Microflex® Microphones
THERE’S NEVER
BEEN A MORE
FLEXIBLE CHOICE.
Page 2
MICROFLEX® MICROPHONES: WORK A ROOM IN MORE WAYS THAN EVER.
Combining sleek, low profile aesthetics and a complete selection of microphones and mounting options,
Microflex microphones include the highest standard of quality and efficiency for installed audio applications.
Get the exact fit for your professional installation; knowing it’s backed by the superior sound quality, reliability,
and durability you only get from Shure.
The New Height
of Flexibility.
MX405/MX410/MX415
Modular Gooseneck
Microphones
Flexible in more ways than one,
Microflex Modular Gooseneck
microphones deliver unsurpassed style
and performance for conference rooms
and similar applications.
Offering desktop or mounted bases,
wired or wireless options, and even
interchangeable cartridges, it’s easy to
get the perfect fit for your conferencing
installation. Fully compatible with SLX®
wireless systems, including the SLX4L
wireless receiver with logic output for
applications requiring logic functionality.
•
Available in 5 inch (12.7 cm),
10 inch (25.4 cm) and
15 inch (38.1 cm) lengths
•
Cardioid and supercardioid
polar patterns
•
Bi-color status indicator
(standard models) or single
color light ring (“R” models)
•
Programmable mute switch
(desktop models only)
•
Logic input/output for remote
LED and mute control dependent
on base option
•
Surface-mount and wired
or wireless desktop base options
MX415, MX410 and MX405
with MX890 Wireless Desktop Base
MX405 (with MX400SMP), MX410 (with MX400DP),
MX415 without base
Available Models
MX405 C/S
5 inch (12.7 cm), includes surface mount preamp
MX405R N
5 inch (12.7 cm), includes light ring, surface mount preamp
MX405LP C/S
5 inch (12.7 cm), less preamp
MX405RLP N
5 inch (12.7 cm), light ring, less preamp
MX 410 C /S
10 inch (25.4 cm), includes surface mount preamp
MX 410R N
10 inch (25.4 cm), includes light ring, surface mount preamp
MX 410L P C /S
10 inch (25.4 cm), less preamp
MX 410RLP N
10 inch (25.4 cm), light ring, less preamp
MX 415 C /S
15 inch (38.1 cm), includes surface mount preamp
MX 415R N
15 inch (38.1 cm), includes light ring, surface mount pre amp
MX 415L P C /S
15 inch (38.1 cm), less preamp
MX 415RLP N
15 inch (38.1 cm), light ring, less preamp
Mounting Options
MX400DP
Desktop Base
MX890
Wireless Desktop Base
MX400SMP
Surface mount Pre amp
C = Cardioid, S = Supercardioid, N = No Cartridge
The MX890 Wireless Desktop Base is compatible
with SLX4 and SLX4L Wireless Receivers.
Page 3
Unmatched
Flexibility.
Unbending
Performance.
MX412/MX418
Standard Gooseneck
Microphones
Microflex Standard Gooseneck
microphones provide the added length
and flexibility needed for speakers in
environments like lecterns, pulpits,
and courtrooms. Available in four
models with a variety of heights and
mounting styles to choose from,
Microflex Gooseneck microphones
feature high sensitivity and balanced,
transformerless output for maximum
resistance to electromagnetic
hum and RF interference,
even over long cable runs.
•
Available in 12 inch (30.5 cm)
and 18 inch (45.7 cm) lengths
•
Interchangeable cartridges provide
the right polar pattern for every
application
•
Locking flange mount for
permanently securing
microphone to surfaces
•
Snap-fit foam windscreen
•
Shock mount provides over 20 dB
isolation from surface vibration noise
•
Models available with attached
preamp, in-line preamp, or
desktop base
Available Models
MX 412 C /S/ N
12 inch (30.5 cm), Attached Preamp
MX 412S C/ S/ N
12 inch (30.5 cm), Attached Preamp, Mute Switch
MX 412SE C /S /N
12 inch (30.5 cm), In-Line Preamp,
10 foot (3.0 m) Side-Exit Cable
MX 412D C/ S/ N
12 inch (30.5 cm), Desktop Base
with 10 foot (3.0 m) Cable
MX 418 C /S/ N
18 inch (45.7 cm), Attached Preamp
MX418S C/S/N
18 inch (45.7 cm), Attached Preamp, Mute Switch
MX418SE C/S/N
18 inch (45.7 cm), In-Line Preamp,
10 foot (3.0 m) Side-Exit Cable
MX 418D C/ S/N
18 inch (45.7 cm), Desktop Base
with 10 foot (3.0 m) Cable
C = Cardioid, S = Supercardioid, N = No Cartridge
MX412S
MX418D
Page 4
COMMSHIELD® TECHNOLOGY IMPROVES RF RESISTANCE.
