Shuttle DH110 Series Quick Manual
__p
DH110 Series Quick Guide【English】
Jumper Settings
Front Panel
C. Memory Module Installation
53R-DH1103-H001
Back Panel
L
The product’s colour and specications may vary from the actually shipping product.
A. Begin Installation
D. Component Installation
Safety Information
Read the following precautions before setting up a Shuttle XPC.
CAUTION
Incorrectly replacing the battery may damage this computer.
Replace only with the same or equivalent as recommended by Shuttle.
Dispose of used batteries according to the manufacturer's instructions.
E. Complete
1. Unscrew the two screws of the chassis cover.
1. As shown, unfasten the screw rst.
B. CPU and ICE Module Installation
5. Place a HDD or SSD in the rack and secure with the four screws from
the side.
Please note the pins of the LGA 1151 socket bend easily.
Always apply extreme care and little force when installing a CPU
and limit the number of times you remove or exchange it. Before
installation, make sure to turn o the computer and unplug the
power cord from the mains to avoid damage.
For safety reasons, please ensure that the power cord is
disconnected before opening the case.
DO NOT touch socket contacts. To protect the CPU socket, always
replace the protective socket cover when the CPU is not installed.
Please be aware of the CPU orientation, DO NOT force the CPU into
the socket to avoid bending of pins and damage of the CPU!
Please do not apply excess amount of thermal paste.
2 . Complete.
2. Slide the cover backwards and upwards.
3. Unfasten the rack mount screw and remove the rack.
1. Unfasten the four ICE module attachment screws and unplug the fan
connector.
Please press the "Del" key while booting to enter BIOS. Here,
please load the default BIOS settings.
3. First unlock and raise the socket lever.
Follow the steps below to correctly install the CPU into the
motherboard CPU socket.
5. Please orientate the CPU correctly and align the CPU notches with the
socket alignment keys. Make sure the CPU sits perfectly horizontal,
then push it gently into the socket.
4. Tear o the protective membrane from the metal load plate. Lift the
metal load plate from the CPU socket.
6. Close the metal load plate, lower the CPU socket lever and lock in place.
7. Spread thermal paste evenly on the CPU surface.
1. Locate the SO-DIMM slot on the mainboard.
2. Align the notch of the memory module with the one of the memory slot.
F1. MIC-in
F2. Headphone
F3. Power LED
F4. HDD LED
F5. Power Button
F6. SD Card Reader
F7. USB 3.0 Port
F8. USB 2.0 Port
Motherboard Illustration
Left / Right Panel
4. Connect the fan connector.
Kensington
®
Lock Port
Kensington
®
Lock Port
B1. COM1 Port
(RS232/RS422/RS485)
B2. COM2 Port (RS232 only)
B3. Power Jack (DC IN)
B4. HDMI Port
B5. DisplayPort
B6. eSATA+USB 2.0 Combo
B7. LAN Port
B8. USB 3.0 Port
B9. PS/2 Port
B10. Clear CMOS & Power Button
5. Repeat the above steps to install additional memory modules, if required.
1. Replace the cover and refasten the screws.
AC Back Auto Power ON (JP2)
J1
J2
Fan Connector (CPU_FAN1)
Battery Connector (CN1)
1
2
notch
SO-DIMM slot
F5 F6
F7
F1 F2 F3 F4
F8
HDD Rack
Triangle Pin1
Marking on the CPU
Notch on the CPU/
Alignment Key of the
CPU Socket
Socket
1151
CPU
Retention tab
Metal load plate
Thermal Paste
application area
Load lever
3. Gently insert the module into the slot in a 45-degree angle.
4. Carefully push down the memory module until it snaps into the
locking mechanism.
Serial ATA Cable
6. Connect the Serial ATA to the HDD or SSD.
Slide the rack into the chassis and refasten the screws.
2.
Install the M.2 device into the M.2 slot and secure with the screw.
Tear o the protective
membrane.
