1: Introduction
The mangOH Red open-source hardware development platform for CF3 modules incorporates several hardware
interfaces and a standardized IoT Expansion Card slot for expanded functionality.
This developer’s guide describes the mangOH Red’s architecture and provides details on how to develop
applications for CF3 modules.
For the full mangOH Red documentation suite, refer to mangoh.io/mangoh-red-resources.
1
Rev 4 May.18 6 41110401
2: Hardware
CF3 Module
SDIO
Wi-Fi/BT
chipset
IoT
Connector
microSD
/uSIM
Holder
ESIM
Main
Diversity
GPS
Wi-Fi + BT
LEDs
3.7V @ 1000mA
Power_ON
Reset
Audio
uUSB
Connector
uUSB
Connector
Type A
USB Connector
Low
Power I/O
Real-time
I/O
Generic
button
Raspberry Pi
Connector
DNI
Integrated
u.FL
Gyroscope /
Accelerometer
Pressure /
Temperature
Sensor
Light Sensor
This chapter describes the mangOH Red platform’s hardware components and interfaces.
2.1 mangOH Red Hardware Overview
Figure 2-1 provides an overview of the mangOH Red’s hardware components relative to the CF3 module, and
Figure 2-2 on page 8 and Figure 2-3 on page 9 show their physical locations.
For additional details, see the following documents:
• Available at mangoh.io/mangoh-red-resources:
· mangOH Red User Guide— Instructions on setting up the hardware components
• Available at source.sierrawireless.com:
· Sierra Wireless CF3 module-specific Product Technical Specification documents
· AirPrime Embedded Module Common Flexible Form Factor (CF3) Specification
2
Figure 2-1: mangOH Red Hardware Components Overview
Rev 4 May.18 7 41110401
mangOH Red Developer’s Guide
1—Pluggable IoT connector
2—Power supply select (CN804)
3—Battery connector (CN802)
4—Signals control (SW401)
5—Main antenna (CN301)
6—GNSS antenna (CN303)
7—Diversity antenna (CN302)
8—Wi-Fi/Bluetooth antenna
9—USB Host (CN304)
10—Audio (CN500)
11—µUSB Console connector
12—Raspberry PI RevB-compatible
13—Generic button (SW200)
1
4
2
11
13
14
9
8
12
14—PWR_ON switch (SW402)
3
1015
6 5
15—Reset switch (SW400)
16—CF3 module socket (J200)
header (CN307)
7
(ANT1000)
(CN305)
16
17—Real Time I/O (CN310)
18—Low Power I/O (CN312)
18
17
(CN306 (IOT0))
Figure 2-2: mangOH Red—Top Side Switches/Connectors
Note: For reference only. For latest schematic, visit mangoh.io/mangoh-red-resources-hardware.
Rev 4 May.18 8 41110401
Hardware
1—µUSB CF3 connector
2—micro-SIM
3—microSD
4—ESIM (U603 (DNI))
1
2
3
4
(CN600, bottom slot)
(CN600, top slot)
(CN801)
5
5—Wi-Fi/BT chipset
(U1000)
6—Integrated
(ANT1000)
7
6
7—Wi-Fi/Bluetooth antenna
(CN1000 (DNI))
Wi-Fi/Bluetooth antenna
Figure 2-3: mangOH Red—Bottom Side Switches/Connectors
Note: For reference only. For latest schematics, visit mangoh.io/mangoh-red-resources-hardware.
Rev 4 May.18 9 41110401
mangOH Red Developer’s Guide
2.2 mangOH Red Hardware Architecture
The mangOH Red platform provides several hardware components, including:
• CF3 module socket
• Wi-Fi/BT chipset (MediaTek Wi-Fi+Bluetooth)
• Pluggable IoT Connector (socket for IoT Expansion Card)
• Raspberry Pi Rev B-compatible 26-pin connector
• Several I/O connectors (SIM, SD, Audio, USB, etc.)
Figure 2-4 illustrates the mangOH Red’s hardware architecture (connectors and signals). The following sections
describe these features in greater detail:
• mangOH Red Hardware Components on page 12—Components available to the CF3 module and Wi-Fi/BT
chipset.
• CF3 Module Signals on page 17— CF3 module connections to hardware components.
• Wi-Fi/BT Chipset on page 28—Wi-Fi/BT chipset connections to hardware components.
• IoT Connector Interfaces on page 31— IoT Expansion Card signal connections to the hardware components.
Rev 4 May.18 10 41110401
This section (Wi-Fi/BT UART1) is only available
when an HL CF3 module is installed.
