1. Overview
1.1. Introduction
This document is the Hardware Product Specification for the AirPrime AR Series of Intelligent
Embedded Modules. It defines the high level product features and illustrates the interfaces for these
features. This document is intended to cover the hardware aspects of the product series, including
electrical and mechanical.
The AirPrime AR Series of Intelligent Embedded Modules are designed for the automotive industry
and any market with similar quality and life-time support requirements. They support several air
interface standards but share a common form-factor and electrical interface. All versions also have
Global Navigation Satellite System (GNSS) capabilities via GPS.
The AirPrime AR series of intelligent embedded modules are based on the Qualcomm MDM6200 and
MDM6600 wireless chipsets. The term AirPrime AR series addresses all of the following specific
products.
Table 1: AirPrime AR Series Intelligent Embedded Modules
Pr oduct Description Band Su pport
AR8550 WCDMA/HSPA/GSM Intelligent Embedded Module
AR8552 WCDMA/HSPA/GSM Intelligent Embedded Module
3G – BAND II, IV, V
2G – 850/900/1800/1900
3G – BAND I, VIII, VI
2G – 850/900/1800/1900
1.2. Reference Specifications
The table below lists the reference specifications for this product.
Table 2: Reference specifications
Ref Ti tle Rev Issu er
[3] Universal Serial Bus Specification 2.0
[4]
[5] Universal Serial Bus Class Definitions for Communication Devices 1.1
[6] AirPrime AR Series LGA Specification 0.5 Sierra Wireless
[7] AirPrime AR Series AT Command Interface Specification 006 Sierra Wireless
Universal Serial Bus CDC Subclass Specification for Wireless
Mobile Communication Devices
1.0
USB Implementers
Forum
USB Implementers
Forum
USB Implementers
Forum
Preliminary Rev 0.6 December 10, 2010 8
2. Features
This chapter highlights the features of the AirPrime AR Series of Intelligent Embedded Modules.
2.1. Modes of Operation
The AR8550 supports quad band GSM operation and WCDMA/HSPA operation in Band II, IV and V.
The AR8552 supports quad band GSM operation and WCDMA/HSPA operation in Band I, VI and VIII.
All models also support Standalone GNSS operation. For complete details, refer to the tables below.
Table 3: AR8552 modes of operation
Mode Band Fr equen cy (MH z)
RX TX
850 869 – 894 824 – 849
GSM/GPRS/EDGE
WCDMA/HSPA
GNSS GPS L1 1574.42 – 1576.42 ---
900 925 – 960 880 – 915
1800 1805 – 1880 1710 – 1785
1900 1930 – 1990 1850 – 1910
I (2100/IMT) 2110 – 2170 1920 – 1980
VI (800) 875 – 885 830 – 840
VIII (900/GSM) 925 – 960 880 – 915
Table 4: AR8550 modes of operation
Mode Band Fr equen cy (MH z)
RX TX
850 869 – 894 824 – 849
GSM/GPRS/EDGE
WCDMA/HSPA
GNSS GPS L1 1574.42 – 1576.42 ---
900 925 – 960 880 – 915
1800 1805 – 1880 1710 – 1785
1900 1930 – 1990 1850 – 1910
II (1900/PCS) 1930 – 1990 1850 – 1910
IV (1700/AWS) 2110 – 2155 1710 – 1755
V (850/CELL) 869 – 894 824 – 849
2.2. Communications Functions
The AirPrime AR series provides the following communications functions via the CDMA, GSM and/or
UMTS networks.
Table 5: Communications functions
Communicat ion s F unctio n AR8550/ AR8552
Voice FR, EFR, HR, AMR, AMR-WB
Data
Circuit Switch (CSD)
Packet
Preliminary Rev 0.6 December 10, 2010 9
Product Specification Features
Communicat ion s F unctio n AR8550/ AR8552
Short Message Service (SMS)
OTA
DTMF Forward link only
OTAPA
OTASP
Preliminary Rev 0.6 December 10, 2010 10
3. Hardware Specification
3.1. Environmental Specification
The environmental specification for both operating and storage are defined in the table below.
Table 6: Environmental specifications
Para met er Te mperatur e Rang e
Ambient Operating Temperature
Ambient Storage Temperature -40°C to +90°C
Ambient Humidity 95% or less
-30°C to +75°C (Class A)
-40°C to +85°C (Class B)
3.2. ESD Specification
The AirPrime AR series devices are sensitive to Electrostatic Discharge. ESD countermeasures and
handling methods must be used when handling the AirPrime AR series devices.
Table 7: ESD ratings
Signal Pad s ESD Rat ing
Primary, Diversity and GNSS antenna pads 8 kV Contact
All other signal pads 1.5 kV Contact
3.3. Absolute Maximum Ratings
This section defines the Absolute Maximum Ratings of the AirPrime AR series devices. If these
parameters are exceeded, even momentarily, damage may occur to the device.
