouble, and AC Failure

• Dual line operation with automatic 24 hour test and

programmable power fail report delay

Eight, Initiating Device Circuits (IDCs) features:

• Two, 4 circuit IDC plug-in modules are standard,

providing 8, Class B IDCs

• Standard IDCs are low current and support up to 20

Simplex detectors per IDC at 2 mA maximum (for
detectors with relay bases, use high current expansion
modules, see chart on page 7)

4005 Module Features (Continued)

IDC operation is individually programmable with

the following 28 operating mode choices (the abbreviated
description is part of the IDC display information):

Point Type Description Point Type Description
FIRE

WATER
HEAT Heat Detector S2STAGE 2 Stage Monitor
DUCT Duct Detector SO

FLAME Flame Detector SC

PULL

SMOKE Smoke Detector WSC

EMERG

SFIRE

VFIRE

SPULL

VSPULL

GENMON

SGENMON

Notification Appliance Circuits (NACs)

Fire Monitor
Zone

WaterFlow
Monitor

Manual Pull
Station

Monitor-Fire
Emergency

Monitor­Smoke/Fire

Monitor-Verified
Smoke/Pull

Monitor­Smoke/Pull

Verified
Smoke/Pull

Generator
Monitor

Supervisory
Generator

FPUMP

SFPUMP

WSO

SUPV

UTIL Utility Monitor

TROUBLE Trouble Monitor

VSMOKE

GVMON

LATSUPV

STYLEC

Fire Pump
Monitor

Supervised Fire
Pump

Sprinkler
Normally Open

Sprinkler
Normally Closed

Waterflow/
Sprinkler Open

Waterflow/
Sprinkler Closed

Supervisory
Monitor

Verified Smoke
Detector

Generic Verified
Zone

Supervisory
Latching

Monitor-Style C
Monitor

One, 4 circuit NAC/Relay plug-in module is standard,
providing 4, Class B NACs that can be individually
reconfigured for dry contact relay operation.

NAC operation is individually programmable

as

Steady Signaling, Temporal Pattern, March Time @
20 BPM, or March Time @ 120 BPM, and with the
following 17 operating modes (the abbreviated
description is part of the NAC display information):

Point Type Description Point Type Description
SSIGNAL

RSIGNAL

TSIGNAL

BSIGNAL

SVISUAL

RVISUAL
CODED Coded Signal AHUF AHU Off Relay

SIGNAL Signal Circuit DHOLDER Door Holder
SWATER

Fire Signal (On
until Silence)

Fire Signal (On
until Reset)

Trouble (On
until Clear)

Trouble (On
until ACK)

Visual (On until
Silence)

Visual (On until
Reset)

WaterFlow (On
until Silence)

RWATER

SUPV

PRIMARY

ALTERN

AHUR AHU Relay

AHUO AHU On Relay

WaterFlow (On
until Reset)

Sprinkler
Supervisory
Signal

Elevator Capture
(primary

Elevator Capture
(alternate)

2 S4005-0001-9 3/2009

NAC Relay Mode Operation

NAC/Relay Selection. Each NAC can be on-site

selected for NAC operation or for unsupervised, dr y
contact, auxiliary relay operation. When operating in the
relay mode, either the normally open or the normally
closed contact can be connected to the output terminal
block. Contacts are rated at 2 A @ 32 VDC, for transient
suppressed loads.

Relay Operation is individually programmable with the
following 17 operating mode choices (the ab breviated
description is part of the relay display information).

Relay Modes:

Point Type Description Point Type Description
RELAY Auxiliary Relay

PRIMARY

ALTERN

AHUR AHU Relay
AHUO AHU On Relay CODED Coded Relay

AHUF AHU Off Relay

SRELAY

RRELAY

TRELAY

Elevator Capture
(Primary)

Elevator Capture
(Alternate)

Fire Relay (On
until Silence)

Fire Relay (On
until Ack)

Trouble Relay (On
until Clear)

BRELAY

DHOLDER Door Holder

SVISUAL

RVISUAL

SWATER

RWATER

SUPV

Trouble Relay
(On until Ack)

Visual (On until
Silence)

Visual (On until
Reset)

Waterflow Relay
(On until
Silence)

Waterflow Relay
(On until Reset)

Supervisory
Relay

4005 Basic Operator Functions

Display Indications. Upon receiving an abnormal

condition of alarm, supervisory, or trouble, the 80
character backlit LCD will identify the quantity and type
of abnormal indications. With the locked door closed, the
display, status LEDs and primary operator switches are
visible through the transparent door viewing panel as
shown in Figure 1 below. This figure represents the LCD
during normal conditions showing normal status, time,
and date.

