BLX
BLX -- Wireless System
Online user guide for Shure BLX wireless system.
Version: 2 (2019-D)
BLX Wireless System
IMPORTANT SAFETY INSTRUCTIONS
1.
READ these instructions.
2.
KEEP these instructions.
3.
HEED all warnings.
4.
FOLLOW all instructions.
5.
DO NOT use this apparatus near water.
6.
CLEAN ONLY with dry cloth.
7.
DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in
accordance with the manufacturer’s instructions.
8.
DO NOT install near any heat sources such as open flames, radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat. Do not place any open flame sources on the product.
9.
DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10.
PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11.
ONLY USE attachments/accessories specified by the manufacturer.
12.
USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
Shure Incorporated
13.
UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14.
REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15.
DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled with liquids, such as
vases, on the apparatus.
16.
The MAINS plug or an appliance coupler shall remain readily operable.
17.
The airborne noise of the Apparatus does not exceed 70dB (A).
18.
Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a protective earthing
connection.
19.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
20.
Do not attempt to modify this product. Doing so could result in personal injury and/or product failure.
21.
Operate this product within its specified operating temperature range.
This symbol indicates that dangerous voltage constituting a risk of electric shock is present within
this unit.
2/25
This symbol indicates that there are important operating and maintenance instructions in the
literature accompanying this unit.
WARNING: Danger of explosion if incorrect battery replaced. Operate only with AA batteries.
System Components
Note: Your system comes with a combination of the following components.
•
BLX1 Bodypack Transmitter
•
BLX2 Handheld Transmitter (choice of SM58, BETA58A, or PG58)
•
BLX4 Wireless Receiver
•
BLX88 Dual Wireless Receiver
•
PS24 Power Supply
•
Lavalier microphone (choice of PG185, WL185 or WL93)
•
Headworn microphone (choice of PG30, SM31FH or SM35)
•
MX153 Earset microphone
•
Instrument microphone (BETA98H/C)
•
Guitar cable (WA302)
Shure Incorporated
Quick Start Guide
1. 1.
2.
Connect receiver to power source.
2.
Connect receiver to mixer or amplifier. Hold power button to turn on.
Press group button on receiver to perform a group scan.
3. 1.
Install batteries and turn on transmitter.
3/25
Shure Incorporated
2.4.On the transmitter, set the group and channel to match the receiver. The audio LED on the receiver
should illuminate.
If setting up additional systems, leave the first transmitter and receiver on. For each additional receiver,
manually set the group to match the first receiver. Note: The receiver will automatically perform a
channel scan to find an available frequency after the group has been selected. Set the transmitter
frequency to match the receiver.
If sound is too faint or distorted, adjust the gain accordingly.
4/25
Features
Front Panel
BLX4
BLX88
① audio LED
Shure Incorporated
Indicates strength of incoming audio signal: green for normal and red for overload.
② ready LED
Green light indicates system is ready for use and receiving transmitter signal.
③ LED Display
Displays group and channel setting.
④ group and channel Buttons
Scan: Push and release group button to scan for an open group and channel.
Manual: Push and hold group button to select a group. Push channel button to select a channel in the current
group.
⑤ power Button
Push and hold to turn power on or off.
Back Panel
BLX4
5/25
BLX88
① DC Power Jack
② Adapter Cord Tie-Off
③ XLR microphone output jack (MIC out)
④ 6.35 mm (1/4") instrument level output jack (instrument out)
BLX1
① LED Indicator
Displays power and battery status (see Transmitter LED Indicators).
② power Switch
Toggles power on or off.
③ 4-Pin Microphone Input Jack (TA4 connector)
④ Antenna
Shure Incorporated
⑤ group Button
Changes group setting.
⑥ LED Display
Displays group and channel setting.
⑦ channel Button
Changes channel setting.
⑧ Battery Compartment
⑨ Audio Gain Adjustment
Rotate to increase or decrease transmitter gain.
6/25
BLX2
① LED Indicator
Displays power and battery status (see Transmitter LED Indicators).
