en Instructions for use
Page 2
Page 3
en
Index
Safety instructions 4 . . . . . . .
Delivery 4 . . . . . . . . . . . . . . . . . . . .
Installation 4 . . . . . . . . . . . . . . . . .
In daily use 4 . . . . . . . . . . . . . . . . .
Children in the household 4 . . . .
Childproof lock (door lock) 4 . . . .
Damage 4 . . . . . . . . . . . . . . . . . . .
Disposal 5 . . . . . . . . . . . . . . . . . . .
Getting to know your appliance 5
Control panel 5 . . . . . . . . . . . . . . .
Appliance interior 5 . . . . . . . . . . . .
Selecting language 6 . . . . . . . . . .
Water softening system 6 . . .
Set 6 . . . . . . . . . . . . . . . . . . . . . . . .
Salt 7 . . . . . . . . . . . . . . . . . . . . .
Using salt 7 . . . . . . . . . . . . . . . . . .
Switching off salt refill indicator/
water softening system 8 . . . . . . .
Rinse aid 8 . . . . . . . . . . . . . . . .
Setting amount of rinse-aid 9 . . .
Switching off rinse-aid refill indicator 9
Utensils 9 . . . . . . . . . . . . . . . . .
Not suitable 9 . . . . . . . . . . . . . . . .
Glass and utensil damage 9 . . . .
Loading the dishwasher 10 . . . . . .
Unloading the dishwasher 10 . . . .
Cups and glasses 10 . . . . . . . . . . .
Pans 10 . . . . . . . . . . . . . . . . . . . . . .
Folding spikes 10 . . . . . . . . . . . . . .
Cutlery drawer 11 . . . . . . . . . . . . . .
Small accessories holder 11 . . . . .
Adjusting the height of the basket 11
Detergent 12 . . . . . . . . . . . . . . . .
Adding detergent 13 . . . . . . . . . . . .
Overview of programmes 14 . .
Programme selection 14 . . . . . . . .
Information about comparability tests 14
Additional options 15 . . . . . . . .
Saving time (VarioSpeed) 15 . . . . .
Half load 15 . . . . . . . . . . . . . . . . . . .
Hygiene 15 . . . . . . . . . . . . . . . . . . . .
IntensiveZone 15 . . . . . . . . . . . . . .
Extra drying 15 . . . . . . . . . . . . . . . .
Washing the dishes 15 . . . . . . .
Programme data 15 . . . . . . . . . . . .
Aqua sensor 15 . . . . . . . . . . . . . . . .
Switching on the appliance 15 . . .
Remaining running time display 16
Display window 16 . . . . . . . . . . . . .
Timer programming 16 . . . . . . . . . .
End of programme 16 . . . . . . . . . . .
Switching off the appliance 17 . . .
Interrupting the programme 17 . . .
Terminating the programme (Reset) 17
Changing the programme 17 . . . .
Intensive drying 17 . . . . . . . . . . . . .
Interior light 18 . . . . . . . . . . . . . . . . .
Maintenance and care 18 . . . .
Overall condition of the machine 18
Filters 19 . . . . . . . . . . . . . . . . . . . . .
Spray arms 19 . . . . . . . . . . . . . . . . .
Waste water pump 20 . . . . . . . . . .
Troubleshooting 20 . . . . . . . . . .
... when the appliance is switched on 20
... on the appliance 20 . . . . . . . . . .
... changing settings 21 . . . . . . . . .
... during the wash cycle 21 . . . . . .
... on the utensils 22 . . . . . . . . . . . .
Customer service 23 . . . . . . . . .
Installation 23 . . . . . . . . . . . . . . .
Safety instructions 23 . . . . . . . . . . .
Delivery 24 . . . . . . . . . . . . . . . . . . . .
Installation 24 . . . . . . . . . . . . . . . . .
Waste-water connection 24 . . . . . .
Fresh-water connection 24 . . . . . .
Electrical connection 25 . . . . . . . . .
Removing the appliance 25 . . . . . .
Transportation 25 . . . . . . . . . . . . . .
Protection against frost 25 . . . . . . .
Waste disposal 26 . . . . . . . . . . .
Packaging 26 . . . . . . . . . . . . . . . . . .
Old appliances 26 . . . . . . . . . . . . . .
Page 4
en
4
Safety instructions
Delivery
Check the packaging and dishwasher
immediately for damage caused in
transit. Do not switch on a damaged
appliance, but contact your supplier.
Please dispose of the packaging
material in an environmentally friendly
manner.
Do not let children play with packaging
and its parts. There is a risk of suffocation from collapsible boxes and film.
Installation
Read the “Installation” chapter to learn
how to install and connect the appliance
correctly.
In daily use
Use the dishwasher only in the
household and only for its designed
purpose, i.e. for washing domestic
dishes.
Do not lean or sit on the open door.
The appliance could tip.
Please note that free-standing
appliances may tip over if the baskets
are overloaded.
Do not add any solvents to the washing
chamber. Danger of explosion!
Open the door carefully when the
programme is still running. There is
a risk of hot water spraying out of the
appliance.
To prevent injuries, e.g. caused by
stumbling, open the dishwasher only
briefly in order to load and unload the
dishwasher.
