Page 1
Flex induction cooktop with integrated
ventilation system
EX8..LX3.E
en Instruction manual
Page 2
,(&
:
:
:
:
:
2 Ø = cm
Page 3
Table of contents
enInst r ucti on manual
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
( Important safety information . . . . . . . . . . . . . . . 6
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Environmental protection . . . . . . . . . . . . . . . . . . 9
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 9
f Induction cooking . . . . . . . . . . . . . . . . . . . . . . . . 9
Advantages of induction cooking. . . . . . . . . . . . . . . . . 9
Cookware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
* Getting to know your appliance . . . . . . . . . . . . 11
Your new appliance . . . . . . . . . . . . . . . . . . . . . . . . . .11
Special accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 11
The control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Residual heat indicator. . . . . . . . . . . . . . . . . . . . . . . . 12
Cooking sensor function (optional) . . . . . . . . . . . . . . 13
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
en
x ShortBoost function . . . . . . . . . . . . . . . . . . . . . 23
Recommendations for use . . . . . . . . . . . . . . . . . . . . .23
Activating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Deactivating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
z Keep warm function. . . . . . . . . . . . . . . . . . . . . . 23
Activating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Deactivating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
s Transferring settings . . . . . . . . . . . . . . . . . . . . . 24
Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Ü Cooking assist functions . . . . . . . . . . . . . . . . . 25
Cooking assistant function types . . . . . . . . . . . . . . . .25
Suitable cookware . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Sensors and special accessories . . . . . . . . . . . . . . . .26
Functions and heat settings . . . . . . . . . . . . . . . . . . . .26
Recommended dishes . . . . . . . . . . . . . . . . . . . . . . . .29
Preparing and maintaining the wireless
temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . .33
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . .35
K Before using for the first time. . . . . . . . . . . . . . 13
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1 Operating the appliance . . . . . . . . . . . . . . . . . . 14
Switching the hob on and off . . . . . . . . . . . . . . . . . . . 14
Applying hotplate settings . . . . . . . . . . . . . . . . . . . . . 14
Switching the ventilation system on and off . . . . . . . .14
Intensive setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Automatic start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Automatic mode with sensor control . . . . . . . . . . . . . 15
Run-on function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chef's recommendations . . . . . . . . . . . . . . . . . . . . . .16
| Flex Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Advice on using cookware. . . . . . . . . . . . . . . . . . . . . 19
As a single hotplate . . . . . . . . . . . . . . . . . . . . . . . . . . 19
As two independent hotplates . . . . . . . . . . . . . . . . . . 19
u Move function. . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Deactivating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
O Time-setting options . . . . . . . . . . . . . . . . . . . . . 21
Programming the cooking time . . . . . . . . . . . . . . . . . 21
The kitchen timer . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Stopwatch function. . . . . . . . . . . . . . . . . . . . . . . . . . . 22
A Childproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 35
Activating and deactivating the childproof lock . . . . .35
Childproof lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
k Wipe protection . . . . . . . . . . . . . . . . . . . . . . . . . 35
b Automatic safety cut-out . . . . . . . . . . . . . . . . . . 35
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 36
To access the basic settings: . . . . . . . . . . . . . . . . . . .38
[ Energy consumption indicator . . . . . . . . . . . . . 38
t Cookware check. . . . . . . . . . . . . . . . . . . . . . . . . 39
h Power manager . . . . . . . . . . . . . . . . . . . . . . . . . 39
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cleaning agents . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Components to clean . . . . . . . . . . . . . . . . . . . . . . . . .41
Hob surround (only on appliances with
hob surrounds) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Ventilation system. . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Cleaning the overflow container . . . . . . . . . . . . . . . . .43
Wireless temperature sensor . . . . . . . . . . . . . . . . . . .44
v PowerBoost function . . . . . . . . . . . . . . . . . . . . . 22
Activating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Deactivating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3
Page 4
en
{ Frequently Asked Questions (FAQ) . . . . . . . . . 45
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 47
4 Customer service. . . . . . . . . . . . . . . . . . . . . . . . 49
E number and FD number . . . . . . . . . . . . . . . . . . . . .49
E Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.siemens-home.bsh-group.com and in the online
shop www.siemens-home.bsh-group.com/eshops
4
Page 5
Intended use en
8Intended use
Intended use
Read these instructions carefully. Please keep
the instruction and installation manual, as well
as the appliance certificate, in a safe place for
later use or for subsequent owners.
Check the appliance after removing it from the
packaging. If it has suffered any damage in
transport, do not connect the appliance,
contact the Technical Assistance Service and
provide written notification of the damage
caused, otherwise you will lose your right to
any type of compensation.
This appliance must be installed according to
the installation instructions included.
This appliance is intended for private domestic
use and the household environment only. The
appliance must only be used for the
preparation of food and beverages. The
cooking process must be supervised. A short
cooking process must be supervised without
interruption. Only use the appliance in
enclosed spaces.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
When using the cooking functions, set the
hotplate on which you have placed the
saucepan with the temperature sensor.
We advise that you exercise caution using or
standing near an induction hob while it is in
operation, if you wear a pacemaker or a
similar medical device. Consult your doctor or
the device manufacturer concerning its
conformity or any possible incompatibilities,
This appliance is intended for use up to a
maximum height of 2000 metres above sea
level.
Do not use covers. These can cause
accidents, for example due to overheating,
catching fire or materials shattering.
Only use safety devices or child protection
grilles approved by ourselves. Unsuitable
safety devices or child protection grilles may
result in accidents.
This appliance is not intended for operation
with an external clock timer or a remote
control.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
5
Page 6
en Important safety information
(Important safety
information
Impor t ant saf ety informat i on
The appliance can only be used safely if it is
correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly at
its installation location.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
Dangerous or explosive materials and vapours
must not be extracted.
Ensure that no small parts or liquids get into
the appliance.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
This appliance is not intended for operation
with an external clock timer or a remote
control.
In combination with an activated vapour
extractor hood, room air is extracted from the
kitchen and neighbouring rooms - a partial
vacuum is produced if not enough fresh air is
supplied. Toxic gases from the chimney or the
extraction shaft are sucked back into the living
space.
■ Adequate incoming air must therefore
always be ensured.
■ An incoming/exhaust air wall box alone will
not ensure compliance with the limit.
Safe operation is possible only when the
partial vacuum in the place where the heatproducing appliance is installed does not
exceed 4Pa (0.04mbar). This can be
achieved when the air needed for combustion
is able to enter through openings that cannot
be sealed, for example in doors, windows,
incoming/exhaust air wall boxes or by other
technical means.
:Warning – Danger of suffocation!
Packaging material is dangerous to children.
Never allow children to play with packaging
material.
:Warning – Danger of death!
Risk of poisoning from flue gases that are
drawn back in.
Always ensure adequate fresh air in the room
if the appliance is being operated in exhaust
air mode at the same time as room airdependent heat-producing appliance is being
operated.
Room air-dependent heat-producing
appliances (e.g. gas, oil, wood or coaloperated heaters, continuous flow heaters or
water heaters) obtain combustion air from the
room in which they are installed and discharge
the exhaust gases into the open air through an
exhaust gas system (e.g. a chimney).
In any case, consult your responsible Master
Chimney Sweep. He is able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures to
you.
Unrestricted operation is possible if the vapour
extractor hood is operated exclusively in the
circulating-air mode.
:Warning – Risk of fire!
■ Hot oil and fat can ignite very quickly. Never
leave hot fat or oil unattended. Never use
water to put out burning oil or fat. Switch off
the hotplate. Extinguish flames carefully
using a lid, fire blanket or something similar.
Risk of fire!
■ The hotplates become very hot. Never
place combustible items on the hob. Never
place objects on the hob.
Risk of fire!
■ The appliance gets hot. Do not keep
combustible objects or aerosol cans in
drawers directly underneath the hob.
Risk of fire!
■ The hob switches off automatically and can
no longer be operated. It may switch on
unintentionally at a later point. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
Risk of fire!
6
Page 7
Important safety information en
■ Grease deposits in the grease filter may
catch fire.
Clean the grease filter at least once a
month.
Never operate the appliance without the
grease filter.
Risk of fire!
■ Fatty deposits in the filters may catch fire.
Clean the appliance as described.
Comply with the cleaning intervals. Never
operate the appliance without the grease
filter.
Risk of fire!
■ When the ventilation system is switched on,
fatty deposits in the grease filter may catch
fire. Never work with naked flames close to
the appliance (e.g. flambéing). Do not install
the appliance near a solid fuel heating
appliance (e.g. wood- or coal-burning)
unless a sealed, non-removable cover is
fitted. There must be no flying sparks.
:Warning – Risk of burns!
■ The hotplates and surrounding area
(particularly the hob surround, if fitted)
become very hot. Never touch the hot
surfaces. Keep children at a safe distance.
Risk of burns!
■ The hotplate heats up but the display does
not work. Switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Risk of burns!
■ Metal objects on the hob quickly become
very hot. Never place metal objects (such
as knives, forks, spoons and lids) on the
hob.
Risk of burns!
■ The filter cover will get very hot very quickly
if left on the hob. Never place the filter
cover on the hob.Do not place pots, pans or
other hot objects on the filter cover.
Risk of fire!!
■ After each use, always turn off the hob at
the main switch. Do not wait until the hob
turns off automatically after the pan is
removed.
Risk of burns!
■ The accessible parts become very hot when
in operation. Never touch hot parts. Keep
children at a safe distance.
Risk of burns!
■ The appliance will become hot during
operation. If hot liquids penetrate the
appliance, leave the appliance to cool for at
least two hours before removing the filter
cover, the metal grease filter, the container,
the overflow reservoir or the appliance
housing.
:Warning – Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the aftersales service.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Risk of electric shock!
■ Cracks or fractures in the glass ceramic
may cause electric shocks. Switch off the
circuit breaker in the fuse box. Contact the
after-sales service.
:Warning – Electromagnetic hazards!
■ This appliance complies with safety and
electromagnetic compatibility standards.
However, people with pacemakers or
insulin pumps must refrain from using this
appliance. It is impossible to ensure that all
of these devices available on the market
comply with current electromagnetic
compatibility standards, and that
interference which may prevent the device
from working correctly will not occur. It is
also possible that people with other types of
devices, such as a hearing aids, could
experience some discomfort.
Hazard due to magnetism!
■ The wireless temperature sensor is
magnetic. The magnetic elements in it may
damage electronic implants, e.g.
pacemakers or insulin pumps. People fitted
with electronic implants should therefore
not carry the temperature sensor in their
pockets and always keep it at least 10 cm
away from their pacemaker or similar
medical device.
7
Page 8
en Causes of damage
:Warning – Risk of injury!
■ When cooking in a bain marie, the hob and
cooking container could shatter due to
overheating. The cooking container in the
bain marie must not directly touch the
bottom of the water-filled pot. Only use heatresistant cookware.
Risk of injury!
■ Saucepans may suddenly jump due to
liquid between the pan base and the
hotplate. Always keep the hotplate and
saucepan bases dry.
Risk of injury!
■ Cookware and cooktops become very hot.
Never reach across the hot cooktop or take
hold of hot cookware.
Risk of injury!
■ The wireless cooking sensor is equipped
with a battery, which may become
damaged if it is exposed to high
temperatures. Remove the sensor from the
cookware and store it away from any heat
sources.
Risk of injury!
■ The temperature sensor may be very hot
when removing it from the saucepan. Wear
oven gloves or use a tea towel to remove it.
Risk of injury!
■ Unsuitable woks may cause accidents. Only
use woks supplied by the manufacturer
(available as optional accessories).
:Warning – Risk of fault!
A fan is located on the underside of this hob. If
a drawer is located on the underside of the
hob, do not store any small or sharp objects,
paper or tea towels in it. These may be sucked
in and damage the fan or impair the cooling.
There must be a clearance of at least 2 cm
between the contents of the drawer and the
fan entry point.
]Causes of damage
Cau s e s of damage
Caution!
■ Objects that are hard or sharp may damage the hob.
Do not allow hard or sharp objects to fall on the hob.
■ Heating cookware when empty may cause surface
damage. Never leave empty cookware on the heat.
■ Hot pots or pans may damage the hob. Never place
hot pots or pans on the control panel, the displays/
indicators, the hob surround or the filter cover.
■ Never leave aluminium foil or plastic containers on
hot hotplates as this may damage the hob. No not
use oven liners.
■ Risk of damage: Risk of breaking the filter cover.
Take the filter cover off with care. Do not drop the
filter cover.
■ Using unsuitable cleaning products may cause
surface damage, discolouration and stains. Only use
cleaning products that are suitable for this type of
hob.
■ Friction from pots and pans may cause surface
damage and discolouration. Always lift pots and
pans up before repositioning them; do not slide
them across the surface of the hob.
■ Burnt-on food may cause surface damage and
staining. Immediately remove any food that has
boiled over using a glass scraper.
■ Salt, sugar and sand may cause surface damage.
Do not use the hob as a work surface or storage
space.
■ Using cookware with a rough base may cause
surface damage. Check all cookware before use.
■ Sugar and foods with a high sugar content may
cause surface damage or conchoidal fracturing.
