1 Overview
This document gives the usage of SIM7100x EVB, user can get useful information about the
SIM7100x EVB quickly through this document.
NOTE: This document is subject to change without notice at any time.
Table 1: SIM7100x EVB Key Features
Feature Implementation
Power supply 1: DC 5.0V ~9.0V
2: USB 5.0V power supply
Interface UART connector
USB connector
USIM card socket
Micro SD card socket
POWER on/off button and RESET button
RF control(Flight mode) switch and UART enable/disable
switch
Three antenna SMAs
Headset and handset interface
ADC/ ISINK/IIC/PCM/UART/GPIO/keypads test points
NOTE: For more details about SIM7100x series frequency bands. Please refer to the
“SIM7100_Hardware_Design” document.
SIM7100x EVB User Guide 2015-07-20
6
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
2 SIM7100x EVB
SIM7100x EVB User Guide 2015-07-20
Figure 1: EVB View
7
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
A: Main antenna SMA, Diversity antenna SMA, GPS/GLONASS antenna SMA
B: IO interface test points（including GPIO, Keypads, ADC, SPI,ISINK）
C: SIM7100x module
D: Power supply selection jumper
E: Micro SD card socket
F: USIM card socket
G: USB connector
H: IO interface test points（including PCM, UART,GPIO,LDO）
I: UART enable/disable switch, RF enable/disable (flight mode) switch
J: Reset button, Power on/off button
K: Headset connector
L: LED indicators
M: UART connector
N: None
O: Handset connector
P: Speaker test points
Q: JTAG test point
R: Power supply adapter connector
SIM7100x EVB User Guide 2015-07-20
8
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
The following
figure shows block diagram of SIM7100x EVB.
Figure 2: EVB Functional Architecture
All hardware sub-interfaces of SIM7100x EVB are described in detail in following chapters.
SIM7100x EVB User Guide 2015-07-20
9
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
3 EVB accessories
Figure 3: EVB Accessories
A: GPS/GLONASS antenna
B and C: Main and Auxiliary antenna
D: USB cable
E: 5V DC adapter
F: USB-UART driver CD
G: USB-UART cable
SIM7100x EVB User Guide 2015-07-20
10
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
At normal circumstance, the EVB and its accessories are equipped as the below figure.
Figure 4: The assembly diagram of the EVB and Accessories
SIM7100x EVB User Guide 2015-07-20
11
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4 EVB Interface
4.1 Power Interface
Figure 5:
Power Jumper
Table 2: The Pin Description of the J202 Jumper
Pin Signal Name Description
1 Adapter_VBAT 3.8V/2A form DC 5V
2 VBAT The power supply for SIM7100x VBAT
3 USB_VBAT 3.8V/0.7A form USB
If user wants to use DC adapter as power supply, Adapter_VBAT should be connected to VBAT
on J202 through a jumper as following figure shows.
If user wants to use USB bus as power supply, USB_VBAT should be connected to VBAT on J202
through a jumper as following figure shows.
SIM7100x EVB User Guide 2015-07-20
12
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.2 Audio Interface
Figure 6: Audio Interface
J306 is the handset interface. X501 is the headset interface.
NOTE: The MIC’s polarity must be correct.
Table 3: The Pin Description of the
Handset and Headset Interfaces
No. Signal Input/Output Description
1 MIC1_P I Positive microphone input
2 EAR_P O Positive receiver output
3 EAR_N O Negative receiver output
4 MIC1_N I Negative microphone input
5 GND Ground
6 HEADSET_MIC+ I Headset microphone input
7 HPH_L O Positive microphone output
8 HPH_R O Negative microphone output
NOTE:
1) Please refer Figure 1.The Pin 1 and Pin 2 of J501 are the SPK_M and SPK_P.
2) Audio cable must be away from the RF antenna, otherwise TDD noise may be occurred.
SIM7100x EVB User Guide 2015-07-20
13
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.3 USIM card interface
Figure 7: SIM card socket
Table 4: The Pin Description of the SIM Card Socket
Pin Signal Input/Output Description
1
V_USIM
O
USIM Card Power output automatic
output on USIM mode，one is
3.0V±10%, another is 1.8V±10%.
Current is about 10mA.
2 USIM_RESET O USIM Card Reset
3 USIM_CLK O USIM Card Clock
4 GND Ground
5 USIM_VPP Not connect
6 USIM_DATA I/O USIM Card data I/O
SIM7100x EVB User Guide 2015-07-20
14
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.4 Antenna Interface
Figure 8: Antenna connectors
Table 5: The Description of The Antenna Connectors
Item Description
J101 Main antenna connector
J105 Auxiliary antenna connector
J106 GPS/GLONASS antenna connector
4.5 RS232 Interface
J205 is 9 pins standard RS232 UART interface. It can be connected to a PC directly.
