Side-Power SE 60/185 S2 Installation And User Manual

Made in Norway

©

Sleipner Motor AS 2019

SLEIPNER MOTOR AS

P.O. Box 519 N-1612 Fredrikstad Norway www.side-power.com

SIDE-POWER

Thruster Systems

Document id:

Revision:

Date:

5693

2

Installation Manual & User Manual

SE 60/185 S2

2 019

2

5693

2 2 019

-

SE60/185 S2

SAMSVARSERKLÆRING

Sleipner Motor AS P.O. Box 519, Arne Svendsensgt. 6-8 N-1612 Fredrikstad, Norway

Erklærer at dette produktet med tilhørende standard kontrollsystemer er i samsvar med helse, og sikkerhetskravene i henhold til:

DIRECTIVE 2013/53/EU DIRECTIVE 2014/30/EU DIRECTIVE 2014/35/EU

DECLARATION OF CONFORMITY

Sleipner Motor AS P.O. Box 519, Arne Svendsensgt. 6-8 N-1612 Fredrikstad, Norway

Declare that this product with accompanying standard control systems complies with the essential health and safety requirements according to:

DIRECTIVE 2013/53/EU DIRECTIVE 2014/30/EU DIRECTIVE 2014/35/EU

FREDRIKSTAD, 20th of January 2018

Arne K Skauen Managing Director, Sleipner Motor AS

MC_0020

Installation instructions

Technical specications ............................................................. 3

Planning & important precautions.............................................. 4

Thruster installation

Gear Leg & Motor Bracket Installation ...................................... 5

Propeller Installation .................................................................. 6

Motor Installation ....................................................................... 7

Thruster Electrical Installation ................................................... 8

Electrical Specications ............................................................. 9

Control Panel Cable Installation .............................................. 10

Wiring Diagram ................................................................... 11-12

Control Panel Installation......................................................... 13

Checklist for DC and IP Thrusters ........................................... 14

Important Thruster User Considerations and Precautions ...... 15

How to use Side-Power thrusters ............................................ 16

Maintenance ............................................................................ 17

Trouble shooting SE ................................................................ 18

Warranty statement ................................................................. 19

Parts List.................................................................................. 20

Contents

EN

3

5693

2 2 019

-

SE60/185 S2

Technical specications

EN

METRIC

IMPERIAL

Motor: Custom made reversible DC-motor.

Gearhouse: Seawateresistant bronze. Ball bearing at

propeller shaft and combination of ball bearing and slide bearing at driveshaft. Pre-lled and sealed for life Motor bracket: Glass bre reinforced composite material. Brass thread inserts.

Tunnel: Cross spun with rowing G.R.P tunnel Steel and aluminium tunnels are available on request.

Propeller: 5-blade skewback design "Q-prop" propeller, reinforced composite.

Batteries: Minimum recommended battery capacity (cold crank capacity by DIN/SAE standard) See table

Max. use: S2 = 3 min. or approx. 7-10% within a limited time frame.

Safety: Electronic time-lapse device protects against sudden change of drive direction. Electric thermal cut-o󰀨 switch in electromotor protects against over heating (auto reset when electro motor cools down). Shearpin between electro-motor and driveshaft protects electromotor and gear system if propeller gets jammed.

If original Sidepower panel is used, the panel

shuts o󰀨 automatically 6 minutes after last use.

Integrated microprocessor monitors solenoids, reducing wear and risk of solenoid lock-in. Auto stop of thruster in case of accidental solenoid lock-in or if run signal is continuous for more than 3 minutes.

C

Waterline

A

F

SE60/185S2

Thrust [lbs] 132

A [in] 7,3

B [in] 10,5

Cmin. [in] 5,91

D [in] 4,5

D recommended [mm] 9,2

Fmin. [in] 0,16

Fmax. [in] 0,24

Motor output [Hp] 4

Voltage [V] 12/24

Weight [lbs] 35

Note: Emin.: wall thickness of a standard Sidepower tunnel Emax.: maximum wall thickness when using other GRP,

steel or aluminium tunnels

SE60/185S2

Thrust [kg] 60

A [mm] 185

B [mm] 268

Cmin. [mm] 150

D [mm] 115

D recommended [mm] 234

Fmin. [mm] 4

Fmax. [mm] 6

Motor output [kW] 3,1

Voltage [V] 12/24

Weight [kg] 16

Note: Emin.: wall thickness of a standard Sidepower tunnel Emax.: maximum wall thickness when using other GRP,

steel or aluminium tunnels

4

5693

2 2 019

-

SE60/185 S2

It is the installers responsibility

When installing Side-Power equipment to follow the outlined regulations/ classi cation rules (electrical/ mechanical) according to

international or special national regulations. Instructions in this guide cannot be guaranteed to comply with global electric/ mechanic

regulations/ classi cation rules.

It is the installers responsibility

To follow all health and safety laws in accordance with their counties outlined regulations/ classi cation rules.

Before installation, it is important that the installer reads this guide to ensure necessary acquaintance with this product.

The recommendations made in this manual are guidelines ONLY, and Sleipner Motor AS (Side-Power) strongly recommend that

before installation, advise is obtained from a naval architect familiar with the particular vessel and regulations/ classi cations.

This manual is intended to support educated/ experienced sta󰀨 and is therefore not suﬃ cient in all details for professional

installation. (NB: These instructions are only general instruction. If you are not skilled to do this work, please contact professional

installers for assistance.)

