SIM2 Multimedia
Innovation in home cinema
SIM2 Multimedia mission is to offer solutions for home cinema applications: in
other words, truly sensational rear (45” and 55” diagonal) and front projection
products, capable of outputting a picture up to 150-300” diagonal.
SIM2 products are designed for today's and future requirements and incorporate
all of those exceptional performances that have created the SIM2 legend.
In the home theatre market, SIM2 Multimedia is today's synonymous of
innovation and quality. The company provides one of the industry's most
comprehensive line of video entertainment projectors and high-end professional
display that have a common denominator: a cinematographic quality for future-
proof products.
The marketing policies of the company are world-oriented with a direct presence
through the headquarter/subsidiary in Italy, USA, UK and Germany and in over 45
countries world-wide through partnerships with qualified distributors. SIM2
Multimedia's headquarters are located in Pordenone, Italy. The capillary, world-
wide distribution, coupled with an excellent customer service, guarantees
absolute serenity in time.
SIM2 celebrates 10 year
anniversary
In 2005, SIM2 Multimedia celebrates its first 10 years of operation.
Since its founding in July 1995, SIM2 has grown from a small company to
one of the most hotly sought-after manufacturer of top-notch products,
continuously meeting the needs of the home entertainment market with
products embodying the very best in performance and available technology.
Today we have a permanent staff of 125 and have earned a reputation for
our continuous innovation and the quality of our products.
SIM2 Research & Development
SIM2 has gained in reputation thanks to its strong commitment on innovation and great passion
for outstanding image quality. Indeed, SIM2 Multimedia invests over 20% of its human resources
and over 10% of total turnover in R&D activities, assuring constant innovation of products.
SIM2 Research & Development team's achievements:
1. an innovative “alpha path” light engine for a revolutionary product
series.
2. the best signal processing device coupled with the most
sophisticated deinterlacer;
3. a wide selection of connections to allow interface with today's and future
sources; in particular, the latest HDMI™ (High Definition Multimedia
Interface) input that safely processes uncompressed signals, making illegal
reproductions impossible to accomplish; HDMI™ doesn't require any analog/digital
conversion - and/or vice versa - and controls simultaneously up to 8 audio channels with a
quality higher than the one offered by normal CDs.
4. the use of fibre optics cable. SIM2 is the only consumer manufacturer to use an optical link
between a remote and external video processing unit (DigiOptic™ Image Processor) and the
projector for a loss-free and interference-free signal.
2 3
home is where
If you’re like most people, you
the theatre is
It has often been said, “A man’s home is his
castle”. With that adage in mind, it’s no surprise
that more and more people are choosing to enjoy
their favorite movies, sporting events and TV
programs in the comfort of their own private
theatre. Whether you’re an avid host or prefer
quiet evenings at home, a personal theatre allows
you to express your style in entertainment.
A name you can trust
On the basis of more than 10 years of experience in cutting edge
innovation, SIM2 Multimedia, is a world-leading manufacturer dedicated to
bringing a cinema-quality picture into your home. Investing in a SIM2’s
projector you can be confident that it will deliver on sharpness, brightness
and colour fidelity.
Sit back, relax and enjoy
A home theatre creates an exclusive domain within your living space, where
the reality of your surroundings is suspended and you’re immersed in a total
entertainment experience. Imagine enjoying a great football game or movie
in the intimate surroundings of friends and family with cinema-quality
projection and sound. A SIM2 projector is an essential part of this
experience.
want to make the most of
your leisure time
SIM2 Multimedia design engineers pay particular attention to ensure
that their projectors are an attractive addition to your home. Your
family and friends will immediately notice the elegant design, which
is certain to complement your décor. Furthermore, all SIM2’s
projectors offer relaxed ease-of-use via remote control and our
comprehensive warranties ensure peace of mind.
Your attitude toward entertainment is as unique
as your personality
Regardless of the size of your home, you may have concerns about how a personal theatre will transform your living space. Retractable
screens and ceiling or bookshelf mounted projectors allow you to convert a multi-purpose living area into a theatre at your discretion. You
may also choose to design a dedicated home theatre room with a wall-mounted screen. Whatever the case, creating a theatre that
complements the personality of your home should be a fulfilling experience; the possibilities are as endless as your imagination.
4 5
DLP™ technology
Dark-metal technology
In first-generation DMD systems, the particles of light
occasionally escaped to screen, subtly affecting the
contrast ratio of the projected image. In the DarkChip™
generation, a light-eating "dark metal" coat is applied to the
interior of each chip, preventing stray light from traveling to
screen when mirrors are switched off. Now, photons go
only where they're wanted.
Digital Light Processing (DLP™) is a new way to
project and display video signals and is based on
the Digital Micromirror Device (DMD) developed
by Texas Instruments.
The inherent digital nature of DLP™ enables
noise-free, precise image quality with digital gray
scale and very good colour reproduction.
Finally, close spacing of the micromirrors causes
video images to be projected as seamless
pictures with higher perceived resolution.
How it works
A DMD can be described simply as a semiconductor light switch.
Thousands of tiny, square, 13x13 µm mirrors, fabricated on hinges atop a
static random access memory (SRAM) make up a DMD.
Each mirror is capable of switching a pixel of light. The hinges allow the
mirrors to tilt between two states: “on” or “off”.
One-chip system
White light passes through a colour wheel filter, causing
red, green and blue light to be shone in sequence on the
surface of the DMD. The colour wheel spins at 60 Hz to
give 180 colour fields per second (256 shades for each of
the primary colours, or 2563 - 16.7 million - possible
colours that can be generated).
The switching of the mirrors, and the proportion of time
they are 'on' or 'off' is coordinated according to the colour
shining on them. The human visual system integrates the
sequential colour and sees a full-colour image. A white
segment may be added to increase brightness efficiency of
the system.
