Sierra Wireless AirCard USB
Modem
User Guide
2131232
Rev. 6
Preface
Important
Notice
Safety and
Hazards
Due to the nature of wireless communications, transmission and reception of data
can never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be
totally lost. Although significant delays or losses of data are rare when wireless
devices such as the Sierra Wireless modem are used in a normal manner with a
well-constructed network, the Sierra Wireless modem should not be used in
situations where failure to transmit or receive data could result in damage of any
kind to the user or any other party, including but not limited to personal injury,
death, or loss of property. Sierra Wireless accepts no responsibility for damages
of any kind resulting from delays or errors in data transmitted or received using
the Sierra Wireless modem, or for failure of the Sierra Wireless modem to
transmit or receive such data.
Do not operate the Sierra Wireless modem in areas where blasting is in progress,
where explosive atmospheres may be present, near medical equipment, near life
support equipment, or any equipment that may be susceptible to any form of radio
interference. In such areas, the Sierra Wireless modem MUST BE POWERED
OFF. The Sierra Wireless modem can transmit signals that could interfere with
this equipment.
Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is
on the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE
POWERED OFF. When operating, the Sierra Wireless modem can transmit
signals that could interfere with various onboard systems.
Limitation of
Liability
Note: Some airlines may permit the use of cellular phones while the aircraft is on the
ground and the door is open. Sierra Wireless modems may be used at this time.
The driver or operator of any vehicle should not operate the Sierra Wireless
modem while in control of a vehicle. Doing so will detract from the driver or
operator's control and operation of that vehicle. In some states and provinces,
operating such communications devices while in control of a vehicle is an offence.
The information in this manual is subject to change without notice and does not
represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND
ITS AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL
DIRECT, INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL,
PUNITIVE OR EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO,
LOSS OF PROFITS OR REVENUE OR ANTICIPATED PROFITS OR REVENUE
ARISING OUT OF THE USE OR INABILITY TO USE ANY SIERRA WIRELESS
PRODUCT, EVEN IF SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR THEY ARE
FORESEEABLE OR FOR CLAIMS BY ANY THIRD PARTY.
Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its
affiliates aggregate liability arising under or in connection with the Sierra Wireless
product, regardless of the number of events, occurrences, or claims giving rise to
liability, be in excess of the price paid by the purchaser for the Sierra Wireless
product.
Rev 6 Dec.10 1
AirCard USB Modem User Guide
Patents This product may contain technology developed by or for Sierra Wireless, Inc.
This product includes technology licensed from QUALCOMM
This product is manufactured or sold by Sierra Wireless Inc. or its affiliates under
one or more patents licensed from InterDigital Group.
®
3G.
Copyright © 2010 Sierra Wireless. All rights reserved.
Trademarks AirCard
Wireless™, the Sierra Wireless logo, and the red wave design are trademarks of
Sierra Wireless.
Windows
Corporation.
Macintosh
the U.S. and other countries.
QUALCOMM
under license.
Other trademarks are the property of their respective owners.
®
and Watcher® are registered trademarks of Sierra Wireless. Sierra
®
and Windows Vista® are registered trademarks of Microsoft
®
and Mac OS® are registered trademarks of Apple Inc., registered in
®
is a registered trademark of QUALCOMM Incorporated. Used
Contact
Information
Sales Desk: Phone: 1-604-232-1488
Hours: 8:00
E-mail: sales@sierrawireless.com
Post: Sierra Wireless
13811 Wireless Way
Richmond, BC
Canada V6V 3A4
AM to 5:00 PM Pacific Time
Fax: 1-604-231-1109
Web: www.sierrawireless.com
Consult our web site for up-to-date product descriptions, documentation,
application notes, firmware upgrades, troubleshooting tips, and press releases:
www.sierrawireless.com
Revision
History
Revision number Release date Changes
1.0 November 2009 New document
2.0 April 2010 Applied new template
3 July 2010 Updated Mac OS X information
4 September 2010 Updated Patents section, added AirCard
312U
2 2131232
Preface
Revision number Release date Changes
5 October 2010 Added AirCard 312U to Regulatory
information for EU countries
6 December 2010 Added AirCard 318U and AirCard 319U
information.
