WISMO Quik Q2686

Product Technical Specification

Reference: WM_PRJ_Q2686_PTS_001

Revision: 006

Date: April 4th2006

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 1 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Document Information

Level Date History of the evolution

001 01/17/2005 Creation (Preliminary version)

002 06/01/2005 Pin-out modification (see chapter 3.1)

003 15/09/2005 Update Functional architecture

004 November

22, 2005

005 February

2006

006 March

2006

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Pin-out modification (see chapter 4.1) Add RESET state of all IO of all interface Update power supply range (see chapter 3.2) Update electrical information for digital IO (see chapter

3.2) Update SPI bus configuration (see chapter 3.4) Remove 3 GPIO (see chapter 3.9) Change MIC1 biasing voltage configuration (see chapter

3.11) Change SPK1 definition to only single ended (see chapter

3.11) Update ON/ÕFF operating sequence (see chapter 3.14) Update BOOT definition (see chapter 3.15) Update ~RESET operating sequence and electrical characteristics(see chapter 3.14) Update Interrupts activation (see chapter 3.17) Update RTC electrical characteristics (see chapter 3.19) Update PCM description and add waveform (see chapter

3.21)

Update Q2686 version “Overview” section Update “Cautions”, “Trademarks” and “Copyright” Update “Electrical information for digital I/O” (see chapter

3.3) Update SPI max frequency (see chapter 3.4) Update available GPIO (see chapter 3.9) Add “OFF state“ voltage caution (see chapter 3.2) Update “Battery charging interface” (see chapter 3.13) Update “Analogue audio interface” (see chapter 3.11) Update ”Environmental Specifications” (see chapter 4.2) Update “General Purpose Connector pin out description” (see chapter 4.1) Update “PCM interface” waveform (see chapter 3.21) Update “Electrical information for digital IO” absolute maximum rating (see chapter 3.3) Update “General purpose connector” (see chapter 3.1) Update “SPI bus” speed (see chapter 3.4.1) Update “I²C bus” (see chapter 3.4.2) Update “Main serial link UART 1” maximum speed (see chapter 3.6) Update “Auxiliary serial link UART 2” maximum speed (see chapter 3.7) Update “SIM” General description (see chapter 3.8.1) Update “USB 2.0 interface” features (see chapter 3.22) Update “Operating system upgrade” (see chapter 6.3) Update “General purpose input / output” signals description (see chapter 3.9) Update “General purpose connector pin out description” signal description(see chapter 4.1) Update “Battery charging interface” (see chapter 3.13) Update “Analog to µDigital Converter” (see chapter 3.10) Update “FLASH-LED signal” (see chapter 3.20) Update ‘Analogue Audio interface” (see chapter 3.11) Update “Power consumption” (see chapter 3.3.2) Update “ON/~OFF signal” (see chapter 3.14) Update “BAT-RTC” (see chapter 3.19)

confidential ©

Page : 2 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Update “Electrical information for digital IO” absolute

maximum rating (see chapter 3.3) Update “Buzzer output” remove PWM features ( see chapter 3.12 ) Update “EMC recommendation” add ESD recommendations (see chapter 6.1.1 ) Update “SPI bus” add waveforms ( see chapter 3.4.1 ) Update “I²C bus” add waveforms ( see chapter 3.4.2 ) Update “Analog to Digital Converter“ sampling rate ( see chapter 3.10)

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 3 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 4 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Overview

This document defines and specifies the WISMO QUIK Q2686, available under two GSM/GPRS Class 10 quad-band versions:

 Q2686: EGSM/GPRS 900/1800/850/1900 MHz version with 32 Mb of

Bursted Flash memory and 8 Mb of SRAM (32/8)

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 5 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Contents

Document Information ....................................................................... 2

Overview ............................................................................................ 5

Contents ............................................................................................ 6

Table of figures ................................................................................ 10

Cautions .......................................................................................... 11

Trademarks ...................................................................................... 11

1 References................................................................................. 12

1.1 References documents ..........................................................................12

1.1.1 WAVECOM reference document ....................................................12

1.1.2 General reference document ..........................................................12

1.2 List of abbreviations..............................................................................13

2 General description.................................................................... 16

2.1 General information...............................................................................16

2.1.1 Overall dimensions ........................................................................16

2.1.2 Environment and mechanics..........................................................16

2.1.3 GSM/GPRS Features......................................................................16

2.1.4 Interfaces.......................................................................................16

2.1.5 Operating system ..........................................................................17

2.1.6 Connection interfaces ....................................................................17

2.2 Functional description ...........................................................................18

2.2.1 RF functionalities...........................................................................19

2.2.2 Baseband functionalities................................................................19

2.3 Operating System..................................................................................19

3 Interfaces .................................................................................. 20

3.1 General Purpose Connector (GPC) .........................................................20

3.2 Power supply ........................................................................................21

3.2.1 Power supply description ..............................................................21

3.2.2 Power consumption ......................................................................22

3.2.2.1 Power consumption without Open AT®processing..................23

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 6 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.2.2.2 Power consumption with Open AT®software..........................24

3.2.2.3 Consumption waveforms samples...........................................25

3.2.2.3.1 Connected mode current waveform.......................................25

3.2.2.3.2 Slow Idle mode current waveform.........................................26

3.2.2.3.3 Fast Idle mode current waveform ..........................................26

3.2.2.3.4 Transfer mode Class 10 current waveform ............................27

3.2.2.4 Power supply pinout................................................................27

3.3 Electrical information for digital I/O........................................................28

3.4 Serial interface.......................................................................................30

3.4.1 SPI bus..........................................................................................30

3.4.1.1 SPI waveforms ........................................................................30

3.4.1.2 SPI configuration .....................................................................31

3.4.1.3 SPI1 bus ..................................................................................31

3.4.1.4 SPI2 bus ..................................................................................32

3.4.2 I2C bus..........................................................................................33

3.4.2.1 I²C waveforms .........................................................................33

3.4.2.2 I²C bus pin out.........................................................................34

3.5 Keyboard interface.................................................................................35

3.6 Main serial link (UART1)........................................................................36

3.7 Auxiliary serial link (UART2) ..................................................................38

3.8 SIM interface.........................................................................................39

3.8.1 General Description .......................................................................39

3.9 General Purpose Input/Output ...............................................................41

3.10 Analog to Digital Converter....................................................................43

3.11 Analogue audio interface.......................................................................44

3.11.1 Microphone inputs ........................................................................44

3.11.1.1 Common microphone inputs characteristics ............................44

3.11.1.2 Main Microphone Inputs (MIC2) ..............................................44

3.11.1.3 Auxiliary Microphone Inputs (MIC1) ........................................45

3.11.1.4 Micro Electrical characteristics.................................................45

3.11.2 Common speaker outputs characteristics ......................................46

3.11.2.1 Differential Connection.............................................................46

3.11.2.2 Single-ended Connection .........................................................46

3.11.3 Speaker outputs ............................................................................46

3.11.3.1 Speaker 2 Outputs ...................................................................46

3.11.3.2 Speaker 1 Outputs ...................................................................47

3.11.3.3 Speakers Outputs Power .........................................................47

3.12 Buzzer Output .......................................................................................48

3.13 Battery charging interface .....................................................................49

3.13.1 Ni-Cd / Ni-Mh Charging algorithm .................................................49

3.13.2 Li-Ion Charging algorithm ..............................................................50

3.13.3 Pré-Charging hardware controlled .................................................51

3.13.4 Temperature monitoring................................................................51

3.14 ON / ~OFF signal...................................................................................52

3.14.1 Operating sequences.....................................................................52

3.14.1.1 Power ON ................................................................................52

3.14.1.2 Power OFF...............................................................................53

3.15 BOOT signal..........................................................................................54

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 7 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.16 Reset signal (~RESET)...........................................................................55

3.17 External Interrupt ..................................................................................57

3.18 VCC_2V8 and VCC_1V8 output ..............................................................58

3.19 BAT-RTC (Backup Battery) ....................................................................59

3.19.1 Interface description ......................................................................59

3.20 FLASH-LED signal .................................................................................60

3.21 Digital audio interface (PCM).................................................................62

3.21.1 Description ....................................................................................62

3.22 USB 2.0 interface ..................................................................................65

3.23 RF interface 66

3.23.1 RF connections..............................................................................66

3.23.2 RF performances ...........................................................................66

3.23.3 Antenna specifications ..................................................................67

4 Technical specifications ............................................................ 68

4.1 General Purpose Connector pin out description.....................................68

4.2 Environmental Specifications.................................................................71

4.3 Mechanical specifications......................................................................73

4.3.1 Physical characteristics .................................................................73

4.3.2 Mechanical drawings ....................................................................73

5 Connectors and peripheral devices references ........................... 75

5.1 General Purpose Connector ...................................................................75

5.2 SIM Card Reader ...................................................................................75

5.3 Microphone...........................................................................................75

5.4 Speaker .................................................................................................76

5.5 Antenna Cable.......................................................................................76

5.6 RF Board to board connector.................................................................76

5.7 GSM antenna ........................................................................................76

6 Design Guidelines ...................................................................... 77

6.1 HARDWARE and RF ..............................................................................77

6.1.1 EMC recommendations .................................................................77

6.1.2 Power Supply ................................................................................77

6.1.3 Layout requirement .......................................................................78

6.1.4 Antenna.........................................................................................80

6.2 Mechanical integration..........................................................................80

6.3 Operating System upgrade....................................................................80

7 Appendix ................................................................................... 81

7.1 Standards and Recommendations.........................................................81

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 8 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

7.2 Safety recommendations (for information only) .....................................85

7.2.1 RF safety .......................................................................................85

7.2.1.1 General ....................................................................................85

7.2.1.2 Exposure to RF energy.............................................................85

7.2.1.3 Efficient terminal operation ......................................................85

7.2.1.4 Antenna care and replacement ................................................86

7.2.2 General safety................................................................................86

7.2.2.1 Driving.....................................................................................86

7.2.2.2 Electronic devices ....................................................................86

7.2.2.3 Vehicle electronic equipment ...................................................86

7.2.2.4 Medical electronic equipment ..................................................86

7.2.2.5 Aircraft ....................................................................................87

7.2.2.6 Children ...................................................................................87

7.2.2.7 Blasting areas..........................................................................87

7.2.2.8 Potentially explosive atmospheres ...........................................87

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 9 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Table of figures

Figure 1 : Functional architecture................................................................... 18

Figure 2 : Power supply during burst emission .............................................. 21

Figure 3 : SPI Timing diagrams, Mode 0, Master, 4 wires.............................. 31

Figure 4 : I²C Timing diagrams, Master .......................................................... 33

Figure 5 : Ni-Cd / Ni-Mh charging waveform .................................................. 49

Figure 6 : Li-Ion full charging waveform ......................................................... 50

Figure 7 : Power-ON sequence (no PIN code activated).................................. 52

Figure 8 : Power-OFF sequence......................................................................53

Figure 9 : Reset sequence waveform.............................................................. 55

Figure 10 : Real Time Clock power supply...................................................... 59

Figure 11 : FLASH-LED state during RESET and Initialization time ................. 61

Figure 12 : PCM Frame waveform.................................................................. 63

Figure 13 : PCM Sampling waveform............................................................. 63

Figure 14 : Environmental classes .................................................................. 72

Figure 15 : Mechanical drawing ..................................................................... 74

Figure 16 : Layout requirement ...................................................................... 79

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 10 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Cautions

This platform contains a modular transmitter. This device is used for wireless applications. Note that all electronics parts and elements are ESD sensitive.

Information provided herein by WAVECOM is accurate and reliable. However no responsibility is assumed for its use and any of such WAVECOM

information is herein provided “as is” without any warranty of any kind, whether express or implied.

General information about WAVECOM and its range of products is available at the following internet address: http://www.wavecom.com

Trademarks

®, WAVECOM®, WISMO®, Open AT®and certain other trademarks and logos appearing on this document, are filed or registered trademarks of Wavecom S.A. in France or in other countries. All other company and/or product names mentioned may be filed or registered trademarks of their respective owners.

This manual is copyrighted by WAVECOM with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of WAVECOM. No patent liability is assumed with respect to the use of their respective owners.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 11 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

1 References

1.1 References documents

For more details, several references documents can be consulted. The WAVECOM reference documents are provided in the WAVECOM documents package contrary at the general reference documents which are not WAVECOM owner.

