UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
A Wireless Starter Kit with the BRD4301A Radio Board is an ex­cellent starting point to get familiar with the
BGM113 Blue Gecko Module. It also provides the necessary tools for developing a Sili­con Labs wireless application.
BRD4301A contains the BGM113 Module, and it is a plug-in board for the Wireless Start­er Kit Mainboard.
The Wireless Starter Kit Mainboard contains an on-board J-Link debugger with a Packet Trace Interface and a virtual COM port, enabling application development and debugging the attached radio board as well as external hardware. The mainboard also contains sensors and peripherals for easy demonstration of some of the BGM113's many capabili­ties.
This document describes how to use the BRD4301A Radio Board together with a Wire­less Starter Kit Mainboard.
BRD4301A RADIO BOARD FEATURES
• BGM113 Blue Gecko Module with 256 kB Flash and antenna, RF matching network, crystals and decoupling (BGM113A256V1).
WIRELESS STK MAINBOARD FEATURES
• Advanced Energy Monitor
Packet Trace Interface
• Virtual COM Port
• SEGGER J-Link on-board debugger
• External device debugging
• Ethernet and USB connectivity
• Silicon Labs Si7021 Relative Humidity and Temperature sensor
• Low Power 128x128 pixel Memory LCD
• User LEDs / Pushbuttons
• 20-pin 2.54 mm EXP header
• Breakout pads for Module I/O
• CR2032 coin cell battery support
SOFTWARE SUPPORT
32 kB RAM, with integrated chip
• Simplicity Studio™
Energy Profiler
• Network Analyzer
• iOS and Android applications
ORDERING INFORMATION
• SLWRB4301A
silabs.com | Building a more connected world. Rev. 2.01

Table of Contents

1. Introduction ................................4
1.1 Radio Boards ..............................4
1.2 Ordering Information ...........................4
1.3 Getting Started .............................4
2. Hardware Overview .............................5
2.1 Hardware Layout .............................5
2.2 Block Diagram..............................6
3. Connectors ................................7
3.1 J-Link USB Connector ...........................7
3.2 Ethernet Connector ............................7
3.3 Breakout Pads .............................8
3.4 EXP Header ..............................9
3.4.1 EXP Header Pinout ..........................10
3.5 Debug Connector.............................11
3.6 Simplicity Connector............................12
3.7 Debug Adapter .............................13
4. Power Supply and Reset .......................... 14
4.1 Radio Board Power Selection ........................14
4.2 Board Controller Power...........................15
4.3 BGM113 Reset .............................15
5. Peripherals ............................... 16
5.1 Push Buttons and LEDs ..........................16
5.2 Si7021 Relative Humidity and Temperature Sensor .................17
5.3 Virtual COM Port .............................18
5.3.1 Host Interfaces ...........................19
5.3.2 Serial Configuration ..........................19
5.3.3 Hardware Handshake .........................20
6. Expansion Board ............................. 21
6.1 Accelerometer..............................21
6.2 Push Buttons and LEDs ..........................21
6.3 Joystick ................................22
7. Board Controller ............................. 23
7.1 Admin Console .............................23
7.1.1 Connecting .............................23
7.1.2 Built-in Help ............................23
7.1.3 Command Examples .........................24
silabs.com
| Building a more connected world. Rev. 2.01 | 2
7.2 Virtual UART ..............................24
8. Advanced Energy Monitor ......................... 25
8.1 Introduction...............................25
8.2 Theory of Operation ............................25
8.3 AEM Accuracy and Performance .......................26
8.4 Usage ................................26
9. On-Board Debugger ............................ 27
9.1 Host Interfaces .............................27
9.1.1 USB Interface ............................27
9.1.2 Ethernet Interface ..........................27
9.1.3 Serial Number Identification .......................27
9.2 Debug Modes ..............................28
9.3 Debugging During Battery Operation ......................29
10. Kit Configuration and Upgrades ....................... 30
10.1 Firmware Upgrades ...........................30
11. Schematics, Assembly Drawings, and BOM .................. 31
12. Mainboard Connectors .......................... 32
12.1 Mainboard Connector Pin Associations ....................32
13. Mechanical Details ............................ 33
14. Radio Board Revision History and Errata ................... 34
14.1 BRD4301A Revision History ........................34
14.2 BRD4301A Errata ............................34
15. Kit Revision History ........................... 35
15.1 SLWSTK6101B Revision History .......................35
15.2 SLWRB4301A Revision history........................35
16. Document Revision History ........................ 36
silabs.com
| Building a more connected world. Rev. 2.01 | 3
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Introduction

1. Introduction

The BGM113 Blue Gecko Module itself is featured on a Radio Board that forms a complete reference design, including the RF section and other components.
The Radio Board plugs directly into a Wireless Starter Kit Mainboard. The Mainboard features several tools for easy evaluation and development of wireless applications. An on-board J-Link debugger enables programming and debugging on the target device over USB or Ethernet. The Advanced Energy Monitor (AEM) offers real-time current and voltage monitoring. A virtual COM port interface (VCOM) provides an easy-to-use serial port connection over USB or Ethernet. The Packet Trace Interface (PTI) offers invaluable debug information about transmitted and received packets in wireless links.
All debug functionality, including AEM, VCOM and PTI, can also be used towards external target hardware instead of the attached radio board.
To further enhance its usability, the Mainboard contains sensors and peripherals demonstrating some of the many capabilities of the BGM113.
The Wireless Starter Kit for BGM113 includes an EXP board (BRD8006A) that can be connected to the Wireless STK mainboard EXP header. The EXP board contains additional peripherals such as an accelerometer, buttons, LEDs and a joystick.

1.1 Radio Boards

A Wireless Starter Kit consists of one or more mainboards and radio boards that plug into the mainboard. Different radio boards are available, each featuring different Silicon Labs devices with different operating frequency bands.
Since the mainboard is designed to work with all different radio boards, the actual pin mapping from a device pin to a mainboard feature is done on the radio board. This means that each radio board has its own pin mapping to the Wireless Starter Kit features such as buttons, LEDs, the display, the EXP header and the breakout pads. Because this pin mapping is different for every radio board, it is important that the correct document be consulted which shows the kit features in context of the radio board plugged in.
This document explains how to use the Wireless Starter Kit when the BGM113 Blue Gecko Module Radio Board (BRD4301A) is com­bined with a Wireless STK Mainboard. The combination of these two boards is hereby referred to as a Wireless Starter Kit (Wireless STK).