Power Section
UART2
CF3 Smart
HSIC
USB3503
SPI1
MASTER
SDIO
uSD
HOLDER
Ctrl
GPIO
Iot con #0
I2C
HUB
I2C
4xGPIO
UART1
SDIO
MUX
I2C
HSIC UP
USB DW USB DW
GPIO
USB
TypeA
USB to
UART
FTDI
USB to SPI
Wi-Fi/BT
chipset
HSIC
MAIN
USB 2.0
I2C1
GPS
Battery
Charger
PowerOn,
Reset,
Generic
button
PCM
Audio
MUX
Analog
Codec
uUSB-1
Battery
Input
PSU 1V8
PSU 3V3
PSU 5V0
switch
Physical
switches
uUSB-2
Gyroscope /
Accelerometer
SX1509
GPIO
Battery
Gauge
SIM 2
Raspberry Pi
Signals
ESIM
SIM 1
SIM
HOLDER #1
SPI_MRDY (GPIO32)
SPI_CLK (GPIO27)
SPI_MISO (GPIO30)
SPI_MOSI (GPIO29)
USB DW
SPI
UART1
UART1_RTS (GPIO38)
UART1_CTS (GPIO39)
UART1_RX (GPIO36)
UART1_TX (GPIO37)
Real
Time
IO
DIV
UART2
UART
Mux
26 pin Rpi
Low Power IO
CN312
CN310
Pressure /
Temperature
Sensor
Level Shifter
WiFi/BT
ADC3
Light Sensor
Various
signals
Multi-function
switch
Integrated
u.FL (DNI)
3.5mm
Jack
ADC0
Default Hardware Configuration
26 MHz XTAL
Hardware
Figure 2-4: mangOH Red Hardware Architecture (Default)
Rev 4 May.18 11 41110401
mangOH Red Developer’s Guide
2.2.1 mangOH Red Hardware Components
Key mangOH Red hardware components and their connections to the CF3 module and/or Wi-Fi/BT chipset are
listed in Table 2-1 on page 12.
The mangOH Red’s default configuration enables specific interfaces when the platform boots. For interface details,
see:
• MUXing on page 17
• CF3 Module Signals on page 17
• Wi-Fi/BT Chipset on page 28
• IoT Connector Interfaces on page 31
• Reset Methods on page 32
• Power Management on page 32
Table 2-1: mangOH Red Hardware Components
Type and
Designator
Modules/Processors/etc.
CF3 module
(J200)
IOT0
(CN306)
Wi-Fi/BT chipset
(U1000)
Card slots
Micro-SIM
(CN600)
micro-SD
(CN600)
ESIM
(U603)
a
Description Signals / Module Pins Notes
IoT Expansion
Card
MediaTek Wi-Fi/
BT chipset with
ARM Cortex-M4
application
processor
Micro-SIM/
microSD holder
(bottom slot)
Micro-SIM/
microSD holder
(top slot)
Embedded SIM
For details, see CF3 Module Signals on page 17.
Connections to multiple CF3
module interfaces.
For details, see Wi-Fi/BT Chipset on page 28.
CF3 UIM1
(Pins: 26–29)
CF3 SDIO
(Pins: 161–166)
CF3 UIM2
(Pins 55–58)
For details, see IoT Expansion Card on page 15.
Purpose: UIM used to establish mobile network
connection.
For details, see UIM1 on page 27.
Purpose: Provide access to microSD card.
For details, see:
• SDIO on page 24
• MUXing on page 17
Purpose: Built-in UIM used to establish mobile network
connection.
For details, see UIM2 on page 28.
Note: eSIM is DNI.
Rev 4 May.18 12 41110401
Table 2-1: mangOH Red Hardware Components (Continued)
Hardware
Type and
Designator
USB-type connectors
micro-USB
(CN801)
micro-USB
(CN305)
USB Host
(CN304)
RF, Audio, Raspberry Pi connectors
RF Antennas
Main (CN301)
GNSS (CN303)
Diversity (CN302)
a
Description Signals / Module Pins Notes
CF3 USB
micro-USB
connector
Console USB
micro-USB
connector
USB Type A
connector
u.FL connectors
• USB
(Pins: 12, 13, 16)
• Power (if selected)
• UART2 (Pins: 96–99)
• Power (if selected)
HSIC
(Pins: 14, 15)
CF3 RF
(Pins: 49 (Main), 38 (GNSS),
31 (Diversity))
Purpose:
• Direct connection to CF3 USB
• Power supply when selected by the Power Supply
Selection Jumper (CN804). See mangOH Red
User Guide for details.
For details, see USB 2.0 on page 28.
Purpose:
• Console—Connects to CF3 module console or
Wi-Fi/BT chipset console
• Power supply when selected by the Power Supply
Selection Jumper (CN804). See mangOH Red
User Guide for details.
For details, see UART2 on page 26.
Purpose: Provides USB host capability to CF3 module.
For details, see HSIC (USB/ Ethernet) on page 20.
For details, see RF on page 24.
Wi-Fi/Bluetooth
Antennas
(Integrated—
ANT1000;
u.FL— CN1000
(DNI))
Audio
(CN500)
Raspberry Pi
(CN307)
Other ICs and components
Gyroscope/
Accelerometer
(U704)
Antenna Wi-Fi/BT chipset RF For details, see Wi-Fi/BT Chipset on page 28.
3.5 mm
connector
26-pin
Rev B-compatib
le connector
Integrated
BMI160 inertial
measurement
module
CF3 digital audio signals
(Pins: 30–33)
• CF3 HSIC signals (via
SPI or USB (DNI))
• Wi-Fi/BT chipset SPI
CF3 I2C1 interface
Purpose: Provide audio capability to CF3 module.
For details, see:
• Audio (Analog and PCM) on page 18
• MUXing on page 17
For details, see Raspberry Pi Rev B-compatible
Connector on page 22.
Purpose: Provides rotational, linear motion, and
gravitational force measurements for use in (for
example) gaming, mapping, navigation, and optical
image stabilitization applications.
For details, see I2C1 on page 21.