1.1.1 WAVECOM reference document

[1] Automotive Environmental Control Plan for WISMO Quik Q2686

WM_PRJ_Q2686_DCP_001

[2] WISMO Quik Q2686 Customer Design Guidelines

WM_PRJ_Q2686_PTS_003

[3] WISMO Quik Q2686 Process Customer Guidelines

WM_PRJ_Q2686_PTS_004

[4] AT Commands Interface Guide for OS 6.60

WM_DEV_OAT_UGD_003

1.1.2 General reference document

[5] “I²C Bus Specification”, Version 2.0, Philips Semiconductor 1998

[6] ISO 7816-3 Standard

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 12 / 87

WM_PRJ_Q2686_PTS_001

1.2 List of abbreviations

Abbreviation Definition

AC Alternative Current ADC Analog to Digital Converter A/D Analog to Digital conversion AF Audio-Frequency AT ATtention (prefix for modem commands) AUX AUXiliary CAN Controller Area Network CB Cell Broadcast CEP Circular Error Probable CLK CLocK CMOS Complementary Metal Oxide Semiconductor

April 4th 2006

CS Coding Scheme CTS Clear To Send DAC Digital to Analogue Converter dB Decibel DC Direct Current DCD Data Carrier Detect DCE Data Communication Equipment DCS Digital Cellular System DR Dynamic Range DSR Data Set Ready DTE Data Terminal Equipment DTR Data Terminal Ready EFR Enhanced Full Rate E-GSM Extended GSM EMC ElectroMagnetic Compatibility EMI ElectroMagnetic Interference EMS Enhanced Message Service EN ENable ESD ElectroStatic Discharges FIFO First In First Out FR Full Rate

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 13 / 87

WM_PRJ_Q2686_PTS_001

Abbreviation Definition

FTA Full Type Approval GND GrouND GPI General Purpose Input GPC General Purpose Connector GPIO General Purpose Input Output GPO General Purpose Output GPRS General Packet Radio Service GPS Global Positioning System GSM Global System for Mobile communications HR Half Rate I/O Input / Output LED Light Emitting Diode LNA Low Noise Amplifier MAX MAXimum

April 4th 2006

MIC MICrophone MIN MINimum MMS Multimedia Message Service MO Mobile Originated MT Mobile Terminated na Not Applicable NF Noise Factor NMEA National Marine Electronics Association NOM NOMinal NTC Négative Temperature Coefficient PA Power Amplifier Pa Pascal (for speaker sound pressure measurements) PBCCH Packet Broadcast Control CHannel PC Personal Computer PCB Printed Circuit Board PDA Personal Digital Assistant PFM Power Frequency Modulation PSM Phase Shift Modulation PWM Pulse Width Modulation RAM Random Access Memory RF Radio Frequency

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 14 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Abbreviation Definition

RFI Radio Frequency Interference RHCP Right Hand Circular Polarization RI Ring Indicator RST ReSeT RTC Real Time Clock RTCM Radio Technical Commission for Maritime services RTS Request To Send RX Receive SCL Serial CLock SDA Serial DAta SIM Subscriber Identification Wireless CPU SMS Short Message Service SPI Serial Peripheral Interface SPL Sound Pressure Level SPK SPeaKer SRAM Static RAM TBC To Be Confirmed TDMA Time Division Multiple Access TP Test Point TVS Transient Voltage Suppressor TX Transmit TYP TYPical UART Universal Asynchronous Receiver-Transmitter USB Universal Serial Bus USSD Unstructured Supplementary Services Data VSWR Voltage Standing Wave Ratio

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 15 / 87

WM_PRJ_Q2686_PTS_001

Wireless CPUs which are compliant with this directive

April 4th 2006

2 General description

2.1 General information

WISMO Quik Q2686 is a self-contained E-GSM/GPRS 900/1800 and 850/1900 quad-band Wireless CPU including the following characteristics :

2.1.1 Overall dimensions

 Length: 40 mm  Width: 32.2 mm  Thickness: 4 mm

2.1.2 Environment and mechanics

 Green policy: RoHS compliant

 Complete shielding

The Q2686 Wireless CPU is compliant with RoHS (Restriction of Hazardous Substances in Electrical and Electronic Equipment) Directive 2002/95/EC which sets limits for the use of certain restricted hazardous

substances. This directive states that “from 1st July 2006, new electrical and electronic equipment put on the market does not contain lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl ethers (PBDE)”.

are identified by the RoHs logo on their label.

2.1.3 GSM/GPRS Features

 2 Watts EGSM 900/GSM 850 radio section running under 3.6 Volts  1 Watt GSM1800/1900 radio section running under 3.6 Volts  Hardware GPRS class 10 capable

2.1.4 Interfaces

 Digital section running under 2.8 Volts and 1.8V.  3V/1V8 SIM interface  Complete interfacing :

o Power supply o Serial link o Analogue audio o PCM digital audio o SIM card o Keyboard

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 16 / 87

o USB 2.0 slave o Serial LCD (not available with AT commands)

2.1.5 Operating system

 Real Time Clock with calendar  Battery charger  Echo Cancellation + noise reduction (quadri codec)  Full GSM or GSM/GPRS Operating System stack

2.1.6 Connection interfaces

WISMO Quik Q2686 has four external connections :

 Three for RF circuit:

o UFL connector o Soldered connection o IMP connection

 One for base band signals:

o 100 pin I/O connector.

WM_PRJ_Q2686_PTS_001

April 4th 2006

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 17 / 87

WM_PRJ_Q2686_PTS_001

PCM

SIM 1.8V/3V

EBI

SPI2

CHARGER

RTC

2.2 Functional description

The global architecture of WISMO Quik Q2686 is described below :

SUPPLY INTERFACE

2 6 8 6

A R

AUDIO FILTER

POWER

AUDIO

INTERFACE

EXT_IT

April 4th 2006

TRANSCEIVER

A R

T E R

F A C E

E C T

USB detection

KEYPAD

UART2

UART1

USB

MEMORY

FLASH / SRAM

SPI1

I2C

GPIO

ADC

DAC

FRONT END

ANTENNA

COAX

UFL

IMP

Figure 1 : Functional architecture

confidential ©

Page : 18 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

2.2.1 RF functionalities

The Radio Frequency (RF) range comply with the Phase II EGSM 900/DCS 1800 and GSM 850/PCS 1900 recommendation. The frequencies are :

Transmit band (Tx) Receive band (Rx)

GSM 850 824 to 849 MHz 869 to 894 MHz

E-GSM 900 880 to 915 MHz 925 to 960 MHz

DCS 1800 1710 to 1785 MHz 1805 to 1880 MHz

PCS 1900 1850 to 1910 MHz 1930 to 1990 MHz

The Radio Frequency (RF) part is based on a specific quad band chip including:

 a Digital low-IF receiver  a Quad-band LNAs (Low Noise Amplifier)  an Offset PLL (Phase Locked Loop) transmitter  a Frequency synthesizer  a Digitally controlled crystal oscillator (DCXO)  a Tx/Rx FEM ( Front-End Wireless CPU) for quad-band GSM/GPRS

2.2.2 Baseband functionalities

The digital part of the WISMO Quik Q2686 is composed of a PCF5212 PHILIPS chip. This chipset is using a 0,18 µm CMOS mixed technology, which allows massive integration as well as low current consumption.

2.3 Operating System

WISMO Quik Q2686 is designed to integrate various types of specific process

applications such as vertical applications (telemetry, multimedia, automotive…).

The Operating System offers a set of AT commands to control the Wireless CPU. With this standard Operating System, some interfaces of the Wireless

CPU are not available since they are dependent on the peripheral devices

connected to the Wireless CPU.

The Operating System is Open AT®compliant.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 19 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3 Interfaces

3.1 General Purpose Connector (GPC)

A 100-pin connector is provided to interface the WISMO Quik Q2686 with a board containing either a serial LCD Wireless CPU, a keyboard, a SIM connector, or a battery connection.

The available interfaces on the GPC are described below.

chapter Name Driven by

3.4 Sérial Interface X X

3.5 Keyboard Interface X X

3.6 Main Sérial Link X X

3.7 Auxiliary Sérial Link X X

3.8 SIM Interface X X

3.9 Général Purpose IO X X

3.10 Analog to Digital Converter

3.11 Analog audio Interface X X

3.12 Buzzer Output X X

3.13 Battery Charging

Interface

3.17 External Interruption X X

3.18 VCC_2V8 and

VCC_1V8

3.19 BAT-RTC (Backup

Battery)

3.20 FLASH-LED signal X X

3.21 Digital Audio Interface

(PCM)

3.22 USB 2.0 Interface X X

OS 6.60

X X

Not

driven by

OS 6.60

X X

Driven by Open AT

V4.00

driven by

Open AT

V4.00

Not

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 20 / 87

WM_PRJ_Q2686_PTS_001

Uripp

VBATT

T = 4,615 ms

t = 577 µs

April 4th 2006

3.2 Power supply

3.2.1 Power supply description

The power supply is one of the key issue in the design of a GSM terminal. Due to the bursted emission in GSM / GPRS, the power supply must be able to

deliver high current peaks in a short time. During the peaks the ripple (U the supply voltage must not exceed a certain limit (see Table 1 Power supply voltage“ Power Supply Voltage”).

 In communication mode, a GSM/GPRS class 2 terminal emits 577µs

radio bursts every 4.615ms. (See Figure 2)

Uripp

ripp

) on

Figure 2 : Power supply during burst emission

 In communication mode, a GPRS class 10 terminal emits 1154µs radio

bursts every 4.615ms.

Only the VBATT power supply input is necessary to provide the Q2686 Wireless CPU.

VBATT:

 supplies directly the RF components with 3.6 V. It is essential to keep a

minimum voltage ripple at this connection in order to avoid any phase error.

The RF Power Amplifier current (2.0 A peak in GSM /GPRS mode) flows with a ratio of:

o 1/8 of the time (around 577µs every 4.615ms for GSM /GPRS cl. 2)

and

o 2/8 of the time (around 1154µs every 4.615ms for GSM /GPRS cl.

10).

The rising time is around 10µs.

 is internally used to provide through several regulators, the power

supply VCC_2V8 and VCC_1V8 needed for the base band signals.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 21 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

The WISMO QUIK Q2686 shielding case is the grounding. The ground has to be connected on the mother board through a complete layer on the PCB.

Input power Supply Voltage

VBATT

1,2

MIN

3.2 3.6 4.8 10mVpp

NOM

MAX

Ripple max (U

ripp

)

Table 1 Power supply voltage (1): This value has to be guarantied during the burst (with 2.0A Peak in GSM or GPRS mode) (2): max operating Voltage Stationary Wave Ratio (VSWR) 2:1

When supplying the Wireless CPU with a battery, the total impedance (battery+protections+PCB)should be <150 mOhms.

When the Wireless CPU is in Alarm mode, no voltage must be applied on any pin of the 100-pin connector excepted on the BAT-RTC (pin 7 ) for RTC operation, or ON/~OFF (pin 19) to power ON the Wireless CPU.

3.2.2 Power consumption

The power consumption is depending of the configuration used. That’s why, the following consumption values are given for each modes, RF bands and software used (AT or Open AT™).

All following information are given assuming a 50  RF output.

The following consumption values are given by measurement on Wireless CPU samples, at temperature of 25°C.

Three VBATT values are used to measure the consumption, VBATT VBATT

(4.8V) and VBATT

MAX

TYP

(3.6V).

MIN

(3.2V),

The average current is given for the three VBATT values and the peak current given is the maximal current peak measured with the three VBATT voltages.

For more information about working mode description, see Appendix of AT Command Interface Guide OS 6.60 [4]

For more information about consumption measurement procedure, see WISMO Quik Q2686 Customer Design Guidelines [2].