1.2 Ordering Information

BRD4301A can be obtained as a separate radio board, SLWRB4301A.
Table 1.1. Ordering Information
Part Number Description Contents Notes
SLWRB4301A BGM113 Blue Gecko Module Ra-
dio Board
SLWSTK6101B Blue Gecko Module Wireless
Starter Kit
1x BRD4301A BGM113 Blue Gecko Module Radio Board
1x BRD4001A Wireless Starter Kit Mainboard
1x BRD4300A BGM111 Blue Gecko Module Radio Board
1x BRD4301A BGM113 Blue Gecko Module Radio Board
1x BRD8006A Blue Gecko Module Kit Add-on Board
Discontinued
1x CR2032 Lithium battery
1x USB Type A to Mini-B cable

1.3 Getting Started

Detailed instructions for how to get started can be found on the Silicon Labs web pages:
http://www.silabs.com/bluetooth-getstarted
silabs.com | Building a more connected world. Rev. 2.01 | 4
On-board USB and Ethernet J-Link Debugger
Radio Board Breakout Pads
Plug-in Radio Board
Si7021 Humidity and Temperature Sensor
EXP header for expansion boards
Serial-port, packet trace and Advanced Energy Monitoring header
ARM Coresight 19-pin trace/debug header
Ultra-low power 128x128 pixel memory LCD, buttons and LEDs
Battery or USB power
USB-serial-port Packet-trace Advanced Energy Monitoring
EXP Board
3-axis Accelerometer 2x Push Buttons 2x LEDs Analog Joystick
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

2. Hardware Overview

2.1 Hardware Layout

The layout of the BGM113 Blue Gecko Module Wireless Starter Kit is shown in the figure below.
Hardware Overview
Figure 2.1. Kit Hardware Layout
silabs.com | Building a more connected world. Rev. 2.01 | 5
WSTK Mainboard
Peripherals
Wireless STK Mainboard
USB Mini-B
Connector
RJ-45 Ethernet
Connector
Debug
UART
Packet Trace
AEM
Debug
UART
ETM Trace
Packet Trace
AEM
Debug
UART
Packet Trace
AEM
Simplicity
Connector
Debug
Connector
Board
Controller
Multiplexer
OUT
IN
MCU
BGM113
Module
GPI
O
EXP
Header
I2C
Si7021
Temperature
& Humidity
Sensor
GPIO
User Buttons
& LEDs
Expansion Board Peripherals
Footprint for
I2C Expansion
BGM113
I2C
Accelerometer
BMA280
SPI
Buttons
&
LEDs
GPIO
Analog
Joystick
ADC input
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

2.2 Block Diagram

An overview of the BGM113 Blue Gecko Module Wireless Starter Kit is shown in the figure below.
Hardware Overview
silabs.com | Building a more connected world. Rev. 2.01 | 6
Figure 2.2. Kit Block Diagram
Simplicity Connector
Debug Connector
GND
GND
5V
5V
P25
P24
P27
P26
P29
P28
P31
P30
P33
P32
P35
P34
P37
P36
P39
P38
P41
P40
P43
P42
P45
P44
GND
GND
NC
NC
Radio Board
Connectors
EXP Header
GND
GND
VMCU
VMCU
P1
P0
P3
P2
P5
P4
P7
P6
P9
P8
P11
P10
P13
P12
P15
P14
P17
P16
P19
P18
P21
P20
GND
GND
P23
P22
VRF
VRF
3V3
3V3
Ethernet Connector
J-Link USB Connector
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3. Connectors

This chapter gives you an overview of the Wireless STK Mainboard connectivity. The placement of the connectors are shown in the figure below.
Figure 3.1. Mainboard Connector Layout

3.1 J-Link USB Connector

The J-Link USB connector is situated on the left side of the Wireless Starter Kit Mainboard. Most of the kit's development features are supported through this USB interface when connected to a host computer, including:
• Debugging and programming of the target device using the on-board J-Link debugger
• Communication with the target device over the virtual COM port using USB-CDC
• Accurate current profiling using the AEM
In addition to providing access to development features of the kit, this USB connector is also the main power source for the kit. USB 5V from this connector powers the board controller and the AEM. It is recommended that the USB host be able to supply at least 500 mA to this connector, although the actual current required will vary depending on the application.

3.2 Ethernet Connector

The Ethernet connector provides access to all of the Wireless Starter Kit's development features over TCP/IP. The Ethernet interface provides some additional development features to the user. Supported features include:
• Debugging and programming of the target device using the on-board J-Link debugger
• Communication with the target device over the virtual COM port using TCP/IP socket 4901
• "VUART" communication with the target device over the debug SWD/SWO interface using TCP/IP socket 4900
• Accurate current profiling using the AEM
• Real-time radio packet and network analysis using the Packet Trace Interface
• Access to advanced configuration options using the admin console over TCP/IP socket 4902
Please note that the Wireless Starter Kit cannot be powered using the Ethernet connector, so in order to use this interface, the USB connector must be used to provide power to the board.
silabs.com | Building a more connected world. Rev. 2.01 | 7
GND
VMCU
P23 / PD15 / BTN1_LED1
P21 / PD14 / BTN0_LED0
P19 / NC
P17 / NC
GND
P15 / NC
P13 / EXP16 / PC10 / I2C_SDA
P11 / EXP14 / PA1 / VCOM_RX
P9 / EXP12 / PA0 / VCOM_TX
P7 / EXP10 / PD13 / SPI_CS
P5 / EXP8 / PB13 / SPI_CLK
P3 / EXP6 / PB12 / SPI_MISO
P1 / EXP4 / PB11 / SPI_MOSI
VRF
GND
VMCU
NC / P22
NC / P20
NC / P18
NC / P16
GND
NC / P14
I2C_SCL / PC11 / EXP15 / P12
NC / EXP13 / P10
NC / EXP11 / P8
NC / EXP9 / P6
NC / EXP7 / P4
VCOM_RTS / PF3 / EXP5 / P2
VCOM_CTS / PF2 / EXP3 / P0
VRF
J101
GNDGND
5V5V
NCNC
P45 / NCNC / P44
P43 / NCNC / P42
P41 / NCNC / P40
3V33V3
P39 / NCNC / P38
P37 / tied high / SENSOR_ENABLENC / P36
P35 / NCNC / P34
P33 / NCNC / P32
P31 / NCNC / P30
P29 / NCNC / P28
P27 / PF1 / DBG_TMS_SWDIONC / P26
P25 / PF0 / DBG_TCK_SWCLKNC / P24
GNDGND
J102
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.3 Breakout Pads

Most pins of the BGM113 are routed from the radio board to breakout pads at the top and bottom edges of the Wireless STK Main­board. A 2.54 mm pitch pin header can be soldered on for easy access to the pins. The figure below shows you how the pins of the BGM113 maps to the pin numbers printed on the breakout pads. To see the available functions on each, refer to the data sheet for BGM113A256V1.
silabs.com | Building a more connected world. Rev. 2.01 | 8
Figure 3.2. Breakout Pad Pin Mapping
12
4
8 6
10
3
5
9 7
12
13
14
11
1516
17
18
20 19
VMCU
SPI_MOSI / PB11
SPI_MISO / PB12
SPI_SCK / PB13
SPI_CS / PD13
UART_TX / PA0
UART_RX / PA1
I2C_SDA / PC10
5V
3V3
GND
PF2 / GPIO
PF3 / GPIO
NC
NC
NC
NC
PC11 / I2C_SCL
BOARD_ID_SDA BOARD_ID_SCL
Reserved (Board Identification)
BGM113 I/O Pin
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.4 EXP Header

