SIGNIFY Smart DJ Speaker, EA0944 Instruction Manual
SPEAKER
SMART
DJ
YEAR
WARRANTY
ONE
Instruction Manual
EA0944
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
AFTER SALES SUPPORT
1300 777 137
02
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
Contents
Welcome 03
Warranty Details 04
General Information and Safety Instructions 05
Product Overview 08
Control Panel 08
Rear Panel 09
Remote Control 10
Audio Modes and Unique Features 11
Buttons and Controls 12
Before First Use 16
Operating Instructions 18
Using the Audio Modes 18
AUX Mode 19
FM Radio Mode 19
Bluetooth
®
Mode 20
USB Mode 22
USB Recording 23
Sound Adjustment 24
Sound Effects 25
Using the Party Lights 27
Troubleshooting 28
Repair and Refurbished Goods or Parts Notice 31
Other Useful Information 32
Cleaning and Maintenance 32
Storage 32
Responsible Disposal 32
Trademarks 33
Specication Table 33
03
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
Welcome
Congratulations on choosing to buy a Signify® product.
All products brought to you by Signify® are manufactured to the highest standards of performance
and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty.
This comprehensive instruction manual will provide you with a detailed guide on how to operate your
product and will also assist you in troubleshooting any problems that you may encounter.
If you have any queries regarding the use of this product, please feel free to phone our technical
support line for some friendly advice. If you are experiencing difculties or believe that the product
may have a technical fault, we will assist you in rectifying the issue. We can generally solve most
problems simply and quickly over the phone, so please always phone us rst!
We are sure that you will enjoy using this product and you can expect to gain years of service from
this product when it is used and maintained in the correct manner.
AFTER SALES SUPPORT
1300 777 137
04
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
The product is guaranteed to be free from defects in workmanship and parts for a period of 12
months from the date of purchase. Defects that occur within this warranty period, under normal
use and care, will be repaired, replaced or refunded at our discretion. The benets conferred by this
warranty are in addition to all rights and remedies in respect of the product that the consumer has
under the Competition and Consumer Act 2010 and similar state and territory laws.
Smart DJ Speaker
Warranty Details
05
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
General Information and Safety Instructions
RETAIN FOR FUTURE USE
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The
safety precautions enclosed herein reduce the risk of re, electric shock and injury when correctly
adhered to. Please keep this user manual in a safe place along with your purchase receipt and carton
for future reference. If applicable, pass these instructions on to the next owner of the product. Always
follow basic safety precautions and accident prevention measures when using an electrical product.
This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated dangerous voltage within the product’s enclosure
that may be of sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
1. Before using the Smart DJ Speaker, ensure the electrical voltage and circuit frequency
correspond to the voltage stated on the rating label of your product and your power outlet is
properly earthed.
2. Do not use the Smart DJ Speaker with an extension cord unless this cord has been checked and
tested by a qualied electrician. If an extension cord is used, please ensure that it has a rating
equal or exceeding the rating of this product.
3. Do not pull or carry by the cord, use the cord as a handle, close a door on the cord, or pull the
cord around sharp edges or corners. Check the power cord regularly for visible damage. If it is
damaged, please contact the After Sales Support Line for further advice.
4. Only use the AC power cord provided with the Smart DJ Speaker. Check the power cord regularly
for visible damage. If it is damaged, please contact the After Sales Support Line for further
advice.
5. When the Smart DJ Speaker is not in use, switch it off and unplug from the power outlet. To
unplug, grip the adaptor and pull from the power outlet. Never pull by the cord.
6. The power adaptor is not user-serviceable. Contact with high voltage components may cause a
risk of electric shock, therefore do not attempt to open the back cover of the Smart DJ Speaker.
This will void the warranty.
7. The installation of a residual current device (safety switch) is recommended to provide additional
safety protection when using electrical devices. It is advisable that a safety switch with a rated
residual operating current not exceeding 30mA be installed in the electrical circuit supplying the
device. See your qualied electrician for professional advice.
WARNING: To reduce the risk of electric shock do not remove cover (or back). No userserviceable parts inside. Refer servicing to qualied service personnel.
AFTER SALES SUPPORT
1300 777 137
06
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
General Information and Safety Instructions (cont.)
8. This Smart DJ Speaker is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the product by a person responsible for
their safety.
9. Install and operate the Smart DJ Speaker in a cool and sufciently ventilated room to ensure it
does not overheat.
10. Never block the ventilation holes and openings. Do not place this product against soft surfaces,
drapery or fabric that may block the ventilation holes. The product should not be placed in an “inbuilt” installation unless all ventilation holes are provided with adequate ventilation.
11. Do not expose the Smart DJ Speaker to water, rain moisture, liquids or dust. Do not store or use
the Smart DJ Speaker in high moisture environments. Moisture can damage and cause corrosion
to the speaker cone and other internal components.
12. The apparatus should not be exposed to water (dripping or splashing) and objects lled with
liquids, such as vases or drinks, should not be placed on the apparatus.
13. Unplug the Smart DJ Speaker in cases of electrical storms to protect against the possibility of
power surges damaging the device.
14. The manufacturer and retailer are not responsible for any eventual damages caused by improper
or faulty use.
15. Always store the Smart DJ Speaker indoors after use. Never leave the Smart DJ Speaker
outdoors especially when it is raining or there is excess humidity in the air.
16. Never operate the Smart DJ Speaker with wet hands, submerge under water or spill liquids into
or onto the device.
17. Do not place the Smart DJ Speaker near a hot burner (gas or electric), other heat emitting
sources or open ames.
