Shuttle XPC Product Overview

Product Overview

2

Compact and stylish

 Only about 13 litres in volume
 Three times smaller than conventional Desktop-PCs
 Stylish design, top-quality workmanship, aluminium cases

Supports powerful Desktop processors

 Supports high-end processors
 Varied choice of processors and chipsets

Simple installation

 Many cables already pre-routed
 Clear installation instructions

Heatpipe cooling system

 Efficient heatpipe cooling system
 Regulated fan speed
 Intelligent airflow control

Wide range of connection options

 High connectivity comparable to large Desktop-PCs
 Supports two hard disks and one optical drive

(standard components)

Welcome to the world of Mini-PCs …

The Shuttle XPC is a fully-fledged Desktop-PC
in a Mini-PC format

3

Introduction to the world of Mini-PCs …

Barebone –
or complete system?
The choice is yours!

What is a barebone?

All Shuttle PC products are available as barebone or complete systems.
Barebones looklike full PCs,but still mustbe fitted withvarious components
(e.g. memory, drives, processor and software) before initial use as shown
in the illustration:

 Processor

 Memory

 Hard disk

 Graphics card*

 Optical drive

 Operating system

Cooling system

+

Power supply unit

+

Cable

+

Mainboard

+

Case




Complete

Shuttle XPC

* Optional depending on XPC model.

4

Shuttle Mini-PCs form basis for top-spec gaming PCs

Shuttle XPCs use the same chipsets and Desk­top components as standard large-format
PCs. Despite the smallcase dimensions,the listed
XPC models support large-format dual-slot
graphics cards with lengths of up to 26.7cm
(for the H series) or 27.3 cm (for the R series).

Example configuration
with the latest high-end components

 Shuttle XPC Barebone SX79R5 Top XPC!

 Intel Core i7-3960X Extreme Edition with 3.46 GHz Top 6-core processor!

 AMD Radeon HD 7970 with 2 GB GDDR5 Top graphics card!

 4x 8 GB DDR3-1333 RAM (total = 32 GB)

 64 GB mSATA-SSD

 2x 4 Terabyte hard disks (total = 8 TB) in RAID 0 or 1

 Blu-ray writer

Mini-PCs are frequently underestimated …

Shuttle Mini-PCs form basis
for top-spec gaming PCs

Doesthebuilt-in power supplyunitsupport my graphics card?

Shuttle usesefficient power supplyunits that arespecifically
tailored to the maximum power requirements of an XPC
and providethe precise performance that they effectively
need. For instance, a 300 W supply unit has the capacity
to power an AMD Radeon HD 7770 graphics card. Shuttle
XPCs offerreliable andstable operation withall thecompo­nents shown in the relevant compatibility lists.
See: http://global.shuttle.com

XPC power supply units and power connectors
for graphics cards

If the power consumption of a graphics card exceeds 75 W, the energy
requirements cannot be met via the PCI-Express slot on its own and the
power supply unit needs to provide one or even two additional power
connectors coupled to relevant graphics cards. You therefore need to
check the power connectors and the compatibility list to find out
whether the desired graphics card is compatible.

Graphics card with one 6-pin power connector Graphics card with two 6-pin power connectors

Single-slot graphics card

Dual-slot graphics card

0

1

0

2

0

3

0

4

0

5

0

6

0

7

0

8

0

9

0

1

0

0

W

5

Nettop or All-in-One

 Slim-PC (only 1.1 to 1.5 litres)
 All-in-One-PC with 39.6 cm (15.6")

or 46.7 (18.5") cm touchscreen

100% fanless

 No fan noise
 Ideal for noise-sensitive areas
 Maintenance-free, passive cooling

Atom dual-core processor

 Intel Atom processor (D2700, D2550 or D525)
 Dual-Core + Hyper-Threading allows for four threads

to be processed simultaneously

 Power consumption only max. 10 to 13 W

Energy-saving

 Consumption only approx. 20-30 W
 Electricity costs only about €12,- per year

based on a normal 8-hour working day

Other compact PC products from Shuttle …

Energy-saving solutions
with Intel Atom processor

Actua l Siz e

6

The ideal addition to any mini-PC …

Your data – securely stored
and available on the go

The uncomplicated network-attached storage system for work groups,
small offices or home use. Make the data on your company or personal
network available to others. Preventdata loss by backing upall important
data at an access-controlled central location.
When did you last REALLY think about the security of your data?

High data security

 In RAID-1 mode a copy of all data is always available

on a second drive

 Backup function enables time-controlled backup copies

onto a third, external drive

Fast data transfer

 Gigabit-LAN ensures almost instantaneous transfer

of large volumes of data

As much storage capacity as you want

 Two internal drives with a total capacity of 8 TB are possible
 Plus, connection capabilities for the latest USB hard disks

and sticks

Mobile access by app

 Free "OMNINAS" app available for iOS and Android
 Password-protected data available on the go via smartphone

or tablet

Technical data Shuttle OMNINAS KD20

Internal drives

2x 3.5" HDD/SSD, SATA 3 Gbit/s
Max. 4 TB per drive (8 TB in total)

Supported RAID modes

0, 1 (hot-swappable), JBOD

Network

1x 10/100/1000 Mbit/s, Gigabit Ethernet
File sharing: SMB, AFP

Additional interfaces

1x USB 3.0, 2x USB 2.0, card reader

Dimensions (DWH)

22.5 x 9 x 16.9 cm

Special features

Basic chassis of high-quality aluminium, low power
consumption, DLNA server, iTunes server, attached
printers can be shared across the network

About Shuttle

Established in Taiwan in 1983, Shuttle Inc. specialises in the development
and production of innovative Mini-PCs. The stock market listed company
is represented globally through subsidiaries in Germany, the USA, China
and Japan. Since 2001 the attractive cuboid PCs designed for virtually
every application area have been themain business area for Shuttle.
New models with state-of-the-art chipsets, new case designs and tech­nical innovations are regularly launched on themarket. The product
range has recently been expanded to include All-in-One-PCs and Slim­PCs (nettops).

