Silicon Graphics F190 User Manual

Silicon Graphics®

F190 Flat Panel Display

User Guide

TCO’99

Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice
has provided you with a product developed for professional use. Your purchase has also con­tributed to reducing the burden on the environment and also to the further development of
environmentally adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established method for encourag­ing the adaptation of goods and services to the environment. The main problem, as far as
computers and other electronics equipment are concerned, is that environmentally harmful substances are used both
in the products and during the manufacturing. Since it has not been possible for the majority of electronics equipment
to be recycled in a satisfactory way, most of these potentially damaging substances sooner or later enter Nature.
There are also other characteristics of a computer, such as energy consumption levels, that are important from the
viewpoints of both the work (Internal) and natural (external) environments. Since all methods of conventional electric­ity generation have a negative effect on the environment (acidic and climate-influencing emissions, radioactive waste,
etc.), it is vital to conserve energy. Electronics equipment in offices consume an enormous amount of energy since
they are often left running continuously.

What does labelling involve?

This product meets the requirements for the TCO’99 scheme which provides for international and environmental
labelling of personal computers. The labelling scheme was developed as a joint effort by the TCO (The Swedish
Confederation of Professional Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Con­servation) and Statens Energimyndighet (The Swedish National Energy Administration).
The requirements cover a wide range of issues: environment, ergonomics, usability, emission of electrical and mag­netic fields, energy consumption and electrical and fire safety.
The environmental demands concern restrictions on the presence and use of heavy metals, brominated and chlori­nated flame retardants, CFCs (freons) and chlorinated solvents, among other things. The product must be prepared
for recycling and the manufacturer is obliged to have an environmental plan which must be adhered to in each country
where the company implements its operational policy. The energy requirements include a demand that the computer
and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more
stages. The length of time to reactivate the computer shall be reasonable for the user.
Labelled products must meet strict environmental demands, for example, in respect of the reduction of electric and
magnetic fields, physical and visual ergonomics and good usability.

Environmental Requirements

Flame retardants
Flame retardants are present in printed circuit boards, cables, wires, casings and housings. In turn, they delay the
spread of fire. Up to thirty percent of the plastic in a computer casing can consist of flame retardant substances. Most
flame retardants contain bromine or chloride and these are related to another group of environmental toxins, PCBs,
which are suspected to give rise to severe health effects, including reproductive damage in fisheating birds and
mammals, due to the bio-accumulative* processes. Flame retardants have been found in human blood and research­ers fear that disturbances in foetus development may occur.
TCO’99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants
with organically bound chlorine and bromine. Flame retardants are allowed in the printed circuit boards since no
substitutes are available.

Lead**

Lead can be found in picture tubes, display screens, solders and capacitors. Lead damages the nervous system and
in higher doses, causes lead poisoning.
TCO’99 requirement permits the inclusion of lead since no replacement has yet been developed.

Cadmium**

Cadmium is present in rechargeable batteries and in the colourgenerating layers of certain computer displays. Cad­mium damages the nervous system and is toxic in high doses.
TCO’99 requirement states that batteries, the colourgenerating layers of display screens and the electrical or elec­tronics components must not contain any cadmium.

TCO’99 - Continued

Mercury**

Mercury is sometimes found in batteries, relays and switches, Mercury damages the nervous system and is toxic in
high doses.
TCO’99 requirement states that batteries may not contain any Mercury. It also demands that no mercury is present in
any of the electrical or electronics components associated with the display unit.

CFCs (freons)

CFCs (freons) are sometimes used for washing printed circuit boards. CFCs break down ozone and thereby damage
the ozone layer in the stratosphere, causing increased reception on Earth of ultraviolet light with consequent in­creased risks of skin cancer (malignant melanoma).
The relevant TCO’99 requirement; Neither CFCs nor HCFCs may be used during the manufacturing and assembly of
the product or its packaging.
*Bio-accumulative is defined as substances which accumulate within living organisms.
**Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.
To obtain complete information on the environmental criteria document, order from:

TCO Development Unit
SE-114 94 Stockholm
SWEDEN
FAX Number: [phone]

E-mail (Internet): [e-mail]
You may also obtain current information on TCO’99 approved and labelled products by visiting their website at: http:/
/www.tcodevelopment.com/

Manufacturer’s Recycling and Energy Information

SGI is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in
trying to minimize the burden placed on the environment. We are engaged in developing environmentally-friendly
products.