Read and observe the safety information and instructions for use on the
packaging for cleaning and rinsing
agents.
Warning
Knives and other utensils with sharp points
must be placed horizontally in the cutlery
drawer.
Children in the household
If fitted, use the childproof lock.
An exact description can be found
in the back of the envelope.
Do not allow children to play with
or operate the appliance.
Keep children away from detergents
and rinse aid. These may cause
chemical burns in the mouth, throat
and eyes or asphyxiation.
Keep children away from open
dishwasher. The water in the rinsing
compartment is not drinking water and
could contain detergent residue.
Ensure that children do not place
fingers in the tablet collecting tray
24
.
Small fingers could become caught in
the slots.
If the appliance is installed at eye-level,
ensure when opening and closing the
door that children are not caught or
crushed between the appliance door
and the cupboard door situated below.
Childproof lock (door lock)
The description of the childproof lock
is at the back in the envelope.
Damage
The appliance may be repaired and
opened up by a technician only. To do
this, disconnect the appliance from the
power supply. Pull out the mains plug
or switch off the fuse. Turn off the tap.
Page 5
en
5
Disposal
Make redundant appliances unusable
to prevent subsequent accidents.
Dispose of the appliance in an
environmentally friendly manner.
Warning
Children could become locked in the
appliance (risk of suffocation) or find
themselves in other dangerous situations.
Therefore: Pull out the mains plug, sever
and dispose of the power cord. Destroy
the door lock so that the door can no
longer be closed.
Getting to know your
appliance
Diagrams of the control panel and the
interior of the appliance can be found
in the envelope at the front.
Individual positions are referred to in the
text.
Control panel
1
ON/OFF switch
2
Programme buttons **
3
Digital display
4
Display “Check water supply”
5
Salt refill indicator
6
Rinse-aid refill indicator
7
Timer programming display
8
Time delay
9
Additional options **
10
START button
11
Door Opener
12 Display window
** Number depending on model
Appliance interior
20
Interior light *
21
Cutlery drawer
22
Top basket
23
Top spray arm
24
Tablet collecting tray
25
Bottom spray arm
26
Dispenser for salt
27
Filters
28
Bottom basket
29
Dispenser for rinse aid
30
Detergent dispenser
31
Lock for detergent dispenser
32
Rating plate
* depending on model
Page 6
en
6
Selecting language
The language in the display window
12
can be set from to . “Deutsch”
is the factory setting.
Language
Setting
Deutsch L:01
English L:02
Français L:03
Nederlands L:04
Italiano L:05
ЕЛЛЗНЙКБ L:06
Español L:07
Português L:08
Svenska L:09
Norsk L:10
Suomi L:11
Dansk L:12
Türkçe L:13
PYCCÅ L:14
Polski L:15
Èe. L:16
Magyar L:17
Croatian L:18
Slovenian L:19
To change the language:
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button
A
and press START button 10 until the
digital display
3
is indicated.
Release both buttons.
Press programme button A until
the factory set value is indicated
on the digital display
3
.
“Deutsch” is indicated in the display
window
12
.
Press programme button C.
Each time the button is pressed,
the set value increases by 1; after
, the setting goes back to .
Press START button 10.
The set value is saved.
Close the door.
Water softening system
To ensure good washing results,
the dishwasher requires soft water,
i.e. containing low amounts of lime,
otherwise white limescale will be
deposited on the utensils and inner
container.
Tap water above 7_ dH (from set value
) must be softened.
The water is softened with salt
(regeneration salt) in the water softening
system of the dishwasher.
The setting and therefore the required
amount of salt depends on the degree
of hardness of your tap water (see table).
Set
The amount of salt dispensed can be set
from
to .
Sal is not required at the set value .
Find out about the hardness value
of your tap water. Your water supply
company will assist you.
Set value can be found in the water
hardness table.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A
and press START button
10
until on
the digital display is indicated
.
Release both buttons.
The LED for button
A flashes and
the digital display displays the factory
setting
.
To change the setting,
press programme button C .
Each time the button is pressed, the set
value increases by one level; when the
value of
has been reached,
the display jumps back to
(off).
Press START button 10.
The chosen setting has now been
stored.
Close the door.
Page 7
en
7
Water hardness table
Salt
Using salt
Always refill with salt immediately before
switching on the appliance. This ensures
that overrun salt solution is immediately
washed out and does not corrode the
rinsing tank.
Open the screw-type cap of the
compartment
26 .
Fill the tank with water (only required
when switching on the appliance for
the first time).
Then add dishwasher salt (not table
salt or tablets).
The water is displaced and runs out.
As soon as the salt refill indicator
5
on the fascia is lit, top up the salt.
* depending on model
Using detergents with salt
component
If combined detergents with a salt
component are used, salt can usually be
omitted up to a water hardness of 21 dH
(37 fH, 26 Clarke, 3.7 mmol/l). If the water
hardness is over 21 dH, salt must be
used.
Page 8
en
8
Switching off salt refill
indicator/water softening
system
If the salt refill indicator
5
is impaired
(e.g. when using combined detergents
containing salt component), it can be
switched off.
