SilverStone Lascala LC11,Lascala LC11M User Manual

LC11 / LC11M

Specification:

Product Overview

LC11

Disassemble Chart

MICRO ATX M/B

8025 FAN

RISER CARD(AGP*1+PCI*2)

TOP PANEL

FRONT IO (1394 + AUDIO)

FRONT IO (USB * 4)

LEFT PANEL

POWER SW

RESET SW

3.5 BAY * 1 ( HIDDEN )

5.25 BAY * 1

RIGHT PANEL

DRIVE BAY DOOR

BUTTON

8025 FAN

3.5 BAY * 2 ( HIDDEN )

BOTTOM PANEL

TFX 240W PFC POWER SUPPLY

Material: Aluminum front panel, 0.8mm SECC body
Color: Black & Silver
Motherboard: Micro ATX
Drive Bay: External - 5.25" x 1
Internal - 3.5" x 3
Cooling System: Front - 80mm intake, 2050rpm, 21dBA
Left side - 80mm exhaust, 2050rpm, 21dBA
Oversized mesh grill CPU air intake vent
Riser Cards: 1 AGP + 2 PCI
Expansion Slot: 3
Front I/O Port: USB2.0 x 4, IEEE1394 x 1, audio x 1, MIC x 1
Power Supply: TFX 240W PFC / TFX 300W PFC
Net Weight: 7.2 kg
Dimension: 424 mm (W) x 96 mm (H) x 430 mm (D)

Product Overview

Specification:

LC11M

Material: Aluminum front panel, 0.8mm SECC body
Color: Black & Silver
Motherboard: Micro ATX
Drive Bay: External - 5.25" x 1
Internal - 3.5" x 3
Cooling System: Front - 80mm intake, 2050rpm, 21dBA
Left side - 80mm exhaust, 2050rpm, 21dBA
Oversized mesh grill CPU air intake vent
Riser Cards: 1 AGP + 2 PCI
Expansion Slot: 3
Front I/O Port: USB2.0 x 4, IEEE1394 x 1, audio x 1, MIC x 1
Multimedia: VFD, IR, remote control, iMON media center software
Power Supply: TFX 240W PFC / TFX 300W PFC
Net Weight: 7.2 kg
Dimension: 424 mm (W) x 96 mm (H) x 430 mm (D)

Optional PCI EXPRESS X16 RISER CARD

Model Matrix

MODEL

240w(PFC) Multimedia

Multimedia

LC11B(Black)

LC11S(Silver)

LC11B - 300

LC11S - 300

LC11B - M

LC11S - M

LC11B - M300

LC11S - M300

300w(PFC)

RC01【Sold Separately】
