Silicon Graphics Rackable C2108-TY10 User Manual

SGI® Rackable™ C2108-TY10 System User’s Guide

007-5688-003

COPYRIGHT

© 2010, 2011 SGI. All rights reserved; provided portions may be copyright in third parties, as indicated elsewhere herein. No permission is granted to copy, distribute, or create derivative works from the contents of this electronic documentation in any manner, in whole or in part, without the prior written permis sion of SGI.

LIMITED RIGHTS LEGEND

The software described in this document is “commercial computer software” provided with restricted rights (except as to included open/free source) as specified in the FA R 52.227-19 and/or the DFAR 227.7202, o r successive sections. Use beyond license prov isions is a violation of worldwide intellectual property laws, treaties and conventions. This document is provided with limited rights as defined in 52.227-14.

The electronic (software) version of this document was developed at private expense; if acquired under an agreement with the USA government or any contractor thereto, it is acquired as “commercial computer software” subject to the provisions of its applicable license agreement, as specified in (a) 48 CFR

12.212 of the FAR; or, if acquired for Department of Defense units, (b) 48 CFR 227-7202 of the DoD FAR Supplement; or sections succeeding thereto. Contractor/manufacturer is SGI, 1140 E. Arques Avenue, Sunnyvale, CA 94085.

TRADEMARKS AND ATTRIBUTIONS

Silicon Graphics, SGI, the SGI logo, and Rackable are trademarks or registered trademarks of Silicon Graphics International Corp. or its subsidiaries in the United States and/or other countries worldwide.

Fusion-MPT, Integrated RAID, MegaRAID, and LSI Logic are trademarks or registered trademarks of LSI Logic Corporation.InfiniBand is a registered trademark of the InfiniBand Trade Association. Intel, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Internet Explorer and MS-DOS are registered trademarks of Microsoft Corporation. Java and Java Virtual Machine are trademarks or registered trademarks of Sun Microsystems, Inc. Linux is a registered trademark of Linus Torvalds, used with permission by SGI. Novell and Novell Netware are registered trademarks of Novell Inc. PCIe and PCI-X are registered trademarks of PCI SIG. Phoenix and PhoenixBIOS are registered trademarks of Phoenix Technologies Ltd. Red Hat and all Red Hat-based trademarks are trademarks or registered trademarks of Red Hat, Inc. in the United States and other countries. SUSE LINUX and the SUSE logo are registered trademarks of Novell, Inc. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd.

All other trademarks mentioned herein are the property of their respective owners.

Adaptec, HostRAID, and the Adaptec logo are registered trademarks of Adaptec Inc.

Record of Revision

Version Description

001 September 2010

Original printing.

003 August 2011

Miscellaneous corrections.

007-5688-003 iii

Contents

Record of Revision . . . . . . . . . . . . . . . . . . . . . . . iii

About This Guide . . . . . . . . . . . . . . . . . . . . . . .xvii

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . 1

Server Board Features . . . . . . . . . . . . . . . . . . . . . . 3

Processors . . . . . . . . . . . . . . . . . . . . . . . . 3

Memory. . . . . . . . . . . . . . . . . . . . . . . . . 3

Serial ATA . . . . . . . . . . . . . . . . . . . . . . . . 3

PCI Expansion Slots . . . . . . . . . . . . . . . . . . . . . 3

UIO . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Onboard Controllers/Ports . . . . . . . . . . . . . . . . . . . . 4

ATI Graphics Controller . . . . . . . . . . . . . . . . . . . . 4

Other Features . . . . . . . . . . . . . . . . . . . . . . . 4

Server Chassis Features . . . . . . . . . . . . . . . . . . . . . . 4

System Power . . . . . . . . . . . . . . . . . . . . . . . 4

Serial ATA Subsystem . . . . . . . . . . . . . . . . . . . . . 5

Front Control Panel. . . . . . . . . . . . . . . . . . . . . . 5

Motherboard . . . . . . . . . . . . . . . . . . . . . . . 5

Cooling System. . . . . . . . . . . . . . . . . . . . . . . 5

2 Server Installation . . . . . . . . . . . . . . . . . . . . . . . 7

Unpack the System . . . . . . . . . . . . . . . . . . . . . . . 7

Prepare for Setup . . . . . . . . . . . . . . . . . . . . . . 7

Choose a Setup Location . . . . . . . . . . . . . . . . . . . . 7

Warnings and Precautions . . . . . . . . . . . . . . . . . . . . . 8

Rack Precautions . . . . . . . . . . . . . . . . . . . . . . 8

Server Precautions . . . . . . . . . . . . . . . . . . . . . . 9

Rack Mounting Considerations . . . . . . . . . . . . . . . . . . . . 9

007-5688-003 v

Contents

Ambient Operating Temperature . . . . . . . . . . . . . . . . . . 9

Reduced Airflow . . . . . . . . . . . . . . . . . . . . . . 9

Mechanical Loading. . . . . . . . . . . . . . . . . . . . . . 9

Circuit Overloading . . . . . . . . . . . . . . . . . . . . . . 10

Reliable Ground . . . . . . . . . . . . . . . . . . . . . . . 10

Install the System into a Rack . . . . . . . . . . . . . . . . . . . . 10

Separate the Sections of the Rack Rails. . . . . . . . . . . . . . . . . 10

Outer Rack Rails. . . . . . . . . . . . . . . . . . . . . . . 12

Install the Outer Rails to the Rack . . . . . . . . . . . . . . . . . 12

Install the Inner Rail Extension . . . . . . . . . . . . . . . . . . . 12

Install the Inner Rails . . . . . . . . . . . . . . . . . . . . 12

Install the Server in a Rack . . . . . . . . . . . . . . . . . . . . 13

Check the Node Board Setup. . . . . . . . . . . . . . . . . . . . . 14

Access the Inside of the Chassis. . . . . . . . . . . . . . . . . . . 14

Check the CPUs (processors) . . . . . . . . . . . . . . . . . . . 16

Check the System Memory . . . . . . . . . . . . . . . . . . . . 16

Install Expansion PCI Cards. . . . . . . . . . . . . . . . . . . . 16

Check all Cable Connections and Airflow . . . . . . . . . . . . . . . . 16

Check the Drive Bay Setup . . . . . . . . . . . . . . . . . . . . 16

Check the System Disk Drives . . . . . . . . . . . . . . . . . . 16

Check the Airflow . . . . . . . . . . . . . . . . . . . . . 17

Supply Power to the System . . . . . . . . . . . . . . . . . . 17

3 System Interface. . . . . . . . . . . . . . . . . . . . . . . . 19

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Control Panel Buttons . . . . . . . . . . . . . . . . . . . . . . 19

Control Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . 20

Power Fail . . . . . . . . . . . . . . . . . . . . . . . . 20

Overheat/Fan Fail . . . . . . . . . . . . . . . . . . . . . . 20

NIC1. . . . . . . . . . . . . . . . . . . . . . . . . . 21

NIC2. . . . . . . . . . . . . . . . . . . . . . . . . . 21

HDD . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Power . . . . . . . . . . . . . . . . . . . . . . . . . 22

SATA Drive Carrier LEDs . . . . . . . . . . . . . . . . . . . . . 22

vi 007-5688-003

Contents

4 System Safety . . . . . . . . . . . . . . . . . . . . . . . . 23

Electrical Safety Precautions . . . . . . . . . . . . . . . . . . . . 23

General Safety Precautions . . . . . . . . . . . . . . . . . . . . . 24

ESD Precautions. . . . . . . . . . . . . . . . . . . . . . . . 25

5 Advanced Severboard Setup . . . . . . . . . . . . . . . . . . . . 27

Handling the Node Board . . . . . . . . . . . . . . . . . . . . . 27

ESD Precautions . . . . . . . . . . . . . . . . . . . . . . 28

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . 28

Connecting the Control Panel . . . . . . . . . . . . . . . . . . . 28

I/O Ports . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Serverboard Details . . . . . . . . . . . . . . . . . . . . . . . 30

Serverboard Quick Reference . . . . . . . . . . . . . . . . . . . 32

Installing Memory . . . . . . . . . . . . . . . . . . . . . . . 32

Install DIMMs . . . . . . . . . . . . . . . . . . . . . . . 32

Memory Configuration . . . . . . . . . . . . . . . . . . . . . 35

Memory DIMM Layout . . . . . . . . . . . . . . . . . . . . 36

Memory DIMM Rules . . . . . . . . . . . . . . . . . . . . . 37

Mixing Processors and DIMM Speeds . . . . . . . . . . . . . . . . . 39

Hard Disk Drives (SGI Rackable C2108-TY10 Chassis) . . . . . . . . . . . . . 45

PCI Card Slotting . . . . . . . . . . . . . . . . . . . . . . 46

Installing Selected PCI cards . . . . . . . . . . . . . . . . . . . 47

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . 48

6 Advanced Chassis Setup . . . . . . . . . . . . . . . . . . . . . 49

Static-Sensitive Device . . . . . . . . . . . . . . . . . . . . . . 51

Precautions . . . . . . . . . . . . . . . . . . . . . . . . 51

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . 51

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . 51

System Fans . . . . . . . . . . . . . . . . . . . . . . . . . 52

System Fan Failure . . . . . . . . . . . . . . . . . . . . . . 52

Replacing System Fans . . . . . . . . . . . . . . . . . . . . . 53

Removing a Fan . . . . . . . . . . . . . . . . . . . . . 53

Installing a New Fan . . . . . . . . . . . . . . . . . . . . 53

007-5688-003 vii

Contents

Drive Bay Installation/Removal . . . . . . . . . . . . . . . . . . . . 53

Accessing the Drive Bays . . . . . . . . . . . . . . . . . . . . 53

SATA Drive Installation. . . . . . . . . . . . . . . . . . . . . 54

Mounting a SATA Drive in a Drive Carrier . . . . . . . . . . . . . . 54

Installing/Removing Hot-swap SATA Drives . . . . . . . . . . . . . . 54

Hard Drive Backplane . . . . . . . . . . . . . . . . . . . . . 56

DVD-ROM Drive Installation . . . . . . . . . . . . . . . . . . . 56

Accessing the Inside of the Chassis . . . . . . . . . . . . . . . . 56

Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . 56

Power Supply Failure . . . . . . . . . . . . . . . . . . . . . 57

Removing/Replacing the Power Supply. . . . . . . . . . . . . . . . . 57

Removing the Power Supply . . . . . . . . . . . . . . . . . . 57

Installing a New Power Supply. . . . . . . . . . . . . . . . . . 57

7 BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Starting BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . 59

How To Change the Configuration Data. . . . . . . . . . . . . . . . . . 60

Starting the Setup Utility. . . . . . . . . . . . . . . . . . . . . . 60

Main Setup . . . . . . . . . . . . . . . . . . . . . . . . . 60

System Time/System Update . . . . . . . . . . . . . . . . . . . 61

Serverboard . . . . . . . . . . . . . . . . . . . . . . . . 61

Processor. . . . . . . . . . . . . . . . . . . . . . . . . 62

System Memory . . . . . . . . . . . . . . . . . . . . . . . 62

Advanced Setup Configurations . . . . . . . . . . . . . . . . . . . . 62

Boot Features . . . . . . . . . . . . . . . . . . . . . . . 63

Quick Boot . . . . . . . . . . . . . . . . . . . . . . . 63

Quiet Boot . . . . . . . . . . . . . . . . . . . . . . . 64

AddOn ROM Display Mode . . . . . . . . . . . . . . . . . . 64

Bootup Num-Lock . . . . . . . . . . . . . . . . . . . . . 64

Wait For 'F1' If Error . . . . . . . . . . . . . . . . . . . . 64

Hit 'Del' Message Display . . . . . . . . . . . . . . . . . . . 64

Interrupt 19 Capture . . . . . . . . . . . . . . . . . . . . 64

Power Configuration . . . . . . . . . . . . . . . . . . . . . 64

Power Button Function . . . . . . . . . . . . . . . . . . . . 65

viii 007-5688-003

Contents

Restore on AC Power Loss . . . . . . . . . . . . . . . . . . 65

Watch Dog Timer . . . . . . . . . . . . . . . . . . . . . 65

Processor and Clock Options . . . . . . . . . . . . . . . . . . . 65

Ratio CMOS Setting . . . . . . . . . . . . . . . . . . . . 65

C1E Support . . . . . . . . . . . . . . . . . . . . . . 65

Hardware Prefetcher (Available when supported by the CPU) . . . . . . . . . 66

Adjacent Cache Line Prefetch (Available when supported by the CPU) . . . . . . . 66

Intel Virtualization Technology (Available when supported by the CPU) . . . . . . 66

Execute-Disable Bit Capability (Available when supported by the OS and the CPU) . . . 66

Simultaneous Multi-Threading (Available when supported by the CPU). . . . . . . 66

Active Processor Cores . . . . . . . . . . . . . . . . . . . 66

Intel EIST Technology. . . . . . . . . . . . . . . . . . . . 67

Intel TurboMode Technology (Available when Intel EIST Technology is enabled) . . . . 67