Rev 4 May.18 13 41110401
mangOH Red Developer’s Guide
Table 2-1: mangOH Red Hardware Components (Continued)
Type and
Designator
Pressure sensor/
Temperature
sensor (U705)
Light sensor
(U706)
GPIO/PWM
expander
(U1004)
Low Power I/O
connector
(CN312)
Real-time I/O
connector
(CN310)
a
Description Signals / Module Pins Notes
Integrated
BMP280
barometric
pressure sensor
Integrated
PNJ4K01F
ambient light
sensor
Integrated
SX1509
expander
CF3 I2C1 interface
CF3 ADC3
CF3 I2C1 interface
Purpose: Provides barometric pressure, altitude, and
temperature measurements for use in (for example)
GPS navigation, indoor/outdoor navigation, and
weather forecasting applications.
For details, see I2C1 on page 21.
Purpose: Provide ambient light measurements for use
in (for example) brightness control systems.
For details, see Raspberry Pi Rev B-compatible
Connector on page 22.
Purpose: Provides additional GPIOs.
For details, see:
• GPIO Expander on page 20
• I2C1 on page 21
6-pin header
6-pin header
CF3 ADC1/ ADC2
CF3 GPIOs (if resistors are
populated)
CF3 UIM2_DET
Wi-Fi/BT chipset userconfigurable multi-purpose
pins (for ADC, GPIO, PWM,
I2C, etc.)
Purpose: Connect low-power input sources to CF3
module.
For details, see ADC on page 17.
Purpose: Connect input sources to Wi-Fi/BT chipset for
use by its real-time application processor.
(Multi-purpose pin details forthcoming.)
For details, see Wi-Fi/BT Chipset on page 28.
LEDs
IoT Expansion
Card 0
(D401)
Rx/Tx (CF3
module)
(D402)
WLAN
Connected
(D200)
VCC_3V3 (D803) Green LED VCC_3V3 Purpose: Indicates device is powered on.
Generic (userdefined)
(D410)
Green LED
Green LED CF3 TX_ON
Green LED CF3 WWAN_LED_N
Green LED
GPIO expander I/O_8 via
LED_CARD_DETECT_IOT0
CF3 GPIO34 (via expander
WP_GPIO_7_lvl)
Purpose: Indicates IoT Expansion Card is in slot IOT0.
Purpose: Indicates CF3 module is transmitting /
receiving.
Purpose: Indicates device is connected to a WLAN (will
be OFF when LowPower Mode is enabled).
Purpose: User-defined (programmable)
Rev 4 May.18 14 41110401
Table 2-1: mangOH Red Hardware Components (Continued)
Hardware
Type and
Designator
Platform controls
Multi-switch
(SW401)
a
Description Signals / Module Pins Notes
Eight dipswitches:
1. PWR_ON Enable/disable CF3 module’s POWER_ON signal
Enable (On)/disable (Off) firmware download (recovery
2. WIFI_UART1_TX
3. VCC_3V7_ULPM
mode) to the CF3 module. Similar functionality to
TP1_BOOT.
When device is in ULPM:
• OFF—only the CF3 module is receiving power.
• ON—the CF3 module + accessories receive
power
Used with pin 8 (LowPower_RESET) to indicate
4. HL_MODE
whether in HL mode or WP mode
• ON—HL mode
• OFF—WP mode
Module signals
control
5. BATT_TS+ Enable (On)/disable (off) battery charging
Console USB connectors connects to:
• OFF—CF3 module console
• ON—Wi-Fi/BT chipset console
6. CONS_DIR
Note: To download firmware to the:
• CF3 module— Set CONS_DIR Off and TP1_BOOT
On.
• Wi-Fi/BT chipset—Set CONS_DIR On and
WIFI_UART_TX On.
7. TP1_BOOT
8. LowPower_RESET
Enable (On)/disable (Off) CF3 module’s TP1 (boot)
signal.
Used with pin 4 (HL_MODE) to indicate whether in HL
mode or WP mode
• ON—WP mode
• OFF—HL mode
For details, see Power Management on page 32.
a. Board designators (e.g. CN311, SW401, etc.) are for reference against the published mangOH Red schematic. For component
locations on the board, see Figure 2-2 on page 8 and Figure 2-3 on page 9.
2.2.1.1 IoT Expansion Card
mangOH Red includes one IoT Expansion Card slot (IOT0), which has an IoT Connector (CN306) that connects to
the CF3’s signals as detailed in Table 2-2.
This slot provides full support for the IoT Expansion Card specification.
By default, specific signals are enabled when the mangOH Red boots. For additional information, including default
configuration and how to temporarily change it, see IoT Connector Interfaces on page 31.
Rev 4 May.18 15 41110401
mangOH Red Developer’s Guide
For detailed specifications, see the Project mangOH IoT Expansion Card Design Specification available at
mangoh.io/iot-card-resources-documentation.
Table 2-2: IoT Expansion Card Signal Connections to CF3 Module
IoT
Signals
USB
UART
SPI
I2C
GPIOs 1–4
SDIO
CF3 Signal(s)
HSIC
(Pins 14, 15)
UART1
(Pins 2, 9)
SPI1
(Pins 51–54)
I2C1
(Pins 1, 66)
GPIO
(7, 8, 13, 42)
SDIO
(Pins 161–166)
Single
MUX
Yes
Hub
Single
Yes
NotesSignal Path
Purpose: Data transfer; application control
For details, see HSIC (USB/Ethernet) on page 20.