FIRE

ALARM

ALARM

ACK

Figure 1. Basic Operator Function Keys with Normal

SYSTEM

SUPERVISORY

SUPV

ACK

SYSTEM

TROUBLE

TROUBLE

ACK

ALARM

SILENCED

ALARM

SILENCE

Display of Status, Time, and Date

AC

POWER

SYSTEM

RESET

4005 Basic Operator Functions (Continued)

Typical Displays. Figure 2 (below) represents typical

fire alarm display screens. For this example, the presence
of three fire alarm conditions is shown in the top screen –
fire zones 2, 7, and 6, displayed in chronological order of
occurrence (up to 10 zones may be shown). The display
will alternate with the one shown below it as the operator
is prompted to assist with the next required action.

Figure 2. Typical 4005 Displays with Alarm Activity

Alarm, Supervisory, and Trouble ACK

Operator Actions. The ALARM ACK, SUPV ACK, or

TROUBLE ACK key will silence the local tone-alert,
corresponding to the type of abnormal condition.
Subsequent entry of the appropriate ACK key will
chronologically scroll through the specifics for each
abnormal condition. Screen information includes custom
labels for each zone that provides a detailed report of the
location, device type description, device condition, and
list count for the first point in the Alarm, Supervisory, or
Trouble list.

Custom Label Display. Figure 3 represents a typical
screen that would appear after using the ALARM ACK
key to scroll to the first fire condition. It displays the zone
location as “First Floor East Wing Room 12”, the device
type as “Smoke Detector” and the device condition of
“Alarm”. The 1/3 indicates that the displayed alarm is the
first of three alarms present in the panel at this time.
Site-specific labels can be upper or lower case and can
provide discrete annunciation that can assist fire response
with clearly defined zone locations and device types.

Figure 3. Typical 4005 Fire Alarm Information Custom

Label Display

Alarm Silence. The ALARM SILENCE key will
silence the notification appliances programmed for
on-until-silence (typically audible notification appliances)
and the ALARM SILENCED LED will remain
illuminated until the panel is reset.

System Reset. When the source of the abnormal
condition is corrected, the SYSTEM RESET key will
reset the panel and return the status to normal.

3 S4005-0001-9 3/2009

4005 Expanded Operator Functions and Programming Information

FIRE

ALARM

ALARM

ACK

Menu Function

SYSTEM

SUPERVISORY

SUPV

ACK

Disable

Enable

Exit

Clear

Figure 4. The Complete 4005 Operator Interface

Passcode Access, Four Levels

Level 1 is basic access and is available by unlocking the

door. Access includes the standard operator functions and
historical log information.

Levels 2 and 3 are on-site programmable to control
functions required by local needs such as clock set,
enable/disable, WALKTEST system test, and custom
label changes.

Level 4 access provides passcode programming of
critical life safety functions, access level programming,
and service level diagnostics and programming.

Expanded Operator Functions

Unlocking the door provides access to the operator
control panel and reveals nine additional keys used for
expanded operator functions and for circuit type and
programming selections (refer to Figure 4 above).

The following expanded operator functions are available:
Circuit Disable/Enable, available for each individual

IDC, NAC, or relay circuit.
WALKTEST Performance Testing allows a single

fire alarm system tester to manually initiate remote alarms
and troubles and obtain a verification output from the
NACs with an automatic Reset. Alarms are initiated to
produce a pulse count that identifies the zone. With the
zone number confirmed, troubles can be then initiated
with a common pulse output for a complete functional test
of each zone.

Indicator Test confirms that all panel LED and LCD
indicators are properly functioning.

History Logs provide up to 50 fire alarm logs and up to
100 trouble logs. They are available for chronological
review as fire, trouble, or fire and trouble combined.

