Siao Shan Po Life STMS03 Users manual
Stereo Puzzle
User Manual
ST-MS-03
Wireless Speaker
Contents
Chapter 1: Instructions
> Assembly Guides
> Fittings Usage
> How to Connect
Chapter 2: Product Description
> Specications
> Caution
> Simple Solutions of Malfunction
• Not-functioning Problem
• Board Vibration Problem
• Speaker Unit Fall-o Problem
Chapter 3: After-sales Service
> Warranty
> Customer Service
Chapter 1: Instructions
> Assembly Guides
We designed assembly guides of dierent levels, Hard and
Easy ones.
We suggest you to try Hard Level rst, so you can fully
experience the enchantment of this product. :)
> Fittings Usage
Shock-absorbing Rubber Feet
Absorb the shock
Avoid slip
Keep stable
Sound-absorbing Material
Absorb the noise inside the sound box
Make the sound more round and full
Pressure Sensitive Adhesive of 3M Corp.
Stick tightly on the contact surface after being
pressed
Absorb the shock from the speaker unit
Transparent Tape
Attach tightly to the pressure sensitive adhesive so
the speaker unit is xed
> Caution
About Safety
This product contains tiny parts. Children 12 or under using it
must be accompanied by adults to avoid eating by mistake.
Keep this product away from any heat source, such as re,
radiators, heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
Keep this product away from water, rain, and moist place, such
as bathroom.
The input voltage of this product is 5 Volts. Please make sure
your transformer provides proper voltage.
This product contains precision parts. Please handle with care,
avoid tossing, and hold up the bottom while moving.
About Coloring
Please use oily pigment to color your Stereo Puzzle.
Water-based pigments, such as watercolor, are not
recommended.
About Warranty
Do not open the circuit box or change the circuit. Once the
circuit box is open, the product is not covered by the warranty.
Please follow the instructions of this User Manual when using
Stereo Puzzle. In case of violation of the rules, Shanpo team
does not be responsible for any malfunction, damage, and
warranty.
> Simple Solutions of Malfunction
Not-functioning Problem
Q1: My speaker is not working. How do I do?
A1: Please try the solutions below. If the malfunction continues,
please contact customer service.
Symptom of
Malfunction
Lines are not successful
No Sound
connected.
Wrong system settings
Board Vibration Problem
Q2: When playing, there is a high-frequency, continuous noise
from the speaker. How do I do?
A2: Tightly compress the speaker from two sides. If there is no
longer noise, then the noise is caused by the vibration of the
wooden boards. We suggest using the white glue to seal the
sound box or vibrating puzzle pieces up.
SolutionsPossible Causes
Please check “How to
Connect” of this manual.
Choose the correct audio
device in Control Panel
Speaker Unit Fall-o Problem
Q3: I accidentally drop the speaker, and the speaker unit falls
o. How do I do?
A3: Put the speaker unit back, and use the hot-melt adhesive or
the instant glue to stick it back.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for
help.
The more airtight the speaker is, the better the sound eect is.
Thus, you can seal the sound box up by the white glue after
playing a few times, then the sound eect will become more
round and full.
Sealing Steps:
1. Apply the white glue on the puzzle
pieces which make up the sound box
as the picture shows.
2. Piece together, hold the speaker
tightly from two sides, and wipe o the
remnant glue outside the gap.
3. Put weight on the speaker for 1 to 2
hours.
> How to Connect
After assembly, connect the cables or connect by wireless
according to the following instructions, and start to enjoy the
acoustics!
Power Input: 5V, via Micro USB, or 3 AAA-batteries
Sound Input: Bluetooth, or via 3.5mm Jack
> Wireless Speaker
Power Button
Power Input
Sound Input
Turn On : Long press the power button
Turn O : Long press the power button
Next Song : Long press the “+” button
Previous Song : Long press the “-” button
Volume Up : Short press the “+”button
Volume Down : Short press the “-” button
Pair up with your devices: Long press the power button to turn
on, then the light will ash, and you can connect it via
bluetooth with your device. If the speaker is connected with a
device, the light will not ash.
Automatic Power O: If the speaker is disconnected to the
device, it will automatically power o after 10 minutes.
Chapter 2: Product Description
> Specications
Product Name
Model No.
Power
Rated Power Supply
Operating Temperature
Stereo Puzzle - Wireless Speaker
ST-MS-03
3W
DC 5 V;Max Input Current 1 A
-10 ~ 45 °C
Chapter 3: After-sales Service
> Warranty
What is covered?
This warranty covers defective hardware of the product
resulting from manufacturing defects during the warranty
period.
What is not covered?
This warranty does not cover
∆ Defects resulting from (1) natural disasters, such as
earthquakes, lightening stroke, and similar accidents, (2)
misapplication / abuse / negligence, such as dropping the
speaker o, damage by pets, expoture to moisture, excessive
heat and chemical cleaners, (3) any cost or expense related to
the removal or reinstallation of product, (4) previously repaired
or modied by any unauthorized facility, (5) any other
additional component which is not provided by Shanpo team.
∆ Freight Damage.
∆ Return shipping on non-defective items and the cost of
shipping product to Shanpo team.
∆ The damage or missing of additional or expendable parts,
such as the packing, cables, and Assembly Guides.
Warranty Period
The warranty period of Stereo Puzzle is 1 year from the date of
purchase.
What to Do if You Need Warranty Service
Please contact customer service for warranty service.
Before mailing the defective product to us for warranty service,
make sure to take out all the subsidiary which doesn’t belong
to the product. Shanpo team won’t take the responsibility of
the damage or missing of the subsidiary.
> Customer Service
If you have questions or need warranty service, please contact:
(1) Stereo Puzzle Facebook Fanpage:
https://www.facebook.com/StereoPuzzle
(2) Shanpo Team. Customer Service Email:
littlemt.slope.cs@gmail.com
Facebook
Fanpage
Instagram
FCC Caution
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This equipment must be installed and operated in accordance
with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.