For more information on SGI’s Environmental Policy and Practices, please visit our website at

http://www.sgi.com/company_info/environment/policy.html

Country-specific recycling programs can also be found at:

Sweden - http://www.el-retur.se
Germany - http://www.recyclingpartner.de/
Holland - http://www.mirec.nl/
Japan - http://www.diarcs.com/

Energy saving:

This monitor features an advanced energy saving capability. When a VESA Display Power Management Signaling
(DPMS) Standard signal is sent to the monitor, the Energy Saving mode is activated. The monitor enters a single
Energy Saving mode.

Mode

Normal Operation

Energy Saving Mode

Off Mode

Power consumption

Approx. 38W

Less than 2W

Less than 0.1W

LED color

Green

Amber

Unlit

Index

Safety Instruction .................. English-1

Warning ................................... English-1

Caution ....................................English-1

Contents .................................. English-2

Quick Start .............................. English-3

Controls................................... English-6

Recommended use ................ English-8

Specifications ..................... English-10

Features ................................ English-11

Troubleshooting ................... English-12

Sicherheitsvorkehrungen....Deutsch-1

Warnung .................................Deutsch-1

Vorsicht ..................................Deutsch-1

Inhalt .......................................Deutsch-2

Schnellstart ...........................Deutsch-3

Bedienelemente .................... Deutsch-6

Einsatzempfehlungen .......... Deutsch-9

Technische Daten ...............Deutsch-11

Merkmale und Funktionen.Deutsch-12

Fehlerbehebung ..................Deutsch-13

Instrucciones de seguridad Español-1

Advertencia ........................... Español-1

Peligro .................................... Español-1

Contenido .............................. Español-2

Inicio rápido .......................... Español-3

Controles................................ Español-6

Uso recomendado ................ Español-9

Especificaciones................. Español-11

Características .................... Español-12

Solución de problemas .......... Español-13

Consignes de sécurité ........ Français-1

Avertissement ...................... Français-1

Attention................................ Français-1

Sommaire .............................. Français-2

Démarrage rapide ................ Français-3

Commandes .......................... Français-6

Conseils d’utilisation .......... Français-9

Spécifications .................... Français-11

Caractéristiques................. Français-12

Résolution des problémes Français-13

Istruzioni di sicurezza........... Italiano-1

Avvertenza .............................. Italiano-1

Attenzione ............................... Italiano-1

Contenuto ............................... Italiano-2

Avvio veloce ........................... Italiano-3

Controlli................................... Italiano-6

Uso consigliato ...................... Italiano-9

Specifiche tecniche ............. Italiano-11

Caratteristiche...................... Italiano-12

Ricerca guasti ...................... Italiano-13

ご使用の前にご使用の前に

ご使用の前にご使用の前に

ご使用の前に

..........................................

..........................................

.....................

日本語日本語

日本語日本語

日本語

-1-1

-1-1

-1

安全のために必ず守ること安全のために必ず守ること

安全のために必ず守ること安全のために必ず守ること

安全のために必ず守ること

....

....

..

日本語日本語

日本語日本語

日本語

-2-2

-2-2

-2

各部の名称各部の名称

各部の名称各部の名称

各部の名称

................................................

................................................

........................

日本語日本語

日本語日本語

日本語

-5-5

-5-5

-5

接続接続

接続接続

接続

....................................................................

....................................................................

..................................

日本語日本語

日本語日本語

日本語

-7-7

-7-7

-7

画面調節画面調節

画面調節画面調節

画面調節

........................................................

........................................................

............................

日本語日本語

日本語日本語

日本語

-9-9

-9-9

-9

特長・機能特長・機能

特長・機能特長・機能

特長・機能

............................................

............................................

......................

日本語日本語

日本語日本語

日本語

-11-11

-11-11

-11

困ったとき困ったとき

困ったとき困ったとき

困ったとき

............................................

............................................

......................

日本語日本語

日本語日本語

日本語

-13-13

-13-13

-13

付録付録

付録付録

付録

................................................................

................................................................

................................