Immediately remove any food that has boiled over
using a glass scraper.
8
Page 9
Environmental protection en
7Environmental protection
Env i r o nment al pr ot ect i on
In this section, you can find information about saving
energy and disposing of the appliance.
Saving energy
■ Always place suitable lids on saucepans. Cooking
without a lid consumes significantly more energy.
Use a glass lid so that you can see into the pan
without having to lift the lid.
■ Use pots and pans with flat bases. Uneven bases
increase the energy consumption.
■ The base diameter of pots and pans should be the
same size as the hotplate. Please note: Cookware
manufacturers often specify the diameter of the top
of the saucepan, which is usually larger than the
diameter of the base of the saucepan.
■ Use small saucepans for small quantities. Using a
large saucepan with little in it consumes a lot of
energy.
■ Cook with only a little water. This will save energy
and preserve the vitamins and minerals in
vegetables.
■ Switch back to a lower heat setting in good time.
This will save energy.
■ During cooking, ensure that there is a sufficient
supply of air to enable the ventilation system to work
efficiently and with a low level of operating noise.
■ Adjust the fan speed to the amount of steam
produced during cooking. Only use intensive mode
when required. The lower the fan speed, the less
energy is consumed.
■ If cooking produces large amounts of steam, select
a higher fan speed in good time. If the cooking
steam has already spread around the kitchen, the
ventilation system will need to be operated for
longer.
■ Switch the appliance off when you are not using it.
■ Clean and (if required) replace the filter at regular
intervals in order to increase the effectiveness of the
ventilation system and to prevent the risk of fire.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
fInduction cooking
Induction cooking
Advantages of induction cooking
Induction cooking is very different from traditional
cooking methods, as heat builds up directly in the item
of cookware. This offers numerous advantages:
■ Saves time when boiling and frying.
■ Saves energy.
■ Easier to care for and clean. Spilled food does not
burn on as quickly.
■ Heat control and safety – the hob increases or
decreases the heat supply as soon as the user
changes the setting. The induction hotplate stops the
heat supply as soon as the cookware is removed
from the hotplate, without having to switch it off first.
Cookware
Only use ferromagnetic cookware for induction cooking,
such as:
■ Cookware made from enamelled steel
■ Cookware made from cast iron
■ Special induction-compatible cookware made from
stainless steel.
To check whether your cookware is suitable for
induction cooking, refer to the section entitled
~ "Cookware check".
To achieve a good cooking result, the ferromagnetic
area on the base of the pan should match the size of
the hotplate. If a hotplate does not detect an item of
cookware, try placing it on another hotplate with a
smaller diameter.
FP
If the flexible cooking zone is being used as a single
hotplate, larger items of cookware can be used as
these are particularly suited to this area. You can find
information on positioning cookware in the section
entitled ~ "Flex Zone" on page 19.
FP
FP
9
Page 10
en Induction cooking
Some induction cookware does not have a fully
ferromagnetic base:
■ If the base of the cookware is only partially
ferromagnetic, only the area that is ferromagnetic will
heat up. This may mean that heat will not be
distributed evenly. The non-ferromagnetic area may
not heat up to a sufficient temperature for cooking.
■ The ferromagnetic area will also be reduced if the
material from which the base of the cookware is
made contains aluminium, for example. This may
mean that the cookware will not become sufficiently
hot or even that it will not be detected.
Empty pans or those with a thin base
Do not heat empty pans, nor use pans with a thin base.
The hob is equipped with an internal safety system.
However, an empty pan may heat up so quickly that the
"automatic switch off" function may not have time to
react and the pan may reach very high temperatures.
The base of the pan could melt and damage the glass
on the hob. In this case, do not touch the pan and
switch the hotplate off. If it fails to work after it has
cooled down, please contact the Technical Assistance
Service.
Pan detection
Each hotplate has a lower limit for pan detection. This
depends on the diameter of the ferromagnetic area of
the cookware and the material from which its base is
made. For this reason, you should always use the
hotplate that best matches the diameter of the base of
the pan.
Unsuitable pans
Never use diffuser hobs or pans made from:
■ common thin steel
■ glass
■ earthenware
■ copper
■ aluminium
Properties of the base of the cookware
The material(s) from which the base of the cookware is
made can affect the cooking result. Using pots and
pans made from materials that distribute heat evenly
through them, such as stainless-steel pans with a threelayer base, saves time and energy.
Use cookware with a flat base; if the base of the
cookware is uneven, this may impair the heat supply.
Absence of pan or unsuitable size
If no pan is placed on the selected hotplate, or if it is
made of unsuitable material or is not the correct size,
the power level displayed on the hotplate indicator will
flash. Place a suitable pan on the hotplate to stop the
flashing. If this takes more than 90seconds, the
hotplate will switch off automatically.
10
Page 11
Getting to know your appliance en
*Getting to know your
appliance
Gett i ng to know your appl i ance
You can find information on the dimensions and power
of the hotplates in~ Page 2
Your new appliance
Note: Depending on the appliance model, individual
details and colours may differ.
In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
No. Name
1 Filter cover
2 Metal grease filter
3 Container
4 Hob
5 Control panel
6 Fan housing
7 Overflow container
8 Housing cover
9 Piping*
10 Activated charcoal filter*
11 Exhaust pipe**
* in air recirculation mode only
** in air extraction mode only
Special accessories
Air extraction set HZ381400
Air recirculation set HZ381500
Activated charcoal filter HZ381700
Suitable cookware
There are pans that are optimally suited for the frying
sensor function. They can be purchased from specialist
retailers or through our technical after-sales service.
Always quote the relevant reference number.
15 cm frying pan HZ390210
19 cm frying pan HZ390220
21 cm frying pan HZ390230
Teppanyaki. Recommended for the
flexible cooking zone only.
Griddle plate. Recommended for the
flexible cooking zone only.
HZ390512
HZ390522
11
Page 12
en Getting to know your appliance
The control panel
Touch controls
#
Ñ
I
" / Ä
0IIIIIIIIIIII Apply heat settings/select fan settings 1-9on the left-
&
Õ
o
è
0
‰
ÿ
ý
Indicators/symbols
‹
‚-Š
•/œ
›
ݯ
–
Ý
õ
‹‹‹ºC
‚
‹‹
x
V
Switch the appliance on and off
Lock the control panel for cleaning and switch on the
childproof lock
Switch between the settings areas for the hob and the
ventilation system/reset the saturation indicators
Select a hotplate
hand settings area
Switch on the PowerBoost and ShortBoost functions
for heat settings/intensive mode for the ventilation
system
Switch on the frying sensor
Switch on automatic mode for the ventilation system
Switch on the keep-warm function
Programme the cooking time and kitchen timer
Switch on the stopwatch function
Activate the Move function
Switch on the flexible cooking zone
Operating status
Heat settings/fan settings
Residual heat
PowerBoost function/intensive mode for ventilation
ShortBoost function
Keep-warm function
Frying sensor
Cooking functions
Temperature for cooking functions
Childproof lock
Timer function
Set the cooking time
Timer
Indicators/symbols
£
ö / ô
o
”‚ ‹
”‚ ‚
Controls
When the hob heats up, the symbols for the controls
available at this time light up.
Touching a symbol activates the respective function.
Notes
■ The corresponding symbols for the controls light up
depending on whether they are available.
The displays for the hotplates or the selected
functions get brighter.
■ Always keep the control panel clean and dry.
Moisture can prevent it from working properly.
■ Do not place any cookware near the indicators or
sensors. The electronics could overheat.
Transferring settings
Timer displays
Ventilation system automatic mode
Metal grease filter saturation indicator
Activated charcoal filter saturation indicator
Residual heat indicator
The hob has a residual heat indicator for each hotplate.
This indicates that a hotplate is still hot. Do not touch a
hotplate while the residual heat indicator is lit up.
The following indicators are shown depending on the
amount of residual heat:
■ Display •: High temperature
■ Display œ: Low temperature
If you remove the cookware from the hotplate during
cooking, the residual heat indicator and the selected
heat setting will flash alternately.
When the hotplate is switched off, the residual heat
indicator will light up. Even after the hob has been
switched off, the residual heat indicator will stay lit for as
long as the hotplate is still warm.
12
Page 13
Before using for the first time en
Cooking sensor function (optional)
Depending on the appliance version, the temperature
sensor will either be supplied with the appliance as a
standard accessory or will be available to order as an
optional accessory using the article no. below.
Temperature sensor HZ39050
Operating modes
This appliance can be used in exhaust-air mode or
circulating-air mode.
Exhaust air mode
The air which is drawn in is cleaned
by the grease filters and conveyed to
the exterior by a pipe system.
KBefore using for the first
time
Bef or e usi ng for the first time
Please read the following information before using the
appliance for the first time:
Clean the appliance and all accessory parts thoroughly.
Before you can use your new appliance, you must apply
certain settings.
Initial use
Note: When it is delivered, the appliance is preset to air
recirculation mode.
Possible settings:
■ In air recirculation mode, if ’‚ˆ is displayed, the
value ‹ (factory setting) is set.
■ In air extraction mode, if ’‚ˆ is displayed, the value
‚ is set.
To switch the appliance to air extraction mode, see
~ "Basic settings" on page 36.
Note: The exhaust air must not be conveyed into a
functioning smoke or exhaust gas flue or into a shaft
which is used to ventilate installation rooms which
contain heat-producing appliances.
■ Before conveying the exhaust air into a non-
functioning smoke or exhaust gas flue, obtain the
consent of the heating engineer responsible.
■ If the exhaust air is conveyed through the outer wall,
a telescopic wall box should be used.
Circulating-air mode
The air which is drawn in is cleaned by the
grease filters and an activated carbon filter
and conveyed back into the kitchen.
Note: To bind odours in circulating-air mode, you must
install an activated carbon filter. The different options for
operating the appliance in circulating-air mode can be
found in the brochure. Alternatively, ask your dealer.
The required accessories are available from specialist
outlets, from customer service or from the Online Shop.
13
Page 14
en Operating the appliance
1Operating the appliance
Operat i ng the appl i ance
This chapter explains how to set a hotplate. The table
shows heat settings and cooking times for various
meals.
:Warning – Risk of burns!
The filter cover will get very hot very quickly if left on the
hob. Never place the filter cover on the hob.Do not
place pots, pans or other hot objects on the filter cover.
Note: Switch on the ventilation system when you start
cooking and switch it off again a few minutes after you
have finished cooking. This is the most effective way of
removing steam from the kitchen.
Note: Never use the appliance without the container,
metal grease filter or filter cover.
Switching the hob on and off
Switch the hob on and off using the main switch.
To switch on: Touch the
sounds. The symbols for the hotplates and the functions
available at this time light up. The hob is ready to use.
To switch off: Touch the # symbol until the indicators
go out. The residual heat indicator remains lit until the
hotplates have cooled down sufficiently.
Notes
■ The hob will automatically switch itself off if all
hotplates have been switched off for more than
30 seconds and the ventilation system is off.
■ The selected settings are stored for 4 seconds after
the hob has been switched off. If you switch it back
on during this time, the hob will operate using the
stored settings.
Applying hotplate settings
Set the required heat setting on the control panel.
Heat setting 1= lowest setting.
Heat setting 9= highest setting.
Every heat setting has an intermediate setting. This is
designated †.
Notes
■ To protect the fragile parts of your appliance from
overheating and electrical overloading, the hob may
temporarily reduce the power.
■ In order to prevent the appliance from producing
excess noise, the hob may temporarily reduce the
power.
Note: The left-hand hotplates are set in the settings
area on the left and the right-hand hotplates are set in
the settings area on the right.
# symbol. An audible signal
Selecting a hotplate and heat setting
The hob must be switched on.
1. Touch the " and Ä symbols for the required
hotplate.
The ‹ indicator gets brighter.
2. Swipe your finger over the relative settings area until
the required heat setting lights up.
The heat setting is set.
Changing the power level
Select the hotplate and set the desired power level in
the programming zone.
Switch off the hotplate
Select the hotplate and set it to ‹ in the programming
panel. The hotplate turns off and the residual heat
indicator appears.
Notes
■ If no pan has been placed on the hotplate, the
selected power level flashes. After a certain time has
elapsed, the hotplate switches off.
■ If a pan has been placed on the hotplate before
switching on the hob, it will be detected within
20 seconds of pressing the main switch and the
hotplate will be selected automatically. Once
detected, select the power level within the next
20 seconds or the hotplate will switch off.
■ The ventilation system must be switched off
separately. ~ "Switching off the ventilation system"
on page 15
Switching the ventilation system on and off
Note: Always adjust the setting according to the current
conditions. To eliminate strong cooking smells, select a
high fan setting.
Note: If no metal grease filter is available, the ventilation
system cannot be switched on. Insert the metal grease
filter. The hob functions are also available if there is no
metal grease filter.~ "Cleaning" on page 40
Note: Do not obstruct the ventilation openings. Do not
place objects on the filter cover, as this will reduce the
power of the ventilation system.
14
Note: Using tall items of cookware may prevent the
extraction system from working at optimum power. The
extraction power can be improved by placing a lid on
the cookware at an angle.