Contact details

Shuttle Computer Handels GmbH
Fritz-Strassmann-Str. 5 · 25337 Elmshorn · Germany
Telephone [phone] · Email: [e-mail]

www.facebook.com/Shuttle.Europe

www.youtube.com/SCHgermany

@shuttle_europe

Milestones

2012  Introduction of OMNINAS (NAS solutions)
2012  Shuttle adds 18.5" model to its All-in-One PC product range
2011  Shuttle launches the world's fastest Mini-PC
2010  Shuttle launches its first 1-litre PC (fanless)
2009  Shuttle starts to use new production facilities in China
2009  Shuttle starts development and production of OEM notebooks
2009  Shuttle launches its first All-in-One-PC (fanless)
2008  Shuttle launches Mini-PC with integrated touchscreen
2006  Shuttle launches its first 3-litre PC
2005  Shuttle opens branch office in China
2005  Shuttle launches its first Media-Center XPC
2005  First Mini-PCs in the world with two graphics cards in SLI mode
2005  Tom’s Hardware awards Shuttle ‘Best SFF PC Maker’
2004  Shuttle introduces XPC complete system solutions
2004  Establishes Japan branch office
2004  Over one million XPCs shipped
2002  Introduces the patented "I.C.E." heatpipe cooling system
2001  Launches first Shuttle XPCs
2000  ISO-14001 certification
2000  Shuttle Inc. becomes publicly listed company (TAIEX: 2405)
1999  ISO-9001 certification
1998  Develops the world’s first 17x17cm motherboard for OEM market
1997  Establishes 3500 m² production facilities in Taoyuan, Taiwan
1995  Shuttle recognized as the world’s 5th largest mainboard maker
1995  ISO 9002 and TÜV certification
1990  Shuttle Computer Handels GmbH established in Germany
1988  Shuttle Computer Group, USA established
1984  Begins manufacturing motherboards in Taoyuan, Taiwan
1983  Shuttle Inc., Taiwan established (formerly Holco)

7

Shuttle from A to Z …

More information on the makers
of these unique products

H7

Here black-clad elegance combines with perfect workmanship. All front
ports and drives are concealed, only to be revealed when the individual
flaps of the front panel are opened. The H7 models boast a distinctive
history and have evolved to perfection.

H7-design models: SX58H7 Pro, SH67H7

8

H3

Shuttle Mini-PCs in H3-design have retained the classic features. All ports
and drives are instantly accessible. The case design itself is oriented to
the firstXPCs which areeven now stillamong the mostsought-after models
thanks to their timeless exterior. The H3-design embodies an extremely
successful revival.

H3-design models: SH67H3

9

R4

Shuttle XPCs in R4-design offer incredible value for money. The special
featureof thesemodels isthe frontpanel which isavailablefor your personal
design. Therefore simply remove the four screws, and a sheet of paper
with a design produced on a standard printer can be inserted. Ideal for
logos, photos and information. A PC that is as individual as you are.

R4-design models: SH61R4

10

R5

Purist shapes and clean lines dictated the development of the R5 design.
Impressive Mini-PCs with remarkable features are the result. Small visual
and technical masterpieces that will suit discerning userswith a weakness
for style down to the ground.

R5-design models: SZ68R5, SZ77R5, SX79R5

11

4.3 cm

XH61

At first glance, these machinesof the 3-litreclass of Mini-PCs that measure
barely 7 cm in height may appear plain. But a look at the technical
data of these small powerhouses presents them in a completely different
light. Processors that are normally found only in large PCs paired with
plenty of memory, a host of ports and practical accessories offer a
convincing package right from the outset.

Models in the Slim-PC format: XH61V, DS61

DS61

12

Small and even smaller – Slim PCs from Shuttle. The thinnest models our
company produces are distinguished by their compact 1-litre format
with a width of just 38 mm and a completely passive (fanless) cooling
system. They are noiseless, even when the operational demands on
them are high – and the absence of any fan reduces the maintenance
required, too. Clever.

Models in the Slim-PC format: XS35 series, XS36 series

XS36

Actua l Siz e

XS35

13

X50

All-in-One systems combine monitor and computer in a single device.
To make these slimline PCs even more versatile, they come with an
integrated webcam, set of speakers and microphone. A touch-sensitive
screen makes it possible to dispense with the mouse and keyboard in
many cases. Passive (fanless) cooling adds the final touch to this solution.
Unless it is your favourite song belting out of the speakers, you’ll hear
nothing from this PC.

14

X70

Shuttle All-in-One-PCs come in a multitude of colours, variants and sizes.
Need more processing power or additional ports? The X70 models can
be fitted with energy-efficient processors and 16 GB DDR3 RAM. Try out
this little power pack with a touchscreen.

Models in the All-in-One format: X50 series, X70 series

15

Shuttle®XPC Barebone SH61R4

Flexible,competitively priced Mini­PC for power-saving Intel CPUs

Customisable front panel for individual designs

 The front of the R4-design offers space for printed motifs

(e.g. logos, photos, information)

Up to 16 GB of DDR3 RAM

 Two DIMM sockets with dual-channel functionality

Wide range of connection options

 USB 3.0, 5.1 Audio, PCIe-x1, Mini-PCIe, LAN, COM-Port (RS232)

Application-optimised

 Upscale entry-level home PC, desktop business PC,

professional applications with COM port (optional)

Optional accessories: PC61J, PC63J, PHD3, H-RS232

SH61R4

Speed Functionality Energy Efficiency Space Saving Price

••

•• •• • •

Shuttle®XPC Barebone SH67H3/ SH67H7

Versatile platform for a wide
spectrum of applications

Two front designs to choose from

 Open (H3) or with stylish front doors (H7)

LGA1155 socket for energy-efficient processors

 Supports the second and third* generation of Intel Core

processors (i3/i5/i7) as well as Pentium and Celeron

Up to 32 GB of DDR3 memory

 Four DIMM sockets with dual-channel mode

Improved CPU-integrated Intel HD graphics function***

 HDMI and DVI-I outputs support full HD and Blu-ray video

and offer solid 3D performance

Optional accessories: PC63, PHD3, H-RS232

SH67H3 SH67H7

Speed Functionality Energy Efficiency Space Saving Price

••

•• •• • ••

16

Mini PC

Shuttle®XPC Barebone SZ68R5

Premium PC platform with
complete CPU compatibility
and SRT (SSD caching)

