SIGNIFY EA0815 Quick Start Manual

Quick Start Guide

EA0815

AUS

1300 777 137 [e-mail]

www.signifyelectronics.com.au

Getting Started

Please refer to the instruction manual for full instructions on how to
operate the Signify® 55’’ 4K Ultra HD LED LCD TV.

PARTS LIST

In the box you will find:

1

1 x 55’’ 4K Ultra HD LED LCD TV
1 x Remote control (not pictured)
2 x AAA batteries (not pictured)
2 x Base stands (including 4 x screws)

WHAT YOU WILL NEED
1 x Phillips head screwdriver (for stand installation)
1 x Antenna cable

RIGHT

LEFT

2 3 4 5

CONNECTIONS

1. HEADPHONES OUTPUT

2

2. HDMI1 (supports 4K)

3. HDMI2 (supports 4K)

4. PC AUDIO INPUT

5. VGA INPUT

6. AV INPUT

7. COAXIAL OUTPUT

8. USB INPUT

9. USB INPUT

10. Y/Pb/Pr INPUT (COMPONENT)

11. ANTENNA INPUT

12. HDMI3 (supports full HD 1080p resolution)

INSTALLATION AND POWER CONNECTION

1. Install the stand (see page 13 of the instruction manual).

3

2. Connect one end of the antenna cable to the antenna socket of the
TV and the other end to the antenna wall socket.

3. Insert the batteries into the remote control.

4. Connect the TV power cord into the mains power socket
and switch it on.

5. Press the power button located on the lower right

hand side of the TV front panel. The indicator light
will illuminate green and the TV screen will display

the First Time Installation menu.

FIRST TIME INSTALLATION MENU
The on-screen display will contain easy

4

instructions for setting up the unit (see
page 22 of the instruction manual).
Select the desired Language, Country and
Energy Model by using the
buttons on the remote control. Then press
the OK

button on the remote control to
initiate Auto Tuning. The TV will
automatically tune all the digital channels.

/ / /

1

6

8 11

TV

10

7

129

ANTENNA

You are now ready to start watching your
Signify® 4K Ultra HD LED LCD TV set.

5

Item Code: EA0815

AUS

1300 777 137 [e-mail]

NOTE: At this stage, TV programming in Australia is not available in 4K
Ultra HD. For instructions on how to watch

the instruction manual

.

www.signifyelectronics.com.au

4K Ultra HD

see page 52

of