Page 15
Operating the appliance en
Note: When you switch on the ventilation system, the
right-hand settings area is no longer available. You can
change the fan setting for the ventilation system in the
left-hand settings area.
Switching on the ventilation system
Note: If the
I and o symbols are not available, insert
the metal grease filter correctly.
The I and o symbols are available. The ventilation
system can be switched on.
1. Touch the I symbol.
The ventilation system starts at fan setting ƒ. The
setting that is selected will be shown on the display
panel and in the left-hand settings area. The right-
hand settings area is not available.
Notes
– Heat settings cannot be changed while the
setting is being applied for the ventilation system.
– During a period of a few seconds, a fan setting
for the ventilation system can be selected. The
settings area can then be used for selecting the
heat settings again.
2. Select the required setting from the settings area.
The setting that is selected will be displayed in the
left-hand settings area.
The › symbol and the symbols in the left-hand settings
area will be lit. › is shown on the display panel.
Intensive mode is now activated.
Note: After eight minutes, the appliance automatically
switches back to fan setting Š.
Note: After a few seconds, the settings area for the heat
settings will be displayed again.
Switching off
1. Touch the I symbol.
2. In the next few seconds, slide your finger over the
settings area until setting ‹ or another setting is
displayed.
Automatic start
Depending on the basic settings selected, the following
options will be available once you have selected the fan
setting for a cooking zone:
3. To set a different setting, touch the I symbol and
select the required setting from the settings area.
The setting that is selected will be displayed in the
left-hand settings area.
Switching off the ventilation system
If you want to switch off the appliance, touch the
# symbol. If you only want to switch off the ventilation
system, proceed as follows:
1. Touch the I symbol.
2. Select the ‹ symbol in the settings area.
3. Touch the I symbol to switch to the setting area for
the hob.
Note: The run-on will start once the appliance has been
switched off (depending on the basic settings selected).
Intensive setting
Activate intensive mode if strong odours or large
amounts of steam are produced. In this mode, the
ventilation system briefly operates at maximum power. It
automatically switches back to a low setting after a
short time.
Switching on
■ The ventilation system will not start.
■ The ventilation system will start at the fan setting
selected by the sensor.
■ The ventilation will start at a specified fan setting.
Select the option you want to use in the basic settings.
The basic settings also offer the option to adjust the
sensitivity of the sensor. ~ "Basic settings"
on page 36
Automatic mode with sensor control
Switching on
Touch the o symbol.
The optimum setting is set automatically using a sensor.
‘ will be shown on the display panel.
Switching off
Touch the o symbol.
The fan setting that was last selected by the sensor will
be shown on the display panel. Automatic mode is
switched off.
1. Touch the I symbol.
2. Touch the › symbol.
15
Page 16
en Operating the appliance
Run-on function
The run-on function leaves the ventilation system
running for a few minutes after it has been switched off.
This eliminates any remaining cooking smells. The
ventilation system will switch off automatically
afterwards.
In the basic settings, you can select the following
options for the run-on:
■ Deactivate the run-on
■ Activate the automatic function with sensor-
controlled run-on
■ Activate the run-on for a fixed period at a fixed fan
setting
Note: The run-on function will only switch on if at least
one cooking zone has been switched on for at least
1minute.
If the automatic function with sensor-controlled run-on
has been activated, the I and ‘ symbols will be lit
during the run-on period.
Switching off
Touch the I symbol.
This will deactivate the run-on function immediately.
If one of the following conditions is present, the run-on
function is switched off:
■ The run-on time has expired.
■ The appliance is switched on again.
■ When the automatic function is activated with a
sensor-controlled run-on, the sensor determines a
corresponding room-air quality level.
Chef's recommendations
Recommendations
■ When heating up puree, cream soups and thick
sauces, stir occasionally.
■ Set heat setting 8to 9for preheating.
■ When cooking with the lid on, turn the heat setting
down as soon as steam escapes between the lid
and the cookware. Steam does not need to escape
for a good cooking result.
■ After cooking, keep the lid on the cookware until you
serve the food.
■ To cook with the pressure cooker, observe the
manufacturer's instructions.
■ Do not cook food for too long, otherwise the
nutrients will be lost. The kitchen clock can be used
to set the optimum cooking time.
■ For a more healthy cooking result, smoking oil
should be avoided.
■ To brown food, fry small portions in succession.
■ Cookware may reach high temperatures while the
food is cooking. We recommend that you use oven
gloves.
■ You can find recommendations for energy-efficient
cooking in section ~ "Environmental protection"
16
Page 17
Operating the appliance en
Cooking table
The table shows which heat setting is suitable for each
type of food. The cooking time may vary depending on
the type, weight, thickness and quality of the food.
Heat setting Cooking time
(mins)
Melting
Chocolate coating 1- 1.5 -
Butter, honey, gelatine 1- 2 -
Heating and keeping warm
Stew, e.g. lentil stew 1.5- 2 -
Milk* 1.5- 2.5 -
Heating sausages in water* 3- 4 -
Defrosting and heating
Spinach, frozen 3- 4 15- 25
Goulash, frozen 3- 4 35- 55
Poaching, simmering
Potato dumplings* 4.5- 5.5 20- 30
Fish* 4- 5 10- 15
White sauces, e.g. Béchamel sauce 1- 2 3- 6
Whisked sauces, e.g. sauce béarnaise, hollandaise 3- 4 8- 12
Boiling, steaming, braising
Rice (with double the volume of water) 2.5- 3.5 15- 30
Rice pudding*** 2- 3 30- 40
Unpeeled boiled potatoes 4.5- 5.5 25- 35
Boiled potatoes 4.5- 5.5 15- 30
Pasta, noodles* 6- 7 6- 10
Stew 3.5- 4.5 120- 180
Soups 3.5- 4.5 15- 60
Vegetables 2.5- 3.5 10- 20
Vegetables, frozen 3.5- 4.5 7- 20
Cooking in a pressure cooker 4.5- 5.5 -
Braising
Roulades 4- 5 50- 65
Pot roast 4- 5 60- 100
Goulash*** 3- 4 50- 60
* Without lid
** Turn several times
*** Preheat to heat setting 8- 8.5
17
Page 18
en Operating the appliance
Heat setting Cooking time
(mins)
Roasting/frying with little oil*
Escalope, plain or breaded 6- 7 6- 10
Escalope, frozen 6- 7 6- 12
Chop, plain or breaded** 6- 7 8- 12
Steak (3cm thick) 7- 8 8- 12
Poultry breast (2cm thick)** 5- 6 10- 20
Poultry breast, frozen** 5- 6 10- 30
Rissoles (3cm thick)** 4.5- 5.5 20- 30
Hamburgers (2cm thick)** 6- 7 10- 20
Fish and fish fillet, plain 5- 6 8- 20
Fish and fish fillet, breaded 6- 7 8- 20
Fish, breaded and frozen, e.g. fish fingers 6- 7 8- 15
Scampi, prawns 7- 8 4- 10
Sautéeing fresh vegetables and mushrooms 7- 8 10- 20
Stir-fry, vegetables, meat cut in Asian-style strips 7- 8 15- 20
Stir fry, frozen 6- 7 6- 10
Pancakes (baked in succession) 6.5- 7.5 -
Omelette (cooked in succession) 3.5- 4.5 3- 10
Fried eggs 5- 6 3- 6
Deep-fat frying* (150-200 g per portion in 1-2 l oil, deep-fat fried in portions)
Frozen products, e.g. chips, chicken nuggets 8- 9 -
Croquettes, frozen 7- 8 -
Meat, e.g. chicken portions 6- 7 -
Fish, breaded or in beer batter 6- 7 -
Vegetables, mushrooms, breaded or battered, tempura 6- 7 -
Small baked items, e.g. doughnuts, fruit in batter 4- 5 -
* Without lid
** Turn several times
*** Preheat to heat setting 8- 8.5
18
Page 19
Flex Zone en
|Flex Zone
Fl ex Zone
You can use each flex zone as a single hotplate or as
two independent hotplates, as required.
It consists of four inductors that work independently of
each other. If using the flexible cooking zone, only the
area that is covered by cookware is activated.
Advice on using cookware
To ensure that the cookware is detected and heat is
distributed evenly, correctly centre the cookware:
As a single hotplate
Diameter smaller than or equal to 13cm
Place the cookware on one of the four positions that can be seen in the illustration.
Diameter greater than 13cm
Place the cookware on one of the three
positions that can be seen in the illustration.
Adding a new item of cookware
Set the new piece of cookware down on the hotplate
and then touch the ý symbol twice. The new piece of
cookware will be detected and the heat setting that was
previously selected will be retained.
Note: If the cookware is moved to the hotplate being
used or lifted up, the hotplate begins an automatic
search and the heat setting selected previously is
retained.
Deactivating
Touch the ý symbol.
This deactivates the flexible cooking zone. The two
hotplates will now function independently.
As two independent hotplates
Use the flexible cooking zone as two independent
hotplates.
Disconnecting hotplates
1. Touch the ý symbol.
2. Select the required hotplate by touching the "
symbol.
3. Select the required heat setting from the settings
area.
The hotplate is activated.
If the cookware takes up more than one
hotplate, place it starting on the upper or
lower edge of the flexible cooking zone.
As two independent hotplates
The front and rear hotplates each have two inductors and can be used independently of each other.
Select the required heat setting for each of the
hotplates. Use only one item of cookware on each
hotplate.
As a single hotplate
The flexible cooking zone is activated as a single
hotplate.
Activating
1. Select the flexible cooking zone by touching the Ä
symbol.
2. Select the required heat setting from the settings
area.
The flexible cooking zone has now been activated.
Notes
■ If the hob switches itself off and then on again, the
flexible cooking zone is used as a single hotplate
again.
■ To change the configuration settings for the flexible
cooking zone, refer to section ~ "Basic settings".
Linking the two hotplates
Touch the ý symbol.
The flexible cooking zone has now been activated.
Changing the heat setting
Select the hotplate and change the heat setting in the
relative settings area.
19
Page 20
en Move function
uMove function
Move f unct i on
This function activates the entire flexible cooking zone,
which is divided into three cooking areas and which has
preset heat settings.
Only use one item of cookware. The size of the cooking
area depends on the cookware used and whether it is
positioned correctly.
Cooking areas
This means that an item of cookware can be moved
during the cooking process to another cooking area
with another heat setting:
Activation
1. Select one of the two hotplates in the flexible
cooking zone.
2. Touch the ÿ symbol; it lights up more brightly. The
flexible cooking zone is activated as a single
hotplate.
The heat setting in the area in which the cookware is
located lights up in the hotplate display.
The function has now been activated.
Changing the heat setting
The heat settings for the individual cooking areas can
be changed during the cooking process. Set the
cookware down on the cooking area and change the
heat setting in the settings range.
Notes
■ Only the heat setting in the area in which the
cookware is located is changed.
■ If the function is deactivated, the heat settings for the
three cooking areas are reset to the preset values.
Deactivating
Touch the ÿ symbol. It lights up dimly.
The function was deactivated.
Note: If one of the cooking areas is set to ‹, the
function deactivates after a few seconds.
Preset heat settings:
Front area = heat setting Š
Middle area = heat setting †
Rear area = heat setting ‚.†
The preset heat settings can be changed independently
of one another. You can find out how to change these in
the section on ~ "Basic settings".
Notes
■ If more than one item of cookware is detected on the
flexible cooking zone, the function is deactivated.
■ If the cookware is moved within the flexible cooking
zone or lifted up, the hob automatically starts
searching and the heat setting of the area in which
the vessel was detected is set.
■ You can find information on the size and positioning
of the cookware in the section on ~ "Flex Zone"
20
Page 21
Time-setting options en
OTime-setting options
Ti me-set ti ng opt i ons
Your hob has three timer functions:
■ Programming the cooking time
■ Kitchen timer
■ Stopwatch function
Programming the cooking time
The hotplate automatically switches off after the time
that is set has elapsed.
Setting procedure:
1. Touch the 0 symbol twice. ‹‹ and the x indicator
light up in the timer display.
2. Select the hotplate. The x indicator lights up.
3. Within the next 10seconds, set the required cooking
time in the settings range.
Frying sensor
If a cooking time has been programmed for a hotplate
and the frying sensor has been activated, the cooking
time will not begin to count down until the selected
temperature setting has been reached.
Cooking functions
If a cooking time has been programmed for a hotplate
and one of the cooking functions has been activated,
the set cooking time will not start to count down until
the temperature for the selected area has been
reached.
Changing or deleting the time
Touch the 0 symbol twice and then select the hotplate.
Change the cooking time in the settings area or set ‹‹
to delete the programmed cooking time.
Touch the 0 symbol to confirm the selected setting.
When the time has elapsed
The hotplate switches itself off, the x indicator flashes
and the hotplate displays ‹. An audible signal sounds.
‹‹ and the x indicator flash in the timer display.
When the 0 symbol is touched, the indicators go out
and the acoustic signal ceases.
4. Touch the 0 symbol to confirm the selected setting.
5. Select the required heat setting.
The cooking time begins to elapse.
Notes
■ The same cooking time can be set automatically for
all hotplates. The set time for each of the hotplates
counts down independently.
