SilverStone raven RVX01 Instruction Manual

RVX01

The following manual and guides were carefully prepared by the RAVEN engineering team to
help you maximize the potential of your SilverStone product. Please keep this manual for future
reference when upgrading or performing maintenance on your system. A copy of this manual can also
be downloaded from our website at:

Installation and system optimization guide:

Instroduction

Special features

Specification

Disassemble Chart

Installation Guide

Connector Definition

Component Size Limitations

Optimal Thermal Performance Layout

Upgrade And Mainterance

Warranty

P.1

P.1

P.1

P.2

P.4

P.11

P.14

P.20

P.22

P.25

RVX01

Redefine value and tradition

1

Model
Material
Motherboard
Drive bay

Cooling system

Expansion slot
Front I/O port
Power supply
Expansion card
CPU cooler limit
Dimensions
*Depending on installed drives

SST-RVX01BR (black with red trim), SST- RVX01BR-W (black with red trim + window)
Plastic outer shell, steel body
ATX (up to 12” x 11”), Micro-ATX
External
Internal
Front
Top
Bottom
7
USB 3.0 x 2, Audio x 1, MIC x 1
Optional PS2 (ATX)
Compatible up to 13.7”, width restriction* - 4.92”~5.91”
162mm
215mm (W) x 485mm (H) x 500mm (D) , 52.1 liters

None

2.5” or 3.5” x 4
120mm fan slot x 1
120mm fan slot x 1
120mm Air Penetrator x 3, 1200±10% rpm, 19.7dBA

After completing the evolutionary RAVEN RV05 with 5.25” drive bay
design completely removed, the RAVEN team created another forward
thinking line of cases with the introduction of the “RAVEN X” subcategory.
This line will not only retain the essence of what made the original
RAVEN series great with features such as signature aggressive styling
and 90 degree rotated layout, but also cater to enthusiasts looking
for more exciting designs in an entry-level price point. With the smallest
ever footprint for a ATX RA VEN tower case, the R VX01 has remarkably
accommodating interior that can easily fit large ATX motherboards
up to 12” x 11”, full size graphics card, four 2.5”/3.5” drives, and spaces
for up to three radiators.
From the factory, the case will come fully equipped with three of
SilverStone’s famed Air Penetrator fans for class-leading thermal
performance and easy to reach filter for easy maintenance. If you
are looking to build an attractive, relatively compact and powerful PC
on a budget, the RVX01’s combination of high affordability, top-level
cooling ability, and flexible layout will fulfill the task beautifully.

Signature RAVEN styling touches
90 degree motherboard mounting from legendary RAVEN RV01
Three 120mm Air Penetrator fans included for sublime vertical air cooling
Positive pressure design for excellent cooling/quietness and dust-prevention
Quick access filter for convenient maintenance
Support up to three sets of liquid cooling radiators

Introduction

Special features

Specifications

MANUAL

ZIPPER BAG

SCREW E #6-32 X5

SCREW C #6-32 X5

SCREW A #6-32 X4
SCREW B M3 X4

SCREW SLEEVE

HDD-TRAY

SCREW D #6-32 X5

USER INSTALLATION GUIDE

MOTHERBOARD STABDOFF

SECURE MOTHERBOARD, PSU and 3.5” HDD (For HDD bracket)

SECURE 2.5” HDD

2.5” OR 3.5” HDD

CONTAINS PARTS

SECURE 3.5” HDD

SECURE 3.5” HDD (For HDD tray)

SECURE STANDOFFS

PICTURE ITEM PURPOSE

2

Disassemble Chart

TOP COVER

12025 FAN X3

BOTTOM-FILTER

PSU (OPTION)

POWER BUTTON

USB 3.0 X2 + MIC + SPK

RESET BUTTON

ATX MB (OPTION)

3.5” & 2.5” HDD X4
(OPTION)

RIGHT-SIDE-PANEL

LEFT-SIDE-PANEL

3

Disassemble Chart

01

02

Lösen Sie die Rändelschrauben
von der Rückseite der oberen
Abdeckung; dann Abdeckung in
der abgebildeten Richtung abziehen.