② power Button
Push to turn power on or off.
③ group Button
Changes group setting.
④ channel Button
Changes channel and gain setting.
⑤ LED Display
Displays group and channel setting.
⑥ Identification Cap
Shure Incorporated
⑦ Battery Compartment
Transmitter LED Indicators
LED Indicator Status
Green Ready
7/25
LED Indicator Status
Rapidly Flashing Red Controls locked
Solid Red Battery power low (less than 1 hour remaining*)
Flashing Red and shuts off Batteries dead (change batteries to power on transmitter)
*For alkaline batteries only. For rechargeable batteries, solid red means the batteries are dead.
Single System Set Up
Shure Incorporated
Before you begin, turn off all transmitters and turn on any equipment (other microphones or personal monitoring
systems) that could cause interference during the performance.
1.
Press and release the group button on the receiver.
The receiver scans for the clearest group and channel.
Note: If you want to stop the scan, push the group button again.
2.
Turn on transmitter and change the group and channel to match the receiver (See Setting Transmitter Group
and Channel).
Once the system is set up, perform an audio check and adjust the gain if necessary.
Setting Transmitter Group and Channel
Transmitter group and channel must be manually set to match the receiver.
Group (letter)
1.
Press and release the group button on the transmitter to activate the display. Press the group button again
and the display flashes.
2.
While the display is flashing, press the group button again to advance to the desired group setting.
Channel (number)
If channel needs to be changed, follow the same procedure using the channel button instead of the group button.
Note:
•
When the group and channel correctly match the receiver, the ready LED on receiver illuminates.
•
After manual setup, the transmitter alternately displays the group and channel setting for about two seconds.
8/25
Shure Incorporated
Multiple System Setup
Up to 12 systems can operate simultaneously (band and RF environment dependent).
Important: Set up each system one-at-a-time. Once a receiver and transmitter are tuned to the same group and
channel, leave the transmitter powered on. Otherwise, scans from the other receivers will not detect that channel as
occupied. For the BLX88, be sure to setup both transmitters before progressing to the next receiver.
Turn on any other equipment that could cause interference during the performance so it will be detected during the
group and channel scans in the following steps.
Before you begin system set up, turn all receivers ON and all transmitters OFF.
For the first receiver:
1.
Perform a group scan.
This finds the group with the most clear channels.
Note: For the BLX88, the group scan sets up both receivers at the same time.
2.
Turn on the first transmitter and change the group and channel to match receiver.
3.
Leave the transmitter on and continue with the additional systems.
Note: If the selected group does not contain enough open channels, manually select group "d" when setting up
larger systems.
For each additional receiver:
1.
Use manual setup to change the receiver to match the group setting of the first receiver. Recall that each time
the group setting is changed, a channel scan is automatically done.
2.
Turn on the transmitter and change the group and channel to match the receiver.
3.
Leave the transmitter on and continue to the next system.
4.
Once all receivers are set up, perform an audio check on all microphones.
9/25
Shure Incorporated
Manually Setting Receiver Group and Channel
The receiver group may need to be changed as part of a multiple system setup.
Group (letter)
1.
Hold the group button on the receiver until the display begins to flash.
2.
While the display is flashing, press the group button again to advance to the next group.
Note: Only the group setting will be displayed during the manual setup.
3.
Once the desired group is reached, release the group button. The receiver automatically performs a channel
scan.
Channel (number)
Always use a channel selected by the channel scan. However, if necessary, the channel can be set manually.
Follow the same steps above using the channel button instead of the group button.
Locking and Unlocking Controls
Lock system controls to prevent accidental setting changes or power off.
Transmitter (lock/unlock)
Turn the transmitter on. Hold the group button, then press the channel button for approximately 2 seconds. The LED
indicator rapidly flashes red when locked.
Receiver (lock/unlock)
Turn the receiver on. Simultaneously hold the group and channel button. The display flashes rapidly.
•
When locked, the display flashes rapidly if any key is pressed.
•
The BLX88 locks on both sides when locked from either side.