All Microflex® models offer CommShield Technology, which guards against unwanted radio interference from consumer
wireless devices such as cell phones and PDA’s. Shure engaged their development teams to redesign Microflex
microphones to be highly resistant to radio frequency interference such as might be experienced with GSM cell phone
technology and to implement design techniques such as multilayer circuit boards, improved grounding techniques,
tighter enclosures for improved shielding, and improved microphone cable and audio connectors. The combination of
improved techniques is utilized to deliver Microflex microphones that are highly resistant to intense nearby radio signals.
Compact, Clear, and Connected.
MX391/MX392/MX393
Wired Boundary Microphones
With slim design and superior audio reproduction, Microflex Boundary microphones
are the ideal conference room solution. Features include programmable, silent
membrane switches, interchangeable cartridges, logic inputs and outputs, and LED
indicators – Microflex Boundary microphones provide high-quality sound for a wide
range of applications.
MX393
MX392
•
Cardioid, supercardioid and
omnidirectional polar patterns
•
Select models available in black or white
•
Programmable, silent membrane switch
•
TTL Logic LED input and
TTL Logic switch ouput (MX392 only)
•
LED indicator (MX392, MX393)
Available Models
MX 391 C /S/ O
Black Attached cable w/ 4-pin mini connector, Preamplier
MX 391W C/ S/O
White Attached cable w/ 4-pin mini connector, Preamplier
MX392 C/S/O
Surface-mount microphone, Attached unterminated cable
MX393 C/S/O
Surface-mount microphone, Mini 3-pin connector cable
C = Cardioid, S = Supercardioid, O = Omnidirectional
Inconspicuously Impressive.
MX395
Low Profile Boundary Microphone
The Microflex Low Profile Boundary microphone is an ideal table microphone when
minimal presence is of high priority. Perfect for meeting rooms, these microphones
deliver exceptional sound pickup while barely being noticed. Choose from a selection
of colors and pickup patterns for customized table and ceiling installations.
•
Only 1.25 inch (3.175 cm) in diameter
•
Cardioid, omni and bidirectional
polar patterns
•
Wide dynamic range and smooth
frequency response
•
Available in black, white and aluminum
•
Bi-color status indicator (select models)
•
TTL Logic LED input and
TTL Logic switch ouput
Available Models
MX395B C/O/BI
Black
MX395AL C/O/BI
Aluminum
MX395W O
White
MX395B O/C /BI-LED
Black, with bi-color status indicato
C = Cardioid, O = Omnidirectional, BI = Bidrectional
MX391
Side view
Page 5
One Microphone That Performs Like Many.
MX396
Multi Element Boundary Microphone
The Microflex Multi-Element Boundary microphone delivers a unique and versatile tool for
conference room installations. Clean and simple in appearance, Multi-Element Boundary
mics come in two or three element configurations, combining the coverage of multiple
microphones into one small, compact package.
•
Multiple coverage patterns
(see diagram below)
•
Individual audio output for each element
•
Bi-color status indicator
•
Programmable mute switch
•
TTL Logic LED input and
TTL Logic switch ouput
Available Models
MX396 C-DUAL
Dual-Element Conguration
MX396 C-TRI
Tri-Element Conguration
Side view
Example of Boardroom Table Mic Placement Coverage
Wireless. Limitless.
MX690
Wireless Boundary Microphone
The Microflex Wireless Boundary microphone offers total freedom of placement with
no holes to drill or cables to run for installation. It is the perfect solution for conference
and meeting spaces where users demand flexibility and high performance. Compatible
with Shure SLX
applications requiring logic functionality.
