AT30
Pentium 4 Processor
Based MAIN BOARD
User's M anual
70
Shuttle AT30
Intel Pentium 4 based Mainboard
Manual Version 1.0
Copyright
Copyright© 2001 by Shuttle Inc . All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system, translated into
any l anguage, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, photocopying, manual, or otherwise, without prior written permission from Shuttle Inc.
Discl aimer
Shuttle Inc. shall not be liable for any incidental or consequential damages resulting from the performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual. Information in this manual has been carefully checked for reliability; however, no guarantee is given as to
the correc tness of the contents. In the interest of continued product improvement, this company
reserves t he right to revise the manual or include changes in the specifications of the product described wi thin it at any time without notice and without obligation to notify any person of such revision
or changes . The information contained in this manual is provided for general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Pentium is a registered trademarks of Intel Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification purposes
only and may be trademarks of their respective owners.
1
TA BLE OF CONTENTS
WHAT’S IN THE MANUAL .................................................................... 5
Quick Reference .............................................................................................. 5
About This Manual .......................................................................................... 5
1 INTRODUCTION ................................................................................ 6
1.1 TO DIFFERENT USERS ............................................................................. 6
FIRST-TIME DIY SYSTEM BUILDER ..................................................... 6
EXPERIENCED DIY USER..................................................................... 6
SYSTEM INTEG RATOR ......................................................................... 6
1.2 ITEM CHECKLIST ...................................................................................... 7
2 FEAT URES......................................................................................... 8
2.1 SPECIFICATIO NS....................................................................................... 8
3 HARDWARE INSTALLATION............................................................11
3.1 STEP BY STEP INSTALLATION ...............................................................11
Accessories Of AT30 .............................................................................11
STEP 1 CPU Installation....................................................................... 12
STEP 2 Install RIMM system memory................................................... 15
STEP 3 Set Jumpers ............................................................................. 17
STEP 4 Install Internal Peripherals in System Case ............................. 17
STEP 5 Mount the Mainboard on the Computer Chassis...................... 18
STEP 6 Connect Front Panel Switches/LEDs/Speaker......................... 19
STEP 7 Connect IDE & Floppy Disk Drives .......................................... 20
STEP 8 Connect Other Internal Peripherals ......................................... 21
STEP 9 Connect the Power Supply ...................................................... 21
STEP 10 Connect External Peripherals to Back Panel ......................... 22
STEP 11 First Time System Boot Up .................................................... 24
STEP 12 Install Drivers & Software Components ................................. 25
2
3.2 JUMPER SETTINGS................................................................................. 26
Jumpers & Connectors Guide .................................................................. 27
Disable onboard LAN EPROM(JP17)....................................................... 30
Safe mode boot setting (JP30)................................................................. 30
USB2/CNR Select Jumper (JP15 & JP16)................................................ 31
Clear CMOS Setting ( JP14) ..................................................................... 31
FSB Speed Setting (JP29) ....................................................................... 32
PS/2 Keyboard & PS/2 Mouse Connectors .............................................. 32
COM1 and COM2 Connectors ................................................................. 33
Parallel Port Connector............................................................................ 33
USB1 / USB2 Port Connectors................................................................. 33
LAN RJ45 Connector ............................................................................... 33
Speaker_out............................................................................................. 34
Line-In...................................................................................................... 34
Mic_in....................................................................................................... 34
MIDI/GAME Port....................................................................................... 34
IDE LED Connector (HDD LED)............................................................... 35
Speaker Connector (SPEAKER) .............................................................. 35
ATX power on/off switch connector .......................................................... 36
ACPI & Power LED................................................................................... 36
Hardware Reset Connector...................................................................... 36
Enhanced IDE and Floppy Connectors .................................................... 37
CD_in Header (CN11) .............................................................................. 38
Aux Fan, CPU Fan, Chassis Fan Headers............................................... 38
ATX Power Connector (ATX 1)................................................................. 39
Dual USB Ports Header (USB 2).............................................................. 39
IR Connector (SIR 1)................................................................................ 40
Wake_on Modem Connector (WOM) ....................................................... 40
3
4 SOFTWARE UTILITY ....................................................................... 42
4.1 AT30 MAINBOARD CD OVERVIEW ................................................. 42
4.2 Install Mainboard Software................................................................ 42
4.2.A Install Chipset System Driver......................................................... 43
4.2.B Install AC97 Audio Driver............................................................... 44
4.2.C Install LAN Device Driver Manually ............................................... 45
4.2.D Install Bus Master IDE Driver Manually ........................................ 46
4.3 View the User’s Manual..................................................................... 47
5 BIOS SETUP.................................................................................... 48
5.1 ENTER THE BIOS .................................................................................... 48
5.2 THE MAIN MENU...................................................................................... 49
Standard CMOS Setup ......................................................................... 51
Advanced BIOS Features ..................................................................... 53
Advanced Chipset Features.................................................................. 57
Integrated Peripherals .......................................................................... 59
Power Management Setup.................................................................... 63
PnP / PCI Configurations ...................................................................... 65
PC Health Status .................................................................................. 66
Frequency Control ................................................................................ 67
Load Setup/Turbo Defaults ................................................................... 67
Set Password........................................................................................ 68
Save & Exit Setup/Exit without Saving .................................................. 69
4
W HAT’S IN THE MANUAL
Quick Reference
Hardware Installation >> Step-by-Step ............................................... Page 11
Jumper Settings >> A Closer Look ..................................................... Page 25
Software Utility >> How to Install ........................................................Page 42
BIOS Setup >> How to Configure........................................................ Page 51
About This Manual
For First-Time DIY System Builder........................................................Page 5
For Experien ced DIY User......................................................................Page 5
For System Integrator ............................................................................Page 5
5
1 IN TRODUCTION
1.1 To Different Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience
successful, right from the start, we have designed the 3 Hardware Installa-
tion section in a step-by-step fashion for all the first-time DIY system builders. Prior to installation, we also suggest you to read the whole manual
carefully to gain a complete understanding of your new AT30 mainboard.
Experienced DIY User
Congratulate on your purchase of the Shuttle AT30 mainboard. You will find
that installing your new Shuttle AT30 mainboard is just easy. Bundled with
an array of onboa rd functions, the highly-integrated AT30 mainboard provides you with a total solution to build the most stable and reliable system.
Refer to sections 3.2 Jumper Settings and Chapter 4 Sof tware Utility to find
out how to get the best out of your new mainboard. Chapter 5 BIOS Setup
also contains the relevant information on how to tune up your system to
achieve higher performance.
System Integr ator
You have wisely chosen Shuttle AT30 to construct your system. Shuttle
AT30 incorporates all the state-of-the-art technology of the Intel 82850
chipset. It integrates the most advanced functions you can find to date in a
ATX board. Refer to sections 3.2 Jumper Settings and Chapter 4 Software
Utility for an in-depth view of system construction.
6
1.2 Item Checklist
Check all items with your AT30 mainboard to make sure nothing is missing.
The complete package should include:
- One Shuttle AT30 M ainboard
- One ATA 100/66 Ribbon Cable
- One Floppy Ribbon Cable
- One Chassis I/O shield
- 2 pieces of Dummy R IMM
- Retention Mechanism for Pentium 4 Cooler
- AT30 U ser’s Manual
C
MC
+
- One CD-ROM containing:
Ø Intel 850 Chipset Driver
Ø AC97 Audio Driver
Ø Lan Driver
Ø ATA 100 IDE Driver
Ø Award Flashing Utility
7
2 FEATU RES
AT30 mainboard is carefully designed for the demanding PC user w ho wants high
performance and maximum intelligent features in a compact package.
2.1 Specifications
-
CPU S upport
Supports Intel Socket 423 Pentium 4 1.0~1.50GHz+ with 400MHz
system bus designed for Socket 423 technology.
