1. Introduction
Product
Description
Band Support
Target Region1
AR7594
LTE-CA / WCDMA / GSM / GPRS / EDGE embedded module
LTE: B1, B3, B7, B8, B20, (B28A), B32 WCDMA: B1, B3, B8 GSM/GPRS/EDGE: 900/1800
EMEA (Europe, Middle East)
Mode
AR7594
Intra-band CA (2CC), Non contiguous
3A+3A, 7A+7A
Intra-band CA (2CC), Contiguous
1C, 3C, 7C
Inter-band CA ( 2CC )
1A+3A, 1A+7A, 1A+8A, 1A+20A, 3A+7A, 3A+8A, 3A+20A, 3A+28A, 7A+20A, 7A+28A, 7A+32A, 20A+32A
Power Supply
Min
Typ
Max
Units
Main DC Power Input Range (VBATT)
3.4
3.7
4.2
V
Power Supply Ripple
0 to 1kHz
- - 200
mVpp
>1kHz
- - 50
mVpp
Peak Current
AR759X
-
2000
3000
mA
1.1. General Features
The AirPrime AR7594 embedded modules are designed for the automotive industry. They support LTE, WCDMA air interface standards and shares hardware and firmware interfaces with the AirPrime AR755x and AR758x. They also have Global Navigation Satellite System (GNSS) capabilities including GPS and GLONASS.
The AirPrime AR7594 embedded modules are based on the Qualcomm MDM9640 wireless chipset and support the following bands.
Table 1. AirPrime AR759x Series Embedded Modules
Table 2. AirPrime AR759x Series Supported Carrier Aggregation Combinations1
1
Refer to 3GPP
2
Optional Band
1.2. Power
The AirPrime AR7594 are powered via a single regulated DC power supply, 3.7V nominal.
Table 3. Power Supply Requirements
41110461 Rev 0.1 January 16, 2017 9