Purpose: Data transfer
For details, see:
• UART1 on page 25
• MUXing on page 17
Purpose: Data transfer
For details, see:
• SPI1 on page 25
• MUXing on page 17
Purpose: Data transfer (standard mode). Higher speeds possible if
supported by host application.
For details, see I2C1 on page 21.
Purpose: Customer-defined data communication
For details, see CF3 GPIOs on page 18.
Purpose: Data transfer
For details, see:
• SDIO on page 24
• MUXing on page 17
Purpose: General purpose ADC output to host application (e.g. indicate
when a sensor has triggered)
For details, see ADC on page 17.
Default configuration—Receives three power inputs:
ADC0
ADC0
(Pin 25)
Single
• 5.0V @ 500 mA
Power Power n/a
• 3.3V @ 1 A
• 1.8V @ 200 mA
For details, see Power Management on page 32.
PCM PCM Single Purpose: Digital audio interface
RESET_IOT0 GPIO2
PPS DR_SYNC
CARD_DETECT_IOT0 GPIO33
Purpose: Data transfer
For details, see CF3 GPIOs on page 18.
Purpose: Clock signal used to manage timing for sensor nodes (or other
devices) that are connected to the expansion card.
The signal is a stratum 1 clock input from the host application, where the
host application operates as a stratum 1 time source connected to GPS (a
stratum 0 source).
Purpose: Data transfer
For details, see CF3 GPIOs on page 18.
Rev 4 May.18 16 41110401
Hardware
CF3
ADC0
IoT Connector #0
(CN306, slot IOT0)
ADC0
ADC1
Low Power I/O
(CN312)
ADC2
ADC3
Light sensor
(U706)
2.3 MUXing
Several interfaces use MUXing (simple switches) to associate multiple hardware connectors with a single signal
from the CF3 module, or multiple signals with a single hardware connector.
The following sections describe these MUX implementations
• MUX
· Audio (Analog and PCM) on page 18
· SDIO on page 24
· UART2 on page 26
• Hubs
· HSIC (USB/Ethernet) on page 20
· I2C1 on page 21
2.4 CF3 Module Signals
This section describes how CF3 module signals connect to the platform hardware (described in mangOH Red
Hardware Components on page 12).
Important: CF3 module signal availability depends on the module type—some modules may not implement certain
Extension signals from the CF3 specification.
2.4.1 ADC
The mangOH Red supports four CF3 module ADC (Analog to Digital converter) signal sources (ADC0-ADC3).
The ADC signals connect to the following sources, as shown in Figure 2-5:
• ADC0—IoT Connector 0 (CN1000, slot IOT0), pin 20
• ADC1, ADC2—Low Power I/O (CN312), pins 4 and 5
• ADC3—Light sensor (U706), pin 6
Figure 2-5: ADC Configuration
Rev 4 May.18 17 41110401
mangOH Red Developer’s Guide
CF3 PCM
DigitalAnalog
Codec
3.5mm
Jack
(CN500)
IoT Connector #0
(CN306, slot IOT0)
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Mux
2.4.2 Audio (Analog and PCM)
The mangOH Red supports the CF3 module PCM (digital) audio signals. The signals connect via a Mux (analog
switch) to the following sources, as shown in Figure 2-6:
• 3.5 mm analog audio jack (Default configuration)
• IoT connector (Alternate configuration)
The audio interface configuration can be modified as described in Table 2-3.
Table 2-3: Audio Interface Configuration Changes
Change type Change effect Method Change duration
Hardware Mux—Use default or
alternate configuration
Figure 2-6: Audio Configuration
2.4.3 CF3 GPIOs
Populate/depopulate resistors on the
Mux:
• R508 pulls signal low (default
configuration)
• R520 pulls signal high (alternate
configuration)
Selected configuration used every
time device boots up.
The mangOH Red supports several CF3 module GPIOs, as shown in Figure 2-7.
Notes:
• Six GPIOs connect to the IoT slot (for card detect, card reset, and four for use as GPIOs).
• One GPIO (GPIO32) connects to the NINT (active low interrupt) output signal from a GPIO expander (U1004).
Note: The mangOH Red uses a GPIO expander for additional I/O functions. See GPIO Expander on page 20.
Rev 4 May.18 18 41110401
Hardware
CF3
GPIO42
GPIO13
GPIO7
GPIO8
IoT Connector #0
(CN306, slot IOT0)
IOT0_GPIO1
IOT0_GPIO2
IOT0_GPIO3
IOT0_GPIO4
GPIO33
GPIO2
CARD_DETECT_IOT0
RESET_IOT0
SW401
GPIO6 LowPower_RESET
Level Shifter (U307)
GPIO25 RESET_WIFI_1V8 RESET_WIFI_3V3
GPIO Expander (U1004)
GPIO32 NINT
GPIO21
Low Power I/O (CN312)
GPIO36 WP_GPIO_5_wakeable
GPIO22
Raspberry Pi
Connector
(CN307)
WP_GPIO_1_lvl
Level Shifter (U306)
WP_GPIO_1
GPIO23 WP_GPIO_2_lvl
WP_GPIO_2
GPIO24 WP_GPIO_3_lvlWP_GPIO_3
EXT_GPS_LNA_EN PWM_OUT_3V3
PWM_OUT
GPIO35 WP_GPIO_8_lvlWP_GPIO_8
LED
(D410)
GPIO34 WP_GPIO_7
Wi-Fi module
(U1000)
SYS_RST_N
GPIO59
SPI2_SRDY
_WIFI_1V8
SPI2_SRDY
_WIFI_3V3
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Figure 2-7: GPIO Configuration
Rev 4 May.18 19 41110401
mangOH Red Developer’s Guide
2.4.4 GPIO Expander
The mangOH Red includes one SX1509 16-channel GPIO/PWM expander (U1004), as detailed in Table 2-4. The
expander provides additional GPIOs (carried over the CF3 module’s I2C1 interface) that are used for internal I/O
functions such as driving LEDs, resetting board components, etc.