日本語日本語

日本語日本語

日本語

-15-15

-15-15

-15

 !KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JO

 !KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JP

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JS

 !KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JU

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNM

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNN

 !KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNO

 ! KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK ! JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK ! JO

 ! KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JP

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK ! JS

 ! KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JU

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNM

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNN

 ! KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  ! JNO

= KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JO

= KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JP

 = KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JS

== KKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JV

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JNN

 KKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKKK  JNO

== KKKKKKKKKKKKKKKKKKKKKKKKKKK  JNP

English

English-1

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of this unit
has been included. Therefore, it should be read carefully in order to avoid any problems.

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT
USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS
THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING

CAUTION

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CSA C22.2 No.60950.

FCC Information

1. Use the attached specified cables with the color display so as not to interfere with radio and television reception.
(1) Please use the supplied power cable or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

2

.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user
may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio­TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No.
004-000-00345-4.
No user serviceable parts inside. Do not attempt to modify this equipment. If modified, your authority to operate this equipment might
be voided by FCC.

Safety Instruction

RISK OF ELECTRIC SHOCK • DO NOT OPEN

ENERGY STAR® is a U.S. registered trademark. All other brands and product names are trademarks or registered trademarks of

their respective owners.
As an ENERGY STAR Partner, Silicon Graphics, Inc. has determined that this product meets the ENERGY STAR guidelines for
energy efficiency.
The ENERGY STAR emblem does not represent EPA endorsement of any product or service.
All other trademarks mentioned in this manual are the property of their respective owners.

English-2

Your new Silicon Graphics F190 Flat Panel Display box* should contain the following:

• Display with tilt base

• User’s Manual

• Video Signal Cable (DVI-D to DVI-D)

• Cable Management Cover

* Remember to save your original box and packing material to transport or ship the display.

Contents

Video Signal Cable

(DVI-D to DVI-D)

User's Manual Cable Management Cover

English

English-3

Quick Start

Figure A

Figure B

To attach the F190 Display to your system, follow these instructions:

1. Turn off the power to your computer.

2. For Workstations with DVI digital output: Connect the DVI signal cable (included) to the connector of the graphics card

in your system (Figure A). Tighten all screws.
For Workstations with Analog output: Connect the 15-pin mini D-SUB signal cable (supplied with the Workstation) to
the connector of the graphics card in your system (Figure B). Tighten all screws.

3. Connect either or the 15-pin mini D-SUB of the video signal cable and DVI signal cable to the appropriate connector

on the back of the display (Figure C).

4. Connect one end of the power cord to the F190 Display and the other end to the power outlet.

Collect cables and keep them at backside of the stand and cover the cables by the optional Cable management
Cover (Figure C).
Please check Tilt, Rise and Lower monitor screen when you manage cables.

5. The vacation switch on the left side of the display must be turned on (Figure D). Turn on the display with the front

power button and the computer.

Note: The vacation switch is a true on/off switch. If this switch is on the OFF position, the display cannot be

turned on using the front button. DO NOT switch on/off repeatedly.

6. Analog input only: No-Touch Auto Adjust automatically adjusts the display to optimal settings upon initial setup for

most timings. For further adjustments, use the following OSD controls:

•Auto Adjust Contrast

•Auto Adjust
Refer to the Controls section of this User’s Manual for a full description of these OSD controls.

Note: If you have any problems, please refer to the Troubleshooting section of this User’s Manual.

D-Sub Connector

5

10

1

6

11

15

DVI Connector

English-4

Quick Start - Continued

Figure RL 1

Vacation Switch

Power Button

Figure D

Raise and Lower Monitor Screen

The monitor may be raised or lowered. To raise or lower screen, place hands on each side of the monitor and lift or lower to
the desired height (Figure RL 1).

Figure C

INPUT1 INPUT2

Note: Handle with care when raising or lowering the monitor screen.

English

English-5

Quick Start - Continued

Tilt and swivel
Grasp both sides of the display screen with your hands and adjust the tilt and swivel as desired (Figure E).

Remove Display Stand for Mounting

To prepare the monitor for alternate mounting purposes:

1. Disconnect all cables.

2. Place hands on each side of the monitor and lift up to the highest position.

3. Place monitor face down on a non-abrasive surface (Place the screen on a 55 mm/2.2 inch platform so that the stand is

parallel with the surface) (Figure F).

4. Remove the 4 screws connecting the display to the stand and lift off the stand assembly (Figure G).

The display is now ready for mounting in an alternate manner.