The EXP header is an angled 20-pin expansion header provided to allow connection of peripherals or plugin boards to the kit. It is loca­ted on the right-hand side of the mainboard and it contains a number of I/O pins that can be used with most of the BGM113 Blue Gecko's features. Additionally, the VMCU, 3V3, and 5V power rails are also exported.
The connector follows a standard which ensures that commonly used peripherals such as an SPI, a UART, and an I2C bus are availa­ble on fixed locations in the connector. The rest of the pins are used for general purpose IO. This allows the definition of expansion boards (EXP boards) that can plug into a number of different Silicon Labs Starter Kits.
The figure below shows the pin assignment of the EXP header. Because of limitations in the number of available GPIO pins, some of the EXP header pins are shared with kit features.
Figure 3.3. EXP Header
silabs.com | Building a more connected world. Rev. 2.01 | 9
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.4.1 EXP Header Pinout

The pin-routing on the BGM113 is very flexible, so most peripherals can be routed to any pin. However, many pins are shared between the EXP header and other functions on the Wireless STK Mainboard. The table below includes an overview of the mainboard features that share pins with the EXP header.
Table 3.1. EXP Header Pinout
Pin Connection EXP Header Function Shared Feature Peripheral Mapping
20 3V3 Board controller supply
18 5V Board USB voltage
16 PC10 I2C_SDA SENSOR_I2C_SDA I2C0_SDA #15
14 PA1 UART_RX VCOM_RX USART0_RX #0
12 PA0 UART_TX VCOM_TX USART0_TX #0
10 PD13 SPI_CS USART1_CS #18
8 PB13 SPI_SCLK USART1_CLK #6
6 PB12 SPI_MISO USART1_RX #6
4 PB11 SPI_MOSI USART1_TX #6
2 VMCU BGM113 voltage domain, included in AEM measurements.
19 BOARD_ID_SDA Connected to Board Controller for identification of add-on boards.
17 BOARD_ID_SCL Connected to Board Controller for identification of add-on boards.
15 PC11 I2C_SCL SENSOR_I2C_SCL I2C0_SCL #15
13 No Connection
11 Not Connected
9 Not Connected
7 Not Connected
5 PF3 GPIO VCOM_RTS USART0_CS #0
3 PF2 GPIO VCOM_CTS USART0_CLK #0
1 GND Ground
silabs.com | Building a more connected world. Rev. 2.01 | 10
1 2
4
8
6
10
5
9
12
13 14
11
15 16 17 18
2019
TMS / SWDIO / C2D TCK / SWCLK / C2CK TDO / SWO TDI / C2Dps
TRACECLK TRACED0 TRACED1 TRACED2 TRACED3
RESET / C2CKps
GND
NC
NC
GND
GND
GND
7
GND
VTARGET
Cable Detect
NC
3
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.5 Debug Connector

The debug connector serves multiple purposes based on the "debug mode" setting which can be configured in Simplicity Studio. When the debug mode is set to "Debug IN", the debug connector can be used to connect an external debugger to the BGM113 on the radio board. When set to "Debug OUT", this connector allows the kit to be used as a debugger towards an external target. When set to "De­bug MCU" (default), the connector is isolated from both the on-board debugger and the radio board target device.
Because this connector is electronically switched between the different operating modes, it can only be used when the board controller is powered (i.e. J-Link USB cable connected). If debug access to the target device is required when the board controller is unpowered, connect directly to the appropriate breakout pins.
The pinout of the connector follows that of the standard ARM Cortex Debug+ETM 19-pin connector. The pinout is described in detail below. Even though the connector has support for both JTAG and ETM Trace, it does not necessarily mean that the kit or the on-board target device supports this.
Figure 3.4. Debug Connector
Note: The pinout matches the pinout of an ARM Cortex Debug+ETM connector, but these are not fully compatible as pin 7 is physically
removed from the Cortex Debug+ETM connector. Some cables have a small plug that prevent them from being used when this pin is present. If this is the case, remove the plug, or use a standard 2x10 1.27 mm straight cable instead.
Table 3.2. Debug Connector Pin Descriptions
Pin Number(s) Function Description
1 VTARGET Target reference voltage. Used for shifting logical signal levels between target and
debugger.
2 TMS / SDWIO / C2D JTAG test mode select, Serial Wire data, or C2 data
4 TCK / SWCLK / C2CK JTAG test clock, Serial Wire clock, or C2 clock
6 TDO/SWO JTAG test data out or Serial Wire Output
8 TDI / C2Dps JTAG test data in or C2D "pin sharing" function
10 RESET / C2CKps Target device reset or C2CK "pin sharing" function
12 TRACECLK Not connected
14 TRACED0 Not connected
16 TRACED1 Not connected
silabs.com | Building a more connected world. Rev. 2.01 | 11
18 TRACED2 Not connected
20 TRACED3 Not connected
9 Cable detect Connect to ground
11, 13 NC Not connected
3, 5, 15, 17, 19 GND Ground
VMCU
1 33V3 5
5V
15
GND
13
GND
11
GND
9
GND
7
GND
17
BOARD_ID_SCL
19
BOARD_ID_SDA
2
VCOM_TX
4 VCOM_RX
6 VCOM_CTS 8
VCOM_RTS
10
PTI0_SYNC
12
PTI0_DATA
14
PTI0_CLK
16
PTI1_SYNC
18
PTI1_DATA
20
PTI1_CLK
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.6 Simplicity Connector

The Simplicity Connector enables the advanced debugging features, such as the AEM, the virtual COM port and the Packet Trace Inter­face, to be used towards an external target. The pinout is illustrated in the figure below.
Figure 3.5. Simplicity Connector
Note: Current drawn from the VMCU voltage pin is included in the AEM measurements, while the 3V3 and 5V voltage pins are not. To
monitor the current consumption of an external target with the AEM, unplug the radio board from the Wireless STK Mainboard to avoid adding the radio board current consumption to the measurements.
Table 3.3. Simplicity Connector Pin Descriptions
Pin Number(s) Function Description
1 VMCU 3.3 V power rail, monitored by the AEM
3 3V3 3.3 V power rail
5 5V 5 V power rail
2 VCOM_TX Virtual COM Tx
4 VCOM_RX Virtual COM Rx
6 VCOM_CTS Virtual COM CTS
8 VCOM_RTS Virtual COM RTS
10 PTI0_SYNC Packet Trace 0 Sync
12 PTI0_DATA Packet Trace 0 Data
14 PTI0_CLK Packet Trace 0 Clock
16 PTI1_SYNC Packet Trace 1 Sync
18 PTI1_DATA Packet Trace 1 Data
20 PTI1_CLK Packet Trace 1 Clock
17 BOARD_ID_SCL Board ID SCL
19 BOARD_ID_SDA Board ID SDA
7, 9, 11, 13, 15 GND Ground
silabs.com | Building a more connected world. Rev. 2.01 | 12
VAEM
1
3
RST
5
VCOM_TX
9
PTI_FRAME
7
SWDIO
2
GND
4
VCOM_RX
6
SWO
8
SWCLK
10
PTI_DATA
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Connectors

