Dear Customer,
Thank you for the confidence you placed in products. Our goal is to ensure
that you use this product, which has been manufactured in our modern
facilities in precise working conditions, conforming to total quality idea and
without harming nature.
We recommend that you read and carefully store the User Manual before
you use your heater, so that it can preserve its features for a long time and
serve you most efficiently.
NOTE:
This User Manual is prepared for more than one model. Some of the features
stated in the manual may not be found in your device. These features are
denoted with *
Our products are for domestical use, not for commercial use.
"READ THE INSTRUCTIONS BEFORE DEPLOYING OR USING THIS
DEVICE.”
"It complies with EEE Regulation."
Contents
2
Safety Instructions
This device is manufactured in compliance with safety
regulations. Usage against the roles causes harm to person and
device.
Please read the User Manual carefully before operating the
device. You will find important information inside the User
Manual regarding mounting, safety, usage and maintenance.
Thus you will both protect yourself and prevent the device from
coming to harm.
If the power cord is damaged, it must be replaced by the
manufacturer or its service agency or a personnel qualified in
the same degree to prevent a dangerous situation. It must be
checked whether there are breaks or deformations on the
heating element present on the device. If glass panels are
damaged, the heater must not be used. Authorized service
must be called.
It must be ensured that the main power is 220-240V AC,
50/60 Hz and the power line is connected to the fuse. Mains
safety must be checked. Fuse must be 16 Amperes. Your
device must be used with grounded socket and grounded
socket must be outside the heater area and the hot surface.
Also, it must be checked whether the socket is loose or
damaged. Because loose sockets damage the device and the
power main.
Your device must not be used connected to the same power
cable or fuse with another device.
Power cord must not be left on the hot body of the device or
near it.
If your device will not be used for a long period of time, if
cleaning or maintenance will be conducted, the device must be
unplugged. It must be ensured that the device has cooled
down.
3
Safety Instructions
Bathroom, near the swimming around havuzu.. should not be used.
4
Safety Instructions
5
Safety Instructions
Do not use this heater in the immediate surroundings of a bath,
a shower or a swimming pool
Children of less than 3 age should be kept away unless
continuously supervised.
The heater must not be used if the glass heating elements
are damaged.
CAUTION — Some parts of this product can become very
hot and cause burns. Particular attention has to be given where
children and vulnerable people are present.
Children aged from 3 years and less than 8 years shall only
switch on/off the appliance provided that it has been placed or
installed in its intended normal operating position and they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in,
regulate and clean the appliance or perform user maintenance.
WARNING:This heater is not equipped with a device to
control the room temperature. Do not use this heater
in small rooms when they are occupied by persons not
capable of leaving the room on their own, unless
constant supervision is provided.
S 1250 WTB, S 1850 WTB, S 2550 WTB
Safe distances: high temperature, fire protection, (* option)
6
Technical Features
APPLIANCA HARDWARE
Model
S 1250 WTB
S 1260 WTB
S 1850 WTB
S 1860 WTB
S 2550 WTB
S 2560 WTB
Model
S 1250 WTB
S 1260 WTB
S 1850 WTB
S 1860 WTB
S 2550 WTB
S 2560 WTB
Height
(A)
750 mm IP20
950 mm
1100 mm
1. Level 2. Level 3. Level
600 W
600 W 600 W 1200 W
900 W 1800 W
540 W
1250 W
750 W 1250 W 2000 W
Width
(B)
400 mm
400 mm
400 mm
1200 W
900 W
2500 W
Depth
(C)
332 mm
332 mm
332 mm
1440 W
Total
Power
(W)
1200 W
1800 W
2500 W
4. Level
1800 W
2500 W
Feed
(V/Hz)
220-240V ~,
50/60 Hz
220-240V ~,
50/60 Hz
220-240V ~,
50/60 Hz
Drawing
Current
Thermostat
(A)
5.2 A
7.9 A
10.9 A
Protection
Degree
Remote
Control
IP20
IP20
Device
class
ı
ı
ı
Control
Panel
MECHANICAL
ELECTRONICS
MECHANICAL
ELECTRONICS
MECHANICAL
ELECTRONICS
7
Using of your heater
Plug the device in an appropriate grounding receptacle.
Bring the on/off switch in working position.
Attention: The device has a safety system. In case of overturning, the safety system will
engage and cut off the power. In order to start the device again, you need to unplug the
device and plug it in again. (applies to models with remote control)
Off
A
B
A
B
LCD display
on / off function button
On
Maximum Level
9
Remote Control (*) option
1
2
Without Remote Control
10
Maintenance and Cleaning
11
Troubleshooting