-
Chipset
The Intel®- 850 chipset consists of three main components: Memory
Control Hub (MCH), I/O Control Hub 2 (ICH2) and Firmwar e Hub
(FWH). All these components ar e interconnected via an Intel® propr ietary
interface called hub interface. The hub interface designed into the Intel
850 chipset to provide efficient communication between components.
Additional hardware platform features include AGP 4x mode, Direct
RDRAM, Ultra ATA/100, Low Pin Count (LPC) interface, integrated LAN
and Universal Serial Bus (USB). The platform is also ACPI compliant and
supports Full-on, Stop Grant, Suspend to RAM, Suspend to Disk and
Soft-off power management states. Through the use of an appropriate
LAN connect, the platform supports Wake-on-LAN for remote adminis-
tration and troubleshooting.
®
-
Expansion Slots
Including five 32-bit/33M Hz PCI, one CNR and one AGP Pro slots. The
PCI local bus throughput can be up to 132MB/s. The Communication &
Networking Riser (CNR) slot provided from AT30 can support CNR
interface for a LAN/Modem/Audio card. The Acceler ated Graphics Port
(AGP) specification provides a new level of video display sophistication
and speed. The AGP video cards support data transfer rate up to
1066MB/s. As AT30 motherboard includes one AGP Pro expansion slot
for a bus mastering AGP graphic card, For AD and SBA signaling, AT30
can support 133MHz 2X/4X mode.
8
-
Memor y Support
Provides four 184-pin DRDRAM DIMM socket that support up to 2GB of
PC-600/700/800 compliant DRDRAM (Direct Rambus DRAM). You may
install 64, 128, 256 or 512MB with ECC (Error Checking and Correction)
RDRAM RIMM modules into each socket.
-
Ultra DMA 100/66/33 Bus Master IDE
Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels, supports Ultra DMA
100/66/33, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and
supports Enhanced IDE devices.
-
On-board AC97 S ound
AX4T uses the SIGMATEL AC97 sound chip. This on-board audio includes
a complete audio recording and playback system.
-
Four USB Connectors
Provides two ports, four USB connectors for USB interface devices, such as
mouse, keyboard, modem, scanner, etc.
-
Power Managem ent/Plug and Play
The AT30 supports the power management function that confirms to the
power-saving standar ds of the U.S. Environmental Protection Agency (EPA)
Energy Star progr am. It also offers Plug-and-Play, which helps save users
from configuration problems, thus making to system user-friendlier.
-
Hardware Monitoring Mangement
Supports CPU or system fans status, temperature and voltage monitoring
and alert, through the on-board hardware monitor module.
-
Enhanced ACPI
Fully implement the ACPI standard for Windows® 95/98/ME/NT/2000 series
compatibility, and supports Soft-Off, STR (Suspend to RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On Modem), WOL (Wake On LAN) features.
9
-
Super I/O Interface:
The AT30 provides two high-speed UART compatible serial ports and one
parallel port with EPP and ECP capabilities. UART2 can also be directed
from COM2 to the Infrared Module for the wireless connections.
-
System BIOS
Provides licensed Award BIOS on 4Mb Firmware Hub.
Supports Green PC and Desktop Management Interface (DM I).
-
ATX For m Factor
System board confor ms to the Micro ATX specification.
Board dimension: 304 mm x 245 mm.
10
3 HARDWAR E INSTALLATION
Before removing or installing any of these devices including CPU, RIMMs, Add-On
Cards, Cables, please make sure to unplug the onboard power connector.
This section outlines how to install and configure your AT30 mainboard. Please refer to
following mainboard layout to help you identifying various jumpers, connectors, slots,
and ports. Then follow these steps designed to guide you through a quick and correct
installation of your system.
3.1 Step-by-Step Installation
Accessories Of AT30
PS2 Keyboard /
PS/2 Mouse Connectors
Serial Port Connector
(COM1)
Parallel Connector
Socket 423
Serial Port Connector
(COM2)
USB1/USB2 Connectors
Intel 850 Chipset
Speaker Out/Line_In/Mic-In
MIDI/GAME Port Connectors
AGP Pro External Power
Connector
CD-IN Connector- CN11
AUX Fan Connector- FAN1
AGP Pro Slot
FSB Select Jumper- JP 29
Audio Connector- JP7
Modem-IN Connector- CN16
Intel 82801BA
USB2 Connector- CN20
AC97 Audio CODEC
Five PCI Slots
Wake on Modem
Connector- CN18
Ir DA Connector- CN21
CNR Slot
FAN 4
CPU FAN
CN2
CN3
CN5
CN8
CN 11
AGP PRO CN14
FAN1
PCI 1
JP7
1
CN16
PCI 2
PCI 3
CN 18
1
PCI 4
SMSC
PCI 5
CN25 CNR
AT 30
Chassis Intrusion Header- JP27
Lan EPROM Disable- JP17
Safe Mode Boot Jumper- JP 30
ATX 1
CPU FAN
SOCKET423
Four 184-Pin RIMM Sockets
24-Pin ATX Power Connector-CN7, CN4
FAN4
STK1: RIMM1
STK2: RIMM2
STK4: RIMM4
STK3: RIMM3
CN 4
CN 7: POWER2
Extra Power Connector
for 3.3V & 5V- CN6
CN 9
CN 10
CN6: POWER1
CN 12
1
JP 29
1
JP 17
1
Ir DA CN 21
ACPI &
Power
Switch
JP 30
1
1 JP 27
Power LED
1
IDE LED
4mbit Flash Rom
CN 15
Two IDE Connectors
FAN2
1
JP14
1JP 15
1
USB2 CN20
Reset
CN 24
SPEAKER
Chassis Fan Connector-FAN2
Floppy Connector
Clear CMOS- JP14
JP 16
1
USB/CNR Select
Jumper-JP15, JP16
Front Panel Connector-CN24
11
Step 1
CPU Inst allation:
This motherboard supports Intel® Pentium® 4 1.30~1.50GHz+ Socket
423 series CPU. Please follow the step as below to finish CPU installation.
Be careful of CPU orientation when you plug it into CPU socket.
1. Pull up the CPU socket level and up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut edge on the
CPU upper interface. Match Pin 1 and cut edge, then insert the CPU into
the
socket.
CPU pin 1 and
cut edge
12
3. Press down the CPU socket level and finish CPU installation.
Note: If you do not match the CPU socket Pin 1 and CPU cut edge well, it
may damage the CPU.
CPU Cooling Fan Installation:
Please follow the step as shown below to finish CPU heatsink and fan
installation:
1. Pull up the both right and left side level of CPU heatsink retention mod-
ule
and up to 90-degree angle.
13
2. Put the CPU heatsink onto the top of CPU and press down both side
levels
steady at the same time for fix the CPU heatsink. Please make sure the
levels had been holed by hook of retention module.
3. If your CPU fan supports H/W monitoring function (Normally, it has 3-
pin
connector), please plug the fan power cable on the 3-pin CPU fan
connector of motherboard, and otherwise, plug the cable on the 2-pin
fan
connector (w /o H/W monitoring function).
14
3-pin CPU Fan Connector
(with H/W monitoring
function)
2-pin CPU Fan Connector
(without H/W m onitoring
function)
Step 2
Install RIMM System Memory
This motherboard has four 184-pin RIMM sockets that allow you to install
PC600, PC700 and PC800 RDRAM up to 2GB. AT30 will detect the
RDRAM speed automatically while system POST, but it still allows you
select the RDRAM type manually by BIOS setup program.
RIMM1
RIMM2
RIMM3
RIMM4
The pictures as below are Direct RDRAM memory module and RIMM
terminator (also called C-RIMM). Please don’t forget insert the RIMM terminator into the blank RIMM socket, otherw ise it will cause the system can’t
boot.
