Siemens CCWC1345-LX, CCWC1345-MX Configuration Manual

Fire Safety & Security Products

Siemens Building Technologies

1/3” CMOS Ultra Wide
Dynamic Color Camera

CCWC1345-LX
CCWC1345-MX

Configuration Manual

Liefermöglichkeiten und technische Änderungen vorbehalten.
Data and design subject to change without notice. / Supply subject to availability.
© 2006 Copyright by
Siemens Building Technologies AG

Wir behalten uns alle Rechte an diesem Dokument und an dem in ihm dargestellten Gegenstand vor. Der Empfänger erkennt diese Rechte
an und wird dieses Dokument nicht ohne unsere vorgängige schriftliche Ermächtigung ganz oder teilweise Dritten zugänglich machen oder
außerhalb des Zweckes verwenden, zu dem es ihm übergeben worden ist.

We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights
and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our
prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.

Dear Customer

By selecting this SIEMENS product, you have chosen a professional device that
guarantees the highest possible quality and reliability. We would like to thank you
very much for your confidence in our products and kindly ask you to read the
following instructions carefully before installing and using the product, in order to
take full advantage of all quality features included in this product line.

WARNING

To reduce the risk of fire or electrical shock, do not expose this product to rain or
moisture. It should be installed by a qualified service person and should conform to
all local codes. Please connect the equipment to a 12 V DC or 24 V AC Class 2
power supply if the LP camera model is to be installed.