Table 8: Absolute Maximum ratings
Para met er Mi n Max Unit s
VBATT Power Supply Input - 5.0 V
VIN Voltage on any digital input or output pin - VCC_1v8+0.5 V
IIN Latch-up current -100 100 mA
Maximum Voltage applied to antenna interface pins
Primary Antenna - 30 V
VANT
Preliminary Rev 0.6 December 10, 2010 11
Diversity Antenna - 25 V
GNSS Antenna - 25 V
4. RF Specification
The section presents the RF interface of the AirPrime AR series intelligent embedded module. The
specifications for the CDMA and GSM/WCDMA interfaces are defined.
4.1. GSM/WCDMA Interface
This section presents the GSM/GPRS/EDGE/WCDMA RF Specification for the AirPrime AR8550 and
AR8552.
4.1.1. GSM/WCDMA Antenna Interface
The specification for the GSM/WCDMA Antenna Interface is defined in the table below.
Table 9: GSM/WCDMA antenna characteristics – AR8550
Char act eri sti cs GSM9 00
Frequency
(MHz)
Impedance RF 50 Ohm
VSWR max
Maximum Voltage
Table 10: GSM/WCDMA antenna characteristics – AR8552
Char act eri sti cs
Frequency
(MHz)
Impedance RF 50 Ohm
VSWR max
Maximum Voltage
TX 880 – 915 824-849 1710 – 1785 1850-1910 1710 – 1755
RX 925 – 960 869-894 1805 – 1880 1930-1990 2110 – 2155
RX 1.5: 1
TX 1.5: 1
Primary Antenna – 30 Volts
Diversity Antenna – 25 Volts
GSM9 00 –
WCDMA
Band VIII
TX 880 – 915 824-849 1710 – 1785 1850-1910 1920 – 1980
RX 925 – 960 869-894 1805 – 1880 1930-1990 2110 – 2170
RX 1.5: 1
TX 1.5: 1
Primary Antenna – 30 Volts
Diversity Antenna – 25 Volts
GSM8 50 –
WCDMA
Band V
GSM8 50 –
WCDMA
Band VI
GSM1800
GSM1 800 GSM1 900
GSM1 900 –
WCDM A
Band II
WCDM A
Band IV
WCDM A
Band I
Preliminary Rev 0.6 December 10, 2010 12
5. GNSS Specification
The AirPrime AR series intelligent embedded module includes optional Global Navigation Satellite
System (GNSS) capabilities via the Qualcomm gpsOne Gen8 Engine, capable of operation in
assisted and stand-alone GPS modes.
5.1. GPS
The GPS implementation supports GPS L1 operation centered at 1575.42 MHz (+/- 1 MHz).
Preliminary Rev 0.6 December 10, 2010 13
6. Baseband Specification
6.1. Power Supply
The AirPrime AR series is powered via a single regulated DC power supply, 4.0V +5/-10%. The
power supply requirements can be found in the following table.
Table 11: Power supply requirements
Power S upp ly Min Typ M ax Units
Main DC Power Input Range 3.6 4.0 4.2 V
Power Supply Ripple
Maximum Current draw AR8550/8552 2.5 A
AirPrime AR series does not support USB self powered operation.
Table 12: Power supply pad
0 to 1kHz 200 mVpp
>1kHz 50 mVpp
Pad N ame Directi on Function If U nus ed
S20 VBATT Input Power Supply Input Required
6.2. Current Consumption
The table below summarizes some key current consumption values for varies modes of the AR series
devices.
Devi ce Mod e Paramet er Typi cal Max Unit s
Maximum TX Output – WCDMA - 800 mA
+0dBm TX Output – WCDMA tbd - mA
GSM Low Band TX – PL5 - tbd mA
GSM High Band TX – PL - tbd mA
Searching for network – WCDMA 46 - mA
Searching for network – GSM 43 - mA
On-network, "listening" for page – WCDMA - 2 mA
On-network, "listening" for page – GSM - 2 mA
AR8550 /
AR8552
All AR
Series
On Call
Scan
Sleep Mode
Off Power OFF Current 3.6 10 µA
6.3. USB
The AirPrime AR series has a High Speed USB2.0 compliant, peripheral only interface.
Table 13: USB pad details
Pad N ame Dir ect ion Functi on
R1 USB_VBUS Input USB Power Supply
Preliminary Rev 0.6 December 10, 2010 14
Product Specification Baseband Specification
Pad N ame Dir ect ion Functi on
V1 USB_D_P In/Out Differential data interface positive
T1 USB_D_M In/Out Differential data interface negative
The AirPrime AR series will not be damaged if a valid USB_VBUS is supplied while the main DC
power is not supplied.
Table 14: USB characteristics
USB Valu e Units
Voltage range 2.0 – 5.25 V
USB_VBUS
Maximum Current draw 1 mA
Maximum Input Capacitance (Min ESR = 50 mOhm) 10 µF
Figure 1. Recommended UIM holder implementation
Preliminary Rev 0.6 December 10, 2010 15
7. RF Circuit Routing Constraints
7.1. General recommendations
To route the RF antenna signals, the following recommendations must be observed for PCB layout:
The RF signals must be routed using traces with a 50 Ω characteristic impedance.
