Sick KUP-1010-W Data Sheet

Product data sheet

KUP-1010-W

A

B

C

D

E

F

H

I

J

K

L

M

N

O

P

Q

R

S

T

M5x6 DIN916 (2x)

26 (1.02) 50 (1.97)

4.5 (0.18) 17 (0.67)

Ø d1 +0.05

Ø d2 +0.05

KUP-1010-W

Ordering information

Type Part no.

KUP-1010-W 5319914

Other models and accessories www.sick.com/

Detailed technical data

Technical specifications

Accessory group

Accessory family

Description

Specialty

Classifications

ECl@ss 5.0

ECl@ss 5.1.4

ECl@ss 6.0

ECl@ss 6.2

ECl@ss 7.0

ECl@ss 8.0

ECl@ss 8.1

ECl@ss 9.0

ECl@ss 10.0

ECl@ss 11.0

UNSPSC 16.0901

Shaft adaptation

Shaft couplings

Spring washer coupling, shaft diameter 10mm / 10mm, maximum shaft offset, radial ±

0.3mm, axial ± 0.4mm, angle ± 2.5°, torsion spring stiffness 30Nm/rad; material: aluminum
flange, glass-fiber reinforced polyamide membrane and hardened steel coupling pin

Maximum shaft offset:radial +/- 0.3mm, axial +/- 0.4mm, angular +/- 2.5°; max. speed
12,000rpm, –10° to +80°C, max. torque 60Ncm; material:aluminum flange, glass fiber-re­inforced polyamide membrane and hardened steel coupling pin

23031090

23031090

23031090

23031090

23031090

23031090

23031090

23031090

23031090

23031090

31163014

Dimensional drawing (Dimensions in mm (inch))