3

Siemens Building Technologies
Fire Safety & Security Products 08.2006

Contents

1 General information................................................................................5

1.1 Work safety information ............................................................................5

1.2 Electromagnetic compatibility (EMC)........................................................5

1.3 Manufacturer's declaration of conformity..................................................6

2 General guidelines..................................................................................7

2.1 Operation and storage ..............................................................................9

2.2 Cleaning ....................................................................................................9

2.3 Transportation...........................................................................................9

2.4 CMOS characteristics ...............................................................................9

3 Technical data .......................................................................................10

3.1 Dimensions .............................................................................................10

3.2 Product specifications .............................................................................10

4 Ordering data.........................................................................................12

4.1 Package contents....................................................................................12

5 Camera part and connector definition................................................13

5.1 Camera part definition.............................................................................13

5.2 Connector pin definition ..........................................................................14

5.2.1 Control switch for twisted pair video out .................................................14

5.2.2 RS485 termination ..................................................................................14

5.2.3 IRIS pin assignment................................................................................14

5.2.4 Y / C terminal ..........................................................................................14

5.2.5 External control terminal .........................................................................15

5.3 OSD setting hierarchy.............................................................................16

6 Install the camera.................................................................................. 18

6.1 Installation...............................................................................................18

6.1.1 Using BNC composite video output ........................................................18

6.1.2 Using twisted pair video output...............................................................18

6.2 Function settings.....................................................................................19

6.2.1 PRESET..................................................................................................19

6.2.2 CAMERA SETUP....................................................................................19

6.2.2.1 EXPOSURE ............................................................................................19

6.2.2.2 SHUTTER ...............................................................................................19

6.2.2.3 LENS LEVEL...........................................................................................20

6.2.2.4 WB MODE...............................................................................................20

6.2.2.5 GAIN .......................................................................................................20

6.2.2.6 GAMMA...................................................................................................21

6.2.2.7 APERTURE.............................................................................................21

6.2.2.8 WD-LEVEL..............................................................................................21

6.2.3 D/N SETUP.............................................................................................21

6.2.3.1 D/N MODE ..............................................................................................22

6.2.3.2 D/N LEVEL..............................................................................................22

6.2.3.3 D/N DELAY .............................................................................................22

6.2.4 OPTION ..................................................................................................22

6.2.4.1 Mirror.......................................................................................................23

6.2.4.2 DZOOM...................................................................................................23

6.2.4.3 DZOOM IN OUT......................................................................................23

6.2.4.4 DZOOM P/T SET ....................................................................................23

6.2.4.5 CHROMA ................................................................................................23

6.2.4.6 COLOR BAR...........................................................................................24

6.2.4.7 DNR ........................................................................................................24

4

Siemens Building Technologies
Fire Safety & Security Products 08.2006

6.2.4.8 BACKFOCUS..........................................................................................24

6.2.4.9 SYSTEM..................................................................................................24

6.2.5 OTHER SETUP.......................................................................................24

6.2.5.1 CAMERA ID ............................................................................................25

6.2.5.2 ALARM....................................................................................................25

6.2.5.3 ALARM TEXT..........................................................................................25

6.2.5.4 ALARM ACTION .....................................................................................25

6.2.5.5 ALARM DELAY .......................................................................................25

6.2.5.6 MOTION..................................................................................................26

6.2.5.7 MOTION LEVEL......................................................................................26

6.2.5.8 MOTION AREA .......................................................................................26

6.2.5.9 SET ZONE POSI.....................................................................................26

6.2.5.10 SET ZONE SIZE ....................................................................................26

6.2.5.11 SET ZONE MOVE..................................................................................27

6.2.5.12 MOTION TEXT.......................................................................................27

6.2.5.13 ALARM OUT ..........................................................................................27

6.2.5.14 MOTION DELAY ....................................................................................27

6.2.6 REMOTE.................................................................................................28

6.2.6.1 ADDRESS...............................................................................................28

6.2.6.2 PROTOCOL ............................................................................................28

6.2.6.3 BAUD RATE............................................................................................28

6.2.7 PRIVACY ZONE .....................................................................................28

6.2.8 BLC ZONE ..............................................................................................29

6.2.9 SYNC MODE...........................................................................................30

6.2.10 BACK.......................................................................................................30

6.2.11 EXIT ........................................................................................................30

6.2.12 CANCEL..................................................................................................30

6.2.13 DEFAULT................................................................................................30

7 Maintenance...........................................................................................31

8 Disposal .................................................................................................31

9 Keyword index.......................................................................................32

General information

5

Siemens Building Technologies
Fire Safety & Security Products 08.2006

1 General information

1.1 Work safety information

z Read these instructions carefully before connecting the camera in order to avoid

damage caused by improper installation or use.

z Installation may be done only by authorized personnel according to the local

safety regulations.

z Operate the camera only with the designated voltage.
z Follow the safety instructions for the camera.
z Never use the camera for purposes other than those designated.
z Repairs and adjustments to the camera may be done only by authorized per-

sonnel.

z If liquids or objects get into the housing, disconnect the camera from the power

supply and have it checked by your authorized dealer before using it again.
(Danger of electric shock!)

z This equipment has been tested and found to comply with the limits for a Class

B digital device. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.

z This equipment may generate, uses and can radiate radio frequency energy

and, if not installed and used according to instructions, may cause harmful inter­ference with radio communications.

z Be aware that any modifications not explicitly approved in this manual may void

your equipment warranty.

z The shielded interface cable recommended in this manual must be used with

this equipment in order to comply with the limits for a digital output device.

1.2 Electromagnetic compatibility (EMC)

This product has been designed for use in general-purpose CCTV applications in a
residential, business or industrial environment. Please contact the supplier of this
product if you intend to use it in medical, intrinsically safe installations or in an in­dustrial EMC environment.

To ensure normal operation and to avoid EMC problems, the product must be in­stalled according to the currently valid EMC installation guidelines.

To meet the CE norms, enclosed EMI-cores should be applied to the Y/C and
power cable (please refer to chapter 7.1).