You can find information on automatically
programming the cooking time in section ~ "Basic
settings"
■ If the flexible cooking zone is selected as the only
hotplate, the set time for the entire cooking zone is
the same.
■ If the Move function is selected for the combined
hotplate, the set time for the three hotplates is the
same.
Notes
■ If a cooking time has been programmed for several
hotplates, the shortest cooking time appears in the
timer display.
■ To query a hotplate's remaining cooking time, touch
the 0 symbol twice and select the hotplate.
■ You can set a cooking time of up to ŠŠ minutes.
The kitchen timer
You can use the kitchen timer to set a time of up to
99minutes.
This functions independently from the hotplates and
from other settings. This function does not automatically
switch off a hotplate.
Setting procedure
1. Touch the 0 symbol. ‹‹ and the V indicator light
up in the timer display.
2. Select the required time in the settings area and
confirm this setting by touching the 0 symbol.
After a few seconds, the time begins to elapse.
Changing or deleting the time
Touch the 0 symbol.
Change the cooking time in the settings area or set ‹‹
to delete the programmed cooking time.
Touch the 0 symbol to confirm the selected setting.
When the time has elapsed
An audible signal sounds once the time has elapsed.
‹‹ and the V symbol flash in the timer display.
The indicators go out after touching the 0 symbol.
21
Page 22
en PowerBoost function
Stopwatch function
The stopwatch function displays the time that has
elapsed since activation.
This functions independently from the hotplates and
from other settings. This function does not automatically
switch off a hotplate.
Activating
Touch the þ symbol. ‹‹ light up in the timer display.
The cooking time begins to elapse.
Deactivating
Touch the þ symbol. ‹‹ appear in the timer display
and then go out.
The function is deactivated.
Note: This function must be selected in order to
deactivate the stopwatch.
vPowerBoost function
Power Boos t function
The PowerBoost function enables you to heat up large
quantities of water faster than when using
heat setting Š.
This function can always be activated for a hotplate,
provided the other hotplate in the same group is not in
use (see illustration).
Note: The PowerBoost function can also be activated in
the flexible area if the cooking zone is being used as a
single hotplate.
Activating
1. Select a hotplate.
2. Touch the & symbol.
The › indicator lights up.
The function has now been activated.
Deactivating
1. Select a hotplate.
2. Touch the & symbol.
The › indicator goes out and the hotplate switches
back to the Š heat setting.
The function is deactivated.
Note: In certain circumstances, the PowerBoost
function can switch itself off automatically in order to
protect the electronic elements inside the hob.
22
Page 23
ShortBoost function en
xShortBoost function
Sho r t Bo o s t f unc t i on
The ShortBoost function enables you to heat cookware
faster than when using heat setting Š.
After deactivating the function, select the appropriate
heat setting for your food.
This function can always be activated for a hotplate,
provided the other hotplate in the same group is not in
use (see illustration).
Note: With the flexible cooking zone, the ShortBoost
function can be activated even if it is used as the only
cooking zone.
Recommendations for use
zKeep warm function
Kee p war m function
This function is suitable for melting chocolate or butter
and for keeping food warm.
Activating
1. Touch the è symbol.
2. Select the required hotplate within the next
10seconds.
The – indicator lights up.
The function has now been activated.
Deactivating
1. Touch the è symbol.
2. Select a hotplate.
The – indicator goes out. The hotplate switches itself
off and the residual heat indicator lights up.
The function is deactivated.
■ Always use cookware that has not been pre-heated.
■ Use pots and pans with a flat base. Do not use
cookware with a thin base.
■ Never leave empty cookware, oil, butter or lard to
heat up unattended.
■ Do not place a lid on the cookware.
■ Place the cookware on the centre of the hotplate.
Ensure that the diameter of the base of the
cookware corresponds to the size of the hotplate.
■ You can find information on the type, size and
positioning of the cookware in section ~ "Induction
cooking"
Activating
1. Select a hotplate.
2. Touch the & symbol twice.
The ݯ indicator lights up.
The function has now been activated.
Deactivating
1. Select a hotplate.
2. Touch the & symbol.
The ݯ indicator goes out and the hotplate switches
back to the Š heat setting.
The function is deactivated.
Note: After 30 seconds, this function will automatically
switch off.
23
Page 24
en Transferring settings
sTransferring settings
Trans f er r i ng set t i ngs
This function can be used to transfer the heat setting,
the programmed cooking time and the selected
cooking function from one hotplate to another.
To transfer the settings, move the cookware from the
hotplate which is switched on to another hotplate.
Note: You can find additional information on the
positioning of the cookware in the section on ~ "Flex
Zone"
Activation
1. Move the cookware from the hotplate which is
switched on to another hotplate.
The heat setting of the original hotplate flashes.
The cookware is detected and the previously
selected heat setting and the £ symbol flash in the
new hotplate display.
2. Select the new hotplate to confirm the settings.
The heat setting of the original hotplate is set to ‹.
The settings have been transferred to the new hotplate.
Notes
■ Move the cookware to a hotplate which is not
switched on, which you have not yet preset or on
which no other cookware has been placed.
■ The PowerBoost or ShortBoost function can then
only be moved from left to right or right to left if no
hotplate is active.
■ If a new item of cookware is set down on another
hotplate before the settings have been confirmed,
this function is ready for both cooking vessels.
■ If several vessels are moved, the function is only
ready for the vessel which was last moved.
24
Page 25
Cooking assist functions en
ÜCooking assist functions
Cooki ng assi st functions
The cooking assistance functions make cooking easy
and always give you excellent results. The
recommended temperature settings are suitable for any
type of cooking.
They enable you to cook without using excessive heat
and promise the perfect cooking and frying results.
wireless temperature sensor is connected.
In this section, you will find information on:
■ Cooking assistant function types
■ Suitable cookware
■ Sensors and special accessories
■ Functions and heat settings
■ Recommended dishes
Sensors measure the heat of the saucepan or frying
pan throughout the cooking process. This ensures that
The cooking functions are available to all hotplates if a
the power is continuously controlled and that the right
temperature is maintained.
Food can be added once the selected temperature has
been reached. Food will not be overheated and liquids
will not boil over.
The hotplates that have a frying sensor are marked with
Cooking assistant function types
The cooking assistance functions are used to select the
best cooking type for each kind of food.
The table shows the various different function settings
that are available for the cooking assistants:
the frying sensor symbol.
Cooking assistance functions Temperature
settings
Frying sensor
Roasting/frying with a small amount of oil 1, 2, 3, 4, 5
Cooking functions
Cookware Available for Activate
Ý Õ
Heating/keeping warm 1/70 ºC All hotplates
Poaching 2/90 ºC All hotplates
Cooking 3/100 ºC All hotplates
All hotplates
»
»
»
»
Cooking in a pressure cooker 4/120 ºC
Frying with a large amount of oil in the saucepan* 5/170 ºC All hotplates
»
*Preheat with the lid on and fry with the lid off.
If the hob does not have a wireless temperature sensor, this can be purchased from specialist retailers or through our technical after-sales service.
Suitable cookware
Select the cooking zone with the diameter that most
closely matches that of the base of the cookware and
place the cookware in the centre of this cooking zone.
For the cooking functions, use cookware that is high
enough that the required water volume lies above the
silicone patch for the wireless sensor.
There are frying pans that are perfect for using with the
frying sensor. These can be purchased from specialist
retailers, our technical after-sales service or our official
website. Quote the relevant reference number:
■ HZ39021015 cm frying pan.
■ HZ39022019 cm frying pan.
■ HZ39023021 cm frying pan.
■ HZ390512teppan yaki. Recommended for the
flexible cooking zone only.
■ HZ390522griddle plate. Recommended for the
flexible cooking zone only.
These frying pans have a non-stick coating so that you
can fry food with a small amount of oil.
Notes
■ The frying sensor has been configured specifically
for this type and size of frying pan.
■ Using a frying pan of a different size or one that is
poorly positioned on the flexible cooking zones may
result in the frying sensor not being activated. See
section ~ "Flex Zone".
■ Other types of frying pan may overheat and reach a
temperature above or below the selected heat
setting. Try the lowest temperature setting to begin
with and change it if required.
Any cookware that is suitable for induction cooking can
be used with the cooking functions. You can find
information on which types of cookware can be used
with an induction hob in section ~ "Induction
cooking".
The cooking assistance functions table lists which
cookware is suitable for which functions.
25
Page 26
en Cooking assist functions
Sensors and special accessories
The sensors measure the temperature of the pot
throughout the entire cooking process. This ensures
that the cooking power is controlled with high precision
to maintain the correct temperature and achieve
optimum cooking results.
Your hob has two different temperature-measuring
systems for achieving the best results:
■ Temperature sensors that are located inside the hob
and monitor the temperature of the base of the
cookware. Suitable for the frying sensor.
■ A wireless cooking sensor that transmits information
about the temperature of the cookware to the control
panel. Suitable for the cooking functions.
The cooking sensor is essential for using the cooking
functions.
If your hob does not have a wireless cooking sensor,
this can be purchased from specialist retailers, our
technical after-sales service or our official website by
quoting the reference number HZ39050.
You can find information about the cooking sensor in
section ~ "Preparing and maintaining the wireless
temperature sensor"
Functions and heat settings
Frying sensor
You can use the frying sensor when pan-frying food with
a small amount of oil.
Hotplates with this function are marked with the frying
sensor symbol.
Benefits
■ The hotplate only heats up when necessary. This
saves energy. Oil and fat will not overheat.
■ A signal will sound once the empty frying pan has
reached the optimum temperature for adding oil and
food.
Notes
■ Do not put the lid on the pan as this will prevent the
controller from working. You can use a splatter
guard to prevent the oil from spitting.
■ Use oil or fat that is suitable for frying. If using butter,
margarine, cold-pressed olive oil or lard, use
temperature setting 1or 2.
■ Never leave fat or oil unattended while you are
heating it.
■ If the hotplate is a higher temperature than the
cookware or vice versa, the temperature sensor will
not be activated correctly.
■ Always use the cooking functions when frying with a
large amount of oil in the saucepan. "Frying with a
large amount of oil in the saucepan", heat setting 5.
Temperature settings
Temperature level Suitable for
1 very low Preparing and reducing sauces, stewing vegetables and frying food in extra virgin olive oil, butter or margarine.
2 low Frying food in extra virgin olive oil, butter or margarine, e.g. omelettes.
3 medium - low Frying fish and thick food such as meatballs and sausages.
4 medium - high Frying steaks (well done), breaded frozen products, and thin food such as schnitzel, strips of meat and vegetables.
5 high Frying food at high temperatures, e.g. rare steaks (rare or medium), potato fritters and fried potatoes.
Setting procedure
Select the appropriate temperature level from the table.
3. Within the next 10seconds, select the required
temperature setting from the settings range.
Set an empty item of cookware down on the cooking
zone.
1. Touch the Õ symbol.
2. Select the hotplate. The Ý indicator lights up in
the hotplate display.
The function has now been activated.
The Ý temperature symbol flashes until the frying
temperature is reached. A signal sounds and the
temperature symbol stops flashing.
4. Once the frying temperature has been reached, add
the fat and then the food to the pan.
26
Note: Turn the food so that it does not burn.
Page 27
Cooking assist functions en
Switching off the frying sensor
Touch the
Õ symbol and select the hotplate. The
hotplate will switch off and the residual heat indicator
will light up.
Cooking functions
You can use these functions to heat, simmer or cook
food, or cook it in a pressure cooker or fry it in a
saucepan with sufficient oil at a controlled temperature.
These cooking functions are available for all hotplates.
Benefits
■ The cooking zone only continues heating for as long
as this is necessary to maintain the temperature.
This saves energy and prevents oil or fat from
overheating.
■ The temperature is continuously monitored. This
prevents the food from spilling over. In addition, the
temperature setting does not need to be changed.
■ A signal sounds once the water or oil has reached
the optimum temperature for adding the food. The
table shows if the food needs to be added right at
the start.
Temperature ranges and settings
Notes
■ Use pots and pans with a thick, flat base. Do not use
pots and pans with a thin or domed base.
■ Fill the pot so that the contents reach high enough to
cover the cooking sensor's silicone patch.
■ Use the frying sensor when frying with a small
amount of oil.
■ Position the cookware in such a way that the
cooking sensor is pointing towards the outer side of
the hob.
■ Do not remove the cooking sensor from the pot
during cooking.
■ Remove the cooking sensor from the pot after
cooking. Be careful as the cooking sensor may be
very hot.
Cooking functions Temperature setting Temperature range Suitable for
Heating, keeping warm 1/70 ºC 60- 70 ºC E.g. soups, punch
Poaching 2/90 ºC 80- 90 ºC E.g. rice, milk
Cooking 3/100 ºC 90- 100 ºC E.g. pasta, vegetables
Cooking in a pressure cooker 4/120 ºC 110- 120 ºC E.g. chicken, stew.
Frying with a large amount of oil in the saucepan 5/170 ºC 170- 180 ºC E.g. doughnuts, meatballs
Tips for cooking with the cooking functions
■ Never leave oil unattended during heating. Use oil or
fat that is suitable for frying. Do not mix different
■ Heating/keep-warm function: Frozen products in
portions, e.g. spinach. Place the frozen product in
the cookware. Pour in the volume of water specified
by the manufacturer. Cover the cookware and select
the setting 1/70 °C. Stir occasionally.