Intel C-STATE Tech . . . . . . . . . . . . . . . . . . . . 67

C-State package limit setting (Available when Intel® C-State Tech is enabled) . . . . . 67

C1 Auto Demotion. . . . . . . . . . . . . . . . . . . . . 67

C3 Auto Demotion. . . . . . . . . . . . . . . . . . . . . 67

Clock Spread Spectrum . . . . . . . . . . . . . . . . . . . 67

Advanced Chipset Control . . . . . . . . . . . . . . . . . . . . 68

CPU Bridge Configuration. . . . . . . . . . . . . . . . . . . 68

Serial Debug Message Level . . . . . . . . . . . . . . . . . . 70

North Bridge Configuration . . . . . . . . . . . . . . . . . . . 70

Crystal Beach/Direct Memory Access (DMA) . . . . . . . . . . . . . 70

Crystal Beach/ Direct Cache Access (DCA) . . . . . . . . . . . . . . 71

Intel VT-d . . . . . . . . . . . . . . . . . . . . . . . 71

SouthBridge Configuration. . . . . . . . . . . . . . . . . . . . 71

USB Functions. . . . . . . . . . . . . . . . . . . . . . 71

Legacy USB Support . . . . . . . . . . . . . . . . . . . . 71

USB 2.0 Controller . . . . . . . . . . . . . . . . . . . . 71

USB 2.0 Controller Mode . . . . . . . . . . . . . . . . . . . 72

BIOS EHCI Hand-Off . . . . . . . . . . . . . . . . . . . . 72

Intel PCI-X Hub Configuration. . . . . . . . . . . . . . . . . . . 72

PCI Bus A0/B0 Frequency. . . . . . . . . . . . . . . . . . . 72

007-5688-003 ix

Contents

I/O Port Decode. . . . . . . . . . . . . . . . . . . . . . 72

RAS Sticky Error Handling. . . . . . . . . . . . . . . . . . . 72

VGA 16-Bit Decode . . . . . . . . . . . . . . . . . . . . 72

IDE and SATA Configuration . . . . . . . . . . . . . . . . . . . 73

SATA#1 Configuration. . . . . . . . . . . . . . . . . . . . 73

Primary IDE Settings . . . . . . . . . . . . . . . . . . . . 73

Hot Plug. . . . . . . . . . . . . . . . . . . . . . . . 76

IDE Detect Timeout (sec) . . . . . . . . . . . . . . . . . . . 76

PCI/PnP Configuration . . . . . . . . . . . . . . . . . . . . . 76

Clear NVRAM . . . . . . . . . . . . . . . . . . . . . . 76

Plug & Play OS. . . . . . . . . . . . . . . . . . . . . . 76

PCI Latency Timer . . . . . . . . . . . . . . . . . . . . . 77

PCI IDE BusMaster. . . . . . . . . . . . . . . . . . . . . 77

Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM . . . . . . . 77

Super IO Device Configuration . . . . . . . . . . . . . . . . . . . 77

Serial Port1 Address/ Serial Port2 Address. . . . . . . . . . . . . . . 77

Remote Access Configuration . . . . . . . . . . . . . . . . . . . 77

Remote Access . . . . . . . . . . . . . . . . . . . . . . 77

Hardware Health Monitor . . . . . . . . . . . . . . . . . . . . 79

CPU Overheat Alarm . . . . . . . . . . . . . . . . . . . . 79

CPU Temperature/System Temperature . . . . . . . . . . . . . . . 79

ACPI Configuration . . . . . . . . . . . . . . . . . . . . . . 81

ACPI Version Features . . . . . . . . . . . . . . . . . . . . 81

ACPI APIC Support . . . . . . . . . . . . . . . . . . . . 81

APIC ACPI SCI IRQ . . . . . . . . . . . . . . . . . . . . 82

Headless Mode . . . . . . . . . . . . . . . . . . . . . . 82

High Performance Event Timer . . . . . . . . . . . . . . . . . 82

Trusted Computing . . . . . . . . . . . . . . . . . . . . . . 82

TCG/TPM Support . . . . . . . . . . . . . . . . . . . . . 82

IPMI Configuration . . . . . . . . . . . . . . . . . . . . . . 83

Status of BMC . . . . . . . . . . . . . . . . . . . . . . 83

View BMC System Event Log . . . . . . . . . . . . . . . . . . . 83

Clear BMC System Event Log . . . . . . . . . . . . . . . . . . 83

x 007-5688-003

Contents

Set LAN Configuration. . . . . . . . . . . . . . . . . . . . . 84

IP Address Configuration . . . . . . . . . . . . . . . . . . . . 84

Parameter Selector . . . . . . . . . . . . . . . . . . . . . 84

IP Address . . . . . . . . . . . . . . . . . . . . . . . 84

Current IP Address in BMC . . . . . . . . . . . . . . . . . . 84

MAC Address Configuration . . . . . . . . . . . . . . . . . . . 85

Parameter Selector . . . . . . . . . . . . . . . . . . . . . 85

Mac Address . . . . . . . . . . . . . . . . . . . . . . 85

Current Mac Address in BMC. . . . . . . . . . . . . . . . . . 85

Subnet Mask Configuration . . . . . . . . . . . . . . . . . . . 85

Parameter Selector . . . . . . . . . . . . . . . . . . . . . 85

Subnet Mask . . . . . . . . . . . . . . . . . . . . . . 85

SEL PEF Configuration . . . . . . . . . . . . . . . . . . . . 86

PEF Support . . . . . . . . . . . . . . . . . . . . . . 86

PEF Action Global Control . . . . . . . . . . . . . . . . . . 86

Alert Startup Delay . . . . . . . . . . . . . . . . . . . . 86

PEF Alert Startup Delay . . . . . . . . . . . . . . . . . . . 86

Startup Delay . . . . . . . . . . . . . . . . . . . . . . 86

PEF Startup Delay . . . . . . . . . . . . . . . . . . . . . 87

BMC Watch Dog Timer Action . . . . . . . . . . . . . . . . . 87

DMI Event Log . . . . . . . . . . . . . . . . . . . . . . . 87

View Event Log . . . . . . . . . . . . . . . . . . . . . 87

Mark all events as read. . . . . . . . . . . . . . . . . . . . 88

Clear event log. . . . . . . . . . . . . . . . . . . . . . 88

Security Settings. . . . . . . . . . . . . . . . . . . . . . . . 88

Boot Configuration . . . . . . . . . . . . . . . . . . . . . . . 89

Boot Device Priority . . . . . . . . . . . . . . . . . . . . . 90

Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . 91

Removable Drives . . . . . . . . . . . . . . . . . . . . . . 91

Exit Options . . . . . . . . . . . . . . . . . . . . . . . . . 91

Save Changes and Exit . . . . . . . . . . . . . . . . . . . . . 92

Discard Changes and Exit . . . . . . . . . . . . . . . . . . . . 92

Discard Changes . . . . . . . . . . . . . . . . . . . . . . 93

007-5688-003 xi

Contents

Load Optimal Defaults . . . . . . . . . . . . . . . . . . . . . 93

Load Fail-Safe Defaults . . . . . . . . . . . . . . . . . . . . . 93

A BIOS Error Codes . . . . . . . . . . . . . . . . . . . . . . . 95

B System Specifications . . . . . . . . . . . . . . . . . . . . . . 97

Processors . . . . . . . . . . . . . . . . . . . . . . . . . 97

Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . 97

BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Memory Capacity . . . . . . . . . . . . . . . . . . . . . . . 97

SATA Controller . . . . . . . . . . . . . . . . . . . . . . . . 97

SATA Drive Bays . . . . . . . . . . . . . . . . . . . . . . . 98

Peripheral Drive Bays . . . . . . . . . . . . . . . . . . . . . . 98

Expansion Slots . . . . . . . . . . . . . . . . . . . . . . . . 98

Serverboard . . . . . . . . . . . . . . . . . . . . . . . . . 98

Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . 98

System Cooling . . . . . . . . . . . . . . . . . . . . . . . . 99

System Input Requirements . . . . . . . . . . . . . . . . . . . . . 99

Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . 99

Operating Environment . . . . . . . . . . . . . . . . . . . . . . 99

Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . 100

xii 007-5688-003

Figures

Figure 1-1 SGI Rackable C2108-TY10 Server . . . . . . . . . . . 1

Figure 1-2 Intel 5520/ICH10R Chipset System Block Diagram. . . . . . . 6

Figure 2-1 Separating and Installing the Rack Rails. . . . . . . . . . 11

Figure 2-2 Installing the Server in a Rack . . . . . . . . . . . . 13

Figure 2-3 Accessing the Inside of the System . . . . . . . . . . . 15

Figure 3-1 System Reset Button . . . . . . . . . . . . . . . 19

Figure 3-2 System Power On Button . . . . . . . . . . . . . 20

Figure 3-3 Power Fail LED . . . . . . . . . . . . . . . . 20

Figure 3-4 Overheat/Fan Fail LED . . . . . . . . . . . . . . 21

Figure 3-5 LAN1 Network Activity NIC1 LED . . . . . . . . . . . 21

Figure 3-6 LAN2 Network Activity NIC2 LED . . . . . . . . . . . 21

Figure 3-7 Hard Drive Activity LED . . . . . . . . . . . . . 22

Figure 3-8 Power On LED . . . . . . . . . . . . . . . . 22

Figure 4-1 Installing the Onboard Battery . . . . . . . . . . . . 24

Figure 5-1 Control Panel Header Pins . . . . . . . . . . . . . 29

Figure 5-2 I/O Ports Locations . . . . . . . . . . . . . . . 29

Figure 5-3 Node Board Features. . . . . . . . . . . . . . . 31

Figure 5-4 DIMM Installation . . . . . . . . . . . . . . . 33

Figure 5-5 Installing DIMM Modules . . . . . . . . . . . . . 34

Figure 5-6 Removing a DIMM Module . . . . . . . . . . . . . 35

Figure 5-7 Memory DIMM Locations . . . . . . . . . . . . . 36

Figure 5-8 Memory Block Diagram . . . . . . . . . . . . . . 37

Figure 5-9 SGI Rackable C2108-TY10 Disk Drive Locations . . . . . . . 45

Figure 5-10 Base PCI card configuration . . . . . . . . . . . . . 47

Figure 6-1 Front and Rear Chassis Views . . . . . . . . . . . . 50

Figure 6-2 Removing System Cooling Fans . . . . . . . . . . . . 52

Figure 6-3 Mounting a SATA Drive in a Carrier . . . . . . . . . . 54

Figure 6-4 Removing SATA Drive Carrier . . . . . . . . . . . . 55

007-5688-003 xiii

Figures

Figure 7-1 System Overview Main BIOS Setup Screen . . . . . . . . . 61

Figure 7-2 Advanced Settings Screen . . . . . . . . . . . . . 63

Figure 7-3 Security Settings Screen . . . . . . . . . . . . . . 88

Figure 7-4 Boot Settings Screen . . . . . . . . . . . . . . . 90

Figure 7-5 Exit Options Screen . . . . . . . . . . . . . . . 92

xiv 007-5688-003

Tables

Table 5-1 Jumper Descripton . . . . . . . . . . . . . . . 32

Table 5-2 Recommended Memory DIMM Configurations . . . . . . . . 40

Table 5-3 Non-Optimal Memory DIMM Configurations . . . . . . . . 43

Table A-1 BIOS Error Codes . . . . . . . . . . . . . . . 95

007-5688-003 xv

About This Guide

This guide provides an overview of the installation, architecture, general operation, and descriptions of the major components in the SGI basic troubleshooting and maintenance information, BIOS information, and important safety and regulatory specifications.

Audience

This guide is written for owners, installers, system administrators, and users of SGI Rackable C2108-TY10 computer systems. It is written with the assumption that the reader has a good working knowledge of computers and computer systems.

Chapter Descriptions

The following topics are covered in this guide:

• Chapter 1, “Introduction”

• Chapter 2, “Server Installation”

• Chapter 3, “System Interface”

®

Rackable®C2108-TY10 server. It also provides

Provides an overview SGI Rackable C2108-TY10 server components.

Provides a quick setup checklist to get the SGI Rackable C2108-TY10 operational.

Describes several LEDs on the control panel as well as others on the SATA drive carriers that keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

• Chapter 4, “System Safety” Provides system safety information.

• Chapter 5, “Advanced Severboard Setup” Provides procedures to install a node board into the SGI Rackable C2108-TY10 chassis, connect the data and power cables, and install expansion cards.

007-5688-003 xvii

• Chapter 6, “Advanced Chassis Setup” Describes the steps required to install components and perform maintenance on the SGI Rackable C2108-TY10 chassis.

• Chapter 7, “BIOS” Describes the AMI BIOS Setup Utility for the SGI Rackable C2108-TY10 severboard.

• Appendix A, “BIOS Error Codes,” Provides BIOS error code information.