5. Connect the AC cord and signal cable to the back of the display (Figure H).

6. Reverse this process to reattach stand.

Note: Use only VESA-compatible alternative mounting method. (100mm pitch)

Note: Handle with care when removing display stand.

Caution:

Please use the attached screws (4pcs) as shown in the picture when installing.
To meet the safety requirements, the display must be mounted to an arm which guaranties the necessary stability under consid­eration of the weight of the display.
The LCD display shall only be used with an approved arm (e.g. GS mark).

Figure F

55 mm

Figure G

Figure H

Figure E

Note: Handle with care when tilting the monitor screen.

English-6

OSD (On-Screen Display) control buttons on the front of the display function as follows:

To access OSD menu, press any of the control buttons (EXIT, , , –, +).
To change signal input, press the SELECT button.

NOTE: OSD must be closed in order to change signal input.

Menu

EXIT Exits the OSD controls.

Exits to the OSD main menu.

/ Moves the highlighted area left/right to select control menus.

Moves the highlighted area up/down to select one of the controls.

-/+ Moves the bar left/right to increase or decrease the adjustment.

SELECT/1 2 Active Auto Adjust function. Enter the OSD controls. Enter the OSD sub menu.

RESET Resets the highlighted control menu to the factory setting.

NOTE: When RESET is pressed in the main and sub-menu, a warning window will appear allowing you to cancel the

RESET function by pressing the EXIT button.

Brightness/Contrast Controls

BRIGHTNESS

Adjusts the overall image and background screen brightness.

CONTRAST

Adjusts the image brightness in relation to the background.

AUTO CONTRAST (Analog input only)

Adjusts the image displayed for non-standard video inputs.

Auto Adjust (Analog input only)

Automatically adjusts the Image Position and H. Size settings and Fine settings.

Position Controls

LEFT / RIGHT (Analog input only)

Controls Horizontal Image Position within the display area of the LCD.

DOWN / UP (Analog input only)

Controls Vertical Image Position within the display area of the LCD.

H.SIZE (Analog input only)

Adjusts the horizontal size by increasing or decreasing this setting.
Should the “AUTO Adjust function” do not give you a satisfactory picture setting, a further tuning can be
performed using the “H.Size” function (dot clock). For this a Moiré test pattern could be used. This function
may alter the width of the picture. Use left/Right Menu to center the image on the screen. If the H.Size is
wrongly calibrated, the result would look like on the left drawing. The image should be homogeneous.

FINE (Analog input only)

Improves focus, clarity and image stability by increasing or decreasing this setting.
If the “Auto Adjust function” and the “H.Size” function do not give you a satisfactory picture setting, a fine
tuning can be performed manually using the “Fine” function. It improves focus, clearity and image stability
by increasing or decreasing this setting.
For this a Moiré test pattern could be used. If the Fine value is wrongly calibrated, the result would look like
on the left drawing. The image should be homogeneous.

When FINE value is wrong. When FINE value is correct.

When H.SIZE value is wrong. When H.SIZE value is improved. When H.SIZE value is correct.

Controls

English

English-7

Color Control Systems

Color Control Systems: Six color presets select the desired color setting (sRGB and NATIVE color presets are

standard and cannot be changed).
R, G, B: Increases or decreases Red, Green or Blue color depending upon which is selected. The change in color
will appear on screen and the direction (increase or decrease) will be shown by the bars.
sRGB: sRGB mode dramatically improves the color fidelity in the desktop environment by a single standard RGB
color space. With this color supported environment, the operator could easily and confidently communicate colors
without further color management overhead in the most common situations.

NATIVE: Original color presented by the LCD panel that is unadjustable.

Tools

LANGUAGE: OSD control menus are available in seven languages.

OSD POSITION: Yo u can choose where you would like the OSD control image to appear on your screen.

Selecting OSD Location allows you to manually adjust the position of the OSD control menu left, right,
down or up.

OSD TURN OFF: The OSD control menu will stay on as long as it is use. In the OSD Turn Off submenu,
you can select how long the display waits after the last touch of a button to shut off the OSD control menu.