■ Poaching function: This function is suitable for
cooking food at low temperatures and for thickening
sauces and stews. Select setting 2/90 °C.
■ Boiling function: This function allows you to boil
water with a lid without it boiling over. You can boil
efficiently thanks to the temperature control. Select
setting 3/100 °C.
■ Cooking in a pressure cooker function: Follow the
manufacturer's recommendations. Continue cooking
for the recommended time once the signal has
sounded. Select setting 4/120 °C.
■ Frying with a large amount of oil in the saucepan
function: To heat the oil with the lid on. Remove the
lid after the signal tone and add the food (insofar as
cooking fats together, e.g. oil and lard. Mixtures of
different fats may froth up when hot.
■ If you are not satisfied with the cooking result, e.g.
when cooking potatoes, next time use less water but
keep the recommended temperature setting.
Setting the boiling point
The point at which water starts to boil depends on the
height of your home above sea level. You can set the
boiling point if water is boiling too strongly or not
strongly enough. To do this, proceed as follows:
■ Select the basic setting ™…; see the section on
~ "Basic settings"
■ The basic setting is 3as standard. If your home is
between 200and 400metres above sea level, there
is no need to set the boiling point. If not, choose the
correct setting from the following table according to
your altitude:
there are no other instructions in the "Recommended
dishes" table). Select setting 5/170 °C.
Notes
■ Always cook with the lid on. Exception: "Frying with a
large amount of oil in the saucepan", temperature
setting 5/170 °C.
■ If an audible signal does not sound, make sure that
the lid is on the pan.
Height
0- 100m.
100- 200m.
200- 400m.
400- 600m.
Setting ™…
‚
ƒ
„*
…
* Basic setting
27
Page 28
en Cooking assist functions
R
Height
600- 800m.
800- 1000m.
1000- 1200m.
1200- 1400m.
Above 1400m.
Setting ™…
†
‡
ˆ
‰
Š
* Basic setting
Note: Temperature setting 3/100ºC is sufficient for
efficient boiling, even if the water does not boil very
strongly. However, the boiling point can be changed.
For example, you can set a lower altitude if you want the
water to boil more strongly.
Connecting the wireless temperature sensor to the
control panel
To connect the wireless temperature sensor to the
control panel, follow the instructions below:
1. Select the basic setting ™‚…; see the section on
~ "Basic settings"
The indicator for one of the hotplates and the b
indicator will light up. The control panels switch off.
2. Select the hotplate and its indicator will light up. A
signal will sound. The õ indicator will flash.
3. Press the » symbol on the wireless temperature
sensor within 30 seconds.
After a few seconds, the status of the connection
between the temperature sensor and the control
panel will appear on the hotplate's display.
Status
Connected correctly
‹
Not connected correctly: Transmission error.
‚
Not connected correctly: Temperature sensor fault.
ƒ
Resetting the wireless temperature sensor
1. Touch and hold the » symbol for approximately
8-10 seconds.
While you are doing this, the temperature sensor's
LED indicator will light up three times. When the LED
lights up for the third time, it will start to reset the
temperature sensor. At this point, you will need to lift
your finger off the symbol.
Once the LED goes out, this means that the wireless
temperature sensor has been reset.
2. Repeat the connection procedure from point 2.
Setting procedure
1. Attach the temperature sensor to the saucepan; see
the section on ~ "Preparing and maintaining the
wireless temperature sensor"
2. Place a saucepan filled with sufficient liquid on the
required hotplate and always put the lid on.
3. Press the » symbol on the wireless temperature
sensor. The õ symbol for all hotplates will light up
on the control panel.
4. Select the hotplate on which you have placed the
saucepan with the temperature sensor.
5. Select the right temperature setting from the table.
4. Turn off the hob with the main switch to save the
settings.
■ The cooking functions are made available once the
temperature sensor has been connected to the
control panel correctly.
■ If there is a fault with the temperature sensor, the
connection may not be established correctly for the
following reasons:
– Bluetooth communication error.
– You did not press the symbol on the temperature
sensor within 30 seconds of selecting a hotplate.
– The battery in the temperature sensor has run
out.
Reset the wireless temperature sensor and follow
the connection procedure once again.
■ If the temperature sensor and the control panel are
not connected correctly due to a transmission error,
follow the connection procedure once again.
If the display continues to show incorrect connection
‚, contact our technical after-sales service.
R
The function has now been activated.
The temperature symbol õ will flash until the water
or oil has reached the right temperature for adding
the food. A signal will sound and the temperature
symbol will stop flashing.
6. Once the signal has sounded, take the lid off and
add the food. Keep the lid on during cooking.
Note: Do not cover the pan when using the "Frying
with a large amount of oil in the saucepan" function.
Switching off cooking functions
Select the hotplate and set it to ‹ in the control panel.
The hotplate will switch off and the residual heat
indicator will appear.
Note: To re-activate the cooking functions, wait for
approximately 10seconds.
28
Page 29
Cooking assist functions en
Recommended dishes
The following table shows a selection of dishes and is
arranged by food type. The temperature and the
cooking time depend on the amount, the condition and
the quality of the food.
Meat Cooking assistance
functions
Function for frying with a small amount of oil
Escalope, plain or breaded Frying sensor 4 6- 10
Fillet Frying sensor 4 6- 10
Chops* Frying sensor 3 10- 15
Cordon bleu, escalope* Frying sensor 4 10- 15
Steak, rare (3 cm thick) Frying sensor 5 6- 8
Steak, medium or well done (3 cm thick) Frying sensor 4 8- 12
Poultry breast (2 cm thick)* Frying sensor 3 10- 20
Sausages, pre-boiled or raw* Frying sensor 3 8- 20
Hamburgers, meatballs, stuffed meatballs* Frying sensor 3 6- 30
Meat loaf Frying sensor 2 6- 9
Strips of meat, gyros Frying sensor 4 7- 12
Minced meat Frying sensor 4 6- 10
Bacon Frying sensor 2 5- 8
Temperature
setting
Total cooking time
from signal tone
(mins)
Poaching function
Sausages Cooking functions 2/ 90ºC 10- 20
Cooking function
Meatballs Cooking functions 3/ 100ºC 20- 30
Chicken Cooking functions 3/ 100ºC 60- 90
Veal, boiled or stewed Cooking functions 3/ 100ºC 60- 90
Function for cooking in a pressure cooker
Chicken, veal*** Cooking functions 4/ 120ºC 15- 25
Function for frying with a large amount of oil
Chicken portions and meatballs** Cooking functions 5/ 170ºC 10- 15
* Turn several times.
** Heat the oil with the lid on. Fry in portions with the lid off (see table for cooking time per portion).
*** Add the food right at the beginning.
Fish Cooking assistance
functions
Function for frying with a small amount of oil
Frying a whole fish, e.g. trout Frying sensor 3 10- 20
Fish fillet, plain or breaded Frying sensor 3- 4 10- 20
Prawns, scampi Frying sensor 4 4- 8
Temperature
setting
Total cooking time
from signal tone
(mins)
Poaching function
Stewing fish, e.g. hake Cooking functions 2/ 90ºC 15- 20
* Heat the oil with the lid on. Fry in portions with the lid off (the table lists the cooking time per portion).
29
Page 30
en Cooking assist functions
Fish Cooking assistance
functions
Function for frying with a large amount of oil
Fish, beer-battered or breaded* Cooking functions 5/ 170ºC 10- 15
* Heat the oil with the lid on. Fry in portions with the lid off (the table lists the cooking time per portion).
Egg-based dishes Cooking assistance
functions
Function for frying with a small amount of oil
Pancakes* Frying sensor 5 -
Omelette* Frying sensor 2 3- 6
Fried egg Frying sensor 2- 4 2- 6
Scrambled egg Frying sensor 2 4- 9
Shredded raisin pancake Frying sensor 3 10- 15
French toast Frying sensor 3 4- 8
Cooking function
Boiling eggs** Cooking functions 3/ 100ºC 5- 10
* Total cooking time per portion. Fry one after another.
** Add the food right at the beginning.
Temperature
setting
Temperature
setting
Total cooking time
from signal tone
(mins)
Total cooking time
from signal tone
(mins)
Vegetables and pulses Cooking assistance
functions
Function for frying with a small amount of oil
Garlic, onions Frying sensor 1- 2 2- 10
Courgettes, aubergines Frying sensor 3 4- 12
Peppers, green asparagus Frying sensor 3 4- 15
Vegetables sautéed in oil, e.g. courgettes, green peppers Frying sensor 1 10- 20
Mushrooms Frying sensor 4 10- 15
Glazing vegetables Frying sensor 3 6- 10
Cooking function
Fresh vegetables, e.g. broccoli Cooking functions 3/ 100ºC 10- 20
Fresh vegetables, e.g. Brussels sprouts Cooking functions 3/ 100ºC 30- 40
Chickpeas* Cooking functions 3/ 100ºC 60- 90
Peas Cooking functions 3/ 100ºC 15- 20
Lentil stew* Cooking functions 3/ 100 ºC 45- 60
Function for cooking in a pressure cooker*
Vegetables, e.g. green beans Cooking functions 4/ 120ºC 3- 6
Chickpeas, beans Cooking functions 4/ 120ºC 25- 35
Lentil stew Cooking functions 4/ 120ºC 10- 20
Temperature setting
Total cooking time
from signal tone
(mins)
Function for frying with a large amount of oil
Vegetables and mushrooms, breaded or beer-battered* Cooking functions 5/ 170ºC 4- 8
* Add the food right at the beginning.
** Heat the oil with the lid on. Fry in portions with the lid off (see table for cooking time per portion).
30
Page 31
Cooking assist functions en
Potatoes Cooking assistance
functions
Function for frying with a small amount of oil
Fried potatoes (made from unpeeled boiled potatoes) Frying sensor 5 6- 12
Fried potatoes (made from raw potatoes) Frying sensor 4 15- 25
Potato fritter* Frying sensor 5 2,5- 3,5
Swiss rösti Frying sensor 1 50- 55
Glazed potatoes Frying sensor 3 15- 20
Poaching function
Potato dumplings Cooking functions 2/ 90ºC 30- 40
Cooking function
Potatoes** Cooking functions 3/ 100ºC 30- 45
Function for cooking in a pressure cooker
Potatoes** Cooking functions 4/ 120ºC 10- 12
* Total cooking time per portion. Fry one after another.
** Add the food right at the beginning.
Pasta and cereals Cooking assistance
functions
Temperature
setting
Temperature
setting
Total cooking time
from signal tone
(mins)
Total cooking time
from signal tone
(mins)
Poaching function
Rice Cooking functions 2/ 90ºC 25- 35
Polenta* Cooking functions 2/ 90ºC 3- 8
Semolina pudding Cooking functions 2/ 90ºC 5- 10
Cooking function
Pasta Cooking functions 3/ 100ºC 7- 10
Pastry parcels and filled dumplings Cooking functions 3/ 100ºC 6- 15
Function for cooking in a pressure cooker
Rice** Cooking functions 4/ 120ºC 5- 8
* Heat up with the lid on; cook with the lid off and stir constantly.
** Add the food right at the beginning.
Soups Cooking assistance
functions
Poaching function
Instant soups, e.g. creamy soups Cooking functions 2/ 90ºC 10- 15
Cooking function
Homemade broths, e.g. meat or vegetable soups** Cooking functions 3/ 100ºC 60- 90
Instant soups, e.g. minestrone Cooking functions 3/ 100ºC 5- 10
Temperature
setting
Total cooking time
from signal (mins)
Cooking in a pressure cooker function
Homemade broths, e.g. vegetable soups** Cooking functions 4/ 120ºC 3- 6
* Stir frequently.
** Add the food straight away.
31
Page 32
en Cooking assist functions
Sauces Cooking as-
sistance
functions
Function for frying with a small amount of oil
Tomato sauce with vegetables Frying sensor 1 25- 35
Béchamel sauce Frying sensor 1 10- 20
Cheese sauce, e.g. Gorgonzola sauce Frying sensor 1 10- 20
Reducing sauces, e.g. tomato sauce, Bolognese sauce Frying sensor 1 25- 35
Sweet sauces, e.g. orange sauce Frying sensor 1 15- 25
Desserts Cooking assistance
functions
Poaching function
Rice pudding* Cooking functions 2/ 90ºC 40- 50
Porridge Cooking functions 2/ 90ºC 10- 15
Compote** Cooking functions 3/ 100 ºC 15- 25
Chocolate pudding*** Cooking functions 2/ 90ºC 3- 5
Function for frying with a large amount of oil
Patisserie, e.g. ring or filled doughnuts**** Cooking functions 5/ 170ºC 5- 10
* Stir regularly.
