Sierra Wireless WMP100 User Guide

WA_DEV_WMPR_PTS_001

001

September 20, 2010

AirPrime WMP Series

User Guide (DRAFT)

User Guide

Important Notice

Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare when wireless devices such as the Sierra Wireless modem are used in a normal manner with a well-constructed network, the Sierra Wireless modem should not be used in situations where failure to transmit or receive data could result in damage of any kind to the user or any other party, including but not limited to personal injury, death, or loss of property. Sierra Wireless accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the Sierra Wireless modem, or for failure of the Sierra Wireless modem to transmit or receive such data.

Safety and Hazards

Do not operate the Sierra Wireless modem in areas where blasting is in progress, where explosive atmospheres may be present, near medical equipment, near life support equipment, or any equipment which may be susceptible to any form of radio interference. In such areas, the Sierra Wireless modem MUST BE POWERED OFF. The Sierra Wireless modem can transmit signals that could interfere with this equipment. Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED OFF. When operating, the Sierra Wireless modem can transmit signals that could interfere with various onboard systems.

Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door

is open. Sierra Wireless modems may be used at this time.

The driver or operator of any vehicle should not operate the Sierra Wireless modem while in control of

a vehicle. Doing so will detract from the driver or operator’s control and operation of that vehicle. In

some states and provinces, operating such communications devices while in control of a vehicle is an offence.

Limitations of Liability

This manual is provided “as is”. Sierra Wireless makes no warranties of any kind, either expressed or

implied, including any implied warranties of merchantability, fitness for a particular purpose, or noninfringement. The recipient of the manual shall endorse all risks arising from its use.

The information in this manual is subject to change without notice and does not represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.

Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates aggregate liability arising under or in connection with the Sierra Wireless product, regardless of the number of events, occurrences, or claims giving rise to liability, be in excess of the price paid by the purchaser for the Sierra Wireless product.

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 2

User Guide

Patents

Sales Desk:

Phone:

1-604-232-1488

Hours:

8:00 AM to 5:00 PM Pacific Time

E-mail:

sales@sierrawireless.com

Post:

Sierra Wireless 13811 Wireless Way Richmond, BC Canada V6V 3A4

Fax:

1-604-231-1109

Web:

www.sierrawireless.com

This product includes technology licensed from QUALCOMM® 3G. Manufactured or sold by Sierra Wireless Inc. or its Licensees under one or more patents licensed

from InterDigital Group.

Trademarks

AirCard® and Watcher® are registered trademarks of Sierra Wireless. Sierra Wireless™, AirPrime™, AirLink™, AirVantage™ and the Sierra Wireless logo are trademarks of Sierra Wireless.

, , ®, inSIM®, WAVECOM®, WISMO®, Wireless Microprocessor®, Wireless CPU®, Open AT® are filed or registered trademarks of Sierra Wireless S.A. in France and/or in other countries.

Windows® and Windows Vista® are registered trademarks of Microsoft Corporation. Macintosh and Mac OS are registered trademarks of Apple Inc., registered in the U.S. and other

countries. QUALCOMM® is a registered trademark of QUALCOMM Incorporated. Used under license. Other trademarks are the property of the respective owners.

Contact Information

Consult our website for up-to-date product descriptions, documentation, application notes, firmware upgrades, troubleshooting tips, and press releases: www.sierrawireless.com

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 3

User Guide

Document History

Version

Date

Updates

001

September 20, 2010

Creation

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 4

Contents

1. INTRODUCTION .................................................................................................. 9

1.1. Physical Dimensions ......................................................................................................... 9

1.2. GSM/GPRS/EDGE-RX Features ...................................................................................... 9

1.3. Interfaces ........................................................................................................................... 9

1.4. Operating System ............................................................................................................ 10

1.5. Connection Interfaces ..................................................................................................... 10

1.6. Environment and Mechanics ........................................................................................... 10

1.6.1. RoHS Directive Compliant ....................................................................................... 10

1.6.2. Disposing of the Product .......................................................................................... 10

2. FUNCTIONAL SPECIFICATIONS ...................................................................... 11

2.1. RF Functionalities ............................................................................................................ 11

2.2. Operating System ............................................................................................................ 11

3. TECHNICAL SPECIFICATIONS ................................................................ ........ 12

3.1. Power Supply .................................................................................................................. 12

3.2. Mechanical Specifications ............................................................................................... 13

3.3. Physical Characteristics .................................................................................................. 13

3.3.1. Mechanical Drawings for the WMP100 and WMP150 ............................................. 13

4. INTERFACES ..................................................................................................... 18

4.1. Ball Grid Array Pin Description ........................................................................................ 18

4.2. RF Interface ..................................................................................................................... 25

4.2.1. RF Connections ....................................................................................................... 25

4.2.2. Antenna Specifications ............................................................................................. 25

5. CERTIFICATION COMPLIANCE AND RECOMMENDED STANDARDS ......... 26

5.1. Certification Compliance ................................................................................................. 26

5.2. Applicable Standards Listing ........................................................................................... 26

6. REFERENCES ................................................................................................... 28

6.1. Web Site Support ............................................................................................................ 28

6.2. Reference Documents ..................................................................................................... 29

6.2.1. Sierra Wireless Reference Documentation .............................................................. 29

6.2.2. General Reference Documentation ......................................................................... 29

6.3. List of Abbreviations ........................................................................................................ 30

7. SAFETY RECOMMENDATIONS (FOR INFORMATION ONLY) ....................... 33

7.1. RF Safety ......................................................................................................................... 33

7.1.1. General Information ................................................................................................. 33

7.1.2. Exposure to RF Energy ............................................................................................ 33