3.7 Debug Adapter

BRD8010A STK/WSTK Debug Adapter is an adapter board which plugs directly into the debug connector and the Simplicity Connector on the mainboard. It combines selected functionality from the two connectors to a smaller footprint 10-pin connector, which is more suitable for space constrained designs.
For versatility, the debug adapter features three different 10-pin debug connectors:
• Silicon Labs Mini Simplicity Connector
• ARM Cortex 10-pin Debug Connector
• Silicon Labs ISA3 Packet Trace
The ARM Cortex 10-pin Debug Connector follows the standard Cortex pinout defined by ARM and allows the Starter Kit to be used to debug hardware designs that use this connector.
The ISA3 connector follows the same pinout as the Packet Trace connector found on the Silicon Labs Ember Debug Adapter (ISA3). This allows the Starter Kit to be used to debug hardware designs that use this connector.
The Mini Simplicity Connector is designed to offer advanced debug features from the Starter Kit on a 10-pin connector:
• Serial Wire Debug (SWD) with SWO
• Packet Trace Interface (PTI)
• Virtual COM port (VCOM)
• AEM Monitored voltage rail
Note: Packet Trace is only available on Wireless STK Mainboards. MCU Starter Kits do not support Packet Trace.
Figure 3.6. Mini Simplicity Connector
Table 3.4. Mini Simplicity Connector Pin Descriptions
Pin Number Function Description
1 VAEM Target voltage on the debugged application. Supplied and monitored by the AEM
when power selection switch is in the "AEM" position.
2 GND Ground
3 RST Reset
4 VCOM_RX Virtual COM Rx
5 VCOM_TX Virtual COM Tx
6 SWO Serial Wire Output
7 SWDIO Serial Wire Data
8 SWCLK Serial Wire Clock
9 PTI_FRAME Packet Trace Frame Signal
10 PTI_DATA Packet Trace Data Signal
silabs.com | Building a more connected world. Rev. 2.01 | 13
VMCU
AEM
USB
BAT
USB Mini-B
Connector
Advanced
Energy Monitor
3 V Lithium Battery
(CR2032 )
B
A
T
U
SB
AE
M
LDO
BGM113
5 V
3.3 V
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Power Supply and Reset

4. Power Supply and Reset

4.1 Radio Board Power Selection

The BGM113 on a Wireless Starter Kit can be powered by one of these sources:
• The debug USB cable
• A 3 V coin cell battery
• A USB regulator on the radio board (for devices with USB support only)
The power source for the radio board is selected with the slide switch in the lower left corner of the Wireless STK Mainboard. The figure below shows how the different power sources can be selected with the slide switch.
Figure 4.1. Power Switch
With the switch in the AEM position, a low noise 3.3 V LDO on the mainboard is used to power the radio board. This LDO is again powered from the debug USB cable. The AEM is now also connected in series, allowing accurate high speed current measurements and energy debugging/profiling.
With the switch in the USB position, radio boards with USB-support can be powered by a regulator on the radio board itself. BRD4301A does not contain an USB regulator, and setting the switch in the USB postition will cause the BGM113 to be unpowered.
Finally, with the switch in the BAT position, a 20 mm coin cell battery in the CR2032 socket can be used to power the device. With the switch in this position no current measurements are active. This is the recommended switch position when powering the radio board with an external power source.
Note: The current sourcing capabilities of a coin cell battery might be too low to supply certain wireless applications.
Note: The AEM can only measure the current consumption of the BGM113 when the power selection switch is in the AEM position.
silabs.com | Building a more connected world. Rev. 2.01 | 14
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Power Supply and Reset

4.2 Board Controller Power

The board controller is responsible for important features such as the debugger and the AEM, and is powered exclusively through the USB port in the top left corner of the board. This part of the kit resides on a separate power domain, so a different power source can be selected for the target device while retaining debugging functionality. This power domain is also isolated to prevent current leakage from the target power domain when power to the board controller is removed.
The board controller power domain is not influenced by the position of the power switch.
The kit has been carefully designed to keep the board controller and the target power domains isolated from each other as one of them powers down. This ensures that the target BGM113 device will continue to operate in the USB and BAT modes.

4.3 BGM113 Reset

The BGM113 Module can be reset by a few different sources:
• A user pressing the RESET button
• The on-board debugger pulling the #RESET pin low
• An external debugger pulling the #RESET pin low
In addition to the reset sources mentioned above, a reset to the BGM113 will also be issued during board controller boot-up. This means that removing power to the board controller (unplugging the J-Link USB cable) will not generate a reset, but plugging the cable back in will, as the board controller boots up.
silabs.com | Building a more connected world. Rev. 2.01 | 15
User Buttons
& LEDs
UIF_BUTTON0_LED0
UIF_BUTTON1_LED1
PD14 (GPIO)
PD15 (GPIO)
BGM113
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Peripherals

5. Peripherals

The starter kit has a set of peripherals that showcase some of the features of the BGM113.
Be aware that most BGM113 I/O routed to peripherals are also routed to the breakout pads. This must be taken into consideration when using the breakout pads for your application.

5.1 Push Buttons and LEDs

The kit features two user push buttons, marked PB0 (BUTTON0) and PB1 (BUTTON1), and two yellow LEDs, marked LED0 and LED1.
BUTTON0 and LED0 share the connection to GPIO pin PD14, and BUTTON1 and LED1 are both connected to PD15.
To use the push buttons as inputs to the BGM113, each button's GPIO pin must be configured as an input. Configure the pins as out­puts to control the LEDs. Note that LEDs are connected to GPIO pins in an active-low configuration.
The push buttons are debounced by RC filters with a time constant of 1 ms.
Figure 5.1. Buttons/LEDs
silabs.com | Building a more connected world. Rev. 2.01 | 16
SENSOR_ENABLE
Si7021
Temperature
& Humidity
Sensor
0: I2C lines are isolated, sensor is not powered 1: Sensor is powered and connected
PC11 (I2C0_SCL #15)
PC10 (I2C0_SDA #15)
NC (tied high)
SENSOR_I2C_SDA
SENSOR_I2C_SCL
VMCU
VDD
SCL
SDA
BGM113
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Peripherals

