Lifestyle Automation
Transview
InterVedo
OPERATION MANUAL
Version TIV01.02
SC-TIV01
Table of Contents
Introduction
Introduction to the Transview® InterVedo
Electrical specifications
Instructions
Installation instructions
Download and registration of the Silux Control® app
®
®
Pairing the Transview
InterVedo
Pairing the Transview® InterVedo
®
®
Joining to a secondary mobile device
Factory reset
Warranty & Support
1. Troubleshooting
2. Warranty
I. What this warranty covers
II. What period does this warranty cover
III. What Silux Control® will do to correct any problems
IV. What is not covered by this warranty
3. Support
4. Disclaimer of liability
Introduction
Cloud
Introduction to the Transview® InterVedo
®
The Transview® InterVedo® is one of the many useful and wonderful products that form part of the
®
Silux Control
automation series. The purpose of this product is to monitor your home/office. With
the dual motion PIR detection, you can now have peace of mind with real-time notifications and
®
updates sent to your mobile device, viewable anywhere in the world via the Silux Control
®
can easily adjust the Transview
InterVedo® to suit your lifestyle, via the Silux Control® app. No more
cloud. You
need for a DVR, store all on a cloud.
Electrical specifications
Input
Operating Temperature
Storage Temperature
WiFi Features
Micro USB 5V / 4 x AA batteries
0 ºC ~ 40 ºC 10% ~90% RH
-10 ºC ~ -70 ºC 5% ~90% RH
Remote cloud connectivity
Cloud backup and restore
Memory
WIFi Module & Encryption
WiFi Range
Built in 32GB (up to 6000 recordings)
WPA, WPA2 WPA/WPA2
±30m
Language
OS
App
English, others coming soon
Android 4.0+, iOS 8.0+, Windows 7+
Silux Control
Silux Control
®
can be integrated with other automation features of
®
.
IF YOU FEEL UNCOMFORTABLE OR YOU ARE UNFAMILIAR WITH HOUSEHOLD
ELECTRICAL WIRING, WE RECOMMEND THAT YOU USE A QUALIFIED ELECTRICIAN TO
INSTALL THESE PRODUCTS FOR YOU.
Instructions
Before continuing with installing and pairing the device, please ensure that your Silux
Control
®
app is installed and registered.
4.1.1
4.2.1
4.1.2
4.2.4
4.1.3
OFF
4.2.2
ON
4.2.3
4.3.2
4.3.1
Installation instructions
Connecting to power using batteries
Please note batteries are primarily for backup.
Step 1. At the bottom of the Transview
Step 2. Insert four AA batteries into the battery compartment
Please note: Pay careful attention to the orientation of the batteries when you insert them.
Step 3. Close the battery door.
Connecting to power using the power supply adapter
Step 1. Switch OFF the plug socket and plug the USB adapter into the plug socket.
Step 2. Plug the USB cable into the adapter and the micro USB on the other end of the cable into the
micro USB slot by opening the small rubber cover at the bottom of the device, as indicated.
Step 3. Switch the power socket back ON.
Please note: If the RED LED is not flashing, reset the device by pressing the pin provided firmly into
the hole for 5 seconds. You will hear a sound, followed by a RED light, indicating that the camera
was successfully reset and has power.
®
Mounting the Transview
Step 1 . Use the magnet bracket plastics and mark with a pencil or pen where you would like to
mount your camera.
Step 2. Drill a hole into the wall, insert the wall plug, screw in the mounting screw and hook your
magnet bracket onto the screw head.
InterVedo
®
InterVedo®, open the battery compartment.
®
Instructions
You can adjust your camera angle to the angle you prefer.
Download and registration of the Silux Control
®
Step 1. The Silux Control
search for Silux Control
app can be downloaded from the Play Store or from the iStore. Simply
®
and install it.
Step 2. Once you open the installed app, you will be directed to the Silux Control
®
app
®
login page. Tap
“Register Now”.
Step 3. You will be asked to register with an email address and password. You will then receive an
email with a verification code. Enter this code into the verification code field on your Silux Control
®
app and tap “Verify”.
Status update successful
Hub 2
Pairing the Transview® InterVedo
®
Pairing the Transview® InterVedo
®
Step 1. On the Silux Control® home screen, locate the camera icon and tap it.