All electrical work must be done by a licensed professional.

IMPORTANT

Faulty installation of the tunnel, thruster or panel will render all warranty given by Sleipner Motor AS void.

MC_0038

MC_0005

Thruster Installation Considerations and Precautions

EN

Before installation, it is important that the installer reads this guide to ensure necessary acquaintance with this product.

• The electromotor must be handled with care. Do not lift it by internal connections/ main terminals or bed placed down on the driveshaft.

DC Thrusters:

• The thruster must NOT be installed in compartments that require ignition proof electric equipment. If necessary, make a separate compartment. (NB: If installing an IP assembly, it has been tested to be fully ignition protected so that it can be installed in areas with possible

explosive gases in accordance with ISO 8846)

• The electromotor will generate some carbon dust so any storage compartment must be separated from the thruster to prevent nearby items from becoming dusty/ dirty.

DC Ignition Protected Thrusters:

• If there is a problem with your Ignition Protected stern thruster, please contact your dealer.

• NEVER Disassemble any part of the Ignition Protected stern thruster assembly. Tampering with the Ignition Protected stern thruster assembly or any attempt to disassemble anything on this thruster assembly inside the boat can cause an explosion with severe consequences.

IMPORTANT

If installing S-link products DO NOT connect any other control equipment to the S-link controlled products except Side-Power original

S-link products or via a Side-Power supplied interface product made for interfacing with other controls. Any attempt to directly control or

at all connect into the S-link control system without the designated and approved interface will render all warranties and responsibilities

for the complete line of Side-Power products connected void and null. If you are interfacing by agreement with Sleipner and through a designated Side-Power supplied interface, you are still required to also install at least one original Side-Power control panel to enable

eﬃ cient troubleshooting if necessary.

5

5693

2 2 019

-

SE60/185 S2

MC_0001

Gear Leg & Motor Bracket Installation

! Please refer to the graphic for special considerations relating to your model !

EN

1. Mark the tunnel centreline and the boat’s centreline. (NB: install the gear leg and propeller(s) as shown above for the thrust direction

to correspond with the control panel. If installing a twin propeller, place gear leg with the P-mark facing port and the S-mark facing starboard.)

2. Use the gasket or template (recommended) to mark the centre of the holes and double check the measurements. One hole MUST be placed with the boat centreline as its centre as shown above. (NB: All holes must be in-line with the tunnels’ centreline for correct installation, as the

clearance between the propeller and the tunnel is minimal.)

3. There must be no casting where the motor bracket is to be installed, as this will cause possible failure to the gear leg. The motor bracket must rest

steady on the tunnel. If the tunnel is not smooth, all bumps or uneven parts must be ground ﬂ at.

4. Drill the main-hole and then the screw-holes.

5. Place the gear leg in the tunnel (without the propeller) with the gasket inside the tunnel. Place the propeller(s) to ensure it is in the centre of the

tunnel and rotates freely with the same clearance from each blade to the tunnel wall. If propeller(s) rotate o󰀨 centre, try to use the other or both

gaskets.

6. Apply MS Polymer sealant or equal to both sides of the gasket, and then run the gear leg shaft through the central hole in the tunnel. Install the gear leg and motor bracket gently together. Use suited sealant to ensure that no leakages occur. (NB: See your sealant datasheet for the correct

application process.)

7. Fasten the gear leg and the motor bracket with the bolts provided. Fasten to torque as shown above.

MG_0027

TUNNEL CENTRELINE

Ø 8.5 mm

0.33”

Ø 28.5 mm

1.1”

Ø 23mm

0.91”

BOATS

CENTRELINE

TUNNEL CENTRELINE

BOATS

CENTRELINE

BOW

1 2 - 4 5

6

7

Fasten bolts 17Nm (12,4lb/ft)

Apply MS Polymer sealant or equal to both sides of the gasket

Measure the drive shaft has come through the motor bracket at the correct height with the template enclosed

6

5693

2 2 019

-

SE60/185 S2

Propeller Installation

EN

1. Centre the drive pin on the propeller shaft and rotate the shaft, so the pin is in a horizontal state.

2. Insert the propeller onto the shaft and rotate the propeller until the drive pin aligns into the slot/ groove in the propeller.

(NB: Installation requires almost no gap (approximately 1mm) between the propeller and the gear leg.)

3. Insert the washer on the propeller shaft and fasten the propeller lock-nut. (NB: Ensure the propeller turns freely.)

4. Insert the anode to the end of the propeller and fasten the anode holding screw. Apply a thread glue (Loctite or similar) to ensure that the anode

holding screw does not un-screw itself from during the rotation of the propeller.

MC_0018

! Please refer to the graphic for special considerations relating to your model !

MG_0028

Anode holding screw

Anode

lock nut

washer

propeller

drive pin

7

5693

2 2 019

-

SE60/185 S2

Motor Installation

EN

1. Insert drive pin on the motor shaft and insert the coupling to the motor shaft.

2. Install the motor onto the motor bracket ensuring both the couplings and the drive shafts have locked together. (NB: depending on your coupling

you may need to wiggle the motor into place. Ensure the connection couplings are engaging correctly. The motor can be placed in all directions on the motor bracket. However, ensure the cable terminals are accessible for electrical installation later.)

3. Fasten the motor loosely to the motor bracket with the provided bolts. (NB: If you are installing the motor at an angle of more than 30º oﬀ

vertical, the motor will require separate/ additional support.)