Dévissez les vis à oreilles depuis la
face arrière du capot supérieur puis
retirez le capot supérieur dans la
direction indiquée dans l'illustration.

Desatornille los tornillos manuales
de la parte posterior de la cubierta
superior y luego tire de la cubierta
superior en la dirección que se muestra
en la ilustración.

Svitare le viti a testa zigrinata dal lato
posteriore del coperchio superiore,
quindi sollevare il coperchio superiore
nella direzione mostrata in figura.

Unscrew thumb screws from the
rear side of the top cover then pull
top cover off in the direction as
shown in the illustration.

Отверните винты с накатанной
головкой на задней части верхней
крышки, затем вытяните верхнюю
крышку в направлении, указанном
на рисунке.

상단 커버 뒷면에서 엄지 나사를
풀고, 아래 그림에 표시된 방향으로
커버를 당겨서 벗깁니다.

將上蓋後方的手扭螺絲移除,
將上蓋依指示方向退出

将上盖后方的手扭螺丝移除,
将上盖依指示方向退出

上部カバーの背面からサムスクリ

ューを 外してから、図に示される方

向にカバーを外します。

Lösen Sie die beiden Schrauben an den
linken und rechten Seitenwänden, nehmen
Sie die Seitenwände ab.

Desserrez les vis des deux panneaux
latéraux pour les retirer

Desatornille dos tornillos de los paneles
izquierdo y derecho para quitarlos.

Per rimuovere i pannelli laterali allentare, per
entrambi, le due viti di serraggio.

Loosen two screws from both left and right
side panels to remove them.

Отвинтите по два винта, крепящих
левую и правую боковых панели, и
снимите панели.

왼쪽과 오른쪽 사이드 패널에서 두 개씩
나사를 풀어 사이드 패널을 제거합니다.

取下左右側板各兩顆螺絲，卸下側板。

取下左右侧板各两颗螺丝，卸下侧板。

両方の左右パネルからネジ2本を緩めて、
取り外します。

have all components collected
check that all components do not have compatibility problems with each other or with the case
if possible, assemble the components outside the case first to make sure they are working
keep the motherboard manual ready for reference during installation
prepare a Philips screwdriver.

1
2
3
4
5

Before you begin, please make sure that you

4

Installation Guide

03

04

Bauen Sie das Netzteil ins
Gehäuse ein

Installez la source d’alimentation
dans le châssis.

Instale la fuente de alimentación
en la carcasa

Installazione dell’alimentatore
nel case.

Install power supply into the
case.

Установите в корпус блок
питания.

전원 공급장치를 케이스에
설치합니다.

安裝電源

安装电源

電源をケースに取り付けます。

Installieren Sie das hintere
I/O-Blech im Gehäuse.

Installez la plaque arrière de la
carte mère dans le boîtier.

Instale la placa trasera de E/S
de la placa base en la carcasa.

Installare la placca I/O della
scheda madre nella sede
preposta.

Insert the I/O shield included
with your motherboard

Установите в корпус заднюю
панель ввода-вывода
материнской платы.

메인보드 후방 I/O 판을
케이스에 장착합니다.

將I/O彈片裝上機殼

将I/O弹片装上机壳

ケース内にマザーボード後部I/O

プレートをインストールします。

5

05

06

Lösen Sie zum Entfernen die Schrauben von
der Abdeckplatte des Erweiterungssteckplatzes,
entfernen Sie zur Installation von Karten wie
erforderlich die Abdeckungen der
Erweiterungssteckplätze.

Retirez les vis de la plaque du couvercle de
l'emplacement d'extension pour le retirer,
puis retirez les couvercles de l'emplacement
d'extension si nécessaire pour installation
ultérieure d'une carte.

Retire los tornillos de la cubierta del zócalo de
expansión para retirarla, luego retire las
cubiertas de los zócalos de expansión según
sea necesario para la instalación posterior de
tarjetas.

