Fanless PC system for POS application

The Shuttle POS DS100 is a sleek comple te mini PC system with a

robust 1.3-litre metal chassis and except ional connectivity. The array of modern connec tors include HDMI 2.0a, Display Port 1.2, USB 3.2 Gen.1, but also traditional ports like VG A, COM and USB 2.0 are part of the pack age whic h are particularly important for commercial applic ations. With Dual Gi gabit LAN and WLAN -ac/ Bluetooth built in, network connectivity is extensive. Thanks to its passive cooling and SSD storage , the system is virtually main tenance -free and appro ved for 24/7 nonstop operation. It is big o n performance , yet extreme ly ene rgy-efficient - the ideal platform for professional applications such as digital signage, POS, Kiosk, Thin Client, Office PC and Multimedia.

Feature Highlights

Slim Design

 Slim 1.3-litre metal chassis, black  Dimensions: 20 x 16.5 x 3.95 cm (LWH)  Incl. Stand & VESA mount (75/100 mm)

Operating

System

 An operat ing system is not included  Compatible with Windows 10, Linux (64-bit)

Processor

 Intel Celeron 4205 U, Dual Core, 15 W TDP

Intel ULV “Whiskey-Lake-U” Generation

 Integrated Intel UHD graphics 610, DX12  Fanless heatpipe cooling

RAM

 4 GB DDR4-2133 , 260-pin SO-DIMM

Storage

 120 GB SSD, 2.5” drive, SATA 3 interface  M.2 2280 slot supports optional M.2 card

Connectors

 HDMI 2.0a, DisplayPort 1 .2 , D-Sub/VGA  4x USB 3.2 Gen 1 (5 Mbps ), 4x USB 2.0  SD card reader , 2x Intel Gigabit LAN  2x Audio (Line out + m ic)  1x COM port (RS232/RS422/RS485)  Connector for external power button

WLAN

 WLAN 802.11ac with two external antennas

Power Supply

 Externa l 65 W fanless power adapter

Optional

Accessories

 CXP01: adapter cable f. ext. power button  PRM01: 2U rack mount kit for two P Cs  PCP11: adapter cable for 2nd COM port  DIR01: DIN-Rail mounting kit

Shuttle XPC slim

POS DS100

PC system without operating system

Images for illustration purposes o nly.

2 Slots

M.2 + 2.5”

COM Port

Shuttle Products based on DS10U Series:

Type

Model

Processor

RAM

Storage

OS

Bare-

bone

DS10U

Celeron 4205U

— — —

DS10U3

Core i3- 8145U

— — —

DS10U5

Core i5- 8265U

— — —

DS10U7

Core i7- 8565U

— — —

Fix

System

POS DS 100

Celeron 4205U

4 GB

120 GB SSD

—

POS DS 100P

Celeron 4205U

4 GB

120 GB SSD

Win 10 IoT

BTO

System

DS10UX A

BTO

—

DS1000B

BTO

Win 10

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 2 2 1 January 202 0

. Pictures for illustration purposes only.

Shuttle XPC slim POS DS100 – Product Views

4

3

1

2

5

6 7 4

8

12

13

15

14

11

17

8

16

10

9

1

Headphones output

2

Microphone input

3

SD card reader

4

4x USB 2.0

5

On/Off power button

6

Hard disk LED indicator

7

Power LED indicator

8

4x USB 3.2 Gen 1

9

Stand with screws

10

Pin connector for external power button or CMOS button or 5 V DC voltage supply

11

2x WLAN antenna

12

HDMI 2.0a output

13

Display Port 1.2 output

14

D-Sub / VGA

15

COM 1: RS-232/422/485

16

2x RJ45 Gigabit LAN

17

DC-Input for Power Adapter

Optional Accessories

CXP01

PRM01

Adapter cable for external power

button (without button)

2U rack mount kit

for two Shuttle XPC slim

DIR01

PCP11

DIN-Rail Mounting Kit

(for standard 35 mm DIN-Rail)

COM port adapter

second COM instead of VGA

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 3 2 1 January 202 0

. Pictures for illustration purposes only.