** Add the food right at the beginning.
*** Heat up with the lid on; cook with the lid off and stir constantly.
**** Heat the oil with the lid on. Fry in portions with the lid off (the table lists the cooking time per portion).
Temperature
setting
Temperature
setting
Total cooking time from
signal tone (mins)
Total cooking time
from signal tone (mins)
Frozen products Cooking assistance
functions
Function for frying with a small amount of oil
Escalope Frying sensor 4 15- 20
Cordon bleu* Frying sensor 4 10- 30
Poultry breast* Frying sensor 4 10- 30
Chicken nuggets Frying sensor 4 10- 15
Gyros, kebab Frying sensor 3 5- 10
Fish fillet, plain or breaded Frying sensor 3 10- 20
Fish fingers Frying sensor 4 8- 12
French fries Frying sensor 5 4- 6
Pan-fried dishes, e.g. fried vegetables with chicken Frying sensor 3 6- 10
Spring rolls Frying sensor 4 10- 30
Camembert/cheese Frying sensor 3 10- 15
Heating/keep-warm function
Frozen vegetables in a creamy sauce, e.g. cream of spinach** Cooking functions 1/ 70 ºC 15- 20
Cooking function
Frozen vegetables, e.g. green beans** Cooking functions 3/ 100ºC 15- 30
* Turn several times.
** Add liquid according to the manufacturer's instructions.
*** Heat the oil with the lid on. Fry in portions with the lid off (see table for cooking time per portion).
Temperature
setting
Total cooking time
from signal tone
(mins)
32
Page 33
Cooking assist functions en
Frozen products Cooking assistance
functions
Temperature
setting
Total cooking time
from signal tone
(mins)
Function for frying with a large amount of oil
Frozen chips*** Cooking functions 5/ 170ºC 4- 8
* Turn several times.
** Add liquid according to the manufacturer's instructions.
*** Heat the oil with the lid on. Fry in portions with the lid off (see table for cooking time per portion).
Miscellaneous Cooking assistance
functions
Temperature
setting
Total cooking time
from signal tone
(mins)
Function for frying with a small amount of oil
Camembert/cheese Frying sensor 3 7- 10
Dried instant meals to which water is added, e.g. pasta dishes Frying sensor 1 5- 10
Croutons Frying sensor 3 6- 10
Almonds/hazelnuts/walnuts/pine nuts Frying sensor 4 3- 15
Heating/keep-warm function
Food in jars and tins, e.g. goulash soup* Cooking functions 1/ 70ºC 10- 20
Mulled wine** Cooking functions 1/ 70ºC -
Poaching function
Milk** Cooking functions 2/ 90ºC -
* Add the food right at the beginning and stir regularly.
** Add the food right at the beginning.
Preparing and maintaining the wireless
temperature sensor
This section provides information on:
■ Adhering the silicone patch
■ Using the wireless cooking sensor
■ Cleaning
■ Changing the battery
1. that the adhesive area on the pan is free from
grease. Clean the pan, dry it thoroughly and wipe the
adhesive area with a spirit.
2. Remove the protective film from the silicone patch.
Adhere the silicone patch to the outside of the pan in
the correct place using the enclosed template as a
guide.
The silicone patch and the cooking sensor can be
purchased at a later time from specialist retailers, our
technical after-sales service or our official website. To
do this, quote the relevant reference number:
00577921 Set of 5silicone patches
HZ39050 Cooking sensor and set of 5silicone patches
Adhering the silicone patch
The silicone patch attaches the temperature sensor to
the cookware.
When a pan is used for the first time with the cooking
functions, the silicone patch must be adhered directly to
3. Press down all over the surface of the silicone patch,
including in the centre.
The adhesive requires one hour to fully harden. Do not
use or clean the pan during this time.
the pan. It is important
Notes
■ Do not leave the pan with the silicone patch to soak
soapy water for long periods of time.
■ If the silicone patch comes off, attach a new one.
33
Page 34
en Cooking assist functions
Fitting the wireless temperature sensor
Attach the temperature sensor to the silicone patch and
align it correctly.
Notes
■ Make sure that the silicone path is completely dry
before attaching the temperature sensor.
■ Position the cookware in such a way that the
temperature sensor is pointing towards the outer
side of the hob.
■ To prevent overheating, the temperature sensor
must not be pointed towards another item of
cookware that is hot.
■ Remove the temperature sensor from the saucepan
after cooking. Store it in a clean, safe place away
from sources of heat.
2. Open the closure of the temperature sensor.
Remove the battery from the lower section of the
housing and insert a new battery (pay attention to
the correct orientation of the battery poles).
Caution!
Do not use any metal objects to remove the battery.
Do not touch the battery connection points.
Cleaning
Do not clean the wireless temperature sensor in the
dishwasher.
You can find information on cleaning the temperature
sensor in the section on ~ "Cleaning"
Changing the battery
Cha n gi n g the bat ter y
If the temperature sensor does not light up when the
symbol is pressed, the battery is flat.
Changing the battery:
1. Remove the silicone cover from the lower section of
the temperature sensor housing and remove both
screws using a screwdriver.
3. Close the closure of the temperature sensor (the
notches for the screws on the closure must align
with the notches on the lower section of the
housing). Tighten the screws with a screwdriver.
4. Reattach the silicone cover to the lower section of
the temperature sensor housing.
34
Note: Use only high-quality batteries of the type
CR2032in order to guarantee a long service life.
Page 35
Childproof lock en
Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the
appliance with wireless temperature sensor function
meets the basic requirements and other relevant
provisions of the Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found
online at www.siemens-home.bsh-group.com on the
product page of your appliance with the additional
documents.
The logos and the Bluetooth® brand are registered
trademarks and property of Bluetooth SIG, Inc. These
trademarks are used by BSH Hausgeräte GmbH under
licence. All other trademarks and brand names are
owned by the respective companies.
AChildproof lock
Childproof lock
You can use the childproof lock to prevent children
from switching on the hob.
Activating and deactivating the childproof
lock
The hob must be off.
To activate:
1. Switch on the hob using the main switch.
2. Touch and hold the Ñ symbol for approx.
4seconds.
The ‚ indicator lights up for 10seconds.
The hob is locked.
To deactivate:
1. Switch on the hob using the main switch.
2. Touch and hold the Ñ symbol for approx.
4seconds.
The lock is released.
kWipe protection
Wipe pr ot ect i on
If you wipe over the control panel while the hob is
switched on, settings may be altered. To avoid doing
this, you can use the hob's "Lock control panel for
cleaning" function.
To activate: Touch the
Ñ symbol. An audible signal
sounds. The control panel is locked for 35seconds.
You can now wipe over the surface of the control panel
without altering any settings.
To deactivate: The control panel will be unlocked once
35seconds have elapsed. To release the function early,
touch the
Ñ symbol.
Notes
■ An audible signal sounds 30seconds after
activation. This indicates that the function is about to
finish.
■ The cleaning lock does not lock the main switch. The
hob can be switched off at any time.
bAutomatic safety cut-out
Aut omati c saf et y cut -out
If a hotplate operates for an extended period and no
settings are changed, the automatic safety shut-off is
activated.
The hotplate stops heating. ”, ‰ and the residual heat
indicator œ or • flash alternately in the hotplate display.
When you touch any symbol, the display switches off.
The hotplate can now be set again.
The point at which the safety shut-off becomes active
depends on which heat setting has been set (after 1to
10hours).
Childproof lock
With this function, the childproof lock automatically
activates when a hob is switched off.
Switching on and off
You can find out how to switch the automatic childproof
lock on in the ~ "Basic settings" section
35
Page 36
en Basic settings
QBasic settings
Bas i c s et t i ngs
The appliance has various basic settings. You can
adapt these to suit your cooking habits.
Indicator/
symbol
™‚
™ƒ
™„
™…
Function
Automatic childproof lock
‹ Manual*.
‚ Automatic.
ƒ Function deactivated.
Audible signals
‹ Confirmation and fault signals are switched off.
‚ Only the fault signal is switched on.
ƒ Only the confirmation signal is switched on.
„ All signal tones are switched on.*
Display energy consumption
‹ Switched off.*
‚ Switched on.
Setting to account for height above sea level
‚-ƒ Decrease
„oBasic setting
…-Š Increase
™†
™‡
™ˆ
Automatic cooking time programming
‹‹ Switched off.*
‹‚-ŠŠ Time until automatic switch-off.
Duration of the timer end signal tone
‚ 10seconds.*
ƒ 30seconds.
„ 1minute.
Power management function. Limiting the total power of the hob
The available settings depend on the maximum power of the hob.
‹ Deactivated. Maximum power of the hob. */**
‚ 1000W minimum power.
‚. 1500W
...
„ 3000W recommended for 13A.
„. 3500W recommended for 16A.
… 4000W
…. 4500W recommended for 20A.
...
Š or Š. Maximum power of the hob.**
™‚‚
Changing the preset power levels for the Move function
׊ Preset power level for the front cooking zone.
Ù† Preset power level for the central cooking zone.
Ø‚.† Preset power level for the rear cooking zone.
* Factory settings
**The hob's maximum power is shown on the rating plate.
36
Page 37
Basic settings en
Indicator/
symbol
™‚ƒ
™‚„
™‚…
™‚ˆ
™‚‰
Function
Check cookware; cooking results
‹ Not suitable
‚ Not perfect
ƒ Suitable
Configuring activation of the flexible cooking zone
‹ As two independent cooking zones.
‚ As a single cooking zone.*
Connecting the wireless temperature sensor to the hob
‹ Connected correctly
‚ Not connected correctly: Transmission error.
ƒ Not connected correctly: Temperature sensor fault.
Configuring air recirculation mode or air extraction mode
‹ Air recirculation mode has been set.*
‚ Air extraction mode has been set.
Configuring automatic start
‹ Switched off.
‚ Switched on: Automatic mode with sensor control.*
ƒ Switched on: The ventilation system starts at a specified power level.
™‚Š
Configuring sensor sensitivity for the ventilation system
‚ Lowest sensor sensitivity setting.
ƒ Medium sensor sensitivity setting.*
„ Highest sensor sensitivity setting.
™ƒ‹
Configuring the run-on
‹ Switched off.
‚ Switched on: Automatic function with sensor-controlled run-on.
ƒ Switched on: The ventilation system runs in air extraction mode for approx. 6 minutes and in air recirculation mode for approx.
30 minutes at power level ‚ and automatically switches off once this time has elapsed.*
™‹
Restoring the factory settings
‹ Custom settings.*
‚ Restore the factory settings.
* Factory settings
**The hob's maximum power is shown on the rating plate.
37
Page 38
en Energy consumption indicator
To access the basic settings:
The hob must be off.
1. Switch on the hob.
2. Within ten seconds, touch and hold the 0 symbol
for approximately four seconds.
The first four displays provide product information.
Touch the settings area to view the individual
displays.
Product information Display screen
After-sales service index (ASSI)
Production number
Production number 1
Production number 2
3. Touching the 0 symbol again takes you to the basic
settings.
™‚ and ‹ light up as a presetting in the displays.
‹‚
”š
Š†.
‹.†
[Energy consumption
indicator
Energy consumpti on indicator
This function indicates the total amount of energy
consumed by this hob the last time it was used for
cooking.
Once the hob is switched off, the energy consumption
is displayed in kilowatt hours (e.g. ‚.‹‰ kWh) for
10seconds.
The accuracy of the information displayed depends on
the voltage quality of the mains power supply, among
other factors.
You can find out how to switch this function on in the
section on ~ "Basic settings"
4. Touch the 0 symbol repeatedly until the required
function is displayed.
5. Then select the required setting from the settings
area.
6. Touch the 0 symbol for at least four seconds.
The settings have been saved.
Leaving the basic settings
Turn off the hob with the main switch.
38
Page 39
Cookware check en
tCookware check
Cookware check
This function can be used to check the speed and
quality of the cooking process depending on the
cookware.
The result is a reference value and depends on the
properties of the cookware and the hotplate being used.
1. Correctly position the pot with approximately 200ml
of water, at room temperature, on the most suitable
cooking zone for the diameter of the bottom of the
pot.
2. Go to the basic settings and select the setting ™‚ ƒ.
3. Press the programming area. A flashes in the
cooking zone displays.
The function has now been activated.
After 10seconds, the cooking result and the speed of
the cooking process appear in the visual displays for
the cooking zone.
hPower manager
Power manager
You can use the power manager to set the total power
of the hob.
The hob is preset at the factory. Its maximum
performance is specified on the rating plate. You can
use the power manager to change the value in
accordance with the requirements for the relevant
electrical installation.
In order not to exceed this set value, the hob
automatically distributes the power available between
the cooking zones that are switched on.
As long as the power manager function is activated, the
output of a cooking zone may temporarily fall below the
nominal value. If a cooking zone is switched on and the
power limit is reached, ¬ appears in the heat setting
display for a short time. The appliance automatically
regulates and selects the highest possible power level.
For more information about how the total power of the
hob is changed, see section ~ "Basic settings"
Check the result using the following table:
Result
The cookware is not suitable for the hotplate and will therefore
‹
not heat up.*
The cookware is taking longer to heat up than expected and the
‚
cooking process is not going as well as it should.*
The cookware is heating up correctly and the cooking process
ƒ
is going well.
* If there is a smaller hotplate available, test the cookware again on the
smaller hotplate.
To reactivate this function, touch the settings range.
Notes
■ The flexible cooking zone only counts as a single
hotplate; place no more than one item of cookware
on it.