5.2 Si7021 Relative Humidity and Temperature Sensor

The Si7021 I2C relative humidity and temperature sensor is a monolithic CMOS IC integrating humidity and temperature sensor ele­ments, an analog-to-digital converter, signal processing, calibration data, and an I2C Interface. The patented use of industry-standard,
low-K polymeric dielectrics for sensing humidity enables the construction of low-power, monolithic CMOS Sensor ICs with low drift and hysteresis, and excellent long term stability.
The humidity and temperature sensors are factory-calibrated and the calibration data is stored in the on-chip non-volatile memory. This ensures that the sensors are fully interchangeable, with no recalibration or software changes required.
The Si7021 is available in a 3x3 mm DFN package and is reflow solderable. It can be used as a hardware- and software-compatible drop-in upgrade for existing RH/ temperature sensors in 3x3 mm DFN-6 packages, featuring precision sensing over a wider range and lower power consumption. The optional factory-installed cover offers a low profile, convenient means of protecting the sensor during assembly (e.g., reflow soldering) and throughout the life of the product, excluding liquids (hydrophobic/oleophobic) and particulates.
The Si7021 offers an accurate, low-power, factory-calibrated digital solution ideal for measuring humidity, dew-point, and temperature, in applications ranging from HVAC/R and asset tracking to industrial and consumer platforms.
The I2C bus used for the Si7021 is shared with the EXP header. The temperature sensor is normally isolated from the I2C line. To use the sensor, SENSOR_ENABLE (tied high) must be set high. When enabled, the sensor's current consumption is included in the AEM measurements.
Figure 5.2. Si7021 Relative Humidity and Temperature Sensor
Refer to the Silicon Labs web pages for more information: http://www.silabs.com/humidity-sensors
silabs.com | Building a more connected world. Rev. 2.01 | 17
VCOM_ENABLE
PA0 (US0_TX #0)
PA1 (US0_RX #0)
NC (tied high)
VCOM_RX
VCOM_TX
Board
Controller
BGM113
USB
Host
PC
Isolation & Level Shift
PF2 (US0_CTS #22)
PF3 (US0_RTS #22)
VCOM_CTS
VCOM_RTS
ETH
or
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Peripherals

5.3 Virtual COM Port

An asynchronous serial connection to the board controller is provided for application data transfer between a host PC and the target BGM113. This eliminates the need for an external serial port adapter.
Figure 5.3. Virtual COM Port Interface
The virtual COM port consists of a physical UART between the target device and the board controller, and a logical function in the board controller that makes the serial port available to the host PC over USB or Ethernet. The UART interface consists of four pins and an enable signal.
Table 5.1. Virtual COM Port Interface Pins
Signal Description
VCOM_TX Transmit data from the BGM113 to the board controller
VCOM_RX Receive data from the board controller to the BGM113
VCOM_CTS Clear to Send hardware flow control input, asserted by the board controller when it is ready to receive more data
VCOM_RTS Request to Send hardware flow control output, asserted by the BGM113 when it is ready to receive more data
VCOM_ENABLE Enables the VCOM interface, allowing data to pass through to the board controller.
The parameters of the serial port, such as baud rate or flow control, can be configured using the admin console. The default settings depend on which radio board is used with the Wireless STK Mainboard.
Note: The VCOM port is only available when the board controller is powered, which requires the J-Link USB cable to be inserted.
silabs.com | Building a more connected world. Rev. 2.01 | 18
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Peripherals

5.3.1 Host Interfaces

Data sent to the board controller through the VCOM interface is available in two different ways to the user. At the same time, data can be sent to the target device using these interfaces:
• Virtual COM port using a standard USB-CDC driver.
• TCP/IP, by connecting to the Wireless STK on TCP/IP port 4901 with a Telnet client.
When connecting via USB, the device should automatically show up as a COM port. Some examples of device names that can be as­sosiated with the kit:
• JLink CDC UART Port (COM5) on Windows hosts
• /dev/cu.usbmodem1411 on macOS
• /dev/ttyACM0 on Linux
Note that these are only examples of what the device might show up as, and the actual assignment depends on the operating system, and how many devices are or have been connected previously. Data sent by the target device into the VCOM interface can be read from this port, and data written to this port is transmitted to the traget device.
Connecting to the Wireless STK on port 4901 gives access to the same data over TCP/IP. Data written into the VCOM interface by the target device can be read from the socket, and data written into the socket is transmitted to the target device.
Note: Only one of these interfaces can be used at the same time, with the TCP/IP socket taking priority. This means that if a socket is connected to port 4901, no data can be sent or received on the USB COM port.

5.3.2 Serial Configuration

By default, the VCOM serial port is configured to use 115200 8N1, with flow control disabled/ignored. (115.2 Kbit/s, 8 databits, 1 stop bit). The configuration can be changed using the Admin Console:
WSTK> serial vcom config Usage: serial vcom config [--nostore] [handshake <rts/cts/rtscts/disable/auto>] [speed <9600,921600>]
Using this command, the baud rate can be configured between 9600 and 921600 bit/s, and hardware handshake can be enabled or disabled on either or both flow control pins.
silabs.com | Building a more connected world. Rev. 2.01 | 19
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Peripherals

5.3.3 Hardware Handshake

The VCOM peripheral supports basic RTS/CTS flow control.
VCOM_CTS (target clear to send) is a signal that is output from the board controller and input to the target device. The board controller de-asserts this pin whenever its input buffer is full and it is unable to accept more data from the target device. If hardware handshake is enabled in the target firmware, its UART peripheral will halt when data is not being consumed by the host. This implements end-to-end flow control for data moving from the target device to the host.
VCOM_CTS is connected to the RTS pin on the board controller, and is enabled by setting handshake to either RTS or RTSCTS using the "serial vcom config" command.
VCOM_RTS (target request to send) is a signal that is output form the target device and input to the board controller. The board control­ler will halt transmission of data towards the target if the target device de-asserts this signal. This gives the target firmware a means to hold off incoming data until it can be processed. Please note that de-asserting RTS will not abort the byte currently being transmitted, so the target firmware must be able to accept at least one more character after RTS is de-asserted.
VCOM_RTS is connected to the CTS pin of the board controller, and is enabled by setting handshake to either CTS or RTSCTS using the "serial vcom config" command in the Admin Console. If CTS flow control is disabled, the state of VCOM_RTS will be ignored and data will be transmitted to the target device anyway.
Table 5.2. Hardware Handshake Configuration
Mode Description
disabled RTS (VCOM_CTS) is not driven by the board controller and CTS (VCOM_RTS) is ignored
rts RTS (VCOM_CTS) is driven by the board controller to halt target from transmitting when input buffer is full. CTS
(VCOM_RTS) is ignored.
cts RTS (VCOM_CTS) is not driven by the board controller. Data is transmitted to the target device if CTS
(VCOM_RTS) is asserted, and halted when de-asserted.
rtscts RTS (VCOM_CTS) is driven by the board controller to halt target when buffers are full. Data is transmitted to the
target device if CTS (VCOM_RTS) is asserted, and halted when de-asserted.
Note: Please note that enabling CTS flow control without configuring the VCOM_RTS pin can result in no data being transmitted from the host to the target device.
silabs.com | Building a more connected world. Rev. 2.01 | 20
PA1 (GPIO)
BUTTON_LED2 (EXP7)
No connection
BGM113
BUTTON_LED3 (EXP14)
Buttons
& LEDs
Accelerometer
BMA280
Analog
Joystick
JOYSTICK (EXP12)
ACC_MOSI (EXP4)
ACC_MISO (EXP6)
ACC_SCK (EXP8)
ACC_CS (EXP10)
ACC_INT (EXP9)
PA0 (ADC)
PB11 (US1_TX #6)
PB12 (US1_RX #6)
PB13 (US1_CLK #6)
PD13 (US1_CS #18)
No connection
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

6. Expansion Board

The User Interface Expansion Board included with the BGM113 Wireless STK includes the following features:
• 1x 3-axis accelerometer (Bosch Sensortech BMA280)
• 1x Joystick with 9 measurable positions
• 2x Push buttons and 2x LEDs
The connections between the Expansion Board and the BGM113 are shown in the figure below:
Expansion Board
Figure 6.1. User Interface Expansion Board
The following sections contain more detailed information about each feature.

