Siemens Building Technologies Two-Way Flanged PICV Data Sheet
Two-Way Flanged PICV
Siemens
Product Guard
Warranty
Control Valve, Adjustable Flow Limiter,
and Automatic Pressure Regulator
2-1/2 to 3"
ANSI Class 125 or 250
Normally Open
PICV
Flanged PICV Valve.
Description
Pressure Independent Control Valves automatically adjust
to differential pressure changes, providing constant ow in
HVAC systems. This reduces “hunting” for the right setting,
and results in better control and increased comfort. Overall
system performance can be optimized with PICV, requiring
less pumping energy and contributing to more efcient
loading of boilers and chillers.
Siemens Pressure Independent Control Valves integrate
three functions into a single device: control valve,
adjustable ow limiter, and automatic pressure regulator.
The 2-1/2 and 3 inch valves have a 20 mm stroke and use
the SAX non-spring return electronic valve actuators and
the new SQV spring return electronic valve actuators.
Features
• 3-in-1 device includes a control valve, eld adjustable
ow limiter, and automatic pressure regulator.
• Full stroke regardless of maximum ow setting.
• Maximum ow preset is easily eld adjustable.
• Choice of low ow (up to 110 gpm for 2.5 inch and
150 gpm for 3 inch) or high ow (up to 154 gpm for
2.5 inch and 190 gpm for 3 inch) versions
• Available in both ANSI 125 and ANSI 250
pressure classes.
• Both SQV actuators (normally open and normally
closed) can be wired for oating, 0-10V or 4-20 mA
control signals
Applications
Typical applications include control of hot or chilled water
or water-glycol solutions up to 50% in closed
loop systems.
A-93
Valves
Siemens
Product Guard
PLUS 3 Warranty
www.usa.siemens.com/hvac
Flanged PICV Specifications
A-94
Valves
Body Material ..............................................................................Cast Iron
Plug ................................................................................................... Brass
Seat .....................................................................................Stainless Steel
Stem ....................................................................................Stainless Steel
Line size .............................................2-1/2-inch (65 mm) 3-inch (80 mm)
Action .............................................................................................2-way
Valve Body Rating .....................................................ANSI 125/ANSI 250
Close-off ........................................................................ 100 psi (700 kPa)
Leakage Rate ..................................................... < ANSI Class IV (0.01%)
Medium Temperature Range .....................34°F to 250°F (1°C to 120°C)
Flow Characteristic .........................................................................Linear
Connection ..........................................................................ANSI Flanged
Actuator Specications
Operating Voltage
SAX, SQV ...........................................................................24 Vac/dc
Frequency ...................................................................................50/60 Hz
Flanged PICV Product Ordering
Valve Size
in. (mm)
2-1/2 (65)
3 (80)
Maximum Flow Range
GPM (m3/h)
19 to 110 (4.4 to 25) 599-07310 —
26 to 154 (6 to 35) 599-07315 —
19 to 110 (4.4 to 25) — 599-07320
26 to 154 (6 to 35) — 599-07325
24 to 150 (5.3 to 34) 599-07311 —
31 to 190 (7 to 43) 599-07316 —
24 to 150 (5.3 to 34) — 599-07321
31 to 190 (7 to 43) — 599-07326
Power consumption (normal operation)
SAX ......................................................................................8 VA/3.75W
SQV ......................................................................................20 VA/7.5W
Control Signal
SAX81.03U.................................................................................Floating
SAX61.03U........................................................................... 0 to 10 Vdc
SQV ...............................Selectable (Floating, 0 to 10 Vdc, 4 to 20 mA)
Run time
SAX .................................................................................... 30 seconds
SQV ..................................................... 40 to 120 seconds (adjustable)
Force
SAX ................................................................................180 lb (800 N)
SQV .............................................................................. 250 lb (1100 N)
Weight
SAX ..................................................................................4 lbs (1.8 kg)
SQV ................................................................................14 lbs (6.2 kg)
Agency Certication
UL .................................................................................... Meets UL 873
cUL ............................Certied to Canadian Standard C22.2 No. 24.93
ANSI Class 125 ANSI Class 250
Part No. Part No.
PICV Actuator Product Ordering
Description Part No. Actuator Prex Code
Floating, 0-10V or 4 to 20mA, Spring Return,
Electro-Mechanical
Electro-Mechanical
Accessories & Service Kits
www.usa.siemens.com/hvac
Normally Open
Floating, 0-10V or 4 to 20mA, Spring Return,
Normally Closed
Floating, 3P, Non-Spring Return SAX81.03U 373
24 Vac, Proportional Non-Spring Return SAX61.03U 371
SQV91P30U 238
SQV91P40U 239
A-257