Rev 6 Dec.10 3
AirCard USB Modem User Guide
4 2131232
Contents
Sierra Wireless AirCard USB Modem User Guide . . . . . . . . . . . . . . . . . . . . . 7
About the AirCard USB Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Your account and coverage area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
AirCard USB Modem features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
LED operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Connection management software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Launching Watcher (Windows) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Launching Watcher (Mac) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Reinstalling the software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connecting to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Using the microSD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
End- and side-loading models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Back-loading models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Removing the SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using AirCard USB Modem accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using the extension cable and clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Attaching the lanyard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Care and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Software installation does not start automatically (Windows) or you do not
see the installer package (Mac) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Modem is not detected after AirCard Watcher installation completes (Win-
dows) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Windows installer fails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Radio frequency and electrical specifications . . . . . . . . . . . . . . . . . . . . .23
Frequency band support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Rev 6 Dec.10 5
AirCard USB Modem User Guide
Regulatory and safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Safety and hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Regulatory information for North America . . . . . . . . . . . . . . . . . . . . . . . . 26
Regulatory information for EU countries . . . . . . . . . . . . . . . . . . . . . . . . . 27
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6 2131232
Sierra Wireless AirCard USB Modem User Guide
About the AirCard USB Modem
The Sierra Wireless AirCard® USB Modem enables you to connect to
the Internet, send and receive email, connect to a corporate network
or virtual private network (VPN), or view streaming video without the
need for a network cable.
The AirCard USB Modem connects to a Type A USB port on your
computer.
If the AirCard USB Modem is TRU-Install enabled, all the required
software is available on the modem. When you set up your AirCard
USB Modem, the software is installed on your computer. You do not
need an installation CD. (Depending on your service provider, your
modem may include an installation CD.)
Note: If you purchased the
modem from a GSM
service provider, you may
already have an account
and a SIM card.
Otherwise, your retailer
should be able to give you
the names of companies
that provide these items.
Note: The fee for service
is usually higher when you
are roaming (connected to
a network other than the
one belonging to your
service provider).
The AirCard USB Modem has a built-in antenna and may have a slot
that accommodates a microSD
on your service provider, a microSD card may be included in your
package, or you may need to purchase it separately.
external memory card. Depending
Your account and coverage area
You must have an account with a GSM service provider to use the
AirCard USB Modem. To use the AirCard USB Modem’s 3G
capability, your account must be with a service provider that offers 3G
service. (The AirCard USB Modem is backwards compatible with 2G
service.)
When you obtain your account, you are given a Subscriber Identity
Module (SIM) card containing account information. You must insert
the SIM card into the AirCard USB Modem before you use it.
(Depending on your service provider, the SIM card may already be
inserted.)
When establishing a connection, your AirCard USB Modem uses the
fastest available service. Your ability to obtain service depends on
these factors:
• Network coverage—You must be within the network coverage
area.
• Service provider—If you are within the coverage area of a
network that is not operated by your own service provider, you
can obtain service only if there is a roaming agreement between
your service provider and the network operator.
Rev 6 Dec.10 7
AirCard USB Modem User Guide
Power LED
Data LED
Power LED
Data LED
microSD card and SIM card slots are under the
back cover. See page16 for details.
microSD slot
SIM card slot is under the back cover. See
page 17 for details.
microSD and SIM card slots are under the back
cover. See page 17 for details.
Data LED
Power LED
• Account provisions—Your account may restrict your usage to certain
networks or limit the amount of time you can use the network.
• Frequency band— You cannot connect to networks operating in bands not
supported by your modem, regardless of roaming agreements or account
provisions.
Most service providers have coverage maps on their web sites.
AirCard USB Modem features
The AirCard USB Modem has a USB connector, slots for a SIM card, and (on
some models) a microSD external storage card. LEDs on the front or side of the
AirCard USB Modem provide status information.
The placement of card slots, connectors, and LEDs varies depending on your
modem model.
8 2131232
LED operation
Power LED
SIM card slot
Data LED
Power LED
SIM card tray
microSD card slot
microSD card slot
Data LED
The AirCard USB Modem has two LEDs that show the current status of the
modem.
LED State Indicates
Power Off Indicates one of the following states:
• The AirCard USB Modem is not inserted in the computer.
• The computer is off or in “suspend and resume” mode.
• The AirCard USB Modem radio has been turned off using Watcher or
other connection management software.