Three-chip system
DLP™ technology-enabled projectors for very high image quality or high
brightness applications such as cinema and large venue displays rely on
a 3-DMD-chip configuration to produce stunning images, whether
moving or still.
In a 3-chip system, the white light generated by the lamp passes
through a prism that divides it into red, green and blue. Each DMD chip
is dedicated to one of these three colours; the coloured light that the
micromirrors reflect is then combined and passed through the projection
lens to form an image.
Advantages in Home Entertainment
Sharper image: all digital technology recreated the source with maximum fidelity so you may enjoy clear, sharp pictures.
Knockout colour: high contrast and better accuracy mean brilliant colours and richer blacks.
Slim design: lightweight semiconductor technology allows for thin and elegant TVs and projectors.
6 7
GRAND CINEMA series
the ultimate home theatre experience
We have changed the
rules of the game
key points
? Designed specifically for home theatre
? Based on Texas Instruments' DLP™
technology
? Built-in deinterlacer and video processor
? Lens shift and digital keystone adjustment
? Long Throw Ratio zoom lens
? HDMI™ and DVI inputs
? Improved software functions
Grand Cinema Line - Cutting-edge technology combined with elegance
and style; brought to you by the masters in home cinema projection: SIM2!
The SIM2 Grand Cinema Line has been created to endorse the strategic
positioning of SIM2 within the home theatre marketplace and to fulfil the
needs of a discerning customer seeking to enjoy a truly high end “ultimate
home cinema experience”, whilst being backed up with reliable product
support from qualified staff.
All Grand Cinema products have been designed and manufactured using
the most advanced cutting edge technology available to the current
marketplace; the SIM2 Research and Development team working closely
with new technologies to develop the ultimate image quality.
Grand Cinema offers a hands on approach to cinema
viewing. An extremely sophisticated and versatile firmware
and software, gives the customer the enjoyment of self
customizing a fully adjustable user interface, allowing the
viewer to tailor the picture to their exacting requirements.
Alternatively, this fully customisable interface offers flexibility
to professional installers and lifestylers, allowing them to
set-up the projector to deliver the best image quality for the
living conditions.
The recent introduction of new projectors to the Grand
Cinema range, together with the introduction of HDMI™
The Grand Cinema line has received a plethora of prestigious international awards for excellence in its category, aesthetics, innovation, etc.
digital Input, places SIM2 firmly at the forefront of the technology
revolution.
The SIM2 Grand Cinema range is the only projector line that features
HDMI™ Input across the entire range. SIM2 is the only company in the
home theatre industry Worldwide to currently offer this to the customer.
8 9
HT
SIM2’s proprietary
engine and optical
path
Since the introduction of the Grand Cinema line
to the World market in 2000, the SIM2 Research
& Development team have been praised and
acknowledged for their outstanding
achievements, no exception being the
revolutionary “alpha path” light engine.
SIM2's optical engineers have once again achieved an extraordinary goal
after months of research and development activities, resulting in a new
optical engine, which has an absolutely perfect light path, delivering
outstanding colours and reaching very high and true contrast ratios.
The coupling of this revolutionary new light engine with the newly
introduced HDMI ™ Input has brought about a truly exceptional picture
quality that has never before been experience!
Last, new electronics and software functions are now featuring the Grand
Cinema Line such as a new Formatter Board that is integrated with the
latest Video Processor. This hardware and software new implementation,
together with others, allow functions such as Video Noise Reduction,
Flesh Tone Correction, Customized Adjustment of all parameters,
Overscan of 33 different positions, Auto POWER ON selectable and many
others.
Grand
Cinema
In the year 2000, SIM2 has revolutionized the
home theatre market with the introduction of the
SIM2 GRAND CINEMA HT series: the new
projector line based on Digital Micromirror Device
by Texas Instruments.
The SIM2 GRAND CINEMA HT series has been completely designed by SIM2
specifically for home theatre and home entertainment applications with a specific
criteria in mind: the best performance without compromise for a product that fulfils
the requirements of the most demanding home theatre enthusiast.
10 11
HT500 E-LINK and HT500 E
Optical Freedom
key points
? 3-chip HD2+ DarkChip™ DMDs by Texas
Instruments
? 720p High Definition native resolution
(1280x720 pixels )
? Phenomenal contrast ratio (>4300:1) &
brightness
? SIM2 Live Colours Management (LCM)
and Gamma functions
? Intelligent Memory functions
? HT500 E-LINK only: External DigiOptic™
Image processor with 12 inputs
? HT500 E-LINK only: Fibre optics
connection up to 500 m (1600 ft)
? Low noise operation and no rainbow effect
? HDMI™-HDCP input
? Choice of 5 high quality zoom lenses
? Screen size up to 9 meters (>29 ft)
? On Board Video Processing
Featuring SIM2 LCM and Gamma control software and three HD2+ DMD
chips by Texas Instruments, the HT500 E-VOLUTION projectors - namely
HT500 E-LINK and HT500 E - deliver a resolution of 1280x720 for a
flawless home theatre excellence.
These projectors have been built to deliver a "real" home cinema
experience, delivering a perfect image where other projectors fall fawl to
the constraints of a screens dimensions and only before seen at
commercial cinemas.
HD2+ DarkChip2™ by Texas Instruments
The HT500 E-LINK and HT500 E projectors are the
first 3-chip on the market to feature the HD2+
DarkChip2™ by Texas Instruments (HD2+ DC2). The
DarkChip2™ incorporates smaller mirror hinges,
reduced gaps between mirrors, a flatter, more
reflective surface and a light absorbent coating for unmatched contrast and
colour uniformity. Also, the DarkChip2™ coupled with improved software
and SIM2 high quality optics allow the HT500 E-LINK and
HT500 E to reach a true contrast ratio of >4300:1 thus
delivering on screen the crispest, sharpest and truest colour
image.
SIM2 Live Colours Management
(LCM) and Gamma functions
SIM2's engineers have given the HT500 E-LINK an ultra-
sophisticated software design that's worthy of the most
discerning home theatre enthusiast.