•
Sleek, low profile design
•
Frequency agile, microprocessor
controlled transmitter
•
Bi-color status indicator
•
IR link to SLX receiver for automatic frequency synchronization
•
Programmable mute function
•
Battery level indicator
•
Operates on two AA batteries
•
TTL Logic transmitter status and TTL Logic battery level signal
when used with SLX4L wireless receiver
®
wireless systems, including the SLX4L receiver with logic output for
Available Models
MX690
Wireless Boundary Mic, Cardioid
Cross-Table
Coverage (Dual)
Front view Side view
End-of-Table
Coverage (Tri)
Center-of-Table
Coverage (Tri)
Page 6
A Microphone
That Goes Above
and Beyond.
MX202
Overhead Microphones
Microflex® Overhead microphones
capture sound from speakers,
choirs, and stages conveniently and
unobtrusively from above. Compact
and flexible, each feature a four-inch
gooseneck and versatile condenser
cartridges for accurate sound
reproduction in any setting. The
available preamp options offer easy
installation in ceilings or microphone
stands, and provide accurate, reliable
sound reproduction.
•
Cardioid and supercardioid
polar patterns
•
Interchangeable condenser cartridges
•
Inline or plate mount preamp
•
Optional desk stand also available
Freedom To Move, Freedom To Hear.
MX150
MX183/MX184 /MX185
Lavalier Microphones
Available Models
MX202B C/S/N
Black In-line preamplier, stand adapter
MX202W C/S/N
White In-line preamplier, stand adapter
MX202BP C/S/N
Black Plate-mounted preamplier
MX202WP C/S/N
White Plate-mounted preamplier
Mounting Options
A202BB
Microphone Desk/Table Stand
C = Cardioid, S = Supercardioid, N = No Cartridge
Attached to a tie or lapel, Microflex Lavalier microphones offer freedom of movement
to any situation involving voice reproduction. As stylish as they are convenient,
lavaliers are available in a wide array of sizes, including two subminiature microphone
models, and are compatible with all Shure wireless platforms.
•
Cardioid, supercardioid and omnidirectional polar patterns
•
Phantom-powered preamp
•
Exceptionally low handling noise
•
Includes tie clip, dual tie clip and snap-fit windscreen
MX15 0/O MX183/184/185
Available Models
MX150/O
Subminiature Omnidirectional
MX150/C
Subminiature Cardioid
MX180/N
No Cartridge
MX183
Omnidirectional
MX184
Supercardioid
MX185
Cardioid
Page 7
Low Profile,
THE SOUND HEARD
High Reliability.
MX153
Earset Headworn Microphone
The Shure Microflex® MX153 is a professional subminiature
earset microphone ideal for speech and other applications
requiring low-profile discreet placement where improved
gain before feedback over lavalier microphones is desired.
Delivering exceptional speech clarity, the MX153 is ideal for
corporate presentations, houses of worship, A/V conferencing
and live sound reinforcement.
•
Subminiature, omnidirectional cartridge offers superior
speech clarity
•
Ultra-lightweight, comfortable, flexible design is easy to
place over either ear
•
Kevlar reinforced, soft flex cable
•
Matte Black, Tan, and Cocoa color options available
MX153 in Black, C ocoa, Tan
Available Models
MX153/BO-TQG
Black
MX153/CO-TQG
Cocoa
MX153/TO-TQG
Tan
AROUND THE WORLD.
Shure has long been the global leader in providing audio
solutions for all types of commercial installations. Whether
in churches, schools, boardrooms, or courtrooms, you’ll
find Microflex microphones providing superior audio and
Shure’s world-class service and support.
Utilized for everything from
auditoriums to band rooms,
Microflex microphones have
delivered exceptional audio
quality to the hallowed halls
of academia for years. By
providing the educational
institutions of the world
with exceptional quality products, Shure tirelessly commits
themselves to delivering unparalleled service and support.
Microflex microphones
have adorned the podiums
and committee rooms of
government institutions
around the world. From
lavaliers to overheads
to goosenecks, Shure
audio products deliver
exceptional sound and afford maximum flexibility in even
the most acoustically challenging environments.
Proven reliable in
installations worldwide,
Microflex microphones
are well suited to meet the
diverse audio requirements
of any House of Worship.
Ideal for choirs, lecterns,
and altars, all Microflex
products are both attractive and inconspicuous and deliver
the superior sound quality you can expect from Shure.