Solid Blue The power is on, the AirCard USB Modem is working normally.
Blinking Blue The firmware is being updated.
Do not remove the AirCard USB Modem from the computer.
Blinking Amber The AirCard USB Modem is searching for service (initializing).
Solid Amber Error—either the AirCard USB Modem is having a problem initializing
(searching for service) or is offline because of a failure.
Contact your service provider.
Rev 6 Dec.10 9
AirCard USB Modem User Guide
LED State Indicates
Data Off The AirCard USB Modem is unable to detect 2G or 3G service.
Blinking Amber The AirCard USB Modem has detected a 2G network (EDGE, GPRS, GSM)
and is ready to connect.
Solid Amber The AirCard USB Modem is connected to a 2G network and is able to send
Blinking Blue The AirCard USB Modem has detected a 3G network (UMTS, HSPA,
Solid Blue The AirCard USB Modem is connected to a 3G network and can send and
and receive data.
HSPA+, DC-HSPA+) and is ready to connect.
receive data.
Connection management software
Your AirCard USB Modem comes with Sierra Wireless AirCard Watcher® for
Windows
your service provider. Use this software to manage the modem and monitor your
connections.
For information on Watcher features and using Watcher, refer to the online Help.
From the main Watcher window, select
(Windows) or Help > Sierra Wireless Watcher Help (Mac).
Note: Watcher is compatible with earlier Sierra Wireless modems.
Watcher enables you to:
• Initiate data connections
• Determine signal strength, roaming status, GPRS, EDGE, UMTS, or HSDPA/
• Monitor the status of the AirCard USB Modem and GSM service
• Send and receive SMS messages
• Enable or disable SIM security that prevents others from using your SIM card
• Configure startup and exit actions for Watcher and the AirCard USB Modem
• Create or modify a connection profile
®
and Mac®, or other connection management software, depending on
Help > Help Topics or click the button
HSUPA availability, and other network connection parameters
if it is lost or stolen
For more information about using Watcher, view the Online Help that comes with
Watcher.
You do not need to run Watcher when you use the AirCard USB Modem, but
Watcher does provide useful status information.
Launching Watcher (Windows)
Unless this feature has been disabled, Watcher launches automatically when you
insert the AirCard USB Modem. You can also launch Watcher by:
• Double-clicking the desktop shortcut, or
10 2131232
• Selecting Start > Programs > Sierra Wireless > AirCard Watcher.
Depending on how your profile is configured, your browser, VPN, or other
program may launch automatically anytime you launch Watcher.
Launching Watcher (Mac)
Watcher starts automatically at login. To disable this feature, go to Watcher >
Preferences
.
You can also start Watcher by navigating to the
and double-clicking
AirCard Watcher.
Applications > Sierra Wireless folder
Tips
To keep the Watcher icon in the dock:
1. Launch Watcher.
2. Click and hold the Watcher icon in the dock.
3. From the pop-up menu, select
Keep in Dock.
Reinstalling the software
Windows
If you need to reinstall or repair the Watcher software:
1. Go to
2. Uninstall Watcher.
3. Insert the modem into your computer.
4. Follow the on-screen instructions.
Or, in Watcher:
1. Select
2. Follow the on-screen instructions.
Start > Control Panel > Add or Remove Programs.
Tools > Software Installation Mode.
Note: Do not remove the AirCard USB Modem until the software installation process is
complete.
Mac
To uninstall Watcher:
1. Select
2. Follow the on-screen instructions.
Rev 6 Dec.10 11
AirCard Watcher > Uninstall AirCard Watcher.
AirCard USB Modem User Guide
Connecting to the network
To use your account (and connect to your service provider’s network), you need to
have at least one profile set up on your AirCard USB Modem. Depending on how
your AirCard USB Modem is configured, the profile may already be set up or you
may need to create one.
Note: If you have a pre-paid wireless account, you’ll need to have credit in your account
before you can connect.
Windows
Once the software is successfully installed and the profile is set up, the AirCard
USB Modem is ready to use.
The first time you insert the AirCard USB Modem in the computer, it takes a few
seconds for it to locate the network. While the AirCard USB Modem is scanning
for a network, the Connect button is unavailable.
When you use the AirCard USB Modem with the same computer, TRU-Install
verifies that the correct software is already installed. This process may take a few
seconds.