Tips to Improve Wireless System Performance
If you encounter interference or dropouts, try the following suggestions:
•
Choose a different receiver channel
•
Reposition the receiver so there is nothing obstructing a line of sight to the transmitter (including the
audience)
•
Avoid placing transmitter and receiver where metal or other dense materials may be present
•
Move the receiver to the top of the equipment rack
•
Remove nearby sources of wireless interference, such as cell phones, two-way radios, computers, media
players, Wi-Fi devices, and digital signal processors
•
Charge or replace the transmitter battery
•
Keep transmitters more than two meters (6 feet) apart
•
Keep the transmitter and receiver more than 5 meters (16 feet) apart
•
During sound check, mark trouble spots and ask presenters or performers to avoid those areas
10/25
Getting Good Sound
Correct Microphone Placement
Shure Incorporated
•
Hold the microphone within 12 inches from the sound source. For a warmer sound with increased bass
presence, move the microphone closer.
•
Do not cover grille with hand.
Wearing the Headworn Microphone
•
Position the headworn microphone 13 mm (1/2 in.) from the corner of your mouth.
•
Position lavalier and headworn microphones so that clothing, jewelry, or other items do not bump or rub
against the microphone.
Adjusting Gain
Monitor the audio LED indicator on the receiver front panel when setting the transmitter gain.
•
Green: normal levels
11/25
•
Red: excessive sound levels (overload).
The red LED should only illuminate infrequently when you speak loudly or play your instrument loudly.
BLX1
Rotate the audio gain adjustment to increase (+) or decrease (−) the gain until desired level is reached.
For instruments, turn gain to minimum setting. For lavaliers, increase the gain as desired.
Shure Incorporated
BLX2
The BLX2 features two gain level settings, default and attenuated (-10 dB). The default setting is used for most
situations. If the receiver audio LED flickers red often, set the microphone to attenuated. Use the channel button to
change the gain setting.
1.
Hold down the channel button for 5 seconds.
A dot appears on the lower right-hand corner of the LED display, which indicates −10 dB gain setting has
been activated.
2.
To change the gain back to default, hold the channel button again for 5 seconds, or until the dot disappears.
Batteries
Expected life for AA batteries is up to 14 hours (total battery life varies depending upon battery type and
manufacturer).
When the LED indicator turns red, it signifies "low battery" with approximately 60 minutes of remaining battery life.
12/25
Shure Incorporated
For alkaline batteries only. For rechargeable batteries, solid red means the batteries are dead.
To remove batteries from the handheld transmitter, push them out through the opening in the microphone battery
compartment.
WARNING: Battery packs shall not be exposed to excessive heat such as sunshine, fire, or the like.
Wearing the Bodypack Transmitter
Clip the transmitter to a belt or slide a guitar strap through the transmitter clip as shown.
For best results, the belt should be pressed against the base of the clip.
Power Off
Hold down the power button to power off the BLX2 or BLX4/88. To power off the BLX1, slide the power toggle switch
to OFF.
13/25
Shure Incorporated
Removing and Installing Identification Caps
The BLX2 is equipped with a black identification cap from the factory (dual vocal systems ship with additional gray
cap).
To remove: Remove battery cover. Squeeze sides and pull off cap.
To install: Align the cap and click into place. Replace battery cover.
An Identification Cap Kit containing assorted colored caps is available as an optional accessory.
Troubleshooting
Issue Indicator Status Solution
No sound or faint sound Receiver ready LED on Verify all sound system connections or adjust
Receiver ready LED off Turn on transmitter
Receiver LED screen off Make sure DC adapter is securely plugged
•
gain as needed (see Adjusting Gain)
•
Verify that the receiver is connected to mixer/
amplifier
•
•
Make sure the batteries are installed
correctly
•
Perform transmitter setup (see Single
System Setup)
•
Insert fresh batteries
•
into electrical outlet.
•
Make sure receiver is powered on.