6.1 Accelerometer

Bosch Sensortec BMA280 is a triaxial, low-power, low-g accelerometer sensor with SPI interface. It features 14-bit digital resolution and allows very low-noise measurement of acceleration in 3 perpendicular axes and can therefore sense tilt, motion, shock and vibration.
Please refer to Bosch Sensortec's product page for a detailed datasheet of this sensor: http://www.bosch-sensortec.com/bst/products/
all_products/bma280

6.2 Push Buttons and LEDs

The Expansion Board contains two push buttons (marked BTN2 and BTN3 on the PCB) and two LEDs (LED2 and LED3, not marked but placed correspondingly above the push button markings). One push button and one LED share the same I/O pin on the BGM113. The push button is connected to the LED through a transistor, allowing the I/O to be used either as an input (for reading the push button state) or as an output (to control the LED state on or off).
When configured as an input, "0" indicates that the button is being pressed and "1" that the push button is not being pressed. Likewise, when configured as an output, "0" will turn the LED on and "1" will turn it off.
Pressing a push button will also light up the corresponding LED because the LED is controlled by the same line (state) regardless of whether it is the BGM113 or the push button that pulls the line low.
The each button is debounced by an RC filter with a time constant of about 1 ms. Pressing the push button while having the pin config­ured as an output in high state ("1") will not cause damage, but will cause extra current to flow.
silabs.com | Building a more connected world. Rev. 2.01 | 21
PA0 (ADC)
BGM113
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Expansion Board

6.3 Joystick

The analog joystick offers 9 measureable positions. This joystick is connected to the BGM113 pin PD4. Each of the joystick output pins are connected to a different resistor value to create a unique voltage that is measured by the internal ADC on the BGM113. The joystick output is connected to AD Channel 0 (ADC0). The figure below shows the connection between the joystíck and the BGM113.
Figure 6.2. User Interface Expansion Board Joystick
The table below lists the expected output voltage from each joystick position.
Table 6.1. Joystick Output Voltage
Position Resistor combinations [kohm]
Joystick output voltage [V]
Center press 0.1 / (0.1 + 10) 0.03 V
Up (N) 60.4 / (60.4 + 10) 2.83 V
Up-Right (NE) {(N // E) / {(N // E) + 10 } = 21.34 / (21.34
2.25 V
+ 10)
Right (E) 33 / (33 + 10) 2.53 V
Down-Right (SE) (S // E) / {(S // E) + 10)} = 7.67 / (7.67 + 10) 1.43 V
Down (S) 10 / (10 + 10) 1.65 V
Down-Left (SW) (S // W) / {(S // W) + 10)} = 6 / (6 + 10) 1.24 V
Left (W) 15 / (15 + 10) 1.98 V
Up-Left (NW) (N // W) / {(N // W) + 10)} = 12.01 / (12.01
1.80 V
+ 10)
Note: 1) Output Voltage is calculated with VMCU of 3.3 V .
1
silabs.com | Building a more connected world. Rev. 2.01 | 22
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Board Controller

7. Board Controller

The Wireless STK Mainboard contains a dedicated microcontroller for some of the advanced kit features provided. This microcontroller is referred to as the board controller, and is not programmable by the user. The board controller acts as an interface between the host PC and the target device on the radio board, as well as handling some house-keeping functions on the board.
Some of the kit features actively managed by the board controller are:
• The on-board debugger, which can flash and debug both on-board and external targets.
• The Advanced Energy Monitor, which provides real-time energy profiling of the user application.
• The Packet Trace Interface, which is used in conjunction with PC software to provide detailed insight into an active radio network.
• The Virtual COM Port and Virtual UART interfaces, which provide ways to transfer application data between the host PC and the target processor.
• The admin console, which provides configuration of the various board features.
Silicon Labs publishes updates to the board controller firmware in the form of firmware upgrade packages. These updates may enable new features or fix issues. See 10.1 Firmware Upgrades for details on firmware upgrade.

7.1 Admin Console

The admin console is a command line interface to the board controller on the kit. It provides functionality for configuring the kit behavior and retreiving configuration and operational parameters.

7.1.1 Connecting

The Wireless Starter Kit must be connected to Ethernet using the Ethernet connector in the top left corner of the mainboard for the admin console to be available. See 9.1.2 Ethernet Interface for details on the Ethernet connectivity.
Connect to the admin console by opening a telnet connection to the kit's IP address, port number 4902.
When successfully connected, a WSTK> prompt is displayed.

7.1.2 Built-in Help

The admin console has a built-in help system which is accessed by the help command. The help command will print a list of all top level commands:
WSTK> help *************** Root commands **************** aem AEM commands [ calibrate, current, dump, ... ] boardid Commands for board ID probe. [ list, probe ] dbg Debug interface status and control [ info, mode,] dch Datachannel control and info commands [ info ] discovery Discovery service commands. net Network commands. [ dnslookup, geoprobe, ip ] pti Packet trace interface status and control [ config, disable, dump, ... ] quit Exit from shell sys System commands [ nickname, reset, scratch, ... ] target Target commands. [ button, flashwrite, go, ... ] time Time Service commands [ client, server ] user User management functions [ login,]
The help command can be used in conjunction with any top level command to get a list of sub-commands with description. For exam­ple, pti help will print a list of all available sub-commands of pti:
WSTK> pti help *************** pti commands **************** config Configure packet trace disable Disable packet trace dump Dump PTI packets to the console as they come enable Enable packet trace info Packet trace state information
This means that running pti enable will enable packet trace.
silabs.com | Building a more connected world. Rev. 2.01 | 23
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Board Controller

7.1.3 Command Examples

PTI Configuration
pti config 0 efruart 1600000
Configures PTI to use the "EFRUART" mode at 1.6 Mb/s.
Serial Port Configuration
serial config vcom handshake enable
Enables hardware handshake on the VCOM UART connection.

7.2 Virtual UART

The Virtual UART interface provides a high performance application data interface that does not require any additional I/O pins apart from the debug interface. It is based on SEGGER's Real Time Transfer (RTT) technology, and uses Serial Wire Output (SWO) to get appliaction data from the device, and a shared memory interface to send data to the target application.
The Wireless Starter Kit makes the Virtual UART interface available on TCP/IP port 4900.
silabs.com | Building a more connected world. Rev. 2.01 | 24
BGM113
LDO
Peripherals
AEM
Processing
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Advanced Energy Monitor

8. Advanced Energy Monitor

8.1 Introduction

Any embedded developer seeking to make his embedded code spend as little energy as the underlying architecture supports needs tools to easily and quickly discover inefficiencies in the running application.
This is what the Simplicity Energy Profiler is designed to do. In real-time, the Energy Profiler will graph and log current as a function of time while correlating this to the actual target application code running on the BGM113. There are multiple features in the profiler soft­ware that allows for easy analysis, such as markers and statistics on selected regions of the current graph or aggregate energy usage by different parts of the application.