General information

6

Siemens Building Technologies
Fire Safety & Security Products 08.2006

1.3 Manufacturer's declaration of conformity

This product complies with the requirements of the European Directives
89/336/EEC “Directive of Electromagnetic Compatibility” and 73/23/EEC “Low
Voltage Directive”. The EU declaration of conformity is available to the responsible
agencies at:

Siemens Building Technologies
Fire & Security Products GmbH & Co. oHG
D-76181 Karlsruhe

European Directive 89/336/EEC „Electromagnetic Compatibility”

Compliance with the European Directive 89/336/EEC has been proven by testing
according to the following standards:

Emitted interference: EN 61000-6-3

EN 55022 Class B

Interference resis­tance:

EN 50130-4

European Directive 73/23/EEC „Low-Voltage Directive”

Compliance with the European Directive 73/23/EEC has been proven by testing
according to the following standard:

Safety: EN 60950-1

General guidelines

7

Siemens Building Technologies
Fire Safety & Security Products 08.2006

2 General guidelines

z Read instructions:

All the safety and operating instructions should be read before the product is op­erated.

z Retain instructions:

The safety instructions and the instruction manual should be retained for future
reference.

z Heed warnings:

All warnings on the product and in the instruction manual should be adhered to.

z Follow instructions:

All operating and use instructions should be followed.

z Attachments:

Do not use attachments not recommended by the video product manufacturer as
they may cause hazards.

z Water and moisture:

Do not use this video product near water, for example near a bath tub, wash
bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool
and the like.

z Accessories:

Do not place this video product on an unstable cart, stand, tripod, bracket or ta­ble. The video product may fall, causing serious injury to a child or adult, and se­rious damage to the product. Use only with the stand, tripod, bracket, or table
recommended by the manufacturer or sold with the video product. Any mounting
of the product should follow the manufacturer's instructions, and should use a
mounting accessory recommended by the manufacturer.

z Ventilation:

This video product should never be placed near or over a radiator or heat regis­ter.

z Power sources:

This video product should be operated only from the type of power source indi­cated on the marking label. If you are not sure of the type of power supply to
your location, consult your product dealer.

z Power-cord protection:

Power supply cords should be routed so that they are not likely to be walked on
or pinched by items placed upon or against them, paying particular attention to
cords at plugs, screws and the point where they exit from the product.

z Lightning:

For added protection for this video product during a lightning storm, or when it is
left unattended and unused for long periods of time, unplug it from the wall outlet
and disconnect the power supply and cable system. This will prevent damage to
the video product due to lightning and power-line surges.

z Overloading:

Do not overload power supply and extension cords as this can result in a risk of
fire or electrical shock.

General guidelines

8

Siemens Building Technologies
Fire Safety & Security Products 08.2006

z Object and liquid entry:

Never push objects of any kind into this video product through openings as they
may touch voltage points or short-cut parts that could result in a fire or electrical
shock. Never spill liquid of any kind on the video product.

z Servicing:

Do not attempt to service this video product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servic­ing to qualified service personnel.

z Damage requiring service:

Disconnect this video product from the power supply and refer servicing to quali­fied service personnel under the following conditions:

a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by following the operating in-

structions in the instruction manual. Adjust only those controls that are cov­ered by the instruction manual as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified

technician to restore the video product to its normal operation.
e. If the video product has been dropped or the cabinet has been damaged.
f. When the video product exhibits a distinct change in performance this indi-

cates a need for service.

z Replacement parts:

When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer that have the same characteris­tics as the original part. Unauthorized substitutions may result in fire, electric
shock.

z Safety check:

Upon completion of any service or repairs to this video product, ask the service
technician to perform safety checks to determine that the video product is in
proper operating condition.

CAUTION

The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.

CAUTION

The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.

NOTE

Tips and information.

General guidelines

9

Siemens Building Technologies
Fire Safety & Security Products 08.2006

2.1 Operation and storage

z Avoid filming very bright objects (such as lighting fixtures) for an extended pe-

riod.

z Do not operate or store the unit in the following locations:

– Extremely hot or cold places.
– Close to sources of strong magnetic fields.
– Close to sources of powerful electromagnetic radiation, such as radios or TV

transmitters.

