Simo Electronics MBH530 User Manual

说明书尺寸：67x96mm 展开尺寸：536x288mm

LOCATION OF CONTROLS:

Charging Station:

1. Charging ON/OFF Button

2. Charging port for L (Left) Earbud

3. Charging port for R (Right) Earbud

4. LED Indicators

5. Cover

6. Micro USB Port (For charger only)

Earbuds:

1. Button

2. Built-in Microphone

3. Contacts for Recharging

4. LED Indicators

2

POWER SOURCE:

The Charging station and Earbuds equipped built in Li-ion rechargeable battery;

recharge it before use or when it is drained as below.

Charging Station:

1. Connect the Micro USB Plug from the supplied USB Connection Cable to the

Micro USB Port on the rear of Charging Station.

2. Connect the full sized USB Plug from the supplied USB Connection Cable to the

USB Port on the Computer or USB Charger. (Computer and USB Charger NOT

supplied).

3. During charging, the Red LED Charging Indicator on the top of Charging Station

will blink. When finished charging, it will stop blinking.

Earbuds:

1. Open the Cover of the Charging Station. Place the L (Left) Earbud onto the L

(Left) Charging Port. Place the R (Right) Earbud onto the R (Right) Charging

Port as illustrated below:

2. Pressing the Charging ON/OFFButton on the Charging Station to power on.

BThe lue LED Indicator will illuminate.

3. Close the cover to start charging, the Red Indicator on each Earbud will

illuminate. When finished charging, the Indicator on each Earbud will turn off.

( The charging time per earbud can be be slightly different, please note this is

normal. )

3

R (Right) Earbud

L (Left) Earbud

Notes:

1. When charging the Charging Station, you can also charge the Earbuds through

it at the same time.

2. Your battery will last longer if you're following these simple guidelines for

caring and storing.

A. Before first time use, charge the Charging Station and Earbuds

approximately 1 hour until they are fully charged.

B. Recharge and store the Charger and Earpieces within the temperature range

of 5°C~35°C (40°F~95°F).

C. Do not charge longer than 24 hours. Excessive charging or running the

Charger and/or Earpieces until battery fully drains will damage battery.

Battery life

will be extended if you keep the battery fully charged.

D. Battery life naturally shortens slowly over time.

E. The rechargeable battery incorporated in this product is not user

replaceable.

4

8 9

Mini Wireless Stereo Earphone

With Bluetooth Wireless Technology

4.2

NOTE: This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help

Changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.