4. Fasten the bolts holding the motor to the motor bracket with the above torque.

5. Check the drive shafts engage by rotating the propeller. It is required the propeller can rotate via hand power. (NB: Rotating the propellers can

be hard because of the gear reduction and the motor.)

6. Apply the gear leg and propeller with antifouling designed for propellers. Do not apply to the propeller drive shaft, the anodes or the end of the gear leg facing the propellers.

Only in shallow installations in workboat and  shing boats we recommend protecting the propeller by installing a grid in the tunnel opening. (NB: Keep

the grid conﬁ guration to a minimum to ensure water ﬂ ow for the thruster is not signiﬁ cantly aﬀ ected. Be aware that any grid conﬁ guration will change the eﬀ ectiveness of the thruster and circular proﬁ le steel will decrease thrust signiﬁ cantly.)

(NB: The motor must be covered to avoid dust from fabrication/ maintenance operation entering the motor or the solenoids. After fabrication maintenance operations have ceased the cover must be removed before operating the thruster.)

MC_0043

! Please refer to the graphic for special considerations relating to your model !

MG_0029

1

2 - 3

4

Drive pin

Coupling

Motor coupling

Gasket

Turn gear leg shaft so the motor coupling will fit

Top

Bottom

Fasten bolts 17Nm (12,4lb/ft)

8

5693

2 2 019

-

SE60/185 S2

MC_0035

Thruster Electrical Installation

EN

IMPORTANT

Check the following with the main switch set to oﬀ :

After all electrical connections have been completed check with an ohm meter that there is no electrical connection between

1. electro-motor ﬂ ange and the positive terminal on the motor

2. electro-motor ﬂ ange and the battery negative terminal on the motor

If unsure contact skilled personnel.

1. Explanation of electrical table. see next page

- All cable lengths are the total of + and - (to and from).

- Battery size is stated as minimum cold crank capacity, not Ah.

- Use slow fuse rated to hold stated Amp-Draw for min. 5 minutes. * Cable size and main battery size when an extra bow battery with minimum the CCA mentioned as A is installed.

2. Use appropriate sized cables and batteries with a high cranking capacity to feed the thruster. The actual voltage at the motor while running the thruster decides the motors output RPM and thrust. You can use larger cables for better results.

- Advised minimum cables and batteries sizes. See next page.

3. Connect the battery supply to the thruster or control unit (PPC).

- Install a main manual/ automatic switch that can take the load without noticeable voltage drop from the positive lead terminal on the battery

to the thruster (or PPC unit). The main switch must be accessible to turn o󰀨 the thruster independently from the rest of the electrical operation

of the vessel when not onboard or in emergencies. (NB: It is advised to install a fuse after the main switch on the positive cable for protection against short-circuiting of the main cables. The fuse should ensure no voltage decrease, slow-blow and sized to take the amperage draw for at least 5 minutes.)

- A circuit breaker can be used instead of the fuse and main power switch If the functionality is the same.

4. Remember to use ignition protected fuses and switches if  tted in areas that require this feature. (NB: For Ignition Protected installations)

5. Cables must have adequate isolation against contact with anything but the lead terminal on the battery and  tted with cable ends.

6. Fasten cables to the required torque. see next page

! Please refer to the graphic for special considerations relating to your model !

MG_0019

Thuster

Motor

Battery

12V or

24V

Fuse

Main

switch

Nut

Tighten to

15Nm/ 11lb/ft

Nut

Tighten to

15Nm/ 11lb/ft

washers

Lugs

++

--

IMPORTANT

Do NOT use washers between lugs

and terminals, this can cause

overheating. Washers must be placed in

the outer position before tightening nut.

Electrical Speci cations

EN

MC_0044

Model Voltage

Nominal current

draw

Min. battery

CCA

Rec.

fuse

<7m total + & - 7-14m total + & - 15-21m total + & - 22-28m total + & - 28-35m total + & - 36-45m total + & -

Min. Rec. Min. Rec. Min. Rec. Min. Rec. Min. Rec. Min. Rec.

SE20/110S 12 V 150 A

DIN: 200

ANL

150

mm2 25 35 35 50 50 70 70 95 95 95 2 x 95 2 x 120

SAE:380 AWG 1 1 1 1/0 1/0 2/0 2/0 3/0 3/0 3/0 2 x 3/0 2 x 4/0

SE25/110S 12 V 200 A

DIN: 200

ANL

150

mm2 25 35 50 50 70 70 95 95 120 120 2 x 70 2 x 70

SAE:380 AWG 1 1 1/0 1/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 2/0 2 x 2/0

SE30/125S 12 V 245 A

DIN: 200

ANL

150

mm2 35 50 50 70 70 95 95 120 120 2 x 70 2 x 70 2 x 95

SAE:380 AWG 1 1/0 1/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 2/0 2 x 2/0 2 x 3/0

SE40/125S 12 V 315 A

DIN: 300

ANL

250

mm2 35 50 70 95 95 120 120 2 x 70 2 x 95 2 x 95 2 x 120 2x 120

SAE: 570 AWG 1 1/0 2/0 3/0 3/0 4/0 4/0 2 x 2/0 2 x 3/0 2 x 3/0 2 x 4/0 2 x 4/0

SE50/140S

12 V 370 A

DIN: 350

ANL

250

mm2 50 50 70 95 120 2 x 70 2 x 70 2 x 95 2 x 95 2 x 120 2 x 120 2 x 120

SAE:665 AWG 1/0 1/0 2/0 3/0 4/0 2 x 2/0 2 x 2/0 2 x 3/0 2 x 3/0 2 x 4/0 2 x 4/0 2 x 4/0

