Silex technology 140-00197-100 User Manual
SX-SDCAG 802.11a/b/g SDIO Module
User Manual
140-00197-100 Rev A
© 2010 Silex Technology America, Inc. All rights reserved.
February 2010
Silex Technology America SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS OF THIS PRODUCT FOR A PARTICULAR PURPOSE. Silex shall not be liable for any errors contained in this
manual or for any damages resulting from loss of use, data, profits, or any incidental or consequential damages arising from
the use of SILEX products or services. The information contained in this documentation is subject to change without notice.
Information and descriptions contained herein are the property of Silex. Such information and descriptions may
not be copied, disseminated, or distributed without the express written consent of Silex. This publication is
subject to change without notice.
Trademarks
ExtendView is a trademark of Silex Technology America, Inc. All other company or product names referenced
in this document may be trademarks or registered trademarks of their respective owners.
Silex Technology America, Inc.
www.silexamerica.com
140-00197-100 Revision A
Contents
About This User Manual............................................................................................................................................ 2
Safety Precautions................................................................................................................................................. 2
Emissions Disclaimer............................................................................................................................................. 2
Chapter 1: Introduction.............................................................................................................................................. 3
Chapter 2 Hardware Specifications/Compliance....................................................................................................... 4
FCC Information..................................................................................................................................................... 4
Information for Canadian Users (IC Notice)........................................................................................................... 5
Specifications......................................................................................................................................................... 7
Chapter 3 Installation................................................................................................................................................. 8
Installation Requirements ...................................................................................................................................... 8
Installation Procedure............................................................................................................................................ 8
Appendix A Antenna Information............................................................................................................................. 10
Antenna Specifications ........................................................................................................................................ 10
Appendix B Silex Contact Information..................................................................................................................... 12
Contents Silex Page 1
140-00197-100 Revision A
About This User Manual
This user manual provides detailed specifications, diagrams and additional information required to install the SXSDCAG 802.11a/b/g SDIO module into a product. The intended audiences are the developers and engineers
responsible for the integration of the module in another product.
Safety Precautions
To prevent damage to the SX-SDCAG module’s electronic circuit components, follow established
ESD practices and procedures for handling static-sensitive devices. All ESD-sensitive components must b e
stored and shipped in ESD-conductive bags or bubble-wrap and labeled as such using the standardized
ESD adhesive warning label.
Ethernet electrical wiring must be at least 6 feet from bare power wiring or lightning rods and
associated wires, and at least 6 inches from other types of wire (antenna wires, doorbell wires, wires from
transformers to neon signs), steam or hot water pipes, and heating devices.
Protectors and grounding wire placed by the service provider must not be connected to, removed,
or modified by the customer.
Emissions Disclaimer
Final emission certification per FCC, IC, CE and other agency requirements are the responsibi lity of the OEM
(refer to chapter 2 for additional information).
Page 2 Silex About This User Guide
140-00197-100 Revision A
Chapter 1: Introduction
The SX-SDCAG is an 802.11a/b/g radio/baseband module in a standard SDIO form factor.
Designed for wireless local area network (WLAN) applications that require low power
consumption, the SX-SDCAG is ideal for battery-operated portable devices in the medical,
weights and measures, transportation and other industries.
SX-SDCAG features include:
• Highly Integrated System for 802.11a/b/g WLAN
• U.FL antenna connectors with diversity support
• Wide operating temperature range
• Integrated Atheros AR6002XZ Single Chip
• Integrated high performance Dual-Band Front End Module (FEM), Band Pass Filter,
26MHz Crystal
• 16Kbit EEPROM
• Advanced power management to minimize standby and active power
• WEP 64/128, WPA (TKIP), WPA2 (802.11i) security
• Linux, Windows CE, and Windows Mobile drivers available from Silex (porting will be
required in most cases)
27.1
4.1
46.0
24.0
Figure 1 SX-SDCAG Dimensions (mm)
Introduction Silex Page 3
140-00197-100 Revision A
1.5