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 22 / 87

WM_PRJ_Q2686_PTS_001

class 8

class 10

3.2.2.1 Power consumption without Open AT®processing

The following measurement results are relevant when :

 there is no Open AT®application  the Open AT®application is disabled  no processing is required by the Open AT®application

Power consumption without Open AT®processing

April 4th 2006

Working modes parameters

MIN

average

VBATT=4,8V

NOM

average

VBATT=3,6V

MAX

average

VBATT=3,2V

MAX

peak

unit

Alarm Mode 21 16 15 µA

Fast Idle Mode

Slow Idle Mode

Paging 9 (Rx burst occurrence ~2s) 15 17 18 160 Paging 2 (Rx burst occurrence ~0,5s) 17 18 19 160

Paging 9 (Rx burst occurrence ~2s)

Paging 2 (Rx burst occurrence ~0,5s)

1.5

(1.5 to 1.75)

(4 to 4.3)

1.6

(1.6 to 1.9)

4.4

(4.4 to 4.75)

(1.7 to 2.05)

(4.6 to 4.95)

1.7

4.6

160

mA mA

Fast Standby Mode 30 36 39 mA Slow Standby Mode 1.4 1.4 1.5 mA

850/900 MHz

Connected Mode

1800/1900 MHz

850/900 MHz

Transfer Mode

(4Rx/1Tx)

1800/1900 MHz

PCL5 (TX power 33dBm) 210 218 222 1450 TXmA PCL19 (TX power 6dBm) 81 89 92 270 PCL0 (TX power 33dBm) 145 153 157 850 PCL19 (TX power 6dBm) 77 85 88 250

PCL3 (TX power 33dBm) 201 209 213 1450 TXmA PCL17 (TX power 5dBm) 78 85 88 270 PCL3 (TX power 30dBm) 138 146 149 850 PCL18 (TX power 0dBm) 74 81 84 250

850/900 MHz

Transfer Mode

(3Rx/2Tx)

1800/1900 MHz

means that the current peak is the RF transmission burst (Tx burst)

means that the current peak is the RF reception burst (Rx burst)

The Slow Idle Mode consumption is depending of the SIM card used. Any

PCL3 (TX power 33dBm) 364 372 378 1450 TXmA PCL17 (TX power 5dBm) 112 120 123 270 PCL3 (TX power 30dBm) 237 245 248 850 PCL18 (TX power 0dBm) 104 111 115 250

SIM cards responses are speeder than others, more the response is long, more the consumption is high. The measurements have been preformed with many 3V SIM cards, the result under brackets are the min and the max current measured among all the SIM used.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 23 / 87

mA mA mA

WM_PRJ_Q2686_PTS_001

class 8

class 10

April 4th 2006

3.2.2.2 Power consumption with Open AT®software

The Open AT™ software used is the Dhrystone application, the following consumption results are measured during the run of the Dhrystone application.

Power consumption with Dhrystone Open AT®application

Working modes parameters

MIN

average

VBATT=4,8V

NOM

average

VBATT=3,6V

MAX

average

VBATT=3,2V

MAX

peak

unit

Alarm Mode N/A N/A N/A µA

Fast Idle Mode

Slow Idle Mode

Paging 9 (Rx burst occurrence ~2s) 31 38 41 160 Paging 2 (Rx burst occurrence ~0,5s) 32 39 42 160 Paging 9 (Rx burst occurrence ~2s) N/A N/A N/A 160 Paging 2 (Rx burst occurrence ~0,5s) N/A N/A N/A 160

mA mA mA mA

Fast Standby Mode 31 38 41 mA Slow Standby Mode N/A N/A N/A mA

850/900 MHz

Connected Mode

1800/1900 MHz

850/900 MHz

Transfer Mode

(4Rx/1Tx)

1800/1900 MHz

PCL5 (TX power 33dBm) 211 219 223 1450 TXmA PCL19 (TX power 6dBm) 82 90 93 270 PCL0 (TX power 33dBm) 146 154 159 850 PCL19 (TX power 6dBm) 78 85 89 250

PCL3 (TX power 33dBm) 202 210 214 1450 TXmA PCL17 (TX power 5dBm) 78 86 89 270 PCL3 (TX power 30dBm) 140 148 151 850 PCL18 (TX power 0dBm) 75 82 85 250

850/900 MHz

Transfer Mode

(3Rx/2Tx)

PCL3 (TX power 33dBm) 365 373 379 1450 TXmA PCL17 (TX power 5dBm) 113 121 125 270 PCL3 (TX power 30dBm) 239 247 250 850

1800/1900 MHz

PCL18 (TX power 0dBm) 105 113 117 250

means that the current peak is the RF transmission burst (Tx burst)

means that the current peak is the RF reception burst (Rx burst)

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 24 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.2.2.3 Consumption waveforms samples.

The consumption waveforms a given for a EGSM900 network configuration, with an AT software running inside the Q2686/X60 Wireless CPU.

The VBATT voltage as the typical value of 3.6V. Four significant workings modes consumption waveforms are described :

 Connected Mode (PCL5 : Tx power 33dBm)  Slow Idle mode (Paging 9)  Fast idle mode (Paging 9)  Transfer mode (GPRS class 10, PCL3 : Tx power 33dBm )

The following waveform provide only the form of the current, for good current values, see chapter 3.2.2.1 and 3.2.2.2.

3.2.2.3.1 Connected mode current waveform

1.6

1.4

1.2

0.8

0.6

0.4

0.2

Connected mode 33dBm

Current(A) / Time (s)

TX PEAK

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 25 / 87

3.2.2.3.2 Slow Idle mode current waveform

Slow Idle mode Paging ~2s

Current(A) / Time (s)

WM_PRJ_Q2686_PTS_001

April 4th 2006

0.16

RX PEAK

0.14

0.12

0.1

0.08

0.06

0.04

0.02

-0.02

3.2.2.3.3 Fast Idle mode current waveform

Fast Idle mode Paging ~2s

Current(A) / Time (s)

0.16

RX PEAK

0.14

0.12

0.1

0.08

0.06

0.04

0.02

confidential ©

Page : 26 / 87

3.2.2.3.4 Transfer mode Class 10 current waveform

Transfer mode Class 10 33dBm

Current(A) / Time (s)

1.6

1.4

TX PEAK

1.2

0.8

0.6

0.4

0.2

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.2.2.4 Power supply pinout

Power Supply Pinout

Signal Pin number

VBATT

GND

The grounding connection is done through the shielding  the four legs have

to be soldered to the ground plane.

confidential © This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

1,2,3,4

Shielding

Page : 27 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.3 Electrical information for digital I/O

There is tree types of digital I/O on the WISMO Quik Q2686 : 2.8Volt CMOS ,

1.8Volt CMOS and Open drain. The tree types are described below.

Electrical characteristics of digital I/O

2.8 Volts type (2V8 )

Parameter I/O type Minim. Typ Maxim. Condition

Internal 2.8V power supply VCC_2V8 2.74V 2.8V 2.86V

Input / Output pin

*Absolute maximum ratings

CMOS -0.5V* 0.84V

CMOS 1.96V 3.2V*

CMOS 0.4V IOL= - 4 mA

CMOS 2.4V IOH= 4 mA

4mA

- 4mA

All 2.8V I/O pins don’t accept input signal voltage over the maximum voltage specified above, excepting the UART1 interface which is 3.3V tolerant.

1.8 Volts type (1V8)

Parameter I/O type Minim. Typ Maxim. Condition

Internal 1V8 power supply VCC_1V8 1.76V 1.8V 1.94V

Input / Output pin

*Absolute maximum ratings

CMOS -0.5V* 0.54V

CMOS 1.33V 2.2V*

CMOS 0.4V IOL= - 4 mA

CMOS 1.4V IOH= 4 mA

4mA

- 4mA

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 28 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Open drain outputs type

Signal name Parameter I/O type Minimum Typ Maximum Condition

SDA /

GPIO27

and

SCL /

TOL

Open Drain 0.4VFLASH-LED

Open Drain 8mA

Open Drain 0.4VBUZZ-OUT

Open Drain 100mA

Open Drain 3.3V Tolerated

voltage

Open Drain 2V

Open Drain 0.8V

GPIO26

Open Drain 0.4V

Open Drain 3mA

The reset state of the I/O are given in each interfaces descriptions chapter. The definition of those states are described below:

Reset state definition

Parameter Définition

Pull down

Set to GND

Set to supply 1V8 or 2V8 depending of I/O type

Internal pull down with ~60K resistor.

Pull up Internal pull up with ~60K resistor to supply 1V8 or 2V8

depending of I/O type.

Z High impedance

Undefined Be careful, undefined mustn’t be used in your application if

a special state at reset is needed. Those pins can be a toggling signal during reset.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 29 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.4 Serial interface

The WISMO Quik Q2686 can be connected to a LCD Wireless CPU driver through either two SPI bus or an I²C 2-wire interfaces.

3.4.1 SPI bus

The both SPI bus interfaces include-:

 a CLK signal,

 an I/O signal,

 an I signal  an CS signal complying with standard SPI bus.

SPI bus characteristics:

 Master mode operation

 The SPI speed is from 101,5 Kbit/s up to 13 Mbit/s in master mode

operation

 3 or 4-wires interface

 SPI-mode configuration: 0 to 3

 1 to 16 bits data length

3.4.1.1 SPI waveforms

Waveform of SPI transfer with 4 wires configuration in master mode 0. ( Chip select is not represented ).

CLK-cycle

SPIx-CLK

Data-OUTdelay

SPIx-IO

Data valid

Data-IN-setup

Data-IN-hold

SPIx-I

Data valid

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 30 / 87

WM_PRJ_Q2686_PTS_001

Maximum

April 4th 2006

Figure 3 : SPI Timing diagrams, Mode 0, Master, 4 wires

AC characteristics

Signal Description Minimum Typ Maximum Unit

CLK-cycle SPI clock frequency 0.1015 13 MHz

Data-OUT delay Data out ready delay time 10 ns

Data-IN-setup Data in setup time 2 ns

Data-OUT-hold Data out hold time 2 ns

3.4.1.2 SPI configuration

Operation

Speed

Master 13 Mb/s 0,1,2,3 Half SPIx-CLK; SPIx-

SPI-

Mode

Duplex 3-wire type 4-wire type

SPIx-CLK; SPIx-IO;

IO; ~SPIx-CS

SPIx-I; ~SPIx-CS

For the 4-wires configuration, the SPIx-I/O is used as output only, SPIx-I is used as input only.

For the 3 wires configuration, the SPIx-I/O is used as input and output.

3.4.1.3 SPI1 bus

Pin description

Signal Pin

number

I/O I/O

type

Reset

state

Description Multiplexed

with

SPI1-CLK 23 O 2V8 Z SPI Serial Clock GPIO28

SPI1-IO 25 I/O 2V8 Z SPI Serial input/output GPIO29

SPI1-I 24 I 2V8 Z SPI Serial input GPIO30

~SPI1-CS 22 O 2V8 Z SPI Enable GPIO31

For Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition refer to chapter

3.3 Electrical information for digital I/O.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 31 / 87

3.4.1.4 SPI2 bus

WM_PRJ_Q2686_PTS_001

April 4th 2006

Pin description

Signal Pin

number

I/O I/O

type

Reset

state

Description Multiplexed

with

SPI2-CLK 26 O 2V8 Z SPI Serial Clock GPIO32

SPI2-IO 27 I/O 2V8 Z SPI Serial input/output GPIO33

SP2-I 29 I 2V8 Z SPI Serial input GPIO34

~SPI2-CS 28 O 2V8 Z SPI Enable GPIO35

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 32 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.4.2 I2C bus

The I2C interface includes a clock signal (SCL) and a data signal (SDA) complying with a 100Kbit/s-standard interface ( Standard mode : s-mode ).

The I²C bus is always master. The maximum speed transfer range is 400Kbit/s ( Fast mode : f-mode ).

For more information on the bus, see the “I²C Bus Specification Version

2.0”from PHILIPS.

3.4.2.1 I²C waveforms

Waveform of I²C bus in master mode configuration.

SCL

SDA

T-free

SCL-freq

T-high

T-start

Data valid

T-data-

hold

T-data-

setup

Data valid

Figure 4 : I²C Timing diagrams, Master

T-stop

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 33 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

AC characteristics

Signal Description Minimum Typ Maximum Unit

SCL-freq I²C clock frequency 100 400 KHz

T-start Hold time START condition 0.6 µs

T-stop Setup time STOP condition 0.6 µs

T-free Bus free time, STOP to START 1.3 µs

T-high High period for clock 0.6 µs

T-data-hold Data hold time 0 0.9 µs

T-data-setup Data setup time 100 ns

3.4.2.2 I²C bus pin out

Pin description

Signal Pin

number

I/O I/O type Reset

state

Description Multiplexed

with

SCL 44 O Open drain Z Serial Clock GPIO26

SDA 46 I/O Open drain Z Serial Data GPIO27

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 34 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.5 Keyboard interface

This interface provides 10 connections :

 5 rows (ROW0 to ROW4) and  5 columns (COL0 to COL4).

The scanning is a digital one and the debouncing is done in the WISMO Quik Q2686.

No discrete components like R,C (Resistor, Capacitor) are needed.

Pin description of the Keyboard interface

Signal Pin

number

I/O I/O

type

Reset

state

Description Multiplexed

with

ROW0 68 I/O 1V8 0 Row scan GPIO9

ROW1 67 I/O

ROW2 66 I/O

ROW3 65 I/O

ROW4 64 I/O

COL0 59 I/O

COL1 60 I/O

COL2 61 I/O

COL3 62 I/O

COL4 63 I/O

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

1V8

0 Row scan GPIO10

0 Row scan GPIO11

0 Row scan GPIO12

0 Row scan GPIO13

Pull up Column scan GPIO4

Pull up Column scan GPIO5

Pull up Column scan GPIO6

Pull up Column scan GPIO7

Pull up Column scan GPIO8

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 35 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.6 Main serial link (UART1)

A flexible 6-wire serial interface is available complying with V24 protocol signaling but not with V28 (electrical interface) due to a 2.8 Volts interface.