24 V 170 A

DIN: 175

ANL

150

mm2 25 25 25 35 35 50 35 50 50 70 70 70

SAE: 332 AWG 1 1 1 1 1 1/0 1 1/0 1/0 2/0 2/0 2/0

SE60/185S

12 V 370 A

DIN: 350

ANL

250

mm2 50 50 70 95 120 2 x 70 2 x 70 2 x 95 2 x 95 2 x 120 2 x 120 2 x 120

SAE:665 AWG 1/0 1/0 2/0 3/0 4/0 2 x 2/0 2 x 2/0 2 x 3/0 2 x 3/0 2 x 4/0 2 x 4/0 2 x 4/0

24 V 170 A

DIN: 175

ANL

150

mm2 25 25 25 35 35 50 35 50 50 70 70 70

SAE: 332 AWG 1 1 1 1 1 1/0 1 1/0 1/0 2/0 2/0 2/0

SE80/185T

12 V 530 A

DIN: 550

ANL

400

mm2 70 70 120 2 x 70 2 x 95 2 x 95 2 x 120 2x 120 2 x 120

340* NA NA

SAE:1045 AWG 2/0 2/0 4/0 2 x 2/0 2 x 3/0 2 x 3/0 2 x 4/0 2 x 4/0 2 x 4/0

24 V 280 A

DIN: 300

ANL

250

mm2 35 35 35 50 50 70 70 95 95 120 120 2 x 95

SAE: 570 AWG 1 1 1 1/0 1/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 3/0

SE100/185T

12 V 740 A

DIN: 750

ANL

500

mm2 95 95 2 x 70 2 x 95 2 x 120

280* 280* 320* NA NA NA NA

SAE: 1425 AWG 3/0 3/0 2 x 2/0 2 x 3/0 2 x 4/0

24 V 340 A

DIN: 400

ANL

325

mm2 50 50 50 70 70 95 95 120 120 2 x 95 2 x 95 2 x 120

SAE: 760 AWG 1/0 1/0 1/0 2/0

2/0 3/0 3/0 4/0 4/0 2 x 3/0 2 x 3/0 2 x 4/0

SE120/215T 24V 420 A

DIN: 450

ANL

325

mm2 70 70 70 70 70 95 95 120 120 2 x 70 2 x 70 2 x 95

SAE: 855 AWG 2/0 2/0 2/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 2/0 2 x 2/0 2 x 3/0

SE130/250T

12V 800 A

DIN: 400

ANL

500

mm2 95 95 2 x 70 2 x 95 2 x 120

- 330* 375* - - - -

SAE: 760 AWG 3/0 3/0 2 x 2/0 2 x 3/0 2 x 4/0

24V

340 A DIN: 400

ANL

325

mm2 35 50 50 70 70 95 95 95 120

-

2 x 95

-

(350 A) SAE: 760 AWG 1 1/0 1/0 2/0 2/0 3/0 3/0 3/0 4/0 2 x 3/0

SE150/215T 24V 610 A

DIN: 560

ANL

500

mm2 70 70 95 95 120 120 2 x 95

-

2 x 95

-

2 x 120

-

SAE: 1064 AWG 2/0 2/0 3/0 3/0 4/0 4/0 2 x 3/0 2 x 3/0 2 x 4/0

SE170/250 24V 550 A

DIN: 560

ANL

400

mm2 70 70 70 95 95 120 120 2 x 95 2 x 95

-

2 x 120

-

SAE: 1064 AWG 2/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 3/0 2 x 3/0 2 x 4/0

SE210/250 24V 500 A

DIN: 700

ANL

400-500

mm2 70 70 70 95 95 120 120 2 x 70 2 x 70 2 x 95 2 x 95

-

SAE: 1330 AWG 2/0 2/0 2/0 3/0 3/0 4/0 4/0 2 x 2/0 2 x 2/0 2 x 3/0 2 x 3/0

SE250/300 24V 610-670 A

DIN: 700

ANL

500

mm2 70

-

95 120 120 2 x 95 2 x 95 (350CCA) 2 x 95 (400CCA) 2 x 120 (400CCA)

SAE: 1330 AWG 2/0 3/0 4/0 4/0 2 x 3/0 2 x 3/0 (665CCA) 2 x 3/0 (760CCA) 2 x 4/0 (760CCA)

SE300/300

24*2

400-450A (48V)

DIN: 400

ANL

325

mm2 50

-

50 70 70 95 95 120 120 120 140

-

48V SAE: 760 AWG 1/0 1/0 2/0 2/0 3/0 3/0 4/0 4/0 4/0 4/0

9

5693

2 2 019

-

SE60/185 S2

10

5693

2 2 019

-

SE60/185 S2

Control Panel Cable Installation

EN

• All standard Sidepower control panels can be used in any combination as well as any two-way switching device when installed with an ON/OFF switch that breaks control power to this switch.

• As many control panels can be installed using optional Y-connectors or T-connectors if installing an S-link system. (NB: If two or more control panels

are operated at the same time in opposite directions, the electronic control box will stop the thruster until it receives a single signal or thrust

in one direction.)

• When using original Sidepower equipment it is entirely “plug & go” and no additional con guration setup is required.