DRDRAM RIMM Module
RIMM Terminator
Please follow the pr ocedure as shown below to finish memory installation.
1. Make sure the RIMM module’s pin face down and match the socket’s
size
as depicted below
60 Pins 88 Pins
15
2. Insert the module straight down to the RIMM slot with both hands and
press dow n firmly until the RIMM module is securely in place.
Repeat step 2 to finish additional RIMM & C-RIMM modules installation.
Direct RDRAM
Modul e
C-RIMM
Modul e
16
Step 3.
Set Jumpers
The default jumper settings have been set for the common usage standard
of this mainboard. Therefore, you do not need to reset jumpers unless you
require special adjustments as any of following cases:
1. Clear CMOS
2. Make BIOS write protected
For first-time DIY system builders, we recommend that you should not
change the default jumper settings if you are not totally familiar with
mainboard configuration procedures. The factory-set default settings are
tuned for optimum system performance. For the advanced users who wish
to customize their system, section 3.2 Jumper Settings will provide the
detailed information on how to configure your mainboard manually.
Step 4
Install Internal Peripherals in System Case
Before you install and connect the mainboard into your system case, we
recommend that you first assemble all the internal peripheral devices into
the computer housing, including but not limited to the hard disk drive (IDE/
HDD), floppy disk drive (FDD), CD-ROM drive, and ATX power supply
unit. This will greatly facilitate in making the connection to the mainboard
described below.
To install IDE & FDD drives, follow this procedure:
1. Set the required jumpers on each device according to the instructions
provided by the manufacturer. (IDE devices, HDD and CD-ROM, must
have jumpers on Master or Slave mode depending on your willing to
install more than one device for each kind.
2. Connect IDE cable and FDD cable to the back panel of the internal
peripheral devices. Note that the cable should be oriented with its
colored stripe (usually in red or magenta) connected to pin#1 both on
the mainboard IDE or FDD connector and on the device as well.
3. Connect an available power cable through your system power supply
unit to the back panel of each peripheral device. Note that the power
cable is directional and cannot fit in if not properly positioned.
17
Step 5
Mount the Mainboard o n the Computer Chassis
1. You may find that there are a lot of different mounting hole positions
both on your computer chassis and on the mainboard. To choose a
correct mounting hole, the key point is to keep the back panel of the
mainboard in a close fit with your system case, as shown below.
2. After deciding the proper mounting holes, position the studs betw een
the frame of chassis and the mainboard. The studs are used to fix the
mainboard and to keep a cer tain distance between the system chassis
and the mainboard, in order to avoid any electrical short between the
board and the metal frame of chassis. (If your computer case is already
equipped with mounting studs, you will need to tighten screws to
attach the mainboard.)
Note: In most computer housings, you will be able to find 4 or more
attachment points to install mounting studs and fix the
mainboard. If there aren’t enough matching holes, then make sure
to install at least 4 mounting studs to ensure proper attachment of
the mainboard.
18
Step 6
Connect Front Panel Switches/LEDs/Speaker
You can find there are several different cables already existing in the system
case and originating from the computer’s front panel devices (HDD LED,
Power LED, Reset Switch, PC Speaker, etc.) These cables serve to connect
the fr ont panel switches and LEDs to the mainboard’s front panel connectors group, as shown below :
ACPI &
Power
Power LED
1. IDE LED
Switch
1
IDE LED
Power
Power LED
Switch
CN24
SPEAKER
ACPI &
Reset
CN24
Reset
2. PC SPEAK ER (SPEAKER)
3. ATX Soft Power On/Off
( Power Switch )
19
1
Power
Switch
Power
Switch
IDE LED
ACPI &
Power LED
IDE LED
ACPI &
Power LED
IDE LED
CN24
CN24
SPEAKER
Reset
SPEAKER
Reset
SPEAKER
4. ACPI & Power LED
5. Hardware Reset Switch (RST)
Step 7
Connect IDE & Floppy Disk Drives
1. IDE cable connector
1
1
Power
Switch
Power
Switch
ACPI &
Power LED
IDE LED
ACPI &
Power LED
IDE LED
CN24
CN24
Reset
SPEAKER
Reset
SPEAKER
CN10CN9
2. Floppy cable connector
CN 15
20
Step 8
Connect O ther Internal Peripherals
1. IR Header
IR CN21
1
Step 9
Connect t he Power Supply
1. System power connector
21
CN 4CN 7
Step 10
Connect External Peripherals to Back Panel
You are now ready to put the computer case back together and get on to
the external per ipherals connections to your system’s back panel.
CN2
CN3
CN5
CN8
1. PS/2 Mouse and PS/2 Keyboard
2. Parallel Port
3. COM1 and COM2 Ports
22
PS/2 Mouse
PS/2 K eyboard
Parallel Port
COM1 and COM2
4. RJ45 10/100Mbps LAN Port
5. USB Ports
6. Speaker_out / Line_In
/ Mic_In Ports
LAN Port
USB1 & USB2 Ports
7. MIDI/Game Port
23
Speaker _out
Line_In
MIDI/GAME Port
Mic_In
Step 11
First Time System Boot-Up
To assure the completeness and correctness of your system installation, you
may check the above installation steps once again before you boot up your
system for the first time.
1. Insert a bootable system floppy disk (DOS 6.2x, Window s 95/98/NT, or
others) w hich contains FDISK and FORMAT utilities into the FDD.
2. Tur n on the system power.
3. First, you must use the FDISK utility to create a primary partition of the
hard disk. You can also add an extended partition if your primary
partition does not use all of the available hard disk space. If you
choose to add an extended partition, you will have to create one or
more logical partitions to occupy all the space available in the ex-
tended partition. The FDISK utility will assign a drive letter (i.e., C:,
D:, E:,...) to each partition which will be shown in the FDISK program.
After FDISK procedure, reboot your system by using the same system
floppy disk.
Note: DOS 6.2x and Windows 95A can only support up to 2.1GB of
HDD partition. If you use the FDISK utility with one of the
operating systems mentioned above, you can only install your
HDD into partitions no larger than 2.1GB each.
4. Now, use the FORMAT utility to format all the partitions you’ve cr e-
ated. When formatting the primary partition (C:), make sure to use
the FORMAT C: /S command.
Note: FORMAT C: /S can transfer all the necessary system files into the
primary partition of your hard disk. Then, your HDD will become a bootable drive.
5. Install all the necessary dr ivers for CD-ROM, Mouse, etc.
6. Set up the complete operating system according to your OS installation
guide.
24
Step 12
Install Drivers & Software Components
Please note that all the system utilities and drivers ar e designed for Win 9x/
2000/ME/NT operating systems only. Make sur e your operating system is
already installed before running the driver installation CD-ROM programs.
1. Insert the AT30 bundled CD-ROM into your CD-ROM drive. The
auto-run pr ogram will display the driver main installation window
on screen .
2. Choose " Install VGA Device Software" and complete the installation.
3. Return to the SHUTTLE MAINBOARD DRIVERS & UTILITIES scr een.
4. Choose "Install Audio Device Driver" and complete the
installation.
5. Return to the main installation window and exit from the auto-run
drivers installation program.
25
3.2 Jumper Settings
1
1
Several hardware settings are made through the use of jumper caps to
connect jumper pins to the mainboard. Pin #1 is located at any corner of
each jumper; you just find a location with pin#1 marked. There are several
types of pin1# shown as below:
3-pin and multi-pin (>3) jumpers are shown as follows:
Pin #1 to the left:
Pin #1 on the top:
Pin #1 to the right:
Pin #1 on the bottom:
1
1
1
Jumpers with two pins are shown as for Close [On] or for
Open [Off]. To Short jumper pins, simply place a plastic jumper cap over
the desir ed pair of pins.