The signals are the follows:

 TX data (CT103/TX)

 RX data (CT104/RX)  Request To Send (~CT105/RTS)

 Clear To Send (~CT106/CTS)

 Data Terminal Ready (~CT108-2/DTR) and  Data Set Ready (~CT107/DSR).

The set of RS-232 signals can be required for GSM DATA services application and is generated by the general purpose I/O provided by the Q2686. The two additional signals are:

 Data Carrier Detect (~CT109/DCD) and

 Ring Indicator (CT125/RI).

Pin description of UART1 interface

Signal Pin

number

I/O I/O

type

Reset

state

Description Multiplexed

CT103/TXD1* 71 I 2V8 Z Transmit serial

data

CT104/RXD1* 73 O

2V8

1 Receive serial

data

~CT105/RTS1* 72 I

2V8

Z Request To

Send

~CT106/CTS1* 75 O

~CT107/DSR1* 74 O

~CT108-

76 I

2/DTR1*

~CT109/DCD1 * 70 O

2V8

Z Clear To Send GPIO39

Z Data Set Ready GPIO40

Z Data Terminal

Ready

Undefined Data Carrier

Detect

~CT125/RI1 * 69 O

2V8

Undefined Ring Indicator GPIO42

with

GPIO36

GPIO37

GPIO38

GPIO41

GPIO43

CT102/GND* Shielding

GND Ground

legs

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

*According to PC view

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 36 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

The rising time and falling time of the reception signals (mainly CT103) have to be less than 300 ns.

The Q2686 is designed to operate using all the serial interface signals. In particular, it is mandatory to use RTS and CTS for hardware flow control in order to avoid data corruption during transmission.

Maximum baud rate of the UART1 is 115 Kbit/s.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 37 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.7 Auxiliary serial link (UART2)

For future applications (e.g. Bluetooth connectivity) an auxiliary serial interface (UART2) will be available on Q2686 product.

Pin description of UART2 interface

Signal Pin

number

CT103 /

31 I 1V8 Z Transmit serial data GPIO14

I/O I/O type Reset

state

Description Multiplexed

with

TXD2*

CT104 /

30 O

1V8

Z Receive serial data GPIO15

RXD2*

~CT106 /

32 O

1V8

Z Clear To Send GPIO16

CTS2*

~CT105 /

33 I

1V8

Z Request To Send GPIO17

RTS2*

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

* According to PC view

Maximum baud rate of the UART2 is 115 Kbit/s.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 38 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.8 SIM interface

The Subscriber Identification Module can be directly connected to the WISMO Quik Q2686 Wireless CPU through this dedicated interface.

3.8.1 General Description

5 signals exist :

 SIM-VCC : SIM power supply.  ~SIM-RST : reset.  SIM-CLK : clock.  SIM-IO : I/O port.  SIMPRES : SIM card detect.

The SIM interface controls a 3V / 1V8 SIM. This interface is fully compliant with GSM 11.11 recommendations concerning SIM functions.

Pin description of SIM interface

Signal Pin

number

I/O I/O type Reset

state

Description Multiplexed

with

SIM-CLK 14 O 2V9 / 1V8 0 SIM Clock Not mux

~SIM-RST 13 O

SIM-IO 11 I/O

SIM-VCC 9 O

2V9 / 1V8

0 SIM Reset

*Pull up SIM Data

SIM Power

Not mux

Supply

SIMPRES 12 I

1V8

Z SIM Card

GPIO18

Detect

*SIM-IO pull up is about 10K ohm

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 39 / 87

WM_PRJ_Q2686_PTS_001

IO,

VCC Output

CLK Rise/Fall

RST, Rise/Fall

IO Rise/Fall

April 4th 2006

Electrical Characteristics of SIM interface

Parameter Conditions Minim. Typ Maxim. Unit

SIM-IO V

~SIM-RST, SIM-CLK V

SIM-IO V

~SIM-RST, SIMSIM-CLK

Voltage

SIM-VCC current

SIMTime

~SIMTime

IIH= ± 20µA

IIL= 1mA

Source current = 20µA

Sink current =

-200µA

SIMVCC = 2.9V

IVCC= 1mA

SIMVCC = 1.8V

IVCC= 1mA

VBATT = 3.6V

Loaded with 30pF

0.7xSIMVCC V

0.4 V

0.9xSIMVCC V

0.8xSIMVCC

0.4 V

2.84 2.9 2.96

1.74 1.8 1.86

VSIM-

20 ns

SIM-

Loaded with 30pF

0.7 1 µs

Time

SIM-CLK Frequency

Loaded with 30pF

3.25

Note : When SIMPRES is used, a low to high transition means that the SIM card is

inserted and a high to low transition means that the SIM card is removed.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 40 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.9 General Purpose Input/Output

The WISMO Quik Q2686 provides up to 42 General Purpose I/O. They are used to control any external device such as a LCD or a Keyboard backlight.

All grey highlight I/O are 1V8 whereas the others are 2V8.

Pin description of GPIO

Signal

number

I/O I/O type*

Reset state

Multiplexed with

Reserved 42 Do not used*

GPIO1 51 I/O 1V8 0 Not mux*

GPIO2 53 I/O 1V8 0 Not mux*

GPIO3 50 I/O 1V8 Z INT0

GPIO4 59 I/O 1V8 Pull up COL0

GPIO5 60 I/O 1V8 Pull up COL1

GPIO6 61 I/O 1V8 Pull up COL2

GPIO7 62 I/O 1V8 Pull up COL3

GPIO8 63 I/O 1V8 Pull up COL4

GPIO9 68 I/O 1V8 0 ROW0

GPIO10 67 I/O 1V8 0 ROW1

GPIO11 66 I/O 1V8 0 ROW2

GPIO12 65 I/O 1V8 0 ROW3

GPIO13 64 I/O 1V8 0 ROW4

GPIO14 31 I/O 1V8 Z CT103 / TXD2

GPIO15 30 I/O 1V8 Z CT104 / RXD2

GPIO16 32 I/O 1V8 Z ~CT106 / CTS2

GPIO17 33 I/O 1V8 Z ~CT105 / RTS2

GPIO18 43 I/O 1V8 Z SIMPRES

GPIO19 45 I/O 2V8 Z Not mux

GPIO20 48 I/O 2V8 Undefined Not mux

GPIO21 47 I/O 2V8 Undefined Not mux

GPIO22 57 I/O 2V8 Z

Not mux**

GPIO23 55 I/O 2V8 Z Not mux

GPIO24 58 I/O 2V8 Z Not mux

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 41 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Signal

number

I/O I/O type*

Reset state

Multiplexed with

GPIO25 49 I/O 2V8 Z INT1

Signal

GPIO26

GPIO27

number

44 I/O

46 I/O

I/O I/O type*

Open

drain

Open

drain

Reset state

Multiplexed with

SCL

SDA

GPIO28 23 I/O 2V8 Z SPI1-CLK

GPIO29 25 I/O 2V8 Z SPI1-IO

GPIO30 24 I/O 2V8 Z SP1-I

GPIO31 22 I/O 2V8 Z ~SPI1-CS

GPIO32 26 I/O 2V8 Z SPI2-CLK

GPIO33 27 I/O 2V8 Z SPI2-IO

GPIO34 29 I/O 2V8 Z SP2-I

GPIO35 28 I/O 2V8 Z ~SPI2-CS

GPIO36 71 I/O 2V8 Z CT103 / TXD1

GPIO37 73 I/O 2V8 1 CT104 / RXD1

GPIO38 72 I/O 2V8 Z ~CT105 / RTS1

GPIO39 75 I/O 2V8 Z ~CT106 / CTS1

GPIO40 74 I/O 2V8 Z ~CT107 / DSR1

GPIO41 76 I/O 2V8 Z ~CT108-2 / DTR1

GPIO42 69 I/O 2V8 Undefined ~CT125 / RI1

GPIO43 70 I/O 2V8 Undefined ~CT109 / DCD1

GPIO44 43 I/O 2V8 Undefined Not mux

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

* On the Q2687/X61 product, those pins are multiplexed with the control signals of the parallel

bus (parallel bus is only available on the Q2687/X61 product).If an upgrade to the Q2687/X61 is envisaged, and if the parallel bus is used, those pins will be mandatory for the parallel bus functionality.

** If a Bluetooth module is used with the Q2686 Wireless CPU, those GPIO must be reserved.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 42 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.10 Analog to Digital Converter

Two Analog to Digital Converters inputs are provided by the WISMO Quik Q2686. Those converters are 10 bits resolution, ranging from 0 to 2V.

Pin description of ADC

Signal Pin number I/O I/O type Description

BAT-TEMP* 20 I Analog A/D converter

AUX-ADC 21 I Analog A/D converter

This input is reserved for battery charging temperature sensor,

see chapter “3.13 Battery Charging interface “.

Electrical Characteristics of ADC

Parameter Min Typ Max Unit

Resolution

Sampling rate

Input signal range

Input

BAT-TEMP

0 2 V

impedance

AUX-ADC

* internally pull up to 2.8V

Sampling rate only for AUX-ADC and Open AT® application.

10 bits

138

S/s



This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 43 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.11 Analogue audio interface

Two different microphone inputs and two different speakers outputs are supported.

The WISMO Quik Q2686 also includes an echo cancellation feature which allows handsfree function.

3.11.1 Microphone inputs

The MIC2 inputs already include the biasing for an electret microphone allowing an easy connection.

The MIC1 input needs to have an external biasing if an electret micro is used.

3.11.1.1 Common microphone inputs characteristics

The connection can be either differential or single-ended but using a differential

connection in order to reject common mode noise and TDMA noise is strongly recommended. When using a single-ended connection, be sure to have a very

good ground plane, a very good filtering as well as shielding in order to avoid any disturbance on the audio path.

The gain of MIC inputs is internally adjusted and can be tuned using an AT command.

Both can be configured in differential or single ended.

3.11.1.2 Main Microphone Inputs (MIC2)

By default, the MIC2 inputs are differential ones, but it can be configured in single ended. They already include the convenient biasing for an electret microphone. The electret microphone can be directly connected on those inputs.

AC coupling is already embedded in the Wireless CPU.

Pin description of MIC2

Signal Pin

I/O I/O type Description

number

MIC2P 36 I Analog Microphone 2 positive input

MIC2N 34 I Analog Microphone 2 negative input

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 44 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.11.1.3 Auxiliary Microphone Inputs (MIC1)

By default, the MIC1 inputs are single-ended but it can be configured in differential. An external biasing is needed if an electret micro is used.

AC coupling is already embedded in the Wireless CPU.

Pin description of MIC1

Signal Pin

I/O I/O type Description

number

MIC1P 40 I Analog Microphone 1 positive input

MIC1N 38 I Analog Microphone 1 negative input

3.11.1.4 Micro Electrical characteristics

The characteristics of the both micro inputs of the WISMO Quik Q2686 are defined in the following arrays.

MIC2 Characteristics

Parameter Min. Typ Max. Unit

Voltage 2 2.1 2.2 VInternal

Biasing

Impedance

single ended

MIC2P (MIC2N left opened) 1100 1340 1600

MIC2N (MIC2P left opened) 1100 1340 1600

Output Current 1.5 mA

Internal AC coupling 100 nF

MIC2P (MIC2N = GND) 900 1140 1400

MIC2N (MIC2P = GND) 900 1140 1400



Differential Input Voltage* 346 mVRMSInput voltage

Absolute maximum ratings 0 6V ** V

MIC1 Characteristics

Parameter Minim. Typ Maxim. Unit

Voltage N/A VInternal

Biasing

Impedance

single ended

MIC1P (MIC1N left opened) 70 100 162

MIC1N (MIC1P left opened) 70 100 162

Output Current N/A A

Internal AC coupling 100 nF

MIC1P (MIC1N = GND) 70 100 162

MIC1N (MIC1P = GND) 70 100 162

k k k k

Differential Input Voltage * 346 mVRMSInput voltage

Absolute maximum ratings 0 6 V

 * The input voltage depends of the input micro gain set by AT command.  ** Because MIC2P is internally biased, it is necessary to use a coupling capacitor to

connect a audio signal provided by an active generator. Only a passive microphone can be directly connected to the MI2P and MIC2N inputs.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 45 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.11.2 Common speaker outputs characteristics

The connection is single-ended on SPK1 and is differential or single-ended on SPK2. Using a differential connection to reject common mode noise and TDMA

noise is strongly recommended. Moreover in single-ended mode, ½ of the power is lost. When using a single-ended connection, be sure to have a very

good ground plane, a very good filtering as well as shielding in order to avoid any disturbance on the audio path.