• All controls must have spring load for automatic return to neutral position.

(NB: If the drive direction of the thruster is running opposite to the control panel, the electronic control box rotated 180 in its clip to swap the blue and grey wire on the thruster solenoid.)

Pin con guration of 4 pole AMP contact:

Pin1: BLACK = Ground Pin2: BLUE = Engages thruster SB solenoid Pin3: GREY = Engages thruster Port solenoid Pin4: RED = Positive voltage for the control panel

MC_0041

! Please refer to the graphic for special considerations relating to your model !

MG_0024

Thuster

Motor

Ext. cable

4- or 5-lead

Y cable

4- or 5-lead

1

Timer

(Direction)

SIDE-POWER ‘on-off’

control panel

(ON)

2 3

blue (STB)

grey (PORT)

red

yellow

black

Ext. cable

4- or 5-lead

Option: Automatic main switch. connects the battery to the thruster. Operated from the control panel(s). Requires 5-lead control cables.

MG_0031

After all electrical connections have been completed check with an ohm meter that there is no electrical connection between electro motor body and positive terminal on the motor and between the electro motor body and the negative (A1) terminal on the motor. If you feel unsure on how to perform this check, contact skilled personnel for guidance.

6 1265 5-LEAD Y-CONNECTOR

6 1265

5-LEAD

Y-CONNECTOR

6 1278-xxM 5-LEAD CONTROL CABLE

6 1277-xxM 4-LEAD CONTROL CABLE

STERN

BOW

STERN

BOW

STERN

6 1278-xxM 5-LEAD

CONTROL CABLE

Switch

5A fuse

Switch

5A fuse

Common negative

10A fuse

+

-

+

-

IMPORTANT!

Common negatvie MUST be wired when using control panel 8940 and 8909C if separate battery banks are installed. (Bow and Stern thtrusters combined)

6 1274 4-LEAD Y-CONNECTOR

STERN

BOW

STERN

BOW

STERN

xA fuse

6 1277-xxM 4-LEAD

CONTROL CABLE

6 1277-xxM 4-LEAD CONTROL CABLE

6 1274 4-LEAD Y-CONNECTOR

xA fuse

Common negative

10A fuse

+

- -

IMPORTANT!

Common negatvie MUST be wired when using control panel 8940 and 8909C if separate battery banks are installed. (Bow and Stern thtrusters combined)

With Automatic Main Switch:

With Manual Main Switch:

11

5693

2 2 019

-

SE60/185 S2

MG_0031

After all electrical connections have been completed check with an ohm meter that there is no electrical connection between electro motor body and positive terminal on the motor and between the electro motor body and the negative (A1) terminal on the motor. If you feel unsure on how to perform this check, contact skilled personnel for guidance.

6 1265 5-LEAD Y-CONNECTOR

6 1265

5-LEAD

Y-CONNECTOR

6 1278-xxM 5-LEAD CONTROL CABLE

6 1277-xxM 4-LEAD CONTROL CABLE

STERN

BOW

STERN

BOW

STERN

6 1278-xxM 5-LEAD

CONTROL CABLE

Switch

5A fuse

Switch

5A fuse

Common negative

10A fuse

+

-

+

-

IMPORTANT!

Common negatvie MUST be wired when using control panel 8940 and 8909C if separate battery banks are installed. (Bow and Stern thtrusters combined)

6 1274 4-LEAD Y-CONNECTOR

STERN

BOW

STERN

BOW

STERN

xA fuse

6 1277-xxM 4-LEAD

CONTROL CABLE

6 1277-xxM 4-LEAD CONTROL CABLE

6 1274 4-LEAD Y-CONNECTOR

xA fuse

Common negative

10A fuse

+

- -

IMPORTANT!

Common negatvie MUST be wired when using control panel 8940 and 8909C if separate battery banks are installed. (Bow and Stern thtrusters combined)

With Automatic Main Switch:

With Manual Main Switch:

12

5693

2 2 019

-

SE60/185 S2

MG_0032

NB!

Make sure to not use any electronic interface box (delay box) older

than the 6 1232i (ex. 6 122x)

Battery

12/ 24 V

+

thruster

motor

c

A1

(B-)

Battery

main switch

Main fuse

D2

red

black

blue

grey

Timer

red

9-way socket

1A (PTC)

Control box

6 1232i

(simplified)

AMP

connector

Control

panel

On

1234

987654321

859247136

brown

white

blue

grey

red

D1

thruster

solenoid

B+

A2

13

5693

2 2 019

-

SE60/185 S2

Control Panel Installation

EN

Find a comfortable location for the control panel where it does not obstruct or is obstructed by other controls. Install the control panel where it is easy to use. (NB: As a guide the side thruster if often operated together with the gear/throttle control. For the optimal user-friendly solution install the control panel where access to both controls is accessible with one hand for each control.

1. Use the enclosed cut-out template to mark the area to remove on your control dash.

2. Cut out the area per template for the control panel. (NB: If the front surface around your cut out is jagged or chipped, use a sealant

to assist the gasket.)

3. Place the gasket to the back face of the panel

4. Plug cables into the connectors at the rear of the control panel. (NB: Twist the locking ring on the connector clockwise to secure connector.)

5. Insert the control panel in place and fasten screws.

6. insert the control panels covering caps.

MC_0042

! Please refer to the graphic for special considerations relating to your model !

MG_0026

50,5mm

38,4mm

Ø52

61,1mm

111,1mm

This way Up!