OSD LOCK OUT: This control completely locks out access to all OSD control functions. When attempting
to activate OSD controls while in the Lock Out mode, a screen will appear indicating the OSD controls are
locked out. There are two types of OSD LOCK OUT:
OSD LOCK OUT with BRIGHTNESS and CONTRAST control: To activate the OSD Lock Out function,
press SELECT, then “+” key and hold down simultaneously. To deactivate the OSD Lock Out, press
SELECT, then “+” key and hold down simultaneously. BRIGHTNESS and CONTRAST can be adjusted
while in the lock out mode.
OSD LOCK OUT with no control: To activate the OSD Lock Out function, press SELECT, then “>” key and
hold down simultaneously. To deactivate the OSD Lock Out, press SELECT, then “>” key and hold down
simultaneously. No controls can be adjusted while in the lock out mode.

RESOLUTION NOTIFIER: This optimal resolution is 1280 x 1024. If ON is selected, a message will appear
on the screen after 30 seconds, notifying you that the resolution is not at 1280 x 1024.

HOT KEY: You can adjust the brightness and contrast directly. When this function is set to ON, you can
adjust the brightness with

or , contrast with + or - key, while the OSD menu is off.

OFF TIMER: Monitor will automatically power-down when the end user has selected a pre-determined
amount of time.

FACTORY PRESET: Selecting Factory Preset allows you to reset all OSD control settings back to the
factory settings. The RESET button will need to be held down for several seconds to take effect. Individual
settings can be reset by highlighting the control to be reset and pressing the RESET button.

Information

DISPLAY MODE: Provides information about the current resolution display and technical data including the

preset timing being used and the horizontal and vertical frequencies. Increases or decreases the current
resolution.

MONITOR INFO.: Indicates the model and serial numbers of your display.

OSD Warning

OSD Warning menus disappear with Exit button.
NO SIGNAL: This function gives a warning when there is no Horizontal or Vertical Sync. After power is

turned on or when there is a change of input signal, the No Signal window will appear.
RESOLUTION NOTIFIER: This function gives a warning of use with optimized resolution. After power is

turned on or when there is a change of input signal or the video signal doesn’t have proper resolution, the

Resolution Notifier window will open. This function can be disabled in the TOOL menu.
OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After

the power is turned on or there is a change of input signal or the video signal doesn’t have proper timing,
the Out Of Range menu will appear.

Controls - Continued

English-8

Safety Precautions and Maintenance

FOR OPTIMUM PERFORMANCE, PLEASE NOTE

THE FOLLOWING WHEN SETTING UP AND

USING THE LCD COLOR DISPLAY:

• DO NOT OPEN THE DISPLAY. There are no user serviceable parts inside and opening or removing covers may expose

you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel.

• Do not spill any liquids into the cabinet or use your display near water.

• Do not insert objects of any kind into the cabinet slots, as they may touch dangerous voltage points, which can be harmful

or fatal or may cause electric shock, fire or equipment failure.

• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.

• Do not place this product on a sloping or unstable cart, stand or table, as the display may fall, causing serious damage to

the display.

• Do not place any objects onto the display and do not use the display outdoors.

• The inside of the fluorescent tube located within the LCD display contains mercury. Please follow the bylaws or rules of

your municipality to dispose of the tube properly.

Immediately unplug your display from the wall outlet and refer servicing to qualified service personnel under the following
conditions:

• When the power supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the display.

• If the display has been exposed to rain or water.

• If the display has been dropped or the cabinet damaged.

• If the display does not operate normally by following operating instructions.

• Do not bend power cord.

• Do not use display in high temperature, humid, dusty, or oily areas.

• Do not cover vent on display.

• If display is broken, do not come in contact with the liquid crystal.

• If glass is broken. Handle with care.

• Allow adequate ventilation around the display so that heat can properly dissipate. Do not block ventilated
openings or place the display near a radiator or other heat sources. Do not put anything on top of
display.

• The power cable connector is the primary means of detaching the system from the power supply. The
display should be installed close to a power outlet which is easily accessible.

• Handle with care when transporting. Save packaging for transporting.

• Image Persistence: Image persistence is when a residual or “ghost” image of a previous image remains visible on the
screen. Unlike CRT monitors, LCD monitor’s image persistence is not permanent, but constant images being displayed for
a long period of time should be avoided.

To alleviate image persistence, turn off the monitor for as long as the previous image was displayed. For example, if an
image was on the monitor for one hour and a residual image remains, the monitor should be turned off for one hour to
erase the image.

NOTE: As with all personal display devices, Silicon Graphics recommends using a moving screen saver at regular
intervals whenever the screen is idle or turning off the monitor when not in use.