Scenario Required action
Watcher automati ca lly detects or creates a
default profile.
Watcher prompts you to create a data profile.
• If Watcher opens the Options window Profile
pane and pre-selects an appropriate profile
(normally the name of your service provider)
from the drop-down list...
• If Watcher opens the Options window Profile
pane, the Profile name field is blank, and
your service provider is not included in the
drop-down list...
Click Connect.
1. Click Yes, then....
a. Click OK to accept that profile (or choose
another from the drop-down list).
b. Click Connect.
You need to create a profile manually. Refer to the
Watcher online help for details.
Click Help > Help topics or click the button.
If you need to re-install the software, see page 11.
12 2131232
Mac
SIM card slot
microSD card slot
The first time you run Watcher:
1. When your computer detects the modem, the message "New network interfaces have been detected" appears.
2. Click the
3. In the Network window, click
a. If there is no profile defined, a message opens asking if you want to
b. Click
c. In the
Network Preferences... button.
Apply. Your modem connects to the network.
create a new profile.
Create a new profile.
Profiles window, click + to create a profile.
To end a high-speed connection, click
Disconnect.
Using the microSD card
Some AirCard USB Modem models can accommodate a microSD external
storage card.
The microSD card appears as a USB memory drive when the AirCard USB
Modem is inserted in your computer. You can copy, paste, and drag files to and
from it the same way as you can with any other external drive.
End- and side-loading models
To insert and use a microSD card:
1. If there is a non-functional microSD card installed:
a. Press it in and then release it.
b. Gently remove the non-functional microSD card.
2. If the microSD slot is on the end of the AirCard USB, insert the microSD card
into the lower slot, as shown in the illustration. Be careful not to insert the
microSD card in the SIM card slot.
Rev 6 Dec.10 13
AirCard USB Modem User Guide
If the microSD card slot is on the side of the AirCard USB Modem, insert the
microSD card as shown in the illustration:
3. Insert the AirCard USB Modem into the computer.
If the computer does not have Watcher installed, you may be given the option
to install it. If you do not want to install Watcher, cancel the installation. You
can use the microSD card without having Watcher installed.
To remove the microSD card:
1. Remove the cap.
-or-
If the microSD card slot is on the side of the AirCard USB Modem, open the
flap.
14 2131232
2. Push the microSD card in and then release it.
3. Gently pull the microSD card out.
Rev 6 Dec.10 15
AirCard USB Modem User Guide
Back-loading models
To insert and use a microSD card:
1. Remove the back cover from the modem.
2. Insert the microSD card in the slot as shown in the illustration.
3. Replace the back cover and insert the AirCard USB Modem into the
computer.
If the computer does not have Watcher installed, you may be given the option
to install it. If you do not want to install Watcher, cancel the installation. You
can use the microSD card without having Watcher installed.
16 2131232
To remove the microSD card:
1. Remove the back cover from the modem.
2. Gently pull the microSD card out.
Removing the SIM card
For instructions on inserting the SIM card, see the printed guide that came with
your product.
Some AirCard USB Modems have a SIM card slot with a “push to insert/push to
release” design. To remove the SIM card from the modem:
1. Push the SIM card in to release it.
2. Pull the SIM card out of the slot as shown in the illustration.
Some AirCard USB Modems have an internal tray for inserting and removing the
SIM card. To remove the SIM card from the AirCard USB Modem, slide out the
SIM card tray and lift out the SIM card as shown in the illustration.
If you slide the tray completely out of the AirCard USB Modem, carefully reinsert
it. Do not dispose of the tray.
Rev 6 Dec.10 17
AirCard USB Modem User Guide
To remove the SIM card on AirCard USB Modems that have the SIM slot behind
the back panel, remove the back panel and slide the SIM card out of the slot.
Using AirCard USB Modem accessories
Depending on your carrier and your modem model, your AirCard USB Modem
may come with a:
• USB extension cable and clip
• Lanyard
Using the extension cable and clip
The extension cable and clip should be used if you have difficulty inserting the
AirCard USB Modem because of the orientation of your computer’s USB slot or
the thickness of your computer.
The clip fits on the top of your notebook computer and holds your AirCard USB
Modem.
Note: To meet FCC (regulatory) requirements, use only the supplied extension cable and
notebook computer clip; other cables and notebook computer clips should not be used.