Proceed as described under “Setting
water softening system” and set the
value to
.
The water softening system and salt
refill indicator are now switched off.
Warnings
Never fill the salt dispenser with
detergent. You will destroy the water
softening system.
To prevent corrosion, always refill with
salt immediately before switching on the
appliance.
Rinse aid
As soon as the rinse-aid refill indicator
6
lights up on the control panel,
refill with rinse aid.
The rinse aid is required for stain-free
utensils and clear glasses.
Use only rinse aid for domestic dishwashers.
Combined detergents with rinse-aid component may be used up to a water hardness of 21 _dH (37 _fH, 26 _Clarke,
3,7 mmol/l) only. If the water hardness
is over 21 _dH, rinse-aid must be used.
Open the dispenser 29 by pressing
and lifting the plate on the cover.
Carefully pour rinse aid up to the max.
mark in the filler opening.
Close cover until it clicks shut.
To prevent excessive foam formation
during the next rinse cycle, remove
any rinse aid which has run over with
a cloth.
Page 9
en
9
Setting amount of rinse-aid
The amount of rinse-aid dispensed can be
set from
to . The factory setting
is
.
Do not change the amount of rinse-aid
unless streaks (select lower setting) or
water stains (select higher setting) are left
on the utensils.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A
and press START button 10 until on
the digital display is indicated
.
Release both buttons.
The LED for button
A flashes and
the digital display displays the factory
setting
.
Press programme button A until the
factory set value
is indicated on
the digital display
3
.
To change the setting,
press programme button C .
Each time the button is pressed, the set
value increases by one level; when the
value of
has been reached, the
display jumps back to
(off).
Press START button 10.
The set value is saved.
Close the door.
Switching off rinse-aid refill
indicator
If the rinse-aid refill indicator
6
is
impaired (e.g. when using combined
detergents containing rinse-aid
component), it can be switched off.
Proceed as described under “Setting
amount of rinse-aid” and set the value
to .
The rinse-aid refill indicator
6
is now
switched off.
Utensils
Not suitable
Cutlery and utensils made of wood.
Delicate decorative glasses, craft and
antique utensils. These decors are not
dishwasher-proof.
Plastic parts not resistant to heat.
Copper and tin utensils.
Utensils which are soiled with ash, wax,
lubricating grease or ink.
Aluminium and silver parts have
a tendency to discolour and fade during
the wash cycle. Even some types of glass
(e.g. crystal glass objects) may turn cloudy
after many wash cycles.
Glass and utensil damage
Causes:
Glass type and glass production
process.
Chemical composition of the detergent.
Water temperature of the wash
programme.
Recommendation:
Use only glasses and porcelain which
the manufacturer designates as
dishwasher-proof.
Use a detergent which protects
utensils.
Take glass and cutlery out of the
dishwasher as soon as possible
after the programme ends.
Page 10
en
10
Loading the dishwasher
Remove large food remnants.
It is not necessary to prerinse utensils
under running water.
Place the utensils so that
D
they are secure and cannot tip over.
D
all utensils with their openings face
down.
D
parts with curves or indentations are
at an angle, thereby allowing water
to drain.
D
does not obstruct rotation of the two
spray arms
23 and 25 .
Very small utensils should not be washed
in the machine, as they may fall out of the
baskets.
Unloading the dishwasher
To prevent water from dripping off the
upper basket onto the utensils in the lower
basket, it is recommended to empty the
appliance from the bottom up.
Cups and glasses
Top basket
22
Pans
Bottom basket
28
Folding spikes
*
* depending on model
The spikes can be folded down to improve
arrangement of pans, bowls and glasses.
Page 11
en
11
Cutlery drawer
Arrange the cutlery in the cutlery drawer
21
as illustrated. Separately arranged
utensils are easier to remove after
washing.
The drawer can be taken out.
Small accessories holder
*
* depending on model
Light-weight plastic accessories, e.g. cups,
lids, etc. can be held securely in the small
accessories holder.
Adjusting the height of the
basket
The height of the upper utensils basket
can be adjusted in 3 stages to create more
space either in the upper or lower basket.
Appliance height 81.5 cm
Top
basket
Bottom
basket
Setting 1
max. ∅
16 cm 30 cm
Setting 2
max. ∅
18.5 cm 27.5 cm
Setting 3
max. ∅
21 cm 25 cm
Appliance height 86.5 cm
Top
basket
Bottom
basket
Setting 1
max. ∅
18 cm 33 cm
Setting 2
max. ∅
20.5 cm 30.5 cm
Setting 3
max. ∅
23 cm 28 cm
Page 12
en
12
Pull out the top basket 22 .
To lower the basket, press in the left
and then the right lever on the outside
of the basket. In doing so, hold the
sides of the basket along the upper
edge to prevent it from suddenly
dropping.
To raise the basket, hold the basket on
the sides of the upper edge and lift it
up.
Before re-inserting the basket again,
ensure that it is at the same height on
both sides. Otherwise, the appliance
door cannot be closed and the upper
spray arm will not be connected to the
water circuit.