For detailed specifications, see the mangOH Red schematics at mangoh.io/mangoh-red-resources-hardware.
Table 2-4: GPIO Expander (U1004) Signals
Pin Signal Name Purpose
I/O 0 BOARD_REV1 Reserved for future use.
I/O 1 BOARD_REV2 Reserved for future use.
I/O 2 BOARD_REV3 Reserved for future use.
I/O 3 GPIO_EXP_RPI_1 Raspberry Pi connector, pin 16
I/O_4 GPIO_EXP_RPI_2 Raspberry Pi connector, pin 18
I/O_5 MTK_TO_WP_UART_EN
I/O_6 WIFI_UART1_TX
I/O_7 GPIO_EXP_RPI_3 Raspberry PI connector, pin 22
I/O_8 LED_CARD_DETECT_IOT0 Indicates whether IoT expansion card is present
I/O_9 SDIO_SEL Connect SD interface to IoT0 (0) or SD card (1)
I/O_10 Power_Fail_Indicator Indicate power fail
I/O_11 SENSOR_INT1 Accelerometer/gyroscope sensor interrupt
I/O_12 SENSORT_INT2 Accelerometer/gyroscope sensor interrupt
I/O_13 PCM_EXP1_SEL Connect PCM interface to IoT0 or to PCM codec (audio)
I/O_14 Generic_Push_Button SW200 generic pushbutton
I/O_15 CONS_DIR
Enable MTK recovery mode from WP (0), or connects CF3 UART1 to
Wi-Fi/BT chipset UART0 (1)
Wi-Fi/BT chipset UART Tx—Normal (0), or MTK recovery mode (1) for
firmware downloads/ recovery
(Note: DNI—R754 must be populated to access this signal.)
Use with MTK_TO_WP_UART_EN to choose UART source -- CF3
module or Wi-Fi/BT chipset
2.4.5 HSIC (USB/ Ethernet)
The mangOH Red supports CF3 module HSIC signals, which connect through a USB hub controller to the
following sources, as shown in Figure 2-8:
• SPI interface:
· Wi-Fi/BT chipset (U1000) and Raspberry Pi Connector (CN307), via USB to SPI bridge (U1006).
Note: The Wi-Fi/BT chipset uses SPI2_CS0, and Raspberry Pi conn ector uses SPI2_CS1/SPI2_CS2.
Rev 4 May.18 20 41110401
• USB interface:
CF3 HSIC
USB3503
Hub
(U701)
HSIC
Up
USB
DW
USB
DW
USB
DW
USB Host Type A Connector
(CN304)
USB to
SPI
bridge
(U1006)
DNI
Raspberry Pi
Connector
(CN307)
USB
IoT Connector #0
(CN306, slot IOT0)
USB
Wi-Fi/BT chipset
(U1000)
SPI
SPI
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
· IoT Connector 0 (CN306)
or
(DNI) Raspberry Pi Connector (CN307)
· USB Host connector (CN304)
Hardware
Figure 2-8: HSIC Configuration
2.4.6 I2C1
The mangOH Red supports CF3 module I2C1 signals, which connect to the following sources (directly or via an
expander), as shown in Figure 2-9:
• Audio codec (U500)
• Pressure sensor (U705) — Accessible via API commands.
• Accelerometer/Gyroscope/Temperature sensor (U704)— Accessible via API commands.
• Battery charger (U800) — Accessible via API commands.
• Battery gauge (U801)— Accessible via API commands.
• IoT Connector 0 (CN306)
• Raspberry Pi connector (CN307)
• GPIO/PWM expander (U1004)— Used internally on the mangOH Red for I/O functions such as driving LEDs,
resetting board components, etc. (see GPIO Expander on page 20)
For detailed information, refer to mangOH Red schematics available at mangoh.io/mangoh-red-resources-
hardware.
• USB Hub controller (U701)
All signal sources are enabled by default.
Note: The mangOH Red I2C interface operates in a single-master/multi-slave setup.
Rev 4 May.18 21 41110401
mangOH Red Developer’s Guide
R793/R794
R460/R461
CF3
I2C1
Pressure /
Temperature
Sensor (U705)
Gyroscope/
Accelerometer
Sensor (U704)
I2C
Expander
(U404)
IoT Connector #0
(CN306, slot IOT0)
GPIO Expander (U1004)
USB3503 Hub (U701)
Audio Codec
(U500)
Battery Charger (U800)
Battery Gauge (U801)
Raspberry Pi Connector
(CN307)
R795/R796
R345/R346
Wi-Fi/BT
chipset
(U1000)
I2C1
3.5mm jack
(CN500)
Note: Populate/depopulate identified resistors to
choose alternate configurations.
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Note: By default, the CF3 I2C interface is connected as shown in Figure 2-9. The board can be modified to connect the Wi-Fi/
BT chipset I2C interface to the I2C expander and gyroscope/accelerometer sensor by populating/depopulating appropriate
resistors.