CAUTION

Recommended use

English

English-9

CORRECT PLACEMENT AND ADJUSTMENT OF THE DISPLAY CAN

REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE

FOLLOWING WHEN YOU POSITION THE DISPLAY:

•For optimum performance, allow 20 minutes for warm-up.

• Adjust the display height so that the top of the screen is at or slightly below eye level.
Your eyes should look slightly downward when viewing the middle of the screen.

•Position your display no closer than 40 cm and no further away than 70 cm from your
eyes. The optimal distance is 50 cm.

• Rest your eyes periodically by focusing on an object at least 6 m away. Blink often.

•Position the display at a 90° angle to windows and other light sources to minimize
glare and reflections. Adjust the display tilt so that ceiling lights do not reflect on your
screen.

• If reflected light makes it hard for you to see your screen, use an antiglare filter.

• Clean the LCD display surface with a lint-free, non-abrasive cloth. Avoid using any
cleaning solution or glass cleaner!

• Adjust the display’s brightness and contrast controls to enhance readability.

• Use a document holder placed close to the screen.

•Position whatever you are looking at most of the time (the screen or reference material) directly in front of you to minimize
turning your head while you are typing.

•Avoid displaying fixed patterns on the display for long periods of time to avoid image persistence (after-image effects).

• Get regular eye checkups.

Ergonomics

To realize the maximum ergonomics benefits, we recommend the following:

• Use the preset Size and Position controls with standard signals.

• Use the preset Color Setting.

• Use non-interlaced signals with a vertical refresh rate between 60-75 Hz.

• Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient
contrast.

Recommended use - Continued

English-10

Monitor Specifications F190 Flat Panel Display Notes

LCD Module Diagonal : 48cm/19 inches Active matrix; thin film transistor (TFT) liquid

Viewable Image Size : 48cm/19 inches crystal display (LCD); 0.294 mm dot pitch;

Native Resolution (Pixel Count): 1280 x 1024 225cd/m2 white luminance; 500:1 contrast ratio,

typical.

Input Signal Video : ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI

Sync : Separate sync. TTL Level
Display Colors Analog input : 16,777,216 Depends on display card used.
Synchronization Range

Horizontal: 31.5 kHz to 81.1 kHz (Analog) Automatically

31.5 kHz to 80.0 kHz (Digital)

Vertical: 56 Hz to 75 Hz Automatically
Image Formation Time 25 ms (Typ.)
Resolutions Supported 720 x 400*1 :VGA text Some systems may not support

640 x 480*1 at 60 Hz to 75 Hz all modes listed.
800 x 600*1 at 56 Hz to 75 Hz

832 x 624*1 at 5 Hz
1024 x 768*1 at 60 Hz to 75 Hz
1152 x 870*1 at 75 Hz

1280 x 1024 at 60 Hz .........................Recommended resolution

Active Display Area Horiz.: 376.3 mm/14.8 inches

Vert.: 301.1 mm/11.9 inches
Power Supply AC100-120 V/220-240 V @ 50/60Hz
Current Rating 0.75 A@100-120 V, 0.4A @ 220-240 V
Dimensions 416.3 mm (W) x 388.7-498.7 mm (H) x 190 mm (D)

16.4 inches (W) x 15.3-19.6 inches (H) x 7.5 inches (D)

Without stand: 416.3 mm (W) x 352.8 mm (H) x 76 mm (D)

16.4 inches (W) x 13.9 inches (H) x 3.0 inches (D)

Weight 8.0 kg (17.6 lbs)

Without tilt stand: 5.8 kg (12.8 lbs)

Environmental Considerations

Operating Temperature : 5°C to 35°C/41°F to 95°F

Humidity : 30% to 80%

Feet : 0 to 3,000 m/0 to 10,000 Feet

Storage Temperature : -10°C to 60°C/14°F to 140°F

Humidity : 10% to 85%

Feet : 0 to 12,000 m/0 to 40,000 Feet

Regulations Safety: UL60950 (UL), CSA C22.2 No.60950 (c-UL),

EN60950 (TÜV-GS), CE-Marking
CCC

EMC: FCC Class-B, DOC Class-B,

EN55022 Class-B, VCCI Class-B,
EN61000-3-2, EN61000-3-3, EN55024
CCC, MIC, BSMI, C-Tick, CE-Marking

Other: MPR-II

ISO13406-2
TCO’99
International ENERGY STAR Program

Specifications

*

1

Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different.
This is normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technolo­gies, each dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.

