15.6” All-in-One PC for POS, POI and
Kiosk Applications
Shuttle’s range o f All-in-One PCs yet comprises mode ls with th ree
differen t screen sizes: 11 .6", 15. 6" and 19.5". The Shuttle XP C a ll -in-one
P51U3 with a capacitive 15.6" mult i-touchscree n offers Ful l-HD
resolution and i s optionally available with an integra ted 30Wh
battery*). An In tel Core i 3 Ultra -Low-Voltage (ULV) processor makes for
high computing powe r whi le it keeps energy consumption at a low
level. Thanks to its passive cooli ng, the system is vir tuall y noiseless,
mainte nance -free and appro ved for 24/7 nonstop operation.
Par ticularly suitable for vertical applications is the arra nge ment of
connec tors at the bottom and the IP54 comp liant front panel which is
dust-protec ted and protected from splashing of wate r.
Feature Highlights
All-in-One
Design
All-in-one PC
Stand can also be used as a handle
100 mm VESA mount capable
IP54-compliant front panel
Approved for 24/7 nonstop operation
Display &
Graphics
39.6 cm (15.6”) Full HD IPS disp lay (1920x1080)
Capa citive 10-point multitouch display
Intel HD 610 graphics w ith HDMI 1.4b and VGA
CPU &
Cooling
Intel Core i3-8145U, 2.1 / 3 .9 GHz, 15W TDP
2/4 Cores/Threads, “W hiskey-La ke-U” Gen.
Fanless cooling system
Storage
(not
included)
Supports max. 2x 32 GB DDR4 SO-DIMM
Supports one 2.5" SATA HDD / SSD ≤9.5 mm
Supports one M.2-2280 SSD (SATA / PCIe)
Supports internal USB stick (USB 2.0, type A)
Operating
System
Operating system is not included
Supports Windows 10 (64-bit) & Linux (64-bit)
Connectivity
HDMI 1.4b , D-Sub/VGA, 2x USB 3.0, 4x USB 2.0
Gigabit L AN, 2x Audio (Mic / Headphones)
2x RS232, internal USB 2.0 t ype A port
Built-in
Wire less LAN 802.11ac (1T1R), B luetooth 4.2
SD card reader , 1080p Full HD webcam
2x 2W speakers and microphone
Optional
Accessories
Two additional COM ports
Battery for 4~7h operat ion (4-cell, 30 Wh) [1]
Integrated NFC module (on request only)
Power
Supply
External fanless power adapter, 65 W
Warranty
24 months Bring-in Service
[1] Note: The battery PBAT01 is available optionally and with
fully-configured systems only.
15.6"
Capacitive Multitouch & Full-HD
15.6”
Multitouch
Nonstop
operation
Fanless
cooling
Front protected
from
dust & water
Two
COM ports
Supports
Windows 10 &
Linux (64-bit)
Wireless and
Wired Network
2x USB 3.0
4x USB 2.0
Internal
USB-Port
Images for illustration purposes only.
XPC all-in-one Barebone
P51U3 Black
Produkt
Farbe
Prozessor
P51U
Schwarz
Celeron 4205U
P51U3
Schwarz
Core i3-8145U
Product Specifications
w w w . s h u t t l e . e u
Shuttle C o m p u t e r H a n d e l s G m b H
Fr it z- St ras sma nn-S tr . 5
25 337 El msh or n | Ge r ma n y
Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0
Fa x + 4 9 ( 0) 41 21- 47 69 0 0
E- Mai l: s ales @shu tt le .eu
Page 2 | 3 March 2020
© 2019 by Shuttle Computer Handels GmbH (Germany). All information subject to change without notice
. Pictures for illustration purposes only.
Shuttle XPC all-in-one P51U3 − Overview
26
27
6
8 9 10
13
1
14
15
15
16
6
1
2
4
5
6
3
24
23
225
20
21
1917 18
11
12
25
6
6a
7
1
2x Perforation for optional LTE antennas
2
Power button
3
Speaker (left)
4
Card reader
5
4x USB 3.0 port (= USB 3.1 Gen 1)
6
Stand
6a
Cover for stand
7
Hole for Clear CMOS button
8
Power LED (blue)
9
Storage LED (orange)
10
Battery LED (red)
11
Microphone
12
Webcam
13
LCD Touchscreen
14
Speaker (right)
15
2x Serial COM port (optional)
16
Hole for Kensington Lock
17
2x Serial COM port
18
D-Sub/VGA output
19
DC-input (for power adapter)
20
2x USB 2.0 port
21
Gigabit LAN port
22
HDMI 1.4b output
23
Audio Line-out (headphones)
24
Microphone input
25
Screw holes for VESA mount
26
Optional LTE antennas
27
Optional NFC module area
Product Specifications
w w w . s h u t t l e . e u
Shuttle C o m p u t e r H a n d e l s G m b H
Fr it z- St ras sma nn-S tr . 5
25 337 El msh or n | Ge r ma n y
Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0
Fa x + 4 9 ( 0) 41 21- 47 69 0 0
E- Mai l: s ales @shu tt le .eu
Page 3 | 3 March 2020
© 2019 by Shuttle Computer Handels GmbH (Germany). All information subject to change without notice
. Pictures for illustration purposes only.