8.2 Theory of Operation

The Advanced Energy Monitor (AEM) circuitry on the board is capable of measuring current signals in the range of 0.1 µA to 95 mA, which is a dynamic range of alomst 120 dB. It can do this while maintaining approximately 10 kHz of current signal bandwidth. This is accomplished through a combination of a highly capable current sense amplifier, multiple gain stages, and signal processing within the kit's board controller before the current sense signal is read by a host computer for display and/or storage.
The current sense amplifier measures the voltage drop over a small series resistor, and the gain stage further amplifies this voltage with two different gain settings to obtain two current ranges. The transition between these two ranges occurs around 250 µA.
The current signal is combined with the target processor's Program Counter (PC) sampling by utilizing a feature of the ARM CoreSight debug architecture. The Instrumentation Trace Macrocell (ITM) block can be programmed to sample the MCU's PC at periodic intervals (50 kHz) and output these over SWO pin ARM devices. When these two data streams are fused and correlated with the running appli­cation's memory map, an accurate statistical profile can be built, that shows the energy profile of the running application in real-time.
At kit power-up or on a power-cycle, an automatic AEM calibration is performed. This calibration compensates for any offset errors in the current sense amplifiers.
Figure 8.1. Advanced Energy Monitor
Note: The 3.3 V regulator feedback point is after the 2.35 Ω sense resistor to ensure that the VMCU voltage is kept constant when the
output current changes. Maximum recommended output current is 300 mA.
silabs.com | Building a more connected world. Rev. 2.01 | 25
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Advanced Energy Monitor

8.3 AEM Accuracy and Performance

The AEM is capable of measuring currents in the range of 0.1 µA to 95 mA. For currents above 250 µA, the AEM is accurate within 0.1 mA. When measuring currents below 250 µA, the accuracy increases to 1 µA. Even though the absolute accuracy is 1 µA in the sub 250 µA range, the AEM is able to detect changes in the current consumption as small as 100 nA.
The AEM current sampling rate is 10 kHz.
Note: The AEM circuitry only works when the kit is powered and the power switch is in the AEM position.

8.4 Usage

The AEM data is collected by the board controller and can be displayed by the Energy Profiler, available through Simplicity Studio. By using the Energy Profiler, current consumption and voltage can be measured and linked to the actual code running on the BGM113 in realtime.
silabs.com | Building a more connected world. Rev. 2.01 | 26
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
On-Board Debugger

9. On-Board Debugger

The Wireless STK Mainboard contains an integrated debugger, which can be used to download code and debug the BGM113. In addi­tion to programming a target on a plug-in radio board, the debugger can also be used to program and debug external Silicon Labs EFM32, EFM8, EZR32, and EFR32 devices connected through the debug connector.
The debugger supports three different debug interfaces for Silicon Labs devices:
• Serial Wire Debug is supported by all EFM32, EFR32, and EZR32 devices
• JTAG is supported by EFR32 and some EFM32 devices
• C2 Debug is supported by EFM8 devices
In order for debugging to work properly, make sure that the selected debug interface is supported by the target device. The debug con­nector on the board supports all three of these modes.

9.1 Host Interfaces

The Wireless Starter Kit supports connecting to the on-board debugger using either Ethernet or USB.
Many tools support connecting to a debugger using either USB or Ethernet. When connected over USB, the kit is identified by its J-Link serial number. When connected over Ethernet, the kit is normally identified by its IP address. Some tools also support using the serial number when connecting over Ethernet, however this typically requires the computer and the kit to be on the same subnet for the dis­covery protocol (using UDP broadcast packets) to work.

9.1.1 USB Interface

The USB interface is available whenever the USB Mini-B connector on the left-hand side of the mainboard is connected to a computer.

9.1.2 Ethernet Interface

The Ethernet interface is available when the mainboard Ethernet connector in the top left corner is connected to a network. Normally, the kit will receive an IP address from a local DHCP server, and the IP address is printed on the LCD display. If your network does not have a DHCP server, you need to connect to the kit via USB and set the IP address manually using Simplicity Studio, Simplicity Commander, or J-Link Configurator.
For the Ethernet connectivity to work, the kit must still be powered through the USB Mini-B connector. See 4.2 Board Controller Power for details.

9.1.3 Serial Number Identification

All Silicon Labs kits have a unique J-Link serial number which identifies the kit to PC applications. This number is 9 digits, and is nor­mally on the form 44xxxxxxx.
The J-Link serial number is normally printed at the bottom of the kit LCD display.
silabs.com | Building a more connected world. Rev. 2.01 | 27
RADIO BOARD
Board
Controller
USB
Host
Computer
DEBUG HEADER
External
Hardware
Board
Controller
USB
Host
Computer
DEBUG HEADER
External
Hardware
RADIO BOARD
Board
Controller
USB
Host
Computer
DEBUG HEADER
External Debug Probe
RADIO BOARD
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
On-Board Debugger

9.2 Debug Modes

Programming external devices is done by connecting to a target board through the provided debug connector, and by setting the debug mode to [Out]. The same connector can also be used to connect an external debugger to the BGM113 Module on the kit, by setting debug mode to [In].
Selecting the active debug mode is done in Simplicity Studio.
Debug MCU: In this mode, the on-board debugger is connected to the BGM113 on the kit.
Figure 9.1. Debug MCU
Debug OUT: In this mode, the on-board debugger can be used to debug a supported Silicon Labs device mounted on a custom board.
Figure 9.2. Debug OUT
Debug IN: In this mode, the on-board debugger is disconnected, and an external debugger can be connected to debug the BGM113 on
the kit.
Figure 9.3. Debug IN
silabs.com | Building a more connected world. Rev. 2.01 | 28
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
On-Board Debugger
Note: For "Debug IN" to work, the kit board controller must be powered through the Debug USB connector.

9.3 Debugging During Battery Operation

When the BGM113 is powered by battery and the J-Link USB is still connected, the on-board debug functionality is available. If the USB power is disconnected, the Debug IN mode will stop working.
If debug access is required when the target is running off another energy source, such as a battery, and the board controller is powered down, the user should make direct connections to the GPIO used for debugging. This can be done by connecting to the appropriate pins of the breakout pads. Some Silicon Labs kits provide a dedicated pin header for this purpose.
silabs.com | Building a more connected world. Rev. 2.01 | 29
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Kit Configuration and Upgrades

10. Kit Configuration and Upgrades

The kit configuration dialog in Simplicity Studio allows you to change the J-Link adapter debug mode, upgrade its firmware, and change other configuration settings. To download Simplicity Studio, go to http://www.silabs.com/simplicity.
In the main window of the Simplicity Studio's Launcher perspective, the debug mode and firmware version of the selected J-Link adapt­er is shown. Click the [Change] link next to any of them to open the kit configuration dialog.
Figure 10.1. Simplicity Studio Kit Information
Figure 10.2. Kit Configuration Dialog

10.1 Firmware Upgrades

Upgrading the kit firmware is done through Simplicity Studio. Simplicity Studio will automatically check for new updates on startup.
You can also use the kit configuration dialog for manual upgrades. Click the [Browse] button in the [Update Adapter] section to select the correct file ending in .emz. Then, click the [Install Package] button.
silabs.com | Building a more connected world. Rev. 2.01 | 30
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Schematics, Assembly Drawings, and BOM