LGA1155 socket for all 22 nm / 32 nm processors

 Supports the second and third* generation of Intel Core

processors (i3/i5/i7)

Up to 32 GB of DDR3 RAM

 Four DIMM sockets with dual-channel functionality

Powerful CPU-integrated Intel HD graphics function***

 HDMI and DVI-I output support full HD as well as Blu-ray video

playback for solid 3D performance

Smart USB for charging iPhone/iPad

 A USB port on the front with 2 Amp power feed is suitable

for devices with high charging or quick-charge requirements

Optional accessories: PHD3, H-RS232

SZ68R5

Speed Functionality Energy Efficiency Space Saving Price

•••

••• •• • ••

Shuttle®XPC Barebone SX58H7 Pro

Mini-PC for Intel 6-core processors
and high-end graphics cards

LGA1366 socket for high-end Intel Core i7 processors

 e.g. Intel Core i7-990X Extreme Edition processor,

(6 cores, 12 MB cache, 3.46 GHz, 6.40 GT/s Intel QPI)

Up to 16 GB of DDR3 RAM

 Four DIMM sockets, supports triple-channel mode

Supports the biggest dual-slot graphics cards**

 2x PCIe-x16-2.0 for two single-slot graphics cards

or one large dual-slot graphics card

 500W power supply with additional 6+8-pin power supply

Dual Gigabit-LAN

 Two interfaces in teaming mode, failure protection

or have one PC connected to two different networks

Optional accessories: PHD3

SX58H7 Pro

Speed Functionality Energy Efficiency Space Saving Price

•••

•• • • •••

***The integrated video outputs cannot be used, if the processor installed does not have an integrated

graphics function such as Intel Core i5-2380P, Core i5-2450P and Core i5-2550K. 17

*from BIOS version .201
**Supports e.g. NVIDIA GeForce GTX 580, NVIDIA Quadro 5000 or AMD Radeon HD 6970.

Please also note compatibility list and dimensions!

Shuttle®XPC Barebone SZ77R5

High-performance desktop chipset
Intel Z77 Express with PCI-Express3.0

Up to 32 GB of DDR3 1600 RAM

 Four DIMM sockets with dual-channel functionality

Supports the latest dual-slot graphics cards*

 500W power supply with additional 6+8-pin power supply

Up to two hard disks and an optical drive

 SSD drive or mSATA slot uses "Smart Response Technology"

for faster booting and program start-up

Performance-optimised

 A host of performance-enhancing adjustment options in BIOS

Application-optimised

 High-end PC for HD content, resource-hungry 3D games

(graphics card required), workstation in content creation field

Optional accessories: PHD3, H-RS232

SZ77R5

Speed Functionality Energy Efficiency Space Saving Price

•••

••• •• • ••

Shuttle®XPC Barebone SX79R5

Ultimate performance:
The world’s only Mini-PC
for Sandy Bridge-E CPUs

LGA2011 socket for Sandy Bridge-E processors

 e.g. Core i7-3960X, 3.3 GHz, 6 cores, 15 MB cache

Supports the biggest dual-slot graphics cards*

 2x PCIe-x16-3.0 for two single-slot graphics cards

or one large dual-slot graphics card

 500W power supply with additional 6+8-pin power supply

Dual Gigabit-LAN

 Two interfaces in teaming mode, failure protection

or have one PC connected to two different networks

Wide range of connectors

 SATA 6 Gbit/s,eSATA with powersupply, mSATA, USB3.0, S/PDIF,

2x Gigabit-LAN

Optional accessories: PHD3, H-RS232

SX79R5

Speed Functionality Energy Efficiency Space Saving Price

•••

•• • • •••

18

19

Shuttle®Barebone XH61V

Strong computing power and
remarkable energy efficiency

LGA1155 socket for effective processors

 Supports the second and third generation of Intel Core processors

(i3/i5/i7) as well as Pentium and Celeron

Up to 16 GB of DDR3 RAM

 Two SO-DIMM sockets with dual-channel functionality

For particularly quiet, energy-saving notebook drives

 Up to three 2.5" hard disks/SSDs or an optical slimline drive

with two 2.5" hard disks/SSDs

High connectivity

 USB 3.0,5.1 Audio, S/PDIF, 2x network, 2x COMport (RS-232/422/485)

Optional accessories: PS01, PV02

XH61V

Speed Functionality Energy Efficiency Space Saving Price

••

••• •• •• •

* Supports e.g. NVIDIA GeForce GTX 580, NVIDIA Quadro 5000 or AMD Radeon HD 6970, also note

compatibility list and dimensions!

** Also available as XS35V2 with Intel Atom D525 CPU or XS35V3 with Atom D2700 processor.

Shuttle®Barebone XS35V3L**

Suitable for continuous operation –
fanless Slim-PC

Completely fanless, exceptionally quiet

 Practically noiseless and maintenance-free

State-of-the-art power-saving processor with two cores

 Intel Atom D2550 with 2x 1.86 GHz already mounted

Power-efficient

 Only 16 to 25W–cool and reliable

DVD/Blu-ray drive possible

 Can be fitted with optical drive and 2.5” HDD/SSD

Optional accessories: PV01, PHD2

XS35V3L

Speed Functionality Energy Efficiency Space Saving Price

•

•• ••• ••• •

Slim PC

Shuttle®Barebone XS35GS V3L*

Extraordinary graphics
performance – completely fanless

Quiet thanks to exclusively passive cooling components

 Practically noiseless and maintenance-free despite dedicated

graphics card

Tiny: only approx. 1.5 litre volume

 For more space – wherever it is set up

Full HD compatible

 AMD HD7410M graphics with HDMI supports smooth playback

of 1080p videos and delivers 3D performance when required

 An additional D-Sub output allows for dual monitoring

Optical drive possible

 Can be fitted with DVD or Blu-ray drive + 2.5" HDD/SSD

Optional accessories: PV01, PHD2

XS35GS V3L

Speed Functionality Energy Efficiency Space Saving Price

•

•• ••• ••• •

20

Shuttle®Barebone XS36VL

Shuttle’s smallest PC
comes fully-loaded

Completely fanless, exceptionally quiet

 Practically noiseless and maintenance-free

Three monitor outputs for flexibility

 Intel GMA 3650 graphics with HDMI, DVI-D

and D-Sub offer a free choice of ports for dual monitoring

Functions for reliable standalone operation

 Power fail resume, Always on, Wake-on-LAN (WOL)