Caution!
1. Do not remove the mainboard from its antistatic protective packaging
until you are ready to install it.
2. Carefully hold the mainboar d by its edges and avoid touching its
components. When putting the mainboard down, place it on the top
of its original packaging film, and on an even surface, and components
side up.
3. Wear an antistatic wrist strap or take other suitable measures to pr ev-
ent electrostatic discharge (ESD) whenever handling this equipment.
26
Jumpers & Connectors Guide
Use the mainboard layout on page 11 to locate CPU socket, memory
banks, expansion slots, jumpers and connectors on the mainboard during
the installation. The following list will help you to identify jumpers, slots,
and connectors along with their assigned functions:
E 1 4
E11
B 1~B 2
B 3~B 5
B 6~B 8
B 9~B 12
E 1
E 2
E 7
E 3
E 4
E 5
A 1
E 6
E 8
A 2
E 1 3
E 1 2
E 1 1
D 1
E 1 0
D 1
A 4
A 3
E 9
C 1~C 5
A 5
CPU/Memory/Expansion Slots
Socket 423 : CPU Socket for socket 423 Intel Pentium 4 pr ocessors.
RIMM 1/2/3/4 : Four RIMM sockets for PC600, PC700 and PC800
RDRAM up to 2GB.
AGP Pro : One AGP (Accelerated Graphics Port) Pro slot
PCI : Five 32-bit PCI expansion slots
CNR : One CNR (Communications and Networking R iser) slot
27
Jumpers
JP17 : Disable onboard lan EPROM.
A1
JP30 : Safe mode boot setting.
A2
JP15 & JP16 : USB 2 or CNR select.
A3
JP14 : Clear CMOS.
A4
JP29 : FSB speed select.
A5
Back Panel Connectors
B1
CN2 : PS/2 Keyboard
B2
CN2 : PS/2 Mouse
B3~4
CN3 : Serial port 1 and 2 (DB9 male).
B5
CN3 : Parallel port (DB25 female).
B6~7
CN5 : 2 × USB ports (Universal Serial Bus).
B8
CN5 : RJ45 10/100Mbps lan port
B9
Speaker _out : Speaker_out port.
B10
Line_In : Line_in port.
B11
Mic_In : Mic_in port.
GAME/MIDI: GAME/MIDI port.
B12
Front Panel Connectors
C1
IDE LED : IDE drive active LED.
C2
SPEAKER : Speaker in housing.
C3
Power Switch : ATX Power On/Off Momentary Type Switch.
C3
C4
ACPI Power LED : Green LED.
C5
Reset : Hardware reset sw itch.
Internal Periph erals Connectors
FDD1 : Floppy Disk Drive Inter face
D1
IDE1 : IDE Primary Interface (Dual-channel)
D1
D1
IDE2 : IDE Secondary Interface (Dual-channel)
28
Other Connectors:
CN11 : CD-in header.
E1
E2
FN4 : Aux fan header.
E3
JP7 : Audio_in header.
E4
CN16 : Modem_in header.
E5
CN18 : Wake on modem header.
E6
CN21 : IR header.
E7
CN12 : AGP Pro external power header.
E8
JP 27 : Chassis intrusion header.
E9
CN20 : Dual USB ports header.
E10
FN3 : Chassis fan header.
CN6 : Extra ATX pow er header for 5V and 3.3V.
E 11
CN7, CN4 : ATX power header.
E12
FAN1 : CPU Fan
E13
FN2 : CPU Fan
E14
29
A1
Disable On board LAN EPROM (JP17)
The CNR interface provides four kinds of solution for users: audio, modem,
LAN and Home LAN. Hence, if you decide to use the LAN solution of
CNR, you should power off system and short pin 1 & pin 2 of JP17 by mini
jumpers, then run BIOS setup program to disable onboard LAN EPROM
through option “Integrated Peripherals > Onboard/CNR LAN selection”.
1
Pin 1-2 (Disable onboard lan)
JP17
1
1
Pin 2-3
(Default, Enable onboard lan)
A2
Safe Mode Boot Setting (JP30)
This jumper allows you to force system boot in “Safe mode”. The “Safe
mode” means system will load BIOS default setting value while in POST
and force CPU speed at 800MHz. You can short pin 1-2 of JP30 by mini
jumpers to enable safe mode boot.
1
Pin 1-2 (Enable- safe mode boot)
1
Pin 2-3 (Normal- Disable the function)
30
JP30
1
1
1
A3
USB 2 / CNR Select Jumper (JP 15 & JP16)
This mainboard provides 4 U SB headers to connect USB devices, such as
mouse, keyboard, modem, printer etc. There are two connectors on PC99
back panel. You can use proper cable to connect others USB connectors to
back panel or front panel of chassis. By the way, if you want to use the USB
solution of CNR, please short pin 2 - pin 3 of JP15 / JP16.
Function
Onboard UDSB
(Default)
CNR USB
A4
Clear CMOS S etting (JP14)
Jumper Setting
1
1
1
JP15
1
You can clear CMOS to restore system default setting. Please follow below
procedure to clear CMOS.
Pin 2-3 (Clear CMOS)
JP14
Pin 1-2 (Default- Normal)
JP16
1
1
1
Step 1. Turn off the system and unplug the AC power.
Step 2. Remove ATX power cable from onboard power connector.
Step 3. Locate JP1 and short pins 2-3 for a few seconds.
Step 4. Return JP1 to its normal setting by shorting pins 1-2.
Step 5. Connect ATX power cable back to onboard power connector.
31
A5
FSB Speed Setting (JP29)
This jumper is used to select CPU FSB frequency manually. If you are not
an overclocker, we recommend you to keep the jumper setting at default.
1
Pin 1-2 (133 MHz)
JP29
1
Pin 2-3 (100 MHz)
1
32
B2B1
PS/2 Keyboar d & PS/2 Mouse Connectors
Two 6-pin female PS/2 keyboard & Mouse
connectors are located at the re ar panel of
the mainboard. Depending on the computer
housing you use (desktop or tower), the PS/
2 Mouse connector is situated at the top of
the PS/2 Key board connector when the
mainboard is laid into a desktop, as opposite to a tower case where the PS/2 Mouse
connector is located at the right of the PS/2
Keyboard's. Plug the PS/2 key board and
mouse jacks into their corresponding connectors.
B3
B4
COM1 and COM2 Connectors
This mainboard can accommodate two
serial device on COM1 and COM2. Attach a serial device cable to the DB 9 serial ports COM1 and COM2 at the back
panel of your computer.
B5
Par allel Port Connector
One DB25 female parallel connector is
located at the rea r panel of mainboard.
Plug the connection cable from your parallel device (printer , scanner, etc.) into this
connector.
PS/2 Mouse
PS/2 K eyboard
COM1 and COM2
Parallel Port
B7B6
USB1 / US B2 Connectors
This mainboard fe atures two USB ports
on back panel. Plug each USB device jack
into an av ailable USB1 / USB2 connector.
B8
LAN RJ45 Connector
This mainboard can accommodate LAN
device. Attach a 10/100 base T cable to
the RJ45 at back panel of computer.
USB1 & USB2 Ports
LAN Port
33
B9
S peaker_out
Speaker_out is a stereo output port through
which the combined sig nal of all internal
and external audio sources on the board is
output. It can be connected to 1/8-inch TRS
stereo headphones or to amplified speakers.
B10
Line_in
Line_in is a stereo line-level input port that
accepts a 1/8-inch TRS stereo plug. It can be
used as a sourc e for digital sound recording, a source to be mixed with the output,
or both.
B11
Mic_in
Microphone is a 1/8-inch jack that provides
a mono input. It can use a dynamic mono
or stereo mic rophone with a resistance of
not more than 600 Ohms.
