Sima SCC User manual

Video Color Corrector

Model SCC

User Manual

PRELIMINARY

Important Safety Precautions

When using this product, basic safety precautions should always be followed to reduce
the risk of fire and electric shock, including the following:

Read and understand all instructions.
Follow all warnings and instructions marked on this product.
Unplug this product from wall outlets before cleaning. Do not use liquid or aerosol

cleaners. Use a damp cloth for cleaning.

To prevent fire or shock hazard, do not expose this product to rain or moisture. Do

not use near a bath tub, wash bowl, sink, or laundry tub; do not use in a wet

basement or in a swimming pool.
To avoid electrical shock, do not open the case of this product.
Operate this product using only the power supply included with it or provided as an

accessory. If you are not sure of the type of power supplied to your home,

consult your dealer or local power company.
Do not overload electrical outlets or extension cords as this can result in fire or

electric shock.
The unit should be situated away from heat sources such as radiators, stoves, etc.

The unit should be situated so that its location or position does not interfere

with its proper ventilation.
This unit is for private use only. Use of this device to duplicate copyrighted video

tapes or other video sources may be against certain federal and state copyright

laws.

Caution: Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate the

equipment.

1998 by Sima Products Corp.
All rights reserved. No part of this publication
may be reproduced or transmitted in any form or
by any means without prior written permission
from Sima Products Corp.

2

Table of Contents

Important Safety Precautions 2

Introduction 4

Typical Hook up 5

Operation 6

Trouble Shooting 8

Technical Specifications 9

Warranty 10

3

Introduction

The Sima Color Corrector, Model SCC, has been designed for the person who
wants to control and adjust a video signal to achieve the best possible viewing
and copies of video tapes. This allows you to enhance dark videos and adjust
for color balance problems on your home movies.

The SCC has the following features:

1) Control of key picture elements like brightness, picture, color, tint, and

sharpness to allow you to adjust the video signal as necessary.

2) Supports composite and S-video sources.

3) Fine tuning of the red, blue and green colors to achieve a correct white

balance.

4) Full sync and color burst restoration for rock solid copies

5) Full electronic bypass to see the before and after pictures easily.

What’s Included:

1 - SCC Color Corrector unit
1 - RCA cable, 1 meter long
1 - S-Video cable, 1 meter long
1 - AC adapter, 120 VAC input, 15 vdc output
1 - This instruction manual

4