The LCM algorithm allow the precise adjustment of the
colour temperature to user preference, by choosing from
the 36 predefined white points in CIE Chart.
And, the Gamma Tables provide a wide range of possibilities to optimise
image based on variations in the source material, ambient lighting, and
individual preferences: 1 Standard curve for movies, 5 SIM2 Enhanced
curves to fully exploit the advantages of DLP™ technology, 2 Graphics
curves for PC and graphic sources, and a User adjustment with 16
parametric gamma curves (ranging from 1.5 to 3 with a 0.1 increment).
HT500 E-LINK only: Positioning the DigiOpticTMImage Processor
The ideal location for the DigiOptic ™Image Processor is on a cabinet shelf or on a rack (dimensions compatible with a standard 19" rack).
Make sure that the support surface is stable and that the unit has sufficient space around it for ventilation purposes (at least 3 cm).
14 15
Intelligent Memory functions
The HT500 E-LINK and HT500 E can store up to
3 image memory settings such as brightness,
contrast, colour temperature, etc. for each input;
that is 75 and 24 settings respectively. When you
select a new source, the parameters stored in
each memory may be applied simultaneously. Or,
you may simply choose to recall despite the
change of source.
Future proof
The E-volution projectors feature an impressive
array of digital connections, including DVI and
HDMI™ inputs (on HT500 E, HDMI™ only).
HDMI™ is a purely digital connection that transmit
the uncompressed bitstream directly from the
source through to the display and is backwards
compatible with DVI.
HT500 E-LINK
On board Video Processing guarantees an image that is free from motion
artefacts and that your film collection is displayed just as the Director
intended!
For ease of installation, the projectors sport the supreme flexibility of five
additional lens options, making it possible to project a perfect 4.7 meter
image from only 1.3 meter from the screen, up to 7.8 meter image from 28
meters. The HT500 E-LINK and HT500 E also sport unparalleled features
such as H/V electrical lens shift, digital keystone adjustment, absence of
HT500 E-LINK and HT500 E
colour wheel for an artifact-free image and many
more.
HT500 E-LINK only: Remote
DigiOptic™ Image Processor
The HT500 E-LINK features all the properties of
the HT500 E plus SIM2's DigiOptic™ Image
Processor, the remote unit equipped with a wide
choice of inputs and linked to the projector
through a thin digital fibre optic cable (0,14"
diameter - 3,5mm).
The rack mount DigiOptic™ Image Processor
can be installed next to the customer's
equipment and up to 12 individual products can
be connected at any one time.
This concept eases the problems with
installation, no issues with interference or losses
(quality connections up to 500 meters- 1600 ft)
from long cable runs, electrical interference from
telecommunications, power cables and lighting
Fibre Optics vs Copper: main advantages
Design and colours
Italian Concept Designer Giorgio Revoldini has
once again delivered a design that sports smooth
curves, making the HT500 series a high-class
focal point for any décor. The HT500 series is
available in an elegant Dark Gray cabinet colour.
16 17
? Speed: Fibre optic networks operate at high speeds - up into gigabits
? Bandwidth: Large carrying capacity
? Distance: Signals can be transmitted further without the need to be “refreshed”
or strengthened
? Resistance: Greater resistance to electromagnetic noise such as radios,
motors or other nearby cables
? Maintenance: Fibre optic cable has a lower maintenance costs
HT300 E-LINK and HT300 E
Your link to E-volution
key points
? HD2+ DC3 chip (0.8" 720p DarkChip3™)
by Texas Instruments
? True contrast ratio: >3500:1
? 1280 x 720 pixel (WXGA) resolution
? Phono Absorbant Materials
? SIM2 Live Colours Management and
Gamma adjustment
? HT300 E-LINK only: fibre optic
connection
? HT300 E-LINK only: External DigiOptic™
Image processor with 12 inputs
(connection up to 500 m - 1600 ft via
fibre optic cable )
? Intelligent picture memory functions
? HDMI™ input
? Lamp life: 8000 hours
? SIM2 proprietary alpha-path light engine
? On board Video Processing
? Lens shift and digital keystone adjustment
? Long Throw Ratio zoom lens
The E-volution models - namely HT300 E-LINK and HT300 E - are the
newest addition to the acclaimed and successful Grand Cinema HT series
of home theatre projectors.
New 0.8" 720p DarkChip3™ by Texas
Instruments
The HT300 E-LINK and HT300 E projectors feature the new 0.8" 720p
DarkChip3™ by Texas Instruments (HD2+ DC3).
A DMD chip contains an array of hinged microscopic mirrors that recreate
a video or graphic source by reflecting or not reflecting light onto a
projection surface, thereby producing a grayscale image. When a DMD
mirror tilts away from its light source, a tiny space is
opened into which stray photons can stumble. In first-
generation DMD systems, these particles of light
occasionally escaped to screen, subtly affecting the
contrast ratio of the projected image.
In the DarkChip generation, a light-eating "dark metal" coat
is applied to the interior of each chip, preventing stray light
from traveling to screen when mirrors are switched off. Now,
photons go only where they're wanted. The DarkChip3™
incorporates:
• Reduced Via Size: Utilizing a new hybrid mirror metal
deposition technique the DarkChip3™, produces more
uniform mirror thickness, superior metal deposition
coverage within the via and from the center to the edge of
the wafer
• Reduced Pixel Gap
Both of these features reduce the scattering of light,
resulting in increasingly higher image contrast (+25%) and a
further improved black colour point / perception of black.
Also the DarkChip3™ is a Fast Track Pixel (FTP) chip that
allows an approx. 50% reduction of the dithering effect for
an exceptionally natural, crystal clear image.