14/25
Issue Indicator Status Solution
Shure Incorporated
Transmitter indicator LED
flashing red
Audio artifacts or dropouts Ready LED flickering or off Change receiver and transmitter to a
Replace transmitter batteries (see Changing
Batteries).
•
different group and/or channel.
•
Identify nearby sources of RF interference,
and shutdown or remove source.
•
Replace transmitter batteries.
•
Ensure that receiver and transmitter are
positioned within system parameters
•
System must be set up within recommended
range and receiver kept away from metallic
surfaces.
•
Transmitter must be used in line of sight from
receiver for optimal sound
Distortion Audio LED on receiver
Reduce transmitter gain (see Adjusting Gain).
indicates overload (red)
Sound level variations
when switching to different
N/A Adjust transmitter gain as necessary (see Adjusting
Gain).
sources
Receiver/transmitter won't
LED/display flashing rapidly See Locking and Unlocking Controls.
turn off
Specifications
System
Working Range
91 m (300 ft) Line of Sight
Note: Actual range depends on RF signal absorption, reflection and interference.
Audio Frequency Response
50 to 15,000 Hz
Note: Dependent on microphone type
Total Harmonic Distortion
Ref. ±33 kHz deviation with 1 kHz tone
0.5%, typical
15/25
Shure Incorporated
Dynamic Range
100 dB, A-weighted, typical
Operating Temperature
-18°C (0°F) to 57°C (135°F)
Note: Battery characteristics may limit this range.
Polarity
Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces
positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 1/4-inch
output.
BLX1
Audio Input Level
max -16 dBV maximum
min (0 dB) +10 dBV maximum
Gain Adjustment Range
26 dB
Input Impedance
1 MΩ
RF Transmitter Output
10 mW, typical
varies by region
Dimensions
4.33 in. X 2.52 in. X 0.83 in. (110 mm X 64 mm X 21 mm) H x W x D
Weight
2.6 oz. (75 g), without batteries
Housing
Molded ABS
Power Requirements
2 LR6 AA batteries, 1.5 V, alkaline
16/25
Battery Life
up to 14 hours (alkaline)
Audio Input Level
0dB -20 dBV maximum
-10dB -10 dBV maximum
Gain Adjustment Range
10 dB
RF Transmitter Output
10 mW, typical
varies by region
Shure Incorporated
Dimensions
8.82 in. X 2.09 in. (224 mm X 53 mm) L x Dia.
Weight
7.7 oz. (218 g) without batteries
Housing
Molded ABS
Power Requirements
2 LR6 AA batteries, 1.5 V, alkaline
Battery Life
up to 14 hours (alkaline)
BLX4 & BLX88
Output Impedance
XLR connector 200 Ω
6.35 mm (1/4") connector 50 Ω
Audio Output Level
Ref. ±33 kHz deviation with 1 kHz tone
XLR connector –27 dBV (into 100 kΩ load)
17/25
6.35 mm (1/4") connector –13 dBV (into 100 kΩ load)
RF Sensitivity
-105 dBm for 12 dB SINAD, typical
Image Rejection
>50 dB, typical
Dimensions
BLX4 1.57 in. X 7.40 in. X 4.06in. (40 mm X 188 mm X 103 mm) H x W x D
BLX88 1.50 in. X 12.13 in. X 3.98in. (38 mm X 308 mm X 101 mm) H x W x D
Shure Incorporated
Weight
BLX4 8.5 oz. (241 g)
BLX88 15.1 oz. (429 g)
Housing
Molded ABS
Power Requirements
12–15 V DC @ 160 mA (BLX88, 320 mA), supplied by external power supply (tip positive)
Certifications
Meets essential requirements of the following European Directives:
•
WEEE Directive 2002/96/EC, as amended by 2008/34/EC
•
RoHS Directive 2011/65/EU
Note: Please follow your regional recycling scheme for batteries and electronic waste
This product meets the Essential Requirements of all relevant European directives and is eligible for CE marking.