• Appendix B, “System Specifications,”

Describes system component specifications.

xviii 007-5688-003

Related Publications

The following SGI and LSI documents are relevant to the SGI Rackable C2108-TY10 server:

• MegaRAID SAS Software User’s Guide, publication number, publication number

• MegaRAID 1078-based SAS RAID Controllers User’s Guide, publication number

• LSI Integrated SAS for RAID User’s Guide, publication number 860-0476-00x

• SGI Foundation Software Start Here, publication number 007-5641-00x

• SGI Performance Suite Start Here, publication number 007-5680-00x

• SGI InfiniteStorage series documentation

• Man pages (online)

You can obtain SGI documentation (as well as the pertinent LSI books), release notes, or man pages in the following ways:

• Refer to the SGI Technical Publications Library at http://docs.sgi.com. Various formats are

:

860-0488-00x

860-0489-00x

available. This library contains the most recent and most comprehensive set of online books, release notes, man pages, and other information.

• You can also view man pages by typing man <title> on a command line.

SGI systems include a set of Linux

®

man pages, formatted in the standard UNIX® “man page” style. Important system configuration files and commands are documented on man pages. These are found online on the internal system disk (or DVD-CD) and are displayed using the man command. For example, to display the man page for the xscsidisktest command, type the following on a command line:

man xscsidisktest

For additional information about displaying man pages using the man command, see man(1).

In addition, the apropos command locates man pages based on keywords. For examp le, to display a list of man pages that describe disks, type the following on a command line:

apropos disk

For information about setting up and using apropos, see apropos(1).

007-5688-003 xix

Conventions

Product Support

The following conventions are used throughout this document:

Convention Meaning

Command This fixed-space font denotes literal items such as commands, files,

routines, path names, signals, messages, and programming language structures.

variable The italic typeface denotes variable entries and words or concepts being

defined. Italic typeface is also used for book titles.

user input This bold fixed-space font denotes literal items that the user enters in

interactive sessions. Output is shown in nonbold, fixed-space font. [ ] Brackets enclose optional portions of a command or directive line. ... Ellipses indicate that a preceding element can be repeated. man page(x) Man page section identifiers appear in parentheses after man page names. GUI element This font denotes the names of graphical user interface (GUI) elements such

as windows, screens, dialog boxes, menus, toolbars, icons, buttons, boxes,

fields, and lists.

SGI provides a comprehensive product support and maintenance program for its products. SGI also offers services to implement and integrate Linux applications in your environment.

• Refer to http://www.sgi.com/support/

• If you are in North America, contact the Technical Assistance Center at

+1 800 800 4SGI or contact your authorized service provider.

• If you are outside North America, contact the SGI subsidiary or authorized distributor in

your country.

xx 007-5688-003

Reader Comments

:

If you have comments about the technical accuracy, content, or organization of this document, contact SGI. Be sure to include the title and document number of the manual with your comments. (Online, the document number is located in the front matter of the manual. In printed manuals, the document number is located at the bottom of each page.)

You can contact SGI in any of the following ways:

• Send e-mail to the following address: techpubs@sgi.com

• Contact your customer service representative and ask that an incident be filed in the SGI incident tracking system.

• Send mail to the following address: SGI

Technical Publications 46600 Landing Parkway Fremont, CA 94538

SGI values your comments and will respond to them promptly.

007-5688-003 xxi

Chapter 1

1. Introduction

Important: SGI Rackable systems may sometimes require driver versions that are not included in the original operating system release. SGI provides these required drivers on the SGI Rackable Driver CD, which ships with all SGI Rackable systems, and on systems that are pre-installed in the factory. For more inf or mation, check with your sales or service representative.

The SGI Rackable C2108-TY10 server is a 2U rackmount server (see Figure 1-1)

main subsystems: the 2U server chassis and the dual processor serverboard

sgi

Figure 1-1 SGI Rackable C2108-TY10 Server

. It has two

.

In addition to the serverboard and chassis, various hardware components have been included with the SGI Rackable C2108-TY10, as listed below:

• One slim DVD-ROM drive (optional)

• Three 8-cm chassis fans

007-5688-003 1

1: Introduction

• Two passive heatsinks

• One air shroud

• SATA and SAS Accessories – One SAS/SATA backplane – One 2-ft. SATA cable – Two 35-cm SATA cables – Two 40-cm SGPIO cables – Two 48-cm SATA cables – One 70-cm SATA cable – Eight drive carriers

• One rackmount kit

• One CD containing drivers and utilities

2 007-5688-003

Server Board Features

At the heart of the SGI Rackable C2108-TY10 system is a dual processor serverboard based on the Intel 5520 + ICH10R chipset and designed to provide maximum performance. Below are the main features of the serverboard.

Processors

The serverboard supports single or dual Intel® Xeon® 5500 processors. The Intel® Xeon® 5200 and 5400 processors are not supported.

Memory

The serverboard has eighteen DIMM slots that can support up to 144 GB of DDR3 1333/1066/800 registered ECC SDRAM (see “Installing Memory” on page 32).

Serial ATA

A Serial ATA controller is integrated into the ICH10R (South Bridge) portion of the chipset to provide a six-port 3 Gb/s SATA subsystem, which is RAID 0, 1, 10 and 5 supported. The SATA drives are hot-swappable units.

Server Board Features

Note: The SATA drives are hot-swappable units if your operating systems has RAID support.

PCI Expansion Slots

The dual processor serverboard has two low-profile PCI Express 2.0 x8 slots, one low-profile PCI Express x4 slot (in a x8 slot), three low-profile 64-bit 133/100 MHz PCI-X slots and one UIO slot (see “PCI Card Slotting” on page 46)

UIO

The serverboard is a specially-designed serverboard that features Universal I/O (UIO) technology. UIO serverboards have a PCI-Express x8 connector that can support one of two types of UIO card types, L8i and H8iR (low-profile only) to add SAS ports, additional LAN ports, and so on, to the serverboard.

007-5688-003 3

1: Introduction

Note: The SGI Rackable C2108-TY10 does not come with a UIO card pre-installed.

When the RAID option is ordered, this slot is filled with the RAID card.

Onboard Controllers/Ports

One onboard ATA/100 connector, which supports IDE hard drives or ATAPI devices. The color-coded I/O ports include one COM port (an additional COM header is located on the serverboard), a VGA (monitor) port, two USB 2.0 ports (two additional USB headers and one Type A port are included on the serverboard), PS/2 mouse and keyboard ports and two gigabit Ethernet ports.

ATI Graphics Controller

The dual processsor serverboard features an integrated ATI video controller based on the ES1000 32 MB graphics chip. The ES1000 was designed specifically for servers, featuring low power consumption, high reliability and superior longevity.

Other Features

Other onboard features that promote system health include onboard voltage monitors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU overheat sensors, virus protection and BIOS rescue.

Server Chassis Features

The following is a general outline of the main features of the SGI Rackable C2108-TY10 server chassis.

System Power

The SGI Rackable C2108-TY10 server chassis features a redundant 720W power supply composed of two separate power modules. This power redundancy feature allows you to replace a failed power supply without shutting down the system.

4 007-5688-003

Serial ATA Subsystem

Front Control Panel

Server Chassis Features

The SGI Rackable C2108-TY10 server chassis supports up to six 3 Gb/s Serial ATA drives. The SATA drives are hot-swappable units and are connected to a backplane that provides power and control.

Note: The operating system you have installed must support RAID to enable the hot-swap capability of the SATA drives.

The control panel on the SGI Rackable C2108-TY10 provides you with system monitoring and control. LEDs that indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included. In addition, two USB ports and one serial port have been incorporated into the control panel to provide front side USB and COM port access.

Motherboard

The SGI Rackable C2108-TY10 server chassis is an A TX form f actor chassis designed to be used in a 2U rackmount configuration. The motherboard provides one UIO slot, seven low-profile expansion slots, one COM port, a VGA port, two USB 2.0 ports, PS/2 mouse and keyboard ports and two Gigabit Ethernet ports.

Cooling System

The SGI Rackable C2108-TY10 server chassis has an innovative cooling design that includes three 8-cm hot-plug system cooling fans located in the middle section of the chassis. An air shroud channels the airflow from the system fans to efficiently cool the processor area of the system. The power supply module also includes a cooling fan.

Figure 1-2 shows a general block diagram of the Intel 5520/ICH10R chipset.

007-5688-003 5

1: Introduction

#1

DDR3 DIMM

A

B

#2

DDR3 DIMM

#1

PCI-x Slot

A

B

CC

#3

Chnl A

PCI-x Slot

Chnl B

JMB368

IDE

#3

#4

#0

PCI-E x8 Slot

#5

A

B

CPU1

C

DDR3 DIMM

#6

PCI-E x8 Slot

SEPC

J11

PCI-Ex16 Slot

PXH

x1

PE

5

x4

PE 4-1

PCI-E x8 Slot

SIMLP

DDR2

CSI

Port1 Port0 Ports

3,4

Intel 5520

Ports

5,6

Ports

7,8

9,10

PCI

VGA

ES1000

ESI

DMI

SATA

CPU2

Ports

1,2

CLINK

ICH10R

SATA #1 SATA #2 SATA #3 SATA #4 SATA #5 SATA #6

D

E

F

#3

DDR3 DIMM

82575

RJ45RJ45

SST25

VF016

SPI

LPC

SIO

83627

Floppy

D

E

F

#2

DDR3 DIMM

D

E

F

#1

DDR3 DIMM

Figure 1-2 Intel 5520/ICH10R Chipset System Block Diagram

6 007-5688-003

VGA

Chapter 2

2. Server Installation

This chapter provides a quick setup checklist to get the SGI Rackable C2108-TY10 operational.

Unpack the System

Inspect the shipping container that the SGI Rackable C2108-TY10 was shipped in and note if it was damaged in any way. If the server shows damage, file a damage claim with the carrier who delivered it.

Decide on a suitable location for the rack that supports the weight, power requirements, and environmental requirements of the SGI Rackable C2108-TY10 server. It should be situated in a clean, dust-free environment that is well ventilated. Avoid areas where heat, electrical noise, and electromagnetic fields are generated. Place the server rack near a grounded power outlet. Refer to

“Warnings and Precautions” on page 8.

Prepare for Setup

The shipping container should include two sets of rail assemblies, two rail mounting brackets and the mounting screws that you will use to install the system into a rack.

Read this section in its entirety before you begin the installation procedure.

Choose a Setup Location

Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

007-5688-003 7

2: Server Installation

Warnings and Precautions

Rack Precautions

!

Warning: The SGI Rackable C2108-TY10 server weighs 57 lbs (26 kg). Always use proper

lifting techniques when your move the server . Always get the assistance of another qualified person when you install the sever in a location above your shoulders. Failure to do so may result in serious personal injury or damage to the equipment.

Warning: Extend the leveling jacks on the bottom of the rack to the floor with the full

weight of the rack resting on them. Failure to do so can result in serious injury or death.

Warning: Attach stabilizers to the rack in single rack installations. Failure to do so can

result in serious injury or death.

Warning: Couple racks together in multiple rack installations. Failure to do so can result

in serious injury or death.

Warning: Be s ure the rack is stable befor e extending a component fr om the rack. Failur e

to do so can result in serious injury or death.

!

8 007-5688-003

Warning: Extend only one component at a time. Extending two or more components

simultaneously may cause the rack to tip over and result in serious injury or death.

Server Precautions

• Review the electrical and general safety precautions.

• Determine the placement of each component in the rack before you install the rails.

• Install the heaviest server components in the bottom of the rack first, and then work up.

• Use a regulating uninterruptible power supply (UPS) to protect the server from power surges

and voltage spikes and to keep your system operating in case of a power failure.

• Allow the hot-pluggable SAS/SATA drives and power supply modules to cool before

touching them.

• Always keep the rack’s front door and all panels and components on the servers closed when

not servicing to maintain proper cooling.

Rack Mounting Considerations

Ambient Operating Temperature

Rack Mounting Considerations

If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (

35º C or 95º F).

Reduced Airflow

Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised.

Mechanical Loading

Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

007-5688-003 9

2: Server Installation

Circuit Overloading

Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

Reliable Ground

A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (for example, the use of power strips, and so on).

Install the System into a Rack

This section provides information on installing the SGI Rackable C2108-TY10 into a rack. If the system has already been mounted into a rack, refer to “Check the Node Board Setup” on page 14. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installat ion instructions that came with the rack unit you are using.

Note: This rail will fit a rack between 26" and 33.5" deep.

Separate the Sections of the Rack Rails

The chassis package includes two rail assemblies in the rack mounting kit. Each assembly consists of two sections: an inner fixed chassis rail that secures directly to the server chassis and an outer fixed rack rail that secures directly to the rack itself.

