Silent Call LLS-04 User Manual

Revision 3

5095 Williams Lake Road, Waterford Michigan 48329

[phone] (Voice / TTY)

"Lamp Lighter"

A multi-function lamp flasher… with

style!

Congratulations on purchasing the Lamp Lighter wireless multi-function alerting
device from Silent Call Communications. The Lamp Lighter represents a new era
in wireless alerting devices… functional yet attractive and stylish at the same
time.

The Lamp Lighter is compatible with all Silent Call transmitters except the new signature series
system. The transmitter(s) may be placed up to 100 feet fr o m the Lamp Lighter. When the Lamp
Lighter receives a signal from a transmitter, it flashes any table lamp plugged into it with a
distinctive pattern for each alert type. Do not use energy saving florescent light bulbs a s t he y wi l l
not operate properly in flashing the flash codes.

Setup

1. If desired, plug a telephone cable in series with the telephone receptacles on the Lamp Lighter

power supply. Plug the other end into any telephone outlet. If there is no telephone outlet
near the Lamp Lighter, you can also use a Silent Call telephone transmitter to activate the
telephone indication.

2. Plug a table lamp into the AC outlet on the Lamp Lighter power supply. Make sure the switch on

the lamp is turned on. If the lamp is not turned on, the Lamp Lighter will flash all its LEDs
when it powers up to indicate a l amp pr obl em.

3. Plug the power supply into an AC outlet. The Lamp Lighter will flash once, indicating it is ready

for operation. As long as you have not changed the code switch setting in your transmitter(s)
from the factory setting of OFF, OFF, OFF, ON, ON the Lamplighter is ready for operation.
If you have changed the code switches, follow the steps in the programming section (below).

Operation

1. The Lamp Lighter will flash the lamp with a distinct pattern for each type of transmitter it

hears. The indication will continue for about 15 seconds after the transmitter stops
transmitting.

SOUND = three short flashes
PHONE = one long fl ash

DOOR = two short flashes
WEATHER = one short and one long flash

FIRE = continuous short flashes

CO = three short flashes and one long flash

Revision 3

5095 Williams Lake Road, Waterford Michigan 48329

[phone] (Voice / TTY)

2. The lamp can be turned on and off manually by pressing the large button on top of the Lamp

Lighter. The Lamp Lighter will indicate alerts whether the lamp is on or off.

3. If for any reason the lamp is unplugged, turned off at the lamp, or burned out, the Lamp

Lighter will periodically flash all LEDs to indicate a problem with the lamp.

4. An optional VIB-PJ bed vibrator an d st ro be may be connected to the vibrator

jack a n d st r ob e
jack on the Lamp Lighter power supply and will vibrate the same code as the lamp and the
strobe flashes on earlier models. Remove four screws from the power supply base. Install VIB­PJ bed vibrator into the vibrator jack insure wires are placed into cable retention cavi ty o f
case fo r ea s y r outing and proper power supply cover closure (FIQ 2). Install the four screws
securing power supply base.

5. An optional battery backup can be used to supply power to your lamplighter should you loose

h ou se po we r. Remove the 4 screws and remove power supply base. Install Battery Backup Pack
Plug onto connector (FIQ 2). Install power supply base cover and secure with the four screws
to power supply base.

Fig. 2

Caution

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO INSTRUCTIONS

V I B -PJ Input

Cable retaining cavity

Battery
Backup
Jack

Strobe Input