Microflex microphones
provide solutions for
meeting rooms, video
conferences, large
presentations or any other
situation the business world
throws at you. Gooseneck
mics meet the needs of any
size conference table while low-profile boundary mics are discreet
and unobtrusive yet provide crystal clear audio. Additionally,
CommShield
™
technology guards against unwanted interference.
Page 8
Technical Specifications Subject to change
MICROFLE X
Lavalier/Headset
Microphones
Typ e Condenser
Frequency Response MX185 /184/ 183:
Output Impedance MX185 /184/ 183:
Sensitivity
(at 1 kHz,
open circuit voltage)
Maximum SPL
(1 kHz at 1% THD,
1 k load)
(electret bias )
50–17000 Hz
MX150: 20–20000 Hz
MX153: 20–20000 Hz
EIA rated at 150 Ω
(170 Ω actual)
MX150: 165.5 Ω
MX15 3: N/A
MX183: -27.5 dB V/Pa
(42.2 mV)
MX184: -3 3.5 dB V/Pa
(21.1 mV)
MX185: -35.0 dB V/Pa
(17. 8 mV)
MX150: -3 9.0 dB V/Pa
MX153: -41.0 dB V/Pa
All settings -12 dB at 0 gain
1 Pascal = 94 dB SPL
MX183: 132.8 dB
MX184: 138.8 dB
MX185: 140.3 dB
MX150: 129. 5 dB
MX153: 107 dB
All settings +6 dB at 0 gain
MX200
Overhead Microphones
Condenser
(electret bias )
50–17000 Hz 50–17000 Hz 50–17000 Hz 50–17000 Hz 50–17000 Hz
180 Ω actual
(EIA rated at 150 Ω)
Cardioid:
-35.0 dB V/Pa (17.8 mV)
Supercardioid:
-33.5 dB V/Pa (21.1 mV)
Omnidirectional:
-27.5 dB V/Pa (42.2 mV)
All values -12 dB at 0 gain
1 Pascal = 94 dB SPL
Cardioid: 124.2 dB
Supercardio id: 122.7 dB
Omnidirectional: 116.7 dB
MX391/392/393
Boundary Microphones
Condenser
(electret bias )
EIA Rated at 150 Ω
(180 Ω actual)
MX391 Cardioid:
-29.6 dB V/Pa (33.5 mV)
MX391 Supercardioid:
-28.3 dB V/Pa (38.5 mV)
MX391 Omnidirect ional:
-21.5 dB V/Pa (81.4 mV)
MX392/393 Cardioid:
-27.5 dB V/Pa (42.2 mV)
MX392/393 Supercardioid:
-26.5 dB V/Pa (47.3 mV)
MX392/393
Omnidirectional:
-22.0 dB V/Pa (79.4 mV)
1 Pascal = 94 dB SPL
Cardioid: 118.8 dB
Supercardioi d: 117.5 dB
Omnidirectional: 110.7 dB
MX395/396
Boundary Microphones
Condenser
(electret bias )
EIA Rated at 150 Ω
(170 Ω actual)
MX395 Cardioid:
–34 dB V/Pa (20 mV)
MX395 Omnidirectional:
–29 dB V/Pa (35.5 mV)
MX395 Bidirectional:
–35 dB V/Pa (17.8 mV)
MX396:
–35 dB V/Pa (18 mV)
1 Pascal = 94 dB SPL
MX395
Cardioid: 120 dB
MX395
Omnidirectional: 115 dB
MX395
Bidirectional: 121 dB
MX39 6: 122 dB
MX400
Gooseneck Microphones
Condenser
(electret bias )
EIA Rated at 150 (170
actual, MX405/410/415 )
(180 actual, MX412/418 )
Cardioid:
–35 dB V/Pa (17.8 mV)
Supercardioid:
–33.5 dB V/Pa (21.1 mV )
Omnidirectional:
-27.5 dB V/Pa (42.2 mV )
1 Pascal= 94 dB SPL
MX 40 5/ 410/415:
Cardioid wit h MX400 SMP:
121.1 dB
Cardioid wit h MX400 DP:
122 dB
Supercardioid: with
MX400SMP:
119.7 dB
Supercardioid: with
MX400DP:
120.5 dB
MX 412 /418 :
Cardioid:
124.2 dB
Supercardioid:
122.7 dB
Omnidirectional:
116.7 dB
MX690
Boundary Microphone
Condenser
(electret bias )
EIA Rated at 150 Ω
(180 Ω actual)
–33 dB V/Pa (33 mV)
1 Pascal= 94 dB SPL
118. 8 dB
For complete specications
on the MX690 and MX890
wireless transmitters, please
visit www.shure.com.