Detergent
You can use tablets as well as powder
or liquid detergents for dishwashers,
but never use washing up liquid. Tablets
contain not only detergent but also
rinse-aid and salt (3in1) and, depending
on the combination (4in1, 5in1, etc.),
additional components such as glass
protection or stainless steel cleaner.
If tablets contain rinse-aid and salt, it is
usually not necessary to add additional
rinse-aid and salt up to a specific degree
of hardness. If the degree of hardness is
higher and if using solo detergents
(powder or liquid detergents or tablets
without rinse-aid and salt) rinse-aid and
salt must be added. The appliance doses
these automatically according to the
preset values for water hardness and
amount of rinse-aid.
As soon as combined detergent
products are used, the rinse
programme is adjusted automatically
to ensure the best possible rinsing and
drying result.
Tip
Follow the instructions for use or the
instructions on the detergent packaging
to ensure that rinse-aid and salt are used
effectively.
If you have further questions, we recommend that you contact the detergent
manufacturers’ helpline.
Detergent dispenser
with dosing aid
The graduated detergent dispenser
30
helps you add the correct amount of
powder or liquid detergent:
lower line: 15 ml
middle line: 25 ml
full: 50 ml
Page 13
en
13
Adding detergent
Pour detergent into the dispenser 30
(insert tablet flat, not on its edge).
Dosage: see manufacturer’s
instructions on the packaging.
Close the cover on the detergent
dispenser by sliding it up until the lock
engages without difficulty.
The detergent dispenser opens
automatically at the optimum time
depending on the programme.
The powder or liquid detergent
is distributed in the appliance and
is dissolved, the tablet falls into the
tablet collecting tray where it dissolves
in doses.
Tip
If the utensils are only lightly soiled,
slightly less than the indicated amount
of detergent is usually adequate.
Warnings
Do not place small parts for washing
in the tablet collecting tray
24 ; this
prevents the tablet from dissolving
evenly.
If you want to add more utensils after
the programme has started, do not
use the tablet collecting tray
24
as a handle for the upper basket.
The tablet could already be there and
you will touch the partially dissolved
tablet.
Note
You will obtain optimum rinsing and
drying results by using solo detergents
and applying salt and rinse-aid
separately.
f programmes are short, tablets may not
have full cleaning effect due to different
dissolving properties and there may
even be undissolved detergent residue.
It is recommended to use washing
powder for these programmes.
The Intensive programme (on some
models) requires one tab only. When
using washing powder, you can apply
some of this cleaning agent to the
inside of the appliance’s door.
Even if the rinse-aid and/or salt refill
indicator is lit, the rinse programme will
run correctly if combined detergents
are used (when using combined
detergents, add rinse-aid at a water
hardness above 21 _dH – see chapter
entitled “Rinse-aid”).
If you switch from combined detergents
to solo detergents, ensure that the
water softening system and amount
of rinse-aid have been set to the correct
value.
If using detergents in a water-soluble
protective cover: Take hold of the cover
with dry hands only and put the
detergent into an absolutely dry
detergent dispenser only, otherwise
the detergent may stick.
Page 14
en
14
Overview of programmes
The max. possible number of programmes is illustrated in this overview. The corresponding
programmes for your appliance can be found on the fascia.
Programme
Type of utensils
and soiling
Programme sequence Possible
additional options
Auto 65–75 Pots, utensils
and cutlery
Highly soiled
Is optimised according
to the soiling with the aid
of sensors.
all
Auto 45–65 Utensils and cutlery
Normally soiled
Is optimised according
to the soiling with the aid
of sensors.
all
Eco 50 Utensils and cutlery
Normally soiled
Prerinse
Clean 50
Intermediate rinse
Final rinse 65
Dry
all
Auto 35–45 Utensils and cutlery
Lightly soiled
Is optimised according
to the soiling with the aid
of sensors.
IntensiveZone
Reduce Time
Half load
Extra drying
Quick 45° Utensils and cutlery
Lightly soiled
Clean 45°
Intermediate rinse
Final rinse 55°
Extra drying
Prerinse Lightly soiled Prerinse none
Programme selection
You can select a suitable programme
according to the type of utensils and
degree of soiling.
Information about comparability
tests
The conditions for running comparability
tests can be found on the supplementary
sheet “Information for comparability tests”.
Page 15
en
15
Additional options
* depending on model
Additional options
9
can be set with the
buttons.
Saving time (VarioSpeed)
*
The >>Save time<< function can reduce
the running time by approx. 20% to 50%
depending on the selected rinse programme. The change in the running time
is indicated on the digital display
3
.
To obtain optimum cleaning results at
a reduced running time, water and energy
consumption are increased.
Half load
*
If you have only a few items to wash (e.g.
glasses, cups, plates), you can switch to
“half load”. This will save water, energy
and time. It is recommended to put a little
less detergent in the detergent dispenser
than for a full load.
Hygiene
*
The temperature is increased during
the rinsing process. This increases the
hygiene status. This additional option
is ideal for cleaning e.g. chopping boards
and baby bottles.
IntensiveZone
*
Perfect for a mixed load. You can wash
very soiled pots and pans in the lower
basket together with normally soiled
utensils in the upper basket. The spray
pressure in the lower basket is intensified,
the rinsing temperature is increased
slightly.