B12
MIDI/GAME P ort
The MIDI/G AME port is a 15-pin female connector. This port can be connecte d to any
IBM PC compatible game with a 15-pin Dsub connector.
MIDI Instrument Connection
You will need a MIDI ada pter to connect a MID I compatible instrument to the
sound c ard. The MIDI adapter can be
connected to the Joystick/MIDI port. You
will also need the MIDI sequencing software to run MIDI instruments with your
computer.
Speaker _out
Line_In
Mic_In
MIDI/GAME Port
34
C1
IDE LED Connector (IDE LED)
Attach connector cable from ID E device LED to the 2-pin IDE LED header.
The IDE LED lights up w henever an IDE device is active.
ACPI &
Power
Power LED
Switch
1
IDE LED
CN24
Reset
SPEAKER
Note : Please notice all LED connectors are directional. If any LED of
CN24 does not light up during running, please simply change to
the opposite direction.
C2
Speaker Connector (SPEAKER)
Atta ch PC speaker cable from case to the 4-pin PC speaker connector
(SPEAKER).
1
35
Power
Switch
ACPI &
Power LED
IDE LED
CN24
Reset
SPEAKER
C3
ATX Power On/Off Switch Connector (Power Switch)
The Power On/Off Switch is a momentary type switch used for turning on
or off system’s ATX power supply. Attach connector cable from Power Switch
to the 2-pin PWR SW header on the mainboard.
ACPI &
Power
Power LED
Switch
1
IDE LED
C4
ACPI & P ower LED (ACPI & Power LED)
CN24
Reset
SPEAKER
If you get a 3-pin LED in dual color connector , attach the cable from housing's
front panel to the PWR LED header on board. The LED stays light while the
system is running ; and it turns to another color while the system is operating from normal mode to ACPI mode.
ACPI &
Power
Power LED
Switch
CN24
Reset
1
C5
Hardware Reset Connector (Reset)
IDE LED
SPEAKER
Attach 2-pin hardware reset switch cable to the RST header. Pressing reset
switch causes system to restart.
ACPI &
Power
Power LED
Switch
1
IDE LED
CN24
Reset
SPEAKER
36
D1
Enhanced IDE and Floppy Connectors
The AT30 mainboard features two 40-pin dual-channel IDE device connectors (CN9/CN10) providing the support to up to four IDE devices, such as
CD-ROM and Hard Disk Drives (H.D.D.). This mainboard also includes
one 34-pin floppy disk controller (CN15) to accommodate the Floppy D isk
Drive (CN15). Moreover, this mainboard comes with one 40pin ribbon
cable to connect to IDE H.D.D. and one 34-pin ribbon cable for F.D.D.
connection.
Note : Please connect your system H.D.D. to IDE 1.
Important: Ribbon cables are directional. The red stripe means pin #1.
Please make sure to always have corr ect connection with
cable and pin #1 of IDE1/IDE2 or FDD1 on the mainboard.
CN10CN9
37
CN 15
E1
GND
+12V
CD_in Header (CN11)
This header is used to connect CD audio cable from CD ROM or DVD drive
to onboard sound.
CN 11
E2
Aux Fan, CPU Fan, Chassis Fan Headers
(FAN1, FAN2, CPUFAN, FAN4)
Plug in the Aux Fan, CPU Fan, Chassis Fan cable to the 3-pin Fan header.
Please be noted that FAN4 is 2-pin header without hardwar e monitor
function. FAN1 and FAN2 are also without hardware monitor function.
Note: Both cable wiring and type of plug may vary and they depend
on fan maker. Keep in mind that the red wire should always
be connected to the 12V header and the black wir e to the
ground (GND) header.
FN1
CPUFAN
FAN4
FN2
38
SENSE
+12V GND
E12E 11
E1
ATX P ower Connector (ATX 1)
This motherboard uses 24-pin Pentium 4 standard ATX power connector
and comes with an extra power connector for 5V/3.3V as shown below.
Please make sure you plug in the right direction.
A traditional ATX system should remain at power off stage when AC power
resumes from power failure. This design is inconvenient for a network
server or workstation, without an UPS, that needs to keep power-on. This
motherboard implements an AC Power Auto Recovery function to solve
this problem.
E9
Dual USB ports Header (USB2)
This motherboard pr ovides 4 USB connectors to connect USB devices, such
as mouse, keyboard, modem, printer, etc. There are two connectors on the
PC99 back panel. Y ou can use proper cable to connect others USB connectors to the back plane or front panel of chassis. By the way, if you want to
use the USB solution of CNR, please short the pin 2 & pin 3 of JP15/JP16.
39
JP15
JP16
USB2
E6
IR Connector (SIR 1)
The IrDA connector can be configured to support wir eless infrared module,
with this module and application software such as Laplink or Windows 95
Direct Cable Connection, the user can transfer files to or from laptops,
notebooks, PDA devices and printers. This connector suppor ts HPSIR
(115.2Kbps, 2 meters) and ASK-IR (56Kbps).
Install the infrared module onto the IrDA connector and enable the infrared
function from BIOS Setup, UART2 M ode, make sure to have the correct
orientation when you plug in the IrDA connector.
VCCNCIRRX
E5
Wake-on Modem Connector (WOM)
This motherboard implements special circuit to support Wake On Modem,
both Internal modem card and external box modem are supported. Since
Internal modem card consumes no power when system power is off, it is
recommended to use an internal modem. To use internal modem, connect
4-pin cable from RING connector of modem card to the WOM connector
on the motherboard.
Gnd RI- NC +5VSB
GNDNCIRTX
40
4 SOFTWARE UTILITY
4.1 AT30 Mainboard CD Over view
Note: The CD contents attached in the AT30 mainboard are subject to
change without notice.
To start your mainboard CD , just insert it into your CD-ROM drive, and the
CD AutoR un screen should appear. If the AutoRun screen does not appear,
double click or run D:\Autorun.exe (assuming that your CD-ROM drive is
drive D:)
Navigation Bar Description:
F
Install Mainboard Software - Mainboard Driver/Software Installation
F
Manual - AT30 Mainboard user’s manual in PDF format.
F
Link to Shuttle Homepage - Link to shuttle w ebsite homepage.
F
Browse this CD - Allows you to see contents of this CD.
F
Quit - Close this CD.
41
4.2 Install Mainboar d Software
Insert the attached CD into your CD-ROM drive, and the CD AutoRun
screen should appear. If the AutoRun screen does not appear, double click
on Autorun icon in My Computer to bring up Shuttle Mainboard Software
Setup screen.
Use your pointing device (e.g. mouse) to select the “Install Mainboard
Software” bar to run into sub-menu.
The Mainboard Software included:
4.2.A Install Chipset System Driver
4.2.B Install AC97 Audio Dr iver
4.2.C Install LAN Device Driver
4.2.D Install Bus Master IDE Driver
42
4.2.A Install Chipset System Dr iver
Select using your pointing device (e.g. mouse) on the “Install Chipset
System driver” bar to install chipset system driver.
Once you made your selection, a Setup window runs the installation automatically.
When the copying files is done, make sure you reboot the system to take
the installation effect.
Note: When the Windows 98/95 first reboot after Intel Chipset System
drivers installed, some new har dware devices will be found and added. For
those new hardware devices, related software driver will be searched for
installing. The user may find the software drivers retain on directory
C:\windows\system if some of softwar e drivers could not be found during
searching.
43
A.2.B Install AC97 Audio Driver
Select using your pointing device (e.g. mouse) on the “Install AC97 Audio
driver” bar to install AC97 audio driver.
Once you made your selection, a Setup window runs the installation automatically.
When the copying files is done, make sure you reboot the system to take
the installation effect.
44
A.2.C Install LAN Device Driver Manually
This mother board comes with an Intel® 82562ET 10/100 LAN controller.
