Page 1
User Guide
Models 410, 420, 430, 440, 450
For Windows® 2000, Windows XP and Mac OS® X v10.2 or later.
Smart Label Printers®
Series
Page 2
14
Specifications
Smart Label Printer 410/420/430/440/450
The SLP is a compact printing device ideally suited for label printing applications. There are
no built-in fonts and any text must be converted to a bitmap image by a host computer or
device for printing on the SLP.
Developer information can be found on our website at www.siibusinessproducts.com
Printer
Technology Direct thermal
Resolution Model 410/420/430 203 dpi (8 dots/mm)
Model 440/450 300 dpi (11.81 dots/mm)
Max. Paper Width Model 410 1.22 in. (31mm)
Model 420/430/440/450 2.28 in. (58mm)
Max. Printable Width Model 410 0.94 in. (24mm)
Model 420/430/440/450 1.89 in. (48mm)
Print Speed Model 410 4-5 seconds*
Model 420 3-4 seconds*
Model 430 2-3 seconds*
Model 440 2-3 seconds*
Model 450 1-2 seconds*
*average speed, standard address label
Interface USB and RS-232
Power
Input Model 410/420/440 AC adapter:
PW-0006 -WH-U1 AC 100 -120V, 50/60 Hz
(US version)
PW-0006 -WH-E1 AC 200-240V, 50/60 Hz
(EU version)
PW-0006 -WH-K1 AC 200-240V, 50/60 Hz
(UK version)
PW-0006 -WH-A1 AC 200-240V, 50/60 Hz
(AU version)
Model 430/450 AC adapter:
PW-0012-WH-W1
(universal) AC 100 -240V, 50/60 Hz
CB-WH-US2 AC Cord for USA
CB-WH-EU2 AC Cord for EU
CB-WH-UK2 AC Cord for UK
CB-WH-AU2 AC Cord for Australia
Page 3
15
LED Indicator
Off
Steady Green
Steady Amber
Blinking Green 1*
Blinking Green 2*
Blinking Amber 1*
Blinking Amber 2*
Blinking Red 1*
Blinking Red 2*
Blinking Red 3*
Blinking Red 4*
(SLP 440/450)
State
Power off/Stand-by
On-line
Off-line
No labels
Print head up
Label jam
Buffer overflow
Temperature error
Voltage error
Print head error
Print head error
Status Light Indicators
* The number refers to the number of blinks.
Output Model 410/420/440: DC6V 1.5A (2.0A max.)
Model 430/450 DC12V, 3.0A (5.0A max.)
Dimensions 4.61 in. (W) x 6.34 in. (D) x 6.22 in. (H)
117mm (W) x 160.9mm (D) x 157.9mm (H)
Weight All models 1.14 lbs. (515 grams)
Life Time Model 410/420: Approx. 2 million characters
(24 H x 12 W dots)
Model 430 : Approx. 5 million characters
(24 H x 12 W dots)
Model 440/450 : Approx. 2.5 million characters
(24 H x 12 W dots)
Environment
Temperature Operating: 15°C to 35°C (59°F to 95°F)
Storage: -20°C to 60°C (-4°F to 140°F)
Humidity Operating: 30 % RH to 80 % RH
(non-condensing)
Storage: 30% RH to 90 % RH
(non-condensing)