Basically, the characteristic impedance depends on the dielectric constant (εr) of the material used,
trace width (W), trace thickness (T), and height (H) between the trace and the reference ground plane.
In order to respect this constraint, Sierra Wireless recommends that a MicroStrip structure be used
and trace width be computed with a simulation tool (such as AppCAD, shown in the figure below and
available free of charge at http://www.avagotech.com).
Figure 2. AppCAD screenshot for MicroStrip design power mode diagram
The trace width should be wide enough to maintain reasonable insertion loss and manufacturing
reliability. Cutting out inner layers of ground under the trace will increase the effective substrate
height; therefore, increasing the width of the RF trace.
Caution:
It is critical that no other signals (digital, analog, or supply) cross under the RF path. The figure below
shows a generic example of good and poor routing techniques.
Product Specification RF Circuit Routing Constraints
Poor rou ting Correct routi ng
The yellow traces cross the RF trace. There is no signal around the RF path.
Figure 3. RF routing examples
•
Fill the area around the RF traces with ground and ground vias to connect inner ground layers
for isolation.
•
Cut out ground fill under RF signal pads to reduce stray capacitance losses.
•
Avoid routing RF traces with sharp corners. A smooth radius is recommended.
•
The ground reference plane should be a solid continuous plane under the trace.
•
The coplanar clearance (G, below) from the trace to the ground should be at least the trace
width (W) and at least twice the height (H). This reduces the parasitic capacitance, which
potentially alters the trace impedance and increases the losses. Note the figure below shows
several internal ground layers cutout, which may not be necessary for every application.
Figure 4. Coplanar clearance example
Figure 5. Antenna microstrip routing example
8. Regulatory Approval
Important Notice
Because of the nature of wireless communications, transmission and reception of data can
never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally lost.
Although significant delays or losses of data are rare when wireless devices such as the Sierra
Wireless modem are used in a normal manner with a well-constructed network, the Sierra
Wireless modem should not be used in situations where failure to transmit or receive data could
result in damage of any kind to the user or any other party, including but not limited to personal
injury, death, or loss of property. Sierra Wireless and its affiliates accept no responsibility for
damages of any kind resulting from delays or errors in data transmitted or received using Sierra
Wireless modem, or for failure of the Sierra Wireless modem to transmit or receive such data.
Safety and Hazards
Do not operate you AR8550 modem:
•
In areas where blasting is in progress
•
Where explosive atmospheres may be present including refueling points, fuel
depots, and chemical plants
•
Near medical equipment, life support equipment, or any equipment which may be
susceptible to any form of radio interference. In such areas, the AR8550 modem
MUST BE POWERED OFF
signals that could interfere with this equipment
•
In an aircraft, the AR8550 modem
AR8550 modem can transmit signals that could interfere with various onboard
systems and may be dangerous to the operation of the aircraft or disrupt the
cellular network. Use of cellular phone in aircraft is illegal in some jurisdictions.
Failure to observe this instruction may lead to suspension or denial of cellular
telephone services to the offender, or legal action or both.
•
Some airlines may permit the use of cellular phones while the aircraft is on the
ground and the door is open. The AR8550 modem may be used normally at this
time.
. Otherwise, the AR8550 modem can transmit
MUST BE POWERED OFF.
Otherwise, the
Important Compliance Information for USA OEM
Integrators
The AR8550 modem is granted with a modular approval for mobile applications. Integrators
may use the AR8550 modem in their final products without additional FCC/IC (Industry
Canada) certification if they meet the following conditions. Otherwise, additional FCC/IC
approvals must be obtained.
1. At least 20cm separation distance between the antenna and the user’s body must be
maintained at all times.
2. To comply with FCC/IC regulations limiting both maximum RF output power and human
exposure to RF radiation, the maximum antenna gain including cable loss in a mobileonly exposure condition must not exceed 5dBi for Cellular band and 3.7dBi for CDMA
PCS band.
3. The AR8550 modem and the antenna must not be co-located or operating in
conjunction with any other transmitter or antenna within a host device.
December 10, 2010
Product Specification
4. A label must be affixed to the outside of the end product into which the AR8550 modem
is incorporated, with a statement similar to the following:
Contains transmitter module IC: 2417C-AR8550
where 2417C-AR8550 is the module’s certification number.
A user manual with the end product must clearly indicate the operating requirements and
conditions that must be observed to ensure compliance with current FCC/IC RF exposure
guidelines.
The end product with an embedded AR8550 modem may also need to pass the FCC Part 15
unintentional emission testing requirements and be properly authorized.
Note: If this module is intended for use in a portable device, you are responsible for separate
approval to satisfy the SAR requirements of FCC Part 2.1093 and IC RSS-102.
This device contains FCC ID: N7NAR8550
Preliminary Rev 0.6
Loading...