Cut-Out Template

double joystick panel - 8940

Cut out area:

Ø 51,8 mm / 2"

61,0 mm / 2,4"

61,0 m m / 2,4 "

For control panels 8950 / 8960

Ø 3,0 mm / 0,12"

For control panels 8955/8965/8990

Ø 2,5 mm / 0,10"

53,0 mm / 2,09"

Cut out area:

Ø 51,8 mm / 2"

(4) COVERING CAPS

CONTROL PANEL TEMPLATES

(4) COVERING CAPS

COVERING CAP

GASKET

CABLES

GASKET

(4) SCREWS

14

5693

2 2 019

-

SE60/185 S2

MC_0033

Checklist for DC and IP Thrusters

EN

�.......... Propeller is fastened correctly to the shaft.

�.......... Propeller turns freely in tunnel.

�.......... The anode holding screw is tightened well with thread glue.

�.......... Anti-fouling have been applied to the gearhouse and propeller but NOT on the anode or the

gearhouse lid where the propeller is fastened.

�.......... Correct drive direction as per controlpanel.

�.......... The bolts holding the gearhouse and motorbracket together are tightened correctly.

�.......... The bolts holding the motor to its bracket are tightened correctly.

The thruster has been installed as per the instructions in this manual and all points in checklist above have been controlled.

Signed: .........................................................................................

Date: .............................................................................................

Extra pre-delivery tests by installer / yard who does not use other quality control systems !

Thruster type: ................................................................................................................................................................................................

Serial number:...............................................................................................................................................................................................

Date of delivery:.............................................................................................................................................................................................

Correct drive direction as per controlpanel: ..................................................................................................................................................

The compartment for the thruster has been isolated from general bilge water and has no obvious or suspected risks for ﬂ ooding:

......................................................................................................................................................................................................................

Other comments by installer: ........................................................................................................................................................................

.......................................................................................................................................................................................................................

......................................................................................................................................................................................................................

15

5693

2 2 019

-

SE60/185 S2

MC_0004

Important Thruster User Considerations and Precautions

EN

• Ensure you know the location of the main battery switch that disconnects the thruster from all power sources (batteries) so the thruster can

be turned o󰀨 in case of a malfunction.

• Always turn the main power switch o󰀨 before touching any part of the thruster, as an incidental start while touching moving parts can cause serious

injuries.

• Always turn the control device o󰀨 when the thruster is not in use.

• The maximum continues run time of the electrical thruster is approximately 3 minutes. The electromotor has a built-in thermal cut-o󰀨 switch that will shut o󰀨 the electro-motor if it is overheating and re-engage when it has cooled down. Consider this when planning your manoeuvring.

• As above this also means that the thruster will limit its total running time per period so that you can not count on the thruster to hold you in a current and side wind for extensive periods. Depending on the surrounding temperatures etc. the thruster will be able to run approximately 10 % of the time.

• Never use a thruster close to objects/ persons or animals in the water, as the thruster will draw objects into the tunnel and contact with the rotating propellers will cause serious injuries and damage the thruster.

• With the boat on land, only run the thruster for a fraction of a second, as without resistance it will accelerate very fast to a damaging rpm.

• While the thruster is in the air, make sure that the propellers have come to a complete stop before performing a directional change of the thruster, as it might cause damage to the thruster.

• If the thruster stops giving thrust while the electro-motor is running, there is possibly a problem in the drive system. You must immediately

stop trying to run the thruster and turn it o󰀨 . Running the electromotor for more than a few seconds without resistance from the propeller, can cause

serious damage to the electromotor.

• When leaving the boat always turn o󰀨 the main power switch for the thruster.

• We advise keeping the main engine(s) running while using the thruster. As this will keep the batteries in a good charge condition. It will also give better performance to the thruster, as a higher voltage at the thruster results in a higher torque (power) in the electromotor.

• Please note that the performance of a thruster strongly depends on the voltage available at the electromotor. This voltage will decrease over time

because ageing batteries will have reduced capacity. By installing new batteries the e󰀨 ect of the thruster should be back at the original level.

• Make sure that only one control is used at the same time, if two panels are operated in opposite directions at the same time the thruster will not run. If both are operated in the same direction, the thruster will run in this direction.

• If the thruster is not performing or functioning as usual, the cause must be found and corrected as soon as possible to avoid causing any other or

further damage to the equipment. You must also turn o󰀨 the main battery switch immediately in case the problem is of electric origin.

• Never store items (e.g. equipment, sails, ropes etc.) in the same compartment as the thruster. When the thruster runs for an extended period, it can reach 100°C and will cause damage to nearby items. The electromotor will generate some carbon dust so any storage compartment must be separated from the thruster to prevent nearby items from becoming dusty/ dirty. Do not store items close to the thruster motor as it can reach 100°C. Any loose items near the thruster motor can cause problems with electrical wiring coming loose and short-circuiting.

• The electromotor, its components, contacts/ plugs or other joints in the control cables must be mounted so they will remain dry at all times.

• It is the owner/ captain/ other responsible parties full responsibility to assess the risk of any unexpected incidents on the vessel. If the thruster stops giving thrust for some reason while manoeuvring you must have considered a plan on how to avoid damage to persons or other objects.

• The primary purpose of the thruster is to manoeuvre/ dock the vessel. Forward/ reverse speed must not exceed 4 knots when operated.

IMPORTANT

Failure to follow the above precautions can cause serious injury / damage and will render all warranty given by Sleipner

Motor AS void.