To separte the inner and outer rails, perform the following steps:

1. Locate the rail assembly in the chassis packaging as shown in Figure 2-1.

2. Extend the rail assembly by pulling it outward.

3. Press the quick-release tab

10 007-5688-003

4. Separate the inner rail from the outer rail assembly.

Install the System into a Rack

1

2

4

5

Rail Assembly

Extending the Rails

3

QuickRelease T ab

Separating the Inner Rail Extension

7

Figure 2-1 Separating an d Installing the Rack Rails

007-5688-003 11

6

2: Server Installation

Outer Rack Rails

Outer rails attach to the rack and hold the chassis in place. The outer rails for the chassis extend between 30 inches and 33 inches.

Install the Outer Rails to the Rack

5. Secure the back end of the outer rail to the rack, using the screws provided (see Figure 2-1).

6. Press the button where the two outer rails are joined to retract the smaller outer rail.

7. Hang the hooks of the rails onto the rack holes and if desired, use screws to secure the front of the outer rail onto the rack.

8. Repeat steps 1-3 for the remaining outer rail.

Install the Inner Rail Extension

The SGI Rackable C2108-TY10 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack The inner rail extension is attached to the inner rail to mount the chassis in the rack.

Install the Inner Rails

Perform the following steps to install the inner rails:

1. Place the inner rail extensions on the side of the chassis aligning the hooks of the chassis

with the rail extension holes. Make sure the extension faces "outward" just like the pre-attached inner rail.

2. Slide the extension toward the front of the chassis.

3. Secure the chassis with 2 screws as illustrated. Repeat steps for the other inner rail

extension.

12 007-5688-003

Install the Server in a Rack

Install the System into a Rack

!

lifting techniques when your move the server . Always get the assistance of another qualified person when you install the sever in a location above your shoulders. Failure to do so may result in serious personal injury or damage to the equipment.

You should now have rails attached to both the server chassis and the rack unit. The next step is to install the server into the rack (refer to Figure 2-2).

1. Extend the outer rails as shown in Figure 2-2.

2. Align the inner rails of the chassis with the outer rails on the rack.

3. Slide the inner rails into the outer rails, keeping the pressure even on both sides. When the

chassis has been pushed completely into the rack, it should click into the locked position.

4. Optional screws may be used to secure the to hold the front of the chassis to the rack.

Warning: The SGI Rackable C2108-TY10 server weighs 57 lbs (26 kg) Always use proper

Figure 2-2 Install ing the Ser ver in a Rac k

007-5688-003 13

2: Server Installation

Check the Node Board Setup

Use the following sections to open the top cover and check that each node board is properly installed and all the connections have been made.

Access the Inside of the Chassis

1. Grasp the two handles on either side and pull the unit straight out until it locks (you will hear a “click”).

2. Depress the two buttons on the top of the chassis to release the top cover as shown in

Figure 2-3.

3. Lift the top cover from the chassis.

Note: T o remove the system from the rack completely , depress the locking tabs on the chassis rails (push the right-side tab down and the left-side tab up) to continue to pull the system out past the locked position.

14 007-5688-003

Check the Node Board Setup

Figure 2-3 Accessing the Inside of the System

007-5688-003 15

2: Server Installation

Check the CPUs (processors)

You may have one or two processors installed into the serverboard. Each processor needs its own heatsink.

Check the System Memory

Your server system is shipped with system memory installed. Make sure all DIMMs are fully seated in their slots. For details on adding system memory, refer to Chapter 3.

Install Expansion PCI Cards

You can install six expansion PCI cards in the system. Refer to Chapter 3 for details on installin g PCI expansion cards.

Check all Cable Connections and Airflow

Make sure all power and data cables are properly connected and not blocking the chassis airflow. Refer to Chapter 3 for details on cable connections.

Check the Drive Bay Setup

Next, you should check to make sure the system disk drives and disk drive backplane have been properly installed and all connections have been made.

Check the System Disk Drives

All drives are accessable from the front of the server. For servicing the DVD-ROM, you will need to remove the top chassis cover. The hard drives can be installed and removed from the front of the chassis without removing the top chassis cover. Depending upon your system configuration, your system may have one or more drives installed. For detailed information about how to install disk drives, see “Hard Disk Drives (SGI Rackable C2108-TY10 Chassis)” on page 45.

If you have more than 4TB of storage, you must create multiple volumes to fully utilize your RAID disks.

16 007-5688-003

Check the Airflow

Check the Node Board Setup

Refer to the MegaRAID SAS Software User's Guide, SGI publication number 860-0488-00x and the MegaRAID 1078-based SAS RAID Controllers User's Guide, SGI publication number 860-0489-00x for more information about configuring your system disks.

A slim DVD-ROM may be preinstalled in your server. Refer to Chapter 6 if you need to install a DVD-ROM disk drive to the system.

Depending upon your system's configuration, your system may have one or more drives already installed. If you need to install hard drives, please refer to Chapter 6.

Airflow is provided by three hot-swappable 8-cm chassis cooling fans . The system component layout was carefully designed to direct sufficient cooling airflow to the components that generate the most heat.

Note: Make sure that all power and data cables have been routed in such a way that they do not block the airflow generated by the fans.

Supply Power to the System

If necessary , install the system in a rack (refer to “Install the System into a Rack” on page 10), and connect the power cord from the power supply module into a power strip or power distributi on unit (PDU). SGI also recommends that you use an uninterruptible power supply (UPS) source.

007-5688-003 17

Chapter 3

3. System Interface

Overview

There are several LEDs on the control panel as well as others on the SATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components. There are also two buttons on the chassis control panel.

Control Panel Buttons

There are two buttons located on the front of the chassis: a reset button and a power on/off button. Use the reset button to reboot the system as shown in Figure 3-1.

Figure 3-1 System Reset Button

Figure 3-2 shows the the main power button, which is used to apply or turn off the mai n sy stem

power. Turning off system power with this button removes the main power but keeps standby power supplied to the system.

007-5688-003 19

3: System Interface

Figure 3-2 System Power On Button

Control Panel LEDs

The control panel located on the front of the chassis has several LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

Power Fail

The power fail LED ndicates a power supply module has failed as shown in Figure 3-3. The second power supply module will take the load and keep the system running but the failed module will need to be replaced. Refer to Chapter 6 for details on replacing the power supply. This LED should be off when the system is operating normally.

Figure 3-3 Power Fail LED

Overheat/Fan Fail

When the red overheat/fan LED flashes (shown in Figure 3-4), it indicates a fan failure. When on continuously it indicates an overheat condition, which may be caused by cables obstructing the airflow in the system or the ambient room temperature being too warm. Check the routing of

20 007-5688-003

NIC1

Control Panel LEDs

the cables and make sure all fans are present and operating normally. You should also check to make sure that the chassis covers are installed. This LED will remain flashing or on as long as the indicated condition exists.

Figure 3-4 Overheat/Fan Fail LED

When flashing, the NIC1 LED indicates network activity on the LAN1 port (see Figure 3-5).

1

Figure 3-5 LAN1 Network Activity NIC1 LED

NIC2

When flashing, the NIC2 LED indicates network activity on the LAN2 port (see Figure 3-6).

2

Figure 3-6 LAN2 Network Activity NIC2 LED

HDD

The HDD LED indicates hard drive drive activity when flashing (see Figure 3-7).

007-5688-003 21

3: System Interface

Power

Figure 3-7 Hard Drive Activity LED

The power LED indicates power is being supplied to the system's power supply units is shown in

Figure 3-8. This LED should normally be illuminated when the system is operating.

Figure 3-8 Power On LED

SATA Drive Carrier LEDs

Each SATA drive carrier has two LEDs, as follows:

• Green: When illuminated, the green LED on the SATA drive carrier indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. Please refer to Chapter 6 for instructions on replacing failed drives.

• Red: The red LED indicates a SATA drive failure. If one of the drives fails, you should be notified by your system management software. Please refer to Chapter 6 for instructions on replacing failed drives.

22 007-5688-003

Chapter 4

4. System Safety

This chapter describes basic safety precautions.

Electrical Safety Precautions

Basic electrical safety precautions should be followed to protect yourself from harm and the SGI Rackable C2108-TY10 system from damage, as follows:

• Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet. If an electrical accident occurs, you can then quickly remove power from the system.

• Do not work alone when working with high voltage components.

• Power should always be disconnected from the system when removing or installing main system components, such as the serverboard, memory modules and SATA drives. When disconnecting power, you should first power down the operating system first and then unplug the power cords. The unit has more than one power supply cord. Disconnect two power supply cords before servicing to avoid electrical shock .

• When working around exposed electrical circuits, another person who is familiar with the power-off controls should be nearby to switch off the power if necessary.

• Use only one hand when working with powered-on electrical equipment. This is to avoid making a complete circuit, which will cause electrical shock. Use extreme caution when using metal tools, which can easily damage any electrical components or circuit boards they come into contact with.

• Do not use mats designed to decrease static electrical discharge as protection from electrical shock. Instead, use rubber mats that have been specifically designed as electrical insulators.

• The power supply power cords must include a grounding plug and must be plugged into grounded electrical outlets.

007-5688-003 23

4: System Safety

• Serverboard Battery

Caution: There is a danger of explosion if the onboard battery is installed upside down,

!

which will reverse its polarites (see Figure 4-1). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

• DVD-ROM Laser

Caution: This server may have come equipped with a DVD-ROM drive. To prevent direct exposure to the laser beam and hazardous radiation exposure, do not open the enclosure or use the unit in any unconventional way.

• Mainboard replaceable soldered-in fuses: Self-resetting PTC (Positive T emperature Coef ficient)

fuses on the mainboard must be replaced by trained service technicians only. The new fuse must be the same or equivalent as the one replaced. Contact technical support for details and support.

Lithium battery

Battery holder

Figure 4-1 Installing the Onboard Battery

General Safety Precautions

Follow these rules to ensure general safety:

• Keep the area around the SGI Rackable C2108-TY10 system clean and free of clutter.

• The SGI Rackable C2108-TY10 system weighs approximately 57 lbs (25.9 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight. Always keep your back straight and lift with your legs.

24 007-5688-003

ESD Precautions

!

ESD Precautions

• Place the chassis top cover and any system components that have been removed away from

the system or on a table so that they won't accidentally be stepped on.

• While working on the system, do not wear loose clothing such as neckties and unbuttoned

shirt sleeves, which can come into contact with electrical circuits or be pulled into a cooling fan.

• Remove any jewelry or metal objects from your body, which are excellent metal conductors

that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present.

• After accessing the inside of the system, close the system back up and secure it to the rack

unit with the retention screws after ensuring that all connections have been made.

Caution: Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other. An electrical discharge is created to neutralize this difference, which can damage electronic com ponents and printed circuit boards.

The following measures are generally sufficient to neutralize this difference before contact is made to protect your equipment from ESD:

• Use a grounded wrist strap designed to prevent static discharge.

• Keep all components and printed circuit boards (PCBs) in their antistatic bags until ready for

use.

• Touch a grounded metal object before removing the board from the antistatic bag.

• Do not let components or PCBs come into contact with your clothing, which may retain a

charge even if you are wearing a wrist strap.

• Handle a board by its edges only; do not touch its components, peripheral chips, memory

modules or contacts.

• When handling chips or modules, avoid touching their pins.

• Put the serverboard and peripherals back into their antistatic bags when not in use.

• For grounding purposes, make sure your computer chassis provides excellent conductivity

between the power supply, the case, the mounting fasteners and the serverboard.

007-5688-003 25

Chapter 5

5. Advanced Severboard Setup

This chapter includes procedures to install a node board into the SGI Rackable C2108-TY10 chassis, connect the data and power cables, and install expansion cards.

A layout and quick reference chart is included in this chapter for your reference. See “Serverboard

Quick Reference” on page 32.

Note: Some software products are protected with software license keys derived from the Media Access Control (MAC) Ethernet address. When you replace a node board, the MAC Ethernet address changes. If you are using such a product, you must request a new license key after replacing the node board. Contact your local customer support office

http://www.sgi.com/support/supportcenters.html

!

Caution: Install the chassis cover after you have completed accessing the components inside the

server to maintain proper airflow and cooling for the system.

Handling the Node Board

!

007-5688-003 27

Caution: Electrostatic discharge (ESD) can damage electrostatic-sensitive devices inside the SGI Rackable C2108-TY10 server. Use the ESD precautions described below when you handle printed circuit boards or other components in the system. The following measures are generally sufficient to protect your equipment from electric static discharge.

5: Advanced Severboard Setup

ESD Precautions

Unpacking

• Use a grounded wrist strap designed to prevent electrostatic discharge.

• Touch a grounded metal object before removing any board from its antistatic bag.

• Handle each printed circuit board (PCB) by the edges; do not touch the components, peripheral chips, memory modules, or gold contacts on the PCB.

• When handling chips or modules, avoid touching the pins.

• Place the node board, expansion PCI cards, or other boards and components into antistatic bags when not in use.

• Make sure your computer chassis provides a conductive path between the power supply, the case, the mounting fasteners, and the node board to chassis ground.

!

Caution: The node board is shipped in antistatic packaging to avoid electrostatic discharge

damage. Be sure to use ESD precautions when you unpack replacement components for the SGI Rackable C2108-TY10 server. Failure to do so can result in damage to the equipment.