Wide range of connectors

 2x COM port (RS-232), internal USB port, card reader, network

Optional accessories: PV03

XS36VL

Speed Functionality Energy Efficiency Space Saving Price

•

••• ••• ••• •

X50V2 Plus

X50V3L

21

* Alsoavailable as XS35GTAV2 withIntel Atom D525processor and AMDHD5430, XS35GTAV3 with IntelAtom

D2700 CPUand AMD HD7410Mor XS35GS V2with Intel AtomD525 processor andHD7410M graphics.

** Also available as X50V2 Plus with Intel Atom D525 processor or X50V3 with Intel Atom D2700 processor.

Shuttle®Barebone X50V3L**

Extremely quiet, saving and
compact All-in-One-PC with
touchscreen (39.6 cm/15.6")

Quiet and frugal

 Fanless – virtually noiseless and maintenance-free
 Only 20 to 27 W – cool and reliable

Serial and parallel ports (optional)

 For industry and business applications

HDMI and VGA connector

 For dual-monitoring

Application-optimised

 POS system, health service communication centre, information

terminal, home automation and equipment control,
digital signage (presentation)

Optional accessories: PF55, PCL69

Speed Functionality Energy Efficiency Space Saving Price

•

••• ••• ••• ••

All-in-One PC

22

Shuttle®Barebone X70S

Powerful 18.5" all-in-one solution
for the latest generation of Intel
desktop processors

Flexible choice of processor

 Suitable for many LGA1155 processors (TDP max. 65 W)
 Supports second and third generation of Intel Core processors

(i3/i5/i7)

Convenient and space-saving

 Fully-functional PC integrated in a flat screen display
 Touchscreen for mouse-free and keyboard-free input

VESA-compatible

 Attachment option for 100 mm VESA mount

Highly integrated design

 Fitted with USB 3.0, card reader, WLAN, Dual Gigabit-LAN,

webcam, microphone and speakers

Optional accessories: PCL70

Speed Functionality Energy Efficiency Space Saving Price

••

••• •• •• •••

* Also available as X50V2 Plus with Intel Atom D525 processor.

X70S

23

Mini PC

PC61J PC63J H-RS232 PHD3

 300W power supply 80PLUS  500W power supply 80PLUS  COM expansion  2.5 inch drive holder

Slim PC

PV01 PV02 PV03 PS01 PHD2

 VESA-mount 75/100 mm  VESA-mount 75/100 mm  VESA-mount 75/100 mm  Vertical stand  2nd HDD/SSD accessory

All-in-One PC

PCL68 PCL69 PCL70 PF55

 COM/LPT expansion  COM/LPT expansion  COM/LPT expansion  Carrying bag

Accessories

Mini PC

24

Category Basic Home-Media Performance

Model SH61R4 SH67H3 / SH67H7 SX58H7 Pro

Colour

Black Black Black

Complete system with Windows

R4 6100B, R4 6100BA H3 6700H H7 5820P

Processor

Socket

LGA1155 LGA1155 LGA1366

Support

Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W

Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W

Intel Core i7, Quad- and Hexa-Core

Cooling

I.C.E. Heatpipe I.C.E. Heatpipe I.C.E. Heatpipe

Memory

2x 240 pin DIMM-slots, maximum 2x 8 GB DDR3-1333
Dual channel

4x 240 pin DIMM-slots, maximum 4x 8 GB DDR3-1333
Dual channel

4x 240 pin DIMM-slots, maximum 4x 4 GB DDR3-1333
Triple channel (3+1)

Chipset

Northbridge

(integrated in CPU) (integrated in CPU) Intel X58 Express

Southbridge

Intel H61 Express Intel H67 Express Intel ICH10R (RAID)

Audio

IDT 92HD89C (5.1 ch) Realtek ALC888 (7.1 ch) Realtek ALC888S (7.1 ch)

Network

Realtek RTL 8111E (Gigabit), supports WOL and PXE Realtek RTL 8111E (Gigabit), supports WOL and PXE 2xRealtek8111E (Gigabit), supports WOL,PXE,Teaming

Integrated graphics function

Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**

Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**

–

Slots

Graphics card

1x PCI-Express-x16-2.0, supports dual-slot graphics
cards, 6-pin power connection

1x PCI-Express-x16-2.0, supports dual-slot graphics
cards, 6-pin power connection

2x PCI-Express-16-2.0, supports 2x single-slot or 1x
dual-slot graphics card, 6+8-pin power connector,
ATI CrossFire, NVIDIA SLI support

PCI

1x PCI-Express-x1-2.0, 1x Mini-PCI-Express-x1-2.0 1x PCI-Express-x1-2.0, 1x Mini-PCI-Express-x1-2.0 1x Mini-PCIe-x1-2.0

Ports,LEDs
and buttons

Front

Microphone input, headphones output, 2x USB 2.0,
Power LED, hard disk LED, On/Off button

Microphone input, headphones output, 2x USB 3.0,
eSATA/USB 2.0 Combo,
Power LED, hard disk LED, On/Off button, Reset button

Microphone input, headphones output, 2x USB 3.0,
eSATA/USB 2.0 Combo, power LED, hard disk LED,
On/Off button, Reset button

Rear

DVI-D, DVI-I (digital and analog), 2x USB 3.0 and 6x
USB 2.0, Gigabit-LAN, Line-out, Line-in, Microphone,
Clear CMOS button, opening for Kensington-Lock

HDMI (with Digital Audio), DVI-I (digital and analog),
2x USB 3.0 and 4x USB 2.0, eSATA, Gigabit-LAN, Audio
8-channel Line-out, Line-in, Optical S/PDIF output,
Clear CMOS button