■ If the diameter of the hotplate used is much smaller
than the diameter of the cookware, only the middle
of the cookware can be expected to heat up. This
may result in the cooking results not being as good
as expected or being less than satisfactory.
■ You can find information on this function in the
section on ~ "Basic settings".
■ You can find information on the type, size and
positioning of the cookware in the sections on
~ "Induction cooking" and ~ "Flex Zone".
39
Page 40
en Cleaning
DCleaning
Cleani ng
:Warning – Risk of burns!
The appliance becomes hot during operation. Allow the
appliance to cool down before cleaning.
:Warning – Risk of burns!
The appliance will become hot during operation. If hot
liquids penetrate the appliance, leave the appliance to
cool for at least two hours before removing the filter
cover, the metal grease filter, the container, the overflow
reservoir or the appliance housing.
:Warning – Risk of electric shock!
Do not use any high-pressure cleaners or steam
cleaners, which can result in an electric shock.
:Warning – Risk of electric shock!
Penetrating moisture may result in an electric shock.
Clean the appliance using a damp cloth only. Before
cleaning, pull out the mains plug or switch off the circuit
breaker in the fuse box.
:Warning – Risk of injury!
Components inside the appliance may have sharp
edges. Wear protective gloves.
Note: Only use a minimal amount of water when
cleaning so that no water enters the appliance.
Notes
■ Before cleaning the appliance, remove any jewellery
you are wearing on your arms and hands.
■ Do not use any cleaning agents while the hob is still
hot. This may mark the surface. Ensure that any
residue left by cleaning agents is removed.
Cleaning agents
Only use cleaning products that are suitable for this
type of hob. Follow the manufacturer's instructions on
the product packaging.
Follow all instructions and warnings included with the
cleaning products.
Suitable maintenance and cleaning products can be
purchased from the after-sales service or in our e-Shop.
To ensure that the different surfaces are not damaged
by using the wrong cleaning product, follow the
instructions in the table.
Area Cleaning product
Glass ceramic Glass cleaner for stains caused by limescale
and residual water:
Clean the hob as soon as it has cooled down.
You can use a cleaning product that is suitable for glass-ceramic hobs or glass cleaner
(article no. 00311499).
Glass scraper (article no. 00087670) for
stains caused by sugar, rice starch or plastic:
Clean immediately. Caution: Risk of burns.
Then clean with a damp dish cloth and then
dry with a cloth or towel.
Note: Do not use cleaning products designed
for dishwashers.
Stainless steel Hot soapy water:
Clean with a dish cloth and then dry with a
soft cloth.
Use a minimal amount of water when cleaning
to prevent water from penetrating the appliance.
Leave dried-on remnants to soak in a small
amount of soapy water; do not scour.
Always clean stainless steel surfaces in the
direction of the grain.
Special stainless steel cleaning products (article no. 00311499) are available from our
after-sales service, through our online shop or
from specialist retailers. Apply a very thin
layer of the cleaning product with a soft cloth.
Note: Do not use a glass scraper to clean the
hob surround.
Plastic Hot soapy water:
Clean with a soft cloth or in the dishwasher.
Controls Hot soapy water or an appropriate glass
cleaner (article no. 00311499):
Clean using a damp dish cloth and then dry
with a soft cloth.
Filter cover Hot soapy water:
Clean using a damp dish cloth and then dry
with a soft cloth.
Caution!
Beware of causing surface damage
Do not use:
■ Undiluted washing-up liquid
■ Cleaning products designed for dishwashers
■ Abrasive cleaning products
■ Pressure washers or steam jet cleaners
■ Oven cleaners
■ Corrosive or aggressive cleaners, or those
containing chlorine
■ Cleaners containing a large percentage of alcohol
■ Hard, scratchy sponges, brushes or scouring pads
Caution!
Beware of causing surface damage
Always wash new sponge cloths thoroughly before use.
40
Page 41
Cleaning en
Components to clean
Hob
Clean the hob each time you use it. This will prevent
food remnants from becoming burned on. Do not clean
the hob until the residual heat indicator has gone out.
Remove boiled-over liquids immediately and do not
allow any food remains to dry on.
Clean the hob with a damp dish cloth and dry it with a
cloth or towel to prevent limescale build-up.
Stubborn dirt is best removed with a glass scraper or
glass ceramic cleaner (available from retailers). Follow
the manufacturer's instructions.
You can obtain a suitable glass scraper (article no.
00087670) from our after-sales service or through our
online shop.
Using a special sponge for cleaning glass-ceramic
hobs achieves great cleaning results.
Ventilation system
The filter must be regularly cleaned or replaced in order
to guarantee efficient filtration of odours and grease.
Metal grease filter
The metal grease filters should be cleaned every
30operating hours or at least once a month.
No. Name
1 Filter cover
2 Metal grease filter
3 Container
4 Hob
5 Control panel
6 Overflow container
7 Housing cover
8 Activated charcoal filter (only in air recirculation mode)
Hob surround (only on appliances with hob
surrounds)
To prevent damage to the hob surround, observe the
following instructions:
■ Only use warm soapy water
■ Wash new dish cloths thoroughly before use.
■ Do not use harsh or abrasive cleaning agents.
■ Do not use a glass scraper or sharp objects.
:Warning – Risk of fire!
Grease deposits in the grease filter may catch fire.
Clean the grease filter at least once a month.
Never operate the appliance without the grease filter.
Activated charcoal filters
The activated charcoal filter should be replaced
regularly. The saturation indicator on your appliance will
tell you how frequently this needs to be done.
Saturation display
If the metal grease filter or activated charcoal filter
becomes saturated, a signal will sound once the
appliance has been switched off.
The following symbols will light up in the display panel:
■ Metal grease filter: ”‚ ‹ lights up
■ Activated charcoal filter: ” ‚‚ lights up
■ Metal grease filter and activated charcoal filter:
” ‚‹ and ”‚‚ light up alternately
Do not wait any longer to clean the metal grease filter or
replace the activated charcoal filter.
Once you have cleaned or replaced the relevant filters,
reset the saturation indicator so that the ”‚ ‹ and
”‚‚ indicators go out.
After the appliance has been switched off, ”‚‹ or ”‚‚
lights up.
1. Touch the a symbol.
A signal tone will sound. The metal grease filter
saturation indicator has now been reset.
2. If ”‚‚ lights up, touch the a symbol again.
A signal tone will sound. The activated charcoal filter
saturation indicator has now been reset.
41
Page 42
en Cleaning
Changing the activated charcoal filter (only in
circulating-air mode)
Activated charcoal filters trap the odour-causing
compounds in cooking smells. They are only used for
circulating-air mode.
Notes
■ The activated charcoal filter is not included with the
appliance.The activated charcoal filter (article
no. HZ381700) is available from specialist retailers,
from our after-sales service or from our online shop.
■ The activated charcoal filter cannot be cleaned or
reactivated.
■ Only use genuine replacement filters. This will
ensure that the appliance performs optimally.
1. Unlock all of the closing elements on the drawer in
the flat duct of the fitted unit.
Removing metal grease filter
The metal grease filters filter the grease out of kitchen
steam. To keep them in good working order, the filters
should be cleaned at least once a month.
1. Take the filter cover off.
Note: Make sure that the filter cover does not fall
and damage the hob.
2. Take the metal grease filter and the container out.
2. Open the drawer in the flat duct and remove the
activated charcoal filter.
3. Insert the new activated charcoal filter.
4. Close the drawer in the flat duct and lock all of the
closing elements.
Note: Make sure that all of the closing elements
have been locked correctly. Otherwise noises may
be generated and the power of the ventilation
system may be reduced.
Note: Fat may accumulate in the bottom of the
container.Hold the metal grease filter level to prevent
fat from dripping out.
3. Press down on the two catches on either side of the
container to separate the metal grease filter from the
container.
4. Empty the container if necessary.
5. Clean the metal grease filter and filter cover.
6. After removing the metal grease filter, clean the
inside of the appliance.
Note: Droplets of water may form on the fan wheel. This
is normal and occurs as a result of the cooking vapours
condensing. It is not a safety hazard and there is no risk
of damage. The electronic components in the appliance
are protected.
42
Cleaning the metal mesh grease filters
Notes
■ Do not use aggressive, acidic or alkaline cleaning
products.
■ The metal grease filter can be cleaned in the
dishwasher or by hand.
Page 43
Cleaning en
By hand:
Note: You can use a special degreaser to remove
stubborn dirt (article no. 00311297). This can be
ordered through our online shop.
■ Soak the metal grease filter in hot soapy water.
■ Clean the metal grease filter with a brush and then
rinse it thoroughly.
■ Leave the metal grease filter to drain.
In the dishwasher:
■ Do not clean the metal grease filter together with
cookware if heavily soiled.
■ Place the metal grease filter in the dishwasher,
leaving plenty of space around it. Do not trap the
metal grease filter.
■ For best results, place the metal grease filter in the
dishwasher filter side down.
Fitting and cleaning other appliance components
Also clean the inside of the hob extractor system
regularly. You can use a special degreaser to remove
stubborn dirt (article no. 00311297).
1. Remove the filter cover and clean it with a damp
cloth.
5. Clean the metal grease filter and the container in the
dishwasher.
6. If required, take off the housing cover underneath
the appliance and clean it.
7. Clean the parts and dry them before refitting them.
Inserting the metal grease filters
1. Insert the container.
2. Insert the metal grease filter.
Note: Ensure that the metal grease filter has been
inserted correctly. Otherwise, the ventilation system
does not work.
3. Put the filter cover on.
2. Remove the metal grease filter and container.
3. Press down on the two catches on either side of the
container to separate the metal grease filter from the
container.
Resetting the saturation displays
Once you have cleaned or replaced the relevant filters,
reset the saturation indicator so that the ”‚ ‹ and
”‚‚ indicators go out.
After the appliance has been switched off, ”‚‹ or ”‚‚
lights up.
1. Touch the a symbol.
A signal tone will sound. The metal grease filter
saturation indicator has now been reset.
2. If ”‚‚ lights up, touch the a symbol again.
A signal tone will sound. The activated charcoal filter
saturation indicator has now been reset.
Cleaning the overflow container
Notes
■ Make sure that the supply to the overflow container
is not blocked. Remove any objects that have
entered the appliance once it has cooled down. To
do this, take the filter cover off and take the metal
grease filter and the container out.
■ Any liquid entering the appliance from above will be
collected in the overflow container. Unscrew the
overflow container and empty it. Take the housing
cover off if necessary.
4. Empty the container if necessary.
43
Page 44
en Cleaning
1. Unscrew the overflow container with both hands.
Notes
– Hold the overflow container level to prevent liquid
from leaking out.
– If the metal grease filter and the container have
been removed and liquid finds its way into the
appliance through the fan grille, you will need to
remove the housing cover.
2. Empty the overflow container, as well as the housing
cover if necessary, and rinse it/them out.
3. Clean the overflow container before screwing it back
into place.
4. Refit the housing cover.
Wireless temperature sensor
Temperature sensor
Clean the temperature sensor with a damp cloth. Never
clean it in the dishwasher. Do not immerse it in water or
clean it under running water.
Remove the temperature sensor from the saucepan
after cooking. Store it in a clean, safe place (such as in
its packaging) away from sources of heat.
Silicone patch
Clean and dry before attaching to the temperature
sensor. Dishwasher safe.
Note: Cookware with the silicone patch must not be left
to soak for long periods in soapy water.
Temperature sensor window
The sensor window must always be clean and dry.
Proceed as follows:
■ Remove dirt and oil splatters regularly.
■ Use a soft cloth or cotton buds and window cleaner
for cleaning.
Notes
■ Do not use abrasive cleaning agents such as
scouring pads, scrubbing brushes or cream
cleaners.
■ Do not touch the sensor window with your fingers.
This may make it dirty or scratch it.
44
Page 45
{Frequently Asked
Questions (FAQ)
Frequent l y As ke d Quest i ons (FAQ)
Using the appliance
Why can't I switch on the hob and why is the childproof lock symbol lit?
The childproof lock is activated.
You can find information on this function in the section on ~ "Childproof lock"
Why are the displays flashing and why can I hear an audible signal?
Remove any liquid or food remains from the control panel. Remove any objects from the control panel.
You can find instructions on how to deactivate the audible signal in the section on ~ "Basic settings"
Noises
Why I can hear noises while I'm cooking?
Noises may be generated while using the hob depending on the base material of the cookware. These noises are a normal part of induction technology. They do not indicate a defect.
Frequently Asked Questions (FAQ) en
Possible noises:
A low humming noise like the one a transformer makes:
Occurs when cooking at a high heat setting. The noise disappears or becomes quieter when the heat setting is reduced.
Low whistling noise:
Occurs when the cookware is empty. This noise disappears when water or food is added to the cookware.
Crackling:
Occurs when using cookware made from different layers of material or when using cookware of different sizes and different materials at
the same time. The loudness of the noise can vary depending on the quantity of food being cooked or the cooking method.
High-pitched whistling noises:
Can occur when two hotplates are used at the highest heat setting at the same time. The whistling noises disappear or become quieter
when the heat setting is reduced.
