Signature Control Systems, Inc. EZ Pro Jr. ,8304,8374,8306,8376,8309,8379,8312,8382 Installation And Programming Manual
Remove
Here
Where do I leave
the LARGE dial?
Leave the dial on
TIME.
Date: July 2014
Revision No.: A
Q.
A.
10
How do I delete a
start time?
Set the Start Time at
12:00. With the 12
blinking, touch the
ADJUST one time.
Q.
A.
7
8
9
11
Part No.: 99903327
12
Jr. Instructions Zone Chart
™
Frequently Asked Questions
Please read before calling Customer Service.
EZ PRO
Does your system run
repeatedly?
Do NOT set a start time for
every zone. Only ONE start
time is necessary if the system
needs to run one time a day.
Q.
A.
EZ Pro™Jr. 8300 Series
Installation and Programming Guide
For EZ ProTMJr. models:
8304 8374
8306 8376
8309 8379
8312 8382
THANK YOU for purchasing the EZ Pro™Jr.
electronic irrigation controller. The EZ Pro™Jr. is so
"EZ", you’ll probably be able to install and program
this feature-packed controller without instructions.
However, before installing and programming the
controller, we recommend you read these instructions
carefully to take full advantage of all the EZ Pro™Jr.
has to offer.
If you have questions, problems or comments on your new
EZ Pro™ Jr., please call our Technical Services Department
toll-free at 1-866-4SIGNATURE, or by visiting us on our website at
www.SignatureControlSystems.com
NOTE: In our efforts to continually improve and update
our products, features and specifications in this
manual may change without notice.
3
Features 5
Installation 6-10
Terminal Strip 9
Connecting Master Valve or Pump-Start Relay 9
Connecting Rain/Moisture Sensor 9
Connecting Battery & Starting Controller 10
Programming the EZ Pro™Jr. 11-21
Programming Overview 11
Front Panel Layout 12-13
Set Time of Day 14
Set Today's Date 14
Set Current Day 14
Select Zones and Set Their Run Times 14
Set Start Times 15
Set % Water Budget 15-16
Set % Water Budget by Month 16
Scheduling 16-17
Set Water Days Scheduling Option 17
Set Odd/Even Day Scheduling Option 18
Set Interval Scheduling Option 18
Set Event Day Scheduling Option 19
Program Review 19
Set Master Valve or Pump 20
Set Rain Delay 20
Turning the Controller Off 21
Advanced Features 22-23
Run a Zone Manually 22
Run a Program Cycle Manually 23
Technical Data/Specifications 24-26
Troubleshooting/Service 27
FCC Rules 28
TABLE OF CONTENTS
FEATURES
• Lithium battery back-up stores programs without AC or
Battery power (AA)
• Programmable delay between zones
• Three independent programs
• Three start times per program (9 total starts)
• Stacking start times
• Three scheduling options to suit the needs of plant material or to
comply with watering restrictions (days of the week, 1-30 day
interval, true odd/even)
• Event days programming per program
• Rain Sensor bypass option
• Leap year compatible-automatically includes Feb 29th every
four years
• Water budget option reduces or increases watering 0-200 percent
• Advanced water budget to set water budget for each month
of the year
• Two test cycles (Manual with ManualAdvance feature and Cycle)
• Programmable run times from one minute to 1 hour 59 minutes
• Poly-fuse self resetting circuit protection
4 5
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
The EZ Pro™Jr. 8300 Series can be mounted indoors or outdoors.
Find a location near a 120V wiring source (230/240V for 8374, 8376,
8379, and 8382 models). Install the EZ Pro™Jr. near eye level if possible.
Wiring the Transformer
120 VAC in United States, Canada and Mexico; 230 VAC in Europe,
and 240 VAC in Australia and South Africa
NOTE: Refer to and follow local codes if different from these
instructions.
CAUTION: Disconnect 120V (230/240V for 8374, 8376, 8379, and 8382
models) power source before wiring transformer. Complete all
wiring and installation before connecting the transformer to
power source. This will avoid accidental shorting which could
damage the controller.
Power supply cables and cords used for connections are to be of
ordinary duty or greater. Low voltage output cables should be enclosed
in conduit affixed to the controller with a suitable adapter. Remove the
two screws and lift out the transformer cover to provide access to the
internal transformer, bring 120V (or 230/240 for 8374, 8376, 8379, and
8382 models) wires up through 1/2" conduit hole in the bottom of the
case. (For field connection, AC wires must have an insulation rated at
75° C minimum). Conduit should be secured to the case
(follow local codes).
For models 8304, 8306, 8309, 8312 (see figure 1)
Remove the transformer cover by loosening the two screws. Attach
AC wires to transformer wires using wire nuts. Also, ensure earth
ground wire is attached to green with yellow stripe ground wire.
Please check local codes for the grounding requirements in your area.
Bundle wire within cable tie loop and tighten cable tie to prevent loose
wiring from touching secondary circuits. The transformer is now
wired. Replace the transformer cover and the two screws.
DO NOT turn on power yet.
NOTE: Failure to ground unit properly may cause severe damage
to the controller and/or personal property and will void
warranty.
Figure 1
6 7
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
For models 8374, 8376, 8379, 8382 (see figure 2)
Remove the transformer cover by loosening the two screws. Route
AC wires to connector provided. Cut and trim wires to install in
chassis mount connector. Tighten the screws. (For Australia an extra
clamp has been provided.) Observe proper polarity of wires as you
install them (ie. L1, L2 and ground). The transformer is now wired.
Replace the transformer cover and the two screws. DO NOT turn on
power yet.
NOTE: Failure to ground unit properly may cause severe damage
to the controller and/or personal property and will void
warranty.
Figure 2
Terminal Strip
All zone, pump and sensor wire connections made inside the EZ Pro
Jr. utilize screw type connectors that require a small screwdriver. The
terminal strips in the controller accept 12 AWG (2.1mm) wire or
smaller.
Connecting Master Valve or Pump-Start Relay
The EZ Pro™Jr. is equipped with a shared circuit to operate either a
pump-start relay or a master valve. Connect one wire from the pumpstart relay to COM (common) on terminal strip, the other to PMP/MV
(pump/master valve) on the terminal strip. Refer to the pump-start
relay manufacturer’s instructions for specific installation details.
Connecting Rain/Moisture Sensor
The EZ Pro™Jr. is equipped to operate a sensor with normally-closed
leads. To install a sensor, remove the factory-installed jumper wire
from the sensor connector on the terminal strip and insert the sensor
wires. Refer to the sensor manufacturer’s instructions for specific
installation details.
(See figure 2)
If a sensor has suspended watering, the sensor indicator segment
will appear on the LCD. The symbol will go off when the sensor has
dried out. The EZ Pro™Jr. will resume operation based on the
selected program.
NOTE: Manual operations will ignore the rain sensor
™
8 9