8x USB 2.0, 2x Gigabit-LAN, eSATA + power supply,
Audio 8-channel Line-out, Audio Line-in, Optical
S/PDIF output, Clear CMOS button

Onboard

4x SATA 3 Gbit/s, serial port (RS-232)

2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0,serial port
(RS-232)

2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0

Drive bays and
supported drives

1x 5.25" (for optical drive), 2x 3.5" internal (e.g. for
hard disk, SSD)

1x 5.25" (for optical drive), 2x 3.5" internal + external
(e.g. for hard disk, SSD,
card reader), supports RAID 0, 1, 5, 10

1x 5.25" (for ODD), 2x 3.5" internal + external (e.g. for
HDD, SSD, card reader), supports RAID 0, 1

Power supply

250W standard power supply,
Input: 100-240 V AC 50/60 Hz

300W 80 PLUS Bronze,
Input: 100-240 V AC 50/60 Hz

500W 80 PLUS Bronze,
Input: 100-240 V AC 50/60 Hz

BIOS

AMI BIOS, supports ACPI 3.0 and UEFI AMI BIOS, supports ACPI 3.0 and UEFI AMI BIOS supports ACPI 3.0 and UEFI

Material

Aluminium Aluminium Aluminium

Dimensions and weight

32.5 x 21.5 x 19 cm (DWH) = 13.3 L, 3.2 kg 32.5 x 20.8 x 19.6 cm (DWH) = 12.8 L, 3.2 kg 32.5 x 20.8 x 19,6 cm (DWH) = 12.8 L, 4.2 kg

Permitted ambient parameters

Operating temperature: 0-35°C, Air humidity: 10-90% Operating temperature: 0-35 °C, Air humidity: 10-90% Operating temperature: 0-35 °C,Air humidity: 10-90 %

Optional accessories

2.5" HDD/SSD installation frame (PHD3),
COM port (H-RS232), 300W power supply unit
(PC61J), 500W power supply unit (PC63J)

2.5" HDD/SSD installation frame (PHD3),
COM port (H-RS232), 500W power supply unit (PC63)

2.5" HDD/SSD mounting frame (PHD3)

* The integrated video outputs cannot be used, if the processor installed does not have an integrated graphics function such as Intel Core i5-2380P, Core i5-2450P and Core i5-2550K.
** Up to four displays are supported, if a

PCI-Express-x16 graphics card is installed.

Mini PC

25

Category Performance Performance Performance

Model SZ68R5 SZ77R5 SX79R5

Colour

Black Black Black

Complete system with Windows

R5 6800P R5 7700P R5 7900P

Processor

Socket

LGA1155 LGA1155 LGA2011

Support

Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W

Intel Core i3/i5/i7, Pentium, Celeron,
TDP max. 95 W

Intel Core i7, Sandy Bridge-E

Cooling

I.C.E. Heatpipe I.C.E. Heatpipe I.C.E. Heatpipe

Memory

4x 240 pin DIMM-slots, maximum 4x 8 GB DDR3-1333
Dual channel

4x 240 pin DIMM-slots, maximum 4x 8 GB DDR3-1600
Dual channel

4x 240 pin DIMM-slots, maximum 4x 8 GB DDR3-1600
Quad channel

Chipset

Northbridge

(integrated in CPU) (integrated in CPU) (integrated in CPU)

Southbridge

Intel Z68 Express Intel Z77 Express Intel X79 Express

Audio

Realtek ALC888S (7.1 ch) Realtek ALC888S (7.1 ch) Realtek ALC888S (7.1 ch)

Network

Realtek 8111E (Gigabit), supports WOL, PXE Realtek 8111E (Gigabit), supports WOL, PXE 2x Realtek 8111E (Gigabit), supports WOL, Teaming

Integrated graphics function

Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**

Intel GMA HD in CPU, UMA max. 1.692 MB*,
supports two displays**

–

Slots

Graphics card

1x PCI-Express-x16-2.0, supports dual-slot graphics
cards, 6-pin power connector

1x PCI-Express-x16-3.0, supports dual-slot graphics
cards, 6-pin power connector

2x PCI-Express-16-2.0, supports 2x single-slot or 1x
dual-slot graphics card, 6+8-pin power connector,
ATI CrossFire, NVIDIA SLI support

PCI

1x PCIe-x4-2.0, 1x Mini-PCIe-x1-2.0, 1x mSATA

1x PCIe-x4-2.0, 1x Mini-PCIe-x1-2.0,
1x Mini-PCIe-x1-2.0 (supports mSATA)

1x Mini-PCIe-x1-2.0, 1x mSATA

Ports,LEDs
and buttons

Front

Microphone input, headphones output, 2x USB 3.0,
2x USB 2.0 (1x with Smart USB), power LED, hard disk
LED, On/Off button, Reset button

Microphone input, headphones output, 2x USB 3.0,
2x USB 2.0 (1x with Smart USB), power LED, hard disk
LED, On/Off button, Reset button

Microphone input, headphones output, 2x USB 3.0,
2x USB 2.0 (1x with Smart USB), power LED, hard disk
LED, On/Off button

Rear

HDMI (with Digital Audio), DVI-I (digital and analog),
2x USB 3.0 and 4x USB 2.0, eSATA, Gigabit-LAN, Audio
8-channel Line-out, Line-in, Optical S/PDIF output,
Clear CMOS button

HDMI (with Digital Audio), DVI-I (digital and analog),
2x USB 3.0 and 4x USB 2.0, eSATA, Gigabit-LAN, Audio
8-channel Line-out, Line-in, Optical S/PDIF output,
Clear CMOS button

2x USB 3.0, 6x USB 2.0, 2x Gigabit-LAN, eSATA +
power supply, Audio 8-channel Line-out, Audio
Line-in, Optical S/PDIF output, Clear CMOS button

Onboard

2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0, RS-232 2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 2x USB 2.0, RS-232 2x SATA 6 Gbit/s, 2x SATA 3 Gbit/s, 4x USB 2.0, RS-232