Mainboard Overview

1 2 5 6 7 8

9

11

12

10

26

27

28

15

14

25

23

21 21 20 19 18 17 16

3 4

24

13

22

1

2x USB 3.2 port

2

2x USB 2.0 port

3

Power LED

4

Hard Disk Drive LED

5

Power Button

6

2x USB 2.0 port

7

Connector for Microphone

8

Connector for Headphones

9

Debug header

10

Header for COM 2 port

11

2x SO-DIMM slot for DDR4 RAM

12

M.2-2280 slot

13

Location of the processor (back side)

14

Always-On jumper (JP9)

15

VGA onboard connector

16

Connector for external power button

17

HDMI 2.0a video output

18

DisplayPort 1.2 video output

19

COM port (D-Sub)

20

2x USB 3.2 port

21

2x Gigabit LAN port

22

DC connector for power adapter

23

COM port jumper (Pin-9 voltage setting)

24

M.2-2230 slot (with WLAN card)

25

Connector for CMOS battery

26

USB 2.0 onboard connector

27

Area of the 2.5” bay

28

Onboard SATA connector

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 4 2 1 January 202 0

. Pictures for illustration purposes only.

Shuttle XPC slim POS DS100 – Product Features

11 cm

16.5 cm

20 cm

3.95

Robust, Stylish and Extremely Small

You should have held it in your own hands t o experience how small it actually is. Barely 1.35 litre in volume, its rigid steel chassis design meets the high standards towards quality and stability that are essential for prof essional a pplications like digital signage. Despite its diminutive size, the process ing power inside the POS DS100 is sufficient to meet the needs of the most dem andin g multimed ia and comput ational workloads. The well-des igned interior of the POS DS100 makes installations and upgrades simple. Other than rough environments, its sleek and stylish look also blends seamlessly in both home and office.

Ease of installation thanks to bay covers

The Shuttle XPC slim POS DS100 features two practical bay covers at the bottom of the chassis which make the installation or upgrade of hardware components a breeze. No cable is r equired and no cooli ng system needs to be installed .

24/7 nonstop operation and 0~40°C temperature range

The Shuttle XPC slim POS DS100 is officially approved for 24/7 permanent operation. Thanks to its low power consumpt ion and completely passive cooling, this PC runs highly reliably making it perfectl y suitable for digital signage and POI/POS appl ications – even at ambient temperatures of up to 40 °C.

Conditions for permanent use:

- Free circulation of air amongst the PC must be guaranteed

- Ventilation holes must stay clear

No fan noise

A large heats ink is concealed behind a plastic cover and cools down the processor in a pass ive way without any fan. Using an SSD drive instead of a hard disk makes the system virtually noiseless and hence perfectly suitable for noise-sensitive environments like e.g. a library, living room, music stud io or even a bedroom.

Energy-saving

Power consumption mainl y depends on system load. Equipped with a

2.5” SSD drive, the system consumes about 6 W in idle mode. Assuming the device runs 5 days a week for eight hours a day in idle mode, the annual consumption would amount to less than 12,5 kWh which would mean just 4 Euros on the power bill (30 Euro ct/kWh) - way less than a conventional desktop PC draws.

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 5 2 1 January 202 0

. Pictures for illustration purposes only.

Energy-efficient Intel® Whiskey Lake-U Processor

The Shuttle XPC slim POS DS100 is equipped with an Intel® Core processor of the Whiskey Lake-U series which is soldered to mainboard and passively cooled by a large heatsink. This ultra low voltage (ULV) processor belongs to Intel's 8th-generation Intel Core processor family manufactured in a new energy-efficient 14 nm architecture. As a result of further integration, it c omes as a system-on-a-chip (SoC) without the need of an extra chipset. The integrated Intel HD-Grap hics engine supports DirectX 12 and Ultra HD / 4K resolution via DisplayPort 1.2 or HDMI 2.0a.