11. Schematics, Assembly Drawings, and BOM

Schematics, assembly drawings, and bill of materials (BOM) are available through Simplicity Studio when the kit documentation pack­age has been installed.
silabs.com | Building a more connected world. Rev. 2.01 | 31
GND
F9 / PF3 / VCOM_RTS
3V3
NC / P36
P200
Upper Row
NC / P38 NC / P40 NC / P42 NC / P44
DBG_SWDIO / PF1 / F0
NC / F14
BUTTON0 / PD14 / F12
LED0 / PD14 / F10
VCOM_CTS / PF2 / F8
DBG_RESET / F4
NC / F2
NC / F16
VCOM_TX / PA0 / F6
PTI_DATA / PB12 / F20
NC / F18
USB_VBUS
5V
Board ID SCL
GND
Board ID SDA
USB_VREG
F7 / PA1 / VCOM_RX
F5 / TIED HIGH / VCOM_ENABLE
F3 / NC
F1 / PF0 / DBG_SWCLK
P45 / NC
P43 / NC
P41 / NC
P39 / NC
P37 / TIED HIGH / SENSOR_ENABLE
F11 / PD15 / LED1 F13 / PD15 / BUTTON1 F15 / NC F17 / NC F19 / PB13 / PTI_FRAME F21 / NC
GND
VMCU_IN
EXP3 / PF2 / P0
P201
Lower Row
EXP5 / PF3 / P2
NC / P4 NC / P6
GND
VRF_IN
P35 / NC
P7 / PD13 / EXP10
P5 / PB13 / EXP8
P3 / PB12 / EXP6
P1 / PB11 / EXP4
P33 / NC
P31 / NC
P29 / NC
P27 / PF1
P25 / PF0
P23 / PD15
P21 / PD14
P19 / NC
P17 / NC
P15 / NC
P13 / PC10 / EXP16
P11 / PA1 / EXP14
P9 / PA0 / EXP12
NC / P34
NC / P32
NC / P30
NC / P28
NC / P26
NC / P24
NC / P22
NC / P20
NC / P18
NC / P16
NC / P14
EXP15 / PC11 / P12
NC / P10
NC / P8
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Mainboard Connectors

12. Mainboard Connectors

BRD4301A contains two dual-row, female socket, 0.05" pitch polarized connectors (P/N: SFC-120-T2-L-D-A-K-TR) which provide the interface to the Wireless STK Mainboard. The Mainboard has the corresponding male header pin connectors (P/N: TFC-120-02-F-D­LC-ND).

12.1 Mainboard Connector Pin Associations

The figure below shows the pin mapping on the connector to the radio pins and their corresponding function on the Wireless STK Main­board.
Figure 12.1. Radio Board Connectors
silabs.com | Building a more connected world. Rev. 2.01 | 32
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

13. Mechanical Details

The mechanical layout of BRD4301A BGM113 Blue Gecko Module Radio Board is illustrated in the figures below.
Mechanical Details
Figure 13.1. BRD4301A Top View
Figure 13.2. BRD4301A Bottom View
silabs.com | Building a more connected world. Rev. 2.01 | 33
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

14. Radio Board Revision History and Errata

14.1 BRD4301A Revision History

The Radio Board revision is printed on the backside of the BRD4301A Radio Board.
Table 14.1. BRD4301A Revision History
Radio Board Revision Released Description
A00 28 March 2016 Initial release.

14.2 BRD4301A Errata

There are no known errata at present.
Radio Board Revision History and Errata
silabs.com | Building a more connected world. Rev. 2.01 | 34
SLWRB4301A
BGM113 Blue Gecko Module Radio Board
124802042
28-03-16
A00
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide

15. Kit Revision History

The kit revision can be found printed on the kit packaging label, as outlined in the figure below.
Figure 15.1. Kit Label

15.1 SLWSTK6101B Revision History

Kit Revision Released Description
Kit Revision History
A01 7 June 2016 Updated BRD4300A to revision A03.
A00 13 April 2016 Initial kit release, replaces SLWSTK6101A.
Added BRD4301A BGM113 Blue Gecko Module Radio Board.
Updated BRD4300A to revision A02.

15.2 SLWRB4301A Revision history

Kit Revision Released Description
A00 27 January 2016 Initial release.
silabs.com | Building a more connected world. Rev. 2.01 | 35
UG187: BGM113 Blue Gecko Module Wireless Starter Kit User's Guide
Document Revision History

16. Document Revision History

Revision 2.01
March 2018
• Corrected peripheral mapping for SPI functionality in EXP Header table.
• Corrected peripheral mapping for CTS/RTS pins in Virtual COM Port Interface figure.
Revision 2.00
October 2016
• Added sections for ordering information, mechanical drawings and radio board connector pin-out, deprecating the BRD4301A Refer­ence Manual.
• Added SLWSTK6101B Rev A01 to kit revision history.
• Smart removed from Bluetooth Smart for consistenty.
• Simplicity Studio added to front page features.
Revision 1.00
March 2016
• Initial document revision.
silabs.com | Building a more connected world. Rev. 2.01 | 36
Simplicity Studio
One-click access to MCU and wireless tools, documentation, software, source code libraries & more. Available for Windows, Mac and Linux!
IoT Portfolio
www.silabs.com/IoT
Disclaimer
Silicon Labs intends to provide customers with the latest, accurate, and in-depth documentation of all peripherals and modules available for system and software implementers using or intending to use the Silicon Labs products. Characterization data, available modules and peripherals, memory sizes and memory addresses refer to each specific device, and "Typical" parameters provided can and do vary in different applications. Application examples described herein are for illustrative purposes only. Silicon Labs reserves the right to make changes without further notice and limitation to product information, specifications, and descriptions herein, and does not give warranties as to the accuracy or completeness of the included information. Silicon Labs shall have no liability for the consequences of use of the information supplied herein. This document does not imply or express copyright licenses granted hereunder to design or fabricate any integrated circuits. The products are not designed or authorized to be used within any Life Support System without the specific written consent of Silicon Labs. A "Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant personal injury or death. Silicon Labs products are not designed or authorized for military applications. Silicon Labs products shall under no circumstances be used in weapons of mass destruction including (but not limited to) nuclear, biological or chemical weapons, or missiles capable of delivering such weapons.
Trademark Information
Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®, EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®, Gecko®, ISOmodem®, Micrium, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress®, Zentri and others are trademarks or registered trademarks of Silicon Labs. ARM, CORTEX, Cortex-M3 and THUMB are trademarks or registered trademarks of ARM Holdings. Keil is a registered trademark of ARM Limited. All other products or brand names mentioned herein are trademarks of their respective holders.
Silicon Laboratories Inc. 400 West Cesar Chavez Austin, TX 78701 USA
SW/HW
www.silabs.com/simplicity
Quality
www.silabs.com/quality
Support and Community
community.silabs.com
http://www.silabs.com
Loading...