Table 6: Serial Interface
SIM7100x EVB User Guide 2015-07-20
Figure 9: Serial Port
15
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
Pin Signal I/O Description
1 DCD O Data carrier detection
2 TXD O Transmit data
3 RXD I Receive data
4 DTR I Data Terminal Ready
5 GND Ground
6 NC NC
7 RTS I Request to Send
8 CTS O Clear to Send
9 RI O Ring Indicator
4.6 Operating Status LED
Figure 10: Status LED
Table 7: The Description of the LED
Status
D301 Status Module Status
Off Module is not running
On Module is running, or voice call is connected
800ms On/ Off Module find the network and registered
200ms On/ Off Data communication
D201 Status Module Status
Off 5V DC adapter is not connected to EVB.
On 5V DC adapter has be connected to EVB.
D202 Status Module Status
Off The USB port of the EVB is not connected to USB
host.
On The USB port of the EVB has been connected to USB
host.
SIM7100x EVB User Guide 2015-07-20
16
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.7 USB interface
Figure 11: USB Interface
Table 8: USB interface
Pin Signal I/O Description
1 VBUS I 5V
2 USB_D+ I/O D+ line
3 USB_D- I/O D- line
4 GND
Ground
4.8 Switch interface
Figure 12: Switch Interface
Table 9: The Description of the Switch status
S204 Status Description
Off The RS232 transceiver is closed.
On The RS232 transceiver is open.
S301 Status Description
Off The RF circuit of SIM7100x is closed.
On The RF circuit of SIM7100x is open.
SIM7100x EVB User Guide 2015-07-20
17
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
Table 10: The Description of the Button status
Item Description
SW302 The RESET button.
SW301 The Power on/off button.
SIM7100x EVB User Guide 2015-07-20
18
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.9 IO interface
SIM7100x EVB User Guide 2015-07-20
Figure 13: The Test Point of the IO Interface
19
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
Table 11: The Pin Description of the
J302
J302 PIN Name I/O Description
1 VDD_3V
The test point of the 3V LDO on the EVB
board
2 CURRENT_SINK I The test point of the ISINK pin.
3 GND
Ground
4 SPI_CS_N O The test point of the SPI_CS pin.
5 ADC1 I The test point of the ADC1 pin.
6 SPI_MISO I The test point of the SPI_MISO pin.
7 GPIO1 O The test point of the NETLIGHT pin.
8 SPI_CLK O The test point of the SPI_CLK pin.
9 GPIO40 I/O The test point of the STATUS pin.
10 SPI_MOSI O The test point of the SPI_MOSI pin.
11 GPIO4 I The test point of the FLIGHTMODE pin.
12 ADC2
I The test point of the ADC2 pin.
13 GPIO42 I/O The test point of the USIM_DET pin.
14 GND Ground
15 GND Ground
16 GND Ground
Table 12: The Pin Description of the J304
J304 PIN Name I/O Description
1 PCM_CLK O The test point of the PCM_CLK pin.
2 PCM_DIN I The test point of the PCM_IN pin.
3 GND Ground
4 UART_DTR The test point of the DTR pin.
5 UART_DCD The test point of the DCD pin.
6 UART_RXD The test point of the RXD pin.
7 UART_RTS The test point of the RTS pin.
8 IIC_SCL The test point of the SCL pin.
9 GPIO43 The test point of the GPIO43 pin.
10 GND Ground
11 VDD_1V8 The test point of the VDD_1V8 pin.
12 GND Ground
13
VDD_2.8V
The test point of the 2.8V LDO on the
EVB board
14 VREG_SDCC The test point of the VDD_EXT pin.
SIM7100x EVB User Guide 2015-07-20
20
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
15 GND Ground
16 GPIO44 The test point of the SD1_DET pin.
17 GPIO41 The test point of the GPIO41 pin.
18 IIC_SDA The test point of the SDA pin.
19 UART_CTS The test point of the CTS pin.
20 UART_RI The test point of the RI pin.
21 UART_TXD The test point of the TXD pin.
22 GND Ground
23 PCM_DOUT The test point of the PCM_OUT pin.
24 PCM_SYNC The test point of the PCM_SYNC pin.
Table 13: The Pin Description of the J305
J305 PIN Name I/O Description
1 VBAT The test point of the VBAT pin.
2 GND Ground
3 NC Not connect
4 NC Not connect
5 KEYSENSE_ N4 I The test point of the KBC4 pin.
6 KEYPAD_4 O The test point of the KBR4 pin.
7 KEYSENSE_ N3 I The test point of the KBC3 pin.
8 KEYPAD_3 O The test point of the KBR3 pin.
9 KEYSENSE_ N2 I The test point of the KBC2 pin.
10 KEYPAD_2 O The test point of the KBR2 pin.
11 KEYSENSE_ N1 I The test point of the KBC1 pin.
12 KEYPAD_1 O The test point of the KBR1 pin.
13 KEYSENSE_N0 I The test point of the KBC0 pin.
14 KEYPAD_0 O The test point of the KBR0 pin.
15 POWER_ON I The test point of the PWRKEY pin.
16 RESET I The test point of the RESET pin.
SIM7100x EVB User Guide 2015-07-20
21
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
4.10 SD card interface
J208 is the Micro SD card socket.