3.11.2.1 Differential Connection

Impedance of the speaker amplifier output in differential mode is shown below:

Parameter Typ Unit

Z (SPK2P, SPK2N)



3.11.2.2 Single-ended Connection

Impedance of the speaker amplifier output in single-ended mode is shown below:

Electrical Characteristics

Parameter Typ Unit

Z (SPK1P, SPK1N)

Z (SPK2P, SPK2N)

16 or 32



3.11.3 Speaker outputs

3.11.3.1 Speaker 2 Outputs

Pin description of Speaker 2 outputs

Signal Pin

I/O I/O type Description

number

SPK2P 39 O Analog Speaker 2 positive output

SPK2N 41 O Analog Speaker 2 negative output

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 46 / 87

3.11.3.2 Speaker 1 Outputs

Single ended with load of 32

Pin description of Speaker 1 outputs

WM_PRJ_Q2686_PTS_001

April 4th 2006

Signal Pin

I/O I/O type Description

number

SPK1P 35 O Analog Speaker 1 positive output

SPK1N 37 O Analog Speaker 1 negative output

3.11.3.3 Speakers Outputs Power

The both speakers maximum power output are not similar, that’s due to the different configuration between the Speaker1 which is only single ended and the speaker2 which can be differential, so speaker2 can provides more power.

The maximal specifications given below are available with the maximum power output configuration values set by an AT command.

Speaker1 single ended SPK1P output Characteristics

Parameter Minim. Typ Maxim. Unit

Output

Voltage 1.20 V

Biasing

Output

0 2.75 VPP

Voltage

Output

Power

ohm

27 mW

Output

Maximum tolerated 85 mA

Current

Only SPK1P can be used.

Speaker2 deferential output Characteristics

Parameter Minim. Typ Maxim. Unit

Output

Voltage SPK2P and SPK2N 1.20 V

Biasing

Output

Voltage

Voltage on SPK2P 0 0.9 VPP

Voltage on SPK2N 0 0.9 VPP

Diff voltage

0 1.8 VPP

(SPK2P – SPK2N)

Output

Power

Output

Differential with load of 8

48 mW

ohm

Maximum tolerated 110 mA

Current

If a singled ended solution is used with the speaker2 output, only one of the both SPK2 has to be chosen. The result is an maximal output power divided by

confidential ©

Page : 47 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.12 Buzzer Output

This output is controlled by a pulse wide modulation controller and can be used only as buzzer.

The BUZZ-OUT is an open drain one. A buzzer can be directly connected between this output and VBATT. The maximum current is 100 mA (PEAK).

Pin description of PWM/Buzzer output

Signal Pin

I/O I/O type Reset state Description

number

BUZZ-OUT 15 O Open

Z Buzzer output

drain

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

Electrical Characteristics

Parameter Condition Minimum Maximum Unit

OL on

PEAK

Frequency 1 50000

Iol = 100mA 0.4

VBATT = VBATTmax 100

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 48 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.13 Battery charging interface

The WISMO Quik Q2686 Wireless CPU supports one battery charging circuit, 2 algorithms and one hardware charging mode (Pré-charging) for 3 batteries technologies:

 Ni-Cd (Nickel-Cadmium) with algorithm 0  Ni-Mh (Nickel-Métal Hydrure) with algorithm 0  Li-Ion (Lithium-Ion) with algorithm 1

The two algorithms control a switch, which connects the CHG-IN signal to the VBATT signal. The algorithm controls the frequency and the connected time of the switching. During the charging procedure the battery charging level is controled and when Li-Ion algorithm is used, the battery temperature is monitoring thorough the BAT-TEMP ADC input.

One more charging procedure is provided by the Q2686 Wireless CPU. It’s

called “Pre-charging” mode, but it’s a special charging mode because it is activated only when the Wireless CPU is OFF. So the control is only performed by the hardware. The goal of this charging mode is to prevent the battery to be damaged by preventing the discharged under the minimum battery level.

3.13.1 Ni-Cd / Ni-Mh Charging algorithm

To charge the battery, the algorithm measures the battery level when the switch is opened T2 and charges the battery by closing the switch T3. When the battery is charged (battery voltage reached BattLevelMax) the switch is opened during the time T3.

BattLevelMax

Battery Level

T1T2 T3

closed

Switch State

opened

Figure 5 : Ni-Cd / Ni-Mh charging waveform

Electrical Characteristics of Ni-Cd / Ni-Mh battery timing charge

Parameter Min Typ Max Unit T1 1 s T2 0.1 s T3 5 s

Note : T1,T2,T3 and BattLevelMax can be configured by AT command.

The battery level is monitoring by the software but not the temperature.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 49 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.13.2 Li-Ion Charging algorithm

The LI-Ion algorithm, provides the temperature monitoring of the battery which is highly recommended to prevent the damage of battery during the charging phase.

The Li-Ion charger algorithm can be decomposed in 3 phases :

1. Constant charge

2. Beginning of pulse charge

3. End of pulse charge

The three phases can be seen on the following waveform of a complete charge:

Figure 6 : Li-Ion full charging waveform

Electrical Characteristics of Li-Ion battery timing charge

Parameter Min Typ Max Unit

Step 1 switching Closed always s

Opened 0.1 sStep 2 switching

Closed 1 s

Opened 0.1 10 sStep 3 switching

Closed 1 s

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 50 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.13.3 Pré-Charging hardware controlled

One more charging mode is existing, but it’s not software controlled, it’s the Pre-charging mode. This mode is only controlled by hardware. This mode is only activated when the Wireless CPU is OFF and when the VBATT is in this voltage range : 2.8V < VBATT < 3.2V. Of course, the charger power supply has to be plugged on the CHG-IN (pin 6,8). During the Pré-charging mode the battery is charged with a direct current of 50mA. The FLASH-LED blinks when this mode is activated.

This mode is not a real charging mode, because it not possible to have a full charge with it, but it is useful to safe the battery life by preventing the battery to be discharge under the low limit voltage value.

3.13.4 Temperature monitoring

The monitoring of the temperature is only available for the Li-Ion battery with the algorithm number 1. The BAT-TEMP (pin 20) ADC input must be used to sample the temperature analog signal provided by a NTC temperature sensor. The minimum an maximum temperature range can be set by AT command.

Pin description of battery charging interface

Signal Pin number I/O I/O type Description

CHG-IN 6,8 I Analog Current source input

BAT-TEMP 20 I Analog A/D converter

Electrical Characteristics of battery charging interface

Parameter Minimum Typ Maximum Unit

Charging Operating temperature 0 50 °C

BAT-TEMP (pin 20 )

CHG-IN (pin 6, 8 )

resolution 10 bits

sampling rate 216 S/s

Input Impedance ( R ) 1M

Input signal range 0 2 V

Voltage (for I=Imax) 4.6* V



Voltage (for I=0) 6* V

Current Imax 800 mA

* To be parameterized as per battery manufacturer

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 51 / 87

WM_PRJ_Q2686_PTS_001

POWER SUPPLY

ON/OFF

STATE OF THE MODULE

RESET mode

INTERNAL RST

Module ON

= overall current

consumption (Base Band + RF part)

April 4th 2006

3.14 ON / ~OFF signal

This input is used to switch ON or OFF the WISMO Quik Q2686 Wireless CPU. A high level signal has to be provided on the pin ON/~OFF to switch ON the

Wireless CPU. The voltage of this signal has to be maintained during a minimum of 1000ms. This signal can be left at high level until switch off.

To switch OFF the Wireless CPU, the pin ON/OFF has to be released. The

Wireless CPU can be switched off through the Operating System.

3.14.1 Operating sequences

3.14.1.1 Power ON

Once the Wireless CPU supplied, the application must set the ON/OFF signal to high to start the Wireless CPU power ON sequence. The ON/OFF signal must be hold for 2000ms minimum. After this time, an internal mechanism keeps it on hold. During the power ON sequence, an internal reset is automatically performed by the Wireless CPU for 40ms (typical). During this phase, any external reset should be avoided. Once the initialization is complete (timing is SIM and network dependent) the AT interface answers « OK » to the application. For further details, please check the AT commands Interface Guide.

on/off-hold

(2000ms min)

rst

(40ms typ)

AT answers « OK »

BB+RF

Module OFF

< 22µA

BB+RF

=20 to 40mA

BB+RF

SIM and Network dependent

BB+RF

(no loc. update)

<120mA

Module READY

Figure 7 : Power-ON sequence (no PIN code activated)

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 52 / 87

WM_PRJ_Q2686_PTS_001

POWER SUPPLY

ON/OFF

AT COMMAND

AT+CPOF

Module OFF

OK response

April 4th 2006

3.14.1.2 Power OFF

To properly power OFF the Wireless CPU, the application must set the ON/OFF signal to low and then send the AT+CPOF command to deregister from the network and switch off the Wireless CPU. Once the « OK » response is issued by the Wireless CPU, the power supply can be switched off.

Network dependent

STATE OF THE MODULE

= overall current consumption (Base Band + RF part)

BB+RF

Module

READY

Figure 8 : Power-OFF sequence

Pin description

Signal Pin number I/O I/O type Description

ON/OFF

19 I CMOS Wireless CPU Power

Electrical Characteristics of the signal

Parameter I/O type Minimum Maximum Unit

CMOS VBATT x 0.2 V

CMOS VBATT x 0.8 VBATT V

BB+RF

<22µA

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 53 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.15 BOOT signal

A specific control pin BOOT is available to download the WISMO Quik Q2686 Wireless CPU only if the standard XMODEM download, controlled with AT command, is not possible.

A specific PC software, provided by WAVECOM, is needed to performed this specific download.

The BOOT pin must be connected to the VCC_1V8 for this specific download.

Operating mode description

BOOT Operating mode Comment

Leave open Normal use No download

Leave open Download XMODEM AT command for Download

AT+WDWL

1 Download specific Need WAVECOM PC software

For more information, see Q2686 / OS 6.60 AT Command Interface Guide.

This BOOT pin must be leave open for normal use or XMODEM download. However, in order to make development and maintenance phases easier, it is

highly recommended to set a test point, either a jumper or a switch to

VCC_1V8 (pin 5) power supply.

Pin description

Signal Pin number I/O I/O type Description

BOOT 16 I 1V8 Download mode selection

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 54 / 87

WM_PRJ_Q2686_PTS_001

RESET mode

~RESET

STATE OF

Module

AT answers “OK”

Module

Module ON

Ct = Typ:34ms

April 4th 2006

3.16 Reset signal (~RESET)

This signal is used to force a reset procedure by providing low level during at least 200µs. This signal has to be considered as an emergency reset only. A reset procedure is already driven by an internal hardware during the power-up sequence.

This signal can also be used to provide a reset to an external device (at power up only ). If no external reset is necessary this input can be left open. If used (emergency reset), it has to be driven by an open collector or an open drain.

The Wireless CPU remains in reset mode as long as the ~RESET signal is held low.

CAUTION: This signal should be used only for “emergency” resets.

An Operating System reset will be preferred to an hardware reset.

Reset sequence :

To activate the « emergency » reset sequence, the ~RESET signal has to be set to low for 200s minimum. As soon as the reset is complete, the AT interface

answers « OK » to the application.

<120mA without

THE

MODULE

READY

Rt = Min1:200s

or Typ2= 40ms

BB+RF

=20 to 40mA

BB+RF

loc update

SIM and network

dependent

READY

Figure 9 : Reset sequence waveform

At power up, the ~RESET time (Rt), is performed after switching ON the Wireless CPU. It is generated by internal WISMO Quik Q2686 voltage supervisor.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 55 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

The ~RESET time is provided by the internal RC component. To keep the same

time, it’s not recommended to plug an other R or C component on the ~RESET signal. Only a switch or an open drain gate is recommended.

The Ct time is the cancellation time needed for the wireless CPU Q2686 initialization. Ct time is automatically done by the Q2686 Wireless CPU after a hardware reset.

Electrical Characteristics of the signal

Parameter Minimum Typ Maxomum Unit

Input Impedance ( R )*

Input Impedance ( C )

~RESET time (Rt)

~RESET time (Rt) 2at power

200

20 40 100

330K

10n



µs

up only

Cancellation time (Ct)

* internal pull up

* V

Hysterisis Voltage

H :

1 This reset time is the minimum to be performed on the ~RESET signal when the power supply is already stabilized.

2 This reset time is internally performed by the power supply supervisor of the Wireless CPU , only when the Wireless CPU power supplies are powered ON.

