SIIG PCI-LP User Manual

SoundWave 5.1 PCI-LP

Quick Installation Guide

Introducing the SoundWave 5.1 PCI-LP

The SoundWave 5.1 PCI-LP transforms your PC into a
high-definition 5.1 channel surround sound home
theater system.

Key Features and Benefits

• Compliant with AC'97 rev. 2.3 and PCI 2.2
specifications

• Supports 24-bit/96kHz digital and 20-bit/48kHz
analog connections

• Supports Dolby Digital/Dolby Digital EX
surround sound, EAX 1.0, 2.0, A3d 1.0 and
DirectSound3D

• HRTF-based 3D positional audio, supporting
DirectSound and A3D interface

• Digital out: S/PDIF (Toslink)

• Universal PCI interface enables this board to be
installed into PCI-X slots

• Perfect audio upgrade for DVD playback, listening
to MP3 or other music, gaming and more!

System Requirements

• Pentium® III or equivalent PC with an available
PCI or PCI-X slot

• Windows® 2000/XP (32-/64-bit)/Server 2003 (32­/64-bit)/Vista (32-/64-bit)

• 128 MB or more system memory

04-0456B

1

Package Contents

• SoundWave 5.1 PCI-LP

• G9 DIN cable

• Spare standard height bracket

• Software CD and Quick Installation Guide

Layout

Mic

Line-In

G9 DIN

Digital Out
(Toslink)

CD-In

Aux-In

S/PDIF Out

Figure 1: Layout

Headphones (green)

Rear (white)

Center/Subwoofer
(yellow)

Front (red)

Figure 2: G9 DIN Cable Connection

2

Audio Connectors

MIC

This connector provides microphone-in function.

LINE In

This connector provides analog line-in function.

Optical Digital Out (Toslink)

Optical Digital (S/PDIF) output via Toslink to Digital

5.1 surround sound speakers.

CD-In (internal)

This connector can be used to attach a CD-ROM or
DVD-ROM audio cable (cable not included).

Aux-In (internal)

This connector can be used to connect a second
CD-ROM or DVD-ROM or other audio output devices.
Audio cable not included.

S/PDIF Out (internal)

Digital output 2-pin connector for connecting to audio
input devices. Audio cable not included.

Front Out (red)

This connector provides front source output, or you can
connect one set of stereo speakers.

Rear Out (white)

This connector provides rear surround sound output.

Center/Subwoofer Out (yellow)

This connector provides center and subwoofer (LFE)
sound source output.

Headphone (green)

This connector can be used to connect stereo headphones.

3

Hardware Installation

General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.

Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges. For full

heighth chassis, install the full heighth bracket now.

1. Turn OFF the power to your computer.

2. Unplug the power cord and remove the computer
cover.

3. Remove the slot bracket from an available PCI slot.

4. Carefully align the card to the selected PCI slot,
push the board down firmly, but gently, until it is
well seated.

5. Replace the slot bracket holding screw to secure
the card.

6. Connect one end of the audio cable from your
CD/DVD-ROM to the CD-In on the soundcard.

7. Replace the computer cover and reconnect the
power cord.

8. Make your speaker and device connections, then
complete the driver installation on the next pages.

4

Driver Installation

Windows 2000

1. Boot up Windows, at the Add New Hardware
Wizard, click Cancel, then insert the driver CD.

2. Click Start, Run, type D:\32bit\setup.exe, then
click OK. (Change D: to match the drive letter of
your CD-ROM)

3. At the Welcome screen, click Next.

4. At the Select Components screen, select Install

Envy24 Family Audio Device Driver, then click
Next.

5. At the Choose Destination screen, click Next.

6. Select the restart Windows option, then click Finish.

32-bit Windows XP/Server 2003

1. Boot up Windows, at the Found New Hardware
Wizard, click Cancel, then insert the driver CD.

2. Click Start, Run, type D:\32bit\setup.exe, then
click OK. (Change D: to match the drive letter of
your CD-ROM)

3. At the Welcome screen, click Next.

4. At the Select Components screen, select Install

Envy24 Family Audio Device Driver, then click
Next.

5. At the Choose Destination screen, click Next.

6. If prompted, at the Hardware Installation box,
click Continue Anyway, otherwise go directly to
step 7.

7. Select the restart Windows option, then click Finish.

5

64-bit Windows XP/Server 2003

1. Boot up Windows, at the Found New Hardware
Wizard, click Cancel, then insert the driver CD.

2. Click Start, Run, type D:\64bit\setup.exe, then
click OK. (Change D: to match the drive letter of
your CD-ROM)

3. At the Welcome screen, click Next.

4. At the Select Components screen, select Install

Envy24 Family Audio Device Driver, then click
Next.

5. At the Choose Destination screen, click Next.

6. Select the restart Windows option, then click Finish.

Windows Vista™

1. Boot up Windows, at the Found New Hardware,
click Cancel.

2. Insert the driver CD:

At the Auto Play window: click Open folder to view
files. Double click the Vista folder, then double
click Setup.exe (Application).

If Auto Play doesn't start: click Start, in the Start
Search box, type D:\vista\setup.exe, press Enter.

(Change D: to match your CD-ROM drive letter)

3. Click Allow.

4. At the Welcome screen, click Next.

5. At the License Agreement screen, select I Agree,
then click Next.

6. Check Envy Family Audio Device Driver V5.20a,
then click Next.

7. At Installing Components List, click Next.

6