Triple Display with HDMI 2.0a, DisplayPort 1.2 and VGA

The POS DS100 features three video outputs which helps improve on productivity by allowing for spreading mult iple windows across three monitors while working with them simultaneously. It even supports two Ultra HD disp lays at 60 Hz via its digital HDMI and DisplayPort outputs.

Dual Intel Gigabit LAN Network

The Shuttle XPC slim POS DS100 supports Dual Gigabit LAN with Intel network adapters, which are popular for their excellent performance and driver compatibility and are the preferred choice for profession al environments.

RS-232/422/485 serial port

Many PCs do not have these legacy ports any longer, since they have been superseded and replaced b y USB for most consumer applications, but they are still commonly used for applicati ons such as industrial automation, scientific analysis, POS systems and other such fields of application. The S huttl e XPC slim POS DS100 features one s erial RS-232/422/485 port which also support s both 5 and 12 V auxiliary voltage. Optionally, a second RS-232 COM p ort can be installed, if the VGA port is not required.

M.2-2280-Slot for SSD cards

The M.2-2280 slot supports M.2 SSD storage cards with PCIe inter face and NVMe support or the SATA standard. Type 2280 means, it supports the usual M.2 cards with a width of 22 mm and a length of 80 mm, but also 2242 and 2260 standard cards are supported.

SD Card Reader

The built-in SD card reader at the front makes fil e transfer from and t o a digital camera easy. It takes SD, SDHC and SDXC memory flash cards in standard size format and also supports booting from bootable SD cards.

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 6 2 1 January 202 0

. Pictures for illustration purposes only.

External power button

If space is an object (e.g. in case of a fixed installation) and the machine cannot be switched on by pressing the front power button, it can be powered on by a separate remote line (also see Shuttle Accessory CXP01). An appropr iate four-pin-connector “SW2” can be found at the back panel of the Shuttle XPC slim POS DS100 (pitch 2.54 mm). In addition, this connector also provides the Clear CMOS function and an e xternal 5 V DC voltage supply.

Pin 1-3

Connect external power button (us e a t empor ary switch)

Pin 3-4

Close these pins f or 3 seconds to perform a Clear CMOS

Pin 2-3

External + 5 V DC voltage (Pin 3 = Ground).

Location of Jumper J9

Power on after Power fail

The BIOS setup provides a "Power-On after Power Fail " function that can be found under "Power Management Configuration". As the name indicates, this fu nction determines t he PC's behaviour after p ower failure: (1) unconditional power on, (2) restore former status, (3) keep system turned off or (4) Power On by LAN. As a matter of the nature of this function , it may fail after short power failures. This is why the POS DS100 also comes with a hardware-based solution. By removing Jumper J9 (see quick guide) the system will start unconditionally once power is applied.

Kensington Lock

This is a small, m etal-reinforced hole as part of an anti-theft syst em. The Shuttle XPC s lim POS DS100 provides an appropriate hole on both sides of its chassis. The lock-and-cable is not included.

VESA mount

The supplied 75/100mm VESA mount allows the Shuttle XPC sl im POS DS100 to be wall-mounted or just to be affixed on the rear side of a monitor which is partic ularly interesting for the industry segment, company buildings and public institutions. Besid es, t he chassis of the Shuttle XPC slim POS DS100 provides n umerous threaded holes (M3) enabling it to be fitted almost anywhere.

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 7 2 1 January 202 0

. Pictures for illustration purposes only.

Shuttle XPC slim POS DS100 - Specifications

Fanless and

Silent

Equipped with passive cooling and SSD drive , no fan noise at all Perfect to be used in noise-sensitive environments Fanless, dust -free and thus virtually mainten ance -free

Low Power

Consumpt ion

Power consumption in idle mode with 2.5" SS D und er Windows 10: ca. 6 W on ly

24/7 Nonstop

Operation

This device is approved for 24/7 permanent operation. Requirements:

- Free circulation of air amongst the PC must be guaranteed.