Figure 2-9: I2C1 Configuration
2.4.7 Light Sensor
The mangOH Red provides a light sensor (U706) that connects to the CF3 module’s ADC3 signal, as shown in
Figure 2-5 on page 17.
2.4.8 Raspberry Pi Rev B-compatible Connector
The mangOH Red provides a 26-pin Raspberry Pi RevB-compatible connector (CN307).
The mangOH Red provides the Raspberry Pi primary signals (alternate Raspberry Pi signals are not supported)
as shown in Figure 2-10 on page 23. These signals connect the mangOH Red’s hardware components to a
Raspberry Pi attached to the connector, as shown in Figure 2-11 on page 23.
Rev 4 May.18 22 41110401
Hardware
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
Power
3.3V (Pins 1/17)
5.0V (Pins 2/4)
I2C
(Pins 3/5)
GPIO (CF3)
(Pins 7/11/13/15)
SPI
(Pins 19/21/23/24/26)
GPIO (Expander)
(Pins 16/18/22)
PWM
(Pin 12)
UART
(Pins 8/10)
Ground
(Pins 6/9/14/20/25)
Raspberry Pi
Connector
CN307
UART1 Level shifter
CF3
UART1
PWM
EXT_GPS_LNA_EN
(4)
GPIO
GPIO
SPI2 SPI bridge
Wi-Fi/BT chipset
(U1000)
GPIO
GPIO
expander
(3)
GPIO
I2C hubI2C
5.0V
Level shifter
USB hub
R371
R382
VCC_5V0
USB_VBUS
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Figure 2-10: Raspberry Pi Signal Groups
Figure 2-11: Raspberry Pi Connections
Rev 4 May.18 23 41110401
mangOH Red Developer’s Guide
CF3
RF_MAIN
RF_DIV
RF_GPS
Main
(CN301)
GPS
(CN303)
DIversity
(CN302)
2.4.9 RF
The mangOH Red provides u.FL connectors that connect to the CF3 module’s RF signals:
• RF_MAIN—CN301
• RF_GPS—CN303
• RF_DIV—CN302
Power for these signals can be enabled/disabled as described in Table 2-5.
Table 2-5: CF3 GPIO Interface Configuration Changes
Change type Change effect Method Change duration
Software
Figure 2-12: CF3 module RF Connections
Enable/disable RF power
for CF3 module
AT command
Legato API
2.4.10 SDIO
The mangOH Red supports the CF3 module SDIO signals, which connect via a MUX to the following sources, as
shown in Figure 2-13:
• microSD holder (CN600)—Default configuration
• IOT Connector 0 (CN306)
The SDIO interface configuration can be modified as detailed in Table 2-6.
Table 2-6: SDIO Interface Configuration Changes
Change type Change effect Method Change duration
Software
• Use default or alternate
configuration.
API command
Selected configuration used every time device
boots up.
Rev 4 May.18 24 41110401
Hardware
uSD Holder
(CN600)
CF3
SDIO
IoT Connector #0
(CN306, slot IOT0)
Mux
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
CF3 SPI1
IoT Connector #0
(CN306, slot IOT0)
SPI
Figure 2-13: SDIO Configuration
2.4.11 SPI1
The mangOH Red supports the CF3 module SPI1 signals, which connect to the following source, as shown in
Figure 2-14:
• IOT Connector 0 (CN306)
Figure 2-14: SPI1 Configuration
2.4.12 UART1
The mangOH Red supports the CF3 module’s UART1 signals, which connect to the following sources, as shown in
Figure 2-15:
• IoT Connector 0 (CN306)— Default configuration
• Raspberry Pi connector (CN307)
• Wi-Fi/BT chipset (Note, the level shifter must be ON. In the default board configuration, the level shifter is
OFF.)
Note: At any one time, use only the IoT expansion card UART or the Raspberry Pi UART, not both.
Rev 4 May.18 25 41110401
mangOH Red Developer’s Guide
CF3 UART1
IoT Connector #0
(CN306, slot IOT0)
UART
Raspberry Pi
Connector (CN307)
UART
Level
shifter
Wi-Fi/BT chipset
(U1000)
UART
Level
shifter
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Figure 2-15: UART1 Configuration
2.4.13 UART2
The mangOH Red supports the CF3 module’s UART2 signals, which connect via a MUX to the following sources,
as shown in Figure 2-16:
• Console USB connector (CN305) — UART2 connects to the physical Console USB connector when both
MTK_TO_WP_UART_EN and CONS_DIR are low.
• Wi-Fi/BT chipset’s UART signal (U1000)— CF3 module’s UART2 and Wi-Fi/BT chipset’s UART0 are linked
when MTK_TO_WP_UART_EN signal is pulled high.