Drive bays and
supported drives

1x 5.25" (for ODD), 2x 3.5" internal + external (e.g. for
HDD, SSD, card reader), supports RAID 0, 1, 10, JBOD

1x 5.25" (for ODD), 2x 3.5" internal + external (e.g. for
HDD, SSD, card reader), supports RAID 0, 1, 10, JBOD

1x 5.25" (for ODD), 2x 3.5" internal + external
(e.g. for HDD, SSD, card reader), supports RAID 0, 1

Power supply

500W 80 PLUS Bronze, Input: 100-240 V AC 50/60 Hz 500W 80 PLUS Bronze, Input: 100-240 V AC 50/60 Hz 500W 80 PLUS Bronze, Input: 100-240 V AC 50/60 Hz

BIOS

AMI BIOS supports ACPI 3.0 and UEFI AMI BIOS supports ACPI 3.0 and UEFI AMI BIOS supports ACPI 3.0 and UEFI

Material

Aluminium Aluminium Aluminium

Dimensions and weight

33.2 x 21.6 x 19.8 cm (DWH) = 14.2 L, 3.5 kg 33.2 x 21.6 x 19.8 cm (DWH) = 14.2 L, 3.5 kg 33.2 x 21.6 x 19.8 cm (DWH) = 14.2 L, 3.5 kg

Permitted ambient parameters

Operating temperature: 0-35°C, Air humidity: 10-90 % Operating temperature: 0-35°C, Air humidity: 10-90 % Operating temperature:0-35 °C, Air humidity: 10-90 %

Optional accessories

2.5" HDD/SSD mounting frame (PHD3),
COM port (H-RS232)

2.5" HDD/SSD mounting frame (PHD3),
COM port (H-RS232)

2.5" HDD/SSD mounting frame (PHD3),
COM port (H-RS232)

Slim PC

26

Category Home-Media Home-Media

Model DS61 XH61V

Colour

Black Black

Complete system with Windows

D 6100B X 6110B

Processor

Socket

LGA1155 LGA1155

Support

Intel Core i3/i5/i7, Pentium, Celeron, TDP max. 65 W Intel Core i3/i5/i7, Pentium, Celeron, TDP max. 65 W

Cooling

I.C.E. Heatpipe I.C.E. Heatpipe

Memory

2x 204-Pin SO-DIMM-slots, maximum 2x 8 GB DDR3-1333, dual-channel 2x 204-Pin SO-DIMM-slots, maximum 2x 8 GB DDR3-1333, dual-channel

Chipset

Northbridge

(integrated in CPU) (integrated in CPU)

Southbridge

Intel H61 Express Intel H61 Express

Audio

Realtek ALC662 (5.1 ch) Realtek ALC887 (7.1 ch)

Network

2x Realtek 8111E (Gigabit) unterstützt WOL und PXE 2x Realtek 8111E (Gigabit) supports WOL and PXE

Integrated graphics function

Intel GMA HD in CPU, UMA max. 1,692 MB, supports two displays Intel GMA HD in CPU, UMA max. 1,692 MB, supports two displays

Slots

Graphics card

– –

PCI

1x Mini-PCIe-x1-2.0 1x Mini-PCIe-x1-2.0, 1x mSATA

Ports,LEDs
and buttons

Front

Microphone input, headphones output, 2x USB 2.0, card reader: SD, SDHC & SDXC,
power LED, hard disk LED, On/Off button

Microphone input, headphones output, 2x USB 2.0, On/Off button with LED

Rear

HDMI (with Digital Audio), DVI-I (digital and analogue), 2x USB 3.0,
2x Gigabit-LAN, 2x COM-Port (RS-232 and RS-232/422/485), Remote Power-On

HDMI (with Digital Audio), DVI-I (digital and analogue), 2x USB 3.0, 2x USB 2.0,
3x Audio, S/PDIF, 2x Gigabit-LAN, 2x COM-Port (RS-232 und RS-232/422/485)

Onboard

6x USB 2.0, S/PDIF, 2x SATA 3 Gbit/s, LPC, LVDS, Converter 3x SATA 3 Gbit/s

Drive bays and
supported drives

Drive bays: 1x 2,5" supports 1x 2,5" hard disk/SSD, card reader: SD, SDHC & SDXC

Drive bays: 1x 2.5" and 1x Slim, supports 1x 2.5" hard disk
and an optical slimline drive

Power supply

External 90 W power supply, output: 19 V DC, input: 100-240 V AC External 90 W power supply, output: 19 V DC, input: 100-240 V AC

BIOS

AMI BIOS unterstützt ACPI 3.0, supports UEFI AMI BIOS supports ACPI 3.0, supports UEFI

Material

Steel Steel

Dimensions and weight

19 x 16.5 x 4.3 cm (DWH) = 1.35 L, 1.3 kg 24 x 20 x 7.2 cm (DWH) = 3.5 L, 2.2 kg

Permitted ambient parameters

Operating temperature: 0-50 °C, Air humidity: 10-90 % Operating temperature: 0-35 °C, Air humidity: 10-90 %

Optional accessories

– Pedestal (PS01), VESA mount (PV02)

* Also available as XS35V2 with Intel Atom D525 CPU or XS35V3 with Atom D2700 processor.
** Also available as XS35GTA V3 with Intel Atom D525 CPU and AMD HD5430, XS35GTAV3 with Intel Atom D2700 CPU and AMD HD7410M or XS35GS V2 with Intel Atom D525 CPU and HD7410M graphics.