- Ventilation holes must stay clear.

Chassis

Slim-PC with black steel chassis Without cooling fan, passive cooling only Bays for memory, 2.5" drive and M .2 card can easily be accessed by removing two cover plates. Dimensions: 200 x 165 x 39.5 mm (LWH) = 1.3 litr es Weight: 1.5 kg net and 2.2 kg gross Two holes for Kensington Lock and numerous threaded holes (M3) at both sides of the chassis

Operating

Position

1) Vertical: Usual operat ing pos ition with the supplied feet (DisplayPort output facing up).

2) VESA-mounted: The devi ce can also be mounted behind an appropriate monitor using the supplied VESA mount kit. Note: From a thermal po int of view horizontal operation is p ermitted . However, ther e are no rubber feet on t he device. The maximum operating temperat ure i s 35 °C then.

Operating

System

This barebone system comes without operatin g system. It is compatible with Windows 10 (64-bit) and Linux (64-bit).

Processor

Model: Intel Celeron 4205U (ULV) System-on-a- chip architecture (SoC) with integrated memor y and graphics controll er: no chipset required FCBGA1528 package - directly soldered onto the mainboard Code name: Whiskey Lake U (8th Generat ion Intel Core) Cores / Threads: 2 / 2 Clock rate: 1.8 GHz L1/L2/L3 Cache: 128 kB / 512 kB / 2048 kB TDP wattage: 15 W maximum Manufacturing process: 3rd-generation enhanced 14nm++ Maximum Tjunction Temperature: 100 °C Supports 64-bit, VT-x (EPT), VT-d, Enhanced SpeedStep, NX bit, AES-NI, SSE 4.1/4.2

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 8 2 1 January 202 0

. Pictures for illustration purposes only.

Integrated

Graphics

Intel UHD Graphics 610 GPU clock frequency: 300~900 MHz Execution Units (EUs): 12 Supports DirectX 12 Supports full H264 , H265 8/10 bit , VP8/9, VC-1, AVC hardwar e decoding Supports Quick Sync Video and Clear Video H D tec hnology Supports up to thr ee independent screens:

1) DisplayPort 1.2 supports Ultra HD @ 60 Hz

2) HDMI 2.0a supports Ultra HD @ 60 Hz

3) D-Sub/VGA supports analog displays

Mainboard

BIOS

Shuttle Mainboar d DS10 All capacit ors are high quality solid capacitors Supports resume after power failure [6] Supports Wake on LAN (WOL) Supports Power on by RTC Alarm Supports boot from M.2 SSD cards, USB devices and SD card reader AMI BIOS in 8 MByte EEPROM with SPI interface Supports hardware monitoring and watch dog function Supports Unified Extensible Firmware Interface (UEFI) Supports Firmware-TPM (fTPM) Version 2.0

Power

Adapter

External 65 W power adapter (fanless) Input: 100~240 V A C, 50/60 Hz, ma x. 1.6 A Output: 19 V DC, max. 3.42 A, max. 65 W DC cable length: ca. 170 cm AC cable length: ca. 170 cm (with 2 -pin Europlug)

DC Input

DC Input Connector: 5.5 / 2.5 mm (o uter/inner diameter) The DC-input of the computer supports an external power source with either 12V±5% or 19V±5%.

Memory

(RAM)

4 GB DDR4-2133 (PC4-17000) SDRAM at 1.2 V SO-DIMM module with 260 pins Two SO-DIMM s ocket supports a maximum of 16 GB each Maximum total size: 32 GB

SSD Drive

120 GB SSD drive in 6.35 cm / 2.5" format with SATA 3 interface

M.2 Slot for

SSDs

The M.2 2280 BM slot provides the following interfaces:

- PCI-Express Gen. 2.0 X4 with up to 2 GB/s

- SATA v3.0 (max. 6 Gbps) It supports M.2 cards with a width of 22 mm and a length of 42 , 60 or 80 mm (type 2242, 2260, 2280). Supports M.2 SATA SSDs (with B+M key) and M.2 PCIe NVMe SSDs (with M key)

Card Reader

Integrated SD card reader Supports SD, SDHC and SDXC memory flash cards Supports booting from SD card

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 9 2 1 January 202 0

. Pictures for illustration purposes only.