2.4.14 UART Console Connections
The mangOH Red supports the following console connections for the CF3 module (UART2) and Wi-Fi/BT chipset
(UART0), as shown in Figure 2-16:
• CF3 module UART2 to Console USB connector (CN305)
• Wi-Fi/BT chipset UART0 to Console USB connector (CN305)
• Direct connect between CF3 module UART2 and Wi-Fi/BT chipset UART0
Table 2-7: UART Console Connection Options
Connection CONS_DIR (SW401 pin 6) MTK_TO_WP_UART_EN (API)
CF3 module UART2 to
Console USB
Wi-Fi/BT chipset UART0 to
Console USB
CF3 module UART2 to Wi-Fi/
BT chipset UART0
Pull low (Pin OFF) Pull low
Pull high (Pin ON) Pulll low
n/a Pull high
Rev 4 May.18 26 41110401
Hardware
CF3 UART2
Wi-Fi/BT
chipset
UART0
Level shifter
USB-UART
FTDI
Console
USB
CONS_DIR
MTK_TO_WP_UART_EN
UART
buffer
Mux
Note: Default configuration — Solid lines
Alternate configurations — Dashed lines
SIM Holder
(CN600)
(DNI)
eSIM (U603)
CF3
UIM1
UIM2
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Figure 2-16: UART Console Connections
2.4.15 UIM Signals
The mangOH Red supports both CF3 module UIM interfaces (UIM1, UIM2), where UIM1 is a removable SIM, and
UIM2 is an embedded SIM (DNI).
The default boot configuration is shown in Figure 2-17.
Note: Throughout this document, ‘UIM’ is used to refer to UIM, USIM, SIM, UICC.
Figure 2-17: SIM Interfaces Configuration
2.4.15.1 UIM1
The CF3 module’s UIM1 signal connects to the micro-SIM holder (CN600).
Note: The CF3 module’s UIM1_DET signal indicates when a SIM is present in the holder.
Rev 4 May.18 27 41110401
mangOH Red Developer’s Guide
CF3 USB
USB2.0 micro-USB
connector
(CN305)
CF3 USB
2.4.15.2 UIM2
Note: The mangOH Red does not ship with an eSIM (the component is DNI). For details, refer to the mangOH Red schematics
available at mangoh.io/mangoh-red-resources-hardware.
The CF3 module’s UIM2 signal connects to the eSIM (U603).
Note: The corresponding UIM2_DET signal pin is reserved for future use.
2.4.16 USB 2.0
The CF3 module’s USB signal connects directly to the mangOH Red’s CF3 USB micro-USB connector (CN305) as
shown in Figure 2-18, for control by a connected computer.
Note: The micro-USB connector also acts as a power source, if selected. See Power Management on page 32.
The USB 2.0 interface configuration can be modified as detailed in Table 2-8.
Table 2-8: USB 2.0 Interface Configuration Methods
Change type Change effect Method Change duration
Hardware • Jumper on pins closest to CF3
USB—Select CF3 USB power
• Jumper on pins closest to
Console USB—Select Console
USB power
• Jumper off— Use battery if
connected, otherwise no power
supplied
Figure 2-18: USB_2.0 Configuration
Position jumper on CN804 to choose
CF3 USB or CONSOLE USB connector
to supply power.
Note: mangOH Red ships with CF3
USB power selected (jumper on pins
closest to CF3 USB connector).
mangOH Red uses the
selected power supply
until the jumper
changes.
2.5 Wi-Fi/BT Chipset
The mangOH Red incorporates a Wi-Fi/BT chipset (MediaTek Wi-Fi+Bluetooth) that provides the following
functionality:
• RF:
· Wi-Fi/Bluetooth/WLAN connections via an integrated 2.4 GHz antenna
· Supports 2.4GHz Wi-Fi (802.11b/g/nHT20) and 2.4GHz BLE (Bluetooth Low Energy)
• IOT0 connection via Wi-Fi/BT chipset’s UART1
• Application processor—Real-time application processing using the mangOH Red’s real-time I/O connector,
via GPIO, ADC, and I2C interfaces.
Rev 4 May.18 28 41110401
Hardware
Wi-Fi/BT chipset
UART0
SPI2
SPI1 32Mb Flash Memory
GPIO
Real-time I/OADC
I2C
UART1 Level shifter
CF3
UART1
RF
Integrated antenna
(ANT1000)
U.FL connector
(CN1000)
Wi-Fi/BT/WLAN
I2C
Expander
R460/R461
HSICSPI Bridge
USB
USB Hub
Raspberry
Pi
SPI2_CS2
Off (default)
SPI2_CS0
SPI2_CS1
I2C
R345/R346
SW401
Pin 4: HL_MODE
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
Refer to Figure 2-16 for UART0 details.
Note: Populate/depopulate identified resistors to
connect either the CF3 module or the
Wi-Fi/BT chipset to the I2C expander.
• Access to mangOH Red’s accelerometer/gyroscope/temperature sensor via GPIO interface
• Access to Raspberry Pi connector via SPI interface
• Wi-Fi/BT chipset console connection to either the Console USB connector or the CF3 module console,
including ability to receive firmware downloads from either source.
• Optional debug connector (CN400, DNI) to use for serial wire debugging
The Wi-Fi/BT chipset can connect to several components on the mangOH Red, as show in Figure 2-19.
Figure 2-19: Wi-Fi/BT Chipset Connections
Rev 4 May.18 29 41110401
mangOH Red Developer’s Guide
2.5.1 Wi-Fi RF
The mangOH Red supports 2.4GHz Wi-Fi (802.11b/g/nHT20).
Table 2-9 describes the mangOH Red’s Wi-Fi RF average output power.
For Wi-Fi 2.4 GHz RF receiver specifications, refer to the MediaTek MT7697 Datasheet, version 1.01.