NOTE: Technical specifications are subject to change without notice.

English

English-11

Reduced Footprint: Provides the ideal solution for environments requiring superior image quality but with size and weight

limitations. The display’s small footprint and low weight allow it to be moved or transported easily from one location to another.
OSD (On-Screen Display) Controls: Allow you to quickly and easily adjust all elements of your screen image via simple to use

on-screen menus.

No-Touch Auto Adjust (Analog input only): No-Touch Auto Adjust automatically adjust the monitor to optimal settings upon
initial setup.

ErgoDesign Features: Enhance human ergonomics to improve the working environment, protect the health of the user and
save money. Examples include

OSD controls for quick and easy image adjustments, tilt base for preferred angle of vision, small

footprint and compliance with MPRII and TCO guidelines for lower emissions

.

Plug and Play: The Microsoft

®

solution with the Windows®95/98/Me/2000/XP operating system facilitates setup and installation

by allowing the display to send its capabilities (such as screen size and resolutions supported) directly to your computer,
automatically optimizing display performance.

IPM (Intelligent Power Manager) System: Provides innovative power-saving methods that allow the display to shift to a lower
power consumption level when on but not in use, saving two-thirds of your display energy costs, reducing emissions and
lowering the air conditioning costs of the workplace.

Multiple Frequency Technology: Automatically adjusts display to the display card’s scanning frequency, thus displaying the
resolution required.

FullScan Capability: Allows you to use the entire screen area in most resolutions, significantly expanding image size.
VESA Standard Mounting Interface: Allows users to connect the SGI display to any VESA standard third party mounting arm

or bracket. Allows for the display to be mounted on a wall or an arm using any third party compliant device.

Features

English-12

No picture

• The signal cable should be completely connected to the display card/computer.

• The display card should be completely seated in its slot.

• Check the Vacation Switch should be in the ON position.

• Front Power Switch and computer power switch should be in the ON position.

• Check to make sure that a supported mode has been selected on the display card or system being used.
(Please consult display card or system manual to change graphics mode.)

• Check the monitor and your display card with respect to compatibility and recommended settings.

• Check the signal cable connector for bent or pushed-in pins.

• Check the signal input, “INPUT 1” or “INPUT 2”.

Power Button does not respond

• Unplug the power cord of the display from the AC outlet to turn off and reset the display.

• Check the Vacation Switch on the left side of the display.

Image persistence

• Image persistence is when a “ghost” image of an image remains on the screen even after the display has been turned off.
Unlike CRT monitors, LCD display’s image persistence is not permanent. To alleviate image persistence, turn the monitor
off for as long as an image was displayed. If an image was on the display for one hour and a “ghost” of that image remains,
the display should be turned off for one hour to erase the image.

NOTE: As with all personal display devices, it is recommended to use a moving screen saver at regular intervals

whenever the screen is idle or turning off the monitor when not in use.

Message “OUT OF RANGE” is displayed (screen is either blank or shows rough images only)

• Image is displayed only roughly (pixels are missing) and OSD warning “OUT OF RANGE” is displayed: Either signal clock
or resolution is too high. Choose one of the supported modes.

• OSD warning “OUT OF RANGE” is displayed on a blank screen: Signal frequency is out of range. Choose one of the
supported modes.

Image is unstable, unfocused or swimming is apparent

• Signal cable should be completely attached to the computer.

• Use the OSD Image Adjust controls to focus and adjust display by increasing or decreasing the fine total. When the display
mode is changed, the OSD Image Adjust settings may need to be re-adjusted.

• Check the display and your display card with respect to compatibility and recommended signal timings.

• If your text is garbled, change the video mode to non-interlace and use 60Hz refresh rate.

LED on display is not lit

(no green or amber color can be seen)

• Power Switch should be in the ON position and power cord should be connected.

Display image is not sized properly

• Use the OSD Image Adjust controls to increase or decrease the Coarse total.

• Check to make sure that a supported mode has been selected on the display card or system being used.
(Please consult display card or system manual to change graphics mode.)

No Video

• If no video is present on the screen, turn the Power button off and on again.

• Make certain the computer is not in a power-saving mode (touch the keyboard or mouse).

Troubleshooting