SYSTEM

TROUBLE

TROUBLE

ACK

ALARM

SILENCED

ALARM

SILENCE

Previous NextEnter

AC

POWER

SYSTEM

RESET

Programming Operations

NOTE: During programming, monitoring remains active

and the 4005 will perform enabled responses.

Programmable operations include:

• Abort Enable; 30 second delay allows zone status

confirmation before enabling

• Alarm Cutout time delay

• Active Status Reminder (Alarm/Supervisory/Trouble

Resound every 8 hours)

• Alarm Silence Inhibit Timer

• Assignment and selection of passcodes and access

levels

• Custom control equations

• Custom label generation and revision

• Doorholder time d e lay (drop upon Alarm, drop upon

AC power loss)

• IDC circuit type (reference list on page 2)

• Module allocation and identification

• NAC or Relay circuit type (reference lists on pages 2

and 3)

• NAC/Relay output coding of: Steady Signaling,

Temporal Pattern, March Time @ 20 BPM, or March
Time @ 120 BPM

• Setting of time and date, and selection of 12 or 24

hour format

Menu Selection and Response Keys

The 4005 LCD provides menu driven prompts for
performing functions. Navigating through the menu is
easily performed by using the operator keys at the bottom
of the interface panel (see Figure 4 above).

Menu always produces the main menu.
Function provides a list of the available actions that can

be performed depending on which pro gram ming or
functional area is being displayed.

(continued next page)

4 S4005-0001-9 3/2009

Menu Selection and Response Keys (Cont’d)

Disable/Enable toggles status of the displayed circuit.
Exit/Clear provides a path out of the chosen menu and

allows manual entries to be cleared.
Enter confirms the selection made and enters program

changes into memory.
Left, Previous, Next, and Right arrow keys move the

display cursor or select screens or specific choices,
depending on the displayed functional area.

4005 System Optional Modules

Class A, 4 Circuit Adaptor Module for either IDCs
or NACs (4005-9806):

• Individually isolated circuit design adapts either IDCs or

NACs for Class A operation allowing a combination of
circuit types

• Mounts on top of the module, maintaining full module

capacity

Power Distribution Module (4005-9807):

• Extends 4005 capacity to ten plug-in modules

• Mounts on left side of 4005 chassis

• Required when plug-in module requirements extend

beyond five and/or for connection of expansion power
supply 4005-9813

City Circuit Module (4005-9809):

• Single circuit, selectable as local energy, reverse

polarity, or form “C” contact

• Reverse polarity is selectable for Alarm/Trouble, Alarm,

Supervisory, or Trouble only reporting

• Up to two modules mount directly to 4005 chassis below

the CPU assembly

Expansion Power Supply (4005-9813):

• Provides power-limited and regulated 24 VDC to

Expansion Module 4005-9807; rated 5 A for Special
Application Appliances and 2 A for Regulated 24 DC
power

• Installs on the left side of the 4005 chassis and fits

behind expansion modules, allowing full module
capacity

• Switch selectable for 120 VAC or 240 VAC

• Provides additional power for notification appliances,

4-wire detectors, annunciator power, or other fire alarm
auxiliary functions

4005 System Capacity Expansion Modules

Optional and expansion modules can be easily installed and
programmed on-site. Their “snap-in-place” design installs
without tools or hardware, allowing configuration for the
initial system capacity or for later system expansion.

2 Circuit IDC with 2 Circuit NAC/Relay
(4005-9803):

• Two, standard low current IDCs, for up to 20 detectors

per IDC, 2 mA maximum

Capacity Expansion Modules (Continued)

• Two circuits, individually on-site selectable as either

Class B NAC, or N.O. or N.C. relay circuits

• Combined on one plug-in module

• Operation and programming is the same as the standard

control panel IDCs and NAC/Relay circuits

4 Circuit IDC Module (4005-9804):

• Four, standard low current IDCs on one plug-in module,

for up to 20 detectors per IDC, 2 mA maximum

• Operation and programming is the same as the standard

control panel IDCs

4 Circuit NAC/Relay Module (4005-9805):

• Four, NAC/Relay Circuits on one plug-in module

• Operation and programming is the same as the standard

control panel NAC/Relay circuits

8 Circuit I/O Module (4005-9808):

• Select each circuit as either an input or output

• Input mode supervises hard wired connections to 4601

Series annunciator switches or utility switch inputs

• Output mode is rated 24 VDC, 150 mA open co llector

driver, short circuit protected, UL listed for pilot duty

• Output mode provides supervised auxiliary control of a

compatible annunciator or remote relay for emergency
control in accordance with NFPA 72 and NFPA 101