Equivalent
Output Noise
(A-weighted)
Signal-to-Noise Ratio
(referenced at
94 dB SPL at 1 kHz)
Dynamic Range
(1 k load at 1 kHz)
Power Requirements 11–52 Vdc phantom,
MX183: 23.7 dB SPL
MX184: 29.7 dB SPL
MX185: 31.2 dB SPL
MX150: 31.0 dB SPL
MX153: 24.9 dB SPL
MX183: 70. 3 dB
MX184: 6 4.3 dB
MX185: 62.8 dB
MX150: 57.5 dB
MX153: 60.0 dB
MX185 /184/ 183:
109.1 dB
MX150: 92.5 dB
MX153: 73.0 dB
100 dB at 0 gain
2.0 mA or 9V bat tery 0.8mA
Cardioid:
28.0 dB SPL
Supercardioid:
26.5 dB SPL
Omnidirectional:
20.5 dB SPL
Cardioid: 66 .0 dB
Supercardioi d: 67.5 dB
Omnidirectional: 73.5 dB
96.2 dB (100 dB at 0 gain) 96.2 dB MX395 Cardioid:
11 to 52 Vdc phantom,
2.0 mA
United States, Canada,
Latin America, Caribbean:
Shure Incorporated
5800 West Touhy Avenue
Cardioid:
22.6 dB SPL
Supercardioid:
21.3 dB SPL
Omnidirectional:
14.5 dB SPL
Cardioid: 71.4 dB
Supercardioi d: 72.7 dB
Omnidirectional: 79.5 dB
11–52 Vdc phantom,
2.0 mA
MX395 Cardioid:
29 dB SPL
MX395 Omnidirectional:
23 dB SPL
MX395 Bidirectional:
27 dB SPL
MX396: 30 dB SPL
MX395 C ardioid: 65 dB
MX395 Omnidirectional:
72 dB
MX395 Bidirectional: 67 dB
MX396: 64 dB
91 dB
MX395 Omnidirectional:
92 dB
MX395 Bidirectional: 95 dB
MX396: 92 dB
MX395: 11–52 Vdc
phantom, 2.0 mA
MX395 -LED: 48–52 Vdc
phantom, 8.0 mA
MX396: MX396/C-DUAL:
48–52 Vdc phantom,
10.0 mA
MX396/C-TRI: 48 –52 Vdc
phantom, 12.0 mA
Europe, Middle East, Africa:
Shure Europe GmbH
Jakob-Dieffenbacher-Str. 12,
75031 Eppingen, Germany
Niles, IL 60714-4608 USA
Phone: 847-600-2000
Fax: 847-600-1212 (USA)
Fax: 847-600-6446
Phone: 49-7262-92490
Fax: 49-7262-9249114
Email: [email protected]
Email: [email protected]
Cardioid:
28 dB SPL
Supercardioid:
26.5 dB SP L
Omnidirectional:
20.5 dB SPL
Cardioid: 66 dB
Supercardioi d: 67.5 dB
Omnidirectional: 73.5 dB
MX 40 5/ 410/415: C ardi oid
with MX4 00SMP: 93.1 dB
Cardioid wit h MX400 DP:
94 dB Supercardioid with
MX40 0SMP: 93.2 dB
Supercardioid with
MX40 0DP: 94 dB
MX412/418: 96.2 dB
100 dB at 0 gain
MX 40 5/ 410/415:
48–52 Vdc phantom,
8.0 mA
MX 412 /418 :
11–52 Vdc phantom,
8.0 mA
22.6 dB SPL
71.4 dB
96.2 dB
3V (2 AA alkaline or
rechargeable batteries)
Asia, Pacic:
Shure Asia Limited
22/F, 625 King’s Road
North Point, Island East
Hong Kong
Phone: 852-2893-4290
Fax: 852-2893-4055
Email: [email protected]
www.shure.com
©2012 Shure Incorporated
AL20244 2.5K 04/12
Loading...