Connecting the Control Panel

JF1 contains header pins for various front control panel connectors. See Figure 5-1 for the pin locations of the various front control panel buttons and LED indicators.

All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the board. The other end connects to the Control Panel PCB board, located just behind the system status LEDs on the chassis.

28 007-5688-003

20 19

I/O Ports

Ground

x (Key)

Power On LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

Power Fail LED

Ground

2 1

Figure 5-1 Control Panel Header Pins

NMI

x (Key)

Vcc

Reset (Button)

Power (Button)

The I/O ports are color coded in conformance with the PC 99 specification. See Figure 5-2 below for the colors and locations of the various I/O ports.

Figure 5-2 I/O Ports Locations

007-5688-003 29

5: Advanced Severboard Setup

Serverboard Details

The 2U SGI Rackable C2108-TY10 chassis has one node board. It can be configured with 1 or 2 processor sockets. When configuring two processors, the following rules apply:

• Both processor sockets must have identical revisions, core voltage, and bus/core speed.

• The stepping between the two processors on a node board must be identical.

• If only one processor is installed, the single processor socket must be installed in the socket

See Figure 5-3 for location of CPU 1.

labeled CPU1 (See Figure 5-3). The other socket remains empty.

30 007-5688-003

Fan5

Fan6

JKM1

JUSB1

JCOM1

JG1

VGA

JLAN1

JLAN2

CPU2 Fan

COM1

Fan8

KB/MS

USB0/1

LAN1

LAN2

J21

Serverboard Details

J15

JPP1

JPP0

J100

J101

J102

J103

J104

J105

J106

J107

J108

PWR I2C

XDP

Fan7 CPU1 Fan

JP6

JPW1

CPU1

P1 DIMM1C

P1 DIMM1B

P1 DIMM1A

P1 DIMM2C

P1 DIMM2B

P1 DIMM2A

P1 DIMM3C

P1 DIMM3B

P1 DIMM3A

JPW4

JPW3

JAR

Fan1

FP CTRL

JF1

Fan2

LE1

JD1

OH LED

JOH1

J118

J117

J116

J115

J114

J113

J112

J111

J110

P2 DIMM3A

P2 DIMM3B

P2 DIMM3C

P2 DIMM2A

P2 DIMM2B

P2 DIMM2C

P2 DIMM1A

P2 DIMM1B

P2 DIMM1C

CPU2

IPMI

SIMLP

VGA CTRL

X8DTN+

LAN CTRL

JPL1

S I/O

JPG1

J6

Slot5 PCI-E X4

J5

Slot4 PCI-E2 X8

J4

Slot3 PCI-X 100/133MHZ

J3

Slot2 PCI-X 100/133MHZ

J2

Slot1 PCI-X 133MHZ

J1

Slot0 PCI-U

J10

JK1

SEPC

Clear CMOS

JBT1

J12

J11

Battery

J13

JP4

IPMB

JWOR1

Fan3

Intel IOH-D36

SPI

BIOS

PXH

COM2

JCOM2

J14

USB6

J7

USB7

USB2/3

JUSB2

J8

JUSB3

USB4

J16

WOL

Intel ICH9R

JL1

I-SATA5

I-SATA4

T-SGPIO1

JWF1 T-SGPIO2

I-SATA2

I-SATA3

Floppy

I-SATA1

I-SATA0

SPKR

SP1

IDE

JIDE1

Fan4

JP3

Slot6 PCI-E2 X8

Figure 5-3 Node Board Features

007-5688-003 31

5: Advanced Severboard Setup

Serverboard Quick Reference

Table 5-1 Jumper Descripton

Jumper Description Default Setting

JBT1 CMOS Clear See Section 5-10 J12 SMB to PCI-Exp. Slots Pins 2-3 (Disabled) J13 SMB to PCI-X Slots Pins 2-3 (Disabled) J21 Watch Dog Enable/Disable Pins 1-2 (Reset) JP3 IDE Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enable)

Installing Memory

!

Install DIMMs

JPL1 LAN1/2 Enable/Disable

Caution: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage.

SGI Rackable C2108-TY10 serverboard supports up to 144 GB of DDR3 1333/1066/800 registered ECC SDRAM in 18 DIMM slots. Three-way interleaved memory is supported. For optimal memory performance, install DIMMs three at a time. Use memory modules of the same type and speed. See the following table for memory installation.

Perform the following steps to install memory modules, as follows:

1. Insert the DIMM module vertically and press down into its slot until it snaps into place. Pay attention to the alignnment notch at the bottom of the module to avoid installing inco rrectly (see Figure 5-4 and Figure 5-5). Insert the desired number of DIMMs into the memory slots, beginning with DIMM #1A and DIMM #2A, then DIMM #3A and DIMM #4A, etc. (see

Pins 1-2 (Enabled)

32 007-5688-003

Installing Memory

R

b

Table 5-2). Always spread DIMMs across all three banks for each CPU (see Figure 5-3).

Gently press down on the DIMM module until it snaps into place in the slot. Repeat for all modules.

2. T o remove a DIMM module, use your thumbs to gently push the release tabs near both ends

of the module (see Figure 5-4). This should release it from the slot (see Figure 5-6).

1

Notch

2

elease tab

Figure 5-4 DIMM Installation

Front view

Top view of DDR3 slot

Notch

Release ta

007-5688-003 33

5: Advanced Severboard Setup

Figure 5-5 Installing DIMM Modules

34 007-5688-003

Installing Memory

Figure 5-6 Removing a DIMM Module

Memory Configuration

When configured with two processors, the SGI Rackable C2108-TY10 can be configured with a maximum of eighteen memory DIMMs.

Unlike previous processors, the Nehalem-EP processor has the memory controller embedded within the processor socket. There are nine memory DIMMs that are controlled by each processor .

If the node board is configured with only one processor the total number of memory DIMMs supported with be reduced from 18 to 9.

See Figure 5-7 for memory DIMM locations.

007-5688-003 35

5: Advanced Severboard Setup

J118

J117

J116

J115

J114

J113

J112

J111

J110

P2 DIMM-3A

P2 DIMM-3B

P2 DIMM-3C

P2 DIMM-2A

P2 DIMM-2B

P2 DIMM-2C

P2 DIMM-1A

P2 DIMM-1B

P2 DIMM-1C

Rear of Chassis

Figure 5-7 Memory DIMM Locations

CPU2

J100

J101

J102

J103

J104

J105

J106

J107

J108

CPU1

P1 DIMM1C

P1 DIMM1B

P1 DIMM1A

P1 DIMM2C

P1 DIMM2B

P1 DIMM2A

P1 DIMM3C

P1 DIMM3B

P1 DIMM3A

Front of Chassis

Memory DIMM Layout

The SGI Rackable C2108-TY10 Nehalem-EP memory controller has three channels with three memory DIMM slots on each channel.

36 007-5688-003

Memory

S

Channel 1

Nehalem-EP

Memory

Channel 2

Memory

Channel 3

Figure 5-8 Memory Block Diagram

D D R 3

lot C

D

R

3

D

R

3

D

R

3

lot BSlot A

Installing Memory

Memory DIMM Rules

Use the following rules when installing memory DIMMs:

The minimum memory allowed on SGI Rackable C2108-TY10 cluster nodes is defined by whether or not the compute nodes are diskless:

• Diskless compute nodes: 8GB per node memory minimum

• Diskful compute nodes: 4GB per node memory minimum

Memory DIMM Rules

• Populate the DIMMs in the furthest slot from the processor for channel 1, first. Then

channels 2 - 3.

• A minimum of one DIMM per processor must always be present - one for each processor.

• Mixing DIMM Sizes - When mixing DIMMs on a channel that has a mixed number of ranks,

it is recommended to have the total number of ranks on the channel be even to avoid bandwidth degradation. Example: placing a single-rank DIMM and a dual-rank DIMM on the same channel is not desirable. The total number of ranks would be three - an odd number

007-5688-003 37

5: Advanced Severboard Setup

of ranks. If this option is used, populate the higher ranking DIMMs furthest from the processor (slot A).

• For maximum memory performance the DIMMs within a node must be identical in: – Speed (1066 or 1333 Mtransfer/sec) – Number of ranks (1 or 2)

Note: The speed of the memory controller will reduce to the lowest speed DIMM on the channel.

• When configuring the memory for maximum performance, it is critical that the memory DIMM capacity is balanced across all memory channels.

Note: The key words are “memory capacity”.

Note: The maximum speed of the memory controller changes based on the number of DIMMs

placed on the channel:

• Three DIMMs on the channel the maximum speed supported is 800 MT/s

• Two DIMMs on the channel the maximum speed supported is 1066 MT/s

• One DIMM on the channel the maximum speed supported is 1333 MT/s

Note: Reason for the decrease in memory performance - as more DIMMs are added to a channel the noise on the channel increases and the voltage levels decrease due to signal loading. As a result we have to lower the frequency that we run the channel as more DIMMs are added.

See Table 5-2 for the recommended DIMM configurations that will achieve the maxim um memory performance.

Memory DIMM configurations that are describe in Table 5-3 will run with degraded performance.

38 007-5688-003

Mixing Processors and DIMM Speeds

The Nehalem-EP processor is rated for the maximum DIMM speed that it will support. Configuring memory DIMMs that have a DIMM speed that is greater than the processors capability to support will result in the memory DIMM running at the maximum speed of the processor - not the maximum speed of the DIMM. See the following table:

Installing Memory

Processor Memory DIMM

1066 MT/s capable CPUs:

LSX-CPU-L5520 LSX-CPU-E5520

LSX-MEM-2G-1066 LSX-MEM-4G-1066

LSX-MEM-8G-1066 LSX-CPU-E5530 LSX-CPU-E5540

1066 MT/s capable CPUs:

LSX-CPU-L5520 LSX-CPU-E5520

LSX-MEM-2G-1333

LSX-MEM-4G-1333

LSX-MEM-8G-1333 LSX-CPU-E5530 LSX-CPU-E5540

1333 MT/s capable CPUs:

LSX-CPU-L5550 LSX-CPU-E5560

LSX-MEM-2G-1066

LSX-MEM-4G-1066

LSX-MEM-8G-1066 LSX-CPU-E5570

1333 MT/s capable CPUs:

LSX-CPU-L5550 LSX-CPU-E5560

LSX-MEM-2G-1333

LSX-MEM-4G-1333

LSX-MEM-8G-1333 LSX-CPU-E5570

Three conditions must be met to have a memory speed of 1333 MT/s:

• The processor must be capable of supporting 1333 MT/2

Actual Memory

DIMM Speed

1066 MT/s

(Based on 1 or 2 DIMMs

per channel)

1066 MT/s

(Based on 1 or 2 DIMMs

per channel)

1066 MT/s

(Based on 1 or 2 DIMMs

per channel)

1333 MT/s

(Based on 1 DIMM per

channel)

• The DIMM must be capable of running at 1333 MT/s

• Only one DIMM is placed on each channel.

Placing three DIMMs on the channel will cause the DIMMs to run at 800 MT/s.

007-5688-003 39

5: Advanced Severboard Setup

Table 5-2 Recommended Memory DIMM Configurations

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1C: 2GB 2C: 2GB 3C: 2GB 1C: 2GB 2C: 2GB 3C: 2GB

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

3

Memory/

Core

1.5 GB/core 12 GB 1333

3 GB/core 24 GB 1066

3 GB/core 24 GB 1333

4.5 GB/core 36 GB 800

6 GB/core 48 GB 1066

6 GB/core 48 GB 1333

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: 4GB 2C: 4GB 3C: 4GB 1C: 4GB 2C: 4GB 3C: 4GB

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

40 007-5688-003

9 GB/core 72 GB 800

12 GB/core 96 GB 1066

Table 5-2 Recommended Memory DIMM Configurations (continued)

Installing Memory

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: 8GB 2C: 8GB 3C: 8GB 1C: 8GB 2C: 8GB 3C: 8GB

3

Memory/

Core

18 GB/core 144 GB 800

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

007-5688-003 41

5: Advanced Severboard Setup

Table 5-2 Recommended Memory DIMM Configurations (continued)

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: 4GB 2C: 4GB 3C: 4GB 1C: 4GB 2C: 4GB 3C: 4GB

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: 4GB 2C: 4GB 3C: 4GB 1C: 4GB 2C: 4GB 3C: 4GB

3

The chart above shows the memory DIMM configurations for the optimum memory performance.

Note: The minimum compute blade memory size is 4GB. The minimum compute memory size is 8GB if the compute blade is in s system running Scali Manage software.