Micro-mirror closeup
HD2 HD2+ HD2+ DC3
Phenomenal Contrast Ratio
The DarkChip3™ coupled with improved software and SIM2 high quality
optics allow the HT300 E-LINK and HT300 E to reach a true contrast ratio
of >3500:1 thus delivering on screen an image of unprecedented quality
from a single chip projector
Intelligent Memory functions
The HT300 E-LINK and HT300 E can store up to 3 image memory
settings such as brightness, contrast, colour temperature, etc. for each
input; that is 75 and 24 settings respectively. When you select a new
source, the parameters stored in each memory may be applied
simultaneously. Or, you may simply choose to recall despite the change
of source.
Contemporary cabinet design
The E-evolution projectors sport a new Phono-Absorbent cabinet to further reduce noise emissions resulting from the
spinning of the colour wheel, and it is available in three different colours: Gun Metal Gray (standard), Royal Burgundy, and
Shiny Silver.
18 19
HT300 E-LINK and HT300 E
Complete colour control
with SIM2 Live Colours
Management (LCM) and
Gamma functions
The HT300 E-LINK and HT300 E feature SIM2
LCM and Gamma functions. SIM2's new LCM
algorithm allows you to precisely adjust colour
temperature to your preference. Simply choose a
white point among the 36 predefined values
inside the neutral colour area of the CIE
cromaticity diagram.
The horizontal lines set the low (right side, red
component, 6.500°K) and high temperature
values (left side, blue component, 10.000°K). The
points along the lower horizontal line represent
colours that belong to the black body curve.
HT300 E-LINK
Along the vertical lines the colour temperature is constant but differs from
the black body curve; for instance if you select a point from the higher part
of the diagram you will increase the green component, while the lower part
will increase the purple component. In addition, the Gamma Correction
determines the system 's response to the grey scale; The higher the
gamma the faster the brightness decreases with signal intensity. SIM2's
HT300 E-volution projectors have 12 gamma curves available to optimise
image based on variations in the source material, ambient lighting, and
individual preferences: 5 STANDARD for movies, 5 ENHANCED to fully
exploit the advantages of DLP technology, and 2 GRAPHICS for PC and
graphic sources.
Future proof inputs and
advanced video processing
The E-volution projectors feature an impressive
array of digital connections, including HDMI™.
HDMI™ is a purely digital connection that
transmits the uncompressed bitstream directly
from the source through to the display - even high
definition - and is backwards compatible with
DVI. The on board Video Processing guarantees
an image that is free from motion artefacts and
that your film collection is displayed just as the
Director intended!
TM
DigiOptic
Processor
Fully-packed products
The HT300 E-LINK and HT300 E are all-inclusive projectors, featuring a
sophisticated proprietary optical design for saturated and vibrant colours,
high performance long lamp life for low operating costs, 6-segment colour
wheel for dramatically-reduced colour separation artefacts, long throw
ratio, power zoom and focus, and lens shift + Keystone Adj. to fine-tune the
projectors from your viewing position.
Fibre optic
cable
The DigiOpticTM Image Processor (HT300 E-LINK only)
The HT300 E-LINK features all the properties of the HT300 E plus SIM2's DigiOptic™ Image Processor, the remote unit equipped with a wide
choice of inputs and linked to the projector through a thin digital fibre optic cable (3,5mm - 0,14" diameter). This means incredible flexibility
with the installation, greatly reducing the need for numerous long cable runs to the projector.
The system is also upgradeable to accommodate future additional connections.
20 21
HT280 E
A simply stunning performance
key points
? Matterhorn DMD chip by Texas Instruments
(1024x576 pixels resolution)
? True contrast ratio: >2500:1
? Phono Absorbant Materials
? SIM2 Live Colours Management and
Gamma adjustment
? Intelligent memory functions
? HDMI™ input
? SIM2 proprietary alpha-path light engine
? On board Video Processing
? Lens shift and digital keystone adjustment
? Long Throw Ratio zoom lens
? New, silent 6-segment colour wheel
? Lamp life: 8000 hours
The HT280 E is a single chip DLP™ technology-based front projector
featuring the 1024 x 576 Matterhorn chipset from Texas Instruments,
ideally suited to European DVD and broadcast formats.
A newly enhanced SIM2 light engine, as featured in other Grand Cinema
projectors, provides a true contrast ratio of around >2500:1 and delivers
stunning film like image quality. The HT280 E long throw lens is perfect for
positioning the projector at the back of the room, behind the audience to
recreate a true cinematic experience.
A combination of SIM2 6 segment colour wheel, Texas Instruments ED2
chip set and SIM2's new proprietary light engine, all components of the
HT280 E, ensures that the HT280 E delivers very accurate
colour rendition capabilities with vibrant reds, greens and
blues for a film-like image.
Accurate colour reproduction
Like all other Grand Cinema HT models, the HT280 E
features SIM2 LCM and Gamma functions. The LCM
algorithm allows you to precisely adjust colour temperature
to your preferences Simply, choose from the 36 predefined
white points in CIE Chart. In addition, you may choose from
the wide range of possibilities provided by the Gamma
Tables to optimise image to the connected source (12).
The HDMI™ input
The HT280 E sports the HDMI™ input. HDMI™ (High
Definition Multimedia Interface) is an uncompressed digital
connection that transmits HDTV at 2.2Gbps - with a strong
content protection (HDCP) - directly from the source
through to the display.
The HT280 E features a new Formatter Board that is integrated with the
latest Video Processro. This new implementation to the hardware and
software allows a broad series of functions such as video noise
reduction, flesh tone correction, customized Adjustment of all
parameters (different adjustments per input), overscan of 33 different
positions, and auto Power On selectable.
The colours
The HT280 E is presented in the attractive world-renowned Grand
Cinema HT cabinet design by Giorgio Revoldini and is available in SIM2's
Gun Metal Gray colour.
2322
Grand
Cinema
RTX
The Grand Cinema RTX line was developed to
challenge the concept of Home Theatre Display.