18 2131232
Note: Do not insert the AirCard USB Modem or the USB extension cable into a USB hub
or, if your keyboard is separate from your notebook computer, a USB slot on your
keyboard.
To use the extension cable and clip:
1. Place the clip on top of the notebook computer.
2. Connect the extension cable to the AirCard USB Modem.
3. Place the modem in the clip holder.
4. Connect the other end of the extension cable to the USB slot on your
computer.
Rev 6 Dec.10 19
AirCard USB Modem User Guide
Attaching the lanyard
To keep everything together, thread the lanyard through the cap and the AirCard
USB Modem, as shown in the illustrations.
Depending on the cap design, you can also attach the lanyard to the cap.
20 2131232
Care and maintenance
As with any electronic device, the AirCard USB Modem must be handled with
care to ensure reliable operation. Follow these guidelines when you use and store
your AirCard USB Modem:
• Do not apply adhesive labels to the SIM card. This may cause it to jam inside
the slot, or prevent it from being inserted properly.
• When not installed in your computer, store the AirCard USB Modem and SIM
card in a safe place.
• The modem should fit easily into your computer’s USB port. Forcing the
AirCard USB Modem into the port may damage the connector pins.
• Protect the AirCard USB Modem from liquids, dust, and excessive heat. (See
the Environmental specifications for maximum tolerances.)
Troubleshooting
This section describes possible problems and solutions for Windows users. If you
have a problem that is not described in this section, visit the Sierra Wireless
support page at www.sierrawireless.com/support.
Software installation does not start automatically (Windows) or you do not see the installer package (Mac)
Windows
If Watcher installation does not start after you insert the AirCard USB Modem:
1. Double-click
Windows 7) on your desktop.
2. Click the
3. Under the
Follow the on-screen prompts to install the software.
Mac OS X
If you do not see the installer package:
1. Open Finder.
2. Under
3. Double-click the installer package.
My Computer (Windows XP) or Computer (Windows Vista,
TRU-Install drive.
TRU-Install drive, open the Win folder and double-click Setup.exe.
Devices, click AirCard
xxx
(where xxx is the model name).
Rev 6 Dec.10 21
AirCard USB Modem User Guide
Modem is not detected after AirCard Watcher installation completes (Windows)
You successfully complete the automatic installation process, but Watcher does
not detect the AirCard USB Modem:
1. Click
2. Double-click
3. When you are prompted to switch to modem mode, click
4. Wait for Watcher to detect the AirCard USB Modem.
5. If the AirCard USB Modem still is not detected, connect to the Internet using
another method and go to www.sierrawireless.com/support for assistance.
Windows installer fails
When you try to install or uninstall Watcher, the message Windows Installer is not
accessible
To fix Error 1601, first see if another installation process is running.
1. Press
2. Go to the
3. Check the running processes for any of these names:
· setup.exe
· isetup.exe
· ikernel.exe
· msiexec.exe
· idriver.exe
· IsUninst.exe
· IsUninst.exe
· Uninst.exe
Start, and then click Control Panel.
TRU-Install.
OK.
(for example, Error code: 1601) appears.
Ctrl + Alt + Del and select Task Manager.
Processes tab.
If any of these processes are running on the system:
1. Select each process.
2. Click
3. Try to run the Watcher installation again.
If the installation is not successful, connect to the Internet using another method
and check Sierra Wireless Knowledge Base articles at sierrawireless.com.
22 2131232
End Process.
Technical specifications
Radio frequency and electrical specifications
The radio frequency bands that your AirCard USB Modem supports will vary
depending on your region and your model.