0.57

0 0.57

1.33

Pin description

Signal Pin

I/O I/O type Description

number

~RESET 18 I/O Open Drain 1V8 Wireless CPU

Reset

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 56 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.17 External Interrupt

The WISMO Quik Q2686 provides two externals interrupts inputs. Those interrupt input can be activated on :

 high to low edge

 low to high edge  low to high and high to low edge

 low level

 high level

When used, interruptions input must not be left opened. If not used, they have to be configured as GPIO.

Pin description

Signal Pin

number

I/O I/O type Reset

state

Description Multiplexed

with

INT1 49 I 2V8 Z External Interrupt GPIO25

INT0 50 I 1V8 Z External Interrupt GPIO3

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

Electrical characteristics of the signals

Parameter Minimum Maximum Unit

INT1

INT0

1.96

1.33 V

0.84

0.54

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 57 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.18 VCC_2V8 and VCC_1V8 output

Those outputs can be used only for pull-up resistor. VCC_2V8 and VCC_1V8 have to be used as a reference supply. Those voltages supplies are available when the Wireless CPU is on.

Pin description

Signal Pin number I/O I/O type Description

VCC_2V8 10 O Supply Digital supply VCC_1V8 5 O Supply Digital supply

Electrical characteristics of the signals

Parameter Minimum Typ Maximum Unit

VCC_2V8

VCC_1V8

Output voltage 2.74 2.8 2.86 V

Output Current 15 mA

Output voltage 1.76 1.8 1.94 V

Output Current 15 mA

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 58 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.19 BAT-RTC (Backup Battery)

The WISMO Quik Q2686 provides an input / output to connect a Real Time Clock power supply.

3.19.1 Interface description

This pin is used as a back-up power supply for the internal Real Time Clock. The RTC is supported by the Wireless CPU when VBATT is available but a back-up power supply is needed to save date and hour when the VBATT is switched off (VBATT = 0V).

Q2686

from VBATT

to RTC

2.5V

regulator

1.8V

regulator

BAT-RTC (Pin 7)

Figure 10 : Real Time Clock power supply

If the RTC is not used this pin can be left open. If the VBATT is available, the back-up battery can be charged by the internal

2.5V power supply regulator. Pin description

Signal Pin number I/O I/O type Description

BAT-RTC 7 I/O Supply RTC Back-up supply

Electrical characteristics of the signal

Parameter Minimum Typ Maximum Unit

Input voltage 1.85 2.5 V

Input current

3.3 µA

consumption*

Output voltage 2.45 V

Output current 2 mA

*Provided by a RTC back-up battery when Wireless CPU power supply are off (VBATT = 0V).

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 59 / 87

WM_PRJ_Q2686_PTS_001

(charger must be

IN to

Wireless CPU switched ON,

gistered on the

Wireless CPU switched ON,

registered on the network,

LED ON for 100ms, OFF

Wireless CPU switched on,

software downloaded is

compatible ("BAD

April 4th 2006

3.20 FLASH-LED signal

FLASH LED is an open drain output. A LED and a resistor can be directly connected between this output and VBATT.

When the Q2686 Wireless CPU is OFF, if 2.8V < VBATT < 3.2V and a charger is connected on CHG-IN inputs, this output indicates, by flashing ( 100 ms ON, 900 ms OFF ) , the pre-charging phase of the battery.

When the Q2686 Wireless CPU is ON, this output is used to indicate the network status.

FLASH-LED status

Q2686 state

s CPU

OFF

Wireles

s CPU

VBATT status FLASH-LED status WISMO Quik Q2686 status

VBATT<2.8V or

OFF Wireless CPU is OFFWireles

VBATT> 3.2V

2.8V < VBATT < 3.2V

Pré-charge flash LED ON for 100 ms,

Wireless CPU is OFF, Pre-charging mode

OFF for 900 ms

connected on CHGactivate this mode)

VBATT > 3.2V

Permanent

not re network

Slow flash LED ON for 200 ms,

registered on the network OFF for 2 s

Quick flash LED ON for 200 ms,

OFF for 600 ms

communication in progress

Very quick flash

Signal Pin

FLASH-

LED

for 200ms

Pin description

I/O I/O type Reset state Description

number

17 O Open Drain

Output

confidential ©

either corrupted or non-

SOFTWARE")

1 and

LED driving

Undefined

Page : 60 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage characteristics and for Reset state definition.

~RESET

pin 18

FLASH-LED

pin 17

led OFF

Undefined

Module Status

Figure 11 : FLASH-LED state during RESET and Initialization time

The FLASH-LED state is high during the RESET time and undefined during the software initialization time. During software initialization time, during 2 seconds max after RESET cancellation , the FLASH-LED signal is toggling and

it doesn’t provide the Wireless CPU status. After the 2s, the FLASH-LED provides the true status of the Wireless CPU.

Electrical characteristics of the signal

Parameter Condition Minimum Typ Maximum Unit

VOL 0.4 V

IOUT 8 mA

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 61 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.21 Digital audio interface (PCM)

The Digital audio interface (PCM) interface mode allows the connectivity with audio standard peripherals. It can be used, for example, for connecting an external audio codec.

The programmability of this mode allows address a large range of audio peripherals.

PCM features :

 IOM-2 compatible device on physical level

 Master mode only with 6 slots by frame, user only on slot 0  Bit rate single clock mode at 768KHz only

 16 bits data word MSB first only

 Linear Law only (no compression law)

 Long Frame Synchronization only  Push pull configuration on PCM-OUT and PCM-IN

The digital audio interface configuration can’t be different from the specified features above.

3.21.1 Description

PCM interface consists of 4 wires :

 PCM-SYNC ( output ) : The frame synchronization signal delivers an

8KHz frequency pulse that synchronizes the frame data in and the frame data out.

 PCM-CLK ( output ) : The frame bit clock signal controls the data transfer

with the audio peripheral.

 PCM-OUT ( output ) : The frame “data out” depending on the selected

configuration mode.

 PCM-IN ( input ) : The frame “data in” is depending on the selected

configuration mode.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 62 / 87

PCM-SYNC

PCM-CLK

PCM-IN

WM_PRJ_Q2686_PTS_001

April 4th 2006

Tsync_high Tsync_low

PCM-OUT

PCM-SYNC

PCM-CLK

PCM-IN

SLOT 5

SLOT 0 SLOT 1 SLOT 5 SLOT 0

Figure 12 : PCM Frame waveform

TSYNC-CLK

TIN-setup

TIN-hold

TCLK-cycle

SLOT 0 bit 15 SLOT 0 bit 14 SLOT 0 bit 13SLOT 5 bit 0

TOUTdelay

PCM-OUT

SLOT 0 bit 15 SLOT 0 bit 14 SLOT 0 bit 13SLOT 5 bit 0

Figure 13 : PCM Sampling waveform

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 63 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

AC characteristics

Signal Description Minimum Typ Maximum Unit

Tsync_low +

PCM-SYNC period 125 µs

Tsync_high

Tsync_low PCM-SYNC low time 93 µs

Tsync_high PCM-SYNC high time 32 µs

TSYNC-CLK PCM-SYNC to PCM-CLK time -154 Ns

TCLK-cycle PCM-CLK period 1302 Ns

TIN-setup PCM-IN setup time 50 Ns

TIN-hold PCM-IN hold time 50 Ns

TOUT-delay PCM-OUT delay time 20 Ns

Pin description of PCM interface

Signal Pin

I/O I/O type Reset state Description

number

PCM-SYNC 77 O 1V8 Pull down Frame synchronization

8Khz

PCM-CLK 79 O 1V8 Pull down Data clock

PCM-OUT 80 O 1V8 Pull up Data output

PCM-IN 78 I 1V8 Pull up Data input

See chapter “3.3 Electrical information for digital I/O” for Open drain, 2V8 and 1V8 voltage

characteristics and for Reset state definition.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 64 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.22 USB 2.0 interface

A 4-wire USB slave interface is available, compiling with USB 2.0 protocol signaling, but not with electrical interface, due to the not complying 5V of VPAD-USB.

The USB interface signals are VPAD-USB, USB-DP, USB-DM and GND. USB interface features :

 12Mbit/s full speed transfer rate  3.3V typ compatible  USB Softconnect feature  Download feature is not supported by USB  CDC 1.1 – ACM compliant

NOTE:

A 5V to 3.3V typ voltage regulator is needed between the external interface power in line ( +5V ) and the Wireless CPU line ( VPAD-USB ).

Pin description of USB interface

Signal Pin

I/O I/O type Description

number

VPAD-USB 52 I VPAD_USB USB Power Supply

USB-DP 54 I/O VPAD_USB Differential data interface positive

USB-DM 56 I/O VPAD_USB Differential data interface negative

Electrical characteristics of the signals

Parameter Min Typ Max Unit

VPAD-USB, USB-DP, USB-DM 3 3.3 3.6 V

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 65 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

3.23 RF interface

The impedance is 50 Ohms nominal and the DC impedance is 0 Ohm.

3.23.1 RF connections

U.FL Connector

A wide variety of cables fitted with U.FL connectors is proposed by different supplier.

Soldered solution

The soldered solution will preferably be based on a RG178 coaxial cable.

IMP connector

This connector is dedicated to board to board application and must be soldered on customer board. The supplier is Radiall with the following reference : R107 064 900.

Notes :

 The WISMO Quik Q2686 does not support an antenna switch for a car

kit but this function can be implemented externally and it can be driven using a GPIO.

 The antenna cable and connector should be chosen in order to minimize

losses in the frequency bands used for GSM 850/900MHz and 1800/1900MHz.

 0.5dB can be considered as a maximum value for loss between the

Wireless CPU and an external connector.

 Concerning mounting, assembly and handling of the IMP connector,

please contact directly the supplier Radiall. Wavecom can not support the customer regarding the use of this connector.

3.23.2 RF performances

RF performances are compliant with the ETSI recommendation GSM 05.05. The main parameters for Receiver are :

 GSM850 Reference Sensitivity = -104 dBm Static & TUHigh  E-GSM900 Reference Sensitivity = -104 dBm Static & TUHigh  DCS1800 Reference Sensitivity = -102 dBm Static & TUHigh  PCS1900 Reference Sensitivity = -102 dBm Static & TUHigh  Selectivity @ 200 kHz : > +9 dBc  Selectivity @ 400 kHz : > +41 dBc  Linear dynamic range : 63 dB  Co-channel rejection : >= 9 dBc

And for Transmitter :

 Maximum output power (EGSM & GSM850): 33 dBm +/- 2 dB at ambient

temperature

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 66 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

 Maximum output power (GSM1800 & PCS1900) : 30 dBm +/- 2 dB at

ambient temperature

 Minimum output power (EGSM & GSM850) : 5 dBm +/- 5 dB at ambient

temperature

 Minimum output power (GSM1800 & PCS1900) : 0 dBm +/- 5 dB at

ambient temperature

3.23.3 Antenna specifications

The antenna must fulfill the following requirements :

 The optimum operating frequency depends on application. A dual Band or a quad band antenna shall work in these frequency bands and have the following characteristics :

Q2686

Characteristic

E-GSM 900 DCS 1800 GSM 850 PCS 1900

TX Frequency 880 to 915

MHz

RX Frequency 925 to 960

MHz

1710 to

1785 MHz

1805 to

1880 MHz

824 to 849

869 to 894

Impedance 50 Ohms

Rx max 1.5 :1

VSWR

Tx max 1.5 :1

Typical radiated gain

0dBi in one direction at least

MHz

1850 to 1910

MHz

1930 to 1990

MHz

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 67 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