18. Always position the Smart DJ Speaker on a at and stable surface.
19. Be careful when transporting the Smart DJ Speaker. This unit is equipped with wheels and will
roll if it's not secure. Please ensure the device is stable and secure to ensure it does not cause
damage to objects, or injury to persons.
20. If the Smart DJ Speaker has been exposed to strong uctuations in temperature (for example,
after transport), do not switch it on immediately. Moisture and condensation could damage the
equipment. Do not switch on the equipment until it has reached room temperature.
21. Be extremely careful when unpacking or relocating the Smart DJ Speaker. Ensure that the Smart
DJ Speaker is not dropped or bumped and that excessive force is not applied to the unit. Impact
such as these can damage the product and its internal components.
22. Keep the Smart DJ Speaker away from any electromagnetic sources, such as magnets or
electronic motors, or from any other object emitting strong radio waves, like mobile phones and
radios. Strong magnetic elds may cause distorted sound, or failure and damage to the Smart DJ
Speaker.
23. The remote control is powered by 2 x AAA batteries (included). Ensure you observe the polarity
markings before inserting or replacing the batteries.
WARNING: Do not leave batteries in the remote control unused for extended periods of time.
Always ensure when changing the batteries you do not mix old batteries with new batteries .
07
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
General Information and Safety Instructions (cont.)
24. Never operate the Smart DJ Speaker in temperatures exceeding 50°C (122°F).
25. Store in a dry, cool place away from heat. If the Smart DJ Speaker is to be stored for the
prolonged periods ensure that the Smart DJ Speaker is not stored in areas that could potentially
reach or exceed 50°C (122°F).
26. The Smart DJ Speaker should always be repacked in its original packaging whenever
transporting to prevent any possible damage to the device.
27. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
WARNING: Do not expose the batteries to excessive heat, direct sunlight, open ames or any
other heat sources.
IMPORTANT: Dispose of all used batteries at designated disposal points. Never dispose of
batteries in a re as this may cause an explosion or leakage of dangerous chemicals and fumes.
WARNING: To prevent possible hearing damage, avoid listening at high volume levels over long
periods of time. Even exposure to short bursts of loud noise can result in hearing loss. Please
keep the volume consistently at a comfortable level.
REC/PLAY
5V 1A 5V 1A
PLAY
Control Panel Parts List
1. USB-A Input
2. DJ Dial (Source A - DJ Sound Effects)
3. DJ AUTO Button (Source A - USB Mode)
4. DJ EFFECT Button (Source A)
5.
Button (Source A - Stop)
6. Playback Controls (Source A)
See page 15 for detailed instructions
7. M Button (Source A - Mode Selection)
8. Source Control Bar
(Cross Fade Between Source A & B)
9. Master Equalizer Control
10. M Button (Source B - Mode Selection)
11. Playback Controls (Source B)
See page 15 for detailed instructions
12.
Button (Source B - Stop)
13. LED Lights Button
14. MUTE Button
15. VOL Dial (Master Volume)
16. USB-B Input
17. Mode Indicator Lights (Source B)
18.
Button (Standby)
19. S Buttons (Sound Effects)
20. BASS Button
21. MIC 2 Input (Microphone)
22. MIC VOL Dial (Microphone Volume)
23. MIC 1 Input (Microphone)
24. Display Screen
25. EQ Button
26. REC Button (Record)
27. Mode Indicator Lights (Source A)
Control Panel
1
2
3 14
15
16
4 5 6 8 9 11 12 13
17
27 22
2325
1826
21
19
2024
7 10
AFTER SALES SUPPORT
1300 777 137
08
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
Product Overview
Included (not pictured): Instruction Manual, AAA Batteries x 2, Allen Key, Screws x 10, Handles x 2, FM Antenna
Cable, AUX Cable and Warranty Card.
09
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
Product Overview (cont.)
Rear Panel Parts List
1. FM Antenna Input
2. POWER Switch (On/Off)
3. AUDIO OUT
4. AUX-A Input
5. AUX-B Input
Rear Panel
AUX-BAUX-A
POWER
ON
OFF
AUDIO OUT
2 3 4 5
1
AFTER SALES SUPPORT
1300 777 137
10
service@unclebills.com.au
MODEL: EA0944 PRODUCT CODE: 59080 12/2017
B
US B
B
AU X
DJ
AUT O
A
A
B
A
US B
A
AU X
FMBT
S+
S1 S2
S4
S3
Product Overview (cont.)
Remote Control Remote Control Parts List
1. Mute Button
2.
Button (Standby)
3. LED Light Button
4. S Buttons (Sound Effects)
5. BT Button (Source A - Bluetooth
®
Mode)
6. FM Button (Source A - FM Radio Mode)
7. A AUX Button (Source A - AUX Mode)
8.
Button (Source A - Record)
9. A
Replay Button (Source A - USB Mode)
10. A USB Button (Source A - USB Mode)
11. Playback Controls (Source A)
See page 15 for detailed instructions
12. DJ AUTO Button
13. EQ Button
14.
Button (Source A - Stop)
15. VOL-/VOL+ Button
16. B USB Button (Source B - USB Mode)
17. B AUX Button (Source B - AUX Mode)
18. Playback Controls (Source B)
See page 15 for detailed instructions
19. B
Button (Source B - Replay)
20.
Button (Source B - Stop)
1 2
6
20
17
13
15
9
4
3
8
11
5
12
16
19
7
10
14
18
NOTE: Please always ensure the remote
control is pointed towards the front top of
the Smart DJ Speaker.
Loading...