Hereby, Shure Incorporated declares that the radio equipment is in compliance with Directive 2014/53/EU. The full
text of the EU declaration of conformity is available at the following internet address: http://www.shure.com/europe/
compliance (http://www.shure.com/europe/compliance)
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
18/25
Shure Incorporated
Jakob-Dieffenbacher-Str. 12
75031 Eppingen, Germany
Phone: +49-7262-92 49 0
Fax: +49-7262-92 49 11 4
Email: EMEAsupport@shure.de
Certified under FCC Part 74.
Certified by ISED in Canada under RSS-123 and RSS-102.
FCC ID: DD4BLX1A, DD4BLX1B, DD4BLX1C, DD4BLX1D; DD4BLX2A, DD4BLX2B, DD4BLX2C, DD4BLX2D,
DD4BLX1W, DD4BLX1S, DD4BLX2W, DD4BLX2S, DD4BLX1H11, DD4BLX2H11, DD4BLX1J11, DD4BLX2J11. IC:
616A-BLX1A, 616A-BLX1B, 616A-BLX1C, 616A-BLX1D; 616A-BLX2A, 616A-BLX2B, 616A-BLX2C, 616A-BLX2D,
616A-BLX1H11, 616A-BLX2H11, 616A-BLX1J11, 616A-BLX2J11
Certified by ISED in Canada under RSS-102 and RSS-210.
IC: 616A-BLX1W, 616A-BLX1S, 616A-BLX2W, 616A-BLX2S
Approved under the Declaration of Conformity (DoC) provision of FCC Part 15.
Important Product Information
LICENSING INFORMATION
Licensing: A ministerial license to operate this equipment may be required in certain areas. Consult your national
authority for possible requirements. Changes or modifications not expressly approved by Shure Incorporated could
void your authority to operate the equipment. Licensing of Shure wireless microphone equipment is the user’s
responsibility, and licensability depends on the user’s classification and application, and on the selected frequency.
Shure strongly urges the user to contact the appropriate telecommunications authority concerning proper licensing,
and before choosing and ordering frequencies.
Information to the user
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.
This device may not cause harmful interference.
2.
This device must accept any interference received, including interference that may cause undesired
operation.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
19/25
Shure Incorporated
Canada Warning for Wireless
This device operates on a no-protection, no-interference basis. Should the user seek to obtain protection from other
radio services operating in the same TV bands, a radio licence is required. For further details, consult Innovation,
Science and Economic Development Canada’s document Client Procedures Circular CPC-2-1-28, Voluntary
Licensing of Licence-Exempt Low-Power Radio Apparatus in the TV Bands.
Ce dispositif fonctionne selon un régime de non‑brouillage et de non‑protection. Si l’utilisateur devait chercher à
obtenir une certaine protection contre d’autres services radio fonctionnant dans les mêmes bandes de télévision,
une licence radio serait requise. Pour en savoir plus, veuillez consulter la Circulaire des procédures concernant les
clients CPC‑2‑1‑28, Délivrance de licences sur une base volontaire pour les appareils radio de faible puissance
exempts de licence et exploités dans les bandes de télévision d’Innovation, Sciences et Développement
économique Canada.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
1.
This device may not cause interference.
2.
This device must accept any interference, including interference that may cause undesired operation of the
device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes :
1.
L’appareil ne doit pas produire de brouillage;
2.
L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Industry Canada ICES-003 Compliance Label: CAN ICES-3 (B)/NMB-3(B)
Note: EMC conformance testing is based on the use of supplied and recommended cable types. The use of other
cable types may degrade EMC performance.
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to
operate the equipment.
Australia Warning for Wireless
This device operates under an ACMA class licence and must comply with all the conditions of that licence including
operating frequencies. Before 31 December 2014, this device will comply if it is operated in the 520-820 MHz
frequency band. WARNING: After 31 December 2014, in order to comply, this device must not be operated in the
694-820 MHz band.