Table 14: Micro SD Card socket
Figure 14: SD card socket
Pin Signal Input/Output Description
1 SD_D2 I/O Data line 2
2 SD_D3 I/O Data line 3
3 SD_CMD O Command line
4 VREG_SDCC O Power supply for SD card
5 SD_CLK O Clock line
6 GND Ground
7 SD_D0 I/O Data line 0
8 SD_D1 I/O Data line 1
SIM7100x EVB User Guide 2015-07-20
22
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
5 Quickly start
5.1 Running
Figure 15: The running steps of the EVB
The running steps of the EVB board are:
1. Insert USIM card to J207, and connect GPS/GLONASS antenna to J106, Main antenna to
J101 and Auxiliary antenna to J105.
2. Connect USB cable to J203, and USB-UART cable to J205.
3. Connect 5V DC adapter to J201 then the D201 LED will be lighted. If using USB power, this
step is not needed, but need to pay attention to the J202 jumper for power selection.
4. Push the SW301 button to power on the EVB.
5. Check that the D301 LED is lighted or not, to judge whether SIM7100 is powered up or not.
SIM7100x EVB User Guide 2015-07-20
23
Smart Machine Smart Decision
b
DISTRIBUTED BY TEXIM EUROPE
5.2 Connecting to PC
There are 2 ways to connect the module to PC:
1. Connect the J203 of EVB to PC USB port via USB cable ;
2. Connect the J205 of EVB to PC RS232 port via USB-UART cable or UART cable.
In the first case, the module USB driver needs to be installed, and this driver can be got from our
FAE or sale. In the second case, the USB-UART cable driver needs to be installed, and this driver
can be got from the CD in the EVB kit.
After Power up and installing the corresponding driver, the HyperTerminal tool can be used to
access the SIM7100 via the virtual COM from USB or the physical UART COM.
NOTE: the HyperTerminal in windows2000/XP/Vista can be found at
START—accessory—communication menu. Please set the Baud Rate to115200bps for the
SIM7100 and the corresponding COM port number, such as COM1 or COM2 etc.
.4 Download
5
The “SIM71x0_UpdateTool.exe” tool can be used to download firmware to the SIM7100.
The follow figure shows the download steps:
Open the “SIM71x0_UpdateTool.exe”
tool
Power up the Module
Install the module USB driver
Click the “Download all”
utton.
Update success
START
SIM7100x EVB User Guide 2015-07-20
Figure 16: The diagram of USB download
24
Smart Machine Smart Decision
DISTRIBUTED BY TEXIM EUROPE
Contact us:
Shanghai SIMCom Wireless Solutions Ltd.
Add: Building A，SIM Technology Building，No.633，Jinzhong Road，Changning
Disdrict，Shanghai P.R. China 200335
Tel: +86-21-3252 3300
Fax: +86-21-3252 3301
URL: www.sim.com
SIM7100x EVB User Guide 2015-07-20
25
Contact details
The Netherlands
Elektrostraat 17
NL-7483 PG Haaksbergen
T: +31 (0)53 573 33 33
F: +31 (0)53 573 33 30
E: nl@texim-europe.com
Germany North
Belgium
Zuiderlaan 14 bus 10
B-1731 Zellik
T: +32 (0)2 462 01 00
F: +32 (0)2 462 01 25
E: belgium@texim-europe.com
Germany South
UK & Ireland
St. Mary’s House, Church Lane
Carlton Le Moorland
Lincoln LN5 9HS
T: +44 (0)1522 789 555
F: +44 (0)845 299 22 26
E: uk@texim-europe.com
Austria
Bahnhofstrasse 92
D-25451 Quickborn
T: +49 (0)4106 627 07-0
F: +49 (0)4106 627 07-20
E: germany@texim-europe.com
Nordic region
Sdr. Jagtvej 12
DK-2970 Hørsholm
T: +45 88 20 26 30
F: +45 88 20 26 39
E: nordic@texim-europe.com
Martin-Kollar-Strasse 9
D-81829 München
T: +49 (0)89 436 086-0
F: +49 (0)89 436 086-19
E: germany@texim-europe.com
General information
info@texim-europe.com
www.texim-europe.com
Warwitzstrasse 9
A-5020 Salzburg
T: +43 (0)662 216 026
F: +43 (0)662 216 026-66
E: austria@texim-europe.com
2015 version 2.0
Loading...