7.1.3. Efficient Terminal Operation..................................................................................... 33

7.1.4. Antenna Care and Replacement .............................................................................. 33

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 5

User Guide

7.2. General Safety................................................................................................................. 34

7.2.1. Driving ...................................................................................................................... 34

7.2.2. Electronic Devices .................................................................................................... 34

7.2.3. Vehicle Electronic Equipment .................................................................................. 34

7.2.4. Medical Electronic Equipment .................................................................................. 34

7.2.5. Aircraft ...................................................................................................................... 34

7.2.6. Children .................................................................................................................... 35

7.2.7. Blasting Areas .......................................................................................................... 35

7.2.8. Potentially Explosive Atmospheres .......................................................................... 35

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 6

List of Figures

Figure 1. Mechanical Drawing of WMP100 (Bottom View) ............................................................ 14

Figure 2. Mechanical Drawing of WMP100 (Top View) .................................................................. 15

Figure 3. Mechanical Drawing of WMP150 (Bottom View) ............................................................ 16

Figure 4. Mechanical Drawing of WMP150 (Top View) .................................................................. 17

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 7

List of Tables

Table 1. List of RF Frequency Ranges .......................................................................................... 11

Table 2. Input Power Supply Voltage ............................................................................................ 12

Table 3. Maximal Voltage Ripple (Uripp) Versus Frequency ........................................................ 12

Table 4. Mechanical Difference of WMP modules ........................................................................ 13

Table 5. WMP Series Pin Description ........................................................................................... 18

Table 6. Antenna Specifications .................................................................................................... 25

Table 7. Standards Conformity for the WMP Series Embedded Module ...................................... 26

Table 8. Applicable Standards and Requirements for the WMP Series Embedded Module ........ 26

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 8

1. Introduction

The AirPrime WMP50/100/150 and WMP100ESIM/150ESIM Intelligent Embedded Modules are selfcontained E-GSM/GPRS 900/1800 and 850/1900 quad-band embedded modules. In addition, they are EDGE-Rx capable except for the WMP50.

1.1. Physical Dimensions

 Length: 25 mm  Width: 25 mm  Thickness: 3.65 mm for WMP50, WMP100, and WMP100ESIM

3.78 mm for WMP150 and WMP150ESIM

 Weight: 4.25 g

1.2. GSM/GPRS/EDGE-RX Features

 2 Watts EGSM 900/GSM 850 radio section running under 3.6 Volts  1 Watt GSM1800/1900 radio section running under 3.6 Volts  Hardware GPRS class 10 capable  Hardware EDGE-Rx class 10 capable

1.3. Interfaces

 Digital section running under 2.8 Volts and 1.8Volts.  3V/1V8 SIM interface  1.8V Parallel interface for devices (memories, LCD, etc.)  Power supplies  Watchdog  Serial links (UART)  Analogue audio  ADC / DAC  PCM digital audio  Keyboard  USB 2.0 slave  Serial buses (I2C, SPI)  PWM (BUZZER)  GPIOs  SIM (external SIM and optional embedded SIM)

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 9

User Guide

Introduction

1.4. Operating System

The WMP Series modules are compliant with RoHS Directive 2002/95/EC which sets limits for the use of certain restricted hazardous substances. This directive states that

“from 1st July 2006, new electrical and electronic equipment put on the market does

not contain lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE)”.

This electronic product is subject to the EU Directive 2002/96/EC for Waste Electrical and Electronic Equipment (WEEE). As such, this product must not be disposed off at a municipal waste collection point. Please refer to local regulations for directions on how to dispose of this product in an environmental friendly manner.

 Real Time Clock with calendar  Echo Cancellation + noise reduction (quadri codec)  Full GSM or GSM/GPRS/EDGE-Rx Operating System stack

1.5. Connection Interfaces

The WMP series embedded module has a ball grid array pin out that includes:

 An RF connection  Baseband signals connection

1.6. Environment and Mechanics

1.6.1. RoHS Directive Compliant

1.6.2. Disposing of the Product

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 10

2. Functional Specifications

RF Bandwidth

Transmit band (Tx)

Receive band (Rx)

GSM 850

824 to 849 MHz

869 to 894 MHz

E-GSM 900

880 to 915 MHz

925 to 960 MHz

DCS 1800

1710 to 1785 MHz

1805 to 1880 MHz

PCS 1900

1850 to 1910 MHz

1930 to 1990 MHz

2.1. RF Functionalities

The Radio Frequency (RF) range complies with the Phase II EGSM 900/DCS 1800 and GSM 850/PCS 1900 recommendation. The frequencies are listed in the table below.

Table 1. List of RF Frequency Ranges

The RF part is based on a specific quad band chip including:

 a Digital low-IF receiver  a Quad-band LNAs (Low Noise Amplifier)  an Offset PLL (Phase Locked Loop) transmitter  a Frequency synthesizer  a Digitally controlled crystal oscillator (DCXO)  a Tx/Rx FEM (Front-End Module) for quad-band GSM/GPRS/EDGE-Rx

2.2. Operating System

The AirPrime WMP Series embedded module is Sierra Wireless Software Suite compliant. With the Sierra Wireless Software Suite and the AirPrime WMP Series embedded module, customers can embed their own applications with the AirPrime WMP and turn the WMP Series embedded module into a solution for their specific market need.

The operating system allows for the AirPrime WMP Series embedded module to be controlled by AT commands. However, some interfaces in the AirPrime WMP Series embedded module may still not be available even with AT command control as these interfaces are dependent on the peripheral devices connected to the AirPrime WMP Series embedded module.

WA_DEV_WMPR_PTS_001 Rev 001 September 20, 2010 11