*
Washing the dishes
Programme data
The programme data (consumption
values) can be found in the summary
of instructions. They refer to normal
conditions and the water hardness set
value
. Different influencing factors
such as water temperature or line
pressure may result in deviations.
Aqua sensor
*
* depending on model
The Aqua sensor is an optical measuring
device (light barrier) which measures the
turbidity of the rinsing water.
The Aqua sensor is used according to the
programme. If the Aqua sensor is active,
“clean” rinsing water can be transferred to
the next rinse bath and water consumption
can be reduced by 3–6 litres. If the
turbidity is greater, the water is drained
and is replaced with fresh water. In the
automatic programmes the temperature
and running time can also be adjusted
to the degree of soiling.
Switching on the appliance
Turn on the tap fully.
Open the door.
Switch on ON/OFF switch 1.
The display of the last selected
programme flashes. This programme
remains selected if no other programme
button
2
is pressed.
The expected programme duration
flashes on the digital display 3.
Press the START button 10.
Close the door.
The programme starts running.
Page 16
en
16
Remaining running time display
When the programme is selected, the
remaining running time of the programme
is indicated on the digital display
3
.
The running time is determined during the
programme by the water temperature, the
number of utensils as well as the degree
of soiling and may vary (depending on the
selected programme).
Display window
Apart from information on the programme
sequence, the display window
12
also
indicates additional information on
e.g. glass protection system is active.
If you would no longer like to have this
additional information displayed, proceed
as follows.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A
and press START button 10 until on
the digital display
is indicated.
Release both buttons.
The LED for button
A flashes and
the digital display displays the factory
setting
.
Press programme button A until the
factory set value
is indicated on
the digital display
3
.
To change the setting,
By pressing the C button, you can
switch the onboard computer
(additional programme information)
off
or on .
Press START button 10.
The set value is saved.
Close the door.
Timer programming
You can delay the start of the programme
in 1-hour steps up to 24 hours.
Open the door.
Switch on ON/OFF switch 1.
Press 8 + button until the timer
programming display 7 jumps to .
Press 8 + or – button until the
displayed time corresponds with your
requirements.
Press START button 10, timer
programming is activated.
To delete timer programming, press
the
8
+ or – button until
is indicated on the digital display 7.
You can change your programme
selection at any time until the
programme starts.
Close the door.
End of programme
The programme has ended when the
value
is indicated on the numerical
display
3
.
The end of the programme is also
indicated by an acoustic signal.
This function can be changed as follows:
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A
and press START button 10 until on
the digital display is indicated.
Release both buttons.
The LED for button
A flashes and the
digital display displays the factory
setting
.
Press programme button A until the
factory set value
is indicated on
the digital display .
Page 17
en
17
To change the setting,
press programme button C .
Each time the button is pressed, the set
value increases by one level; when the
value of has been reached, the
display jumps back to
(off).
Press START button 10, the set value
is saved.
Close the door.
Switching off the appliance
Short time after the end of the programme:
Open the door.
Switch off ON/OFF switch 1.
Turn off the tap (not applicable
if Aqua-Stop fitted).
Remove the utensils when they have
cooled down.
Warning
At the end of the programme please open
the door fully and not partially when
emptying the dishwasher. Any escaping
water vapour could damage sensitive
worktops.
Interrupting the programme
Open the door.
Switch off ON/OFF switch 1.
The LEDs go out. The programme
is saved.
If the door was opened on an appliance
which has a warm water connection
or is heated, first leave the door ajar
for several minutes and then close.
Otherwise, expansion (pressure) may
cause the appliance door to spring
open or water to run out of the
appliance.
To continue the programme, switch
on the ON/OFF switch
1
again.
Close the door.
Terminating the programme
(Reset)
Open the door.
Press START button 10 for
approx 3 sec. is indicated
on the digital display
3
.
Close the door.
The programme sequence lasts
approx. 1 min.
is indicated on the digital
display
3
(buzzer sounds).
Open the door.
Switch off ON/OFF switch 1.
Close the door.
Changing the programme
When the START button
10
has been
pressed, the programme cannot be
changed.
The only way a programme can be
changed is by Cancel programme (reset).
Intensive drying
The final rinse uses a higher temperature
which improves the drying result.
The running time may increase slightly.
(Caution if utensils are delicate!)
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A
and press START button
10
until on
the digital display
is indicated.
Release both buttons.
The LED for button
A flashes and
the digital display displays the factory
setting
.
Press programme button A until the
factory set value
is indicated on
the digital display
3
.
To change the setting,
Press the button C to switch
intensive drying on
or off .
Press START button 10.
The set value is saved.
Close the door.
Page 18
en
18
Interior light
*
20
The interior light comes on when the door
is opened irrespective of whether the
ON/OFF switch
1
is switched on or off.
When the door is closed or ajar, the light
is off.
Open the door.
Switch on ON/OFF switch 1.
Hold down programme button A and
press START button
10
until
is indicated on the digital display.
Release both buttons.
The LED for button
A flashes and
the digital display displays the factory
setting
.
Press programme button A until
the factory set value
is indicated
on the digital display
3
.