4 Circuit IDC, High Current, Required for
Detectors with Relay Bases (4005-9824):

• Four, high current IDCs on one plug-in module

• High current operation for up to 30 detectors per IDC,

3 mA maximum detector power (required for detectors
with relay bases)

• Operation and programming is the same as the standard

control panel IDCs

Accessories

4602 Series Annunciators:

• Supervised serial communications using twisted,

shielded pair

• SCU has 16 LED zone status indicators

• RCU has 8 LED zone status indicators, Power-On LED

and Trouble LED, Local tone-alert, and keyswitch
enabling of Trouble and Alarm Silence, System Reset,
and Manual Evacuation

4601 Series Annunciators:

• Provides LED status indications and switches for

acknowledge, silence, and reset

• Modular design allows sizing as needed

4005-9150 and 4002 Adapter Kits for Retrofit:

• Replace existing 4002 Fire Alarm Control Panels with

the 4005 panel features, supplied with high current IDC
modules for convenient retrofit

• Cabinet, door, and electronics may be ordered separately

to satisfy early cabinet (backbox) installation
requirements

5 S4005-0001-9 3/2009

4005 Product Selection (refer to page 7 for specifications details)

Category Model Description

Panel with
Cabinet

* 4005-9101C is the ULC English version; 4005-9101CF is the ULC French version; both 4005-9101C and 4005-9101CF models delete the

Dual Line DACT and include low battery cutout operation.

Category Model Description

Electronics Only 4005-9150

Optional Modules

4005-9101* Beige cabinet

4005-9102 Red cabinet

4005 Fire Alarm Control Panel, 8 high current IDCs, 4 NAC/Relay Circuits, 4 A power supply,
internal Dual Line DACT; requires 4002 Adapter Kit or separately ordered cabinet and door

4005-9806

4005-9807

Four Circuit Class A Adapter Module for IDC and/or NAC modules, standard or expansion;
mounts on top of plug-in IDC/NAC module; circuits convert either NAC or IDC, or combination

Additional Five Slot Power Distribution Module, required when plug-in
module count exceeds five, or for connection of Expansion Power Supply

4005-9809** Single (1) Circuit City Module, chassis mounted, below CPU Qty, 2 Max.**
4005-9810**

Internal Dual Line DACT; aftermarket add-on; for connecting to RJ31X Telco
jacks, includes two DACT Cables with RJ45 Plug, 14 ft long (4.3 m)

Expansion Power Supply, 24 VDC, 5 A, regulated; chassis mounted beneath

4005-9813

left side modules; requires 4005-9807 Power Distribution Module and
provides power to 4005-9807 only

** DACT module is standard equipment on 4005-9101 and 4005-9102. Operation allows for either a DACT module or one or two City

Connection modules. The DACT is programmed using a terminal or a laptop computer in terminal emulation mode. Connection and
programming details are provided with Installation Instructions 574-049.

Expansion
Modules

(capacity is 10
expansion slots, 3
expansion slots are
used in base panel)

Cabinets

Doors

Batteries

select one model
number;

two
required for
24 VDC system

see page 7

power;

for currents

4005-9803 Standard Operation, 2 Circuit IDC with 2 NAC/Relay circuits
4005-9804 Standard Operation, 4 Circuit IDC Module
4005-9805 4 Circuit NAC/Relay Module
4005-9808 8 Circuit Programmable I/O Module
4005-9824 4 Circuit IDC Module, high current operation, Class B, for detectors with relay bases
2975-9209 Beige 4005 Cabinet

2975-9210 Red 4005 Cabinet
4005-9857 Beige Door
4005-9858 Red Door

Model Description Model Description

2081-9272 6.2 Ah Battery, 12 VDC 2081-9288 12.7 Ah Battery, 12 VDC
2081-9274 10 Ah Battery, 12 VDC 2081-9275 18 Ah Battery, 12 VDC
2081-9271 33 Ah Battery, 12 VDC; requires External Battery Cabinet 4009-9802