Installable Components
2242
2260
2280
1
USB Stick
2
LTE Antenna Kit
4
M.2 SSD Card
5
DDR4 RAM
7
2.5” SSD / Hard Disk
6
Rechargeable Battery
8
Additional
COM-Ports
3
NFC Module
1
USB Stick
The P51U3 features an internal USB 2.0 Type A connector for expansion sticks (such as flash
memory or LTE modules).
2
LTE Antenna
Kit
The chassis features two perforated 7 mm holes for optional external antennas with SMA
connector. You may add mobile network functionality by, for example, using the USB LTE
stick Huawei MS2372h-153 (for EMEA region) which provides two antenna connectors.
3
NFC Module
The PNFC02 is a 13.56 MHz NFC module for internal installation. It supports Windows 10 and
is not certified for payment applications. This Shuttle accessory is available on request only.
4
M.2 SSD card
The P51U3 supports M.2 SSD cards with a length of 42, 60 or 80 mm and with both SATA and
PCIe interface.
5
DDR4 RAM
The P51U3 supports up to two 32 GB DDR4-2400(+) SO-DIMM memory modules.
6
Rechargeable Battery
The PBAT01 is a rechargeable Li-Ion battery for 4~7 h operating time (14.4V / 2100 mAh,
30.24 Wh). The PBAT01 is available optionally and with fully-configured systems only.
7
2.5” SSD/HDD
Supports one SATA SSD or Hard Disk in 2.5” format (max. height: 9.5 mm).
8
Additional
COM-Ports
The optional Shuttle Accessory PCP21 (or 2x PCP11) provides two more serial COM por ts.
Product Specifications
w w w . s h u t t l e . e u
Shuttle C o m p u t e r H a n d e l s G m b H
Fr it z- St ras sma nn-S tr . 5
25 337 El msh or n | Ge r ma n y
Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0
Fa x + 4 9 ( 0) 41 21- 47 69 0 0
E- Mai l: s ales @shu tt le .eu
Page 4 | 3 March 2020
© 2019 by Shuttle Computer Handels GmbH (Germany). All information subject to change without notice
. Pictures for illustration purposes only.
Mainboard Overview
1 2 3 5 6 7
8
11
12
13
14
40
39
37
35
34
32
29
30
31
33
36
38
26 25 24 23 22 21 20 19 18
9
41
28
4
10
15
17
16
27
1
Conn. for Beacon Module
2
Connector for NFC-Module
3
M.2-2280 Slot
4
CPU Voltage Regulator
5
Speakers Connector (res.)
6
Microphone Connector
7
Webcam Connector
8
Onboard Power Button
9
Soldered Processor
10
SO-DIMM Memory Slots
11
SD Card Reader
12
USB 3.1 Connector
13
USB 3.1 Connector
14
Clear CMOS Button
15
LED Connector
16
Microphone Port (reserved)
17
Jumper Block
18
Microphone Port
19
Audio Line-Out
20
HDMI 1.4b Connector
21
USB 3.1 Connector
22
USB 3.1 Connector
23
RJ45 Network Connector
24
USB 2.0 Connector
25
USB 2.0 Connector
26
DC-in for Power Adapter
27
Location of CMOS Battery
28
Connector for CMOS Battery
29
USB-Conn. f. Touch Screen
30
Speakers Connector
31
VGA Connector
32
Embedded DisplayPort (eDP)
33
Cash Drawer Connector
34
Battery Pack Connector
35
Connector for POS01/PCL71
36
Conn. for POS03 I/O board
37
Debug Port (Reserved)
38
BIOS EEPROM
39
Serial ATA Connector
40
Debug Port (Reserved)
41
M.2-2230 Slot
