Page 1
SST-ST60F
STRIDER SERIES
Page 2
01
This specification describes the requirements of 600W with active P.F.C Switching Power
Supply with an ATX form-factor,+5V standby voltage,fan control,ATX12V 2.3/EPS12V 2.91
Power supply version, remote on/off control,full range input capability and forced air cooling
characteristics.
1. AC INPUT REQUIREMENTS
The input voltage, current, and frequency requirements for continuous
operation are stated below.
90 100 240 265 VACrms
47 63 Hz
lin 10 5 A
Parameter Min
Nom Max Unit
Vin Frequency
Vin
Power factor correction (PF)>0.95 at full load.
1.1 Inrush current limiting
2. DC OUTPUT
2.1 DC voltage regulation
50A @ 115Vrms
100A @ 230Vrms (at 25 C ambient cold start).
Page 3
STRIDER SST-ST60F
02
2.2 Load Ranges
2.2.1 Typical Power Distribution for 600W ATX12V Configuration
Parameter Min
Nom.
PeakMax Unit
1.Maximum continuous total DC output power should not exceed 600W
2.Maximum continuous combined load on +3.3VDC and +5VDC outputs shall not
exceed 170W
3.The maximum peak total DC output power shall not exceeed 620 watts
4.Peak power and current loading shall be supported for a minimum of 12 second.
5.Maximum combined current for the 12V outputs shall be 48A.
2.3 DC Output Ripple/Noise.
2.3.1 Ripple regulation
mVp-p
mVp-p
mVp-p
mVp-p
mVp-p
2.3.2 Definition
The ripple voltage of the outputs shall be measured at the pins of the output connector
when terminated in the load impedance specified in figure 1. Ripple and noise are
measured at the connectors with a 0.1uF ceramic capacitor and a 10uF electrolytic
capacitor to simulate system loading.Ripple shall be measured under any condition of
line voltage,output load,line frequency,operation temperature.
Page 4
03
AC Hot
AC Neutral
Power Supply
Vout
Vreturn
10uF 0.1uF
Load
Scope
AC Ground
Figure 1. Ripple/Noise voltage test circuit
2.4 Overshoot
Any overshoot at turn on or turn off shall be less 10% of the nominal voltage value, all
outputs shall be within the regulation limit of section 2.0 before issuing the power good
signal of section 4.0.
2.5 Efficiency
2.5.1 Power supply typical efficiency is 80% min under 20% Load / 50% Load / 100%
Load at nominal input voltage of 115VAC .
2.5.2 Other Low Power System Requirements
To help meet the Blue Angel*, RAL-UZ 78, US Presidential executive order 13221, future
EPA requirements, and other low Power system requirements, it is recommended that
the +5VSB standby supply should be as efficient as possible. Standby efficiency is
measured with the main outputs off (PS_ON# high state). Standby efficiency should
be greater than 50% with a minimum loading of 100mA at input 115Vac. Pin 1W with a
minimum loading of 50mA at input 230Vac.
2.6 Remote on/off control
When the logic level "PS-ON" is low, the DC outputs are to be enabled.
When the logic level is high or open collector, the DC outputs are to be disabled.
2.3.3 Ripple/Noise voltage test circuit
Page 5
STRIDER SST-ST60F
04
3. PROTECTION
3.1 Over-power protection
The power supply will be shutdown and latch off when output power is 110%~150%.
3.2 Over voltage protection
The over voltage sense circuitry and reference shall reside in packages that are separate
and distinct from the regulator control circuity and reference.No single point fault shall be
able to cause a sustained over voltage condition on any or all outputs.The supply shall
provide latch-mode over voltage protection as defined in Table.
output Minimum Nominal Maximum Unit
+12V1DC or +12V2DC
output Minimum Nominal Maximum Unit
+12V1DC or +12V2DC
3.3 Under voltage protection
The under voltage sense circuitry and reference shall reside in packages that are separate
and distinct from the regulator control circuity and reference.No single point fault shall be
able to cause a sustained under voltage condition on any or all outputs.The supply shall
provide latch-mode under voltage protection as defined in Table.
3.4 Over Current Protection
+5VDC, +12V1DC, +12V2DC and +3.3VDC have separate over current protection circuits
to meet 240VA safety requirement.
3.5 Short circuit
An output short circuit is defined as any output impedance of less than 0.1 ohms.The
power supply shall shut down and latch off for shorting the +3.3VDC,+5VDC,or+12VDC
rails to return or any other rail. Shorts between main output rails and +5VSB shall not
cause any damage to the power supply. The power supply shall either shut down and
latch off or fold back for shorting the negative rails.+5VSB must be capable of being
shorted indefinitely,but when the short is removed,the power supply shall recover
automatically or by cycling PS_ON#.The power supply shall be capable of withstanding
a continuous short-circuit to the output without damage or overstress to the unit.
Page 6
05
3.6 No load operation
No damage or hazardous condition should occur with all the DC output connectors
disconnected from the load.The power supply may latch into the shutdown state.