Innovative and unique both in technology
solutions and aesthetic design, the RTX
epitomizes the mission of SIM2: delivering superior quality Home
Theatre display systems to Home Cinema enthusiasts.
Innovation, is the word often used when an unique product is
developed. However, the expectations of the SIM2 customer are
more than innovation, expecting products that do not become
outdated both technically and on aesthetics. In addition to this,
they expect performance as well as uniqueness and longevity.
The SIM2 RTX line offers an impressive alternative to other
medium sized Home theatre screens currently on the
market, providing exceptional video performance from the
DLP™ based light engine, through to a contemporary and
stylish finish, befitting to the most diverse of home interiors.
Furthermore, the versatility of the SIM2 LINK concept allows
for an incredibly discrete installation every time!
SIM2 has an impressive history in DLP™ front projection
and as one of the pioneering manufacturers within this
market has built a loyal customer base within their front
projection range of products.
The SIM2 rear projection displays are however astounding
the discerning front projector enthusiasts, who are amazed
at the rich colours and sharp detail achievable from a SIM2
rear projection unit. With the Grand Cinema RTX, emotions
and enthusiasm are enjoyed in the comfort of the most
suitable environment: your own home.
26
27
RTX45 and RTX55H
Make the most of your leisure time
Video Entertainment: a new
concept
key points
? HD2+ DarkChip™ (RTX55H) and HD2
DarkChip™ (RTX45) by Texas Instruments
(1280 x720 pixel resolution)
? 45” and 55" screen dimensions
? RTX55H: Contrast ratio >2300:1
? RTX45: Contrast ratio >2000:1
? External DigiOptic™ Image Processor
with 12 inputs (connection via fibre optic
cable)
? Proprietary Fresnel lens and cabinet design
? Future-proof digital inputs: HDMI™-HDCP
(RTX55H only) and DVI
? On board Video Processing
? Reduced depth
? Lamp life: 6000 hours under optimal
conditions
After the success of Grand Cinema HT series, SIM2 realized the need to
apply the projectors technology to a display device that could be utilized in
a variety of rooms while fulfilling the need of the Home Theatre enthusiasts.
The market is demanding a self contained product which features
innovative exterior design and installation flexibility while maintaining the
stunning picture the Grand Cinema HT projectors produce.
With this concept in mind, SIM2 designed the Grand Cinema RTX line: a
revolutionary concept where image quality, technology and design are
combined.
Within the cabinet of the RTX, lies the heart of the system.
Based on Texas Instruments DLP™ technology (HD2+
DarkChip), the Grand Cinema RTX55H delivers sharp, high
contrast (>2300:1) images, edge-to-edge definition, an
excellent colourimetry and grey scale tracking.
The Grand Cinema RTX55H is available in 55” diagonal
screen size - 16:9 image format) and far exceeds today's
standards of technology. Features such as a fibre optic link,
high speed laser, custom-made lens and engine, latest
generation video processing and finally HDMI™ input, all
create a truly future proof product.
In fact, the RTX 55H integrates perfectly within your existing
high-end audio system. All inputs can be conveniently
connected via the SIM2 proprietary DigiOptic™ Image
Processor, a remote system that channels the input feeds,
including the newly added HDMI™ digital connector and
DVI, along a thin kevlar-coated fibre optic cable to the RTX
system. This, together with the RTX55H simple menus and vertical tilting
system, make installation and set-up easy and fast.
SIM2 manufacturers all of their products with foresight and the RTX line
is no exception. It can be constantly upgraded via the RS232 connector
and is fully compatible with emerging products and technologies.
Also, the RTX line features three custom-made components (SIM2 patent
rights): first, a high resolution projection lens for reduced cabinet depth;
second, a specific Fresnel lens to match the DMD chip; and, third, an
improved and sealed light engine for super-high contrast (>2300:1) and
black level.
28 29
Through your eyes and emotion
you will be left breathless every
time you watch your Grand
Cinema RTX
The RTX55H features the well received SIM2's DigiOptic™
Image Processor, the remote processor box equipped with
a wide choice of inputs and linked to the projector through
a thin fibre optic cable (3,5mm - 0,14" diameter).
With this innovative feature of using an external input/image
processing box connected via fibre optics to the projector,
SIM2 has made installation and signal management an easy
task.
Video sources are typically located far away from the
projector and it is becoming very difficult to run HD-
compatible cables for long distances. With the DigiOptic™
Image Processor this issue no longer exists.
RTX45 and RTX55H
Based on a Complementary Metal Oxide Semiconductor (CMOS) chip-set
the optical link allows a fully digital source-to-display link, which is capable
of transmitting data over a distance in excess of 1600 ft, with 3 high-speed
lasers between the DigiOptic™ Image Processor and the projector for a
loss-free and interference-free signal..
BS_BlackShadow
The Grand Cinema RTX55H elegant cabinet (available in different colours) is immediately recognisable: A fancy crystal front, a reduced depth
of 14,5” (approx. 37 cm), sophisticated shapes, and prestigious material make it a true masterpiece by the award winning designer - Giorgio
Revoldini.
SR_SilverRed
BR_BlackRed SG_SilverGray
30 31
RTX55 TV display
Picture Perfect
key points
? HD2+ DMD chip by Texas Instruments
? 1280x720 pixels resolution
? 55” screen dimension
? Proprietary Fresnel lens and cabinet
design
? True contrast ratio >2300:1
? Proprietary sealed engine
? Built-in tuner (100 channels)
? 2x40W high quality front speakers
? Internal amplifier up to 90W RSM at
front/central channel input
? Silent 6-segment colour wheel
? Wide choice of inputs
? On board Video Processing
? Reduced depth
? Elegant design and prestigious materials
After the success of its Grand Cinema RTX predecessors, SIM2 has
designed for the discerning home theatre enthusiast the RTX55 TV display
device.