To change the setting,
Press the button C to switch
the interior light off or on .
Press START button 10.
The set value is saved.
Close the door.
* depending on model
Maintenance and care
A regular inspection and maintenance of
your machine will help to prevent faults.
This saves time and prevents problems.
Overall condition
of the machine
Check spray arm for grease and
limescale deposits.
If you find such deposits:
Fill detergent dispenser with detergent.
Start the appliance without utensils in
the programme with the highest rinsing
temperature.
Clean the appliance with detergents/
appliance cleaners which are particularly
suitable for use with dishwashers.
Regularly clean door seal with a damp
cloth.
Never use a steam cleaner to clean your
dishwasher. The manufacturer is not liable
for any consequential damage.
Regularly wipe the front of the appliance
and fascia with a damp cloth; water and
a little washing up liquid are adequate.
Do not use sponges with a rough surface
or abrasive detergents, as these could
scratch the surfaces.
Stainless steel appliances: To prevent
corrosion, avoid using sponge cloths or
wash them out thoroughly several times
before using for the first time.
Warning
Never use other chlorinated household
detergents! Health hazard!
Salt and rinse-aid
Check the refill indicators 5 and 6.
If required, refill salt and/or rinse-aid.
Page 19
en
19
Filters
The filters
27 keep large foreign objects
in the rinsing water away from the pump.
These foreign objects may occasionally
block the filters.
The filter system consists of a coarse filter,
a flat fine filter and a microfilter.
After each washing cycle check the
filters for residue.
Unscrew filter cylinder as illustrated
and take out filter system.
Remove any residue and clean filters
under running water.
Re-install filter system in reverse
sequence and ensure that the arrow
marks are opposite each other after
closing the filter system.
Spray arms
Limescale and contaminants in the rinsing
water may block nozzles and bearings on
the spray arms
23 and 25 .
Check outlet nozzles on the spray arms
for blockages.
Unscrew the upper spray arm 23 .
Remove the lower spray arm 25
upwards.
Clean spray arms under running water.
Re-engage or screw on spray arms.
Page 20
en
20
Waste water pump
Large food remnants in the rinsing water
not retained by the filters may block the
waste water pump. The rinsing water is
then not pumped out and covers the filter.
In this case:
First disconnect the appliance from the
power supply.
Remove the filters 27 .
Scoop out water, use a sponge
if required.
Using a spoon, prise off pump cover
(as illustrated) until it clicks, then grip
the cover by the lug and first pull it
upwards until it resists and then pull
it out forwards.
Check inner compartment and remove
any foreign objects.
Place cover in the original position,
press down and engage.
Install filters.
Troubleshooting
Experience has shown that you can rectify
most faults which occur in daily operation
without calling customer service.
Obviously this will save on costs and
ensure that the machine is quickly
available again. The following overview
should help you locate the causes of faults
which may occur.
Warning
If an error code (E:01 to E:30) is indicated
on the digital display
3
, always
disconnect the appliance from the power
supply and then turn off the tap.
You can rectify certain faults yourself
(see following fault description), for all
other faults please contact customer
service and state the indicated fault E:XX.
Warning
Remember: Repairs may be carried out by
technicians only. If a component has to be
replaced, ensure that only original spare
parts are used. Improper repairs or use
of non-original spare parts may cause
considerable damage and put the user
at considerable risk.
... when the appliance is
switched on
The appliance does not start.
The mains fuse has tripped.
The appliance plug has not been
inserted.
The appliance door has not been
shut properly.
... on the appliance
Lower spray arm rotates sluggishly.
Spray arm blocked.
The door is difficult to open. *
Child-proof lock is activated.
The deactivation instructions are
at the back in the envelope.
* depending on model
Page 21
en
21
Door cannot be closed.
Door lock has been activated.
To reset, close the door with
greater force.
... changing settings
A setting cannot be changed,
a programme starts.
Wrong programme button pressed.
Terminate the programme
(see chapter entitled “Terminating
the programme (Reset)”) and start
all over again.
You did not wait until programme
ended.
Cover on the detergent dispenser
cannot be closed.
Detergent dispenser overfilled
or mechanism blocked by sticky
detergent residue.
Detergent residue in the detergent
dispenser.
Dispenser was damp when filled.
“check water supply” 4 display
lights up.
Tap turned off.
Water supply interrupted.
Supply hose kinked.
Filter in the water supply blocked.
Switch off the appliance and
pull out the mains plug.
Turn off the tap.
Clean filter in the supply hose.
Reconnect power supply.
Turn on the tap.
Switch on the appliance.
Water is left in the appliance
at the end of the programme.
(E24) Waste water hose is
blocked or kinked.
(E25) Waste water pump
blocked, cover on the waste
water pump is not locked in
position (see Maintenance
and Care).
Filters blocked.
The programme has not yet
ended. Wait until programme
ends (digital display indicates
0:00) or implement the ”Reset”
function.
Refill indicator for salt 5 and/or
rinse-aid
6
is not lit.
Refill indicator/s switched off.
Adequate salt/rinse-aid available.
Refill indicator for special salt
5
is lit.
No salt.
Refill with salt.
Sensor does not detect salt
tablets.
Use different special salt.
