Shuttle XP19 Specifications

Product Specification

www.shuttle.com

Shuttle Computer Handels GmbH

Fritz-Strassmann-Str. 5
25337 Elmshorn | Germany

Tel. [phone]
Fax [phone]
[e-mail]

Page 1 | 11 July 2008

©2008 by Shuttle Computer Handels GmbH (Germany). All information subject to change without notice. Pictures for illustration purposes only.

19" Widescreen LCD Monitor

Experience the optimized and colorful image with Shuttle XP19
immediately! XP19 offers well-defined images with its stylish and
elegant appearance. Featuring 24Slim™ body for the space saving
and the slim frame border to maximize the vision. Especially the 5ms
fast response time delivers outstanding image quality definitely gets
you to the true-to-life entertainment. The conveniently integrated
speaker provides incredible audio experience and the friendly on
screen display lets the users individualize the visual preferences while
enjoying the stunning XP19.

XP19 is definitely ideal companion for various applications to extreme
your vision and life. Never miss XP19 if you want to look good with a
good look monitor.

Feature Highlight

Screen

• Size: 19" (inch) Widescreen, WSXGA+

• Type: active Panel TFT Display

• Panel Surface: Anti-Glare

• Native Resolution: 1680 x 1050

• H/V frequency: H: 30-81KHz, V: 56-75Hz

• Brightness: 300 cd/m2

• Contrast ratio: 1000:1

• Viewing angle: 170° (H) x 160° (V)

• Response time: 5 ms

• Color resolution: 16.7 million (true color)

• Pixel Pitch: 0.243 mm

Connectors

• Video input: RGB Analog, D-Sub 15 pin

• Video output: RGB Analog, D-Sub 15 pin

• Speaker input

• Power: Input for external power supply

On Screen

Display

(OSD)

• User Controls: 5 key Control Button

• Languages: Eng/Deu/Fre/Ita/Spa/Por/Ch-

s/Ch-t/Pol/Rus/Kor/Dan/Dut/Fin/Swe/Jap

Other

features

• Dimensions: 433 x 356 x 24 mm WHD
(17.0" x 14" x 0.9" WHD)

• Packing Dimensions: 613 x 517 x 110 mm

• Weight: 4.6 / 6.5 kg (net/gross)

• Power Supply: external, fanless

• Power Consumption:

max. 40 W, Standby < 2 W

• Speakers: integrated, hidden

Shuttle TFT Monito

r

XP19

Images for illustration purposes only.