The RTX55 TV display offers the same outstanding image quality of the
RTX series, but has no need for the added functionality that the
DigiOptic™ Image Processor and the associated fibre optic lead has to
offer. It utilises the same advanced light engine and high quality optics that,
coupled with two powerful loudspeakers (built-in) and TV tuner, allow the
RTX55 TV to deliver a truly-undeniable cinematic experience.
If you're a film fan, sports enthusiast, games console addict,
want to surf the Net or simply watch the Soaps the new
RTX55 TV will display these in glorious colour and definition
thanks to SIM2's unique technological solutions and DLP™
technology from Texas Instruments.
Based on HD2+ DMD chip (1280x720 pixels), the RTX55 TV
delivers native support for 720p, as well as a 16:9 aspect
ratio for true high definition capability, and a contrast ratio of
>2300:1.
As always, SIM2 has left nothing to chance, designing a
customised sound system for this hi-end TV display. In fact,
the SIM2 DLP™ Projection TV has two built-in, high quality
front speakers (L/R or Centre channel),and a 40-Watt sound
system for a more lifelike sound and clearer dialog.
SIM2's RTX55 TV is multimedia-ready. It provides multiple sets of inputs
and outputs to offer you maximum flexibility to expand your home theatre.
They can handle your PC, DVD, game console, HDTV receiver, satellite
dish, camcorder and more. Plug-and-play has never been easier.
The RTX55 TV is available in 55" screen size and Silver Gray cabinet
colour.
32 33
HTL40 LINK and HTL40
Challenging the way you perceive images
key points
? 40" (101cm), 16:9 Aspect Ratio
? Advanced TFT LCD panel
? WXGA resolution: 3,147,264 pixels
? 170º Viewing Angle
? High pixel response time
? True contrast ratio: 1000:1
? High brightness: >600 cd/m2
? HTL40 LINK only: The first LCD display to
feature fibre optic connection
? HTL40 LINK only: External DigiOptic™
Image Processor with 12 inputs
? HDMI™-HDCP & DVI (HTL40LINK) inputs
? On board Video Processing
? Intelligent memory functions
? 60.000 hours lamp life time
? Wall Mount (standard)
? Crystal or Matt Silver tabletop support
(optional)
? Elegant cabinet design available in 3
different colours
Unprecedented image quality
The 40-inch HTL40 series combines state-of-the-art technology and
stylish, compact design and is available with (HTL40 LINK) or without
(HTL40) SIM2’s DigiOptic™ Image Processor. Featuring the latest TFT
panel technology, the HTL40 series has a WXGA resolution of 1366 x 768
- fitting a native 16:9 aspect ratio - and an enhanced 1000:1 contrast ratio.
The HTL40 displays deliver rich, saturated colours, a superb gray scale
tracking, and a brightness of 600 cd/m2, for a sharp vivid picture even in
direct sunlight conditions.
Intelligent Memory functions
The HTL40 LINK and HTL40 can store up to 3 image memory settings
such as brightness, contrast, colour temperature, etc. for each input; for a
total of 75 settings and 24 respectively. When you select a new source, the
parameters stored in each memory may be applied simultaneously. Or, you
may simply choose to recall it despite the change of source type.
Design and colours
The HTL40 series sports a contemporary and stylish
design, befitting to the most diverse of home interiors; a
new masterpiece by the award-winning designer Giorgio
Revoldini. The adopted technological solutions represent
the best in terms of material selections. Every component
speaks of attention to details: from the front crystal glass,
to the refined wood or matt silver back panels, to the
crystal or Matt Silver tabletop support (optional).
The HTL40 series back panel is available in Matt Silver
(standard) and two types of refined woods: Rosewood or
Whitened Oak.
Also, LCD allows screens to be thinner than ever before. In
fact, the HTL40 series, with its depth of only 10,2 cm (4”)
not only can fit flat on a wall, it can fit in places conventional
televisions cannot.
Rosewood
Black version
Whitened Oak version
Extraordinary Features
The HTL40 LINK and HTL40 displays feature an impressive array of digital
connections, including HDMI™ and DVI. HDMI™ is a purely digital
connection that transmits the uncompressed bitstream directly from the
source through to the display - even high definition - and is backwards
compatible with DVI. The on-board Video Processing guarantees an
image that is free from motion artefacts and that your film collection is
displayed just as the Director intended!
Wide Viewing Angle and long-life lamp
You can enjoy watching the HTL40 LINK and HTL40 from a variety of
angles and distances up to 170 degrees horizontally and vertically.
Also, the HTL40 series is equipped with a high performance, long-life
lamp (60.000 hours) for low operating costs.
36
HTL40 LINK only: the DigiOpticTMImage Processor
The HTL40 LINK features SIM2's DigiOptic™ Image Processor, the remote unit equipped with a wide choice of inputs and linked to the
display through a thin digital fibre optic cable (3,5mm - 0,14" diameter). This means incredible flexibility with the installation, greatly reducing
the need for numerous long cable runs to the display. The system is also upgradeable to accommodate future additional connections.