Step 2. Tap the “+” at the bottom of the page, create a name for your Transview
®
the QR code located on the bottom of your camera
Step 3. You can either pair your camera with your IntelliHub
®
- To pair with IntelliHub
, tap “Link with Hub” and select your IntelliHub®.
and tap “Save”.
®
, or use it as a stand-alone camera.
®
InterVedo®, scan
- To pair as stand-alone camera, tap “Do not link”.
Step 4. If not joined to your local WiFi yet, tap “No”.
Step 5. Enter your local WiFi SSID and password.
Step 6. Ensure the RED light is flashing on your camera and that the volume on your mobile device
is turned up, then tap “Start Join”
You will hear sounds coming from your mobile device.
Step 7. A GREEN light will start flashing, tap “end join”.
The light will turn a solid GREEN indicating the join was successful.
Joining to a secondary mobile device
®
Step 1. On the Silux Control
home screen, locate the camera icon and tap it.
Step 2. Tap the ”+” sign
Step 3. Name your camera and enter the password created by the first user.
Step 4. Scan the QR code on the bottom of the Transview
®
InterVedo® and tap “Save”.
You can now tap the corresponding icons to view what your Transview InterVedo
capturing live and record it, view saved recordings, take screen-shots etc.
Factory Reset
This function will remove all paired devices and restore the settings to the original state. Press and
hold the teach button on the Transview® InterVedo® for 5 consecutive seconds. On the 5th second,
the light will turn RED and you will hear a chime. Your device will now be restored to its default state.
®
is
Warranty & Support
1. Troubleshooting
Please visit our website at www.siluxcontrol.com/FAQ for a detailed list of all the Frequently Asked Questions.
• Ensure that the power going to the device is on.
• Ensure you have the latest app installed on your device and that you’re connected to your local network.
®
• Ensure that your IntelliHub
• Ensure that this device is added to your device list when using the app.
• Ensure that you have the correct device selected when using the app.
2. Warranty
I. What this warranty covers:
®
Silux Control
warrants to the original purchaser of this Silux Control® product that the product shall be free from defects
in design, assembly, material or workmanship under normal use and operation.
Silux Control
®
‘s sole and exclusive obligation under the foregoing warranty shall be to repair or replace, at its option, any
defective product that fails during the warranty period. The expense of removal and re-installation of any item is not
included in this warranty.
WARNING: Silux Control
might have caused including 3rd party damages.
is on and connected to your local network.
®
and its distributors and resellers cannot be held responsible for any damages this product
II. What period does this warranty cover:
Silux Control
III. What Silux Control
Silux Control
®
warrants this product for 12 months.
®
will do to correct any problems:
®
will repair or replace, at its option, any defective product free of charge (excluding shipping charges for this
product).
®
Silux Control
reserves the right to discontinue any of its products without notice and disclaims any limited warranty to
repair or replace any such discontinued products.
IV. What is not covered by this warranty
Upon claiming this warranty, all above warranties are null and void if the purchased Silux Control® product is not returned
for an authorized inspection, at the sole expense of the purchaser, or if Silux Control
product has been improperly installed, altered in any way or opened/tampered with. The Silux Control
®
determines that the Silux Control®
®
product warranty
does not protect against instances of uncontrollable natural disasters such as flood, lightning, earthquake, war,
vandalism, theft, normal use wear and tear, erosion, depletion, obsolescence, physical damage, water damage, damage
due to low voltage disturbances (i.e. brownouts or sags), non-authorized program or system equipment modification
/alteration.
3. Support
Please visit our website at www.siluxcontrol.com for any other support, products, future products, and updated user
manuals.
4. Disclaimer of Liability
Please read this user manual thoroughly before using Silux Control® products. Follow all safety precautions when
installing this product. It is always recommended to use a qualified electrician.
®
Under no circumstances shall Silux Control
consequential damage that results from the use of or inability to use the Silux Control
®
Control
automation products, you expressly agree that the use of these products are at own risk. Neither Silux Control®
or its associates be liable for any direct, indirect, incidental, special or
®
products. By using any Silux
nor its affiliates, subsidiaries, or designees nor each of their respective officers, directors, employees, agents, third party
content providers, designers, contractors, distributors, merchants, sponsors or licensors can be held responsible for any
injury, death or damages this product might have caused.