You can find the LAN driver from the Shuttle CD disc. Please copy LAN
driver w ith all directory \mainbrd\lan from the CD to your hard disk
drive before go through installation as following:
1. Install operation system fully.
2. After installation, go the “Start” menu and choose “Setting”.
3. From the “Set ting” menu”, choose “Control Panel”.
4. In the “Cont rol Panel” window, double-click on the “System” icon.
5. In the “System” window, choose the “Device Manager” tab.
6. In the hierarchical display under “Other Devices” is a listing for “PCI
Ethernet Controller”. Choose it and then press the ”Properties” but-
ton.
7. Choose the “Driver” tab in the “Propert ies” window, choose “Update
Driver”, and then pr ess “Next”.
8. Choose “Search for a better driver than the one your device id using
now (recommended)”, and then press “Next”.
9. Choose “Specify Location”, and then type full path of driver location
o n
your hard disk drive in the text box. Or you can choose “Browse”
button for specify driver’s location.
10. Insert the Shuttle CD into the CD-ROM.
11. Press the “Next” button. A message informing you that system has found
“Intel (R) PR O/100 VE Network Connection” should appear.
12. Press the “N ext”, and then “Finish”, and then “Yes” when asked if you
want to restart your computer.
45
A.2.D Install Bus Master IDE Driver Manually
This driver may do bad effect on some model or brand of IDE HDD devices. Hereby, we won’t suggest users to install it cause if might crash your
HDD data. However, if you are very usre that the driver matches your IDE
HDD, please follow below indication to complete setup.
Insert the attached CD into your CD-ROM drive and the CD AutoRun
screen should appear. If the AutoRun screen does not appear, double click
on AutoRun icon in My Computer to bring up Shuttle Mainboard Software
Setup screen.
Select using your pointing device (e.g. mouse) on the “Browse this CD”
bar. And then find out the location: Mainboard\ata\ata100 to install the
driver.
P.S.: Before doing IDE Driver installation, setup Chipset System Driver is
necessary.
Once you made your selection, a Setup window runs the installation automatically.
When the copying files is done, make sure you reboot the system to take
the installation effect.
46
4.3 V iew the User’s Manual
Insert the attached CD into your CD-ROM drive, and the CD AutoRun
screen should appear. If the AutoRun screen does not appear, double click
on Autorun icon in My Computer to bring up Shuttle Mainboard Software
Setup screen.
Use your pointing device (e.g. mouse) to select the “Manual” bar.
Then On-line Information window will appear on your screen. Click on
the “Install Acrobe Reader” bar if you need to install acrobe r eader.
47
5 BIOS SETU P
AT30 BIOS ROM has a built-in Setup program that allows users to modify
the basic system configuration. This information is stored
in battery-backed RAM so that it retains the Setup information even if the
system pow er is turned off.
The system BIOS is managing and executing a variety of hardware related
functions in the system, including:
System date and time
Hardware execution sequence
Power management functions
Allocation of system resources
5.1 Enter the BIOS
To enter the BIOS (Basic Input / Output System) utility, follow these steps:
Step 1.Power on the computer, and the system will perform its
POST (Pow er-On Self Test) routine checks.
Step 2.Press <Del> key immediately, or at the following message:
“Press DEL to enter SETUP”
,or simultaneously press <Ctrl>, <Alt>, <Esc> keys
Note 1. If you miss trains of words mentioned in step2 (the message
disappears before you can respond) and you still wish to enter
BIOS Setup, r estart the system and try again by turning the computer OFF and ON again or by pressing the <RESET> switch located at the computer’s front-panel.
You may also reboot by simultaneously pressing
the <Ctrl>, <Alt>, <Del> keys.
Note 2. If you do not press the keys in time and system does not boot, the
screen will prompt an error message, and you will be given the
following options:
“Press F1 to Continue, DEL to Enter Setup”
Step 3.As you enter the BIOS program, the CMOS Setup Utility will
prompt you the Main Menu, as shown in the next section.
48
5.2 The Main Menu
Once you enter the AwardBIOS(tm) CMOS Setup Utility, the M ain
Menu will appear on the screen. The Main Menu allows you to select
from several setup functions and two exit choices. Use the arrow keys
to select among the items and press <Enter> to accept and enter the
sub-menu.
Note that a brief description of each highlighted selection appears at
the bottom of the screen.
Setup Items
The main menu includes the following main setup categories. Recall
that some systems may not include all entries.
Standard CMOS Features
Use this menu for basic system configuration.
Advanced BIOS Features
Use this menu to set the Advanced Features available on your system.
Advanced Chipset Features
Use this menu to change the values in the chipset registers and optimize your system's performance.
Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
49
Power Management Setup
Use this menu to specify your settings for power management.
PnP / PCI Configuration
This entry appears if your system supports PnP / PCI.
PC Health Status
This entry shows the current system temperature, Voltage, and FAN
speed.
Frequency Control
Use this menu to specify your settings for frequency contr ol.
Load Setup Defaults
Use this menu to load the BIOS default values for the minimal/stable
performance of your system to operate.
Load Turbo Defaults
Use this menu to load the BIOS default values that are factory-set for
optimal performance system operation. While Award has designed
the custom BIOS to maximize performance, the factory has the right
to change these defaults to meet users' needs.
Set Password
Use this menu to change, set, or disable super visor/user password. It
allows you to limit access to the system and Setup, or only to Setup.
Save & Exit Setup
Save CMOS value changes in CMOS and exit from setup.
Exit Without Saving
Abandon all CMOS value changes and exit from setup.
50
@
Standard CMOS Features
The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items.
Use the arrow keys to highlight the item and then use the <PgUp>
or <PgD n> keys to select the value you want in each item.
Date
<Month> <DD> <YYYY>
Set the system date. Note that the 'Day' automatically changes w hen
you set the date.
Time
<HH : M M : SS>
The time is converted based on the 24-hour military-time clock. For
example, 5 p.m. is 17:00:00.
IDE Primary Master
Options are in its sub-menu.
Press <Enter> to enter the sub-menu of detailed options.
IDE Primary Slave
Options are in its sub-menu.
Press <Enter> to enter the sub-menu of detailed options.
51
IDE Secondary Mast er
Options are in its sub-menu.
Press <Enter> to enter the sub-menu of detailed options.
IDE Secondary Slave
Options are in its sub menu.
Press <Enter> to enter the sub-menu of detailed options.
Drive A/Drive B
Select the type of floppy disk drive installed in your system.
Ø The choice: N one, 360K, 5.25 in, 1.2M, 5.25 in, 720K, 3.5 in,
1.44M, 3.5 in, or 2.88M, 3.5 in.
Video
Select the default video device.
Ø The choice: EGA/VGA, CGA 40, CGA 80, or MONO.
Halt On
Select the situation in which you want the BIOS to stop the POST
process and notify you.
Ø The choice: All Errors, No Errors, All, But Keyboard, All, But
Diskette, or All, But Disk/Key.
Base Memory
Displays the amount of conventional memory detected during boot up.
Ø The choice: N/A.
52
@
Advanced BIOS Features
This section allows you to configure your system for basic operation.
You have the opportunity to select the system's default speed, boot-up
sequence, keyboard operation, shadowing, and security.
Virus Warning
Allows you to choos e the VIRUS Warning feature for IDE Hard Disk
boot sector protection. If this function is enables and someone attempts
to write data into this area, B IOS will show a warning message on screen,
and an alarm beep.
Enabled Activates automatically when the system boots up,
causing a warning message to appear when anything
attempts to access the boot sector or hard disk parti-
tion table.
Disabled No warning message will appear when anything
attempts to access the boot sector or hard disk parti-
tion table.
Ø The choice: Enabled or D isabled.
CPU L1 & L2 Cache
This item enables CPU inter nal level 1 and level 2 cache to speed up
memory access.