Metal load plate
Default：Short 1-2 =>Function Disable
4 3 2 1
Audio Connector (AUDIO1)
J4
13
11
9
7
5
3
1
14
12
10
8
6
4
2
J7
Debug Connector (DBG1)
COM Port (COM1,COM2)
J6
J8
VGA Connector (CN6)
J9
2. Remove the ICE module from the chassis and put it aside.
3. Screw the ICE module to the mainboard. Note to press down on the
opposite diagonal corner while tightening each screw.
Fan connector
Fan connector
2
4
3
1
This mainboard does only support 1.35V DDR3L SO-DIMM
memory modules.
B3
B2
B1
B4
B8
B9
B10
B5 B6
B7
1
2
J3
USB Connector (CN12)
4 3 2 1
COM1 & COM2 Power Switch (JP1)
J5
2 4 6 8 10
1 3 5 7 9
USB 2.0 (x2) Port
USB 3.0 (x2) Port
SD Card Reader Slot
Power Button-SW2
Fan Connector
-CPU_FAN1
AC Back Auto
Power ON-JP2
LAN Port-LAN1,LAN2
USB 3.0 (x2) Port
Headphone
MIC-in
COM PORT-COM1,COM2
Debug Connector-DBG1
VGA Connector-CN6
Clear CMOS & Power
Button-SW1
COM1 & COM2 Power
Switch-JP1
DisplayPort
HDMI Port
DC IN
Intel H110 Chipset
DDR3L SO-DIMM Slot
LGA1151 Package
CPU Socket
Audio Connector
-AUDIO1
Battery Connector
-CN1
Power LED
HDD LED
J2
J5
J4
J1
M.2 2230 A,E Key slot
J7
J6
J8
PS/2 Port
USB Connector
-CN12
eSATA+USB 2.0
Combo
J3
J9
SATA Cable Connector
-SATA1
J10
2 4 6 8 10
1 3 5 7 9
1=AMP(+)
2=GND
1=GND
2=+12V
3=SPEED_SENSE
4=PWM_CTRL
1=GND
2=DATA+
3=DATA4=+5V
1=
10K to AGND
2=
LINE-R
3=NA
4=
LINE-L
5=
5.1K to AGND
6=
FRONT-L
7=
NULL
8=
JACK_DET
9=
20K to AGND
10=
FRONT-R
11=
AUDIO1-JD
12=MIC-R
13=AGND
14=MIC-L
1=-XRI1
2=COM_-XRI1
3=-XRI2
4=COM_-XRI2
5=+5V
6=+5V
7=COM1_PWR
8=COM2_PWR
9=+12V
10=+12V
2 4 6 8 10
1 3 5 7 9
1=DCD
2=RX
3=TX
4=DTR
5=GND
6=DSR
7=RTS
8=CTS
9=RI
10=NULL
1=LCLK_24M
2=LAD1
3=LRESET4=LAD0
5=LFRAME-
6=+3.3V
7=LAD3
8=GND
9=LAD2
10=NULL
1=GND
2=GND
3=DDC_CLK
4=GND
5=DDC_SDA
6=GND
7=GND
8=GND
9=VSYNC
10=GND
11=HSYNC
12=GND
13=GND
14=GND
15=BLUE
16=+5V
17=GREEN
18=+5V
19=RED
20=+5V
1 19
2 20
Clear CMOS & Power Button (SW1)
J10
2
1
4
3
1=BATPWR(+3V)
2=GND
1=RTCRST2=+5V
3=GND
4=PWRSW-
M.2 2242/2260 M Key slot
M.2 2230 A,E
Key slot
M.2 2242/2260 M
Key slot
1
COM PORT Pin 9 "Ring Indicator" (RI) conguration:
Congure COM 1 with the rst jumper:
- Short Pin 1-2: Pin 9 = RI (default)
- Short Pin 5-7: Pin 9 = +5V
- Short Pin 7-9: Pin 9 = +12V
Congure COM 2 with the second jumper:
- Short Pin 3-4: Pin 9 = RI (default)
- Short Pin 6-8: Pin 9 = +5V
- Short Pin 8-10: Pin 9 = +12V
62R-DH1100-5201 DH110
English.Spanish.Korean.
Traditional Chinese.Japanese.
French. German Quick Guide
Latch
Latch
3
45-degree
angle
1
2