Table 2-9: Maximum Wi-Fi RF Average Output Power
Average Power (dBm)
Mode Frequency
2412 11.5 12.0 11.5
2.4 GHz WLAN
Parameter Description Min (dB) Max (dB)
2437 11.5 13.0 14.0
2462 10.5 11.5 11.0
802.11b 802.11g 802.11n-HT20
• TSSI closed-loop control across all
temperature range and channels and
Output power variation
VWSR 1.5:1
-1.5 1.5
• VCC_3V3 voltage is within ±5% of typical
value
2.5.2 Bluetooth RF
The mangOH Red supports 2.4GHz BLE (Bluetooth Low Energy).
Table 2-10 describes the mangOH Red’s Bluetooth RF average output power.
For Bluetooth 2.4 GHz RF receiver specifications, refer to the MediaTek MT7697 Datasheet, version 1.01.
Table 2-10: Maximum Bluetooth RF Average Output Power
Mode Average Power (dBm)
Bluetooth LE, GFSK 8.5
Rev 4 May.18 30 41110401
Hardware
CF3
IoT Connector #0
(CN306, slot IOT0)
UART
PCM
SPI
SDIO
USB
I2C
ADC0
PPS
GPIO(1-4)
n_RESET
n_CARD_DETECT
Note: Default configuration — Solid lines
Alternate configuration — Dashed lines
2.6 IoT Connector Interfaces
The mangOH Red provides one IoT Connector (CN306, slot IOT0), which supports the signals defined in the
Project mangOH IoT Expansion Card Design Specification, as detailed in Table 2-2 on page 16.
The default configuration (enabled signals) for the IoT Connector is shown in Figure 2-20.
The IoT Connector interface configuration can be modified as detailed in Table 2-11.
Table 2-11: IoT Connector Interface Configuration Changes
Change type Change effect Method Change duration
Software Enable/disable identified signal(s) on
a specific IoT Connector.
API command Modifies running configuration until device
reboots or another change is made.
Figure 2-20: IoT Connector Configuration
Rev 4 May.18 31 41110401
mangOH Red Developer’s Guide
Battery
Charger
Main C F3
USB HUB
(USB3503)
GPIO
Expander(SX1509)
IoT # 1Reset Io T #1
RESET_WIFI_1V8
System_reset
DNI
NCP303
POR reset
3.0V
Reset
(open drain out)
3V7
Reset
Button
47k
CF3_IOT0_RESET
CF3_GPIO_WIF I_RESET
RESET_WIFI_3V3
CP2130
MTD76 97D
VCC_1V8
10k
SW401.pin8
WP= ON
HL=OFF
SW401.pin4
WP= OFF
HL=ON
TCA9546
WP_LowPower_Reset
LowPower_Reset
47k
VCC_1V8
Level
Shift
U307
100k
2.7 Reset Methods
The mangOH Red supports hardware and software resets of the entire board or certain components of the board,
as shown in Figure 2-21:
Table 2-12: Reset Methods
Board Components to Reset Reset Method
Entire board, including CF3 module (WP or HL) Press Reset button (SW400)
IOT Expansion Card CF3_IOT0_RESET
or
Use an API command to trigger the CF3 module signal
GPIO_IOT0_RESET.
Wi-Fi/BT chipset CF3_GPIO_WIFI_RESET
For detailed specifications showing how full or partial resets are enabled, see the mangOH Red schematics
available at mangoh.io/mangoh-red-resources-hardware.
Figure 2-21: Reset Methods
2.8 Power Management
The mangOH Red has two primary power supplies (CF3 USB connector and CONSOLE USB connector), and a
rechargeable backup battery power supply option.
Figure 2-22 illustrates these power supplies, their voltage/current specifications, and how they supply various
components on the mangOH Red platform.
A multi-function switch (SW401) controls some power-related features (see Multi-switch (SW401) on page 15),
including:
• Pin 1 (PWR_ON)—Enable/disable CF3 module’s POWER_ON_signal
Rev 4 May.18 32 41110401
Hardware
Vbatt
LiPo
Battery
3.7V
0 OHM
1.8V Buck
5V Peripherals
1V8 Peripherals
50mA typ
100mA Max
Battery Charger
with Power Path
100mA typ
500mA Max
5V boost
Regulator
and
charger
3.3V Buck
3V3 Peripherals
Including WiFi/BT
chipset
300mA typ
600mA max
1V8
3V3
5V
1x IoT
0 ohm
300mA typ
500mA Max
200mA typ
900mA max
50mA typ
100mA Max
4.5V to 5.5V
3.7V @ 1A continous, 2.5A peak
CF3 Main
uUSB CF3
uSUB
Console
JST-PH
Connector
Jumper
Battery
Gauge
Jumper:
Battery
SW401SLQ
EN
0 ohm
0 Ohm
EN
EN
VGPIO
VGPIO
VGPIO
Low
Power
1.8V LDO
Low Power
I/Os
Raspberry
Pi
Connector
DNI
L910
L911
• Pin 3 (VCC_3V7_ULPM)— In ULPM, enable/disable power to accessories (CF3 module always receives
power)
• Pin 5 (BATT_TS+)—Enable/disable backup battery charging
Figure 2-22: Power Management
Rev 4 May.18 33 41110401
3: Regulatory Compliance
3.1 Important Compliance Information for North American
Users
3.1.1 USA
Caution: Changes or modifications not expressly approved by Sierra Wireless could void the user's authority to operate the
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
3
3.1.2 Canada
This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two
conditions:
1) This device may not cause interference; and
2) This device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
1) l'appareil ne doit pas produire de brouillage;
2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Rev 4 May.18 34 41110401
Loading...