16

5693

2 2 019

-

SE60/185 S2

How to use Side-Power thrusters

EN

How to use a bowthruster

1. Turn main power switch for the bowthruster on. (Always turn o󰀨

the main power switch when not onboard.)

2. Please take some time to exercise thruster usage in open water to avoid damages to your boat.

3. Turn the control panel on by pushing both “ON” buttons on the original Sidepower panel simultaneously. If another type of control

is installed, engage the On/O󰀨 switch for the bowthruster.

4. Turn the bow in the desired direction by pushing the red button for port movement or the green button for starboard movement. If you have a joystick control, move it in the direction you wish the bow to move. Other controls like footswitches or toggle-switches on the throttle can be used. These are normally logically installed, so by engaging the port control, the bow goes port etc. In case of

any doubts, try in open waters  rst.

5. Depending on the sideways speed of the bow, you must disengage the control device shortly before the bow is in the desired direction, as the boat will continue to move after stopping the bowthruster.

How to use a single stern thruster

Some boats might however have installed a single stern thruster because of space limitation in the bow. In this case the stern thruster is used in the same way as a single bow thruster (see above) for moving the boat’s stern.

How to use a bow and stern thruster combined

The combination of a bow and stern thruster o󰀨 ers total

manoeuvrability to the boat and the opportunity to move the bow and the stern separately from each other. This enables you to move the boat sideways in both directions and to turn the boat around its own axis staying at the same place.

• Again, if in doubt, try in open water  rst!

Turn boat to port

Turn boat to starboardTo turn panel OFF

To turn panel ON

Bow+Stern

Thruster

Turn boat to port (Stern)

Turn boat to starboard (Stern)

17

5693

2 2 019

-

SE60/185 S2

Maintenance

EN

Electromotor Directional solenoids Motorbracket for holding motor and

gearhouse together on the tunnel. Breakpin secures the electromotor if

propeller is jammed. Changeable from inside the boat.

5-blade skew propeller for ultimate performance.

Prelled lifetime lubricated gearhouse.

Changeable anode protects gear-house from corrosion in seawater.

7

4

5

6

1

3

2

» Retighten the bolts holding the gearhouse to the motor bracket during the rst on-land service with the specied bolt tightening force.

» Keep the propeller and gearhouse clean from growth by painting with antifouling before every season.

PS! The anode, sealing and propeller shafts must absolutely not be painted. Be careful that you don’t ll paint in the “tracks” in the gearhouse that the

propeller hub moves in.

» Change the anode before every season, or when about half the anode is gone. Always use a sealant on the screw holding the anode to ensure that

it does not fall o󰀨. Please observe that in some waterconditions it can be necessary to install an extra anode to ensure that it lasts for the whole

period between regular service lifts of the boat. Consult your dealer for information on how to do this.

» As a part of the seasonal service of your boat, and before every season, always check that:

• The propeller is securely fastened

• The bolts holding the electric motor to the motor bracket are fastened correctly.

• The area where the thruster is installed is clean and dry. If there are signs of water you must try to nd the source and eliminate it.

• All electrical connections are clean and fastened rmly.

• Make sure that your batteries are in a good condition so that the thruster gets a good voltage. Old or bad batteries will give a reduced performance from the thruster.

5

34

1

2

Locktite

SE60/185S

Fastening screw for anode Anode Propeller lock nut Washer Drivepin for propeller

4

5

1

3

2

1

3

4

2

5

7

6

18

5693

2 2 019

-

SE60/185 S2

Before seeking assistance at the help desk of your Side-Power dealer/distributor please perform these tests and make notes of all measurements to ensure that they have as much information as possible to work on.

NB! All check points and solutions must be carried out after consulting the relevant information elsewhere in this manual to under-stand how the system is intended to work. If you are unable to understand what to check, you must consult a professional.

Trouble shooting SE

EN

Solution

Check the ﬂ exible coupling/shear pin and the motor installation to ensure correct connection of the ﬂ exible coupling before re- tting the electromotor.

Re-fasten or replace the propeller and/or key/drive pin.

In case of a failure inside the gearhouse, we advice to get a replacement gear-house instead of attempting to repear the internal gear and bearing system.

If wrong, contact your dealer or distributor to obtain parts with the correct voltage.

The no load voltage should be: 12V system =12,7V / 24V system = 25,4 V. If below 12,3V / 24,6V your batteries are not in a good charge state or worn out and must be recharged or replaced before trying to run the thruster.

If less than 8,5V at the thruster the voltage is to low for the thruster to operate correctly. In a 24V boat the thruster will operate down to approx. 12V, but the performance will be very bad. Find and correct the reason for this low voltage which will probably be one or more of these points: main battery cable sizes and connections, battery size and condition, fuse and main power switch performance.

If the thruster runs in both directions, try the same in the connector that goes into the back of the control panel. If it also works in this position, check the contact and wires on the back of the panel and try to engage this again by pushing both ON buttons simultaneously. If the panel does not turn on (see control light), measure the voltage between the Red and the Black in the contact going into the thruster. If the voltage is good, chances are that the panel is not working. If it works by the thruster, and not by the panel there is a bad contact or a broken lead the control cables between these two test points. Measure that you have the correct voltage between the Red (+) and all the other colours in the contact. If you do not get a reading.