External Battery Cabinet, beige with solid door; includes battery harness; mounts close-nippled

4009-9802

to 4005 cabinet; for up to 33 Ah batteries; cabinet size:
25-3/4” W x 20-3/4” H x 4-1/8” D (654 mm x 527 mm x 105 mm)

4002 Adapter Kits

(for mounting
4005-9150
electronics into a
Simplex Model 4002
cabinet)

4005-9850
4005-9851
4005-9852
4005-9854

Two Unit
Four Unit
Six Unit
Four Unit 4002 Cabinet size, includes 4005 chassis adapter plate with red retainer panel

4081-9004 6.8 kΩ, 1/2W, End-of-Line Resistor Harness for standard IDCs; (ref. 733-886)
4081-9002 3.3 kΩ, 1 W, End-of-Line Resistor Harness for high current IDCs; (ref. 733-893)
4081-9008 10 kΩ, 1/2 W, End-of-Line Resistor Harness for NACs; (ref. 733-894)
4081-9001 2.2 kΩ, 1/2 W, End-of-Line Resistor Harness for 8 Pt I/O input mode; (ref. 733-892)

4005 Accessory

Selection

Reference

4081-9007 1.2 kΩ, 1 W, End-of-Line Resistor Harness for N.O. tamper switch monitoring; (ref. 733-891)
4602-9101 Status Command Unit (SCU), 16 LED serial connection annunciator

Remote Command Unit (RCU), 8 LED serial connection annunciator with remote tone-alert and

4602-9102

control panel status LEDs, and switch control for Trouble and Alarm Silence, System Reset,
and Manual Evacuation (4602 Series Annunciators are available for multiple packaging
applications, for further information, refer to data sheets S4602-0001 and S4602-0004)

4601 Series

LED/Switch Annunciators, modular design allows selection of required LEDs and control
switches (refer to data sheet S4601-0002)

4005 Fire Alarm Control Panel; includes 8 standard IDCs, 4 NAC/Relay
circuits, 4 A power supply/battery charger, cabinet and door, and internal Dual
Line DACT with two RJ45 plug DACT Cables, 14 ft long (4.3 m)

Qty, 1 Max.

Qty, 1 Max.**

Qty, 1 Max.

Order cabinets if required for pre-installation. 4005-9150
Electronics only model requires a cabinet and door or a 4002
Adapter Kit.

4002 Cabinet size

Includes 4005 chassis adapter plate with beige retainer
panel

6 S4005-0001-9 3/2009

Specifications

Electrical

Standard Panel Input (Switch Selectable)

Main Power Supply Output*

Expansion Power Supply Input (Switch Selectable)

Expansion Power Supply Output*
NAC Operation, Per Circuit 2 A maximum

Special Application Appliances

Regulated 24 DC Appliances

8 Circuit I/O Module

Input Mode Dry Contact, supervised with 2.2 kΩ end-of-line resistor 4081-9001

Output Mode 24 VDC, 150 mA, open collector

Relay Operation, N.O./N.C. 2 A @ 32 VDC
Resettable 4-Wire Smoke Detector Power 24 VDC, 500 mA, open collector
Auxiliary Power Connections (two taps) 2 A; maximum each tap, power-limited; 18.7 to 32 VDC

Wiring and
Environmental

Wiring Terminal Blocks Pluggable type, wire size is 18 to 12 AWG (0.82 mm2 to 3.31 mm2 )

Operating Temperature 32° F to 120° F (0° C to 49° C)

Operating Humidity Range Up to 93% RH, non-condensing @ 100°F (38° C)

*NOTE: Power supply output currents listed are entirely available for NAC appliances and auxiliary equipment. 4005 modules are

powered from separate circuits.

See Field Wiring Diagram 841-990 and Installation Instructions 574-068 for additional detail.