Audio

Audio Realtek® ALC 662 High-Definition Audio Two analog audio connectors (3.5 mm) at the back pan el:

1) 2 channel line out ( headphones), 2) microphon e inp ut Digita l multi -channel audio output: via HDMI and DisplayPort

Dual Intel

Gigabit LAN

Dual network with two RJ45 ports Used network chips:

1) Intel i211 Ethernet Contr oller with MAC, PHY and P CIe int erface

2) Intel i219LM PHY connected to the MAC of the processor Supports 10 / 100 / 1.000 MB it/s operation Supports WAKE ON LAN (W OL) Supports network boot by Preboot eXecution Envir onment (PX E) Supports Teaming mode [3]

Wireless

Network

(WLAN)

Built-in M.2-2230-A/E WLAN card with connectors f or tw o external antennas WLAN Controller Realtek RTL8821AE Supports WiFi IEEE 802.11b/g/n/a c in the 2.4 / 5 GHz band, 1T1R Supports 20 / 40 / 80 MHz channel bandwidth Security: supports WPA( -PSK), WPA2(-PSK), WEP 64/128 bit, IEEE 802.11x, IEEE 802.11i Supports Bluetooth 4.0 in the 2.4 GHz band

Front Panel Connectors

2x USB 3 .2 Gen 1 (max. 5 Gbps) 4x USB 2.0 Microphone input Audio Line-out (headphones) SD card reader (supports SD, SDHC, SDX C) Power button Power LED (blue) HDD LED (yellow)

Back Panel

Connectors

DisplayPort 1.2 HDMI 2.0a D-Sub/VGA 2x USB 3 .2 Gen 1 (max. 5 Gbps) 2x Intel Gigabit LAN (RJ45) Serial COM port (5 V / 12V, switchable to RS232 / RS422 / RS485) [1] DC-input connector for external power adapter 4-pin connector "SW2" (2.54 mm pitch) for power button, Clear CMOS and 5 V DC [4]

Always-On-

Jumper

By removing Jumper J9 (please ref er to the quick user guide), the system will start unconditionally once power is applied. [6]

Scope of

Delivery

Multi-languag e user gui de Two metal feet with four screws M3 x 7 VESA mount for 75/100mm standard (two metal brackets) Four screws M3 x 7 mm (screws together VESA mount and PC) Four screws M4 x 10 mm (to fix the VESA mount to the external surface) Two screws M3 x 5 mm to mount a 2.5" storage in the bay Two screws M3 x 5 mm to mount M.2 cards Driver DVD for Windows 10 (64-bit) External 65W power a dapter wit h pow er cord (Europlug)

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 10 21 January 2020

. Pictures for illustration purposes only.

Optional

Accessories

PCP11: adapter cable for the second COM port (replaces the VGA port) CXP01: adapter cable for external p ower button PRM01: 2U rack mount fr ont plate for two Shuttle XPC slim DIR01: mounting kit for 35 mm DIN-Rail

Environmental Specifications

Operating temperature range: 0~40 °C [5] Relative humidity, non-condensing: 10~90%

Conformity

Certification s

EMI: FCC, CE, BSMI, C-Tick Safety: ETL, CB, BSMI Other: RoHS, Energy Star, ErP This device is classed as a technical informati on eq uipment (ITE) in class B and is intended for use in living room and office. The CE -mark approves the conform ity b y the EU dir ectives: (1) 2014/30/EU relating to electr omagnetic compatibility (EMC), (2) 2014/35/EU relating to Ele ctrical Equipment designed for use within certain voltage limits (LVD), (3) 2009/125/EC relating to eco design requirem ents for energy-related pr oducts (ErP), (4) 2014/53/EU Radio Equipment Directive (RED)