Memory/

Core

9 GB/core 72 GB 1066

12 GB/core 96 GB 800

15 GB/core 120 GB 800

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

42 007-5688-003

Table 5-3 Non-Optimal Memory DIMM Configurations

Installing Memory

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 2GB 2A: none 3A: none 1A: 2GB 2A: none 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: none 1A: 2GB 2A: 2GB 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: none 3B: none 1B: 2GB 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: 2GB 3B: none 1B: 2GB 2B: 2GB 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1C: 2GB 2C: none 3C: none 1C: 2GB 2C: none 3C: none

1A: 2GB 2A: 2GB 3A: 2GB 1A: 2GB 2A: 2GB 3A: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1B: 2GB 2B: 2GB 3B: 2GB 1C: 2GB 2C: 2GB 3C: none 1C: 2GB 2C: 2GB 3C: none

3

Memory/

Core

0.5 GB/core 4 GB 1333

1 GB/core 8 GB 1333

2 GB/core 16 GB 1066

2.5 GB/core 20 GB 1066

3.5 GB/core 28 GB 800

4 GB/core 32 GB 800

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

1A: 4GB 2A: none 3A: none 1A: 4GB 2A: none 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 4GB 2A: 4GB 3A: none 1A: 4GB 2A: 4GB 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

007-5688-003 43

1 GB/core 8 GB 1333

2 GB/core 16 GB 1333

5: Advanced Severboard Setup

Table 5-3 Non-Optimal Memory DIMM Configurations (continued)

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: none 3B: none 1B: 4GB 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: 4GB 3B: none 1B: 4GB 2B: 4GB 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: 4GB 2C: none 3C: none 1C: 4GB 2C: none 3C: none

1A: 4GB 2A: 4GB 3A: 4GB 1A: 4GB 2A: 4GB 3A: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1B: 4GB 2B: 4GB 3B: 4GB 1C: 4GB 2C: 4GB 3C: none 1C: 4GB 2C: 4GB 3C: none

1A: 8GB 2A: none 3A: none 1A: 8GB 2A: none 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 8GB 2A: 8GB 3A: none 1A: 8GB 2A: 8GB 3A: none 1B: none 2B: none 3B: none 1B: none 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

3

Memory/

Core

4 GB/core 32 GB 1066

5 GB/core 40 GB 1066

7 GB/core 56 GB 800

8 GB/core 64 GB 800

2 GB/core 16 GB 1333

4 GB/core 32 GB 1333

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: none 3B: none 1B: 8GB 2B: none 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: none 1B: 8GB 2B: 8GB 3B: none 1C: none 2C: none 3C: none 1C: none 2C: none 3C: none

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: 8GB 2C: none 3C: none 1C: 8GB 2C: none 3C: none

44 007-5688-003

8 GB/core 64 GB 1066

10 GB/core 80 GB 1066

14 GB/core 112 GB 800

Hard Disk Drives (SGI Rackable C2108-TY10 Chassis)

Table 5-3 Non-Optimal Memory DIMM Configurations (continued)

Processor 1 Processor 2

Channel 1Channel 2Channel 3Channel 1Channel 2Channel

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: 8GB 2C: 8GB 3C: none 1C: 8GB 2C: 8GB 3C: none

1A: 8GB 2A: 8GB 3A: 8GB 1A: 8GB 2A: 8GB 3A: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1B: 8GB 2B: 8GB 3B: 8GB 1C: 8GB 2C: 8GB 3C: 8GB 1C: 8GB 2C: 8GB 3C: 8GB

3

Memory/

Core

16 GB/core 128 GB 800

18 GB/core 144 GB 800

Hard Disk Drives (SGI Rackable C2108-TY10 Chassis)

The 2U chassis supports a maximum of eight SAS or SATA disk drives. Install the drives from left to right. Note: All disk drive bays must be populated to maintain system thermals. Drive bays must either have a disk drive or a drive blank installed.

COMPACT

Drive 4 Drive 5 Drive 6 Drive 7 Drive 0 Drive 1 Drive 2 Drive 3

Total Node

Memory

Size

Maximum

Mem

Speed

(MT/s)

RESET

Figure 5-9 SGI Rackable C2108-TY10 Disk Drive Locations

The supported disk drive configurations are as follows:

• LSX-CONFIG-JBOD JBOD, supports any number of drives between one and eight. The operating system is placed on the disk drive in location 0. All other drives are data drives.

• LSX-CONFIG-RAID0 Disk striping without parity, supports any number of drives between two and eight. Note: all drives must be the same type. The operating system will be striped across all drives in the system. This configuration is not recommended.

007-5688-003 45

5: Advanced Severboard Setup

• RAID1 Disk mirroring, supports exactly two drives. The two drives represents one RAID1 logical drive. The operating system will be installed on the drives located in Drive 0 and 1. Note: Both drives must be the same type.

• RAID5 Disk striping with parity, supports a minimum of three drives and a maximum of eight drives. Possible configurations are 2+1, 3+1, 4+1, 5+1, 6+1 and 7+1. The operating system will be striped across all drives in the system. Note: all drives must be the same type

• RAID6 Disk striping with dual parity, supports a minimum of four drives and a maximum of eight drives. The operating system will be striped across all drives in the system. Note: all drives must be the same type

• RAID10 Mirrored disk striping, the data is striped across one set of drives and then mirrored on another set of drives. A minimum of four drives of the same type are required.The total number of drives must be an even number (4, 6, 8). A total of four drives is a 2+2, six drives is a 3+3, and eight drives is a 4+4. The operating system will be striped across all drives in the primary set and then mirrored on the secondary set of drives. Note: all drives must be the same type

PCI Card Slotting

There are three basic configurations of the SGI Rackable C2108-TY10:

• No RAID card installed

• L8i RAID card installed

• H8iR RAID card installed

The available PCI slots for the above three configurations are as follows::

• Configuration 1: (three PCIe and 3 PCI-X slots open)

• Configurations 2 and 3: (three PCIe and 2 PCI-X slots open -slot 1 is blocked)

Note: PCI-X slot 1 is blocked when configurations 2 and 3 are used.

46 007-5688-003

Hard Disk Drives (SGI Rackable C2108-TY10 Chassis)

PCIe x8

PCIe x4

PCIe x8

PCI-X

UIO

Slot 6 5 4 3 2 1 0

Figure 5-10 Base PCI card configuration

For consistency use the following configuration rules for slotting optional PCI cards:

• PCIe InfiniBand card - use either slot 4 or slot 6

• PCI-X GigE card - use either slot 2 or slot 3

The SGI Rackable C2108-TY10 PCI slots are configured as follows:

• Slot 0 - UIO

• Slot 1 – PCI-X 133 MHz (this slot will be blocked when a either the L8i or H8iR RAID card

is installed in the UIO slot.)

• Slot 2 – PCI-X 133 MHz (slot 2 shares the PCI-X bus with slot 1)

• Slot 3 – PCI-X 133 MHz

• Slot 4 – PCIe x8 Gen2

• Slot 5 – PCIe x4 Gen1

• Slot 6– PCIe x8 Gen2

Note: Both the L8i and H8iR RAID cards use the UIO slot.

Installing Selected PCI cards

PCIe Transfer Rates

PCIe Gen1 supports the following maximum bandwidths per slot:

• Gen1 PCIe runs at 2.5 GT/s (GT/s = GigaTransfers per second)

• Supports a maximum of 250 MB/s/lane

• X4 = 1GB/s maximum transfer rate in each direction

007-5688-003 47

5: Advanced Severboard Setup

• X8 = 2GB/s maximum transfer rate in each direction

PCIe Gen2 supports the following maximum bandwidths per slot:

• Gen2 PCIe runs at 5.0 GT/s (GT/s = GigaTransfers per second)

• Supports a maximum of 500 MB/s/lane

• X4 = 2GB/s maximum transfer rate in each direction

• X8 = 4GB/s maximum transfer rate in each direction

Installing PCI-X cards

There are three PCI-X slots: slots 1 and 2 share a single bus, slot 3 has a dedicated bus. The maximum bandwidth, if both slots 1 and 2 are filled, is 1024 MB/s for both slots combined.

If either of the RAID options are selected, then slot 1 will not be available. The remaining two PCI-X slots are equal. For consistency, fill slot 2 first.

If the RAID options are not selected, then all three PCI-X slots will be available. Slot 3 will each support 1024 MB/s, but slots 1 and 2 share a single bus and therefore the total bandwidth available to both slots is 1024 MB/s. When slotting PCI-X card, make sure to place the highest bandwidth card in slot 3.

Installing PCIe cards

Use the following guidelines:

• Install Gen2 PCI cards in slots 4 and 6. Fill slot 4 first then slot 6.

• Install Gen 1 PCI cards in slot 5.

Power Supply

The default configuration is a single 720 watt power supply. The single power supply is slotted in the top power bay slot. A second (redundant) 720 watt power supply can be added to the server in the lower slot.

A dummy power supply must be installed in the lower power bay when the server is configured with a single power supply.

48 007-5688-003

Chapter 6

6. Advanced Chassis Setup

This chapter covers the steps required to install components and perform maintenance on the SGI Rackable C2108-TY10 chassis shown in Figure 6-1. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

Tools Required: The only tool you will need to install compo nents and perform maintenance is a Philips screwdriver.

007-5688-003 49

6: Advanced Chassis Setup

n er

PCI expansion slots

Dedicated

Power

supplies

Mouse

Keyboard

USB ports

COM

port 1

BMC port

VGA

port

Ethernet

ports

USB

ports

COMPACT

Slim DVD-ROM

drive

COM

port 2

System

LEDs

System

reset

21

Mai

pow

RESET

Figure 6-1 Front and Rear Chassis Views

50 007-5688-003

Static-Sensitive Device

Electrostatic discharge (ESD) can damage electronic components. To prevent damage to any printed circuit boards (PCBs), it is important to handle them very carefully. The following measures are generally sufficient to protect your equipment from ESD damage.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing any board from its antistatic bag.

• Handle a board by its edges only; do not touch its components, peripheral chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the serverboard, add-on cards and peripherals back into their antistatic bags when not in use.

Static-Sensitive Device

• For grounding purposes, make sure your computer chassis provides excellent conductivity between the power supply, the case, the mounting fasteners and the serverboard.

Unpacking

The serverboard is shipped in antistatic packaging to avoid static damage. When unpacking the board, make sure the person handling it is static protected.

Control Panel

The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications. A ribbon cable has bundled these wires together to simplify the connection. Connect the cable from JF1 on the serverboard to the Control Panel PCB (printed circuit board). Make sure the red wire plugs into pin 1 on both connectors. Pull all excess cabling out of the airflow path. The LEDs inform you of system status. See Chapter 3 for details on the LEDs and the control panel buttons. Details on JF1 can be found in Chapter 5.

007-5688-003 51

6: Advanced Chassis Setup

System Fans

Three 8-cm hot-swap fans provide the cooling for the system. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components. See Figure 6-2.

Figure 6-2 Removing System Cooling Fans

System Fan Failure

Fan speed is controlled by system temperature via a BIOS setting. If a fan fails, the remaining fans will ramp up to full speed and the overheat/fan fail LED on the control panel will turn on. Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan). Remove the top chassis cover while the system is still running to determine which of the fans has failed.

52 007-5688-003

Replacing System Fans

This section describes how to remove or install a system fan.

Removing a Fan

1. Remove the chassis cover.

2. Press the tabs on the sides of the fan to unlock and remove the fan and its housing. The fan's

3. System power does not need to be shut down since the fans are hot-pluggable.

Installing a New Fan

1. Replace the failed fan with an identical 8-cm, 12 volt fan.

2. Position the new fan into the space vacated by the failed fan previously removed. A "click"

3. If the system power is on, the hot-plug feature will cause the fan to start immediately upon

Drive Bay Installation/Removal

power connections will automatically detach.

can be heard when the fan is fully installed in place and the power connections are made.

being connected to its header on the serverboard.

Drive Bay Installation/Removal

This section describes drive bay installation and removal.

Accessing the Drive Bays

SATA Drives: You do not need to access the inside of the chassis or remove power to replace or swap SATA drives. Proceed to the next step for instructions.

Note: You must use standard 1" high, SATA drives in the system.

DVD-ROM Drive: For installing/removing the DVD-ROM disk drive, you will need to gain access to the inside of the server by removing the top cover of the chassis. Proceed to the "DVD-ROM Drive Installation" section later in this chapter for instructions.

007-5688-003 53

6: Advanced Chassis Setup

SATA Drive Inst allation

The SATA drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the drives. For this reason, even empty carriers without hard drives installed must remain in the chassis.

Mounting a SATA Drive in a Drive Carrier

1. T o add a new SATA drive, install the drive into the carrier with the printed circuit board side facing down so that the mounting holes align with those in the carrier.

2. Secure the drive to the carrier with four screws, as shown in Figure 6-3.

Figure 6-3 Mounting a SATA Drive in a Carrier

Installing/Removing Hot-swap SATA Drives

1. Push the release button located beside the drive's LEDs.

2. Swing the handle fully out and use it to pull the drive carrier straight out (see Figure 6-4).

54 007-5688-003

H

andle

Drive Bay Installation/Removal

Release button

Figure 6-4 Removing SATA Drive Carrier

Note: Your operating system must have RAID support to enable the hot-plug capability of the drives.