Ø The choice: Enabled or D isabled.
53
CPU L3 Cache
This item enables CPU level 3 cache to speed up memory access.
Ø The choice: Enabled or D isabled.
Compatible FPU OPCODE
Leave on default setting for optimized performance of Pentium 4
processor.
Ø The choice: Enabled or D isabled.
CPU Fast String
When set to enabled, the CPU has direct access to the memory.
Leave on default setting for optimized performance.
Ø The choice: Enabled, or Disabled.
Quick Pow er On Self Test
This item speeds up Power-On Self Test (POST) after you power on
the computer. If it is set to enabled, B IOS will shorten or skip some
check items during POST.
Ø The choice: Enabled, or Disabled.
First/Second/Third Boot Device
The BIOS attempts to load the operating system from the devices in
the sequence selected in these items.
Ø The Choice: Floppy, LS120, HDD-0, SCSI, CDROM, HDD-1,
HDD-2, HDD-3, ZIP100, USB -FDD, USB-ZIP, USB-CDROM,
USB-HDD, LAN, or Disabled.
Boot Other Device
Select Your Boot Device Priority.
Ø The choice: Enabled or D isabled.
Swap Floppy Drive
If the system has two floppy drives, you can swap the logical drive
name assignment.
Ø The choice: Enabled or D isabled.
Boot Up Floppy Seek
Seeks disk drives during boot-up. Disabling speed boots up.
Ø The choice: Enabled or D isabled.
54
Boot Up NumLock Status
Selects power-on state for NumLock.
Ø The choice: Off or On.
Gate A20 Option
This entry allows you to select how the gate A20 is handled. The gate
A20 is a device used for above 1MByte of address memory. Initially,
the gate A20 was handled via a pin on the keyboard. Today, while a
keyboard still provides this support, it is more common and much
faster in setting to Fast for the system chipset to provide support for
gate A20.
Ø The choice: Normal, or Fast.
Typematic Rate Set ting
Keystrokes repeat at a rate determined by the keyboard controller.
When this controller enabled, the typematic rate and typematic delay
can be selected.
Ø The choice: Enabled or D isabled.
Typematic Rat e (Chars/Sec)
This item sets how many times the keystroke will be repented in a
second when you hold the key down.
Ø The choice: 6, 8, 10, 12, 15, 20, 24, or 30.
Typematic Delay (Msec)
Sets the delay time after the key is held down before it begins to
repeat the keystroke.
Ø The choice: 250, 500, 750, or 1000.
Security Option
Select w hether the password is required every time the system boots
or only when you enter setup.
System The system will not boot and access to Setup will be
denied if the correct password is not entered promptly.
Setup The system will boot, but access to Setup will be
denied if the correct password is not entered promptly.
Ø The choice: System or Setup.
55
Note: To disabled security, select PASSWORD SETTING at Main
Menu, and then you will be asked to enter password. Do not
type anything and just press <Enter>; it will disable security.
Once the security is disabled, the system will boot, and you
can enter Setup freely.
OS Select For D RAM > 64MB
Selects the operating system that is running with greater than 64MB of
RAM in the system.
Ø The choice: Non-OS2 or OS2.
Report No FD D For Win 95
Whether report no FDD runs for Win 95 or not.
Ø The choice: Yes or No.
56
@
Advanced Chipset Features
This section allow s you to configure the system based on the specific featur es of the installed chipset. This chipset manages bus speeds and access
to system memory r esources, such as DRAM and the external cache. It also
coor dinates communications between the conventional ISA bus and the
PCI bus. It states that these items should never need to be altered.
The default settings have been chosen because they provide the best oper ating conditions for your system. If you discovered that data was being lost
while using your system, you might consider making any changes.
RDRAM Bus Frequency
This feature is used to set the clock generator what frequency to sent
to the RDRAM. The default setting "Auto" seeks to balance optimal
performance with stability.
System BIOS Cacheable
Selecting Enabled allows caching of the system BIOS ROM at F0000hFFFFFh, resulting in better system performance. However, if any
program is written to this memory ar ea, a system error may result.
Ø The choice: Enabled or D isabled.
Video BIOS Cacheable
Selecting Enabled allows caching of the video BIOS , resulting in
better system performance. However, if any program is written to this
memory area, a system error may result.
57
Ø The Choice: Enabled or Disabled.
Video RAM Cacheable
This is a new cache technology for the video memory of the processor. It can improve the display speed by caching the display data.
You must set this to disabled if your display car d cannot support this
feature; otherwise your system may not boot.
Ø The Choice: Enabled or Disabled.
Memory Hole At 15M-16M
You can r eserve this area of system memory for ISA adapter ROM.
When this area is reserved, it cannot be cached. The user information
of peripherals that need to use this area of system memory usually
discusses their memory requirements.
Ø The Choice: Enabled or Disabled.
CPU Latency Timer
This item Enable/Disable the defer rable CPU cycle being deferred
when other device access memory.
Ø The Choice: Enabled or Disabled.
Delayed Transaction
The chipset has an embedded 32-bit posted write buffer to support
delayed transactions cycles. Select Enabled to support compliance
with PCI specification version 2.1.
Ø The Choice: Enabled or Disabled.
AGP Graphics Aperture Size (MB)
Select the size of Accelerated Graphics Port (AGP) aperture. The
aperture is a portion of the PCI memory address range dedicated to
graphics memory address space. Host cycles that hit the aperture
range are forwarded to the AGP without any translation.
Ø The Choice: 64MB or 32MB.
Delay Porior to Thermal
This item allows you to select the timing of delay priority to thermal.
Ø The Choice: 4 Min, 8 Min, 16 Min or 32 Min.
58
@
Integrated Peripherals
On-Chip Primary/Secondary PCI IDE
The integrated peripherals controller contains an IDE interface with
support to two ID E channels. Select Enabled to activate each channel
separately.
Ø The choice: Enabled or D isabled.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a PIO
mode (0-4) for each of the four IDE devices that the onboard IDE
interface supports. Modes 0 through 4 provide successively increased
performance. In Auto mode, the system automatically determines the
best mode for each device.
Ø The choice: Auto, Mode 0, Mode 1, Mode 2, Mode 3, or Mode 4.
59
IDE Primary/Secondary Master/Slave UD MA
Ultra DMA33/66/100 implementation is possible only if your IDE
hard drive supports it and the operating environment includes a DMA
driver (Windows 95 OSR2 or a third-party IDE bus master driver). If
both of your hard drive and your system software support Ultra
DMA33/66/100, select Auto to enable BIOS support.
Ø The Choice: Auto or Disabled.
AC PWR Auto Recovery
This allows you to set whether you want your system to reboot after
the power has been interrupted.
Ø The choice: Off or On.
USB Controller
Select Enabled if your system contains a Universal Serial Bus (U SB)
controller and you have USB peripherals.
Ø The choice: Enabled or Disabled.
USB Keyboard Support
Select Enabled if your system contains a Universal Serial Bus (U SB)
controller and you have a USB keyboard.
Ø The choice: Enabled or Disabled.
USB Mouse Support
Select Enabled if your system contains a Universal Serial Bus (U SB)
controller and you have a U SB Mouse.
Ø The choice: Enabled or Disabled.
Init Display First
This item allows you to decide to activate whether PCI Slot or AGP
Slot first.
Ø The choice: PCI Slot or AGP .
AC97 Audio
This item allows you to decide to enable/disable the 810 chipset
family to support AC97 Audio.
Ø The choice: Auto or Disabled.
60
AC97 Modem
This item allows you to decide to enable/disable the 810 chipset
family to support AC97 Modem.
Ø The choice: Auto or Disabled.
On board CNR Lan Select ion
This item allows you to select Communication and Network to onboard or external device.