37
Technical
Specifications
39
GRAND CINEMA HT HT500 E-LINK HT500 E HT300 E-LINK HT300 E HT280 E
LIGHT ENGINE
DLPTMType 3 Chip DMD™ HD2+ 3-Chip DMD™ HD2+ 1 DMD HD2+ DarkChip3™ 1 DMD HD2+ DarkChip3™ 1 Chip DMD™ ED2
Resolution 1280x720 1280x720 1280x720 1280x720 1024x576
Lens High Quality, high resolution improved High Quality, high resolution improved High Quality, high resolution improved High Quality, high resolution improved High Quality, high resolution improved
Lamp power consumption & life time* 250W, 1500 hours 250W, 1500 hours 120W 8000 hours 120W 8000 hours 120W 8000 hours
INSTALLATION
Throw ratio 1,44-1,8:1 (standard lens - type L2) 1,44-1,8:1 (standard lens - type L2) 1,8-2,4:1 1,8-2,4:1 2,1-3,1:1
Lens shift V+13°-5,5° ; H +/-3,9°; V+13°-5,5° ; H +/-3,9°; V+/-8° V+/-8° V+/-10°
Digital keystone adjustment: V+/-18°; H+/-10° V+/-18°; H+/-10° V+/-18°; H+/-10° V+/-18°; H+/-10° V+/-18°; H+/-10°
Picture size (inches diagonal) 50-300 50-300 50-250 50-250 50-250
Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox, panoramic, pixel to pixel • • • • •
+ 3 custom-user adjustments
ELECTRONICS
Horizontal & vertical scan freq.: 15-80kHz/48-100Hz • • • • •
SDTV: PAL (B,G,H,I,M,N,60); SECAM; NTSC 3,58; NTSC 4,43 automatically selected • • • • •
HDTV: ATSC (480p, 720p, 1080i); 576p • + 1080i 50Hz • + 1080i 50Hz • + 1080i 50Hz • + 1080i 50Hz •
PC graphic standard: VGA, SVGA, XGA, SXGA, UXGA @ 60 Hz. • UXGA @ 65Hz • UXGA @ 65Hz • • •
On Board Video Processing • • • • •
Contrast ratio (Full ON/ Full OFF) >4300:1 >4300:1 >3500:1 >3500:1 >2500:1
Colour temperature: 3 preset colour temperatures + RC user adjustment acting • • • • •
directly on each colour (RGB)
Special video adjustments: noise reduction, fleshtone regulation • • • • •
Other special adjustments: memories/overscan • • • • •
optics for higher contrast and better optics for higher contrast and better optics for higher contrast and better optics for higher contrast and better optics for higher contrast and better
black level with both motorized black level with both motorized black level with both motorized black level with both motorized black level with both motorized
zoom and focus adj. zoom and focus adj. zoom and focus adj. zoom and focus adj. zoom and focus adj.
INPUTS/OUTPUTS
On DigiOptic™ Image Processor On DigiOptic™ Image Processor
Composite Video (RCA) 2 1 2 1 1
S-Video (mini Din 4 pin) 2 1 2 1 1
RGBS/YCrCb (RCA) - - - 1 1
RGBHV/YCrCb (RCA) 3 1 3 - RGBHV/YCrCb (BNC) 1 1 1 - RGBHV (D-Sub 15 pin) 2 1 2 1 1
DVI (DVI-D) 1 1 1 - -
TM
HDMI
1 1 1 1 1
OUT Digital Audio (Toslink) 1 1 1 1 1
RS232 (D-Sub 9 pin) 1 1 1 1 1
OUT 12V 100mA (via Jack) 2 2 2 2 2
1
Choice of 5 different lenses with these throw ratio: 0,64:1 1,2-1,44:1 1,8-2,4:1 2,4-3,6:1 3,6-5,6:1
(*) Lamp life: the hours quoted have been calculated in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding environment.
The calculated lamp life cannot be guaranteed and is not protected by warranty
40 41
GRAND CINEMA HT HT500 E-LINK HT500 E HT300 E-LINK HT300 E HT280 E
GENERAL SPECIFICATIONS
Software control: upgradable via RS232 serial interface • • • • •
Power consumption: 340W max 340W max 180W max 180W max 180W max
Mains voltage range: 120-240Vac ±10% (48/62Hz) • • • • •
Weight: 28Kg lbs (61.7) 28 Kg. (61.7 lbs) 5.8 Kg. (12.8 lbs) 5.8 Kg. (12.8 lbs) 5.8 Kg. (12.8 lbs)
Dimensions (WxHxD): 540x210x615mm 540x210x615mm 350x173x318mm 350x173x318mm 350x173x318mm
SUPPLIED ACCESSORIES
Installation and User Manual • • • • •
AC power cords 2m (EU, UK ed USA) • • • • •
Remote control and batteries - - - - Backlit remote control and batteries • • • • •
DigiOptic™ Image Processor • - • - Fibre optics cable - 20m • - • - -
OPTIONAL ACCESSORIES
HT BRKT floor and ceiling mounting bracket • (ceiling mounting only) • • • •
HT fibre optics cable 40m • - • - -
(21.25”x8.27”x24.21”) (21.25”x8.27”x24.21”) (13.8”x6.8”x12.5”) (13.8”x6.8”x12.5”) (13.8”x6.8”x12.5”)
42 43
GRAND CINEMA RTX RTX55-H RTX45 RTX55 TV
LIGHT ENGINE
DLPTMType 1 Chip DMD HD2+ DarkChip2 1 Chip DMD HD2 1 Chip DMD HD2+ DarkChip2
Resolution 1280x720 1280x720 1280x720
Lens High quality, high resolution optics High quality, high resolution optics High quality, high resolution optics
Lamp power consumption & life time* 120W 6000 hours 120W 6000 hours 120W 6000 hours
INSTALLATION
Picture size (inches diagonal): 55 45 55
Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox, 3 custom-user adjustments
+ panoramic and pixel to pixel • • • 2
ELECTRONICS
Horizontal & Vertical scan freq.: 15-80kHz/48-100Hz (freq. Max H = UXGA 60Hz) • • •
SDTV: PAL (B,G,H,I,M,N,60); SECAM; NTSC 3,58; NTSC 4,43 automatically selected • • • no PAL (M,N)
ATSC (480p, 720p, 1080i); 576p • + 1080i 50Hz • •
PC graphic standards: VGA, SVGA, XGA, UXGA (1600x1200) • • •
On Board Video Processing • • •
Contrast ratio (Full ON/ Full OFF) >2300:1 >2000:1 >2300:1
Colour temperature: 3 preset colour temperatures + a RC user adjustment • + high and low light • •
acting directly on each colour (RG
Special video adjustment: noise reduction, fleshtone regulation • Other special adjustments: memories/overscan • Hyperband tuner - - •
Tuner: PAL (B/G, D, K, I), SECAM (B/G, D, K, L, L1) - - •
Audio: 2x20W RMS with built-in amplifier - - •
SRS TXT surround and equalizer - - •
Teletext leel 1.5 FLOP - - •
Sleep Timer / child lock - - •
custom-user adjustments
-
-
GENERAL SPECIFICATIONS
Control: control software upgradable via RS232 serial interface • • •
Power consumption 170W max 170W max 270W max
Mains voltage range: 100-240Vac ±10% (48/62Hz) • • 240 Vac ±10% (48/62Hz)
Weight: 85 Kg (187,4 lbs) 65 Kg (143,3 lbs) 105 Kg (187,4 lbs)
Dimensions (WxHxD): 1494 x 1228 x 425 mm 1228x1108x374 mm 1494x1228x425mm
(*) Lamp life: the hours quoted have been calculated in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding environment.