Between main minus (A1 on motor) and the blue and the grey wire connected to the sides of the main solenoids you should have the same voltage as between the main battery cables on the thruster. If not, check that the internal wiring on the solenoid is ok and measure that there is contact through the magnetising spools of each side of the solenoid (measure between the red and blue on one side, and red and grey on the other side with an Ohm meter.). If there is no contact between these, the solenoid is broken and needs replacing.

If less than 10,5 V / 21V the thruster will not perform at speci ed e󰀨 ect.

If one or more brushes are loose/has no tension from the brush-spring, the performance will be low.

If there is growth in the tunnel, this will disturb/block the waterﬂ ow and especially bar-

nacles on the propeller will greatly reduce performance.

Re-charge battery(ies), if this is not suﬃ cient, replace battery(ies).

Check for bad cable connections, if necessary tighten/re-adjust connections. Check cable size in accordance to manual.

Shut o󰀨 thruster main switch, tap slightly on the solenoid to see if it will release. Turn

on thruster main switch. If solenoid is still in lock-in mode, replace solenoid.

Check

If the ﬂ exible coupling between the motor and driveshaft is not  tted correct inside the boat.

Are the propellers in the tunnel fastened correctly on the prop-shaft (key/drive pin present)

With the motor removed, turn the driveshaft from inside the boat to feel if the gears are engaging and turning the prop-shaft.

Check that the voltage of the electromotor is correct for your installation by their labels.

Check the voltage at the thruster between main minus input (A1 on motor) and main plus input point:

Check the voltage at the thruster while you are trying to run it. Keep main engine(s) running to have continous charge to the batteries.

If the main solenoids on the thruster are not even trying to engage (clicking) they are probably not getting a "run" signal from the control system. Try to run the thruster without the panel by directly connecting the red and the blue or the red and the grey wires in the controlcable contact coming from the thruster.

If the thruster does not run at all, or only in one direction in the above tests, check the internal wiring on the thruster motor, solenoids and electronic motor inter-face box to be in accordance with the wiring diagram and ensure that all connections are clean and tight.

Check voltage at thruster when running.

Check that all the brush-springs sits correctly on the brushes in the electromotor.

Check that the propeller, gearhouse and tunnel is free from growth/barnacles etc.

Solenoid ﬂ apping, most probable cause:

low voltage.

Solenoid lock-in, auto stop of thruster, auto retry every 10 seconds.

» The electromotor runs, but there is no thrust.

» The thruster does not start at all or works only in one direction.

» The thruster has an unexpected low performance.

» The thruster runs for approximately 0,5 seconds every 4 seconds.

» The thruster runs for approximately 0,5 seconds every 10 seconds.

19

5693

2 2 019

-

SE60/185 S2

Warranty statement

EN

1. The equipment manufactured by Sleipner Motor AS (The “Warrantor”) is warranted to be free from defects in workmanship and materials under normal use and service.

2. This Warranty is in e󰀨 ect for of two years (Leisure Use) or one year (Commercial use) from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period.

3. This Warranty is transferable and covers the product for the speci ed time period.

4. In case any part of the equipment proves to be defective, other than those parts excluded in paragraph 5 below, the owner should do the following: (a) Prepare a detailed written statement of the nature and circumstances of the defect, to the best of the Owner’s knowledge, including the date of

purchase, the place of purchase, the name and address of the installer, and the Purchaser’s name, address and telephone number; (b) The Owner should return the defective part or unit along with the statement referenced in the preceding paragraph to the warrantor,

Sleipner Motor AS or an authorized Service Centre, postage/shipping prepaid and at the expense of the Purchaser; (c) If upon the Warrantor’s or Authorized Service Centre’s examination, the defect is determined to result from defective material or workmanship, the

equipment will be repaired or replaced at the Warrantor’s option without charge, and returned to the Purchaser at the Warrantor’s expense; (d) no refund of the purchase price will be granted to the Purchaser, unless the Warrantor is unable to remedy the defect after having a reasonable

number of opportunities to do so. Prior to refund of the purchase price, Purchaser must submit a statement in writing from a professional boating equipment supplier that the installation instructions of the Installation and Operation Manual have been complied with and that the defect remains;

(e) warranty service shall be performed only by the Warrantor, or an authorized Service Centre, and any attempt to remedy the defect by anyone else shall render this warranty void.

5. There shall be no warranty for defects or damages caused by faulty installation or hook-up, abuse or misuse of the equipment including exposure to

excessive heat, salt or fresh water spray, or water immersion except for equipment speci cally designed as waterproof.

6. No other express warranty is hereby given and there are no warranties which extend beyond those described in section 4 above. This Warranty is

expressly in lieu of any other expressed or implied warranties, including any implied warranty of merchantability,  tness for the ordinary purposes for which such goods are used, or  tness for a particular purpose, and any other obligations on the part of the Warrantor or its employees and

representatives.

7. There shall be no responsibility or liability whatsoever on the part of the Warrantor or its employees and representatives for injury to any person or

persons, or damage to property, loss of income or pro t, or any other consequential or resulting damage or cost which may be claimed to have been

incurred through the use or sale of the equipment, including any possible failure or malfunction of the equipment, or part thereof.

8. The Warrantor assumes no liability for incidental or consequential damages of any kind including damages arising from collision with other vessels or objects.

9. This warranty gives you speci c legal rights, and you may also have other rights which vary from country to country.

20

5693

2 2 019

-

SE60/185 S2

MC_0037

Notes

EN

..................................................................................................................................................................................................................................................