Ø The choice: Onboard, Ext.CNR or Auto.
IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or
multiple sector read/write. If your IDE hard drive supports block
mode (most new drives do), select Enabled for automatic detection of
the optimal number of block r ead/writes per sector the drive can
support.
Ø The choice: Enabled, or Disabled
Onboard FDC Controller
This item specifics onboard floppy disk drive controller. This setting
allows you to connect your floppy disk drives to the onboard floppy
connector. Choose the "Disabled" settings if you have a separate
control card.
Ø The choice: Enabled D isabled.
Onboard Serial Port1/Port2
Select an address and corresponding interrupt for the first and second
serial ports.
Ø The choice: 3E8/IRQ4, 2E8/IRQ3, 3F8/IRQ4, 2F8/IRQ3,Auto, or
Disabled.
UART Mode Select
The main board support IrDA infrared through COM 2 port.
Note : FIR is not available currently.
Ø The choice: IrDA or Normal.
TxD, RxD Polarity Active
This item specifies the Active level for RxD & TxD signal.
Ø The choice: Hi,Lo, Lo,Hi, Lo,Lo, or Hi, Hi.
61
Use IR Pins
This item select the InfraRed module pin out.
Ø The choice: IR-R x2Rx2 or RxD2, TxD2.
Onboard Parallel Port
This item allows you to determine onboard parallel port controller I/O
address setting.
Ø The choice:: 378/IRQ7, 278/IRQ5, 3BC/IRQ7, or Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel (printer) port.
Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes.
Ø The choice: SPPl, EPP, ECP, or ECP/EPP.
ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP mode.
Ø The choice: 1 or 3.
Game Port Address
This item select the Game Port Address.
Ø The choice: Disabled, 201H or 209H.
Midi Port Address
This item select the Midi Port Address.
Ø The choice: Disabled, 330H, 300H, or 209H.
Midi Port IRQ
This item select the Midi Port IRQ.
Ø The choice: 5 or 10.
62
@
Power Management Setup
The Power Management Setup allows you to configure your system to
most effectively saving energy w hile operating in a manner consistent
with your own style of computer use.
ACPI Function
This item allow s you to enable/disable the Advanced Configuration
and Pow er Management (ACPI)
Ø The choice: Enabled or D isabled.
ACPI Suspend Type
This item allow s you to select sleep state when suspend.
Ø The choice: S1(POS) or S3(STR).
Power Management
This category allows you to select the type (or degree) of power saving
and is directly related to the following modes:
1. Suspend Mode
2. HDD Power Down
Min Saving Minimum power management.
Suspend Mode=
HDD Power Down=15min.
Allows you to set each mode individually.
63
Max Saving Maximum power management.
Suspend Mode=
HDD Power Down=1min.
User Defined Allows you to set each mode individually. When this
item not disabled, each of the ranges are from 1 min. to 1 hr. except
for HDD Power Down which ranges from 1 min. to 15 min. and
disable.
Ø The choice: User Define, Min Saving, or Max Saving.
Video Off Method
This determines the manner in which the monitor is blanked.
V/H SYNC+Blank This selection will cause the system to turn
off the vertical and horizontal synchronization ports and write blanks
to the video buffer.
Blank Screen This option only writes blanks to the video buffer.
DPMS Initial display pow er management signaling.
Ø The choice: V/H SYNC+Blank, Blank Screen, or DPMS.
Video Off In Suspend
This item determines the manner in which the monitor is blanked.
Ø The choice: Yes or No.
Suspend Type
This item allows you to select the Suspend Type.
Ø The choice: PwrOn Suspend, Stop Grant.
Allows you to set each mode individually.
MODEM Use IRQ
This item determines the IRQ in which the MODEM can use.
Ø The choice: 3, 4, 5, 7, 9, 10, 11, or NA.
Soft-Off by PWR-BTTN
Pressing the power button for more than 4 seconds forces the system
to enter the Soft-Off state when the system has "hung.".
Ø The choice: Instant-Off or Delay 4 Sec.
Wake-Up Events
These items include Primary IDE0/1, Secondary IDE 0/1, Floppy Disk,
Serial Port, Parallel Port, and PCI PIRQ[A-D]#. allow you to set wake
up events from power management.
64
@
PnP/PCI Configurations
This section describes the configuration of PCI bus system. PCI or
Personal Computer Interconnection is a system which allows I/O
devices to operate at the speed CPU itself keeps when CPU
communicating with its own special components.
This section covers some very technical items, and it is strongly
recommended that only experienced users should make any
changes to the default settings.
Reset Configuration D ata
Normally, you leave this field Disabled. Select Enabled to reset
Extended System Configuration Data (ESCD) when you exit from
Setup
if you have installed a new device or software and the system
reconfiguration has caused such a ser ious conflict that the operating
system can not boot.
Ø The choice: Enabled or Disabled .
Resource controlled By
The Awar d Plug-and-Play BIOS has the capacity to automatically
configure all of the boot and Plug-and-Play compatible devices.
However, this capability means absolutely nothing unless you are
using a Plug-and-Play operating system such as Windows 95.
If you set this field to "manual" , choose specific resources by going
into each of the sub-menu that follows this field (a sub-menu is proceeded by a ">").
Ø The choice: Auto(ESCD) or Manual.
65
PCI/VGA Palette Snoop
Leave this field Disabled.
Ø The choice: Enabled or D isabled.
@
PC Health Status
Shutdown Temperature
Select the combination of lower and upper limits for the system shutdown temperature, if your computer contains an environmental
monitoring system. If the temperature extends beyond either limit, the
system shuts down.
Ø The choice: Disabled, 60°C/140°F, 65°C/149°F, 70°C/158°F, or
75°C/167°F.
66
@
Frequency Control
CPU Clock Ratio
This item allows you to select the Pentium 4 CPU ratio.
Ø The choice: 8X ~ 23X.
@
@
Load Setup Def aults
When you press <Enter > on this item, you will get a confirmation
dialog box with a message similar to:
Load Setup Defaults (Y/N) ? N
Pressing 'Y' loads the BIOS default values for the most stable,
minimal performance system operations.
Load Turbo Defaults
When you press <Enter > on this item, you will get a confirmation
dialog box with a message similar to:
Load Turbo Defaults (Y/N) ? N
Pressing 'Y' loads the default values that are factory-set for optimal
performance system operation.
67
@
Set Password Setting
Set Password
Enter Password
The options on the Password screen menu make it possible to restr ict
access to the Setup program by enabling you to set password.
Type the password up to eight characters, and press <Enter>. The
password typed now will clear any previously entered password from
CMOS memory. You will be asked to confirm the password. Type
the password again and pr ess <Enter>. You may also press <Esc>
to abort the selection and not enter a password.
To disable password, just press <Enter> when you are prompted to
enter password. A message will confirm the password being disabled.
Once the password is disabled, the system will boot and you can
enter Setup freely.
Password Disable
If you select System at Security Option of BIOS Features Setup Menu,
you will be prompted in entering the password whenever the system
is rebooted or you try to enter Setup. If you select Setup at Secur ity
Option of BIOS Featur es Setup Menu, you will be prompted only
when you tr y to enter Setup.
68
@
Save & Exit Setup
Pressing <Enter> on this item asks for confirmation:
Save to CMOS and EXIT (Y/N)? Y
Pressing "Y" stores the selections made in the menus of CMOS - a
special section of memory that stays on after you turn your system off.
The next time you boot your computer, the BIOS configures your
system according to the Setup selections stored in CMOS. After saving
the values the system is r estarted again.
@
Exit Without Saving
Pressing <Enter> on this item asks for confirmation:
Quit without saving (Y/N)? Y
This allows you to exit from Setup without storing in CMOS any
change. The previous selections remain in effect. This exits from the
Setup utility and restarts your computer.
69
Loading...