Fan noise:
The hob is equipped with a fan that switches on automatically at high temperatures. The fan may continue to run even after you have
switched off the hob if the temperature detected is still too high.
Cookware
Which types of cookware can be used with an induction hob?
You can find information on which types of cookware can be used with an induction hob in the section on ~ "Induction cooking".
Why is the hotplate not heating up and why is the heat setting flashing?
The hotplate on which the cookware is standing is not switched on.
Check that you have switched on the correct hotplate.
The cookware is too small for the hotplate that is switched on or it is not suitable for induction cooking.
Check that the cookware is suitable for induction cooking and that it is placed on the hotplate that best corresponds to its size. You can
find information on the type, size and positioning of cookware in the sections on ~ "Induction cooking", ~ "Flex Zone" and ~ "Move
function".
Why is it taking so long for the cookware to heat up or why is it not heating up sufficiently despite being on a high heat setting?
The cookware is too small for the hotplate that is switched on or it is not suitable for induction cooking.
Check that the cookware is suitable for induction cooking and that it is placed on the hotplate that best corresponds to its size. You can
find information on the type, size and positioning of cookware in the sections on ~ "Induction cooking", ~ "Flex Zone" and ~ "Move
function".
45
Page 46
en Frequently Asked Questions (FAQ)
Cleaning
How do I clean the hob?
Using a special glass-ceramic cleaning agent produces the best results. We advise against using harsh or abrasive cleaning agents, dishwater detergent (concentrated) or scouring pads.
You can find more information on cleaning and caring for your hob in the section on ~ "Cleaning"
46
Page 47
Trouble shooting en
3Trouble shooting
Troubl e shoot i ng
Usually, faults are small matters that are easy to
eliminate. Please read the information in the table
before calling the after-sales service.
Fault/display Possible cause Solution
The appliance does not work The plug is not plugged into the mains Connect the appliance to the electricity supply
Power cut Check whether other kitchen appliances are working
The circuit breaker is faulty Check in the fuse box to make sure that the fuse for the appliance
The symbol lighting is not
working.
The ventilation system is not
working.
”‚‹
”‚‚
”‚‹ / ”‚‚
Nothing on the display The power supply has been disconnected. Use other electrical appliances to check whether a short circuit
The indicators/symbols are
flashing
”ƒ
”…
Ӡ + heat setting and signal
tone
Ӡ and signal tone
”‚ / ”‡
”‹
”Š
”‰
“‰ƒ‹ƒ
“‰ƒ‹„
“‰ƒ‹…
Do not place hot pans on the control panel.
The control unit is faulty. Call our after-sales service.
The metal grease filter has not been inserted correctly.
The filter detection sensor is not working. Call the after-sales service.
The metal grease filter is saturated. Clean the metal grease filter.~ "Cleaning" on page 40
The activated charcoal filter is saturated. Replace the activated charcoal filter. ~ "Cleaning" on page 40
The saturation indicator is lit even though the filter
has been cleaned or replaced.
The appliance has not been connected as shown
in the circuit diagram.
Electronics fault. If the fault cannot be rectified, inform the technical after-sales ser-
The control panel is wet or an object is covering it. Dry the control panel or remove the object.
The electronics have overheated and switched off
the affected hotplate.
The electronics have overheated and all the hotplates have been switched off.
There is a hot pan near the control panel. There is
a risk that the electronics will overheat.
There is a hot pan near the control panel. To protect the electronics, the hotplate has been
switched off.
The hotplate has overheated and has been
switched off to protect the work surface.
The transfer settings function cannot be activated Touch any touch control to check the fault code. You can cook as
The FlexPlus cooking zone cannot be activated Touch any touch control to check the fault code. You can use the
The hotplate has been operating continuously for
an extended period.
The temperature sensor has overheated and the
hotplate has been switched off.
The temperature sensor has overheated and all
the hotplates have been switched off.
The battery in the temperature sensor is flat. Replace the 3 V CR2032battery. See the section entitled
:Warning – Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be
carried out and damaged power cables replaced by
one of our trained after-sales technicians. If the
appliance is defective, unplug the appliance from the
mains or switch off the circuit breaker in the fuse box.
Contact the after-sales service.
is OK
Insert the metal grease filter correctly. ~ "Cleaning" on page 40
Reset the saturation indicator. ~ "Resetting the saturation
displays" on page 43
has occurred in the power supply.
Check that the appliance has been connected as shown in the circuit diagram.
vice.
Wait until the electronics have cooled down sufficiently. Then
touch any symbol on the hob.
Remove the pan. The fault code will go out shortly afterwards. You
can resume cooking.
Remove the pan. Wait a few seconds. Touch any touch control.
When the fault code on the display goes out, you can resume
cooking.
Wait until the electronics have cooled down sufficiently before
switching the hotplate on again.
usual without using the transfer settings function. Contact the
technical after-sales service.
remaining hotplates to cook as usual. Contact the technical aftersales service.
The automatic safety switch-off function has been activated. See
the section entitled
Wait until the temperature sensor has cooled down sufficiently
before activating the function again.
If you are not using the temperature sensor, remove it from the
cookware and keep it away from the other hotplates and sources
of heat. Switch the hotplates back on.
~ "Changing the battery"
47
Page 48
en Trouble shooting
“‰ƒ‹†
“‰ƒ‹‡
The temperature sensor indicator is not lighting up
The indicator on the temperature sensor flashes twice.
The temperature sensor is disconnected. Switch the function off and then on again.
The temperature sensor is broken/faulty. Contact the technical after-sales service.
The temperature sensor is not responding and
the indicator is not lighting up.
The battery in the temperature sensor has almost
run out. You may be interrupted the next time you
cook by the battery running out.
The indicator on the tempera-
The temperature sensor is disconnected. Press and hold the symbol on the temperature sensor for 8secture sensor flashes three
times.
“Š‹‹‹
“Š‹‚‹
—…‹‹
š“
The operating voltage is incorrect/outside of the
normal operating range.
The hob is not connected properly Disconnect the hob from the power supply. Check that it has been
Demo mode is activated Disconnect the hob from the power supply. Wait for 30 seconds
Do not place hot pans on the control panel.
--------
Notes
■ If “ appears on the display, press and hold the
button for the relevant cooking zone in order to read
the fault code.
■ If the fault code is not listed in the table, disconnect
the hob from the mains power supply and wait
30 seconds before reconnecting it. If this code is
displayed again, contact the technical after-sales
service and specify which fault code has appeared.
■ If a fault occurs, the appliance will not switch to
standby mode.
Replace the 3 V CR2032battery. See the section entitled
~ "Changing the battery"
If this does not solve the problem, press and hold the temperature
sensor button for 8minutes, and then reconnect the temperature
sensor to the hob.
If the problem persists, contact the technical after-sales service.
Replace the 3 V CR2032battery. See the section entitled
~ "Changing the battery"
onds and then reconnect the temperature sensor to the hob.
Contact your electricity supplier.
connected as shown in the circuit diagram.
before reconnecting it. Touch any touch control in the next
3 minutes. This will deactivate demo mode.
48
Page 49
4Customer service
Cus t o mer servi ce
Our after-sales service is there for you if your appliance
needs to be repaired. We will always find an
appropriate solution, also in order to avoid after-sales
personnel having to make unnecessary visits.
E number and FD number
Please quote the E-number (product number) and the
FD number (production number) of your appliance
when contacting our after-sales service.
The rating plate bearing these numbers can be found:
■ On the appliance certificate.
■ On the underside of the hob.
=1U)'(1U
7\SH
Customer service en
The E number can also be found on the hob's glass
ceramic surface. You can check the after-sales service
index (KI) and FD number by going to the basic
settings.Refer to the section entitled ~ "Basic settings"
to find out how to do this.
Please note that a visit from an after-sales service
engineer is not free of charge in the event that the
appliance has been misused, even during the warranty
period.
Please find the contact data of all countries in the
enclosed customer service list.
To book an engineer visit and product advice
GB 03448928999
Calls charged at local or mobile rate.
IE 014502655
0.03 € per minute at peak. Off peak 0.0088 €
per minute.
Rely on the professionalism of the manufacturer. You
can therefore be sure that the repair is carried out by
trained service technicians who carry original spare
parts for your appliances.
49
Page 50
en Test dishes
ETest dishes
Test di shes
This table has been produced for test institutes to
■ Saucepan Ø 16cm, 1.2l for hotplates of Ø 14.5cm
■ Pot Ø 16cm, 1.7l for hotplates of Ø 14.5cm
■ Pot Ø 22cm, 4.2l for hotplates of Ø 18cm
■ Frying pan Ø 24cm, for hotplates of Ø 18cm
facilitate the testing of our appliances.
The data in the table refers to our Schulte-Ufer
cookware accessories (4piece cookware set for the HZ
390042induction hob) with the following
measurements:
Test dishes Cookware
Melting chocolate
Chocolate coating (e.g. Dr. Oetker brand, dark chocolate 55% cocoa,
150g)
Saucepan,
16 cm
diameter
Heating and keeping lentil stew warm
Lentil stew*
Initial temperature 20 °C
Amount: 450 g
Cooking
pot, 16 cm
diameter
Amount: 800 g
Saucepan,
22 cm
diameter
Lentil stew from a tin
E.g lentils with Erasco sausages.
Initial temperature 20 °C
Amount: 500 g
Cooking
pot, 16 cm
diameter
Amount: 1 kg
Saucepan,
22 cm
diameter
Preheating Cooking
Heat setting
Cooking time
(min:sec)
Lid Heat setting Lid
- - - 1.5 No
1:30
9
(without stir-
Yes 1.5 Yes
ring)
2:30
9
(without stir-
Yes 1.5 Yes
ring)
Approx. 1:30
9
(stir after
approx.
Yes 1.5 Yes
1 minute)
Approx. 2:30
9
(stir after
approx.
Yes 1.5 Yes
1 minute)
Preparing Béchamel sauce
Temperature of the milk: 7 ºC
Ingredients: 40 g butter, 40 g flour, 0.5 l milk (3.5% fat content) and a
pinch of salt
1. Melt the butter, stir in the flour and salt, and heat up the mixture. Saucepan,
2Add the milk to the roux and bring to the boil, stirring continuously.
3. Once the Béchamel sauce comes to the boil, leave it on the hotplate for a further two minutes, stirring continuously.
*Recipe in accordance with DIN 44550
**Recipe in accordance with DIN EN 60350-2
50
16 cm
diameter
2 Approx. 6:00 No - -
7 Approx. 6:30 No - -
- - - 2 No
Page 51
Test dishes Cookware
Cooking rice pudding
Rice pudding, cooked with the lid on
Temperature of the milk: 7 ºC
Heat the milk until it starts to rise up. Set the recommended heat setting
and add rice, sugar and salt to the milk.
The cooking time, including preheating, is approx. 45minutes.
Ingredients: 190 g short-grain rice, 90 g sugar, 750 ml milk (3.5%
fat content) and 1 g salt
Ingredients: 250 g short-grain rice, 120 g sugar, 1 l milk (3.5% fat
content) and 1.5 g salt
Rice pudding, cooked without lid
Temperature of the milk: 7 ºC
Add the ingredients to the milk and heat the mixture up while stirring con-
tinuously. Once the milk has reached approx. 90 ºC, select the recommended heat setting and leave it to simmer on a low heat for approx.
50 minutes.
Ingredients: 190 g short-grain rice, 90 g sugar, 750 ml milk (3.5%
fat content) and 1 g salt
Ingredients: 250 g short-grain rice, 120 g sugar, 1 l milk (3.5% fat
content) and 1.5 g salt
Cooking
pot, 16 cm
diameter
Saucepan,
22 cm
diameter
Cooking
pot, 16 cm
diameter
Saucepan,
22 cm
diameter
Test dishes en
Preheating Cooking
Heat setting
8.5 Approx. 5:30 No
8.5 Approx. 5:30 No
8.5 Approx. 5:30 No 3 No
8.5 Approx. 5:30 No 2.5 No
Cooking time
(min:sec)
Lid Heat setting Lid
3
(stir after
10 minutes)
3
(stir after
10 minutes)
Yes
Yes
Cooking rice*
Water temperature: 20 °C
Ingredients: 125 g long grain rice, 300 g water and a pinch of salt Cooking
Ingredients: 250 g long grain rice, 600 g water and a pinch of salt Saucepan,
Roasting a pork loin
Initial temperature of the loin: 7 °C
Amount: 3pork loins (total weight approx. 300 g, 1 cm thick) and
15 ml sunflower oil
Preparing pancakes**
Amount: 55 ml batter for each pancake Frying pan,
Deep-fat frying chips
Amount: 2l sunflower oil, per portion: 200 g frozen chips (e.g.
McCain 123Original fries)
*Recipe in accordance with DIN 44550
**Recipe in accordance with DIN EN 60350-2
pot, 16 cm
diameter
22 cm
diameter
Frying pan,
24 cm
diameter
24 cm
diameter
Saucepan,
22 cm
diameter
9 Approx. 2:30 Yes 2 Yes
9 Approx. 2:30 Yes 2.5 Yes
9 Approx. 1:30 No 7 No
9 Approx. 1:30 No 7 No
Until the oil
9
temperature
reaches
180 °C
No 9 No
51