Transmit GSM 1900 (PCS): 1850 – 1910 MHz
GSM 1800 (DCS):1710 – 1785 MHz
EGSM 900: 880 – 915 MHz
GSM 850: 824 – 849 MHz
WCDMA 2100 (Band 1): 1920 – 1980 MHz
WCDMA 1900 (Band 2): 1850 – 1910 MHz
WCDMA 850 (Band 5): 824 – 849 MHz
WCDMA 800 (Band 6): 830 – 840 MHz
WCDMA 900 (Band 8) 880 – 915 MHz
Receive GSM 1900 (PCS): 1930 – 1990 MHz
GSM 1800 (DCS): 1805 – 1880 MHz
EGSM 900: 925 – 960 MHz
GSM 850: 869 – 894 MHz
WCDMA 2100 (Band 1): 2110 – 2170 MHz
WCDMA 1900 (Band 2): 1930 – 1990 MHz
WCDMA 850 (Band 5): 869 – 894 MHz
WCDMA 800 (Band 6): 875 – 885 MHz
WCDMA 900 (Band 8) 925 – 960 MHz
Frequency band support
Technology Bands Location
2G 850 MHz (cellular band) North America
900 MHz (EGSM band) Europe
1800 MHz (DCS band) Europe and Asia
1900 MHz (PCS band) North America
3G WCDMA 850 (Band 5) North America, Australia,
WCDMA 800 (Band 6) Japan
WCDMA 900 (Band 8) Europe, Asia, and
WCDMA 1900 (Band 2) North America
WCDMA 2100 (Band 1) Europe, Asia, and
and New Zealand
Australia
Australia
Rev 6 Dec.10 23
AirCard USB Modem User Guide
Environmental specifications
Operating temperature
(ambient)
Storage temperature -40°C to +85°C, 96 hours (-40°F to +185°F)
Humidity 85%, non-condensing
Vibra t i o n Random vibration, 10 to 1000 Hz, nominal 6 G
Drop 1 m on concrete on each of 6 faces, 2 times
0°C to 35°C (32°F to 95°F),
0°C to 45°C (32°F to 113°F) for AirCard 318U
RMS in each of 3 mutually perpendicular axes.
Test duration of 60 minutes for each axis, for a
total test time of 3 hours (non-operating).
24 2131232
Regulatory and safety information
Notice
Because of the nature of wireless communications, transmission and reception of
data can never be guaranteed. Data may be delayed, corrupted (that is, have
errors), or be totally lost. Although significant delays or losses of data are rare
when wireless devices such as the Sierra Wireless modem are used in a normal
manner with a well-constructed network, the Sierra Wireless modem should not
be used in situations where failure to transmit or receive data could result in
damage of any kind to the user or any other party, including but not limited to
personal injury, death, or loss of property. Sierra Wireless and its affiliates accept
no responsibility for damages of any kind resulting from delays or errors in data
transmitted or received using the Sierra Wireless modem, or for failure of the
Sierra Wireless modem to transmit or receive such data.
Safety and hazards
The modem MUST BE POWERED OFF in all areas that may be susceptible to
radio interference, in particular:
• Prohibited areas
Obey all signs and notices and follow all rules and regulations. Power off the
modem when instructed to do so or when you suspect that it may cause interference or danger.
• In areas where blasting is in progress
• Where explosive atmospheres may be present
Areas with a potentially explosive atmosphere are not always clearly marked.
Such areas include gas stations, fuel depots, chemical transfer or storage
facilities, areas where blasting is in progress, areas where the air contains
chemicals or particles such as grain, dust, or metal powders, and any other
area where you would normally be advised to turn off your cellular phone or
vehicle engine.
• Near medical or life-support equipment
Medical equipment may be susceptible to any form of radio interference. In
such areas the modem can transmit signals that could interfere with this
equipment.
• On board aircraft
In addition to Federal Aviation Authority (FAA) requirements, many airline regulations state that you must suspend wireless operations before boarding an
aircraft. The modem is capable of transmitting signals that could interfere with
various onboard systems and controls.
Failure to observe this instruction may lead to suspension or denial of cellular
telephone services to the offender, legal action, or both.
Some airlines may permit the use of cellular phones while the aircraft is on the
ground and the door is open. The modem may be used normally at this time.
• While operating a vehicle
Rev 6 Dec.10 25
AirCard USB Modem User Guide
The driver or operator of any vehicle should not use a wireless data device
while in control of a vehicle. Doing so detracts from the driver or operator's
ability to control and operate the vehicle. In some countries, using such communications devices while in control of a vehicle is an offence.
Regulatory information for North America
Note: Regulatory information in this section
applies to these models:
Compass 888
USB 306
USB 308
AirCard 319U
CAUTION: Unauthorized modifications or changes not expressly approved by
Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby
your authority to use this equipment.