Slim PC

27

Category

Basic Home-Media Basic

Model

XS35V3L* XS35GS V3L** XS36VL

Colour

Black Black Black

Complete system with Windows

XS 3501B3, XS 3501BAV3 XS 3531M3, XS 3531MA V3 XS 3601B, XS 3601BA

Processor

Model

Intel Atom D2550 Intel Atom D2550 Intel Atom D2550

Clock speed

2x 1.86 GHz, 4 Threads 2x 1.86 GHz, 4 Threads 2x 1.86 GHz, 4 Threads

Cooling

Passive, fanless Passive, fanless Passive, fanless

Memory

2x 204 pin SO-DIMM slots
maximum 2x 2 GB DDR3-1066

2x 204 pin SO-DIMM slot
maximum 2x 2 GB DDR3-1066

2x 204 pin SO-DIMM slot
maximum 2x 2 GB DDR3-1066

Chipset

Northbridge

(integrated in CPU) (integrated in CPU) (integrated in CPU)

Southbridge

Intel NM10 Intel NM10 Intel NM10

Audio

IDT 92HD81 IDT 92HD81 IDT 92HD81

Network

Realtek RTL8411 (Gigabit) supports WOL Realtek RTL8411 (Gigabit) supports WOL Realtek RTL8411 (Gigabit) supports WOL

Wireless network, WLAN

802.11b/g/n, 150 Mbit 802.11b/g/n, 150 Mbit 802.11b/g/n, 150 Mbit

Integrated graphics function

Intel GMA 3650, UMA max. 384 MB,
supports two displays

AMD HD7410M, 512 MB,
supports two displays

Intel GMA 3650, UMA max. 384 MB,
supports two displays

Slots

Graphics card

– – –

PCI

– – –

Ports,LEDs
and buttons

Front

1x USB 2.0, card reader, power LED, hard disk LED,
On/Off button

1x USB 2.0, card reader, power LED, hard disk LED,
On/Off button

2x RS-232, 1x USB 2.0, card reader, power LED, hard
disk LED, On/Off button

Rear

HDMI (with Digital Audio), VGA, 4x USB 2.0, 2x Audio,
Gigabit-LAN, power supply

HDMI (with Digital Audio), VGA, 4x USB 2.0, 2x Audio,
Gigabit-LAN, power supply

HDMI (with Digital Audio), DVI-D, VGA, 4x USB 2.0, 2x
Audio, Gigabit-LAN, power supply

Onboard

2x SATA 3 Gbit/s 2x SATA 3 Gbit/s 1x USB 2.0, 1x SATA 3 Gbit/s

Drive bays and
supported drives

Drive bays: 1x 2.5" and 1x Slim, supports 1x 2.5" hard
disk and an optical slimline drive, Card reader: SD,
SDHC, SDXC

Drive bays: 1x 2.5" and 1x Slim, supports 1x 2.5" hard
disk and an optical slimline drive, Card reader: SD,
SDHC, SDXC

Drive bays: 1x 2.5" Supports 1x 2.5" hard disk
Card reader: SD, SDHC, SDXC

Power supply

External 40 W power supply, output: 19 V DC,
input: 100-240 V AC

External 40 W power supply, output: 19 V DC,
input: 100-240 V AC

External 40 W power supply, output: 19 V DC,
input: 100-240 V AC

BIOS

AMI BIOS supports ACPI 2.0 and UEFI AMI BIOS supports ACPI 2.0 and UEFI AMI BIOS supports ACPI 2.0 and UEFI

Dimensions and weight

25.2 x 16.2 x 3.85 cm (DWH) = 1.57 L, 2.1 kg 25.2 x 16.2 x 3.85 cm (DWH) = 1.57 L, 2.1 kg 22 x 16 x 3.6 cm (DWH) = 1.15 L, 1.6 kg

Permitted ambient parameters

Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-35 °C, Air humidity: 10-90 %

Optional accessories

VESA mount (PV01), kit for second HDD/SSD (PHD2) VESA mount (PV01), kit for second HDD/SSD (PHD2) VESA mount (PV03)

All-in-One PC

28

Category

Basic Basic Home-Media

Model

X50V2 Plus X50V3L* X70S

Colour

Black or white Black or white Black

Complete system with Windows

X 5020T Plus, X 5020TA Plus X 5031T, X 5031TA X 7000T, X 7000TA

Processor

Model

Intel Atom D525 Intel Atom D2550

Intel Core i3/i5/i7, Pentium, Celeron
(LGA1155, TDP max. 65 W)

Clock speed

2x 1.8 GHz, 4 Threads 2x 1.86 GHz, 4 Threads (dependant on processor)

Cooling

Passive, fanless Passive, fanless I.C.E. Heatpipe

Memory

2x 204-Pin SO-DIMM slots, maximum 2x 2 GB DDR3-800

2x 204-Pin SO-DIMM slots, maximum 2x 2 GB DDR3­1066

2x 204-Pin SO-DIMM slots, maximum 2x 8 GB
DDR3-1600

Chipset

Northbridge

(integrated in CPU) (integrated in CPU) (integrated in processor)

Southbridge

Intel NM10 Intel NM10 Intel H61 Express

Audio

IDT 92HD81 IDT 92HD87 Realtek ALC269

Network

JMC261 (100 Mbit) supports WOL Realtek RTL8411 (Gigabit) supports WOL 2x Realtek 8111E (Gigabit) supports WOL and PXE

Wireless network, WLAN

802.11b/g/n, 150 Mbit 802.11b/g/n, 150 Mbit 802.11b/g/n, 300 Mbit

Integrated graphics function

Intel GMA 3150, UMA max. 265 MB,
supports dual monitoring

Intel GMA 3650, UMA max. 384 MB,
supports dual monitoring

Intel GMA HD integrated in processor,
UMA max. 1.692 MB, supports dual monitoring

Screen

Resolution

39.6 cm/ 15.6" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768

39.6 cm/ 15.6" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768

46,7 cm/ 18,5" LCD display, LED backlight,
16:9 widescreen resolution: 1.366 x 768

Touchscreen

Resistive Resistive Resistive

Communication

Webcam

2.0 Megapixels (1.600 x 1.200) 2.0 Megapixels (1.600 x 1.200) 2,0 Megapixel (1.600 x 1.200)

Loudspeakers
and microphone

2x 2 W loudspeaker, capacitor microphone 2x 2 W loudspeaker, capacitor microphone 2x 2 W loudspeaker, capacitor microphone

Ports,LEDs
and buttons

Front

Power LED, hard disk LED, WLAN LED Power LED, hard disk LED, WLAN LED Power LED, hard disk LED

Rear

VGA, (Option: 2x RS-232, 1x LPT)