102–132 VAC, 60 Hz; 2 A maximum
204–264 VAC, 50/60 Hz; 1 A maximum

4 A for Special Application Notification Appliances
2 A for Regulated 24 VDC Notification Appliances

102–132 VAC, 60 Hz; 3 A maximum
204–264 VAC, 50/60 Hz; 1.5 A maximum

5 A for Special Application Notification Appliances
2 A for Regulated 24 VDC Notification Appliances

Simplex 4901, 4903, 4904, and 4906 Series non-addressable horns, strobes,
and combination horn/strobes and speaker/strobes (contact your Simplex
product representative for compatible appliances)

Power for other applicable UL listed appliances; use associated external
synchronization modules where required

Battery Requirements

Module

4005-9101 & -9102 † Includes 2, 4005-9804 & 1, 4005-9805 135 293
4005-9101C & CF † Includes 2, 4005-9804 & 1, 4005-9805 168 328
4005-9150 † Includes 2, 4005-9824 & 1, 4005-9805 141
Separate Modules; Standard, Optional, and Expansion; see NOTES ( ) below

4005-9806, Class A Adapter 1 x = 33 x =
4005-9807, Expansion Power Distribution Module 1 x = 1 x =
4005-9809, 1 Circuit Remote Station/City Connect 11 x = 22 x =
4005-9813, Expansion Power Supply 12 x = 12 x =
4005-9803, 2 IDC, Low Current, and 2 NAC/Relay (1, 2, 3, 4, 5) 10 x = 34 x =
4005-9804, 4 IDC, Low Current (1, 2, 3) 22 x = 57 x =
4005-9805, 4 NAC/Relay (5) 8 x = 53 x =
4005-9808, 8 Circuit I/O Module 1 x = 1 x =
4005-9824, 4 IDC, High Current (1, 2, 4) 28 x = 94 x =
Internal DACT (aftermarket PID 4005-9810) (6) 35 x = 50 x =

† Standard panels and 4005-9150 include

IDC loop currents for both supervisory
and alarm.

NOTES:

1. IDC supervisory currents include loop currents of 2 mA/circuit for “low” current IDCs and 3 mA/circuit for “high” current IDCs.

2. IDC Alarm currents, add as required. Low current IDCs = 13 mA/circuit; High current IDCs = 50 mA/circuit.

3. Add 8 mA supervisory current per SC, WSC point used.

4. Add 10 mA supervisory current per SC point used.

5. Add 8 mA supervisory current per circuit if used as auxiliary relay and programmed for normally on.

6. DACT Current is 50 mA when reporting.

Total, 4-Wire Detector Power + +

Total, Other Auxiliary Power + +

Total, Notification Appliance Power + +

Supv.

(mA)

Total, 4005 Modules

Total Supervisory Current Total Alarm Current

Quantity

Select

one

Supv.

Total

Alarm

(mA)

330

Quantity

Select one

Alarm

Total

7 S4005-0001-9 3/2009

Mounting Dimensions Reference

Conduit knockouts are provided on top and bottom

Reference, 24" stud centers

Box width = 22-1/2" (572 mm)

FIRE

ALARM

SUPERVISORY

ALARM

ACK

Knockouts are provided for

nailing. Two on each s id e an d

one each on top and bottom.

SYSTEM

SYSTEM

ALARM

TROUBLE

SILENCEDACPOWER

TROUBLE

SUPV
ACK

SYSTEM

ALARM

RESET

SILENCE

ACK

Drywall markers indicate
1/2" (13 mm) depth, two
on each side

24"

(610 mm)

Box includes an 0.048 "
(1.2 mm) thick trim for semi­flush mounting. Height and
width are same as door.

(584 mm)

23-3/8" (594 mm)

1/2"

(13 mm)

3-7/8"

(98 mm)

NOTE: A system ground must be provided for Earth Detection and transient protection devices. This connection

shall be made to an approved, dedicated Earth connection per NFPA 70, article 25 0, and NFPA 780.

23"

Tyco is a registered trademark of Tyco International Services GmbH and is used under license. Simplex the Simplex logo, LifeAlarm, and WALKTEST are trademarks of Tyco
International Ltd. and its affiliates and are used under license. NFPA 70, NFPA 72, and National Fire Alarm Code are registered trademarks of the National Fire Protection
Association (NFPA).

Tyco Safety Products Westminster • Westminster, MA • 01441-0001 • USA S4005-0001-9 3/2009

www.tycosafetyproducts-usa-wm.com

© 2009 Tyco Safety Products Westminster. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