The calculated lamp life cannot be guaranteed and is not protected by warranty
(58.82”x48.35”x16.73”) (48.35x43.62x14.72) (58.82”x48.35”x16.73”)
44 45
GRAND CINEMA RTX RTX55-H RTX45 RTX55 TV
INPUTS / OUTPUTS on DigiOptic™ Image Processor on DigiOptic™ Image Processor
Aerial75 Ohm - - 1
SCART 1 - - 1 composite video or 1 RGB + L/R audio
SCART 2 - - 1 composite video + L/R audio
L/R audio (RCA) - input - - 3
Amplified L/R audio - input - - 1 (90W max)
L/R audio (RCA) - output - - 1
Subwoofer (RCA) - - 1
Composite Video (RCA) 2 2 1
S-Video (mini Din 4 pin) 2 2 1
RGBS/YCrCb (RCA) - - 1
RGBHV/YCrCb (RCA) 3 3 RGBHV/YCrCb (BNC) 1 1 RGBHV (D-Sub 15 pin) 2 2 1
DVI (DVI-D) 1 1 HDMI 1 - OUT Digital Audio (Toslink) 1 1 RS232 (D-Sub 9 pin) 1 1 software updates only
OUT 12V 100mA (via Jack) 2 2 -
SUPPLIED ACCESSORIES
Installation and User Manual • • •
AC power cords 2m (EU, UK ed USA) • • • (EU and UKonly)
Remote control and batteries - • •
Backlit remote control and batteries • - DigiOptic™ Image Processor • • Fibre optics cable- 20m • • -
OPTIONAL ACCESSORIES
HT fibre optics cable 40m • • -
46 47
GRAND CINEMA HTL HTL40 LINK HTL40
GRAND CINEMA HTL HTL40 LINK HTL40
DISPLAY
LCD PANEL: latest generation TFT LCD latest generation TFT LCD
Resolution: Wide XGA (1366x768 x3) 3.147.264 pixels for HD Images • •
Picture Format - Screen Size: true 16:9, 40” • •
Brightness: 600 cd/m² • •
Contrast ratio: 1000:1 • •
Viewing Angle: 170° • •
Lamp life time*: 60.000 hrs in standard lighting conditions and brightness • •
Response Time: Typical 8ms • •
ELECTRONICS
Horiz. scan freq.: 15-80KHz - Vert. Scan freq.: 48 - 85Hz • •
Aspect ratio: 16:9 Anamorphic, LetterBox, panoramic, pixel to pixel + 3 custom-user adjustments
Video Signals Compatibility: PAL (B, G, H, I, M, N, 60); SECAM; NTSC 3,58; NTSC 4,43 automatically selected
HDTV: ATSC (480p, 720p, 1080i); 576p + 1080i 50Hz;
PC graphic standard: VGA, SVGA, XGA, SXGA, UXGA (1600X1200 60 Hz)
On Board Video Processing • •
Colour Temperature: 3 preset colour temperature selectable by OSD • •
Special adjustments: noise reduction, fleshtone regulation, overscan, • •
Intelligent picture memory functions: 75 total - 3 for each input • •
INPUTS/OUTPUTS (on DigiOpticTMImage Processor)
Composite Video (RCA) 2 1
S-Video (mini Din 4 pin) 2 1
RGBS/YCrCb (RCA) - 2
RGBHV/YCrCb (RCA) 3 RGBHV/YCrCb (BNC) 1 RGBHV (D-Sub 15 pin) 2 1
DVI (DVI-D) 1 HDMITM- HDCP 1 1
OUT Digital Audio (Toslink) 1 1
RS232 (D-Sub 9 pin) 1 1
OUT 12V 100 mA (via jack) 2 USB - 1
SUPPLIED ACCESSORIES
Installation and User Manual • •
AC Power cords (EU,UK,and USA) 6.6 ft (2m) • •
Backlit remote control and batteries • •
DigiOptic™ Image Processor • Fibre optics cable - 20 m (65,6 ft) • -
OPTIONAL ACCESSORIES
Crystal desktop support • •
Aluminium desktop support • •
HT fibre optics cable 40 m (131,2 ft) • -
CABINET COLOURS AND MATERIALS
Matt Silver Rear Panel and stand in Aluminium • •
Black Rosewood: Rosewood rear panel and Crystal stand • •
Whitened Oak: Whitened Oak rear panel and Crystal stand • •
GENERAL SPECIFICATIONS
Power Consuption: 200 W • •
Mains Voltage Range: 90 - 240V AC • •
Weight: 35 Kg net (77 lbs) • •
Dimensions (WxHxD) without tabletop support (stand) 1106x652x102 mm 1106x652x102 mm
43.54”x25.67”x4” 43.54”x25.67”x4”
Dimensions (WxHxD) with tabletop support (stand) 1106x702x230 mm 1106x702x230 mm
43.54”x27.63”x9.05” 43.54”x27.63”x9.05”
(*) Lamp life: the hours quoted have been calculated in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding environment.
The calculated lamp life cannot be guaranteed and is not protected by warranty