The design of the Sierra Wireless modems complies with U.S. Federal Communications Commission (FCC) and Industry Canada (IC) guidelines respecting safety
levels of radio frequency (RF) exposure for portable devices, which in turn are
consistent with the following safety standards previously set by Canadian, U.S.
and international standards bodies:
• ANSI/IEEE C95.1-2005, IEEE Standard for Safety Levels with Respect to
Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300
GHz
• National Council on Radiation Protection and Measurements (NCRP) Report
86, -1986, Biological Effects and Exposure Criteria for Radio Frequency
Electromagnetic Fields
• Health Canada, Safety Code 6, 1999, Limits of Human Exposure to Radio
frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300
GHz
• International Commission on Non-Ionising Radiation Protection (ICNIRP)
1998, Guidelines for limiting exposure to time-varying electric, magnetic, and
electromagnetic fields (up to 300 GHz)
Caution: The Sierra Wireless USB modem must be 1 cm or more from users during
operation, to satisfy FCC / IC RF exposure requirements. The Sierra Wireless USB modem
has been tested for compliance with FCC / IC RF exposure limits in the notebook
computer(s) configurations with horizontal and vertical USB slots and can be used in
notebook computers with substantially similar physical dimensions, construction, and
electrical and RF characteristics. This USB modem must not be used with any other
antenna or transmitter that has not been approved to operate in conjunction with this
modem. Note: This USB modem must not be used in any unapproved configurations. For
details, contact Sierra Wireless.
Note: The Sierra Wireless USB modem is approved for normal-size notebook computers
only (typically with 12 inches or larger display screens). For notebook computers with a
display screen smaller than 12 inches or if the orientation of the USB slot does not allow for
at least 1 cm between the modem and the user or bystanders, use the provided extension
cable and clip to ensure a safe distance between the modem antenna and users or
bystanders.
To meet FCC requirements, use only the supplied USB extension cable and laptop clip;
other cables and laptop clips should not be used.
26 2131232
These devices comply with Part 15 of the FCC Rules. Operation is subject to the
*
**
condition that these devices do not cause harmful interference.
Where appropriate, the use of the equipment is subject to the following conditions:
Warning: (EMI) – United States FCC Information – This equipment has been tested and
found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in an appropriate
installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
If you have purchased this product under a United States Government contract, it
shall be subject to restrictions as set forth in subparagraph (c)(1)(ii) of Defense
Federal Acquisitions Regulations (DFARs) Section 252.227-7013 for Department
of Defense contracts, and as set forth in Federal Acquisitions Regulations (FARs)
Section 52.227-19 for civilian agency contracts or any successor regulations. If
further government regulations apply, it is your responsibility to ensure
compliance with such regulations.
Regulatory information for EU countries
Note: Regulatory information in this section
applies to these models:
Compass 888
Compass 889
USB 306
USB 307*
USB 309
AirCard 310U
AirCard 312U
AirCard 318U**
AirCard 319U**
*
*
*
*
*
**
Rev 6 Dec.10 27
Sierra Wireless hereby declares that the Sierra Wireless USB wireless modem
conforms to all the essential requirements of Directive 1999/5/EC:
The Declaration of Conformity made under Directive 1999/5/EC is available for
viewing at the following location in the EU community:
Sierra Wireless UK
Suite 6, The Hub,
Fowler Avenue
Farnborough Business Park
Far nborough
GU14 7JP
United Kingdom
AirCard USB Modem User Guide
28 2131232
Index
A
accessories, 18
account, 7
C
clip, 18
connect to the network, 12
coverage area, 7
E
electrical specifications, 23
environmental specifications, 24
extension cable, 18
external memory storage, 7, 13
external SD, 13
external storage card, 13
F
features, 8
flash drive, 13
frequencies
receive, 23
transmit, 23
H
humidity, 24
L
N
network, overview, 7
notebook computer clip, 18
P
profile, 12
R
radio frequency specifications, 23
receive frequencies, 23
regulatory information, 25
RF specifications, 23
roaming, 7
S
safety notice, 25
SIM card, removing, 17
specifications
electrical, 23
environmental, 24
radio frequency, 23
storage
temperature, 24
when not using card, 21
T
temperature, 24
transmit frequencies, 23
lanyard, 20
launching Watcher, 10
LEDs, 9
M
memory card, 7
microSD, 7, 13
V
vibration, 24
W
Watcher
introduction, 10
launching, 10
Rev 6 Dec.10 29
AirCard USB Modem User Guide
30 2131232
Loading...