... during the wash cycle
Unusual foam formation
Handwash liquid in the rinse
aid dispenser.
Spilled rinse-aid causes excessive
frothing, therefore please remove
with a cloth.
Appliance stops during the wash
cycle.
Power supply interrupted.
Water supply interrupted.
Knocking/rattling noise during
rinsing
Spray arm is striking utensils.
Utensils not arranged correctly.
Page 22
en
22
Filling valves making striking
noises
Caused by the installation of the
water line and has no effect on the
function of the machine. Remedial
action is not possible.
... on the utensils
Food residue on the utensils.
Utensils placed too closely
together, utensils basket overfilled.
Too little detergent.
Rinse programme too weak.
Spray arm rotation obstructed.
Spray arm nozzles blocked.
Filters blocked.
Filters incorrectly inserted.
Waste water pump blocked.
Top basket on right and left not set
to same height.
Tea or lipstick residue is not
completely removed.
Detergent has inadequate
bleaching effect.
Too low rinsing temperature.
Too little/unsuitable detergent
White stains on the
utensils/glasses remain milky.
If phosphate-free detergents are used with
hard tap water, white deposits may be
deposited more easily on utensils and the
container walls.
Too little/unsuitable detergent.
Too weak programme selected.
No/too little rinse-aid.
No/too little salt.
Water softening system set to the
wrong value.
Salt dispenser lock not fastened.
Contact the detergent manufacturer,
in particular if:
the utensils are very wet at the end
of the programme.
limescale forms.
Dull, discoloured glasses,
film cannot be washed off.
Unsuitable detergent.
Glasses not dishwasher-proof.
Streaks on glasses and cutlery,
glasses have metallic appearance.
Too much rinse-aid.
Plastic parts discoloured.
Too little/unsuitable detergent.
Too weak programme selected.
Rust spots on the cutlery.
Cutlery not rust-resistant.
Salt content in the rinsing water
too high, as salt dispenser lock not
fastened firmly or salt was spilled
while being refilled.
Utensils not dry.
Appliance door opened too early
and utensils taken out too early.
Programme selected without
drying.
Too little rinse-aid.
Page 23
en
23
Customer service
If you are unable to rectify the fault, please
contact your customer service.
Your nearest customer service centre can
be found in the customer service list.
When calling customer service, please
quote the appliance number (1) and the
FD number (2) which can be found on the
rating plate
32
on the appliance door.
FD
1
2
Warning
Please note that a visit by a customer
service technician to repair a malfunction
or one of the described faults will not be
free of charge even during the warranty
period.
Installation
The dishwasher must be connected
correctly, otherwise it will not function
properly. The specifications for the inlet
and outlet as well as the electrical
connected loads must correspond with
the required criteria as specified in the
following paragraphs or in the installation
instructions.
Install the appliance in the correct
sequence:
Checking appliance on delivery
Installing the appliance
Waste-water connection
Fresh-water connection
Electrical connection
Safety instructions
Install and connect the appliance
according to the installation and
assembly instructions.
Prior to installation, disconnect the
dishwasher from the power supply.
Ensure that the protective conductor
system of the domestic supply has
been correctly installed.
The electrical connection conditions
must correspond with the specifications
on the dishwasher rating plate.
If the power cord of this appliance
is damaged, it must be replaced with
a particular power cord.
To prevent injury, the power cord may
be replaced by customer service only.
If the dishwasher is installed in a highsided unit, the unit must be secured
properly.
Install built-under or integratable
appliances only under continuous
worktops which have been screwed
to adjacent cupboards to ensure
stability.
Page 24
en
24
Do not install the appliance near heat
sources (radiators, heat storage tanks,
cookers or other appliances which
generate heat) and do not install under
a hob.
After installing the appliance, ensure
that the plug is easily accessible.
Some models:
The plastic housing on the water
connection contains an electric valve,
the connecting cables are in the supply
hose. Do not cut through this hose,
do not immerse the plastic housing
in water.
Warning
If the appliance is not in a cavity and
a side panel is accessible, the door hinge
area must be covered at the side for
reasons of safety (risk of injury).
The covers are available as optional
accessories from customer service
or specialist outlets.
Delivery
Your dishwasher has been checked
thoroughly in the factory to ensure that it
is in working order. This may cause small
water stains. These will disappear after the
first wash cycle.
Installation
The required installation dimensions can
be found in the installation instructions.
Level the appliance with the aid of the
height-adjustable feet. Ensure that the
appliance is situated securely on the floor.
A built-under or integrated appliance
which is installed subsequently as
a free-standing appliance must be
secured to prevent it from overturning,
e.g. by screwing it to the wall or by
installing it under a continuous worktop
which is screwed to adjacent
cupboards.
The appliance can easily be installed
in a fitted kitchen between wooden and
plastic walls. If the plug is not freely
accessible following installation,
an allpole disconnector with a contact
opening of at least 3 mm must be fitted
on the installation side to satisfy the
relevant safety regulations.
Waste-water connection
The required work sequence can be
found in the installation instructions.
If required, fit a siphon with an drainage
connection.
Connect the waste-water hose to the
drainage connection of the siphon with
the enclosed parts.