!

007-5688-003 55

Important: Regardless of how many hard drives are installed, all drive carriers must remain in the drive bays to maintain proper airflow.

Caution: Use caution when working around the SATA backplane. Do not touch the backplane with any metal objects and make sure no ribbon cables touch the backplane or obstruct the holes, which aid in proper airflow.

6: Advanced Chassis Setup

Hard Drive Backplane

The hard drives plug into a backplane that provides power, drive ID and bus termination. A RAID controller can be used with the backplane to provide data security. The operating system you use must have RAID support to enable the hot-swap capability of the hard drives. The backplane is already preconfigured, so no jumper or switch configurations are required.

DVD-ROM Drive Installation

The top cover of the chassis must be opened to gain full access to the DVD-ROM drive bays. The SGI Rackable C2108-TY10 system accomodates only slim type DVD-ROM drives. Side mounting brackets are typically needed to mount a slim DVD-ROM drive in the server.

Accessing the Inside of the Chassis

1. Grasp the two handles on either side and pull the unit straight out until it locks (you will hear a "click").

2. Next, depress the two buttons on the top of the chassis to release the top cover and at the same time, push the cover away from you until it stops. You can then lift the top cover from the chassis to gain full access to the inside of the server.

Note: You must power down the system before installing or removing IDE components.

Drives mount on rails and should "click" into place to be correctly and fully installed in their bays.

Power Supply

The SGI Rackable C2108-TY10 system has a 720 watt redundant power supply consisting of two power modules. Each power supply module has an auto-switching capability, which enables it to automatically sense and operate at a 100V - 240V input voltage.

56 007-5688-003

Power Supply Failure

If either of the two power supply modules fail, the other module will take the full load and allow the system to continue operation without interruption. The PWR Fail LED will illuminat e and remain on until the failed unit has been replaced. The power supply units have a hot-swap capability, meaning you can replace the failed unit without powering down the system.

Removing/Replacing the Power Supply

Y ou do not need to shut down the system to replace a power supply unit. The backup power supply module will keep the system up and running while you replace the failed hot-swap unit. Replace with the same model.

Removing the Power Supply

1. First unplug the AC power cord from the failed power supply module.

2. Depress the locking tab on the power supply module.

3. Use the handle to pull it straight out with the rounded handle.

Power Supply

Installing a New Power Supply

1. Replace the failed hot-swap unit with another identical power supply unit.

2. Push the new power supply unit into the power bay until you hear a click.

3. Secure the locking tab on the unit.

4. Finish by plugging the AC power cord back into the unit.

007-5688-003 57

Chapter 7

7. BIOS

This chapter describes the AMI BIOS Setup Utility for the SGI Rackable C2108-TY10 severboard. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

Starting BIOS Setup Utility

T o enter the AMI BIOS Setup Utility screens, press the <Delete> key while the system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS setup screen. There are a few cases when other keys are used, such as <F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured. Grayed-out options cannot be configured. Options in blue can be configured by the user. The right frame displays the key legend. Above the key legend is an area reserved for a text message. When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it.

Note: The AMI BIOS has default text messages built in. These text messages my be included, omitted, or changed across BIOS releases.

The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys". Most of the AMI BIOS setup utility "hot keys" can be used at any time during the setup navigation process. These keys include <F1>, <F10>, <Enter>, <ESC>, arrow keys, etc.

007-5688-003 59

7: BIOS

Note: Options printed in Bold are default settings.

How To Change the Configuration Data

The configuration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <Del> at the appropriate time during system boot.

Starting the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens. An AMI BIOS identification string is displayed at the left bottom corner of the screen below the copyright message.

!

Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have t o upd ate the BIOS, do not shut down or reset the system while the BIOS is updating. This is to avoid possible boot failure.

Main Setup

When you first enter the AMI BIOS Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS Setup screen is shown in Figure 7-1.

60 007-5688-003

Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue.

Main Setup

Figure 7-1 System Overview Main BIOS Setup Screen

System Time/System Update

Use this option to change the system time and date. Highlight System Time or System. Date using the arrow keys. Key in new values through the keyboard and press <Enter>. Press the <Tab> key to move between fields. The date must be entered in Day MM/DD/YY format. The time is entered in HH:MM:SS format.

Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.

Serverboard

• BIOS Build Version: This item displays the BIOS revision used in your system.

007-5688-003 61

7: BIOS

Processor

• BIOS Build Date: This item displays the date when this BIOS was completed.

• AMI BIOS Core Version: This item displays the revision number of the AMI BIOS Core upon which your BIOS was built.

The AMI BIOS will automatically display the status of the processor used in your system:

• CPU Type: This item displays the type of CPU used in the motherboard.

• Speed: This item displays the speed of the CPU detected by the BIOS.

• Physical Count: This item displays the number of processors installed in your system as detected by the BIOS.

• Logical Count: This item displays the number of CPU Cores installed in your system as detected by the BIOS.

• Micro_code Revision: This item displays the revision number of the BIOS Micro_code used in your system.

System Memory

This displays the size of memory available in the system:

• Size: This item displays the memory size detected by the BIOS

Advanced Setup Configurations

Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items shown in

Figure 7-2.

62 007-5688-003

Advanced Setup Configurations

Figure 7-2 Advanced Settings Screen

Boot Features

This section describes the Boot Features options.

Quick Boot

If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot. The options are Enabled and Disabled.

Note: The default option is highlighted in bold face throughout this chapter.

007-5688-003 63

7: BIOS

Quiet Boot

AddOn ROM Display Mode

Bootup Num-Lock

Wait For 'F1' If Error

Hit 'Del' Message Display

This option allows the bootup screen options to be modified between POST messages or the OEM logo. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages. The options are Enabled and Disabled.

This sets the display mode for Option ROM. The options are Force BIOS and Keep Current.

This feature selects the Power-on state for Numlock key. The options are Off and On.

This forces the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.

This feature displays "Press DEL to run Setup" during POST. The options are Enabled and Disabled.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at boot and allow the drives that are attached to these host adaptors to function as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adaptors will not capture Interrupt 19, and the drives attached to these adaptors will not function as bootable devices. The options are Enabled and Disabled.

Power Configuration

This section describes power configuration options.

64 007-5688-003

Power Button Function

If set to Instant_Off, the system will power off immediately as soon as the user hits the power button. If set to 4_Second_Override, the system will power off when the user presses the power button for 4 seconds or longer. The options are Instant_Off and 4_Second_Override.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Power-Off for the system power to remain off after a power loss. Select Power-On for the system power to be turned on after a power loss. Select Last State to allow the system to resume its last state before a power loss. The options are Power-On, Power-Off and Last State.

Watch Dog Tim er

If enabled, the W atch Dog T imer will allow the system to reboot when it is inactive for more than 5 minutes. The options are Enabled and Disabled.

Processor and Clock Options

Advanced Setup Configurations

This submenu allows the user to configure the Processor and Clock settings.

Ratio CMOS Setting

This option allows the user to set the ratio between the CPU Core Clock and the FSB Frequency.

Note: If an invalid ratio is entered, the AMI BIOS will restore the setting to the previous state.

The default setting depends on the type of CPU installed on the motherboard. The default setting for the CPU installed in your motherboard is [21]. Press "+" or "-" on your keyboard to change this value.

C1E Support

Select Enabled to use the feature of Enhanced Halt State. C1E signifi cantly reduces the CPU's power consumption by reducing the CPU's clock cycle and voltage during a "Halt State." The options are Disabled and Enabled.

007-5688-003 65

7: BIOS

Hardware Prefetcher (Available when supported by the CPU)

If set to Enabled, the hardware prefetcher will pre fetch streams of data and instructions from the main memory to the L2 cache in the forward or backward manner to improve CPU performance. The options are Disabled and Enabled.

Adjacent Cache Line Prefetch (Available when supported by the CPU)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The CPU fetches both cache lines for 128 bytes as comprised if Enabled.

Intel Virtualization Technology (Available when supported by the CPU)

Select Enabled to use the feature of Virtualization Technology to allow one platform to run multiple operating systems and applications in independent partitions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and restart the system for the change to take effect. Please refer to Intel’s web site for detailed information.

Execute-Disable Bit Capability (Available when supported by the OS and the CPU)

Set to Enabled to enable the Execute Disable Bit which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from flooding illegal codes to overwhelm the processor or damage th e system during an attack. The default is Enabled. (Refer to Intel and Microsoft Web Sites for more information.)

Simultaneous Multi-Threading (Available when supported by the CPU)

Set to Enabled to use the Simultaneous Multi-Threading Technology, which will result in increased CPU performance. The options are Disabled and Enabled.

Active Processor Cores

Set to Enabled to use a processor's Second Core and beyond. (Please refer to Intel's web site for more information.) The options are All, 1 and 2.

66 007-5688-003

Intel EIST Technology

Enhanced Intel SpeedStep T echnology (EIST) allows the system to automatically adjust processor voltage and core frequency in an effort to reduce power consumption and heat dissipation. Please refer to Intel’s web site for detailed information. The options are Disable (Disable GV3) and Enable (Enable GV3).

Intel TurboMode Technology (Available when Intel EIST Technology is enabled)

Select Enabled to use the Turbo Mode to boost system performance. The options are Enabled and Disabled.

Intel C-STATE Tech

If enabled, C-State is set by the system automatically to either C2, C3 or C4 state. The options are Disabled and Enabled.

C-State package limit setting (Available when Intel® C-State Tech is enabled)

If set to Auto, the AMI BIOS will automatically set the limit on the C-State package register. The options are Auto, C1, C3, C6 and C7.

Advanced Setup Configurations

C1 Auto Demotion

When enabled, the CPU will conditionally demote C3, C6 or C7 requests to C1 based on un-core auto-demote information. The options are Disabled and Enabled.

C3 Auto Demotion

When enabled, the CPU will conditionally demote C6 or C7 requests to C3 based on un-core auto-demote information. The options are Disabled and Enabled.

Clock Spread Spectrum

Select Enable to use the feature of Clock Spectrum, which will allow the BIOS to monitor and attempt to reduce the level of Electromagnetic Interference caused by the components whenever needed. The options are Disabled and Enabled.

007-5688-003 67

7: BIOS

Advanced Chipset Control

The items included in the Advanced Settings submenu are listed below:

CPU Bridge Configuration

QPI Links Speed

This feature selects QPI's data transfer speed. The options are Slow-mode, and Full Speed.

QPI Frequency

This selects the desired QPI frequency. The options are Auto, 4.800 GT, 5.866GT, 6.400 GT.

QPI L0s and L1

This enables the QPI power state to low power. L0s and L1 are automatically selected by the motherboard. The options are Disabled and Enabled.

Memory Frequency

This feature forces a DDR3 frequency slower than what the system has detected. The available options are Auto, Force DDR-800, Force DDR-1066, and Force DDR-1333.

Memory Mode

The options are Independent, Channel Mirror, Lockstep and Sparing.

Independent - All DIMMs are available to the operating system.

Channel Mirror - The motherboard maintains two identical copies of all data in memory for redundancy.

Lockstep - The motherboard uses two areas of memory to run the same set of operations in parallel.

Sparing - A preset threshold of correctable errors is used to trigger fail-over. The spare memory is put online and used as active memory in place of the failed memory.

Demand Scrubbing

68 007-5688-003

Advanced Setup Configurations

A memory error-correction scheme where the Processor writes corrected data back into the memory block from where it was read by the Processor. The options are Enabled and Disabled.

Patrol Scrubbing

A memory error-correction scheme that works in the background looking for and correcting resident errors. The options are Enabled and Disabled.

Memory ECC Error Threshold

This feature allows the user to set the correctable memory ECC error limit for AMI BIOS to handle it. The Default setting is 255.

Throttling - Closed Loop/Throttling - Open Loop

Throttling improves reliability and reduces power in the processor by automatic voltag e control during processor idle states. Available options are Disabled and Enabled. If Enabled, the following items will appear:

Hysteresis Temperature (Available for Closed Loop only) Temperature Hysteresis is the temperature lag (in degrees Celsius) after the set DIMM

temperature threshold is reached before Closed Loop Throttling begins. The options are Disabled, 1.5oC, 3.0oC, and 6.0oC.

Guardband Temperature (Available for Closed Loop only)

This is the temperature which applies to the DIMM temperature threshold. Each step is in 0.5oC increment. The default is [006]. Press "+" or "-" on your keyboard to change this value.

Inlet Temperatu re

This is the temperature detected at the chassis inlet. Each step is in 0.5oC increment. The default is [070]. Press "+" or "-" on your keyboard to change this value.

Temperature Rise

This is the temperature rise to the DIMM thermal zone. Each step is in 0.5oC increment. The default is [020]. Press "+" or "-" on your keyboard to change this value.

Air Flow

007-5688-003 69

7: BIOS

This is the air flow speed to the DIMM modules. Each step is one mm/ sec. The default is [1500]. Press "+" or "-" on your keyboard to change this value.