3.7 Over temperature protection
In the event of a fan failure or the vents being blocked, the power supply shall
have protection such that any over temperature condition caused by these events
shall protect the power supply from damage or abnormal and/or dangerous
operation.A shutdown of the power supply is acceptable A temperature derating
factor less than 110% for the critical components is recommended before the
power supply is shut down. Temperature derating factors higher than 110% can
be evaluated on a case by case basis.
4. TIMING
4.1 Signal timing drawing
Figure 4 is a reference for signal timing for main power connector signals and rails.
T1
T2
T3
T5
T4
T6
VAC
PS-ON
PW-OK
PW-OK Sense level=95% of
nominal
+12V/+5V/+3.3V O/P
Figure 2. PS-OK Timing Sequence
(1)T2: Rise time (0.1ms~20ms)
(2)T3: Power good turn on delay time (100ms~500ms)
(3)T4: Power good turn off delay time (1ms min)
(4)T5: Rise time (10ms max)
4.2 Hold up time (T6 of figure 2.)
When the power loss its input power, the output shall maintain 16ms in regulation
ranges at nominal input voltage. (AC:115V/60Hz or 230V/50Hz)
Page 7
STRIDER SST-ST60F
06
5. ENVIRONMENT
5.1 Operation
Temperature
Relative Humidity 5 to 90%, non-condensing
5.2 Shipping and Storage
5.3 Altitude
Operating 3,000FT max.
Storage 15,000FT max.
6. SAFETY
6.1 Underwriters Laboratory (UL) recognition.
The power supply designed to meet UL 1950.
6.2 The power supply must bear the German Bauart Mark from TUV.
7.0 ELECTROMAGNETIC COMPATIBILITY (EMC)
7.1 ELECTROSTATIC DISCHARGE (ESD) – EN 61000 – 4 - 2：1995
7.2 ELECTRICAL FAST TRANSIENT / BURST ( EFT/B) – EN 61000 – 4 - 4：1995
7.3 SURGE – EN 61000 – 4 - 5：1995
7.4 POWER FREQUENCY MAGNETIC FIELD – EN 61000 – 4 - 8：1993
7.5 VOLTAGE DIPS – RN 61000 – 4 - 11：1994
7.6 RADIATED SUSCEPTIBILTY – EN 61000 – 4 - 3：1996
7.7 CONDUCTED SUSCEPTIBILTY – EN 61000 – 4 - 6：1996
7.8 VOLTAGE FLUCTATION – EN 61000 – 3 - 3：1995
Page 8
07
7.9 EN61000-3-2 harmonic current emissions.
If applicable to sales in Europe, the power supply shall meet the requirements of EN
61000-3-2 Class D and the Guidelines for the Suppression of Harmonics in Appliances
and General Use Equipment Class D for harmonic line current content at full-rated
power.
7.10 EN55022 Class B Radio interference (CISPR 22).
7.11 FCC Part 15, Subpart J class B 115VAC operation.
8. MTBF
8.1 MTBF (MEAN TIME BETWEEN FAILURES) CALCULATION
9. MECHANICAL REQUIREMENTS
9.1 Physical Dimension
150mm (W) × 86mm (H) × 160mm (D)
9.2 Connectors
M/B 24PIN connector
Orange(22AWG)
Blue (18AWG)
Green(18AWG)
Grey (18AWG)
Yellow/Black stripe
Yellow/Black stripe
Red (22AWG)
The demonstrated MTBF shall be 100,000 hours of continuous operation at 25 C,full
load,80% confidence limit and nominal line. The MTBF of the power supply shall be
calculated in accordance with MIL-STD-217D/E. The DC FAN is not included.
Page 9
08
EPS 12V 8PIN connector
18AWG wire Signal Pin Pin Signal 18AWG wire
Yellow +12V2 5 1 COM Black
Yellow +12V2 6 2 COM Black
+12V1 7 3 COM Black
+12V1 8 4 COM Black
Yellow/Black stripe
Yellow/Black stripe
ATX 12V 4PIN
18AWG wire Signal Pin Pin Signal 18AWG wire
Black GND 1 3 +12V1 Yellow
Black GND 2 4 +12V1 Yellow
Yellow/White stripe
Yellow/White stripe
SATA connector
STRIDER SST-ST60F
Page 10
09
6PIN PCI Express connector #1 & #2 & #3 & #4
18AWG wire Signal Pin Pin Signal 22AWG wire
+12V2 1 4 COM Black
+12V2 2 5 COM Black
+12V2 3 6 COM Black
Yellow/Blue stripe
Yellow/Blue stripe
Yellow/Blue stripe
8PIN PCI Express connector
+12V2 1 5 COM Black
+12V2 2 6 COM Black
+12V2 3 7 COM Black
COM 4 8 COM Black
18AWG wire Signal Pin Pin Signal 22AWG wire
Yellow/Blue stripe
Yellow/Blue stripe
Yellow/Blue stripe
Black sense1
10. FAN SPEED CONTROL
Fan voltage varies with the ambient temperature or output power.
Page 11
STRIDER SST-ST60F
10