– In humid or excessively dusty places.
– Where exposed to mechanical vibrations.
– Close to fluorescent lamps or objects reflecting light.
– Under unstable or flickering light sources.

z Do not attempt to service this unit yourself unless you are authorized to do so.

Opening the camera may expose you to dangerous voltages or other hazards.
Refer all servicing to qualified personnel only.

2.2 Cleaning

Do not touch the imaging surface of sensor. Use a soft cloth moistened with alco­hol to clean the surface if it is touched accidentally.

2.3 Transportation

Use the original packing material or materials of equal quality.

2.4 CMOS characteristics

The following conditions may be observed when using a CMOS camera. These are
inherent in the design and do not stem from any fault in the camera itself.

Vertical smear

This phenomenon occurs when viewing a very bright object.

Patterned noise

This is a fixed pattern, which may appear over the entire moni­tor screen when the camera is operated at a high temperature
or in low luminance environment.

Jagged picture

When viewing stripes, straight lines, or similar patterns, the
image on the screen may appear jagged.

Technical data

10

Siemens Building Technologies
Fire Safety & Security Products 08.2006

3 Technical data

3.1 Dimensions

Fig. 1 Dimensions

3.2 Product specifications

Image area 5.04 mm x 3.78 mm
Pickup elements 720 (H) x 540 (V) pixels 1/3” WD CMOS, PIXIM* D2500
Scanning system PAL: 2:1 interlace V: 50 Hz, H: 15,625 Hz

NTSC: 2:1 interlace V: 59.94 Hz, H: 15,734 Hz
Sync system Internal/ line lock selectable (AC only)
Video output BNC composite, Y/C output, Twisted pair
Lens mount CS mount
Resolution > 500 TV lines (horizontal) @ Y/C output
Gamma correction 0.45, 1.0 selectable
Minimum illumination 0.5 lux @F=1.4 (AGC 30 dB , 50 IRE video output)

Dynanic range 120 dB
S/N ratio > 50 dB
Slow shutter 2X, 4X, 8X, 16X
Gain control Selectable 0, 6, 12, 18, 24 up to 30 dB
Backlight compensation 6 area selectable: Center 1, Center 2, Up Half, Low Half,

Middle Low, Middle High
Privacy zone 1 blocks
Motion detect Motion alarm, level control: selectable 0…255
D/N mode AUTO, COLOR, MONO
D/N level HIGH, MID, LOW
D/N DLY 0, 5, 10, 15, 20 selectable
Digital zoom 4 x (max.)
Aperture correction HIGH, MID, LOW
White balance AUTO: Color temperature ranges are depending on

preset mode.

Manual: 40 steps by push button for R and B

Technical data

11

Siemens Building Technologies
Fire Safety & Security Products 08.2006

Iris control DC iris for galvano lens
Camera text 24 characters
OSD control 5 control keys on the side-panel of camera
Default settings Preset: IN Door (2900 °K – 6500 °K), OUT Door

(2900 °K – 9500 °K)
Default settings Default setting restored by pushing the DEFAULT button
Remote control RS-485: Siemens-B/ -S/ -U protocol, MOLYNX-D
Twisted Pair Video Twisted Pair Video out
Alarm IN 1CH
Alarm OUT NC, BW, OUT selectable
Tripod thread A (1/4); ¼ inch on bottom and top
Power source

CCWC1345-LX:

DC 12 V ±10% regulated power supply

AC 24 V ±10%, 50/60 Hz
CCWC1345-MX:

AC 100 - 240 V ±10%, 50/60 Hz
Power consumption CCWC1345-LX: 4 VA (max.)
CCWC1345-MX: 4.5 VA (max.)
Ambient conditions -10 - +55 °C / 95% max relative humidity,

no condensation
Dimensions in mm 122 (L) x 72 (W) x 63 (H)
Weight 550 g (max.)

*) PIXIM and Digital Pixel System are registered trademarks of PIXIM, Inc. All
rights reserved.