4 Technical specifications

4.1 General Purpose Connector pin out description

Description I/O* Voltage

Power

Supply

Power

Supply

1.8V Supply Output

RTC Battery

connection

SIM Power

Supply

SIM Data I/O

SIM reset

Output

Buzzer Output

Flash Led

Output

ON / ~OFF

Control

Analogue to

Digital Input

SPI1 Clock O VCC_2V8 GPIO32 SPI1-CLK

SPI1 Data

Input /

Output

SPI2 Data

Input /

Output

SPI2 Data

Input

Auxiliary

RS232

Transmit

Auxiliary

RS232

Request To

Send

Speaker 1

Output

Positive

Speaker 1

Output

Negative

I VBATT VBATT

O VCC_1V8 VCC_1V8

BAT-

I/O

I/O VCC_2V8 GPIO29 SPI1-IO

I/O VCC_2V8 GPIO33 SPI2-IO

RTC

1V8 or

O Analog SPK1P

O Analog SPK1N

1V8 or

Open Drain

I VBATT ON/~OFF

I Analog

I VCC_2V8 GPIO34 SPI2-I

I VCC_1V8 GPIO14

I VCC_1V8 GPIO17

Signal Name Signal Name

Mux Nominal

BAT-RTC

SIM-VCC

SIM-IO

~SIM-

RST

BUZZ-

OUT

FLASH-

LED

AUX-

ADC

CT103-

TXD2

~CT105-

RTS2

Number

1 2

3 4

5 6

7 8

9 10

11 12

13 14

15 16

17 18

19 20

21 22

23 24

25 26

27 28

29 30

31 32

33 34

35 36

37 38

Nominal Mux

VBATT VBATT I

CHG-IN CHG-IN I

VCC_2V8 VCC_2V8 O

SIMPRES GPIO18 VCC_1V8 I

SIM-CLK

BOOT VCC_1V8 I Not Used

~RESET VCC_1V8 I/O RESET Input

BAT-

TEMP

~SPI1-CS GPIO31 VCC_2V8 O

SPI1-I GPIO30 VCC_2V8 I

SPI2-CLK GPIO32 VCC_2V8 O SPI2 Clock

~SPI2-CS GPIO35 VCC_2V8 O

CT104-

RXD2

~CT106-

CTS2

MIC2N Analog I

MIC2P Analog I

MIC1N Analog I

GPIO15 VCC_1V8 O

GPIO16 VCC_1V8 O

Voltage I/O* Description

Power Supply

Charger

input

Charger

input

2.8V Supply Output

SIM

Detection

1V8 or

Analog I

O SIM Clock

Analogue

temperature

SPI1 Chip

Select

SPI1 Data

Input

SPI2 Chip

Select

Auxiliary

RS232

Receive

Auxiliary

RS232 Clear

To Send

Micro 2

Input

Negative

Micro 2

Input

Positive

Micro 1

Input

Negative

confidential ©

Page : 68 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Description I/O* Voltage

Speaker 2

Output

Positive

Speaker 2

Output

Negative

Interruption

1 Input

Keypad column 0

Keypad column 2

Keypad column 4

Keypad Row 3

Keypad Row 1

Main RS232

Ring

Indicator

Main RS232

Transmit

Main RS232

Receive

Main RS232

Clear To

Send

PCM Frame

Synchro

PCM Clock O VCC_1V8

O Analog SPK2P

O Analog SPK2N

I/O VCC_2V8 GPIO44

I/O VCC_2V8 GPIO19

I/O VCC_2V8 GPIO21

I VCC_2V8 GPIO25 INT1

I/O VCC_1V8 ** GPIO1

I/O VCC_1V8 ** GPIO2

I/O VCC_2V8 ** GPIO23

I/O VCC_2V8 ** GPIO22

I/O VCC_1V8 GPIO4 COL0

I/O VCC_1V8 GPIO6 COL2

I/O VCC_1V8 GPIO8 COL4

I/O VCC_1V8 GPIO12 ROW3

I/O VCC_1V8 GPIO10 ROW1

O VCC_2V8 GPIO42

I VCC_2V8 GPIO36

O VCC_2V8 GPIO37

O VCC_2V8 GPIO39

O VCC_1V8

Signal Name Signal Name

Mux Nominal

~CT125-

CT103-

TXD1

CT104-

RXD1

~CT106-

CTS1

PCMSYNC

PCM-

CLK

Number

39 40

41 42

43 44

45 46

47 48

49 50

51 52

53 54

55 56

57 58

59 60

61 62

63 64

65 66

67 68

69 70

71 72

73 74

75 76

77 78

79 80

Nominal Mux

MIC1P Analog I

Reserved **

SCL GPIO26

SDA GPIO27

GPIO20 VCC_2V8 I/O

INT0 GPIO3 VCC_1V8 I

VPAD-

USB

USB-DP

USB-DM

GPIO24 VCC_2V8 I/O

COL1 GPIO5 VCC_1V8 I/O

COL3 GPIO7 VCC_1V8 I/O

ROW4 GPIO13 VCC_1V8 I/O

ROW2 GPIO11 VCC_1V8 I/O

ROW0 GPIO9 VCC_1V8 I/O

~CT109-

DCD1

~CT105-

RTS1

~CT107-

DSR1

~CT108-

2-DTR1

PCM-IN VCC_1V8 I

PCM-

OUT

Voltage I/O* Description

Open Drain

VPAD-

USB

VPAD-

USB

VPAD-

USB

GPIO43 VCC_2V8 O

GPIO38 VCC_2V8 I

GPIO40 VCC_2V8 O

GPIO41 VCC_2V8 I

VCC_1V8 O

I/O I²C Data

I/O USB Data

Micro 1

Input

Positive

O I²C Clock

Interruption

0 Input

USB Power

supply input

Keypad

column 1

Keypad

column 3

Keypad Row

Main RS232

Data Carrier

Detect

Main RS232

Request To

Send

Main RS232

Data Set

Ready

Main RS232

Data

Terminal

Ready

PCM Data

Input

PCM Data

Output

confidential ©

NC-1

NC-3

NC-5

81 82

83 84

85 86

Reserved

NC-2

NC-4

Page : 69 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Description I/O* Voltage

* The I/O direction information is concerning only the nominal signal. When the signal is

configured in GPIO, it can always be an Input or an Output.

** For more information about the multiplexing of those signals, see “General purpose input

/output” chapter 3.9

Signal Name Signal Name

Mux Nominal

NC-7

NC-9

NC-11

NC-13

NC-15

NC-17

NC-19

Number

87 88

89 90

91 92

93 94

95 96

97 98

99 100

Nominal Mux

Voltage I/O* Description

NC-6

NC-8

NC-10

NC-12

NC-14

NC-16

NC-18

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 70 / 87

WM_PRJ_Q2686_PTS_001

Q2686

ENVIRONNEMENTAL CLASSES

90% - 100% RH

April 4th 2006

4.2 Environmental Specifications

Wavecom specify following temperature range Q2686 product The Wismo Quik Q2686 is compliant with following operating class

Conditions Temperature range

Operating / Class A

Operating / Storage / Class B -40 °C to +85°C

Function Status Classification: Class A: The Wireless CPU remains fully functional, meeting GSM performance criteria

in accordance with ETSI requirements, across the specified temperature range. Class B: The Wireless CPU remains fully functional, across the specified temperature

range. Some GSM parameters may occasionally deviate from the ETSI specified requirements and this deviation does not affect the ability of the Wireless CPU to connect to the cellular network and function fully, as it does within the Class A range.

-20 °C to +55°C

TYPE OF TEST STANDARDS STORAGE TRANSPORTATION OPERATING (PORT USE)

Cold IEC 68-2.1 -25° C 72 h -40° C 72 h -20° C (GSM900) 16 h

Ab test -10° C (GSM1800/1900) 16h

Dry heat IEC 68-2.2 +70° C 72 h +70° C 72 h +55° C 16 h

Bb test

Change of temperature IEC 68-2.14 -40° / +30° C 5 cycles -20° / +30° C (GSM900) 3 cycles

Na/Nb test t1 = 3 h -10° / +30° C (GSM1800/1900):

Damp heat IEC 68-2.30 +30° C 2 cycles +40° C 2 cycles +40° C 2 cycles

cyclic Db test

Damp heat IEC 68-2.56 +30° C 4 days +40° C 4 days +40° C 4 days

Cb test

Sinusoidal vibration IEC 68-2.6 5 - 62 Hz : 5 mm / s

Fc test 62 - 200Hz : 2 m / s2

Random vibration IEC 68-3.36 20 - 500Hz : - 3 dB / oct 12 - 150Hz : - 3 dB / oct

wide band Fdb test 3 x 10 min 3 x 30 min

Class 1.2 Class 2.3 Class 7.3

3 cycles t1 = 3 h

90% - 100% RH

variant 1 variant 1 variant 1

3 x 5 sweep cycles

5 - 20 Hz : 0.96 m2 / s3 10 -12 Hz : 0.96 m2 / s3

confidential ©

Page : 71 / 87

WM_PRJ_Q2686_PTS_001

Figure 14 : Environmental classes

April 4th 2006

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 72 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

4.3 Mechanical specifications

4.3.1 Physical characteristics

The WISMO Quik Q2686 Wireless CPU has a complete self-contained shield.

 Overall dimensions :32.2x40x4 mm (except shielding pins)

 Weight : <10 g

4.3.2 Mechanical drawings

The next page gives the mechanical specifications of WISMO Quik Q2686.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 73 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Figure 15 : Mechanical drawing

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 74 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

5 Connectors and peripheral devices

references

5.1 General Purpose Connector

The GPC is a 100-pin connector with 0.5mm pitch of P5K series from PANASONIC group with the following reference :

AXK69510002 The matting connector has the following reference : AXK59510001 The stacking height is 3.0 mm. WAVECOM recommends to you to used the AXK59510001 connector for your

application to profit of WAVECOM’s prices. For more information, contact

WAVECOM by specifying the WAVECOM connector reference : WM17077.

For further details see GPC data sheets in appendix. More information is also available from http://www.panasonic.com/host/industrl.html

5.2 SIM Card Reader

 ITT CANNON CCM03 series (see http://www.ittcannon.com )

 AMPHENOL C707 series (see http://www.amphenol.com )

 JAE (see http://www.jae.com )

Drawer type :

 MOLEX 99228-0002 (connector) / MOLEX 91236-0002 (holder) (see

http://www.molex.com )

5.3 Microphone

Possible suppliers :

 HOSIDEN

 PANASONIC

 PEIKER

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 75 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

5.4 Speaker

Possible suppliers :

 SANYO  HOSIDEN

 PRIMO

 PHILIPS

5.5 Antenna Cable

A wide variety of cables fitted with UF-L connectors is proposed by HIROSE :

 UF-L pigtails, Ex :Ref = U.FL-2LP(V)-04-A-(100)

 UF-L Ref = U.FL-R-SMT  UF-L cable assemblies,  Between series cable assemblies.

More information is also available from http://www.hirose-connectors.com/. A coaxial cable can be also soldered on the RF pad. The following reference

has been qualified for being mounted on WISMO Quik Q2686:

 RG178

 RG316

5.6 RF Board to board connector

The supplier for the IMP connector is Radiall (http://www.radiall.com) with the following reference :

 R107 064 900.

5.7 GSM antenna

GSM antennas and support for antenna adaptation can be obtained from manufacturers such as:

 ALLGON (http://www.allgon.com )  IRSCHMANN (http://www.hirschmann.com/ )

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 76 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

6 Design Guidelines

The purpose of the following paragraphs is to give design guidelines.

6.1 HARDWARE and RF

6.1.1 EMC recommendations

The EMC tests have to be performed as soon as possible on the application to detect any possible problem.

When designing, special attention should be paid to:

 Possible spurious emission radiated by the application to the RF receiver

in the receiver band

 ESD protection is mandatory on all signals which have external

accessibility ( typically human accessibility ). See WISMO Quik Q2686 Customer Design Guidelines WM_PRJ_Q2686_PTS_003 [2] for ESD protection samples.

o Typically ESD protection is mandatory for :

 SIM (if accessible from outside)

 serial link,…

 EMC protection on audio input/output (filters against 900MHz

emissions)

 Biasing of the microphone inputs

 Length of the SIM interface lines (preferably <10cm)

 Ground plane : WAVECOM recommends to have a common ground

plane for analog / digital / RF grounds.

 Metallic case or plastic casing with conductive paint are recommended Note : The Wireless CPU does not include any protection against overvoltage.

6.1.2 Power Supply

The power supply is one of the key issues in the design of a GSM terminal. A weak power supply design could affect in particular :

 EMC performances

 the emissions spectrum

 the phase error and frequency error

WARNING: Careful attention should be paid to :

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 77 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

 Quality of the power supply : low ripple, PFM or PSM systems should be

avoided (PWM converter preferred).  Capacity to deliver high current peaks in a short time (pulsed radio

emission).

6.1.3 Layout requirement

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 78 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

Figure 16 : Layout requirement

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 79 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

6.1.4 Antenna

WARNING: Wavecom strongly recommends to work with an antenna manufacturer either

to develop an antenna adapted to the application or to adapt an existing solution to the application.

Both the mechanical and electrical antenna adaptation is one of the key issues in the design of the GSM terminal.

6.2 Mechanical integration

Attention should be paid to :

 Antenna cable integration (bending, length, position, etc)

 Legs of the Wireless CPU to be soldered on the Ground plane

6.3 Operating System upgrade

The WISMO Quik Q2686 Operating System is stored in flash memory and it can easily be upgraded.