Ensure that the drainage hose is not
kinked, crushed or twisted and that
there is no cover plate in the drainage
to prevent the waste water from flowing
out!
Fresh-water connection
Connect the fresh-water connection
to the tap according to the installation
instructions with the enclosed parts.
Ensure that the fresh-water connection
is not kinked, crushed or twisted.
When replacing the appliance,
always use a new water supply hose.
Water pressure:
at least 0.05 MPa (0.5 bar), maximum
1 MPa (10 bar). At a higher water
pressure: connect pressure-reducing
valve ahead.
Inlet rate:
minimum 10 litres/minute
Water temperature:
cold water preferred; hot water max.
temp. 60 C.
Page 25
en
25
Electrical connection
Connect the appliance to an alternating
current only, ranging from 220 V to
240 V and 50 Hz or 60 Hz via a correctly
installed socket with protective earth
conductor. See rating plate for required
fusing
32 .
The socket must be near the appliance
and freely accessible following
installation.
The connection may be modified
by technicians only.
A power cord extension may be
purchased from customer service only.
Use only a residual-current-operated
circuit-breaker which features the
symbol. Only this extension guarantees
compliance with the currently valid
regulations.
The appliance features a water damage
protection system. Please note the
system will function only when the
power supply is connected.
Removing the appliance
Also observe the sequence of worksteps
here.
Disconnect the appliance from
the power supply.
Turn off the water supply.
Disconnect the waste water and fresh
water connections.
Loosen the fastening screws under
the worktop.
If fitted, remove the base panel.
Pull out the appliance, carefully pulling
the hose behind.
Transportation
Empty the dishwasher and secure
loose parts.
Drain the appliance according to the
following steps:
Turn on the tap.
Open the door.
Switch on ON/OFF switch 1.
The displays of the last selected
programme light up.
Select programme with the highest
temperature.
The expected programme duration
is indicated on the numerical
display
3
.
Press START button 10.
Close the door.
The programme starts running.
Open door after approx. 4 minutes.
Press the START button 10 until
on the digital display is indicated
.
Close the door.
Open door after approx. 1 minutes.
The numerical display indicates
.
Switch off appliance 1 and turn
off the tap.
Transport appliance upright only.
(This prevents residual water from
running into the machine control and
damaging the programme sequence).
Protection against frost
If the appliance is in a room where there
is a risk of frost (e.g. holiday home),
empty the appliance completely
(see Transportation).
Turn off the tap, disconnect supply hose
and drain water.
Page 26
en
26
Waste disposal
Both the packaging of new appliances
and the old appliances themselves contain
valuable raw materials and recyclable
materials.
Please dispose of the individual parts
separated according to type.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
Packaging
All plastic parts of the appliance are
identified with internationally standardised
abbreviations (e.g. >PS< polystyrene).
Therefore, plastic waste can be sorted out
when the appliance is being disposed of.
Please follow the safety instructions under
“Delivery of your appliance”.
Old appliances
Please follow the safety instructions under
“Disposal of your appliance”.
This appliance is identified according
to the European guideline 2002/96/EC on
waste electrical and electronic equipment
– WEEE. The guideline specifies the
framework for an EU-wide valid return
and re-use of old appliances.
Page 27
en
27
en Subjekt to modification
Page 28
Child-proof lock *
40 Switch on the child-proof lock
41 Open the door with child-proof
lock switched on
42 Switch off the child-proof lock
Always close the appliance door
completely before leaving the
appliance. Only in this way can you
protect your children from potential
hazards.
Baking sheet spray head *
Large sheets or grilles and plates which have a diameter greater than 30 cm (gourmet plates, pasta
plates, dinner plates) can be cleaned with the aid of the spray head.
To do this, remove the top basket and insert the spray head as illustrated in the diagram.
To ensure that the spray jet can reach all parts, arrange the baking sheets as illustrated (max. 4 baking
sheets and 2 grilles).
Never operate the dishwasher without the top basket or baking sheet spray head!
* some models
Page 29
AQUA-STOP guarantee
(does not apply to appliances without Aqua-Stop)
In addition to warranty claims against the seller based on the
purchase contract and in addition to our appliance warranty
we will pay damages under the following conditions:
1. If our Aqua-Stop system is defective and causes water
damage, we will make good the damage for private users.
To ensure water damage protection, the appliance must be
connected to the power supply.
2. This liability guarantee is valid for the service life of the
appliance.
3. A prerequisite for the warranty claim is that the appliance
has been correctly installed and connected with Aqua-Stop
according to our instructions.
This also includes the correct installation of the Aqua-Stop
extension (original accessory).
Our warranty does not extend to defective feed lines or fittings
up to the Aqua-Stop connection on the tap.
4. If your appliance is fitted with Aqua-Stop, you can leave your
appliance unattended during operation and leave the tap
turned on afterwards. The tap should only be turned off if you
are absent from home for a prolonged period, e.g. several
weeks holiday.
Siemens-Electrogeräte GmbH
Carl-Wery-Straße 34, 81739 München
To contact us directly, use the tel. no or fax no. in the
enclosed customer service list.
www.siemens-homeappliances.com
Loading...