Frequency Range and Transmitter Output Level
Band Range Output Power
H8 518 to 542 MHz 10 mW
H8E 518 to 542 MHz 10 mW
20/25
Band Range Output Power
H9 512 to 542 MHz 10 mW
H10 542 to 572 MHz 10 mW
H10E 542 to 572 MHz 10 mW
H11 572 to 596 MHz 10 mW
H62 518 to 530 MHz 10 mW
J10 584 to 608 MHz 10 mW
J11 596 to 616 MHz 10 mW
K3E 606 to 630 MHz 10 mW
Shure Incorporated
K12 614 to 638 MHz 10 mW
K14 614 to 638 MHz 10 mW
M15 662 to 686 MHz 10 mW
M17 662 to 686 MHz 10 mW
M18 694 to 703 MHz 10 mW
Q24 748 to 758 MHz 10 mW
Q25 742 to 766 MHz 10 mW
R12 794 to 806 MHz 10 mW
S8 823 to 832 MHz 10 mW
T11 863 to 865 MHz 10 mW
*
Note: Frequency bands might not be available for sale or authorized for use in all countries or regions.
NOTE: This Radio equipment is intended for use in musical professional entertainment and similar applications.
This Radio apparatus may be capable of operating on some frequencies not authorized in your region. Please
contact your national authority to obtain information on authorized frequencies and RF power levels for wireless
microphone products.
21/25
Frequencies for European Countries
H8E 518-542 MHz
Shure Incorporated
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, EST 518 - 542 MHz*
F, GB, GR, H, I, IS, L, LT 518 - 542 MHz*
NL, P, PL, S, SK, SLO 518 - 542 MHz*
DK, FIN, M, N *
HR, E, IRL, LV, RO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
K3E 606-630 MHz
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, EST 606 - 630 MHz*
F, GB, GR, H, I, IRL, L, LT 606 - 630 MHz*
NL, P, PL, S, SK, SLO 606 - 630 MHz*
DK, FIN, M, N *
HR, E, IRL, LV, RO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
22/25
K14 614-638 MHz
Shure Incorporated
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, EST 614 - 638 MHz*
F, GB, GR, H, I, IS, L, LT 614 - 638 MHz*
NL, P, PL, S, SK, SLO 614 - 638 MHz*
DK, FIN, M, N *
HR, E, IRL, LV, RO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
K14 614-638 MHz
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, EST 614 - 638 MHz*
F, GB, GR, H, I, IS, L, LT 614 - 638 MHz*
NL, P, PL, S, SK, SLO 614 - 638 MHz*
DK, FIN, M, N *
HR, E, IRL, LV, RO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
23/25
Q25 614-638 MHz
Shure Incorporated
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, EST 742 - 766 MHz*
F, GB, GR, H, I, IS, L, LT 742 - 766 MHz*
NL, P, PL, S, SK, SLO 742 - 766 MHz*
RO 742 - 743; 750 - 751; 758 - 759 MHz*
HR, E, IRL, LV, TR, DK, RIN, M, N *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
R12 796-806 MHz
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
N 796 - 806 MHz*
A, B, BG, CH, CY, CZ, D, DK, E, EST *
F, FIN, GB, GR, H, HR, I, IRL, IS, L, LT *
LV, M, NL, P, PL, S, SK, SLO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
24/25
S8 823-832 MHz
Shure Incorporated
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
BG, CH, D, DK, EST, F, FIN, IS, N, NL, S license free*
A, B, CY, CZ *
E, GB, GR, H, HR *
I, IRL, LV, L, LT, M, P, PL *
SK, SLO, RO, TR *
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
T11 863-865 MHz
Country Code
Code de Pays
Codice di paese
Código de país
Länder-Kürzel
Frequency Range
Gamme de frequences
Gamme di frequenza
Gama de frequencias
Frequenzbereich
A, B, BG, CH, CY, CZ, D, DK, E, EST license free
F, FIN, GB, GR, H, HR, I, IRL, IS, L, LT license free
LV, M, N, NL, P, PL, S, SK, SLO license free
TR 863 - 865 MHz*
* This equipment may be capable of operating on some frequencies not authorized in your region. See Licensing
Information.
25/25
Loading...
