AirLink LX40 Datasheet
Sierra Wireless EMBEDDED MODULES HL SERIES
AirLink® LX40 LTE Router
BENEFITS
Out-of-Box LTE Connectivity: Add
LTE connectivity to your existing
equipment
150 Mbps LTE with optional
Wi-Fi, plus LTE-M/NB-IoT version
with extended coverage and
reach for challenging locations
Enables edge processing with
secure embedded application
framework (ALEOS Application
Framework)
Integrated 7-36VDC industrial
grade power supply and –30C
to +65C temperature range
to provide superior reliability
without need for additional power
conditioning or adapters
Power-over-Ethernet powered
device (PD) for fixed low power
applications
ALMS Cloud or AMM On-Premises
Management single pane device
management across all devices
Compact LTE Router for IoT Applications
The AirLink® LX40 is a compact LTE and LTE-M / NB-IoT router for IoT/M2M
applications, offering “out-of-the box” connectivity that is simple to install, and easy
to manage.
LX40 provides purpose-built, secure, managed LTE networking for applications such
as Camera, Security, Point-of-Sale terminals and Smart Lockers. LX40 is also ideal
for connecting industrial, remote data logging and sensing equipment in protected
(indoor) locations, and enables processing of IoT data at the edge.
As part of the AirLink Essential series, the LX40 is designed to meet the
environmental and performance requirements of these applications, while
delivering superior reliability and uninterrupted operation in fixed, indoor and
protected outdoor environments.
LX40 is available with optional Wi-Fi with Dual Band 802.11ac to provide an access
point or to connect to local Wi-Fi networks.
Purpose-Built, Secure, Reliable, Managed Cellular
LTE Networking
IDEAL APPLICATIONS
Primary cellular connectivity for:
IoT/M2M
Camera, Security
Digital Signage
Building Automation
ATMs, Kiosks, Point of Sale,
Lottery
Smart Lockers
Industrial Process Automation
Application Example - Digital Signage
sierrawireless.com/LX40
AirLink® LX40
LTE Router
LTE CATEGORY
Peak D/L
Peak U/L
4G LTE
Frequency Bands
LX40
North America
Verizon
Cat 4 Cat 4 Cat 4 Cat 4 Cat M1/NB1
Up to 150 Mbps Up to 150 Mbps Up to 150 Mbps Up to 150 Mbps Cat-M1: 300kbps
Up to 50 Mbps Up to 50 Mbps Up to 50 Mbps Up to 50 Mbps Cat-M1: 375kbps
AWS(B4), 700(B13) 1900(B2), AWS(B4),
North America
AT&T/Generic
850(B5), 700(B12)
EMEA
2100(B1), 1800(B3), 2600(B7),
900(B8),
800(B20), 700(B28)
Australia & New
Zealand
2100(B1), 1800(B3),
850(B5), 2600(B7),
900(B8),
700(B28)
Global
LTE-M/NB-IoTLTE
Cat-NB1: 27kbps
Cat-NB1: 65kbps
2100(B1), 1900(B2),
1800(B3), AWS(B4),
850(B5), 900(B8), 700(B12),
700(B13), 700(B17), 850
(B18), 850(B19), 800(B20),
850(B26),700(B28)
3G WCDMA/HSPA+
Frequency Bands
2G GSM/GPRS
Frequency Bands
APPROVALS
Regulatory
Carrier
PART NUMBERS
HOST INTERFACES
WI-FI (Optional)
INPUT/OUTPUT
LAN (ETHERNET/USB)
NETWORK AND ROUTING
1900(B2), AWS(B4),
850(B5)
FCC FCC, IC, PTCRB
Verizon AT&T
1104176 1104178 1104181 1104183 1104180
1104177 (Wi-Fi) 1104179 (Wi-Fi)
T-Mobile USA
Specification
1 Gigabit RJ-45 Ethernet Port
USB 2.0 Micro-B Connector
2 SMA antenna connectors (cellular, diversity), 1 SMA for
LTE-M version
1 RP SMA antenna connector (1x1 MIMO Wi-Fi)
Dual Band 2.4/5GHz Wi-Fi
802.11 b/g/n/ac (Wave2 Client Mode)
Support for 10 clients, WPA2 Enterprise
Output power 16dBm per channel
Access Point or Client Mode (Wi-Fi as WAN)
Single SSID Support
Captive Portal
Configurable I/O pin on power connector
Digital Inputs: ON Voltage: 2.7 to 36 VDC
Configurable Pull-ups for dry contact input
Digital Open Collector Output > sinking 500 mA
Analog Inputs: 0.5-36VDC (range selectable)
DHCP Server
IP Passthrough
VLAN
Host Interface Watchdog
PPPoE
Network Address Translation Ethernet WAN
Port Forwarding Verizon PNTM
NEMO/DMNR IPv6 Gateway
VRRP Policy Routing
Reliable Static Route Dynamic DNS
2100(B1), 900(B8) 2100(B1), 850(B5), 900(B8)
900, 1800 850, 900, 1800, 1900
GCF, CE
1104182 (Wi-Fi) 1104184 (Wi-Fi)
GCF, RCM PTCRB, FCC, GCF, IC
Planned: Telstra Planned: Verizon, AT&T
T-Mobile USA
Specification
SECURITY
NETWORK
MANAGEMENT
EVENTS ENGINE
ENVIRONMENTAL
Remote Authentication (LDAP, RADIUS, TACACS+) DMZ
Inbound and Outbound Port filtering
Inbound and Outbound Trusted IP
MAC Address Filtering
PCI compatible
Secure Firmware Update
Secure mobile network & asset management application
available in the cloud or licensed platform in the enterprise
data center
Fleet wide firmware upgrade delivery
Router configuration and template management
Router staging over the air and local Ethernet connection
Over-the-air software and radio module firmware updates
Device Configuration Templates
Configurable monitoring and alerting
Remote provisioning and airtime activation (where
applicable)
Custom event triggers and reports
Configurable interface, no programming
Event Types: Digital Input, Network Parameters, Data Usage,
Timer, Power, Device Temperature and Voltage Report Types:
RAP, SMS, Email, SNMP Trap, TCP (Binary, XML, CSV)
Event Actions: Drive Relay Output
Operating Temperature: -30°C to +65°C / -22°F to
+149°F (+60°C / +140°F when using PoE)
Storage Temperature: -40°C to +85°C / -40°F to
+185°F
Humidity: 90% RH @ 60°C
Military Spec MIL-STD-810G conformance to shock,
vibration, thermal shock, and humidity
IP21 rated ingress protection