Altitude

This feature defines how many meters above or below sea level the system is located. The options are Sea Level or Below, 1~300, 301~600, 601~900, 901~1200, 1201~1500, 1501~1800, 1801~2100, 2101~2400, 2401~2700, 2701~3000.

DIMM Pitch

This is the physical space between each DIMM module. Each step is in 1/1000 of an inch. The default is [400]. Press "+" or "-" on your keyboard to change this value.

Serial Debug Message Level

This feature allows the user to set the level of debug messages to be displayed. The options are None, MIN, MAX and Test.

North Bridge Configuration

This feature allows the user to configure the settings for the Intel North Bridge chip.

Crystal Beach/Direct Memory Access (DMA)

This feature works with the Intel I/O Acceleration T echnology (AT) to accelerate the performance of TOE devices.

Note: A TOE device is a specialized, dedicated processor that is installed on an add-on card or a network card to handle some or all packet processing of this add-on card.

When this feature is set to Enabled, it will enhance overall system performance by providing direct memory access for data transferring. The options are Enabled and Disabled.

70 007-5688-003

Crystal Beach/ Direct Cache Access (DCA)

This feature is available when Crystal Beach/DMA is enabled.This feature works in conjunction with the Intel I/O AT to accelerate the performance of the TOE device. When this feature set to Enabled, it will enhance overall system performance by providing direct cache access for data transferring. The options are Enabled and Disabled.

Intel VT-d

Select Enabled to enable Intel's Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to VMM through the DMAR ACPI Tables.

This feature offers fully-protected I/O resource-sharing across the Intel platforms, providing the user with greater reliability, security and availability in networking and data-sharing. The settings are Enabled and Disabled.

SouthBridge Configuration

This feature allows the user to configure the settings for the Intel ICH South Bridge chipset.

Advanced Setup Configurations

USB Functions

This feature allows the user to decide the number of onboard USB ports to be enabled. The Options are: Disabled, 2 USB ports, 4 USB ports, 6 USB ports, 8 Ports, 10 Ports and 12 USB ports.

Legacy USB Support

Select Enabled to use Legacy USB devices. If this item is set to Auto, Legacy USB support will be automatically enabled if a legacy USB device is installed on the motherboard, and vise versa. The settings are Disabled, Enabled and Auto.

USB 2.0 Controller

This item indicated if the USB 2.0 controller is activated. The options are Enabled and Disabled.

007-5688-003 71

7: BIOS

USB 2.0 Controller Mode

This setting allows you to select the USB 2.0 Controller mode. The options are Hi-Speed (480 Mbps) and Full Speed (12 Mbps).

BIOS EHCI Hand-Off

Select Enabled to enable BIOS Enhanced Host Controller Interface support to provide a workaround solution for an operating system that does not have EHCI Hand-Off support. When enabled, the EHCI Interface will be changed from the BIOS-controlled to the OS-controlled. The options are Disabled and Enabled.

Intel PCI-X Hub Configuration

PCI Bus A0/B0 Frequency

This option allows the user to set the maximum PCI speed to be used in the PCI slot specified. Select Auto to allow the BIOS to automatically detect the capability of the device installed on the bus. The options are Auto, 33 MHz PCI, 66 MHz PCI, 66 MHz PCI-X MI, 100 MHz PCI-X MI, and 133 MHz PCI-X MI.

I/O Port Decode

This option allows the user to select the decode range for the I/O connections. The options are 4K Decode and 1K Decode.

RAS Sticky Error Handling

This option allows the user to decide how to handle Sticky RAS errors. The options are Clear Errors and Leave Errors (unchanged).

VGA 16-Bit Decode

Select Enabled to enable the function of decoding VGA for the devices installed behind the PXH PCI Controller Hub. The options are Enabled and Disabled.

72 007-5688-003

IDE and SATA Configuration

When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE devices and displays the following items:

SATA#1 Configuration

If Compatible is selected, it sets SA TA#1 to legacy compatibility mode, while selecting Enhanced sets SATA#1 to native SATA mode. The options are Disab led, Compatible, and Enhanced.

Configure SATA#1 as

This feature allows the user to select the drive type for SATA#1. The options are IDE, RAID and AHCI. (When the option-RAID is selected, the item-ICH RAID Code Base will appear. When the option-AHCI is selected, the item-SATA AHCI will be available.)

ICH RAID Code Base (This feature is available when the option-RAID is selected)

Select Intel to enable Intel's SATA RAID firmware to configure Intel's SATA RAID settings. Select Adaptec to enable Adaptec's SATA RAID firmware to configure Adaptec' s SATA RAID settings. The options are Intel and Adaptec.

Advanced Setup Configurations

SATA AHCI (This feature is available when the option-AHCI is selected)

Select Enable to enable the function of Serial ATA Advanced Host Interf ace. (Take caution when using this function. This feature is for advanced programmers only.) The options are Enabled and Disabled. If the option-Enabled is selected, the following item will display.

SATA#2 Configuration (This feature is available when the option-IDE is selected)

Selecting Enhanced will set SATA#2 to native SATA mode. The options are Disabled, and Enhanced.

Primary IDE Settings

Primary IDE Master/Slave, Secondary IDE Master/Slave, Third IDE Master, and Fourth IDE Master

These settings allow the user to set the parameters of Primary IDE Master/Slave, Secondary IDE Master/Slave, Third and Fourth IDE Master slots. Hit <Enter> to activate the following

007-5688-003 73

7: BIOS

submenu screen for detailed options of these items. Set the correct configurations accordingly. The items included in the submenu are:

Type

Select the type of device connected to the system. The options are Not Installed, Auto, CD/DVD and ARMD.

LBA/Large Mode

LBA (Logical Block Addressing) is a method of addressing data on a disk drive. In the LBA mode, the maximum drive capacity is 137 GB. For drive capacities over 137 GB, your system must be equipped with a 48-bit LBA mode addressing. If not, contact your manufacturer or install an A TA/133 IDE controller card that supports 48-bit LBA mode. The options are Disabled and Auto.

Block (Multi-Sector Transfer)

Block Mode boosts the IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if Block Mode is not used. Block Mode allows transfers of up to 64 KB per interrupt. Select Disabled to allow data to be transferred from and to the device one sector at a time. Select Auto to allow data transfer from and to the device occur multiple sectors at a time if the device supports it. The options are Auto and Disabled.

PIO Mode

The IDE PIO (Programmable I/O) Mode programs timing cycles between the IDE drive and the programmable IDE controller. As the PIO mode increas es, the cycle time decreases. The options are Auto, 0, 1, 2, 3, and 4.

Select Auto to allow the AMI BIOS to automatically detect the PIO mode. Use this value if the IDE disk drive support cannot be determined.

Select 0 to allow the AMI BIOS to use PIO mode 0. It has a data transfer rate of 3.3 MBs.

Select 1 to allow the AMI BIOS to use PIO mode 1. It has a data transfer rate of 5.2 MBs.

Select 2 to allow the AMI BIOS to use PIO mode 2. It has a data transfer rate of 8.3 MBs.

Select 3 to allow the AMI BIOS to use PIO mode 3. It has a data transfer rate of 11.1 MBs.

Select 4 to allow the AMI BIOS to use PIO mode 4. It has a data transfer bandwidth

74 007-5688-003

Advanced Setup Configurations

of 32-Bits. Select Enabled to enable 32-Bit data transfer.

DMA Mode

Select Auto to allow the BIOS to automatically detect IDE DMA mode when the IDE disk drive support cannot be determined.

Select SWDMA0 to allow the BIOS to use Single Word DMA mode 0. It has a data transfer rate of 2.1 MBs.

Select SWDMA1 to allow the BIOS to use Single Word DMA mode 1. It has a data transfer rate of 4.2 MBs.

Select SWDMA2 to allow the BIOS to use Single Word DMA mode 2. It has a data transfer rate of 8.3 MBs.

Select MWDMA0 to allow the BIOS to use Multi Word DMA mode 0. It has a data transfer rate of 4.2 MBs.

Select MWDMA1 to allow the BIOS to use Multi Word DMA mode 1. It has a data transfer rate of 13.3 MBs.

Select MWDMA2 to allow the BIOS to use Multi-W ord DMA mode 2. It has a data transfer rate of 16.6 MBs.

Select UDMA0 to allow the BIOS to use Ultra DMA mode 0. It has a data transfer rate of 16.6 MBs. It has the same transfer rate as PIO mode 4 and Multi Word DMA mode 2.

Select UDMA1 to allow the BIOS to use Ultra DMA mode 1. It has a data transfer rate of 25 MBs.

Select UDMA2 to allow the BIOS to use Ultra DMA mode 2. It has a data transfer rate of 33.3 MBs.

Select UDMA3 to allow the BIOS to use Ultra DMA mode 3. It has a data transfer rate of 66.6 MBs.

Select UDMA4 to allow the BIOS to use Ultra DMA mode 4. It has a data transfer rate of 100 MBs.

Select UDMA5 to allow the BIOS to use Ultra DMA mode 5. It has a data transfer rate of 133 MBs.

007-5688-003 75

7: BIOS

Hot Plug

Select UDMA6 to allow the BIOS to use Ultra DMA mode 6. It has a data transfer rate of 133 MBs. The options are Auto, SWDMAn, MWDMAn, and UDMAn.

S.M.A.R.T. For Hard disk drives

Self-Monitoring Analysis and Reporting Technology (SMAR T) can help predict impending drive failures. Select Auto to allow the AMI BIOS to automatically detect hard disk drive support. Select Disabled to prevent the AMI BIOS from using the S.M.A.R.T. Select Enabled to allow the AMI BIOS to use the S.M.A.R.T. to support hard drive disk. The options are Disabled, Enabled, and Auto.

32Bit Data

Select Enable to enable the function of 32-bit IDE data transfer. The options are Enabled and Disabled.

This feature is available when the option-AHCI Under "Confiigure SATA#1 as" is selected.

Select Enable to enable the hot plug function for the SATA devices. The options are Enabled and Disabled.

IDE Detect Timeout (sec)

Use this feature to set the time-out value for the BIOS to detect the AT A, ATAPI devices installed in the system. The options are 0 (sec), 5, 10, 15, 20, 25, 30, and 35.

PCI/PnP Configuration

Clear NVRAM

This feature clears the NVRAM during system boot. The options are No and Yes.

Plug & Play OS

Selecting Yes allows the OS to configure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug & Play.) Select No to allow the AMI BIOS to configure all devices in the system.

76 007-5688-003

PCI Latency Timer

This feature sets the latency Timer of each PCI device installed on a PCI bus. Select 64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96, 128, 160, 192, 224 and 248.

PCI IDE BusMaster

When enabled, the BIOS uses PCI bus mastering for reading/writing to IDE drives. The options are Disabled and Enabled.

Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM

Select Enabled to enable the onboard LAN1 or LAN2 Option ROM. This is to boot computer using a network interface. The options are Enabled and Disabled.

Super IO Device Configuration

Serial Port1 Address/ Serial Port2 Address

Advanced Setup Configurations

This option specifies the base I/O port address and the Interrupt Request address of Serial Port 1 and Serial Port 2. Select Disabled to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port physically becomes unavailable. Select 3F8/IRQ4 to allow the serial port to use 3F8 as its I/O port address and IRQ 4 for the interrupt address. The options for Serial Port1 are Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3. The options for Serial Port2 are Disabled, 2F8/IRQ3, 3E8/IRQ4, and 2E8/IRQ3.

Remote Access Configuration

Remote Access

This allows the user to enable the Remote Access feature. The options are Disabled and Enabled.

If Remote Access is set to Enabled, the following items will display:

Serial Port Number

This feature allows the user decide which serial port to be used for Console Redirection. The options are COM 1 and COM 2.

007-5688-003 77

7: BIOS

Base Address, IRQ

This item displays the based address and IRQ of the serial port specified above. The options are

COM 1 and COM 2.

Serial Port Mode

This feature allows the user to set the serial port mode for Console Redirection. The options are

115200 8, n 1; 57600 8, n, 1; 38400 8, n, 1; 19200 8, n, 1; and 9600 8, n, 1.

Flow Control

This feature allows the user to set the flow control for Console Redirection. The options are None, Hardware, and Software.

Redirection After BIOS POST

Select Disabled to turn off Console Redirection after Power-On Self-Test (POST). Select Always to keep Console Redirection active all the time after POST.

Note: This setting may not be supported by some operating systems.

Select Boot Loader to keep Console Redirection active during POST and Boot Loader. The options are Disabled, Boot Loader, and Always.

Terminal Type

This feature allows the user to select the target terminal type for Console Redirection. The options are ANSI, VT100, and VT-UTF8.

VT-UTF8 Combo Key Support

A terminal keyboard definition that provides a way to send commands from a remote console. Available options are Enabled and Disabled.

Sredir Memory Display Delay

This feature defines the length of time in seconds to display memory information. The options are No Delay, Delay 1 Sec, Delay 2 Sec, and Delay 4 Sec.

78 007-5688-003