Rimuovere le viti del coperchio di un alloggio
di espansione per rimuoverlo, quindi rimuovere
i coperchi degli alloggi di espansione necessari
per la successiva installazione della scheda.

Remove screws from expansion slot cover
plate to remove it, then remove expansion
slot covers as needed for card installation
later.

Отверните винты крышки слота
расширения и снимите крышку, затем
снимите крышки слотов расширения
для установки карты.

확장 슬롯 커버 플레이트에서 나사를
풀어 플레이트를 분리한 후 카드 설치를
위해 필요한 경우 확장 슬롯 커버를
분리합니다.

用螺絲取下擴充卡檔板蓋，接著依安裝
需求移除擴充卡的檔片

用螺丝取下扩充卡档板盖，接着依安装
需求移除扩充卡的档片

拡張スロットカバ ープレ ートのネ ジを外

して、後からインストールするカードに

備えて拡張スロットカバ ーを 取り外しま
す。

Stecken Sie die Abstandshalter wie für Ihr
Motherboard erforderlich in die entsprechenden
Befestigungsbohrungen. Installieren Sie dann
das Motherboard.

Insérez les entretoises comme requis par
votre carte mère dans les trous de montage
correspondant, puis installez la carte mere.

Inserte los soportes según sea necesario
para su placa base en los agujeros de montaje
correspondientes, luego instale la placa base.

Inserire nei corrispondenti fori di fissaggio i
distanziatori, come richiesto dalla scheda
madre, quindi installare la scheda madre.

Insert standoffs as required by your
motherboard in corresponding mounting
holes, then install motherboard.

Принеобходимостиустановите
опорныестойкидлясистемной
платывсоответствующие
крепежныеотверстия, затем
установитесистемнуюплату.

메인보드에서 필요한 경우 해당 장착
구멍에 스탠드오프를 삽입한 후
메인보드를 설치합니다.

請依需求安裝主機板螺柱, 安裝主機板

请依需求安装主板螺柱, 安装主板

マザーボードに応じて、必要な孔にスペ
ーサーを取り付けてからマザーボードを
取り付けま す。

6

07

08

Schließen Sie alle Kabel an.

Branchez tous les câbles et les
fils.

Conecte todos los cables.

Collegare tutti i cavi ed i fili.

Connect all cables and wires

Подключите все кабели и
провода.

모든 케이블과 전선을
연결합니다.

將連接所有線材

将连接所有线材

ケーブルとリード線を全て接続

します。

Nach Installation aller erforderlichen
Erweiterungskarten und Stromkabel
installieren Sie die Abdeckplatte des
Erweiterungssteckplatzes wieder;
befestigen Sie sie mit Schrauben.

Après avoir installé toutes les cartes
d'extension nécessaires et le câble
d'alimentation, réinstallez la plaque du
couvercle de l'emplacement d'extension
et fixez-la solidement avec les vis.

Tras instalar todas las tarjetas de
expansión y cable de potencia necesarios,
reinstale la placa que cubre el zócalo de
expansión y fíjela con tornillos.

Dopo l'installazione di tutte le schede di
espansione necessarie e del cavo di
alimentazione, reinstallare il coperchio
alloggio d’espansione e fissarlo con le
viti.

After installing all required expansion
cards and power cable, reinstall
expansion slot cover plate and
secure with screws.

После установки всех нужных
карт расширения и кабеля питания
установите крышку слота
расширения на место и закрепите
винтами.

필요한 확장 카드와 전원 케이블을
모두 설치한 후 확장 슬롯 커버
플레이트를 다시 설치하고 나사로
고정합니다.

裝上擴充卡及供電線後，將擴充卡擋
板夾片裝回、鎖固

装上扩充卡及供电线后，将扩充卡挡
板夹片装回、锁固

必要な拡張カード並びに電源ケーブル
を全て装着してから、拡張スロットカバ
ープレ ートを戻して ネジで固 定します。

7