Power Consumption:

Configuration: BIOS V1.00, 2x 4GB DDR4-2400, SSD SATA 2.5" Samsung 120GB 750 EVO, Windows 10 Pro (64-bit) 1809

DS10U

DS10U3

DS10U5

DS10U7

CPU

Cel. 4205U

i3-8145U

i5-8265U

i7-8565U

Win 10 idle

5.72 W

Win 10 full load

26.39 W

32.85 W

33.77 W

33.89 W

Win 10 S3 (standby)

0.85 W

Win 10 S5 (EUP=ON)

0.19 W

Win 10 S5 (EUP=OFF)

0.51 W

Product Specifications

w w w . s h u t t l e . eu

Shuttle C o m p u t e r H a n d e l s G m b H

Fr it z- St ras sma nn-S tr . 5 25 337 El msh or n | Ge r ma n y

Te l. +4 9 ( 0 ) 412 1 -4 7 6 8 6 0 Fa x + 4 9 ( 0) 41 21- 47 69 00 sa les @sh ut tle .eu

Page 11 21 January 2020

. Pictures for illustration purposes only.

Footnote:

[1] Jumper for COM port configuration Pin 9 of the COM-Port is a multi-functiona l signal. Based on the Jumper JP1 configuration on the mainboard, it can be configured as Ring Indicator ( RI) or external power supply with a voltag e level of either 5 V or 12 V. Each COM port can be config ured separately. The operating mode of COM 1 can be set to RS2 32, RS422 or RS48 5 in the BIOS. The second COM port (COM 2) supports RS232 mode only, and in the standard SKU of POS DS100 this is only available as an onboard connector on the main board. An appropriate adapter ( e.g. the optional access ory PCP11) is required in order to provide this port as D-Sub connector at the back panel. In this case the VGA port cannot be used.

[2] LTE Adapt er Kit WWN03 Using the opt ional L TE adapter kit WWN03 means, that the 2.5" bay can no longer be used for SATA drives in 2.5" format (hard disk or SSD). An SSD card in the M.2-2280 format must be used instead .

[3] Teaming Mode The teaming function allows you to group both availab le network adapters together to function as a single adapter. The benefit of this appr oach is that it enables load balanci ng and fa ilover. Driver download: https://downloadcenter.intel.com/download/21642

[4] Four -pin header at the bac k panel This header allows for connecting an external power button. It also provides 5 V DC voltag e for external devices and the Clear CMOS function. Optional accessory: the adapter cable CXP01.

[5] Caution: For ambient temperatur es higher than 35 °C we strongly recommend to use an SSD instead of an HDD .

[6] Power on after power fail: The BIOS setup provides a "Power-On after Power Fail" function that can be found und er "P ower Management Configuration ". This function determines the PC's behaviour after power failure. As a matter of the nature of this function, it may fail after short pow er failures. This is why the Shuttle XPC slim POS DS100 also comes wit h a hardware-based solution. By removing Jumper J9 (please refer to the quick user guide), the syst em will start unconditionally once power is applied.

[7] HDMI output supports DVI-D w ith an optional adapter.

[8] How to convert DisplayPort into HDMI/D VI The DisplayPort output can be con verted to HDMI or DVI by an additional, passive adapter cable. For example: DELOCK 82590: 1 m, DisplayPort (male, 20p) to HDMI -A (male, 19p) DELOCK 82435: 5 m, DisplayPort (male, 20p) to DVI-D (male, 24p) The integrated graphics automatically detects the connected display and puts out the appropriate electric signal either through DisplayPort (without an adapter) or HDMI/DVI (with an adapter). However, a monitor with a DisplayPort connector cannot be connected to the HDMI port with a simple, passive adapter.

Shuttle DS100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
