ExpressCard 11-in-1
Reader/Writer
Quick Installation Guide
Features and Benefits
• Compatible with SD, mini SD, MMC, RS-MMC,
Memory Stick, Memory Stick Duo (incl. PRO and
MagicGate), Memory Stick PRO, MagicGate
Memory Stick and xD Picture Card memory cards
Note: The copyright protection feature of Magic
Gate is not supported. However, Memory Stick
read/write function is supported.
• Hot-swapping feature allows you to attach/detach
this reader/writer without powering down your
system
• Compliant with USB Storage Class specifications –
no driver installation required!
Serial # Sticker
For future product return or exchange, this serial # is
required. Please keep it for your reference.
04-0420A
1
System Requirements
• Notebook or desktop computer with an available
ExpressCard slot
• Windows 2000/XP/Server 2003
Package Contents
• ExpressCard 11-in-1 Reader/Writer
• This quick installation guide
Layout
Memory
Card Slot
Figure 1. ExpressCard 11-in-1 Reader/Writer
ExpressCard
Connector
Installation
Hardware Installation
General instructions for installing the ExpressCard
11-in-1 Reader/Writer are provided below. Since the design
of computers vary, refer to your system’s reference manual
for further information, if needed.
1. Insert the ExpressCard 11-in-1 Reader/Writer into the
ExpressCard slot of the computer with it's Express
Card Connector facing the slot. Push the card into
the slot gently, yet firmly for a solid connection.
2
Note: Some ExpressCard slots will click when the
ExpressCard is fully inserted into the slot.
2. If your system was powered off when you plugged
in the ExpressCard, turn it on and go to Driver
Installation on page 3. Otherwise, go directly to
Driver Installation on page 3.
Driver Installation
Windows 2000, XP and Server 2003 automatically detects
and installs the correct driver for the ExpressCard 11-in-1
Reader/Writer. No driver installation is needed.
Verify 2000/XP/2003 Installation
1. Right click My Computer, click Manage, then click
Device Manager.
2. Click on the + (plus sign) in front of Disk Drives,
Generic STORAGE DEVICE USB Device should
be displayed.
Using the Reader/Writer
When inserting or removing memory cards, make sure
that the ExpressCard 11-in-1 Reader/Writer does not move
from side to side in the ExpressCard slot, otherwise it may
accidentaly eject from the slot.
3
Inserting Memory Cards
For all memory cards, insert with the gold pins forward
and facing down. Push the memory card into the slot until
you hear of feel a click then release. The memory card will
retract slightly upon release.
Removing Memory Cards
Memory cards can be removed at any time. Push in on
the memory card, when you hear or feel a click, release
pressure and pull the memory card out.
Accessing Memory Cards
When the reader/writer is successfully installed, a
Removable Disk icon will appear in My Computer. To
access the memory card, double click the disk icon.
Removing the ExpressCard
Before ejecting the ExpressCard 11-in-1 Reader/Writer from
the ExpressCard slot, first use the Safely Remove
Hardware utility to stop it. Not following the steps below
could lead to system crashes, data corruption or data loss.
Follow the steps below for your version of Windows.
For Windows 2000
1. Click the Unplug or Eject Hardware icon located in
the taskbar by the system clock.
2. Click Stop USB Mass StorageDevice.....
4
3. At the Safe To Remove Hardware box, click OK.
The ExpressCard 11-in-1 Reader/Writer can be ejected.
For Windows XP/Server 2003
1. Click the Safely Remove Hardware icon located in
the taskbar by the system clock.
2. Click Safely remove USB Mass Storage Device.....
3. When Safe to Remove Hardware box pops up, the
ExpressCard 11-in-1 Reader/Writer can be ejected.
5
Blank Page
6
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our website
at www.siig.com and click on Support. Our online support database is updated
daily with new drivers and solutions. Answers to your questions could be just
a few clicks away. You can also submit questions online and a technical
support analysts will promptly respond.
A 5-year manufacturer warranty supplied with this product is
offered by SIIG, Inc. Please see SIIG website for more warranty
details. If you should happen to encounter any problems with this product,
please follow the procedures below.
If it is within the store's return policy period, please return the
product to the store where you purchased from. If your purchase has passed the
store's return policy period, please follow these steps to have the product
repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com , click Support , then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued. SIIG RMA department can also
be reached at (510) 413-5333.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came
with the original package must be included.
• Clearly write your RMA number on the top of the returned package.
SIIG will refuse to accept any shipping package, and will not be
responsible for a product returned without an RMA number posted on
the outside of the shipping carton.
• You are responsible for the cost of shipping the product to SIIG at the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538
RMA #: ________________
• SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.
7
About SIIG, Inc.
Founded in 1985, SIIG, Inc. is a leading computer upgrade manufacturer of
I/O connectivity products, including PCI & ISA serial and parallel ports,
USB, Serial ATA & UltraATA controllers, FireWire (1394a/b), Networking,
Sound Cards, and other accessories. SIIG is the premier one-stop source of
upgrades.
SIIG products offer comprehensive user manuals, many user-friendly
features, and are backed by an extensive manufacturer warranty. Highquality control standards are evident by the overall ease of installation and
compatibility of our products, as well as one of the lowest defective return
rates in the industry. SIIG products can be found in computer retail stores,
mail order catalogs, and e-commerce sites in the Americas and the UK, as
well as through major distributors, system integrators, and VARs.
PRODUCT NAME
ExpressCard 11-in-1 Reader/Writer
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Ave.
Fremont, CA 94538-3152
ExpressCard 11-in-1 Reader/Writer is a trademark of SIIG, Inc. SIIG and SIIG logo are
registered trademarks of SIIG, Inc. Other names used in this publication are for
identification only and may be trademarks of their respective companies.
January, 2006 Copyright © 2006 by SIIG, Inc. All rights reserved.