HDMI (with Digital Audio), VGA, (Option: 2x RS-232,
1x LPT)

HDMI (with DigitalAudio), Microphone input, head­phones output, 2x USB 3.0, 2x USB2.0, 1x RS-232,
2x LAN,power supply,(Option: 2x RS-232, 1x LPT)

Side

Microphone input, headphones output, 4x USB 2.0,
network, power supply, On/Off button

Microphone input, headphones output, 4x USB 2.0,
network, power supply, On/Off button

4x USB 2.0,
On/Off button

Drive bays and
supported drives

Drive bays: 1x 2.5", supports 1x 2.5" hard disk internal
ports: 1x SATA 3 Gbit/s, card reader: SD, SDHC & SDXC

Drive bays: 1x 2.5", supports 1x 2.5" hard disk, internal
ports: 1x SATA 3 Gbit/s, card reader: SD, SDHC & SDXC

Drive bays:1x 2,5",supports 1x 2,5"hard disk/SSD,inter­nal ports:2x SATA 3 Gbit/s,card reader:SD, SDHC, SDXC

Power supply

External 40 W power supply, output: 19 V DC,
input: 100-240 V AC

External 40 W power supply, output: 19 V DC,
input: 100-240 V AC

External 120 W power supply, output: 19 V DC,
input: 100-240 V AC

BIOS

AMI BIOS supports ACPI 3.0 AMI BIOS supports ACPI 3.0 AMI BIOS supports ACPI 2.0 and UEFI

Dimensions

39.13 x 32.7 x 3.6 cm (DWH), 2.93 kg 39.13 x 32.7 x 4.2 cm (DWH), 2.93 kg 46.8 x 36.4 x 5.7 cm (DWH), 4.6 kg

Permitted ambient parameters

Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-35 °C, Air humidity: 10-90 % Operating temperature: 0-40 °C, Air humidity: 10-90 %

Optional accessories

IO expansion 2x COM + 1x LPT (PCL68),
carrying bag (PF55)

IO expansion 2x COM + 1x LPT (PCL69),
carrying bag (PF55)

IO expansion 2x COM + 1x LPT

Category Home-Media

Model OMNINAS KD20

Colour

White/silver

Processor

Model

PLX NAS 7821

Clock speed

2x 750 MHz

Memory

256 MB

Ports,LEDs
and buttons

front

1x USB 3.0, card reader, status LED, card reader LED, USB LED, hard disk LED, On/Off button

rear

2x USB 2.0, Gigabit LAN, power supply unit, reset button

Drive bays and
supported drives

2x 3.5" for hard disks/SSDs up to a total of 8 TB, supports RAID-0, 1, JBOD, single disk

Card reader

Supports SD, SDHC and SDXC

Networking services

Samba server (SMB file sharing), Apple File Protocol (AFP), media server (supports DLNA), iTunes server, printer server (supports USB printer),
BT download without PC (scheduled), external device sharing (via USB or card reader), NTP support for scheduled time synchronisation

In-built backup functions

Quick Auto Copy for external storage (from USB 3.0 or card reader to NAS), NAS to USB storage backup, NAS to NAS backup

System services

Firmware upgrade, time zone settings, factory reset function, system log report

Mobile use

Free apps for mobile devices with iOS or Android, access via browser

Power adapter

External 65 W power supply,
output: 19 V DC, input: 100-240 V AC

Materials

Aluminium, plastic

Dimensions and weight

22.5 x 17 x 9 cm (DHW) = 3.44 litres, 2.2 kg

Environmental parameters

Operating temperature: 5-35 °C
Humidity: 10-90 %

NAS

* Also available as X50V3 with Intel Atom D2700 processor.

29

30

Exclusive offers and services for resellers …

Register for the Shuttle Reseller Program at

www.shuttle.eu/reseller

The Shuttle Reseller Program was created to support resellers directly in
their sales and marketing of Shuttle products. Benefit from always being
a step ahead of the market.

3-year warranty and additional guarantee service

 Only registered resellers benefit from extended warranty periods

and additional guarantee services. Learn more about these
advantages in the Shuttle Reseller Program.

Meet us in person

 Shuttle takes part to several industry trade fairs and events

over the course of the year. Where and when?
Find out in the Business Area on our website, choose the time
and date, and pay us a visit.

Keep up-to-date with the latest information
and publications

 You will always receive the latest information about new

products, press releases and special activities. Official partners
remain a step ahead of the competition.

Take part in regular special promotions
and increase your profit margin

 Participants in the Shuttle Reseller Program can take part in bonus

programs (kickback, complimentary items, special prices.) All the
details are available in the Reseller area of Shuttle's website.

Use Direct RMA Service

 Shuttle partners have the ability to benefit from Direct RMA

Service from Shuttle. All you need to do is send us your defective
Shuttle Barebones and we will repair them as quickly as possible.

Professional Support for Technical Queries

 Our technical support department is at your disposal for all

questions about Shuttle products. They can be reached by phone
or email during regular business hours and can handle queries in
English, German or French

Telephone advice and direct contact
with our European sales team

 Our sales team is available by phone or email to help you with

questions about new products, special projects or anything else
Shuttle-related in English, German or French.

Advertise yourself as an official supplier

 Registered resellers can apply to be listed in the "where to buy"

section of Shuttle's website.

 Select product category

Find your

desired product

 Configure and send request for quotation

31

With the "Shuttle Systems Configurator" you can create your desired
turnkey systems based on a Shuttle Barebone product. After selecting the
required hardware components andWindows version, you can request
a non-binding quotation from an authorised dealer of your choice.

It's easy to use and has lots of benefits

 Original Shuttle complete system

 Custom configuration (built-to-order)

 Manufactured and tested directly by Shuttle in Germany

 24-month Pick-Up-And-Return service

for Windows-based complete systems

 Many Windows 7/Windows 8 operating systems as Shuttle OEM version

 Free Service Hotline

 Free shipping

Order custom configured Mini-PC products …

Configure Shuttle complete
systems online at

www.shuttle.eu/systems

Printing mistakes, errors and technical modifications excepted. All brand names mentioned are the property of the relevant brand owner.

issue Q1/2013
