SilverStone SST-ST45SF-G User Manual

The SFX form factor milestone

The SFX form factor milestone

Special Features:

Support standard SFX form factor and ATX via included bracket
80 PLUS Gold level efficiency (87%~90% efficiency at 20%~100% loading)
100% modular cables
450W continuous power output at 40℃ operating temperature rated for 24/7 operation
Class-leading single +12V rail with 37A

Strict ±3% voltage regulation and low ripple & noise
Silent running 80mm fan with 18dBA minimum
Single PCI-E 8pin and dual PCI-E 6pin connectors support
Active PFC

www.silverstonetek.com

ST45SF-G

The SFX form factor milestone

Specifications

Color：Black (lead-free paint)
Cooling System：Single 80mm silent fan
Noise Level：18 BA minimum
Weight：1.45 kg
Dimension：125 mm (W) × 63.5 mm (H) × 100 mm (D)
MTBF：100,000 hours at 25C , full load
Operating temperature：0 ~ 40C

d

Stability

(ripple and noise)

+3%

Performance(output)

444W / 450W for +12V output

100%

80%

+1%

+3%

+5%

60%

Bronze

Efficency

80 Plus Gold

Gold

Silver

Model No. Max. output +3.3V +12V -12V +5Vsb

SST-ST45SF-G

450W

19A

14A 37A

90W

444W

0.3A

2.5A

3.6W 12.5W

MB 24/20P CPU 4+4P PCI-E 6+2P PCI-E 6P SATA Peripheral 4P Floppy 4PModel No.

SST-ST45SF-G

x 1 x 1

x 1

Size

100mm

180mm

140mm

100mm

Operating temperature

(component grade)

25C

40C

50C

40 C

40

20

0

Quietness

d

18 BA

x 1x 1 x 3 x 2