IMPORTANT:

In order to follow the regular evolutions of the GPRS standard and to offer state of the art Operating System, Wavecom recommends that the application designed around a WISMO (or WISMO based product) allows easy Operating System upgrades on the Wireless CPU via the standard Xmodem protocol. Therefore, the application shall either allow a direct access to the WISMO serial link through an external connector or implement any mechanism allowing the WISMO Operating System to be downloaded via Xmodem.

The Operating System file can be downloaded into the modem using the Xmodem protocol. AT+WDWL command allows to launch the download process (see description in the AT command User Guide.

The necessary serial signals to proceed with the Xmodem downloading are: Rx, Tx, RTS, CTS and GND. The Operating System file can be also downloaded into the modem using the

DOTA (download over the air) feature. This feature is available with Open AT interface. For more detail, please, refer to the Open AT®documentation.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 80 / 87

WM_PRJ_Q2686_PTS_001

Technical Specification Group GSM/EDGE. Radio

02.07 version

General Packet Radio Service (GPRS); Service

8.1.0 Release

Technical Specification Group Services and System

2+);

General Packet Radio Service (GPRS); Service

064 V5.0.0

Technical Specification Group GERAN; Digital cellular

telecommunications system (Phase 2+); General Packet

Radio Service (GPRS); Overall description of the GPRS

3GPP TS 03.22 V8.7.0

ical Specification Group GSM/EDGE. Radio

Access Network; Functions related to Mobile Station

Release

3GPP TS 03.40 V7.5.0

rt Message Service

Technical Specification Group Terminals; Technical

(Release

Transmission planning aspects of the speech service in

(GSM

April 4th 2006

7 Appendix

7.1 Standards and Recommendations

GSM ETSI, 3GPP, GCF and NAPRD03 recommendations for Phase II & FCC.

Specification Reference Title 3GPP TS 45.005 v5.5.0

(2002-08) Release 5

GSM 02.07 V8.0.0 (1999-

07)

Access Network; Radio transmission and reception Digital cellular telecommunications system (Phase 2+);

Mobile Stations (MS) features (GSM

8.0.0 Release 1999)

GSM 02.60 V8.1.0 (1999-

07)

GSM 03.60 V7.9.0 (2002-

09)

3GPP TS 43. (2002-04)

(2002-08)

(2001-12)

Digital cellular telecommunications system (Phase 2+);

description, Stage 1 (GSM 02.60 version

1999)

Aspects; Digital cellular telecommunications system (Phase

description; Stage 2 (Release 1998)

radio interface; Stage 2 (Release 5) Techn

(MS) in idle mode and group receive mode; (

1999) Technical Specification Group Terminals; Technical realization of the Sho

(SMS) (Release 1998)

3GPP TS 03.41 V7.4.0 (2000-09)

realization of Cell Broadcast Service (CBS)

1998)

ETSI EN 300 903 V8.1.1

Digital cellular telecommunications system (Phase 2+);

(2000-11)

the GSM Public Land Mobile Network (PLMN) system

03.50 version 8.1.1 Release 1999)

confidential ©

Page : 81 / 87

Specification Reference Title

3GPP TS 04.06 V8.2.1

/EDGE Radio Access

BSS) interface; Data Link (DL) layer specification

3GPP TS 04.08 V7.18.0

Release

3GPP TS 04.10 V7.1.0

Mobile radio interface layer 3 Supplementary services

Technical Specification Group Core Network; Digital

2+);

Point (PP) Short Message Service (SMS)

Technical Specification Group GSM/EDGE. Radio

Access Network; Radio transmission and reception

3GPP TS 45.008 V5.8.0

Radio Access Network; Radio subsystem link control

010 V5.1.0

Radio Access Network; Radio subsystem

3GPP TS 46.010 V5.0.0

Technical Specification Group Services and System

3GPP TS 46.011 V5.0.0

Technical Specification Group Services and System

Full rate speech; Substitution and muting of lost

3GPP TS 46.012 V5.0.0

p Services and System

Full rate speech; Comfort noise aspect for full rate

Technical Specification Group GSM

(2002-05)

Network; Mobile Station - Base Station System (MS -

(Release 1999) Technical Specification Group Core Network;

(2002-09)

Digital cellular telecommunications system (Phase 2+); Mobile radio interface layer 3 specification (

1998) Technical Specification Group Core Networks;

(2001-12)

specification; General aspects (Release 1998)

3GPP TS 04.11 V7.1.0 (2000-09)

cellular telecommunications system (Phase Point-tosupport on mobile radio interface

WM_PRJ_Q2686_PTS_001

April 4th 2006

3GPP TS 45.005 v5.5.0 (2002-08)

(2002-08)

3GPP TS 45. (2002-08)

(2002-06)

(Release 1998)

(Release 5) Technical Specification Group GSM/EDGE

synchronization (Release 5)

Aspects; Full rate speech; Transcoding (Release 5)

Aspects;

frames for full rate speech channels (Release 5)

Technical Specification Grou Aspects;

speech traffic channels (Release 5)

confidential ©

Page : 82 / 87

Specification Reference Title

3GPP TS 46.031 V5.0.0

Technical Specification Group Services and System

peech; Discontinuous Transmission (DTX) for

3GPP TS 46.032 V5.0.0

Technical Specification Group Services and System

; Voice Activity Detector (VAD) for full

General on Terminal Adaptation Functions (TAF) for

GSM 07.01 version 8.0.0

General requirements on interworking between the

Public Land Mobile Network (PLMN) and the

Integrated Services Digital Network (ISDN) or Public

GSM 09.07

; Radio

;Digital cellular telecommunications

system (Phase 2+);Mobile Station (MS) conformance

specification; Part 1: Conformance specification

P TS 51.011 V5.0.0

Technical Specification Group Terminals; Specification

Mobile Equipment

ME) interface (GSM 11.12

t for

WM_PRJ_Q2686_PTS_001

April 4th 2006

(2002-06)

TS 100 913V8.0.0 (1999-

08)

GSM 09.07 V8.0.0 (1999-

08)

3GPP TS 51.010-1 v5.0.0 (2002-09)

Aspects; Full rate s

full rate speech traffic channels (Release 5)

Aspects; Full rate speech

rate speech traffic channels (Release 5) Digital cellular telecommunications system (Phase 2+);

Mobile Stations (MS) ( Release 1999)

Digital cellular telecommunications system (Phase 2+);

Switched Telephone Network (PSTN) ( version 8.0.0 Release 1999)

Technical Specification Group GSM/EDGE Access Network

(Release 5)

3GP (2001-12)

ETS 300 641 (1998-03)

of the Subscriber Identity Module (SIM - ME) interface (Release 5)

Digital cellular telecommunications system (Phase 2); Specification of the 3 Volt Subscriber Identity Module -

Mobile Equipment (SIMversion 4.3.1)

GCF-CC V3.7.1 (2002-08) Global Certification Forum – Certification criteria

NAPRD03 V2.6.0 (2002-06) North America Permanent Reference Documen

PTCRB tests

The Q2686 Wireless CPU connected on a development kit board application is certified to be in accordance with the following Rules and Regulations of the Federal Communications Commission (FCC).

Power listed on the Gant is conducted for Part 22 and conducted for Part 24

This device contains GSM, GPRS Class 10 functions in the 900

confidential ©

Page : 83 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

and 1800MHz Band which are not operational in U.S. Territories.

This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Antennas used for this OEM module must not exceed 3.3dBi gain for PCS 1900 MHz and 6dBd(8.14dBi) GSM 850 MHz for mobile and fixed operating configurations. This device is approve as a module to be installed in other devices.

Installed in other portable devices, the exposure conditions required a separate equipment authorization.

The license module had a FCC ID label on the module itself. The FCC ID label must be visible through a window or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the device that contains the following text: Contains FCC ID: O9EQ2686

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT: Manufacturers of mobile or fixed devices incorporating Q2686 Wireless CPU are advised to

• clarify any regulatory questions,

• have their completed product tested,

• have product approved for FCC compliance, and

• include instructions according to above mentioned RF exposure statements in end product user manual.

Please note that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 84 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

7.2 Safety recommendations (for information only)

IMPORTANT

FOR THE EFFICIENT AND SAFE OPERATION OF YOUR GSM APPLICATION

BASED ON WISMO Quik Q2686

PLEASE READ THIS INFORMATION CAREFULLY

7.2.1 RF safety

7.2.1.1 General

Your GSM terminal1is based on the GSM standard for cellular technology. The GSM standard is spread all over the world. It covers Europe, Asia and some parts of America and Africa. This is the most used telecommunication standard.

Your GSM terminal is actually a low power radio transmitter and receiver. It sends out and receives radio frequency energy. When you use your GSM application, the cellular system which handles your calls controls both the radio frequency and the power level of your cellular modem.

7.2.1.2 Exposure to RF energy

There has been some public concern about possible health effects of using GSM terminals. Although research on health effects from RF energy has focused on the current RF technology for many years, scientists have begun research regarding newer radio technologies, such as GSM. After existing research had been reviewed, and after compliance to all applicable safety standards had been tested, it has been concluded that the product was fitted for use.

If you are concerned about exposure to RF energy there are things you can do to minimize exposure. Obviously, limiting the duration of your calls will reduce your exposure to RF energy. In addition, you can reduce RF exposure by operating your cellular terminal efficiently by following the below guidelines.

7.2.1.3 Efficient terminal operation

For your GSM terminal to operate at the lowest power level, consistent with satisfactory call quality :

If your terminal has an extendible antenna, extend it fully. Some models allow you to place a call with the antenna retracted. However your GSM terminal operates more efficiently with the antenna fully extended.

Do not hold the antenna when the terminal is « IN USE ». Holding the antenna affects call quality and may cause the modem to operate at a higher power level than needed.

based on WISMO2D

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 85 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

7.2.1.4 Antenna care and replacement

Do not use the GSM terminal with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Replace a damaged antenna immediately. Consult your manual to see if you may change the antenna yourself. If so, use only a manufacturer-approved antenna. Otherwise, have your antenna repaired by a qualified technician.

Use only the supplied or approved antenna. Unauthorized antennas, modifications or attachments could damage the terminal and may contravene local RF emission regulations or invalidate type approval.

7.2.2 General safety

7.2.2.1 Driving

Check the laws and the regulations regarding the use of cellular devices in the area where you have to drive as you always have to comply with them. When using your GSM terminal while driving, please :

 give full attention to driving,

 pull off the road and park before making or answering a call if driving

conditions so require.

7.2.2.2 Electronic devices

Most electronic equipment, for example in hospitals and motor vehicles is shielded from RF energy. However RF energy may affect some improperly shielded electronic equipment.

7.2.2.3 Vehicle electronic equipment

Check your vehicle manufacturer representative to determine if any on-board electronic equipment is adequately shielded from RF energy.

7.2.2.4 Medical electronic equipment

Consult the manufacturer of any personal medical devices (such as pacemakers, hearing aids, etc...) to determine if they are adequately shielded from external RF energy.

Turn your terminal OFF in health care facilities when any regulations posted in the area instruct you to do so. Hospitals or health care facilities may be using RF monitoring equipment.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 86 / 87

WM_PRJ_Q2686_PTS_001

April 4th 2006

7.2.2.5 Aircraft

Turn your terminal OFF before boarding any aircraft.

 Use it on the ground only with crew permission.

 Do not use it in the air.

To prevent possible interference with aircraft systems, Federal Aviation Administration (FAA) regulations require you to have permission from a crew member to use your terminal while the aircraft is on the ground. To prevent interference with cellular systems, local RF regulations prohibit using your modem while airborne.

7.2.2.6 Children

Do not allow children to play with your GSM terminal. It is not a toy. Children could hurt themselves or others (by poking themselves or others in the eye with the antenna, for example). Children could damage the modem, or make calls that increase your modem bills.

7.2.2.7 Blasting areas

To avoid interfering with blasting operations, turn your unit OFF when in a « blasting area » or in areas posted : « turn off two-way radio ». Construction crew often use remote control RF devices to set off explosives.

7.2.2.8 Potentially explosive atmospheres

Turn your terminal OFF when in any area with a potentially explosive atmosphere. It is rare, but your modem or its accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injuries or even death.

Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fuelling areas such as petrol stations ; below decks on boats ; fuel or chemical transfer or storage facilities ; and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

Do not transport or store flammable gas, liquid, or explosives, in the compartment of your vehicle which contains your terminal or accessories.

Before using your terminal in a vehicle powered by liquefied petroleum gas (such as propane or butane) ensure that the vehicle complies with the relevant fire and safety regulations of the country in which the vehicle is to be used.

This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged

confidential ©

without prior written agreement. Ce document est la propriété exclusive de WAVECOM. Il ne peut être communiqué ou divulgué à des tiers sans son autorisation préalable.

Page : 87 / 87

Sierra Wireless Q2686 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
