SIIG Trio 2S1P User Manual

Cyber 2S1P PCIe

Quick Installation Guide

Introducing the Cyber 2S1P PCIe

The Cyber 2S1P PCIe high-speed serial I/O card
provides two 9-pin serial ports and one parallel
port.

Key Features and Benefits

• Adds 2 RS-232 9-pin serial ports and 1
ECP/EPP parallel port to your PCIe enabled
system

• Compliant with PCI Express Base
Specification, Revision 1.1

• Supports ECP, EPP and Buffered SPP
parallel port modes

System Requirements

• PCI Express enabled system with an
available PCI Express slot

• Windows® 7 (32-/64-bit) / Vista (32-/64­bit) / XP (32-/64-bit) / Server 2003 & 2008
(32-/64-bit)

04-0655A

1

Package Contents

• Cyber 2S1P PCIe board

• 2-Port DB9 serial port cable

• Driver CD

• Quick installation guide

Layout

2-Port DB9 serial port cable

Parallel port

Figure 1: Board Layout

Note: When connecting the 2-Port DB9
serial port cable, position the ribbon

cable(s) so that the stripe is on the side
closest to the parallel port. See Figure 1.

Stripe

2

Hardware Installation

General instructions for installing the card are
provided below. Since the design of computer
cases and motherboards vary, refer to your
computer’s reference manual for further
information, if needed.

Static Electricity Discharge may permanently
damage your system. Discharge any static
electricity build up in your body by touching your
computer’s case for a few seconds. Avoid any
contact with internal parts and handle cards
only by their external edges.

1. Turn OFF the power to your computer and
any other connected peripheral devices.

2. Unplug the power cord from the computer.

3. Remove the computer cover.

4. Remove the slot bracket from an available
PCIe slot.

5. Connect the 2-Port DB9 (9-pin) serial port
cable connector now and remove another
slot bracket cover from the system chassis.
See Figure 1 on the page 2 for more details.

3

Skip this step if you don't need any serial
ports.

6. To install the card, carefully align the card's
bus connector with the selected PCIe slot on
the motherboard. Push the board down
firmly, but gently, until it is well seated.

7. Replace the slot bracket holding screw to
secure the card.

8. Mount the second serial port and secure it
with the slot bracket holding the screw.
Skip this step if you don't need any serial
ports.

9. Replace the computer cover and reconnect
the power cord.

Driver Installation

Please make sure the board is installed before
proceeding with driver installation.

Windows 7 (32-/64-bit)

1. Install the board and boot up Windows.

2. Right click Computer, click Manage, click
Device Manager.

4
